The characteristic of delayed airfoil stalls caused by the bio-inspired Wavy Leading-Edges (WLEs) has attracted extensive attention. This paper investigated the effect of WLEs on the aerodynamic performance and flow topologies of the airfoil through wind tunnel experiments, while also discussing the flow control mechanism of WLEs. The result shows that, at small Angle of Attack (AOA), the flow through the WLEs exhibits periodic and symmetrical characteristics, where flow vortices upwash at the trough and downwash at the crest, resulting in flow from the crest to the trough. Upwash leads to the formation of a localized three-dimensional laminar separation bubble (LSB) structure at the leading edge of the trough section. At large AOA after baseline airfoil stall, the flow on the airfoil surface of WLEs presents a two-period pattern along the spanwise direction, and the separation zone and the attachment zone appear alternately, indicating that the control effect of delayed stall is accomplished by reducing the separation zone on the airfoil surface. The alternating occurrence of the separation and attachment zones is the result of intricate interactions among flows passing through multiple WLEs. This interaction causes the convergence of high-momentum attached airflows on both sides, thereby constraining the spread of the separation from the leading edge and enabling the re-attachment of separated air. The research results of this paper provide a reference for researchers to reveal the flow control mechanism of WLEs more comprehensively. Full article

The purpose of this experimental work was to investigate the role of the leading-edge wavy shape technique on the performance of small-scale HAWT fixed-pitch rotor blades operating under off-design conditions. Geometric parameters such as amplitude and wavelength were considered design variables to generate five different wavy shape blade models in order to increase the aerodynamic performance of the rotor with a diameter of 280 mm. A dedicated airfoil type S822 for small wind turbine application from the NREL Airfoil Family was chosen to fulfil both the aerodynamic and structural aspects of the blades. Rotor models were tested in a wind tunnel for different wind speeds while maintaining constant rotational speed to provide the blade-tip chord Reynolds number of 4.7 × 10⁴. The corrected tunnel data, in terms of power coefficients and tip-speed ratios, were compared first with the literature to validate the experimental approach, and then among themselves. It was observed that for minimal sizes of tubercles, the performance of the rotor increases by about 40% compared to the RB1 baseline rotor model for a low tip-speed ratio. Conversely, for the maximum size of the tubercles, there is a marked decrease of about 51% of the rotor performance for a moderate tip-speed ratio compared to the RB1 rotor model. Among these models, specifically, the RB2 rotor model with the smallest values of amplitude and wavelength provides a 2.8% higher peak power coefficient compared to the RB1 rotor model, and at the same time preserves higher performance values for a broad range of tip-speed ratios. Full article

Aerodynamic noise produced by the rotating blade is an important hindrance for the rapid development of modern wind turbines. Among the various noise sources, the airfoil trailing edge noise contributes a lot to the wind turbine noise. The control of wind turbine airfoil trailing edge self-noise by bio-inspired sinusoidal wavy leading edges is experimentally studied in a semi-anechoic chamber. The noise radiated by the baseline NACA 0012 airfoil and various wavy airfoils is measured using a planar microphone array consisting of fifty-two microphones. The noise source identifications are achieved by using the CLEAN-SC method. The effects of velocity and angle of attack on noise radiation of the baseline airfoil are analyzed in detail. The noise control law of the wavy amplitude and wavelength on airfoil trailing edge noise is explored. Based on the acoustic beamforming results, the noise control effects of the wavy leading edges are intuitively demonstrated. In general, the wavy leading edge with a larger amplitude and smaller wavelength has a better effect on the airfoil trailing edge noise reduction. The maximum sound pressure level reduction can be up to 33.9 dB. The results of this study are expected to provide important information for wind turbine aerodynamic noise control. Full article

Skin corrugation and tandem configuration are two distinct features that characterize the flow around dragonfly wings. In contrast to the smooth airfoil and single pair of wings of conventional airplanes, corrugated surfaces and tandem wings influence aerodynamics both locally and globally. In this article, several kinds of doubly- tandem wing configurations were designed, then computational investigations based on wind tunnel experiments were conducted to investigate the aerodynamic characteristics of these models. Computational simulations using in-house codes were carried out with a freestream velocity of 20 m/s at an angle of attack from −4° to 16°. Based on these computational results, the effects of airfoil thickness, surface waviness and hindwing decalage on aerodynamic characteristics were compared and presented quantitatively. Final results demonstrate that a tandem wing configuration could eliminate separation close to the trailing edge at angles of attack 8°~10°, or delay the trailing edge separation at angles of attack greater than 10°. Thus, the aerodynamic efficiency of tandem configurations could provide significant improvement compared to configurations with a single wing. The greatest percentage of aerodynamic efficiency improvement for a tandem thick configuration compared to a single thick configuration is 1376% at angle of attack 0°. Surface waviness will stall at a lower angle of attack, but will gain some aerodynamic benefit from the standing separated flow. Hindwing decalage has obvious lift enhancement for the tandem configuration. Therefore, it is concluded that the tandem configuration is attractive and promising for MAVs with flexible structures in the near future. Full article

