The precise real-time detection of polytetrafluoroethylene (PTFE) emulsion rotary vibration sieve levels is critical for improving production efficiency, ensuring product quality, and safeguarding personnel safety. This research presents a deep-learning-oriented video surveillance model for the intelligent level detection of vibrating screens, waste drums, and emulsion outlets, effectively addressing the limitations of traditional methods. With the introduction of TransResNet, which combines Vision Transformer (ViT) with ResNet, we can utilize the advantages of both approaches. ViT has excellent global information capture capability for processing image features, while ResNet excels in local feature extraction. The combined model effectively recognizes level changes in complex backgrounds, enhancing overall detection performance. During model training, synthetic data generation is used to alleviate the marker scarcity problem and generate synthetic images under different liquid level states to further enrich the training dataset, solve the issue of unequal data distribution, and enhance the model’s capacity to generalize. In order to validate the efficacy of our proposed model, we carried out a performance test with real-world data obtained from a material production site. The test results show that the model achieves 96%, 99%, and 99% accuracy at three test points, respectively: the vibrating screen, waste drum, and emulsion. These results not only prove the efficiency of the model but also highlight its significant value in practical applications. Full article

Existing cleaning devices for edible sunflower have a low cleaning efficiency, high cleaning loss rate, and high impurity rate; therefore, a wind-sieve-type cleaning device for edible sunflower harvesting was designed. According to the characteristics of dislodged objects, a vibrating screen for the device was designed, and the dislodged edible sunflower objects in the device were used for a mechanical analysis of the force conditions to determine the displacement of the different edible sunflower objects dislodged by the action of airflow. Using FLUENT-DEM gas–solid coupling simulation technology, the velocity of the flow field, the velocity vector, and the trajectory of the dislodged objects inside the cleaning device were analyzed, and the law of motion applied to the airflow and the dislodged objects inside the device was clarified. According to the results of the coupled simulation analysis, the key factors affecting the operation of the cleaning device were wind speed, vibration frequency, and amplitude. Based on the key factors of wind speed, vibration frequency, and amplitude, an orthogonal rotary combination test was carried out with the loss rate and impurity rate of cleaned grains as the evaluation indexes, and the test parameters were optimized to obtain the optimal combination of operating parameters of the device, which were as follows: wind speed: 30 m·s⁻¹; vibration frequency: 8.44 Hz; and amplitude: 41.35 mm. With this combination of parameters, the seed loss rate and impurity rate reached 3.47% and 6.17%, respectively. Based on the optimal combination of operating parameters, a validation test was performed, and the results of this test were compared with the results of the test bench using this combination of parameters. The results show that the relative errors of the loss rate and impurity rate between the bench test and the simulation test were 3.45% and 3.07%, respectively, which are less than 5%, proving the reliability of the simulation analysis and the reasonableness of the design of the test bench. Full article

To improve its cleaning performance, the peanut sheller’s air–screen cleaning device was used as the research object, and a numerical simulation was carried out. A scheme was proposed to optimize the installation angle of the screen surface of the air–screen cleaning device, and the influence of the airflow velocity of the sieve surface before and after the structural improvement of the machine on the airflow distribution of the whole chamber was evaluated. At the same time, the computational fluid dynamics–discrete element method (CFD–DEM) of coupling simulation was used to carry out single-factor simulation tests on the improved air–screen cleaning device, analyze the movement trajectory, velocity, and displacement of the extrudates in the cleaning chamber, characterize the separation law of extrudates, and determine the parameter ranges for each factor. In addition, based on the central composite Box–Behnken design, an orthogonal simulation test was carried out with three factors, including fan speed, amplitude, and vibration frequency, and the influence of each factor on the kernel loss rate and impurity rate was investigated. Furthermore, the influencing factors were optimized, and the optimal parameter combination was obtained; when the fan speed was 1682.72 r/min, the amplitude was 3.74 mm, and the vibration frequency was 492.86 Hz, it was more conducive to the cleaning of kernels. Finally, the accuracy of the simulation and optimization methods was verified via the machine test, and the optimal parameter combination was obtained: at a fan speed of 1680 r/min, an amplitude of 3.7 mm and a vibration frequency of 490 Hz were achieved, and the kernel loss rate and impurity rate were 2.01% and 2.42%, 3.71 and 4.42 percentage points lower than those before optimization, respectively. Full article

