Compact toroid (CT) injection, with its characteristics of high plasma density and extremely high injection velocity, is considered a highly promising method for core fueling in fusion reactors. Previous studies have lacked investigation into the transport process of CT within drift tubes. To investigate the dynamic processes of CT in drift tubes, this study developed a compressible magnetohydrodynamics (MHD) solver and a magnetic diffusion solver based on the OpenFOAM platform. They were integrated into a multi-region coupling framework to create a multi-region coupled MHD solver, mhdMRF, for simulating the dynamic behavior of CT in drift tubes and its interaction with finite-resistivity walls. The solver demonstrated excellent performance in simulations of the Orszag–Tang MHD vortex problem, the Brio–Wu shock tube problem, analytical verification of magnetic diffusion, and validation of internal coupling boundary conditions. Additionally, this work innovatively explored the effects of the geometric structure at the end of the inner electrode and finite-resistivity walls on the transport processes of CT. The results indicate that optimizing the geometric structure at the end of the inner electrode can significantly enhance the confinement performance and stability of CT transport. The resistivity of the wall profoundly influences the magnetic field structure and density distribution of CT. Full article

This study presents a numerical investigation of the internal flow characteristics within the draft tube of a Kaplan turbine using computational fluid dynamics (CFD). The distribution and evolution of vortical structures, particularly the formation and development of vortex ropes under various operating conditions, are systematically analyzed. The study aims to explore the effects of blade angle and guide vane opening on the internal flow characteristics of the unit, thereby providing guidance for flow control strategies. The influence of guide vane opening and turbine head on vortex dynamics and flow stability is examined, with a focus on the pressure pulsations induced by vortex ropes through frequency-domain analysis. The results indicate that increased guide vane openings and higher heads lead to the expansion and downstream extension of the vortex rope into the elbow section, causing significant low-frequency pressure pulsations and enhancing flow instability. These findings contribute to a deeper understanding of unsteady flow behavior in Kaplan turbine draft tubes and provide a theoretical foundation for improving hydraulic stability and optimizing operational performance. Full article

This study investigates the organized flow structures and turbulence quantities in a transitional oscillatory boundary-layer flow over a smooth bed using a DNS model set up by the open-source framework Nektar++ (v5.2.0). The present model was validated against the results of a previous study involving a bypass transition mechanism in the intermittently turbulent regime. To trigger the initial perturbations, a roughness element was placed on the bed and removed at the very moment a two-dimensional vortex tube, caused by an inflectional-point shear-layer instability, was observed on it. Then, the turbulent spots where the flow experienced intense fluctuations in an otherwise laminar boundary layer were identified from the bed shear-stress distribution on the bed, which served as a reliable indicator of turbulence. These flow features emerged as the first sign of the initiation of turbulence. Several measurement points were selected to follow the bed shear-stress variations and to observe the spatial and temporal development of turbulent spots at a low-wave Reynolds number, $Re=1.8\times {10}^5$. Along with these observations, phase-resolved turbulence quantities were also investigated over successive half-cycles for the first time in the literature to understand how turbulence develops and spreads over the flow domain. The results show that the turbulence generated in the near-bed region becomes stronger in the deceleration stage due to the adverse pressure gradient and diffuses away from the bed during the subsequent phases of the developing oscillatory boundary-layer flow. The findings related to the turbulence quantities also indicate that the turbulence gradually evolves and spreads into the fluid domain in successive half-cycles. Full article

This article reports the effect of twisted tapes with continuous V-ribs on the thermal performance index characteristics of a heat exchanger tube. Numerical and experimental studies were conducted to investigate the influence of V-rib attack angles (β = 15°, 30°, and 45°) in forward and backward arrangements. This investigation employed 0.9 mm thick, continuous V-rib twisted tapes (CVRTs) made from aluminum sheets formed with a twist ratio of y/w = 4.0. The experimental results indicated that a continuous V-rib twisted tape (CVRT) was more effective in heat transfer improvement than a typical twisted tape (TT). This was due to swirl and longitudinal vortex flows that helped increase flow mixing and reduce boundary layer thickness. Decreased V-rib attack angles (β) led to greater heat transfer enhancement, pressure drop, and thermal performance index values due to the greater turbulent mixing of fluid. The numerical result revealed that a continuous V-rib twisted tape created strong longitudinal vortex flow, especially with higher attack angles. The Turbulent Kinetic Energy (TKE) and core fluid temperature increased with the insertion of CVRTs. Local Nusselt numbers also remained relatively high for heat exchanger tubes with CVRTs. The experimental study illustrated that a tube with a CVRT installed augmented heat transfer. In the experimentally studied cases, a backward arrangement had more heat transfer, a greater friction factor, and a better thermal performance index. Compared to a plain tube, a tube with CVRT installed, having β = 15°, 30°, and 45°, showed 76.8, 71.6, and 66.2% improved heat transfer, respectively. CVRTs with these three β-values, respectively, exhibited higher thermal performance than a TT. Among the investigated CVRTs, the backward-arranged tape with β = 15° offered the maximum thermal performance index, 1.13 at Re = 6000. The results are congruent with the simulation outcomes, hence supporting the CFD analysis. Full article

