Search Results (6,853)

To address the challenge of effectively extracting early-stage failure features in rolling bearings, this paper proposes a two-stage harmonic optimization-gram method based on spectral amplitude modulation (SAM-TSHOgram). The method first employs amplitude spectra with varying weighting exponents to preprocess the signal, performing nonlinear adjustments to the vibration signal’s spectrum to enhance weak periodic impact characteristics. Subsequently, a two-stage evaluation strategy based on spectral coherence (SCoh) was designed to adaptively identify the optimal frequency band (OFB). The first stage employs the Periodic Harmonic Correlation Strength (PHCS) metric, based on autocorrelation, to coarsely screen candidate bands with strong periodic structures. The second stage utilizes the Sparse Harmonic Significance (SHS) metric, based on spectral negative entropy, to refine the candidate set, selecting bands with the most prominent harmonic features. Finally, SCoh is integrated over the selected OFB to generate an Improved Envelope Spectrum (IES). The proposed method was validated using both simulated and experimental vibration signals from bearings and gearboxes. The results demonstrate that SAM-TSHOgram significantly outperforms conventional approaches such as EES, Fast Kurtogram, and IESFOgram in terms of signal-to-noise ratio (SNR) enhancement, harmonic clarity, and diagnostic robustness. These findings confirm its potential for reliable early fault detection in rolling bearings. Full article

This study aims to demonstrate the feasibility of a hybrid measurement system that combines Laser Doppler Vibrometry (LDV) and conventional accelerometers for operational modal analysis (OMA) of civil engineering structures. The proposed approach addresses the limitations of traditional accelerometer-based systems, particularly for large-scale or inaccessible structures, by integrating non-contact LDV measurements with conventional sensor data. Experimental tests were conducted on a cantilever beam and a pedestrian laboratory footbridge to validate the hybrid system. The LDV was used to measure velocity at key points, while accelerometers provided complementary reference acceleration measurements. Reflective targets were employed to facilitate non-contact data collection, allowing for the subsequent reuse of these targets for repeated measurements. The velocity data from the LDV were differentiated to obtain acceleration and integrated to estimate displacement, enabling a direct combination with accelerometer data. ARTeMIS Modal software was utilized to process and analyze the collected data, successfully identifying the natural frequencies and vibration modes of both structures. The results demonstrate that the LDV–accelerometer hybrid system effectively captures the dynamic behavior of structures, offering a comprehensive solution for modal analysis without extensive sensor deployment. This approach provides significant advantages in scenarios where traditional methods are impractical, positioning the hybrid system as a promising tool for dynamic analysis and infrastructure monitoring of complex structures. Full article

Spherical caps exploit their intrinsic curvature to achieve efficient stress distribution, delivering exceptional strength-to-weight ratios. This advantage renders them indispensable for aerospace systems, pressurized containers, architectural domes, and structures operating in extreme environments, such as deep-sea or nuclear containment. Their superior load-bearing capacity enables diverse applications, including satellite casings and high-pressure vessels. Meticulous optimization of geometric parameters and material selection ensures robustness in demanding scenarios. Given their significance, this study examines the natural frequency and static response of bio-inspired helicoidally laminated carbon fiber–reinforced polymer matrix composite spherical panels surrounded by Winkler elastic foundation support. Utilizing a 3D elasticity approach and the finite element method (FEM), the governing equations of motion are derived via Hamilton’s Principle. The study compares five helicoidal stacking configurations—recursive, exponential, linear, semicircular, and Fibonacci—with traditional laminate designs, including cross-ply, quasi-isotropic, and unidirectional arrangements. Parametric analyses explore the influence of lamination patterns, number of plies, panel thickness, support rigidity, polar angles, and edge constraints on natural frequencies, static deflections, and stress distributions. The analysis reveals that the quasi-isotropic (QI) laminate configuration yields optimal vibrational performance, attaining the highest fundamental frequency. In contrast, the cross-ply (CP) laminate demonstrates marginally best static performance, exhibiting minimal deflection. The unidirectional (UD) laminate consistently shows the poorest performance across both static and dynamic metrics. These investigations reveal stress transfer mechanisms across layers and elucidate vibration and bending behaviors in laminated spherical shells. Crucially, the results underscore the ability of helicoidal arrangements in augmenting mechanical and structural performance in engineering applications. Full article