To solve the problem of grain loss caused by nibbling during the working process of the maize ear and stem harvesting machine, a vibrating screen-type grain-recovery device with an upper centrifugal fan was designed. The device mainly consists of a centrifugal fan and vibrating screen. The work process of the grain-recovery device is theoretically analyzed, and it is clarified that the turning of the bracts is the key to separating the bracts from the grains, and the design criteria of the vibrating screen are obtained. The CFD–EDEM coupled single-factor simulation experiment was carried out on the size of the vibrating screen sieve hole and the number of draft bars, and the motion posture of the bracts was simulated. Based on the previous CFD–EDEM coupled simulation study, the orthogonal experiment was carried out on the fan speed, vibration screen drive-shaft speed, and operation speed of the grain-recovery device. The orthogonal experimental results show that, when the fan speed is 1000 r/min, the vibration screen drive-shaft speed is 300 r/min, and the operation speed is 3.62 km/h, the performance of the grain-recovery device reaches the optimum level, and the grain recovery rate is approximately 85%. Full article

The condition-based maintenance of vibrating screens requires new methods of their elements’ diagnostics due to severe disturbances in measured signals from vibrators and falling pieces of material. The bolted joints of the sieving deck, when failed, require a lot of time and workforce for repair. In this research, the authors proposed the model-based diagnostic method based on modal analysis of the 2-DOF system, which accounts for the interaction of the screen body and the upper deck under conditions of bolted joint degradation. It is shown that the second natural mode with an out-of-phase motion of the upper deck against the main screen housing may coincide with the excitation frequency or its higher harmonics, which appear when vibrators’ bearings are in bad condition. This interaction speeds up bolt loosening and joint opening by the dynamical loading of higher amplitude. The proposed approach can be used to detune the system from resonance and anti-resonance to reduce maintenance costs and energy consumption. To prevent abrupt failures, such parameters as second natural mode frequency, damping factor, and phase space plot (PSP) distortion measures are proposed as bolt health indicators, and these are verified on the laboratory vibrating screen. Also, the robustness is tested by the impulsive non-Gaussian noise addition to the measurement data. A special diagram was proposed for the bolted joints’ strength capacity assessment and maintenance actions planning (tightening, replacement), depending on clearance in the joints. Full article

Predictive maintenance is increasingly popular in many branches, as well as in the mining industry; however, there is a lack of spectacular examples of its practice efficiency. Close collaboration between Omya Group and Wroclaw University of Science and Technology allowed investigation of the failure of the inertial vibrator’s bearing. The signals of vibration are captured from the sieving screen just before bearing failure and right after repair, when it was visually inspected after replacement. The additional complication was introduced by the loss of stable attachment of the vibrator’s shield, which produced great periodical excitation in each place of measurement on the machine. Such anomalies in the signals, in addition to falling pieces of material, made impossible the diagnostics by standard methods. However, the implementation of advanced signal processing techniques such as time–frequency diagrams, envelope spectrum, cyclic spectral coherence, orbits analysis, and phase space plots allowed to undermine defects (pitting on the inner ring). After repair, the amplitudes of vibration from the damaged bearing side were reduced by five times, while sound pressure was only two times lower. The quantitative parameters of vibrations showed significant changes: time series RMS (−68%) median energy of spectrograms (89%), frequencies ratio of cyclic spectral coherence (−85%), and average amplitude of harmonics in envelope spectrum (−80%). The orbits demonstrated changes in inclination angle (16%) and sizes (−48, … −96%), as well as phase space plots sizes (−28, … −67%). Directions of further research are considered. Full article

The application of the conventional vibrating screen to the separation of the black soldier fly (BSF) sand mixture has several problems (e.g., high rate of impurity and low efficiency). A two-stage sieve surface vibratory sorting device with combined planar and curved surfaces was investigated, and its critical operating parameters were determined. Moreover, a coupling simulation model of the sieve surface and the larvae–sand mixture was built based on the characteristics of the BSF breeding process, and its critical operating parameters were optimized. Next, the Plackett–Burman test was set to determine the significant factors for the separation of two-stage sieve surface vibrations as amplitude and curved height. The process of crushing separation of frass aggregates and the process of collision transport of BSF larvae were studied through simulation, and the actual test stand was built for parameter verification tests. The preferred parameter combinations comprised 0.012 m amplitude and 0.007 m curved surface height at the impurity rate of 2.34% and the insect injury rate of 5.65%, as well as 0.013 m amplitude and 0.005 m curved surface height at the impurity rate of 3.15% and the insect injury rate of 4.3%, respectively, thus conforming to the requirement of separating BSF larvae–sand mixture to reduce the impurity and prevent larvae injury. The results of this study can lay a basis for the structural improvement and operational parameter adjustment of the BSF larvae–sand mixture separation device. Full article

