To investigate how severe wear at No. 12 turnout frogs in an urban rail transit line operating at speeds over 120 km/h on the dynamic performance of the vehicle, a vehicle–frog coupled dynamic model was established by employing the 2021 version of SIMPACK software. Profiles of No. 12 alloy steel frogs and metro wheel rims were measured to simulate wheel–rail interactions as the vehicle traverses the turnout, using both brand-new and worn frog conditions. The experimental results indicate that increased service life deepens frog wear, raises equivalent conicity, and intensifies wheel–rail forces. When a vehicle passes through the frog serviced for over 17 months at the speed of 120 km/h, the maximum derailment coefficient, lateral acceleration of the car body, and lateral and vertical wheel–rail forces increased by 0.14, 0.17 m/s², 9.52 kN, and 105.76 kN, respectively. The maximum contact patch area grew by 35.73%, while peak contact pressure rose by 236 MPa. To prevent dynamic indicators from exceeding safety thresholds and ensure train operational safety, it is recommended that the frog maintenance cycle be limited to 12 to 16 months. Full article

Wheel polygonal wear of metro deteriorates the vibration environment of the vehicle system, potentially leading to resonance-induced fatigue failure of components. This poses serious risks to operational safety and increases maintenance costs. To address the adverse effects of wheel polygonal wear, dynamic tracking tests and numerical simulations were conducted. The modal analysis focused on the vehicle–track coupling system, incorporating various track structures to explore the formation mechanisms and key influencing factors of polygonization. Test results revealed dominant polygonal wear patterns of the seventh to ninth order, inducing forced vibrations in the 50–70 Hz frequency range. These frequencies closely match the P2 resonance frequency generated by wheel–rail interaction. When vehicle–track coupling is considered, the track’s frequency response shows multiple peaks within this range, indicating susceptibility to resonance excitation. Additionally, rail joint irregularities act as geometric excitation sources that trigger polygonal development, while the P2 force resonance mode plays a critical role in its amplification. Full article

The Dujiangyan–Siguniangshan mountain rack railway project is China’s first mountain rail transit. Most of its lines are located in mountainous areas and close to natural ecological protection areas, which have strict restrictions on the vibration and noise of train operation. At the same time, the vibration of mountain rack railway trains is also an important factor affecting the safety and riding comfort of trains. However, due to the multi-source vibration of gear teeth, wheels, rails, and suspensions, it is difficult to clearly define the vibration characteristics and vibration transmission path of the train, which has a serious impact on its vibration noise suppression and optimization. To this end, this study proposed a set of evaluation methods for the vibration characteristics and transfer paths of mountain rack trains based on a combination of dynamics and operational transfer path analysis (OTPA). Considering the interaction between the dynamic behaviors of the primary and secondary suspensions, the gear tooth contact behavior, the wheel–rail contact behavior and the dynamic behaviors of the track system, a dynamic model of a mountain rack train based on the finite element method was established, and the effectiveness of the model was verified through field experiments. On this basis, the OTPA method was used to establish a vibration transfer path model between the secondary suspension and the center of mass of the car body, and it was used to analyze the vibration mechanism and transfer path of the train body at the rated speed (20 km/h) and the limited speed (30 km/h). This study is of great significance for suppressing the vibration noise of mountain rack trains, reducing the impact on the ecological environment and improving ride comfort. Full article

Epidemiological analysis has revealed key insights into the frequency, severity, and circumstances surrounding subway-to-pedestrian incidents; however, there remains a lack of available impact test data specific to this impact type that can be used in modelling and countermeasure design studies. To address this gap, nine controlled impact tests were conducted using a cylindrical headform to derive force–penetration relationships for foam, as well as foam encased in 1 mm aluminium or 3 mm ABS shells. These relationships were validated in MADYMO multibody simulations. Building on a previous multibody computational study of subway-to-pedestrian collisions this research evaluates three passive countermeasure designs using a reduced simulation test matrix: three impact velocities (8, 10, and 12 m/s) and a trough depth of 0.75 m. In subway collisions, due to the essential rigidity of a subway front relative to a pedestrian, it is the pedestrian stiffness characteristics that primarily dictate the contact dynamics, as opposed to a combined effective stiffness. However, the introduction of energy-absorbing countermeasures alters this interaction. Results indicate that modular energy-absorbing panels attached to the train front significantly reduced the Head Injury Criterion (HIC) (by 90%) in the primary impact and pedestrian-to-wheel contact risk (by 58%), with greater effectiveness when a larger frontal area was covered. However, reducing primary impact severity alone did not substantially lower total fatal injury risk. A rail-guard design, used in combination with frontal panels, reduced secondary impact severity and led to the largest overall reduction in fatal injuries. This improvement came with an expected increase in hospitalisation-level outcomes, such as limb trauma, reflecting a shift from fatal to survivable injuries. These findings demonstrate that meaningful reductions in fatalities are achievable, even with just 0.5 m of available space on the train front. While further development is needed, this study supports the conclusion that subway-to-pedestrian fatalities are preventable. Full article

