This paper proposes disturbance detection algorithms to mitigate the oscillations in smartphone camera module actuators induced by external shocks (e.g., drop events). Smartphone camera modules operate under volumetric constraints with inter-component trade-offs. Specifically, the limited space leads to insufficient performance because actuators are unstable under external disturbances. To optimize actuator function, we define the dynamic model of a voice coil motor (VCM) actuator, a controller model, and a shock disturbance model and perform worst-case operational analysis with MATLAB/Simulink (R2015a) simulations. Moreover, we propose two disturbance detection techniques: a phase-based detection algorithm that statistically analyzes the phase difference between the control input and the position feedback signal to detect disturbances and a frequency-based detection algorithm that uses discrete Fourier transform (DFT) to identify the characteristic spectral component of disturbances at 500 Hz. According to the simulation results, both methods reduce recovery time upon disturbance. Furthermore, the frequency-based algorithm achieves faster recovery performance than the phase-based detection algorithm. The phase-based detection method offers low computational complexity but increased processing latency, while the frequency-based detection method requires more memory capacity. The proposed techniques are anticipated to improve the recovery time of smartphone camera modules under disturbances, thereby enhancing system robustness and contributing to a more stable user imaging experience by mitigating image blur. Full article

This study introduces a systematic and optimised methodology for designing Linear Variable Differential Transformer (LVDT) sensors and Voice Coil (VC) actuators, tailored for high-precision applications such as gravitational wave detectors and particle accelerators. Unlike prior studies, which focus primarily on industrial-grade LVDT design frameworks or isolated parameter studies, this work addresses the specific challenges of achieving both enhanced sensor response and actuation force within strict geometric and thermal constraints. Using a custom-developed simulation pipeline based on Finite Element Method Magnetics (FEMM), we evaluate the influence of key design parameters such as coil dimensions, radial gaps, and coil wire diameter on performance metrics such as response and linearity. The novelty of this work lies in its systematic exploration of design trade-offs, such as maximising performance while minimising heat dissipation, and its applicability to high-precision environments. In this work, particular emphasis is placed on the combination of the LVDT and VC functionalities in one unified sensor-and-actuator system designed for gravitational wave detectors. In addition, the methodology and simulation results are validated with experimental measurements of an optimised design, demonstrating a 2.8-fold increase in LVDT response and a 2.5-fold increase in VC actuation force compared to the initial configuration while preserving LVDT linearity and VC force stability. This work represents a significant advance over existing methodologies by offering a structured, scalable design process. Full article

Tactile working memory limits the amount of information that can be processed through touch, with important implications for the design of haptic communication systems. Although visual and auditory working memory have been extensively investigated, tactile working memory, particularly for spatial and spatiotemporal sequences, remains less well understood. The present study examined tactile working memory capacity in two psychophysical experiments. Participants reproduced sequential vibrotactile stimuli delivered to the forearm via a 3 × 3 array of voice-coil actuators by entering responses through keypresses. Both experiments employed an adaptive 3-up/1-down staircase procedure, in which sequence length was adjusted according to response accuracy, and thresholds were estimated from reversal points. In Experiment 1 (Ordered Recall), participants reproduced both the spatial locations and the temporal order of stimulation, yielding a memory capacity threshold of approximately four items. In Experiment 2 (Unordered Recall), participants recalled only the set of stimulated locations without regard to order, resulting in a higher threshold of approximately five items. These results demonstrate that incorporating temporal sequencing demands into spatial recall substantially increases cognitive load and reduces effective tactile memory capacity. The findings clarify fundamental limits of tactile working memory and provide practical guidance for the development of haptic interfaces, wearable feedback systems, and sensory substitution technologies that must balance information complexity with human cognitive constraints. Full article