Sediment erosion of hydraulic turbines has gradually become a key factor affecting their long-term stable operation. There are many different factors that can cause erosion in the Francis hydraulic turbine; among them, the vortex occurs in the turbine, which is also a negative factor for the unit. In this paper, the purpose is to study the complex erosion characteristics and specific influencing factor mechanism. The method is based on numerical simulation, combined with the verification data on site. Research results show that the differences in flow patterns among various components correspond to the erosion distribution of the unit at the same location, indicating that local flow patterns affect the unit’s erosion. The highest total erosion rate is on the surface of the runner at 1.08 × 10⁻³ kg·s⁻¹·m⁻². The erosion rate on the guide vane wall is second highest, also at 9.8 × 10⁻⁴ kg·s⁻¹·m⁻². The total erosion rate in the clearance is lower than that on the guide vane wall at 7.03 × 10⁻⁴ kg·s⁻¹·m⁻². The lowest total erosion rate is found in the draft tube at 2.57 × 10⁻⁴ kg·s⁻¹·m⁻². The effect of local vortices not only exacerbate the microscopic damage on the blade surface but also leads to a more obvious nonuniform erosion distribution, especially at the clearance, where erosion is more severe. The vortex in the guide vane passage alters the particle trajectory at the guide vane outlet, increasing the erosion in the guide vane clearance. Similarly, the vortex in the draft tube increases particle rotation, enhancing erosion on the draft tube wall. Research indicates that eliminating vortices is beneficial for reducing sediment erosion within the unit. The research results provide a theoretical basis for the optimization design of Francis hydraulic turbine. Full article

The thermal-hydraulic performance of circular heat transfer tubes equipped with isosceles trapezoidal winglet longitudinal vortex generators (ITWL-VGs) was investigated through integrated experimental and numerical approaches. Experimental studies were conducted that focused on the effects of key parameters: (1) the ITW quantity (n = 4, 6, 8); (2) the attack angle (α = 0°, 15°, 30°, 45°); and (3) four distinct VG arrangements. Numerical simulations employing multi-physical field analysis elucidated the underlying heat transfer enhancement mechanisms. The numerical simulations demonstrated excellent agreement with the experimental measurements. The results indicated that uniformly distributed ITWL-VGs with suitable angles of attack (α) significantly enhanced the thermal performance. Increasing the number of ITWs (N) generated additional longitudinal vortices, intensifying fluid mixing and heat transfer enhancement, thereby improving the PEC value. All the Nusselt number (Nu), friction factor (f) and PEC values exhibited positive correlations with the α and the spacing (L_P), respectively. Within the scope of this study, the α should not be less than 30°. In addition, an optimal value should be used for the L_P. The maximum PEC value was 1.27. These findings conclusively demonstrated the significant heat transfer enhancement capabilities of ITWL-VGs. Full article

In this study, we propose a novel device, the coaxial cross double-twisted tape and vortex generator (CV), to significantly enhance the heat transfer performance of high-viscosity lubricating oil. Based on numerical simulation results, we thoroughly analyze the thermal–hydraulic behavior of the lubricating oil within the enhanced pipe. We explore four distinct geometrical configurations of the CV. Among them, a particular variant, the CVCP, achieves the most remarkable enhancement in heat transfer performance. To further understand the heat transfer characteristics of CVCPs, we examine the effects of twist ratios (y = 2.0, 3.0, 4.0, and ∞) and angles (α = 0°, 30°, and 60°). The results reveal that, across a wide Reynolds number range (40 ≤ Re ≤ 840), the heat transfer performance of CVCP is closely related to the twist ratio and angle. Notably, the performance evaluation criterion (PEC) of a tube with CVCP inserted is 1.14–1.54 times higher than that of conventional twisted tapes. Overall, these findings provide valuable insights into optimizing heat transfer in high-viscosity fluids and serve as a meaningful reference for future research and engineering applications aimed at enhancing lubricating oil heat transfer within tubes. Full article