The vibration compaction behavior of fully graded fresh concrete differs fundamentally from that of conventional two-graded concrete. Based on measured vibration responses of an internal vibrator and sinking-ball tests, an energy transfer model for fully graded concrete was established by incorporating the effects of aggregate-specific surface area, paste–aggregate ratio, dynamic damping, and natural frequency, and the spatiotemporal attenuation of vibration energy in fresh concrete was systematically analyzed. Experimental results indicate that fully graded concrete exhibits a higher energy absorption capacity during the early stage of vibration, with a maximum energy absorption rate of 423 W and a peak energy transfer efficiency of 76.3%, both of which are significantly higher than those of two-graded concrete at the same slump. However, as a dense aggregate skeleton rapidly forms, the energy absorption efficiency of fully graded concrete decreases more rapidly during the middle and later stages of vibration, showing a characteristic pattern of “high initial absorption followed by rapid attenuation.” Through segregation assessment and porosity analysis, a safe vibration energy range for fully graded concrete was quantitatively determined, with lower and upper energy thresholds of 159.7 J·kg⁻¹ and 538.5 J·kg⁻¹, respectively. In addition, the experiments identified recommended vibration durations of 30–65 s and effective vibration influence radii of 22–85 mm for fully graded concrete under different slump conditions. These findings provide a quantitative basis for the control of vibration parameters and energy-oriented construction of fully graded concrete. Full article

The Survey Camera (SC) is the key instrument of the China Space Station Telescope (CSST), with its imaging performance significantly constrained by microvibrations from internal sources such as the shutter and cryocoolers. This paper proposes a systematic microvibration suppression scheme integrating disturbance source control, payload isolation, and transfer path optimization to meet the stringent requirements. The Cryocooler Assembly (CCA) compressor adopts a symmetric piston layout and a real-time vibration cancellation algorithm to reduce the vibration. Coupled with a vibration isolator designed by combining hydraulic damping and a flexible structure, it achieves a vibration isolation efficiency of 95%. The shutter adopts dual-blade symmetric design with sinusoidal angular acceleration control, ensuring its vibrations fall within the compensable range of the Fast Steering Mirror (FSM). And the finite element optimization method is used to optimize the dynamic characteristics of the Support Structure (SST) made of M55J carbon fiber composite material, to avoid resonance in the critical frequency bands. System-level tests on the integrated SC show that the RMS values of vibration force and torque within 8–300 Hz are 0.25 N and 0.08 N·m, respectively, meeting design specifications. This scheme validates effective microvibration control, guaranteeing the SC’s high-resolution imaging capability for the CSST mission. Full article

The ultrasonic guided wave method is successfully used for structural health monitoring (SHM) of aircraft structures utilizing PZT (Pb-Zr-Ti based piezoceramic material) sensors for guided wave generation and detection. To increase the mechanical durability of the sensors in operational conditions, this paper demonstrates the feasibility of the integration of PZTs into the Glass fiber/Polymethyl methacrylate (G/PMMA) composite plate and evaluates the possibility of impact damage detection using generated guided waves. Two types of PZT sensors were embedded into different layers during the manufacturing process. Generally, radial mode disc sensors are used for Lamb wave generation, and thickness-shear square-shaped sensors are used for both Lamb and shear wave generation. First, the wave propagation was analyzed considering the sensor type and sensor placement within the layup. The main objective was to propose the optimal sensor network with embedded sensors for successful impact damage detection. Lamb wave frequency tuning of disk sensors and unique vibrational characteristics of integrated shear sensors were exploited to selectively actuate only one guided wave mode. Finally, the Reconstruction Algorithm for the Probabilistic Inspection of Damage (RAPID) was utilized for damage localization and visualization. Full article

We numerically investigate vibrational resonance (VR) and vibrational energy harvesting (VEH) in a mechanical system driven by a low-frequency periodic force, using time-periodic phase modulation of the potential function. We focus on how the characteristics of high-frequency excitations influence frequency response, power output, and harvesting efficiency. We uncover two modulation-induced phenomena—resonant induction and resonant amplification—that together produce a double VR effect. We demonstrate that in the weak low-frequency regime ($\omega \le 0.3$), the power output can exceed that of the moderate regime ($\omega \approx 1$). Among the modulating waveforms, square waveform (SQW) demonstrated superior efficiency over other waveforms, which corresponds to higher response amplitude. In addition, the frequency ratio $K=6.7$ yielded optimal performance compared to other frequency ratios, thereby providing both maximum power output and efficiency. These findings suggest a new design strategy for energy harvesters, leveraging both primary and induced VR to enhance performance. Full article