The screen surface particle distribution is an important factor affecting screening performance. A vibrating screen with an adjustable horizontal attitude angle was used, the non-uniform feeding and horizontal attitude angles were used as variables and the screening of rice particles was simulated by the discrete element method. The screen surface distribution and movement speed of the rice particles were analyzed based on the influence of the variables on screening performance. The results indicated that the material distribution became more unbalanced with the increase in non-uniform feeding, and the particles’ speed increased with the increase in attitude angle on the y-axis. The particles experienced accelerated dispersion, which improved the unbalanced distribution of the particles and screening performance. According to the loss rate, the horizontal attitude angle adjustment model was established and optimized under non-uniform feeding. The reliability of the model was verified by simulation. A bench test was carried out to verify the simulation. The optimization model can reduce the loss rate, improve the screening performance of non-uniform feeding, and provide a reference for the material screening of non-uniform feeding. Full article

In order to realize mechanized and efficient harvesting of tiger nuts, study the efficient screening technology of beans and soil in a mechanized harvesting operation and improve the harvesting operation efficiency of crawler-type tiger nut harvesters, a theoretical analysis of the motion process of detritus particles on a sieve surface was conducted to determine the main factors affecting the motion of the particles on the sieve surface. A numerical simulation of the sieving process using the discrete element method was conducted to improve the screening efficiency of tiger nuts. The transport law of the debris particle population was analyzed from different perspectives, such as the average velocity of particle motion, particle distribution rate, screening efficiency and loss rate. The effects of factors such as screen amplitude (SA), vibration frequency (VF) and inclination angle (IA) on the sieving performance of the tiger nut threshing and screening device were investigated. The results show that sieving performance evaluation indexes, such as the average speed of particle movement, particle distribution rate, screening efficiency and loss rate, are non-linearly related to the factors of screen amplitude, vibration frequency and screen inclination angle; the effects of amplitude and frequency on the distribution particle size are consistent and show a gradual increase, with the distribution particle size reaching 3.32 mm at an amplitude of 14 mm and 3.46 mm at a frequency of 22 Hz. In the sieving process, the average velocity of the particle population decreases gradually along the direction of motion, and the influence of each factor on the average velocity of the particle population in the motion of the detritus is similar, all showing an increasing trend. This study can provide a reference for exploring the transport law of particles and the efficient screening technology of tiger nuts. Field harvesting tests showed that the screening efficiency and loss rate were 92.87% and 0.83%, respectively, at a screen amplitude of 14 mm, a vibration frequency of 10 Hz and an inclination angle of 2°, and the test results corresponded to the simulation results and met the design requirements of the tiger nut harvester. This study can provide reference for the investigation of the particle transport law and efficient screening technology for tiger nuts. Full article

Various vibrating screens are often applied in various industries, e.g., mining, agriculture, and others. The complex shapes of the screen trajectories in the oscillating motion strongly affect the best processing properties of such machines. One of the possible methods for obtaining such complex shapes is the application of double-frequency vibrators on such screens. The goal of the present study was to analyze the dynamical behavior of the prototype sifter sieve elaborated. The simulation model of such a sifter sieve and the research stand for studies on its sifter trajectories were elaborated. Simulations of sifter motion were conducted, and their results were compared with those obtained from measurements on the research stand. The recommendations as to the frequency ratio of vibrators enabling obtaining a high complexity of sieve movement have been formulated and included in the paper. Particularly, the multiple of the value equal to one third for the ratio of angular velocities under their reverse synchronization for two rotary vibrators exciting the screen analyzed was the best among all analyzed values of such a ratio. Full article

Among food crops, rice has the largest planting area, the highest yield per unit area and the largest total yield in China. However, cleaning performance is reduced by the high moisture content of rice during the harvesting process. In order to decrease the adhesion among wet rice threshed mixtures and improve the cleaning performance, the method of hot airflow cleaning was proposed. Firstly, the fluidization characteristics of wet sticky rice under the action of hot air were compared with those of dry particles. In this work, the minimum suspension velocity and the fastest suspension time were used and quantified to characterize the fluidization characteristics. It was found that the minimum suspension velocity and the fastest suspension time of the wet rice threshed mixture are both higher than those of dry particles due to the liquid bridge force. Moreover, the dispersion degree of the wet rice threshed mixture can be improved by the hot airflow due to the decrease in the surface water content of impurities. Secondly, the influence of the temperature and vibration frequency in the air-and-screen cleaning device on the dispersion characteristics of the wet rice threshed mixture were investigated. The accumulation mass was measured to quantify the dispersion degree. It was found that the increase in vibration frequency has little effect on the dispersion of the wet rice threshed mixture. The accumulation mass on the front of the sieve decreases slightly with the increase in the gas temperature range from ambient temperature to 30 °C. Then, the dispersion degree increases rapidly when the temperature exceeds 40 °C. The dispersion effect is the best when the temperature is 50 °C and the vibration frequency is 5 Hz. These results provide a basis for the cleaning of the wet rice threshed mixture in a combine harvester. Full article