To address the trade-off between macroscopic stroke and high stiffness in XY precision positioning, this study proposes a platform utilizing a Connecting Arm and Guide Rail Integration decoupling mechanism. Distinct from traditional suspended-mover or flexure-based schemes, this design integrates precision guiding directly into a rigid connecting arm to mechanically isolate parasitic motion. Finite Element Analysis confirms a safety margin with a maximum equivalent stress of 8.34 MPa. Notably, the platform achieves a first-order natural frequency of 864.82 Hz, which is significantly higher than the Voice Coil Motor’s actuation frequency, effectively mitigating low-frequency resonance. Transient dynamic analysis further suggests that the mechanism suppresses cross-axis interference to the sub-nanometer level (0.61 nm) during high-acceleration maneuvers. Experimental validation demonstrates favorable tracking capabilities: for a 5 mm step motion, the positioning deviation is controlled within 0.005 mm. These findings suggest that the proposed solution offers a feasible and competitive approach for high-stiffness precision positioning applications. Full article

Segmented telescopes face significant challenges in achieving high segment positioning accuracy under complex disturbances, which directly impact observational sensitivity and resolution. Conventional rigid actuators with limited bandwidth (e.g., Keck ~20 Hz) struggle to maintain control stability. Novel dual-stage actuators combining coarse and fine adjustment (e.g., voice coil motors) now achieve <8 nm precision over millimeter-level strokes. Moreover, their higher closed-loop bandwidth (e.g., TMT ~60 Hz) can ensure rapid settling without overshoot and robust suppression of high-frequency disturbances (e.g., pulsating wind and mechanical vibration). In parallel, system-level control strategies have been updated accordingly. Ground-based systems focus on real-time multimodal decoupling, while space-based systems emphasize non-contact vibration isolation and nested multi-loop control to achieve sub-arcsecond pointing stability. This review surveys the design and control strategies of damping–positioning mechanisms for segmented telescopes and discusses the key trade-offs among critical performance metrics, including resolution, stroke, and load capacity. Particular attention is given to the disturbance-sensitivity analysis and active damping techniques (up to ~50% vibration reduction) implemented in the ELT “hard” actuator approach. Future directions include cross-scale collaborative control, smart material applications, and AI-based adaptive parameter optimization, which together provide a technical pathway toward high-precision imaging in next-generation highly segmented telescopes. Full article

The application of mechanical products in many situations involves linear motion. The cylinder head of an internal combustion engine (ICE), a mechanical product, contains intake and exhaust valves. These valves open or close using the linear motion converted by the camshafts rotated by the engine. A typical engine is operated with a single cam profile; depending on the engine rotation, there are areas where the cam profiles do not match, resulting in a poor engine performance. An intake and exhaust system with an actuator can solve this problem. In a previous study on this system, the geometry and processing during manufacturing were complex. Therefore, in response, a linear actuator operated by Lorentz force with a coil as the mover was designed in this study. Through an electromagnetic field analysis using the finite element method, a three-phase alternating current was applied to the coil, assuming that it would be used as a power source for a general inverter. Consequently, the thrust obtained in the valve-actuation direction was 56.7 N, indicating improved axial thrust over the conventional model. Full article

This paper presents the design of an integrated micro-vibration isolation and pointing platform with a four-leg structure, incorporating pitch and yaw adjustment functions using voice coil motors. The primary objective is to mitigate the impact of spacecraft-generated micro-vibrations on the pointing accuracy and imaging clarity of large space optical payloads while adhering to lightweight requirements. The research methodology encompasses three main phases. Initially, a simplified dynamic model of the integrated platform is established, and dynamic control equations are derived based on the proportional–integral–derivative (PID) control strategy. The effects of centroid deviation and control parameters on the control efficacy are analyzed. Subsequently, a principle prototype of the two-dimensional micro-vibration isolation and pointing platform is designed, detailing the development of the membrane, actuator, legs, and integrated system. Finally, a ground test verification system is implemented under gravity unloading conditions using elastic strings. The experimental results demonstrate the platform’s effective vibration isolation and pointing capabilities, achieving a 23 dB attenuation effect at the fundamental frequency. Furthermore, the PID control algorithm exhibits enhanced isolation performance at low frequencies and facilitates directional tracking of target signals. Full article