Hollow wear on wheels is a common form of surface damage often observed in high-velocity vehicles. It is widely recognized that hollow wear of the wheel tread degrades the dynamic performance of rail vehicles, especially in the issue commonly referred to as “operational stability”, and leads to abnormal wheel–rail contact interactions. However, the evaluation criteria for vehicle stability are not uniform, which affects the assessment of wheel conditions and the timing of wheel re-profiling during maintenance. Therefore, numerical simulations were conducted by matching the measured worn wheel profiles with standard rails, and three different methods were employed to evaluate vehicle stability in this article. The numerical results revealed that the wheel equivalent conicity exhibits a nonlinear characteristic caused by hollow wear, which means that the nominal equivalent conicity is unable to accurately represent the geometric contact relationship between the wheel and rail. Under identical wheel wear conditions, a certain difference was observed in the critical speed of the vehicle determined by the velocity-reducing method and the bifurcation configuration method. Both methods were capable of reflecting the impact of wheel hollow wear on vehicle stability at the critical speed. Compared to the velocity-reducing method, the bifurcation configuration method can better reflect the transition process of a vehicle from stable running to hunting instability. Furthermore, the lateral vibration acceleration values measured above the bogie frame indicated that slight wheel wear is insensitive to increased speed. However, when the wear was severe, the lateral vibration acceleration of the bogie was found to increase sharply, exceeding the established stability criteria. This phenomenon was consistent with the safety alarms that occurred during actual vehicle operation, indicating that the vehicle had failed to meet stability requirements. Full article

Rail corrugation causes various problems such as a decrease in ride comfort due to aggravation of train noise and vibration, and an increase in the amount of track component maintenance due to the amplification of the track impact. Most of the preceding research on rail corrugation has been conducted on the causes and characteristics of rail corrugation, but there are no countermeasures or management plans for existing rail corrugation. In this study, dynamic track response measurement results are analyzed. The dynamic wheel load, rail acceleration, and displacement of the rails and sleepers due to rail grinding were reduced by approximately 48%, 18%, and 12%, respectively. The analysis model was confirmed to be appropriate by comparing the measured and analyzed values of the dynamic wheel load before and after rail grinding in the section where rail corrugation occurred. Additionally, a maintenance method for rail corrugation was proposed considering the wheel–rail interaction force by calculating the appropriate grinding amount (upper and lower limit) for each train speed. Full article

The development of cost-effective and reliable railway monitoring technologies is crucial for the maintenance of modern infrastructure. Embedding sensors into rail pads has emerged as a promising approach for monitoring wheel–track interactions, but the successful implementation of these systems requires a robust framework for signal data acquisition and analysis. This study validates a custom-designed External Signal Acquisition Device (ESAD) for use with smart rail pads, comparing its performance against a high-precision commercial analog module. While the commercial module delivers exceptional accuracy, its high cost, bulky size, and complex installation requirements limit its practicality for large-scale railway applications. Laboratory-scale and full-scale experiments simulating real-world railway conditions demonstrated that the custom ESAD performs comparably to the commercial module. During simulated train passages, the ESAD showed reduced signal dispersion as load and train speed increased, confirming its ability to provide reliable calibration data. Moreover, the device maintained over 95% reliability in analyzing load-to-signal linearity, ensuring consistent and dependable performance in both laboratory and field settings. However, the ESAD does have limitations, including slightly lower resolution for low frequencies and potential sensitivity to extreme environmental conditions, which may affect its performance in specific scenarios. These findings highlight the ESAD’s potential to strike a balance between cost and functionality, making it a viable solution for widespread railway monitoring applications. This research contributes to the advancement of affordable and efficient railway monitoring technologies, fostering the adoption of preventive maintenance practices and enhancing overall infrastructure performance. Full article