Among the several noise-generation mechanisms of airfoil self-noise, trailing-edge bluntness noise is an important noise source, which is caused by the vortex shedding at blunt trailing edges. A numerical study on airfoil trailing-edge bluntness noise control using the bio-inspired wavy leading edges is presented in this paper. The high-fidelity, improved, delayed, detached eddy simulation (IDDES) method was used to calculate the flow field, and the acoustic analogy method was used for noise prediction. For both the blunt-trailing-edge airfoils, a baseline airfoil with a straight leading edge and a bio-inspired airfoil with a wavy leading edge were used in this study. The chord-based Reynolds number was 400,000, and there was no angle of attack. The numerical results show that the trailing-edge bluntness noise of the baseline airfoil was significantly reduced by the wavy leading edges. The sound pressure level reduction was about 3.7 dB at the characteristic frequency, and the maximum sound pressure level reduction was as high as 35 dB. The trailing-edge bluntness noise was decreased at all directional angles. The maximum overall sound pressure level reduction was 6.3 dB at 0°. In addition, by analyzing the pressure fluctuations, wake characteristics, turbulent vortex structures and spanwise correlation and coherence of the flow field, the noise-reduction mechanisms of the bio-inspired airfoil are deeply revealed. Full article

The flow structures and surface pressure distributions on corrugated airfoils significantly differed from those on a conventional, smooth airfoil. An unsteady, two-dimensional computational simulation was carried out to investigate the flow behavior and associated aerodynamic performance of a group of corrugated airfoils with different levels of waviness at angles of attack from 0° to 20° with an interval of 2° at a low Reynolds number regime (Re = 1.2 × 10⁵) and were quantitatively compared with those of its smooth counterpart. Time-averaged aerodynamic coefficients demonstrated that the corrugated airfoils have a lower lift and higher drag because of trapped vortices in the corrugations. The pressure drag of the corrugated airfoils was greater than that of the smooth airfoil. In contrast, the viscous drag of the corrugated airfoils was smaller than that of the smooth airfoil because the recirculation generated in the corrugation could reduce the viscous drag. The averaged velocity gradient in the boundary layer showed that the thickness of the boundary layer increased significantly for the corrugated airfoils because of recirculating flow caused by the small-standing vortices trapped in the valley of corrugations. The smoother the corrugated surface, the closer the aerodynamic characteristics are to those of the smooth airfoil. Full article

In this paper, a pitching airfoil near flat and wavy ground is studied by numerical simulations. The kinematic features of the airfoil and the flow field around it are analyzed to reveal unsteady vorticity dynamics of the self-propelled airfoil in ground effect. The optimal pitching periods at different initial heights above flat ground are obtained, which make the pitching airfoil achieve the maximum lift-to-drag ratio. Compared with flat ground, at the same initial height, the optimal pitching periods vary with the shape of ground. The structure and the strength of the wake vortices shedding from the airfoil are adjusted by the wavelength of ground. This leads to the changes of amplitude and occurrence times of the peak and valley of lift and drag force. The results obtained in this study can provide some inspiration for the design of underwater vehicles in the ground effect. Full article

A numerical investigation is proposed to explore the flow past a novel wavy circular cylinder as a passive flow control, whose shape is determined by a sinusoidal function applied to its leading edge line, similar to studies with wavy leading-edge airfoils. The latter are motivated by the wavy-shaped tubercles found in the flippers of humpback whales, which are believed to improve their maneuverability. Our attempt is, therefore, to assess the effects of leading-edge waviness now on a simpler and canonical geometry: circular cylinders. The present work relies on iLES simulations conducted with Nektar++ at a Reynolds number of 3900. Besides the straight cylinder, two wavy geometries are assessed, which are determined by a single wavelength of 37.5% for two amplitudes, 3% and 11%, based on the mean diameter of the wavy cylinder. Our results showed that, contrary to what is usually the case with traditional wavy cylinders at similar Reynolds numbers, waviness caused a reduction in the near-wake recirculation length and an increase in the mean near-wake turbulent kinetic energy compared to the straight cylinder. This was followed by a reduction in base pressure (up to about 36%) leading to a rise in lift oscillations and also to a significant increase in the mean drag coefficient of up to about 28%. An attempt to detail the flow phenomena is provided, evidencing the emergence of counter-rotating pairs of streamwise vortices between peaks. It is argued that the differences observed in recirculation length, turbulent kinetic energy, and force coefficients start even prior to the formation of these coherent structures and end up with interactions with the near wake. Full article