In our previous research work, we investigated different methods to mitigate the vortex rope that appears in the draft tube of a Francis turbine when it operates at off-design operating points. The most promising results were obtained for a method involving an axial jet of water. The minor disadvantage of this method was the high value of the flow rate of the water jet. Our present work focuses on another method that decreases the value of the flow rate of the jet. In this sense, a new device has been developed that produces a pulsating water jet, which mitigates the pressure fluctuations associated with the swirling flows. The objective of this paper is to use our experimental test rig to validate the efficiency of a pulsating water jet in mitigating the vortex rope. To perform that, pressure measurements were carried out at four test levels to evaluate the pressure amplitude evolution when the pulsating jet was deployed. From preliminary investigations, the results indicate that this method leads to a decrease of the pressure amplitude of the vortex rope, with a lower value of the flow rate of the jet. Full article

Bubbles in pipes are widely present in marine engineering, transmission, and fluid systems with complex environments. This paper divides tubes into short, longer, and long tubes due to different lengths. In short tubes, the formation, development, and stability of spark bubbles are deeply analyzed through numerical simulation and experimental measurement, and the morphology and period of vortex rings generated in the surrounding fluid are studied. The results show that bubbles in tubes are significantly elongated compared with those in free fields. Changing the parameters of tubes can affect the size and oscillation speed of vortex rings. Secondary cavitation is found in asymmetric positions in longer tubes. The conditions, positions, and periods of multiple secondary cavitations are summarized in a series of experiments on long tubes. It is found that bubbles in tubes are related to the ${\gamma }_t$ and ${\gamma }_L$ tube parameters. More secondary cavitation is easily generated in thinner and longer tubes. In addition, the pumping effect brought about by the movement of bubbles in tubes is studied. By designing reasonable tube parameters, the life cycle of bubbles can be changed, and the pumping efficiency can be improved. This study provides important theoretical support for the reliability of the movement of bubbles and surrounding fluid in tubes and lays a foundation for the optimization and promotion of this technology in practical applications. Full article

With the development of a power system predominantly reliant on new energy sources, turbine generator sets are increasingly required to operate under wide load conditions, resulting in numerous unstable flow phenomena and substantial economic losses for power stations. This study employs the Shear Stress Transport (SST) k-ω turbulence model to combine numerical simulations with experimental methods. It calculates the guide vane opening at the rated head of a Francis turbine and examines the internal flow field characteristics and pressure pulsations under various operating conditions. The findings indicate that the entropy production ratio in the draft tube is the highest among all load conditions, ranging from about 72.7% to 95.9%. Energy dissipation in the vaneless zone and the runner increases with greater opening. At 45% and 100% load conditions, the draft tube is mainly influenced by dynamic and static interference, single and double frequencies induced by runner rotation, and low-frequency fluctuations of the vortex and. Under 60% load conditions, pressure fluctuations in the draft tube are primarily caused by the eccentric vortex band, characterized by higher intensity and a frequency of 0.2 f_n. Numerical results closely align with experimental observations. The findings provide essential guidance for ensuring the stable operation of power plant units. Full article

This study introduces a tornado perturbation model utilizing the cyclostrophic wind model, implemented through a shallow-water equation framework. Four numerical experiments were conducted: a single cyclonic wind perturbation (EXP1), a single low-geopotential height perturbation (EXP2), a cyclonic wind perturbation with a 0 Coriolis parameter (EXP3), and a single anticyclonic wind perturbation (EXP4). The outputs showed that in a static atmosphere setting, a small-scale cyclonic wind perturbation generated a tornado-like pressure structure. The centrifugal force in the central area exceeded the pressure gradient force, causing air particles to flow outward, leading to a pressure drop and strong pressure gradient. The effect of the Coriolis force is negligible for meso-γ-scale and smaller systems, while for meso-β-scale and larger systems, it begins to have a significant impact. The results indicate that a robust cyclonic and an anticyclonic wind field can potentially generate a pair of cyclonic and anticyclonic tornadoes when the horizontal vortex tubes in an atmosphere with strong vertical wind shear tilt, forming a pair of positive and negative vorticities. These tornadoes are similar but have different rotation directions. Full article