In this paper, a two-DOF L-shaped yoke spherical actuator based on the principle of traditional voice coil actuators is developed. By utilizing the shape characteristics of the yoke and the magnetization direction of the magnet, the magnetic flux is concentrated and the magnet is shared, thereby improving the performance of the actuator. In the design process, SOLIDWORKS 2018 software is used for design modeling and assembly simulation, ANSYS Maxwell 2018 software is employed for magnetic circuit analysis and electromagnetic simulation, while MATLAB is utilized for analyzing the dynamic characteristics through a mathematical model. A prototype was also fabricated, and torque measurement experiments were conducted to verify the performance and feasibility of the proposed design. Full article

Manipulation involves both fine tactile feedback, with dynamic transients perceived by fingerpad mechanoreceptors, and kinaesthetic force feedback, involving the whole hand musculoskeletal structure. In teleoperation experiments, these fundamental aspects are usually divided between different setups at the operator side: those making use of lightweight gloves and optical tracking systems, oriented toward tactile-only feedback, and those implementing exoskeletons or grounded manipulators as haptic devices delivering kinaesthetic force feedback. At the level of hand interfaces, exoskeletons providing kinaesthetic force feedback undergo a trade-off between maximum rendered forces and bandpass of the embedded actuators, making these systems unable to properly render tactile feedback. To overcome these limitations, here, we investigate a full upper limb exoskeleton, covering all the upper limb body segments from shoulder to finger phalanxes, coupled with linear voice coil actuators at the fingertips. These are developed to render wide-bandwidth tactile feedback together with the kinaesthetic force feedback provided by the hand exoskeleton. We investigate the system in a pick-and-place teleoperation task, under two different feedback conditions (visual-only and visuo-haptic). The performance based on measured interaction forces and the number of correct trials are evaluated and compared. The study demonstrates the overall feasibility and effectiveness of a complex full upper limb exoskeleton (seven limb-actuated DoFs plus five hand DoFs) capable of combined kinaesthetic and tactile haptic feedback. Quantitative results show significant performance improvements when haptic feedback is provided, in particular for the mean and peak exerted forces, and for the correct rate of the pick-and-place task. Full article

The performance of laser beams in tracking Lissajous scan trajectories is severely limited by beam jitter. To enhance the performance of fast steering mirror (FSM) control in tracking Lissajous scan trajectories, this paper proposed a fractional order active disturbance rejection controller (FOADRC) and verified its effectiveness in improving system scanning tracking accuracy. A dynamic mathematical model of a fast steering mirror was studied, and the design of parameters for the control mode of the closed-loop system was determined. A reduced-order linear active disturbance rejection controller suitable for FSM systems was designed, and the corresponding fractional-order proportional differentiation (FOPD) controller was determined according to the mathematical model. The use of the designed controller enabled high-performance tracking of high-frequency Lissajous scanning curves (X-axis 500 Hz, Y-axis 350 Hz) and met the need for high-frequency repetitive scanning. The controller has the characteristics of simple implementation and low computational complexity and is suitable for closed-loop control applications in engineering. Full article

This paper presents a state-of-the-art overview of fine beam steering mechanisms for free-space optical communication on satellites. Precise beam pointing is a critical task for the successful operation of free-space optical communication systems. Based on past research and ongoing projects, the use of fast steering mirrors (FSMs) is still the most popular solution for free-space optical communication applications. Although a variety of commercial off-the-shelf (COTS) FSM solutions exist, there is limited publicly available data on these solutions in the space environment. Three main actuation principles are considered (electro-static force actuated, magnetic force actuated, piezo-effect actuated) and reviewed using available data from past space missions. The article describes the most important criteria in the choice of a fine beam steering solution for free-space optical communication in space. Full article