One of the tasks of ensuring the safe and sustainable operation of railway transport is to assess the life cycle of the railway track and its elements—in particular, rails. It is known that the main cause of their failure is the development of defects that arise as a result of contact of rails with the wheels of rolling stock—contact fatigue defects. Modern approaches to predicting the contact-fatigue endurance of railway rails and wheels of rolling stock are based on the use of the kinetic theory of damage. The basis of such predictions is the calculation of the stress–strain state of rails under the action of combinations of external force and temperature influences, which is associated with the need to solve spatial boundary value problems of contact interaction. The complexity of such problems necessitates the use of numerical methods, such as the finite element method in particular, for their solution. This paper considers the features of constructing calculation schemes for such problems. Attention is primarily paid to assessing the influence of some design parameters of the rail track and wheels on the magnitude and distribution of stresses in the contact zone. The results will be useful for understanding the physical processes of damage accumulation, the occurrence and development of defects in rails and wheels, as well as for developing methods for predicting the contact fatigue endurance of important elements of railway infrastructure. Full article

Based on the dynamic receptance method, a vehicle–track–bridge interaction model was developed to calculate the wheel–rail interaction forces and the forces transmitted to the bridge in an elevated urban rail transit system. A prediction model integrating the finite element method–boundary element method (FEM-BEM) and the statistical energy analysis (SEA) method was established to obtain the noise from the main girder, track slab, and wheel–rail system for elevated urban rail transit. The calculated results agree well with the measured data. Thereafter, the noise radiation characteristics of a single source and the total noise of elevated urban rail transit systems with resilient fasteners, trapezoidal sleepers, and steel spring floating slabs were investigated. The results demonstrate that the noise prediction model for elevated urban rail transit that was developed in this study is effective. The diversity of track forms altered the noise radiation field of elevated urban rail transit systems significantly. Compared to monolithic track beds, where the fastener stiffness is assumed to be 60 × 10⁶ N/m (MTB_60), steel spring floating slab tracks (FSTs), trapezoidal sleeper tracks (TSTs), and resilient fasteners with a stiffness of 40 × 10⁶ N/m (MTB_40) and 20 × 10⁶ N/m (MTB_20) can reduce bridge-borne noise by 24.6 dB, 8.8 dB, 2.1 dB, and 4.2 dB, respectively. These vibration-mitigating tracks can decrease the radiated noise from the track slab by −0.7 dB, −0.6 dB, 2.5 dB, and 2.6 dB, but increase wheel–rail noise by 0.4 dB, 0.8 dB, 1.3 dB, and 2.4 dB, respectively. The noise emanating from the main girder and the track slab was dominant in the linear weighting of the total noise of the elevated section with MTBs. For the TST and FST, the radiated noise from the track slab contributed most to the total noise. Full article

When a railway train runs along a curved track with braking, the dynamic behaviors of the vehicle are extremely complex and difficult to accurately reveal due to the coupling effects between the wheel–rail interactions and the disc–pad frictions. Therefore, a rigid–flexible coupled trailer car dynamics model of a railway train is established. In this model, the brake systems and vehicle system are dynamically coupled via the frictions within the braking interface, wheel–rail relationships and suspension systems. Furthermore, the effectiveness of the established model is validated by a comparison with the field test data. Based on this, the dynamic response characteristics of vehicle under curve and straight braking conditions are analyzed and compared, and the influence of the curve geometric parameters on vehicle vibration and operation safety is explored. The results show that braking on a curve track directly affects the vibration characteristics of the vehicle and reduces its operation safety. When the vehicle is braking on a curve track, the lateral vibration of the bogie frame significantly increases compared to the vehicle braking on a straight track, and the vibration intensifies as the curve radius decreases. When the curved track maintains equilibrium superelevation, the differences in primary suspension force, wheel–rail vertical force, and wheel axle lateral force between the inner and outer sides of the first and second wheelsets are relatively minor under both straight and curved braking conditions. Additionally, under these circumstances, the derailment coefficient is minimized. However, when the curve radius is 7000 m, with a superelevation of 40 mm, the maximum dynamic wheel load reduction rate of the inner wheel of the second wheelset is 0.54, which reaches 90% of the allowable limit value of 0.6 for the safety index, and impacts the vehicle running safety. Therefore, it is necessary to focus on the operation safety of railway trains when braking on curved tracks. Full article

Curve squeal is a highly disturbing tonal noise produced by railway vehicles on tight curves, primarily attributed to lateral sliding at the wheel–rail interface. An essential step to estimate curve squeal noise levels is to determine the nonlinear self-sustained vibrations, for which time integration is a commonly used method. However, although it is known that the initial conditions affect the solutions obtained with time integration, their impact on the limit cycles is often overlooked. This study investigates this aspect for a curve squeal model based on falling friction and a modal reduction of the wheel and provides some insights on the mode competition phenomena and the nature of the final limit cycles obtained. The paper first details the curve squeal model, stability analysis, as well as the initial condition derivation, and then discusses the time integration and limit cycle results in both time and frequency domains. The results reveal two primary families of limit cycles that can be obtained for both types of initial conditions. The cases where stationary vibrations result in a quasi-periodic regime converge to a unique limit cycle which displays three fundamental frequencies corresponding to specific wheel modes, plus harmonic interactions among them. Full article

