In the earthquakes that occurred in the Pazarcık (Mw = 7.7) and Elbistan (Mw = 7.6) districts of Kahramanmaraş Province on 6 February 2023, many buildings collapsed in the Hayrullah neighborhood of the Onikişubat district. In this study, we investigated whether there was a soil amplification effect on the damage occurring in the Hayrullah neighborhood of the Onikişubat district of Kahramanmaraş Province. Firstly, borehole, SPT, MASW (multi-channel surface wave analysis), microtremor, electrical resistivity tomography (ERT), and vertical electrical sounding (VES) tests were carried out in the field to determine the engineering properties and behavior of soil. Laboratory tests were also conducted using samples obtained from bore holes and field tests. Then, an idealized soil profile was created using the laboratory and field test results, and site dynamic soil behavior analyses were performed on the extracted profile. According to The Turkish Building Code (TBC 2018), the earthquake level DD-2 design spectra of the project site were determined and the average design spectrum was created. Considering the seismicity of the project site and TBC (2018) criteria (according to site-specific faulting, distance, and average shear wave velocity), 11 earthquake ground motion sets were selected and harmonized with DD-2 spectra in short, medium, and long periods. Using scaled motions, the soil profile was excited with 22 different earthquake scenarios and the results were obtained for the equivalent and non-linear models. The analysis showed that the soft soil conditions in the area amplified ground shaking by up to 2.8 times, especially for longer periods (1.0–2.5 s). This level of amplification was consistent with the damage observed in mid- to high-rise buildings, highlighting the important role of local site effects in the structural losses seen during the Kahramanmaraş earthquakes. Full article

After the 2011 earthquake, lake water depletion has become a widespread issue in Sikkim, especially in regions classified as high to very high seismic zones, where many lakes have turned into seasonal water bodies. This study investigates Chochen Lake in the Barapathing area of Sikkim’s Pakyong district, which is facing severe water seepage and instability. The problem, intensified by the 2011 seismic event and ongoing local construction, is examined through subsurface fracture mapping using Vertical Electrical Sounding (VES) and profiling techniques. A statistical factor method, applied to interpret VES data, helped identify fracture patterns beneath the lake. Results from two sites (VES-1 and VES-2) reveal significant variations in weathered and semi-weathered soil layers, indicating fractures at depths of 17–50 m (VES-1) and 20–55 m (VES-2). Higher fracture density near VES-1 suggests increased settlement risk and ground displacement compared to VES-2. Contrasting resistivity values emphasize the greater instability in this zone and the need for cautious construction practices. The findings highlight the role of seismic-induced fractures in ongoing water depletion and underscore the importance of continuous dewatering to stabilize the swampy terrain. Full article

The characterization of dimensional stone deposits is essential for quarry assessment and design. However, uncertainties in mapping and designing pose significant challenges. To address this issue, an innovative approach is initiated to develop a virtual reality model by integrating unmanned aerial vehicle (UAV) photogrammetry for surface modeling and Electric Resistivity Tomography (ERT) for subsurface deposit imaging. This strategy offers a cost-effective, time-efficient, and safer alternative to traditional surveying methods for challenging mountainous terrain. UAV methodology involved data collection using a DJI Mavic 2 Pro (20 MP camera) with 4 K resolution images captured at 221 m altitude and 80 min flight duration. Images were taken with 75% frontal and 70% side overlaps. The Structure from Motion (SfM) processing chain generated high-resolution outputs, including point clouds, Digital Elevation Models (DEMs), Digital Surface Models (DSMs), and orthophotos. To ensure accuracy, five ground control points (GCPs) were established by a Real-Time Kinematic Global Navigation Satellite System (RTK GNSS). An ERT method known as vertical electric sounding (VES) revealed subsurface anomalies like solid rock mass, fractured zones and areas of iron leaching within marble deposits. Three Schlumberger (VES-1, 2, 3) and two parallel Wenner (VES-4, 5) arrays to a depth of 60 m were employed. The resistivity signature acquired by PASI RM1 was analyzed using 1D inversion technique software (ZondP1D). The integrated outputs of photogrammetry and subsurface imaging were used to design an optimized quarry with bench heights of 30 feet and widths of 50 feet, utilizing open-source 3D software (Blender, BIM, and InfraWorks). This integrated approach provides a comprehensive understanding of deposit surface and subsurface characteristics, facilitating optimized and sustainable quarry design and extraction. This research demonstrates the value of an innovative approach in synergistic integration of UAV photogrammetry and ERT, which are often used separately, for enhanced characterization, decision-making and promoting sustainable practices in dimensional stone deposits. Full article

