Search Results (101)

Field measurements of ground vibrations were conducted along the Paris–Brussels high-speed railway (HSR) to systematically analyze vibration characteristics generated by embankment and cutting sections. Utilizing the 2.5D finite element method (FEM), numerical models were developed for both earthworks to evaluate the influences of design parameters on ground vibration responses. Results demonstrate that train axle load dominates vibration amplitude in the near-track zone, while the superposition effect of adjacent wheelsets and bogies becomes predominant at larger distances. Vibration energy attenuates progressively with increasing distance from the track, with medium- and high-frequency components decaying more rapidly than low-frequency components. The dominant vibration frequency is determined by the fundamental train-loading frequency (f₁), which increases with train speed. Distinct attenuation patterns are identified between earthwork types: embankments exhibit a two-stage attenuation process, whereas cuttings undergo three stages, including a vibration rebound phenomenon at the slope crest. Furthermore, greater embankment height or cutting depth reduces ground vibrations, but beyond a critical threshold, further increases yield negligible benefits. A higher elastic modulus of the embankment material correlates with reduced vibrations, and steeper cutting slopes, while ensuring slope stability, contribute to additional mitigation. Full article

This study examines the modernization of the 61-4179 TVZ passenger coach for transporting light automobiles up to 3 tons, addressing the efficiency of multifunctional rail use. The objective was to assess how additional mass–dimensional loading influences strength, load distribution, and the dynamic stability of the vehicle–track system. Finite element simulations in ANSYS Workbench 2021 R2 determined stress distribution, deformations, and safety margins, while multibody dynamics modeling in Universal Mechanism evaluated wheel–rail contact forces, carbody accelerations, and stability coefficients. Field tests on curves with radii of 350 m and 300 m at 60 km/h validated the models. Carbody accelerations were 0.65–0.68 m/s², below the 0.7 m/s² regulatory limit; wheelset attack angles remained under 0.01 rad; and derailment safety coefficients were 1.6–1.8, all meeting international standards. Uniform load distribution maintained stability and suppressed oscillations. However, critical scenarios (wheel wear, extreme flange clearance, higher speeds) produced parameters approaching threshold values. To mitigate risks, clearance adjustment per δ₀ standards, a 1:20 guard-rail inclination, and optimized crossing profiles are proposed. These measures reduced lateral dynamic forces by 12–15% and raised the strength coefficient by 1.2–1.3. The results confirm technical feasibility, operational safety, and extended service life, supporting sustainable multimodal transport development. Full article

For urban rail vehicles operating at speeds ranging from 60 to 250 km/h, the dominant source of radiated noise is the wheel–rail interaction. Finite element modal analysis was conducted on the wheelset, rails, and track slab. A multibody dynamics model under straight-line condition was established. It was a rigid–flexible coupling dynamics model, including the rigid vehicle body, flexible wheelsets, flexible rails, and flexible track slabs. Dynamic simulation calculations were carried out in this model to obtain the wheel–rail forces. The finite element and boundary element models of wheels and rails were established using simulation software to obtain the results of wheel–rail noise. The sound pressure levels on the surfaces of wheels and rails were calculated under the operating conditions of 120 km/h, 140 km/h, 160 km/h, and 200 km/h in the straight-line condition. The variation law of the frequency distribution of wheel–rail noise with the change in speed was obtained. The variation fitting function of wheel–rail noise SPL with speeds was obtained. Within the speed of 200 km/h, as the speed increased, the total value of wheel–rail SPL basically shows a linear growth. The simulation analysis results were compared with the experiment results. It indicated that the simulation results were reasonable. The simulation models are of great significance for the noise prediction in train design and manufacturing. Full article

In this paper, the rail mean vertical alignment is estimated through double integration of wheel–rail contact forces measured using dynamometric wheelsets on a dedicated track recording vehicle (TRV). A simplified three degrees of freedom (DOF) linear model of half a train coach has been developed for this purpose. The model’s ability to simulate the average left and right longitudinal level has been tested using vertical contact force recordings from a constant speed track section, as measured by the TRV. The results are compared with available track geometry (TG) data, recorded by the optical system of the same vehicle, used for condition monitoring of the Italian railway infrastructure. Model parameters, such as masses, stiffness, and damping of the suspensive system have been optimized. An error analysis has been conducted on results. A good agreement is found between simulated and recorded vertical alignment at the D1 level, suggesting the feasibility of using contact forces measured with instrumented wheelsets for railway TG condition monitoring. This computationally efficient approach highlights the potential of strain gauges and instrumented wheelsets as alternative or complementary technologies to the widely adopted accelerometers, rate gyros, and optical devices for railway condition monitoring. Given its low computational cost, embedded and real-time TG estimation could be further investigated. Full article