The structural vibration of industrial droplet dispensers can be modeled by telegraph-like equations to a good approximation. We reinterpret the telegraph equation from the standpoint of an electric–circuit system consisting of an inductor and a resistor, which is in interaction with an environment, say, a substrate. This interaction takes place through a capacitor and a shunt resistor. Such interactions serve as leakage. We have performed an analytical investigation of the frequency dispersion of telegraph equations over an unbounded one-dimensional domain. By varying newly identified key parameters, we have not only recovered the well-known characteristics but also discovered crossover phenomena regarding phase and group velocities. We have examined frequency responses of the electric circuit underlying telegraph equations, thereby confirming the role as low-pass filters. By identifying a set of physically meaningful reduced cases, we have laid the foundations on which we could further explore wave propagations over a finite domain with appropriate side conditions. Full article

Spacer fabrics are a breathable material option for wearable cushioning, but the cushioning performance is still not comparable to that of traditional elastomeric cushioning materials. The polymer-based connective structure of spacer fabrics largely affects fabric properties, compression, and mechanical performance, and this is a research gap that calls for the development of spacer fabrics with enhanced cushioning functions. This study develops a new square-wave inlay pattern and investigates the effects of the inlay structure and spatial frequency of the spacer course, as well as the effects of the silicone inlay on compression, impact force absorption, and vibration isolation of the spacer fabric. Twelve samples are designed and evaluated. The results show that the square-wave inlaid spacer fabric has higher energy absorption during compression. The square-wave pattern with a shorter transition distance between the front and back tuck stitches could increase the inclination angle close to a right angle, and extra tuck stitches on the surface float could secure the square-wave structure to enhance the impact force absorption ability. The increment in the spatial frequency of spacer courses provides a less stiff fabric with lower impact force absorption but higher vibration isolation ability. This study shows the innovative development of spacer fabric for enhancing cushioning properties. Full article

With the rapid development of high-voltage DC (HVDC) power systems, accurate measurement of surface electrostatic potential on insulating components has become critical for electric field assessment and insulation reliability. This paper proposes an electrostatic potential sensor based on cantilever micro-vibration modulation, which employs piezoelectric actuators to drive high-frequency micro-vibration of cantilever-type shielding electrodes, converting the static electrostatic potential into an alternating induced charge signal. An electrostatic induction model is established to describe the sensing principle, and the influence of structural and operating parameters on sensitivity is analyzed. Multi-physics coupled simulations are conducted to optimize the cantilever geometry and modulation frequency, aiming to enhance modulation efficiency while maintaining a compact sensor structure. To validate the effectiveness of the proposed sensor, an electrostatic potential measurement platform for insulating components is constructed, obtaining response curves of the sensor at different potentials and establishing a compensation model for the working distance correction coefficient. The experimental results demonstrate that the sensor achieves a maximum measurement error of 0.92% and a linearity of 0.47% within the 1–10 kV range. Surface potential distribution measurements of a post insulator under DC voltage agreed well with simulation results, demonstrating the effectiveness and applicability of the proposed sensor for HVDC insulation monitoring. Full article

During orbital service, precision aerospace equipment is frequently subjected to harsh vibration environments that can significantly affect reliability and service life. Consequently, the development of effective vibration isolation technologies has become a crucial aspect of aerospace structural design. In this study, random vibration theory and frequency-domain analysis methods were employed to investigate the dynamic response characteristics of a symmetrical frustum-shaped metal rubber (FSMR) isolation device under complex operating conditions. The influence of metal rubber density, spring stiffness, and input vibration level on its isolation performance was systematically examined. This work presents the first systematic experimental investigation into the nonlinear dependencies of the performance of a symmetrical frustum-shaped metal rubber isolator on multiple parameters (density, stiffness, excitation level) under random vibration. The test results show that under identical excitation conditions, the device achieves optimal damping ratio and isolation efficiency (59.71%) when the metal rubber density is 2.0 g/cm³. A moderate increase in spring stiffness reduces the resonance peak and improves stability, with a stiffness of 100 kN/m exhibiting the best overall performance. In addition, higher input vibration levels markedly elevate the acceleration response and the resonant peak amplification factor of the isolator, demonstrating that high-intensity excitation magnifies the vibration response and degrades the isolation efficiency. Full article