The epikarst (the subsurface cavernous part of karstic rock studied in the Bakony Regions, the Mecsek Mountains and the area of Pádis) was compared across several karst sample sites. Since the degree of cavity formation in the epikarst cannot be studied directly, statistical analysis of the measured resistivity values was used to determine and compare the characteristics of the epikarst at different sample sites and, thus, the associated karst areas. For this, the significance of bedrock resistivity values obtained by Vertical Electrical Sounding (VES) was determined by t-tests. The mean values and standard deviations along the profiles of the VES measurement sites were calculated and graphically represented. It was established that the epikarst of profiles with high resistivity mean values is thicker, and the epikarst is of heterogeneous cavity formation (cavity formation is of different degrees) at sites where the standard deviation of resistivity is high. The epikarst of some karst sample sites can be compared by their standard deviation fields since in areas with higher resistivity, a thicker epikarst results in more expanded cavities and a lower water table, while heterogeneous cavity formation causes different cavity sizes and different resistivities. At sites where the standard deviation fields overlap with each other, their epikarsts are similar, at those where they do not overlap, they are different, and at sites where the fields touch, their similarity is transitional. If the standard deviation fields overlap each other, those with higher mean values and higher standard deviation have more cavities and their cavity formation is more heterogeneous. The epikarst with these characteristic features is regarded as more mature because at a lower water table, a higher arithmetic mean of resistivity and a higher standard deviation can be established. The reliability of the comparisons is shown by the fact that those with a more mature epikarst are karstified to a greater degree. Full article

The effect of the epikarst on the development of drawdown dolines and subsidence dolines is described. For this, the resistivity values of the bedrock determined by Vertical Electrical Sounding (VES) measurements were used. The higher resistivities below drawdown dolines are explained by the deeper position of the piezometric surface, while the low resistivity values below subsidence dolines can be traced back to the more elevated position of the piezometric surface. Resistivities increasing towards the centre of drawdown dolines refer to cavity heterogeneity increasing towards the centre and increasing vertical percolation rate, while decreasing resistivity values indicate an increasing degree of cavity fill above the piezometric level. At their asymmetrical variety, the bedrock of their opposite slope is of asymmetric resistivity, which is explained by the different elevations of the piezometric surface and the latter by different infiltration that took place on slopes with different inclinations. The same resistivity values of the doline with a flat floor indicate the homogeneous cavity formation of the epikarst. This latter results in homogeneous vertical infiltration, which favours horizontal dissolution. The piezometric surface is not deflecting below the subsidence dolines because resistivity differences are small between the bedrock below the doline and the bedrock of its environment. Below subsidence doline, above the piezometric surface, cavities develop (the resistivity is higher relative to the resistivity of the environment), and then the cavities become filled by suffosion (therefore, the resistivity below the doline is lower relative to its environment). The passage below the doline develops into a shaft as a result of its concentrated water supply and the epikarst is separated into parts. Full article

This study aimed to investigate the shallow groundwater status around the Sheba Leather Tannery area, Wikro, North Ethiopia, through geophysical and hydrochemical methods. Seventeen Vertical Electrical Soundings (VESs) acquisitions, 4 upstream and 13 downstream, of the leather tannery area were conducted. Using the data, four geoelectric profiles were generated. The aquifers’ geoelectrical layers, depth, and lateral extent were delineated. The VES curves depicted three to four resistivity layers. These alternating layers of low, moderate, and high resistivity values, traced at different VES points, were attributed to the formations’ composition and the groundwater quality status. Besides the geophysical survey, 32 water samples were collected from the area. Parameters such as electrical conductivity (EC), total dissolved solids (TDSs), pH, major ions, and heavy metals were analyzed. Moreover, PHREEQC was used to determine the groundwater mineral saturation indices where most minerals, except halite, were found supersaturated. The quality status for drinking purposes was also evaluated using the water quality index (WQI), and the water was classified as good (56.3%), poor (37.5%), and very poor (6.2%). The sodium adsorption ratio (SAR) and the percentage of sodium (Na⁺%) were calculated, and the results indicated that the water is suitable for direct use in irrigation. Full article