The main task of mineral processing plants is to further process the raw material extracted in the mining faces into a concentrate with the highest possible concentration of the final product. In practice, it is a complex process in which several stages can be distinguished. After the ore has been transported to the surface by the skip shaft, one of the first steps is sieving the ore, which is typically performed using vibrating mining screens. In a typical Ore Enrichment Plant, the screening process is carried out by several such machines. This is a typical bottleneck in the technological chain. For this reason, the main challenge for users is to achieve the highest reliability and efficiency of these technical facilities. The solution is to focus on predictive maintenance strategies based on the development of monitoring and advanced diagnostic procedures capable of estimating the time of safe operation. This work was developed as part of an advanced diagnostic system ensuring comprehensive technical conditioning and early fault detection of components such as the engine, transmission, bearings, springs, and screen. This article focuses on vibration data. The problem of damage detection in the presence of periodically impulsive components resulting from falling feed material on the screen and its further screening process has been considered. These disturbances are of a non-Gaussian noise nature, the elimination of which is essential to extract the fault-related signal of interest. One solution may be to properly smooth and filter the raw signal. In this article, a wavelet filtering technique is applied. First, the wavelet filtering procedure is described. In the next step, the performance of a wavelet filter is investigated depending on its parameters. Then, the results of wavelet filtering are compared with such methods as low-pass filtering and smoothing using a moving average. Finally, the impact of wavelet filtering on the calculation of screen trajectories is investigated. Full article

Vibrating flip-flow screens (VFFS) are widely used to separate high-viscosity and fine materials. The most remarkable characteristic is that the vibration intensity of the screen frame is only 2–3 g (g represents the gravitational acceleration), while the vibration intensity of the screen surface can reach 30–50 g. This effectively solves the problem of the blocking screen aperture in the screening process of moist particles. In this paper, the approximate state of motion of the sieve mat is realized by setting the discrete rigid motion at multiple points on the elastic sieve mat of the VFFS. The effects of surface energy levels between particles separated via screening performance were compared and analyzed. The results show that the flow characteristics of particles have a great influence on the separation performance. For 8 mm particle screening, the particle’s velocity dominates its movement and screening behavior in the range of 0–8 J/m² surface energy. In the feeding end region (Sections 1 and 2), with the increase in the surface energy, the particle’s velocity decreases, and the contact time between the particles and the screen surface increases, and so the passage increases. When the surface energy level continues to increase, the particles agglomerate together due to the effect of the cohesive force, and the effect of the particle’s agglomeration is greater than the particle velocity. Due to the agglomeration of particles, the difficulty of particles passing through the screen increases, and the yields of various size fractions in the feeding end decrease to some extent. In the transporting process, the agglomerated particles need to travel a certain distance before depolymerization, and the stronger the adhesive force between particles, the larger the depolymerization distance. Therefore, for the case of higher surface energy, the screening percentage near the discharging end (Sections 3 and 4) is greater. The above research is helpful to better understand and optimize the screening process of VFFS. Full article

Diagnostics of industrial machinery is a topic related to the need for damage detection, but it also allows to understand the process itself. Proper knowledge about the operational process of the machine, as well as identification of the underlying components, is critical for its diagnostics. In this paper, we present a model of the signal, which describes vibrations of the sieving screen. This particular type is used in the mining industry for the classification of ore pieces in the material stream by size. The model describes the real vibration signal measured on the spring set being the suspension of this machine. This way, it is expected to help in better understanding how the overall motion of the machine can impact the efforts of diagnostics. The analysis of real vibration signals measured on the screen allowed to identify and parameterize the key signal components, which carry valuable information for the following stages of diagnostic process of that machine. In the proposed model we take into consideration deterministic components related to shaft rotation, stochastic Gaussian component related to external noise, stochastic $\alpha$-stable component as a model of excitations caused by falling rocks pieces, and identified machine response to unitary excitations. Full article

The low energy efficiency and excessive power of electric motors of large-scale vibrating machines for processing bulk materials motivated a new design of the inertial drive. This drive consists of one motor and two coaxial unbalanced masses, whose rotational frequencies are related in the ratio 2:1. This approach allows for a generation of the excitation force with variable amplitude and frequency, which changes depending on the inertial characteristics and shaft rotation frequency and does not relate to the phase difference of the unbalanced masses. Because of this, the symmetry axis of the resulting vector hodograph can be changed. The spectral composition of the exciting force up to 200 Hz contains higher harmonics, the energy share of which is 25.4% from the 2nd harmonic and 14.1% from the 3rd and higher harmonics that correspondingly improves bulk material treatment in comparison to single-frequency vibrators. The finite element model is used for checking the strength capacity of the most loaded units of a dual-frequency drive. Its use allows the realization of complex trajectories of motion that are more technologically efficient for variable parameters of the treated media and energy saving in sieving screens and other vibrating machines. Full article