Railway turnout is a critical railway infrastructure that guides trains in switching tracks. Over time, uneven rail wear can lead to switch rail reduction value (SRRV) deviation, a typical structural defect that compromises turnout functionality and jeopardizes train operation safety. Current SRRV deviation detection methods rely primarily on inefficient manual inspections, making it difficult to ensure operational safety. To address this issue, the study carried out a comprehensive investigation combining numerical and experimental analyses. First, a rigid–flexible coupled dynamics model of a vehicle-turnout system was developed to analyze the wheel–rail dynamic interaction forces and contact relationships under various SRRV deviation conditions. The results revealed that SRRV deviation significantly affects both wheel–rail interaction forces and the turnout structural irregularity wavelength. Thus, based on discrete wavelet transform (DWT), a wheel–rail force trend component was derived that can effectively analyze the turnout structural irregular wavelength, and the mapping relationship between SRRV deviation and the wheel–rail force trend component was then established. Finally, an efficient and accurate method for identifying SRRV deviation based on wheel–rail force trend component was proposed and validated using field-measured data from trains passing through turnouts. This study contributes to the timely detection of track defects, helping to prevent safety incidents during train operations. Full article

Prolonged rolling contact fatigue between wheels and rails results in the formation of surface cracks on the rail and accurately analyzing the crack expansion behavior is essential to ensuring the safe operation of the train. Drawing upon the principles of fracture mechanics and finite element theory, this study establishes a finite element model of wheel–rail rolling contact that incorporates the presence of cracks. The method utilizes an interaction integral to calculate the stress intensity factors at the leading edge of the crack; then, the Paris formula is used to solve the crack spreading rate. It systematically examines the effects of the initial crack angle, the coefficient of friction of wheels to rails, and crack size on the behavior of fatigue crack propagation. The results indicate that the cracks primarily extend in the depth direction of the rail, transforming the semi-circular surface cracks into elliptical cracks with the major axis oriented along the rail’s width. Crack propagation is primarily driven by model II and III composite crack propagation, with their expansion rates influenced by operating conditions. In contrast, mode-I expansion is less sensitive to these conditions. Under single-variable loading conditions, a smaller initial crack angle results in a faster crack growth rate. Increasing crack length accelerates crack growth, while a higher friction coefficient inhibits it. Full article

Twin-disc testing is crucial for understanding wheel–rail interactions in railway systems, but the vast array of testing parameters and conditions makes data interpretation challenging. This review presents a comprehensive analysis of the twin-disc literature experimental data, focusing on how various parameters influence friction and wear characteristics under stationary contaminant conditions. We systematically collected and analyzed data from numerous studies, considering factors such as contact pressure, speed, material hardness, sliding speeds, adhesion, and a range of contaminants. This research showed inconsistent data reporting across different studies and statistical analyses revealed significant correlations between testing parameters and wear rates. For sand-contaminated tests, a correlation between particle size and flow rate was also highlighted. Based on these findings, we developed a simple predictive model for forecasting wear rates under varying conditions. This model achieved an adjusted R² of 0.650, demonstrating its potential for optimizing railway component design and maintenance strategies. Our study provides a valuable resource for researchers and practitioners in railway engineering, offering insights into the complex tribological interactions in wheel–rail systems and a tool for predicting wear behavior. Full article

This paper presents the development of a numerical analysis model designed to estimate the lifespan of reduced-diameter wheels used in freight wagons based on their diameter, under quasi-static conditions. These wheels are increasingly being used in combined transport applications, where they are installed in various bogie configurations and subjected to different operational environments. However, due to the unique characteristics of reduced-diameter wheels, their lifespan has been scarcely studied. To accurately build this model, an in-depth investigation of the rolling phenomenon was required, addressing key issues in the track–vehicle interaction and establishing relationships between these factors. After constructing the rail–wheel interaction model, it was applied to calculate the lifespan of wheels with standard, medium, and reduced diameters under identical conditions for comparison. This approach makes it possible to determine the lifespan of reduced-diameter wheels relative to standard ones, as well as to observe how lifespan changes with wheel diameter, and it is observed how lifespan diminishes non-linearly with decreasing diameters. The underlying reasons for this variation are explained through a comprehensive understanding of the rolling phenomenon, enabled by the full analysis. Full article