The Mateur aquifer system in Northern Tunisia was examined using data from 19 water boreholes, 69 vertical electrical sounding (VES) stations, and a Sentinel-2 satellite image. Available boreholes and their corresponding logs were compared to define precisely the multi-layer aquifer system, including the Quaternary and Campanian aquifers of the Mateur plain. Quantitative interpretation and qualitative evaluation of VES data were conducted to define the geometry of these reservoirs. These interpretations were enhanced by remote sensing imagery processing, which enabled the identification of the Mateur plain’s superficial lineaments. Based on well log information, the lithological columns show that the Quaternary series in the Ras El Ain region contains a layer of clayey, pebbly, and gravelly limestone. Additionally, in the Oued El Tine area, a clayey lithological unit has been identified as a multi-layer aquifer. The study area, exhibiting apparent resistivity values ranging between 20 and 170 Ohm·m, appears to be rich in groundwater resources. The correlation between the lithological columns and the interpreted VES data, presented as geoelectrical cross-sections, revealed variations in depth (8–106 m), thickness (10 to 55 m), and resistivity (20–98 Ohm·m) of a coarse unit corresponding to the Mateur aquifer. Twenty-three superficial lineaments were extracted from the Sentinel-2 image. Their common superposition indicated that both of them are in a good coincidence; these could be the result of normal faults, creating an aquifer system divided into raised and sunken blocks. Full article

The application of hydrogeophysical techniques to delineating aquifers was conducted in De Aar, the eastern part of the Karoo region, Northern Cape, South Africa. Previously, recharge estimations in this region assumed a uniform aquifer type, overlooking the presence of diverse aquifer systems. This study identified both unconfined and confined aquifers to improve recharge potential assessments. Vertical electrical resistivity sounding (VES) and ground telluric methods were applied. Six VES stations and eleven profiles were measured using a 1D Wenner array configuration. The VES data, processed with IPI2win software, generated a 2D subsurface model. In contrast, the telluric data were analyzed using an automated algorithm to create a 2D profile. The electric potential difference curve was interpreted in comparison with lithological cross-sections. The VES results revealed three to four distinct layers of low-resistivity (0.9–8.1 Ωm), moderate-resistivity (22.4–125 Ωm), and high-resistivity (68–177 Ωm) values, indicating three lithological formations. The telluric data suggested that shallow groundwater boreholes were located in areas with groundwater levels above 50 m. These findings, which matched the lithological data, pointed to a double-layer aquifer system, suggesting that recharge estimates should be carried out to different aquifer layers. The study demonstrated how hydrogeophysical methods can effectively delineate aquifer systems and enhance the identification of recharge areas. Full article

Geothermal energy is a key part of sustainable and renewable energy strategies, especially for clean heating in northern regions. This study focuses on Qihe County in Shandong Province, applying a controlled source audio-frequency magnetotellurics (CSAMT) method to investigate deep karst geothermal reservoirs. This research addresses the complex geological conditions and electromagnetic interference in the region, aiming to improve sustainable geothermal resource development. The findings indicate that the geothermal reservoir in the study area primarily consists of Ordovician limestone, characterized by moderate burial depth, high water volume, and elevated water temperature. Integrating CSAMT with vertical electrical sounding (VES) and radiometric surveying has clearly defined the deep aquifer layers and major water-controlling fault structures. Drilling verification results demonstrate the significant effectiveness of the integrated geophysical methods employed, providing reliable technical support for deep geothermal exploration in similar regions. This study makes a significant contribution to the scientific and technical foundation necessary for the sustainable development and utilization of geothermal resources, supporting the broader goals of environmental sustainability and renewable energy. Full article

The integration of various geophysical methodologies is considered a fundamental tool for accurately reconstructing the extent and shape of a groundwater body and for estimating the physical parameters that characterize it. This is often essential for the management of water resources in areas affected by geological and environmental hazards. This work aims to reconstruct the pattern and extent of two groundwater bodies, located in the coastal sectors of the North-Eastern Sicily, through the integrated analysis and interpretation of several geoelectrical, seismic and geological data. These are the Sant’Agata-Capo D’Orlando (SCGWB) and the Barcelona-Milazzo (BMGWB) Groundwater Bodies, located at the two ends of the northern sector of the Peloritani geological complex. These two studied coastal plains represent densely populated and industrialized areas, in which the quantity and quality of the groundwater bodies are under constant threat. At first, the resistivity models of the two groundwater bodies were realized through the inversion of a dataset of Vertical Electrical Soundings (VES), constrained by stratigraphic well logs data and other geophysical data. The 3D resistivity models obtained by spatially interpolating 1D inverse VES models have allowed for an initial recognition of the distribution of groundwater, as well as a rough geological framework of the subsoil. Subsequently, these models were implemented by integrating results from active and passive seismic data to determine the seismic P and S wave velocities of the main lithotypes. Simultaneous acquisition and interpretation of seismic and electrical tomographies along identical profiles allowed to determine the specific values of seismic velocity, electrical resistivity and chargeability of the alluvial sediments, and to use these values to constrain the HVSR inversion. All this allowed us to recognize the areal extension and thickness of the various lithotypes in the two investigated areas and, finally, to define the depth and the morphology of the base of the groundwater bodies and the thickness of the filling deposits. Full article