As the environmental crisis intensifies, the demand for energy-efficient systems has never been greater. Vortex generators have emerged as an effective method for enhancing heat transfer within tubes. While extensive research has been conducted on their application in straight tubes, studies focusing on their performance in curved tubes remain limited. This simulation study examined three different arrangements of triangular vortex generators in a common flow-down configuration within a U-turn tube to optimize heat transfer. The analysis conducted under constant wall temperature conditions across a range of Reynolds numbers spans both laminar and turbulent flow regimes to evaluate the broader impacts of vortex generators on flow and thermal fields. The efficiency of each arrangement was evaluated based on the Nusselt number and friction factor. Results show a remarkable increase in the Nusselt number, reaching up to 115% for the configuration with the highest number of vortex generators. However, this enhancement was accompanied by a significant increase in the friction factor, rising by up to 383% at higher Reynolds numbers. Overall, vortex generators demonstrated their highest effectiveness in curved tubes during the laminar-to-turbulent flow transition. In fully turbulent flow, the friction factor increased disproportionately to the modest gains in heat transfer. Despite these limitations, the use of vortex generators in curved tubes offers promising efficiency improvements and merits further exploration. Full article

Heat transfer enhancement is always pursued in the industry to achieve high-performance and low-energy-consumption heat exchange devices and systems. For decades, various types of heat transfer-enhancing tubes with differing geometries and wall configurations have been developed. In this paper, the heat transfer and pressure drop characteristics of air inside an innovative heat transfer tube with regular wall dimples, namely a vortex-enhanced tube, which has a great application prospect in the gas–gas heat exchanger, are numerically studied with an experimentally validated model. The effects of the depth, axial pitch, and radial rotation angle of the dimple in the tube wall on the convective heat transfer coefficient and friction drag coefficient are comprehensively analyzed. Based on the Performance Evaluation Criteria (PEC) of the tubes, the optimal parameters of the vortex-enhanced tube are obtained. When Re ranges from 10,000 to 40,000, the comprehensive evaluation factor of the vortex-enhanced tube is 1.29 times higher than the smooth tube. Dimple pacing, dimple depth, and dimple helical angle of the optimal tube type are 8 mm, 6 mm, and 83°, respectively. Full article

Pumped storage units often deviate from the optimal operating conditions in the process of regulating new energy fluctuations. To effectively improve the performance of the units, the variable speed of the units is one of the more feasible means at present. This paper focuses on the part-load condition of turbine operation, with an emphasis on the internal flow characteristics and pressure pulsation characteristics of the pump turbine during the linear reduction of the rated speed. It is found that the streamlines in the runner become turbulent in the process of speed reduction, forming a vortex at the inlet of the runner, and the vortex scale gradually increases with the speed reduction. The vortex rope in the draft tube undergoes three types of changes during the speed reduction: helical eccentric vortex rope, vanishing vortex rope, and columnar vortex rope. Before the speed change, the low-frequency components with high amplitude exist in each flow-passing part, but gradually disappear with the speed reduction. Except for the runner, the frequency affected by rotor–stator interference of each flow-passing part increases with the decrease of speed, and the growth is most obvious in the vaneless region. The findings of this research can serve as a valuable reference for the variable speed operation of pumped storage units. Full article

The pump turbine, as the core equipment of a pumped storage power plant, is most likely to operate in the hump zone between condition changes, which has a great impact on the stable operation of the power plant, and the high sedimentation of a natural river will lead to wear and tear in the overflow components of the equipment. Therefore, this paper is based on the Euler–Lagrange model, and seeks to investigate the distribution of vortices in the hump zone of the pump turbine and its effect on the movement of sand particles. The study shows that as the flow rate increases, the strip vortex in the straight cone section of the draft tube becomes elongated, and the cluster vortex in the elbow tube section gradually decreases. The strip vortex encourages the sand particles to move along its surface, while the cluster vortex hinders the movement of the sand particles. The accumulation areas of the sand particles in the straight cone section and the elbow tube section increase axially and laterally, respectively. The blade vortex in the runner gradually occupies the flow channel as the flow rate increases, and the blade vortex near the pressure surface encourages the sand particles to move towards the suction surface, resulting in the serious accumulation of sand particles on the suction surface. As the flow rate increases, the number of blades where sand particles accumulate increases and the accumulation area moves towards the cover plate and the outlet. The flow separation vortex in the double-row cascade decreases as the flow rate increases, which drives the sand movement in the middle and lower sections of the vanes. The area of sand accumulation in the stay vane decreases with increasing flow rate, but the area of sand accumulation between the guide vanes increases and then decreases. The vortex on the wall surface of the volute gradually decreases with the flow rate, and the vortex zone at the outlet first decreases, then disappears, and finally reappears. The vortex at the wall surface suppresses the sand movement, and its sand accumulation area changes from elongated to lumpy and finally to elongated due to the increase in flow. The results of the study provide an important theoretical reference for reducing the wear of pump turbine overflow components. Full article