The working conditions of bearings, as a key component in electromechanical systems, are becoming increasingly complex with the rapid development of current intelligent manufacturing technology. Therefore, it is difficult to accurately identify the abnormal operating state of the bearing through a single signal. In addition, data-based bearing fault diagnosis methods insufficiently utilize bearing prior knowledge under complex working conditions. To address the above issues, this paper proposes a bearing fault diagnosis method based on multi-source information fusion with physical prior knowledge (MSIF-PPK). An information fusion module and a physical embedding module are designed: the former module fuses frequency-domain, time–frequency-domain, and working condition information through an attention mechanism, while the latter one embeds physical working condition data and features. The feasibility and the effectiveness of the modules are verified through comparative experiments and ablation experiments using the Southeast University (SEU) Bearing Dataset, the Mehran University of Engineering and Technology (MUET) Induction Motor Bearing Vibration Dataset, and the Harbin Institute of Technology (HIT) Aeroengine Bearing Dataset. Experimental results show that this method is feasible, reliable, and interpretable for bearing fault diagnosis under complex working conditions. Full article

This paper introduces an Improved Red-Billed Blue Magpie Optimizer (IRBMO) to enhance the Maximum Second-Order Cyclostationary Blind Deconvolution (CYCBD) method, which traditionally depends on manual, experience-based setting of its key parameters (filter length $L$ and cyclic frequency $\mathsf{\alpha }$). By adopting an Improved Envelope Spectrum Entropy (EK) as the fitness function, the IRBMO autonomously optimizes these parameters, eliminating the need for prior knowledge and improving its applicability in industrial settings. The Improved Red-Billed Blue Magpie algorithm is employed to adaptively optimize the penalty parameter and kernel function parameter of the support vector machine, thereby obtaining an optimal support vector machine model. By introducing fuzzy entropy theory, the feature vectors of filtered signals—processed by the Cyclostationary Blind Deconvolution method with optimal parameters—are extracted and used as input for the optimally parameterized support vector machine, achieving multi-fault classification for bogie bearings. The results show that the IRBMO-CYCBD method significantly enhances the periodic weak fault impulse components and improves the signal-to-noise ratio of the processed signal. Envelope spectrum analysis of the filtered signal allows for clear observation of shaft frequency components, as evidenced by the accurate identification of the 110 Hz fundamental frequency and its harmonic components at 220 Hz, 330 Hz, and 440 Hz in the spectrum. Simulation tests verify the efficacy of the IRBMO-CYCBD method in processing rolling bearing vibration signals under strong noise interference. Under laboratory conditions, simulation experiments were conducted by collecting vibration acceleration signals from rolling bearings in various states. The aforementioned method was applied for fault diagnosis, achieving a maximum diagnostic accuracy of 100%. Through repeated experiments, it was verified that this method meets the fault diagnosis requirements for rolling bearings in metro train bogies. Full article

This study presents the design optimization and semi-active resonance control of a small-scale vortex-induced vibration (VIV) bladeless wind turbine (BWT) equipped with a power efficient binary resonance controller. The proposed system integrates a smart-material-based stiffness-tuning module that adaptively adjusts the structure frequency of the BWT to match varying wind speeds. A coupled mechanical–electromagnetic model for BWT was formulated to quantify the relationships among key design parameters, including mast geometry, pivot length, and rod dimensions, and the resulting induced voltage. Multi-parameter optimization was performed to maximize energy-harvesting efficiency under mass and geometric constraints. Experimental evaluation verified an 88.9 % resonance shift capability, broadening the operational lock-in wind speed range from 1.7 to 3.2 m/s. The results confirm the potential of the semi-active BWT control concept for compact, low-noise, and adaptive wind-energy harvesters. Full article

This study investigates the application of machine learning (ML) techniques for predicting vibration frequencies of thin rectangular plates with variable thickness. Traditional optimization methods, such as genetic algorithms, require repeated solutions of the plate vibration eigenproblem using finite element (FE) analysis, which is computationally expensive. To reduce this cost, a surrogate model based on artificial neural networks (ANNs) is proposed as an efficient alternative. The dataset includes variations in plate geometry, boundary conditions, and thickness distribution, encoded numerically for model training. ANN architecture and hyperparameters—such as the number of hidden layers, neurons per layer, and activation functions—were systematically tuned to achieve high prediction accuracy while avoiding overfitting. Data preprocessing steps, including standardization and scaling, were applied to improve model stability. Performance was evaluated using metrics such as RMSE and R². The results demonstrate that ANNs can accurately predict eigenvalues with significantly reduced computational effort compared to FE analysis. This approach offers a practical solution for integrating machine learning into structural optimization workflows. Full article