A dynamic stall will cause dramatic changes in the aerodynamic performance of the blade, resulting in a sharp increase in the blade vibration load. The bionic leading-edge airfoil with different waviness ratios, inspired by the humpback whales flipper, is adopted to solve this problem. In this study, based on the NACA0015 airfoil, the three-dimensional unsteady numerical simulation and sliding mesh technique are used to reveal the flow control mechanism on the dynamic stall of the bionic wavy leading edge. The effects of the waviness ratio on the dynamic stall characteristics of the airfoil are also investigated. The results show that the peak drag coefficient is dramatically reduced when a sinusoidal leading edge is applied to the airfoil. Although the peak lift coefficient is also reduced, the reduction is much smaller. When the waviness ratio R is 0.8, the peak drag coefficient of the airfoil is reduced by 17.14% and the peak lift coefficient of the airfoil is reduced by 9.20%. The dynamic hysteresis effect is improved gradually with an increasing waviness ratio. For the bionic airfoil with R = 1.0, the area of the hysteresis loop is the smallest. Full article

Wing–in–ground crafts will face waves with different amplitudes when flying over the ocean, and the high amplitude situations are especially lack of exploration. Hence, the aerodynamic characteristics of the NACA 4412 airfoil in proximity to the wavy water surface for various wave amplitudes are inspected in this paper. By solving Navier–Stokes equations, the lift coefficients of the airfoil when the angle of attack ranges from 0° to 4° are obtained. The results show that the fluctuation amplitudes of aerodynamic coefficients increase remarkably with successive increases in the wave amplitude and might threaten flight safety. The flow fields at 0° with low and high wave amplitudes are investigated. It is revealed that the upward movement of the water surface is the critical factor for the change of aerodynamics, and the mechanism varies with different wave amplitudes. Comparison of the flow fields at 0° and 2° further indicates that the influence of high amplitude waves depends on the distance between the leading edge of the airfoil and the water surface. This study discovers the reasons for the different aerodynamic characteristics under various wave amplitudes and angles of attack, and is of great value for the design of wing–in–ground crafts. Full article

Wing-in-ground craft often encounter waves when flying over the sea surface, and the ground effect is more complicated than that of flat ground. Therefore, the aerodynamic characteristics of the NACA 4412 airfoil in proximity to wavy ground for a wide range of angles of attack is studied by solving the Reynolds Averaged Navier–Stokes equations. The validation of the numerical method is carried out by comparing it with the experimental data. The results show that the aerodynamic coefficients will fluctuate periodically when the airfoil moves over wavy ground at a small ride height. Except for the angle of attack of 0°, the fluctuation trend of aerodynamic coefficients at other angles of attack is the same. The analysis of aerodynamic fluctuation amplitude found that the medium angle of attack should be selected as the design cruise angle of attack for wing-in-ground craft. The time-averaged aerodynamic coefficients in the case of wavy ground are almost the same as those of flat ground. Hence, wavy ground mainly causes a fluctuation in aerodynamic coefficients. Considering the difference between aerodynamic coefficients at the angle of attack of 0° and at other angles of attack, the flow field structure at an angle of attack of 0° and 4° is analyzed. The results reveal the aerodynamic characteristics of the airfoil moving over wavy ground, which gives a deeper understanding of the ground effect in the conditions of wavy surface/ground. This has a certain guiding significance for the design of wing-in-ground craft. Full article

The effect of the number of waves and the width of the ridge and valley in chord direction for a wavy airfoil was investigated at the angle of attack of $0^{\circ }$ and Reynolds number of ${10}^3$ through using the two-dimensional direct numerical simulation for four kinds of wavy airfoil shapes. A new method for parameterizing a wavy airfoil was proposed. In comparison with the original corrugated airfoil profile, the wavy airfoils that have more distinct waves show a lower aerodynamic efficiency and the wavy airfoils that have less distinct waves show higher aerodynamic performance. For the breakdown of the lift and drag concerning the pressure stress and friction stress contributions, the pressure stress component is significantly dominant for all wavy airfoil shapes concerning the lift. Concerning the drag, the pressure stress component is about $75\%$ for the wavy airfoils that have more distinct waves, while the frictional stress component is about $70\%$ for the wavy airfoils that have less distinct waves. From the distribution of pressure isoline and streamlines around wavy airfoils, it is confirmed that the pressure contributions of the drag are dominant due to high pressure on the upstream side and low pressure on the downside; the frictional contribution of the drag is dominant due to large surface areas of the airfoil facing the external flow. The effect of the angle of attack on the aerodynamic efficiency for various wavy airfoil geometries was studied as well. Aerodynamic shape optimization based on the continuous adjoint approach was applied to obtain as much as possible the highest global aerodynamic efficiency wavy airfoil shape. The optimal airfoil shape corresponds to an increase of $60\%$ and $62\%$ over the aerodynamic efficiency and the lift from the initial geometry, respectively, when optimal airfoil has an approximate drag coefficient compared to the initial geometry. Concerning an fixed angle of attack, the optimal airfoil is statically unstable in the range of the angle of attack from $-1^{\circ }$ to $6^{\circ }$ , statically quasi-stable from $-6^{\circ }$ to $-2^{\circ }$ , where the vortex is shedding at the optimal airfoil leading edge. Concerning an angle of attack passively varied due to the fluid force, the optimal airfoil keeps the initial angle of attack value with an initial disturbance, then quickly increases the angle of attack and diverges in the positive direction. Full article