In this research, a hydraulic characterization of a 14 km segment of the San Pedro River, flowing through the center of the Aguascalientes Valley, was conducted. More than 50 years of flow measurement records were processed to obtain daily flows during dry and rainy seasons. Through geospatial analysis, areas with hydraulic retention, influenced by the region’s topography and sediment accumulation during the flood season, were identified. Similarly, the digital map of geological surface features revealed that some of these structures spatially coincide with these retention areas. Later, potential hydraulic connectivity between the surface and the aquifer were evaluated in the identified hydraulic stagnation areas (HSAs) using vertical electrical soundings (VESs). Finally, through an experimental process in which water collected from the San Pedro River flowed through a device filled with surface soil taken from the retention areas, the potential retention of pollutants by the local soil was evaluated based on toxicity tests using the monogonont rotifer Lecane papuana. The findings suggest the presence of three hydraulic stagnation areas (HSAs) in the examined section of the river, with one of them intersected by a surface discontinuity. According to the results of the VES, the water table beneath the HSA varies between 70 and 90 m in depth. Further analysis of the vertical electrical sounding (VES) results suggests the presence of vertical hydraulic connectivity between the San Pedro River and the local aquifer in the hydraulic stagnation areas (HSA). This is indicated by the identification of low-resistivity strata associated with highly saturated soil above the water table, as measured in the adjacent pumping wells. Additionally, the experiments involving the device filled with soil showed a reduction in water toxicity (ranging from 12 to 40%) as the San Pedro River water flowed through a 1 m column of local near-surface soil. The results of this experimental work suggest that the soil acts as a natural filter for contaminant transport under conditions in time and space similar to those of the experiment. However, there is still a significant research niche in conducting an experimental campaign in terms of hydrogeochemistry to obtain more specific results. Full article

In recent decades, the fortunes of energy economies have been closely linked in Pakistan. A major energy inefficiency issue was found in Pakistan due to the mismatch between horsepower (HP) requirements and bore depth. Keeping this in view, a total of 194 tubewells were chosen for an energy audit in the Multan region, Pakistan. The Terrameter SAS 4000 was used to measure the accurate demand of the head during the resistivity surveys at all of the selected locations. The results showed that the tubewell sets were installed arbitrarily at high power, irrespective of the provided flow and head, and these pumps used more energy for their flow. The results revealed that the efficiency of the tubewell sets increased from 35 to 54%, from 55 to 80%, from 49 to 80%, and from 48 to 75% for centrifugal pumps with electric motors and diesel engines and for turbines with electric motors and diesel engines, respectively. A weighted overlay analysis indicated that the efficiency of tubewells covering 838.12, 1131.8, and 2077.1 km² for centrifugal pumps with electric motors, diesel engines, and turbines, respectively, was enhanced for the study area. Similarly, the energy saved for the study area covered 1423.8, 1161.1, and 1131.1 km², as shown by the overlay analysis. The results revealed that the annual energy saving was found of 3486 kw for 194 tubewells, resulted in the saving of USD 0.204 million in operational costs over one year. The overall results indicate the strong need to adopt proper investigations of the head and power requirements before installing a system in the study area. Full article