Accurate online inspection of train wheelset tread defects is challenging owing to the variety and position uncertainty of defects. This study develops an improved YOLOv7 model capable of inspecting various wheelset tread defects with high accuracy and low computation complexity. This model comprises GSConv, a small target enhancement (STE) module, and StyleGAN3. GSConv significantly reduces the model volume while maintaining the feature expression ability, achieving a lightweight structure. The STE module enhances the fusion of shallow features and distribution of attention weights, significantly improving the sensitivity to small-sized defects and positioning robustness. StyleGAN3 enhances small samples by addressing inhomogeneity, thereby generating high-quality defect samples; it overcomes the limitations of traditional amplification methods regarding texture authenticity and morphological diversity, systematically improving the model’s generalization ability under sample scarcity conditions. The model achieves 1.6%, 10.7%, 48.63% and 37.97% higher mean average precision values than YOLOv7, YOLOv5, SSD, and Faster R-CNN, respectively, and the model parameter size is reduced by 73.91, 94.69, 122.11, and 154.91 MB, respectively. Hence, the proposed YOLOv7-STE model outperforms traditional models. Moreover, it demonstrates satisfactory performance in detecting small target defects in different samples, highlighting its potential applicability in online wheel tread defect inspection. Full article

Undetected cracks in railroad wheels pose significant safety and economic risks, while current inspection methods are limited by cost, coverage, or contact requirements. This study explores the use of passive, air-coupled ultrasonic acoustic (UA) sensors for detecting wheel damage on stationary or moving wheels. Two controlled datasets of wheelsets, one with clear damage and another with early, service-induced defects, were tested using hammer impacts. An automated system identified high-energy bursts and extracted features in both time and frequency domains, such as decay rate, spectral centroid, and entropy. The results demonstrate the effectiveness of UAE (ultrasonic acoustic emission) techniques through Kernel Density Estimation (KDE) visualization, hypothesis testing with effect sizes, and Receiver Operating Characteristic (ROC) analysis. The decay rate consistently proved to be the most effective discriminator, achieving near-perfect classification of severely damaged wheels and maintaining meaningful separation for early defects. Spectral features provided additional information but were less decisive. The frequency spectrum characteristics were effective across both axial and radial sensor orientations, with ultrasonic frequencies (20–80 kHz) offering higher spectral fidelity than sonic frequencies (1–20 kHz). This work establishes a validated “ground-truth” signature essential for developing a practical wayside detection system. The findings guide a targeted engineering approach to physically isolate this known signature from ambient noise and develop advanced models for reliable in-motion detection. Full article

A physics-based vehicle–track coupled dynamic model embedding a hydraulic electromechanical regenerative damper (HERD) is developed to quantify electrical power recovery and wear depth in high-speed service. The HERD subsystem resolves compressible hydraulics, hydraulic rectification, line losses, a hydraulic motor with a permanent-magnet generator, an accumulator, and a controllable; co-simulation links SIMPACK with MATLAB/Simulink. Wheel–rail contact is computed with Hertz theory and FASTSIM, and wear depth is advanced with the Archard law using a pressure–velocity coefficient map. Both HERD power regeneration and wear depth predictions have been validated against independent measurements of regenerated power and wear degradation in previous studies. Parametric studies over speed, curve radius, mileage and braking show that increasing speed raises input and output power while recovery efficiency remains 49–50%, with instantaneous electrical peaks up to 425 W and weak sensitivity to curvature and mileage. Under braking from 350 to 150 km/h, force transients are bounded and do not change the lateral wear pattern. Installing HERD lowers peak wear in the wheel tread region; combining HERD with flexible wheelsets further reduces wear depth and slows down degradation relative to rigid wheelsets and matches measured wear more closely. The HERD electrical load provides a physically grounded tuning parameter that sets hydraulic back pressure and effective damping, which improves model accuracy and supports calibration and updating of digital twins for maintenance planning. Full article

This study presents a novel design for emulating wheelset curving dynamics by implementing a laterally constrained wheelset and two independently powered rollers. The new configuration extends the test capability of the existing Virginia Tech-Federal Railroad Administration (VT-FRA) roller rig from a single wheel to a wheelset (i.e., two wheels). The redesigned rig is intended for evaluating both the tangent track and curving dynamics of a wheelset on a railcar. Test data from earlier experiments with a single wheelset is analyzed to assess the control system’s ability to maintain the commanded roller speed. This evaluation determines whether the new system can accurately emulate curves. The study develops correction factors to account for the dissimilar contact patch sizes and longitudinal creep forces resulting from the dissimilar roller diameters. A novel force measurement method is proposed to resolve the creep forces at each contact patch independently. An assessment of the existing VT-FRA roller rig data indicates a maximum roller speed deviation of 0.37% from actual values, which is deemed to be within the intended accuracy for future tests with the redesigned rig. An analysis of the force measurements by a load platform demonstrates the feasibility of accurately determining the wheel–rail contact forces for the new design rig, identical to the original design. Despite the numerous challenges in integrating a new wheel and roller into the existing VT-FRA roller rig, the study demonstrates that such a redesign can be achieved within the space and kinematic constraints, while maintaining the intended measurement accuracy. Full article