We examined discrimination accuracy of vibrotactile patterns on the upper forearm using a 2 × 3 array of voice coil actuators to generate 100 Hz vibrotactile stimulation. We evaluated participants’ ability to recognize distinct vibrotactile patterns presented both simultaneously (1000 ms) and sequentially (500 ms with a 450 ms interval). Recognition accuracy was significantly higher for sequential (93.24%) than for simultaneous presentation (26.15%). Patterns using 2–3 actuators were recognized more accurately than those using 4–5 actuators. During sequential presentation, there were primacy and recency effects; accuracy was higher for the initial and final stimulations in a sequence. Over time, participants also demonstrated a learning effect, becoming more adept at recognizing and interpreting vibrotactile patterns. This underscores the potential for skill development and emphasizes the value of training for wearable vibrotactile devices. We discuss the implications of these findings for the design of tactile communication devices and wearable technology. Full article

In pipe organs, the oldest and most commonly chosen system for connecting the organist operator to the source of sound (i.e., the pipes to the action) is mechanical action. This article presents a mechatronic action with a voice coil motor (VCM) actuator to reproduce the action of a mechanical action on pipe organ. The mechatronic action makes it feasible to mechanically separate the keyboard from the pipes and to determine the control strategy for the mechatronic action by utilizing sensors, an actuator and a microcontroller. The time response of the organ pipe with mechanical action and the requirements for mechatronic action were outlined. The control strategy was preceded by measurements of the mechanical action and measurements of the behavior of the VCM actuator system, which moves the pneumatic valve pallet. Two control strategies, open-loop and closed-loop, were proposed and analyzed for the mechatronic action with the VCM actuator. According to the results, the suggested control strategies successfully reproduce the mechanical action’s behavior to a good extent. Full article

To meet the ever-increasing demand for next-generation lithography machines, the actuator plays an important role in the achievement of high acceleration of the wafer stage. However, the voice coil motor, which is widely used in high-precision positioning systems, is reaching its physical limits. To tackle this problem, a novel way to design the actuator using the magnetoresistance effect is argued due to the high force densities. However, the strong nonlinearity limits its application in the nan-positioning system. In particular, the hysteresis is coupled with eddy effects and displacement, which lead to a rate-dependent and displacement-dependent hysteresis effect in the reluctance actuator. In this paper, a Hammerstein structure is used to model the rate-dependent reluctance actuator. At the same time, the displacement-dependent of the model is regarded as the interference with the system. Additionally, a control strategy combining inverse model compensation and the disturbance observer-based discrete sliding mode control was proposed, which can effectively suppress the hysteresis effect. It is worthy pointing out that the nonlinear system is transformed into a linear system with inversion bias and disturbance by the inverse model compensation. What is more, the sliding mode controller based on the disturbance observer is designed to deal with the unmodeled dynamics, displacement disturbances, and model identification errors in linear systems. Thus, the tracking performance and robustness to external disturbances of the system are improved. The simulation results show that it is superior to the PI controller combined with an inverse compensator and even to the discrete sliding mode controller connected with inverse compensator, confirming the effectiveness of the novel control method in alleviating hysteresis. Full article

What are the effects of frequency variation of vibrotactile stimuli on localization acuity? The precise localization of vibrotactile stimuli is crucial for applications that are aimed at conveying vibrotactile information. In order to evaluate the ability to distinguish between vibrotactile stimuli based on their frequency and location on the forearm, we used a relative point localization method. Participants were presented with pairs of sequential vibrotactile stimuli at three possible locations on the forearm and asked to determine whether the second stimulation occurred at the same location as the first one in the pair or not. The stimulation frequency varied between 100 Hz, 150 Hz, 200 Hz and 250 Hz, which covers the range of frequencies that human observers are most sensitive to. The amplitude was kept constant. Our results revealed that the ability to discriminate between actuators remained unaffected by variations in the frequency of vibrotactile stimulation within the tested frequency range. The accuracy of the tactile discrimination task was heavily dependent on the location of the stimulation on the forearm, with the highest accuracy close to the wrist and elbow, locations that may serve as tactile anchor points. Our results highlight the critical role of stimulation location in precise vibrotactile localization and the importance of careful consideration of location in the design of forearm-mounted vibrotactile devices. Full article