This study aimed to investigate the potential reserves of potable water in Islamabad, Pakistan, considering the alarming depletion of water resources. A detailed vertical electrical sounding (VES) survey was conducted in two main localities: Bara Kahu (Area 1) and Aabpara to G-13 (Area 2), based on accessibility, time, and budget constraints. A total of 23 VES measurements were performed, with 13 in Area 1 and 10 in Area 2, reaching a maximum depth of 500 m. Geologs and pseudosections were generated to assess lithological variations, aquifer conditions, and resistivity trends with depth. Statistical distribution of resistivity (SDR), hydraulic parameters, true resistivity, macroanisotropy, aquifer depth and thickness, and linear regression (R²) curves were calculated for both areas, providing insights into the aquifer conditions. The results revealed that the study areas predominantly consisted of sandy lithology as the aquifer horizon, encompassing sandstone, sandy clay, and clayey sand formations. Area 2 exhibited a higher presence of clayey horizons, and aquifers were generally deeper compared to Area 1. The aquifer thickness ranged from 10 m to 200 m, with shallow depths ranging from 10 m to 60 m and deeper aquifers exceeding 200 m. Aquifers in Area 1 were mostly semi-confined, while those in Area 2 were predominantly unconfined and susceptible to recharge and potential contamination. The northwest–southeast side of Area 1 exhibited the highest probability for ground resource estimation, while in Area 2, the northeast–southwest side displayed a dominant probability. The study identified a probable shear zone in Area 2, indicating lithological differences between the northeast and southwest sides with a reverse sequence. Based on the findings, it is recommended that the shallow aquifers in Area 1 be considered the best potential reservoir for water supply. In contrast, deeper drilling is advised in Area 2 to ensure a long-lasting, high-quality water supply. These results provide valuable information for water resource management and facilitate sustainable water supply planning and decision making in Islamabad, Pakistan. Full article

Some vertical electrical sounding (VES) data from tectono-thermal environments usually plot anomalously on a VES curve, thereby distorting the curve trend at the points of their occurrence. These datasets usually plot noisily in the form of a sudden rise and drop in electrical resistivity values. They constitute abnormal datasets that are usually deleted to recover trends and consequently develop confidence in both the datasets and the modelling and interpretational processes. This study was conducted to assess their origin and consequently gain an understanding of their contributions to groundwater accumulation and transmission in saprock aquifers. The results, supported by co-located drilling and pumping test data, show that these datasets are indicators of subsurface conditions where high-resistivity unconformal structures directly overlie saturated (low-resistivity) porous media, provided that the resistivity of the first breakout point is less than those from subsequent points. Remote sensing data reveal that these types of curves are common in hard rock and metasedimentary environments. Borehole groundwater yields can also be assessed qualitatively from the number and trend of breakoff points. The integrity of the breakoff points must be affirmed by using more sensitive equipment for data acquisition and repeating the measuring process using different potential electrode separations and—where possible—VES profile orientation. Full article

Geoelectrical resistivity measurements were conducted in five locations within the eastern portion of the Dahomey basin for the purpose of subsurface evaluation and detecting saturated zones. The locations are Covenant University (L1), Bells University (L2), Oju-Ore-Ilogbo Road (L3), Obasanjo-Ijagba Road (L4), and Iyana Iyesi (L5). The study was carried out to avert the common challenges of drilling low-yield groundwater boreholes in the area. A total of 30 Vertical Electrical Soundings (VES) and five two-dimensional Electrical Resistivity Tomography (ERT) data sets have been acquired along the study areas. The geoelectrical resistivity results were integrated with the borehole logs to generate the spatial distribution of the subsurface lithologies in the area. The delineated subsurface lithologies include the topsoil (lateritic clay), clayey sand, sandy clay, fine silty sand, coarse sand, and shale/clay units. The fine silty sand and coarse sand units were identified as the two main aquifer units within the area. The depths to the upper aquifer unit in the area include 31.7–96.7 m, 38.5–94.0 m, 30.7–57.5 m, 39.1–63.4 m, and 46.9–57.5 m for locations L1, L2, L3, L4, and L5, respectively. At the same time, the depths to the lower aquifer unit in the area include 43.4–112.7 m, 52.2–108.0 m, 44.2–72.5 m, 53.7–78.5 m, and 63.5–72.9 m for locations L1, L2, L3, L4, and L5, respectively. The estimated hydraulic parameters for both aquifers show they are highly productive with mean porosity, mean hydraulic conductivity, and mean transmissivity of 20–22%, 12.4–17.0 × 10⁻² m/s, 1.56–2.18 m²/s for the upper aquifer, and 48–50%, 371–478 × 10⁻² m/s, 50.00–62.14 m²/s for the lower aquifer. By focusing on these aquifer systems during exploration, sustainable groundwater resources can be secured, providing relief to homeowners within the study area who might otherwise face the frustration of drilling unproductive and low-yield boreholes. However, it is crucial to consider the presence of sub-vertical faults in the study area, as these faults can significantly impact groundwater development and management. These sub-vertical structural faults may lead to changes in the permeability, hydraulic conductivity, and transmissivity of the delineated aquifers, affecting their productivity across the divide and ultimately influencing the overall water availability in the area. Careful consideration of these geological factors is essential for effective aquifer management and sustainable groundwater utilisation. Full article