Heavy machinery degrades agricultural soils, with severity influenced by wheel type, contact area, and soil moisture. Tropical agriculture is characterized by the constant maintenance of straw on the ground. This permanent cover, among other benefits, can mitigate the stress imposed by wheels on the physical structure of the soil. This study aimed to evaluate the effect of tire types and straw amounts on soil stresses. Static studies were carried out under controlled conditions in a static tire test unit (STTU), equipped with standardized sensors and systems that simulated real farming conditions. Three tire models were tested: road truck double wheelset—2 × 275/80R22.5 (p1); agricultural radial tire—600/50R22.5 (p2); and bias-ply tire—600/50-22.5 (p3) on four contact surfaces (rigid surface; bare soil; soil with 15 and 30 Mg ha⁻¹ straw cover). We performed comparative statistical tests and subsurface stress simulations for each tire and surface condition. On the hard surface, the contact areas were 4.7 to 6.8 times smaller than on bare soil. Straw increased the tire’s contact area, reducing compaction and subsoil stresses. Highest pressure was imposed by the road tire (p1) and lowest by the radial tire (p2). Adding 15 Mg ha⁻¹ of straw reduced soil SPR by 18%, while increasing it to 30 Mg ha⁻¹ led to an additional 8% reduction. Tire selection and effective straw management improve soil conservation and agriculture sustainability. Full article

This study investigates the dynamic interaction between railway vehicles and tracks, focusing on the effects of elastic–viscous properties of spring suspensions and track inertia. This research examines vertical oscillations of a railway car moving on a non-uniformly elastic track, modeled as a system with lumped parameters. Analytical and numerical methods are employed to derive track parameters by comparing frequency characteristics of continuous and discrete models. Key findings reveal that adjacent wheelsets influence interaction forces and bending moments by approximately 10%, while rail deflections are affected by up to 20% within the speed range of 60–180 km/h and for disturbances up to 20 Hz. Experimental validation using a roller test rig confirms the theoretical predictions, demonstrating the significance of track inertia and damping in dynamic analyses. This study provides practical recommendations for improving railway vehicle design and track maintenance, emphasizing the need to account for nonlinearities and inertial effects in high-speed scenarios. Full article

The gear-transmission system plays a crucial role in power transmission for urban railway vehicles. However, it can experience abnormal meshing conditions due to wheel polygonization, which presents a potential safety hazard for vehicle operations. To address this issue, the present study develops a dynamic model of an urban railway vehicle that integrates the gear-transmission system, simulating the effects of wheel polygonization on its dynamic behavior. The simulation results reveal that as the amplitude of wheel polygonization and vehicle speed increase, the vertical wheel–rail force, gear-meshing force, and dynamic transmission error (DTE) escalate. Furthermore, an increase in the order of wheel polygonization leads to a rise in the vertical wheel–rail force. In contrast, the gear-meshing force and DTE exhibit distinct trends at different speeds. At a speed of 20 km/h, these parameters increase by 51.34% and 0.29%, respectively. As the speed increases, the peaks of gear-meshing force and DTE occur at the 7th-order and 3rd-order polygon, respectively, suggesting that the dynamic response of the gear-transmission system becomes more sensitive to lower-order polygon effects at higher speeds, which necessitates greater attention during operation. Additionally, the phase difference of wheel polygonization exerts a significant influence on gear-meshing force under various conditions, such as in-phase, out-of-phase, 60° phase difference, and 120° phase difference. Therefore, in engineering applications, it is essential to consider the phase difference of wheel polygonization to alleviate excessive gear-meshing forces and ensure stable transmission performance. The findings of this paper offer insights into the dynamic evaluation and wheelset re-profiling of gear-transmission systems in urban railway vehicles. Full article

A reduction of forces acting between the railway track and the vehicle is one of the key issues in the design of modern rolling stock. Because the capabilities of reducing wheel–rail contact forces in track curves by conventional methods are encountered at their limits, innovative approaches in the design of vehicle suspension and wheelset guidance occur. Among them, an active wheelset steering appears to be very promising. However, an active wheelset steering system is rather complicated and expensive and raises many safety issues. Therefore, a passive hydraulic system that links longitudinal motions of axle boxes is proposed. The system is relatively simple and, compared to the active wheelset steering, does not need any energy supply or sensor system for the detection of a track shape. Two arrangements of the hydraulic system had been proposed and implemented in a simulation model. The simulation model is based on a cosimulation of two separate models, a multibody model of an electric locomotive, and a model of the hydraulic system. The goal of this study is to evaluate the contribution of the hydraulic system to the natural radial alignment of wheelsets in curves and thus to reduce the wear of wheels and to determine the parameters of the hydraulic system to maximize the wear reduction benefits while minimizing a decrease in critical speed. Simulations of a vehicle running in various scenarios, including a run in a real track section of a length of 20 km, have been performed. As a criterion for the wear of wheels and rails, a T-gamma wear number was used, from which a sum of frictional work in wheel–rail contacts was calculated. The results of the simulations and the comparison of hydraulic axle box connection systems and a standard locomotive are presented and discussed in the paper. The results obtained confirmed a significant potential benefit of the proposed hydraulic system in reducing wheel wear on curved tracks. Full article

This paper addresses the issue of wheelset slip in trains caused by low-adhesion track surfaces and proposes an active anti-slip tracking control strategy. Considering the wide operational range of trains and the complex adhesion conditions between wheels and rails, a comprehensive model of the train, incorporating adhesion effects, is developed and then transformed into a mathematical model with perturbations. To tackle the slip phenomenon on low-adhesion track surfaces, a robust adhesion observer with high dynamic accuracy is designed. Building on this, an active anti-slip strategy is proposed to ensure that the control command does not exceed the maximum traction force available from the track surface. To further enhance controller performance, higher-order sliding mode control is integrated with a saturation compensation law. Finally, a Hardware-in-the-Loop (HIL) platform is constructed using a Digital Signal Processor (DSP) controller and a Modular Test (MT) PXI real-time simulator. The simulator loads the adhesion model, while the DSP controller executes the designed anti-slip control algorithm. Experimental results demonstrate that the proposed controller effectively prevents wheelset slip under low-adhesion conditions and significantly reduces tracking errors along the target speed-displacement curve. Full article

This paper aims to present a hybrid steering control method combining the self-guidance capability of a wheelset and fuzzy logic controller (FLC), which were applied to our new micro-autonomous railway inspection vehicle, enhancing the vehicle’s stability. The vehicle features intelligent inspection systems and a suspension system with variable damping capability that uses smart magnetorheological fluid to control vertical oscillations. A mathematical model of the steering dynamic system was developed based on the vehicle’s unique structure. Two simulation models of the vehicle were built on Simpack and Simulink to evaluate the lateral dynamic capability of the wheelset, applying Hertzian normal theory and Kalker’s linear theory. The hybrid steering control was designed to adjust the torque differential of the two front-wheel drive motors of the vehicle to keep the vehicle centered on the track during operation. The control simulation results show that this hybrid control system has better performance than an uncontrolled vehicle, effectively keeps the car on the track centerline with deviation below 10% under working conditions, and takes advantage of the natural self-guiding force of the wheelset. In conclusion, the proposed hybrid steering system controller demonstrates stable and efficient operation and meets the working requirements of intelligent track inspection systems installed on vehicles. Full article

When a railway train runs along a curved track with braking, the dynamic behaviors of the vehicle are extremely complex and difficult to accurately reveal due to the coupling effects between the wheel–rail interactions and the disc–pad frictions. Therefore, a rigid–flexible coupled trailer car dynamics model of a railway train is established. In this model, the brake systems and vehicle system are dynamically coupled via the frictions within the braking interface, wheel–rail relationships and suspension systems. Furthermore, the effectiveness of the established model is validated by a comparison with the field test data. Based on this, the dynamic response characteristics of vehicle under curve and straight braking conditions are analyzed and compared, and the influence of the curve geometric parameters on vehicle vibration and operation safety is explored. The results show that braking on a curve track directly affects the vibration characteristics of the vehicle and reduces its operation safety. When the vehicle is braking on a curve track, the lateral vibration of the bogie frame significantly increases compared to the vehicle braking on a straight track, and the vibration intensifies as the curve radius decreases. When the curved track maintains equilibrium superelevation, the differences in primary suspension force, wheel–rail vertical force, and wheel axle lateral force between the inner and outer sides of the first and second wheelsets are relatively minor under both straight and curved braking conditions. Additionally, under these circumstances, the derailment coefficient is minimized. However, when the curve radius is 7000 m, with a superelevation of 40 mm, the maximum dynamic wheel load reduction rate of the inner wheel of the second wheelset is 0.54, which reaches 90% of the allowable limit value of 0.6 for the safety index, and impacts the vehicle running safety. Therefore, it is necessary to focus on the operation safety of railway trains when braking on curved tracks. Full article
