A review of morphing actuation systems in relation to rotary-wing aerial platforms is presented. The research highlights an inadequate maturation of rotary actuation systems, characterised by a scarcity of (1) comprehensive full-scale experimental research relative to non-rotary (fixed-wing) systems, (2) techniques used for rotary actuation systems and (3) implementation of full-chord morphing systems, with existing research only utilising partial-chord actuation techniques. Additionally, another notable shortcoming is presented to be the lack of comprehensive proportional investigation in the proposed five-step development process for rotary actuation designs. A comprehensive critical review is offered, covering the following challenges of progressing through this development process for rotary actuation systems from conceptual design to production: (1) numerical and computational studies, (2) small-scale wind-tunnel testing, (3) full-scale wind-tunnel testing, (4) demonstrator, and ultimately (5) fabrication for industrial implementation. The review examines several existing rotary actuation systems, including (but not limited to) leading-edge, trailing-edge and Gurney flaps; active twist; chord extension; variable span and camber systems. Comparisons are made between rotary morphing actuation systems and their non-morphing counterparts, highlighting the distinct difficulties encountered by rotary-wing systems due to the more complex and challenging operational conditions found in rotorcraft. The review reveals that a significant portion of existing research on rotary-wing systems has focused only on early-stage development, including computational modelling and sub-scale wind-tunnel experiments, underscoring the necessity for more comprehensive full-scale testing and prototype evaluation given that only a small number of studies have progressed to full-scale wind-tunnel testing or actual prototype evaluation, with only one example identified as having been tested on a production helicopter. In addition, a comparative Technology Readiness Level (TRL) assessment is presented for both rotary-wing and fixed-wing morphing actuation systems, enabling a structured evaluation of relative technology maturity, experimental validation depth, and proximity to operational implementation. Building upon this assessment, a morphing Actuation Concept-Transfer Feasibility (ACTF) study is also provided, examining the potential for adapting mature fixed-wing morphing actuation technologies for application in rotary-wing environments, while identifying the key structural, aerodynamic, and operational constraints that currently limit direct technology transfer. This study addresses and proposes opportunities for a novel rotary actuation system design and concludes by suggesting the potential for future research on more effectual systems to include full-chord configuration over larger spanwise blade footprints with innovative actuation mechanisms that could be utilised and progressed through all development stages from numerical studies to full-scale fabrication. Full article

Morphing aircraft can actively or passively change their shape in different flight environments and missions to ensure optimal flight performance at all flight stages, thereby enhancing environmental adaptability and meeting extensive multi-mission requirements. This paper proposes a stable flight control strategy for a variable-span aircraft based on Model Predictive Control (MPC). The Linear Parameter Varying (LPV) modeling approach is adopted to establish a longitudinal dynamic model that varies with the wingspan deformation rate. Without considering disturbances, a model predictive control strategy is designed to achieve dynamic stability control during flight. Considering the existence of composite disturbances during the morphing process, a robust model predictive control (RMPC) strategy is proposed, using set containment as the performance index. To verify the robustness of the control strategy, numerical tests are conducted under different wingspan deformation rates and disturbance intensities. The test results demonstrate that the RMPC strategy can effectively suppress external disturbances under various deformation rates, maintain stable flight speed and altitude, and ensure smooth transitions of critical flight state parameters such as angle of attack and pitch angle. These results validate the effectiveness of the proposed method. Full article

This work uses state-of-the-art climate model data at 30 European airport locations to examine how climate change may affect summer take-off distance required—TODR—and maximum take-off mass—MTOM—for a 30-year period centred on 2050 compared to a historical baseline (1985–2014). The data presented here are for the Airbus A320; however, the methodology is generic and few changes are required in order to apply this methodology to a wide range of different fixed-wing aircraft. The climate models used are taken from the 6th Coupled Model Intercomparison Project (CMIP6) and span a range of climate sensitivity values; that is, the amount of warming they exhibit for a given increase in atmospheric greenhouse gas concentrations. Using a Newtonian force-balance model, we show that 30-year average values of TODR may increase by around 50–100 m, albeit with significant day-to-day variability. The changing probability distributions are quantified using kernel density estimation and an illustration is provided showing how changes to future daily maximum temperature extremes may affect the distributions of TODR going forward. Furthermore, it is projected that the 99th percentile of the historical distributions of TODR may by exceeded up to half the time in the summer months for some airports. Some of the sites studied have runways that are shorter than the distance required for a fully laden take-off, which means they must reduce their payloads as temperatures and air pressures change. We find that, relative to historical mean values, take-off payloads may need to be reduced by the equivalent of approximately 10 passengers per flight, as these significant increases (as high as approximately 60%) show a probability of exceeding historical extreme values. Full article

This paper proposes a fixed-time backstepping control method based on a disturbance observer for a hypersonic morphing waverider (HMW). Firstly, considering the disturbance of attitude channels, a dynamic model of a variable-span-wing HMW considering additional forces and moments is established, and an aerodynamic model of the aircraft is constructed using the polynomial fitting method. Secondly, the fixed-time stability theory and backstepping control method are combined to design an HMW fixed-time attitude controller. Based on the fixed-time convergence theory, a fixed-time disturbance observer is designed to achieve an accurate online estimation of disturbance and to compensate for the control law. In order to solve the problem of the “explosion of terms”, a nonlinear first-order filter is used instead of a traditional linear first-order filter to obtain the differential signal, ensuring the overall fixed-time stability of the system. The fixed-time stability of the closed-loop system is strictly proven via Lyapunov analysis. The simulation results show that the proposed method has good adaptability under different initial conditions, morphing speeds, and asymmetric morphing rates of the HMW. Full article

Variable camber wing technology stands out as the most promising morphing technology currently available in green aviation. Despite the ongoing advancements in smart materials and compliant structures, they still fall short in terms of driving force, power, and speed, rendering mechanical structures based on kinematics the preferred choice for large long-range civilian aircraft. In line with this principle, this paper introduces a linkage-based variable camber trailing edge design approach. Covering coordinated design, internal skeleton design, flexible skin design, and drive structure design, the method leverages a two-dimensional supercritical airfoil to craft a seamless, continuous two-dimensional wing full-size variable camber trailing edge structure, boasting a 2.7 m span and 4.3 m chord. Given the significant changes in aerodynamic load direction, ground tests under cruise load utilize a tracking-loading system based on tape and lever. Results indicate that the designed single-degree-of-freedom Watt I mechanism and Stephenson III drive mechanism adeptly accommodate the slender trailing edge of the supercritical airfoil. Under a maximum cruise vertical aerodynamic load of 17,072 N, the structure meets strength requirements when deflected to 5°. The research in this paper can provide some insights into the engineering design of variable camber wings. Full article

A multi-dimensional morphing wing skeleton mechanism is proposed with double-sided triangular pyramid units, which can realize continuous variable span-wise bend, span-wise twist, and sweep. A lockable morphing unit is designed, and its mechanism/structure characteristics, degree of freedom, and the deformable function of its deformable wing skeleton mechanism are analyzed. One kind of flexible skin is proposed to meet the performance requirements, consisting of an internal metastructure and a flexible surface bonded on both sides. The morphing wing skeleton mechanism and the equivalent treated metastructure flexible skin are then combined. Subsequently, a two-way fluid–structure interaction analysis is conducted to investigate the influence of aerodynamic loads on the flexible skin and skeleton mechanism in different deformation states, including the influence of structural passive deformation on the aerodynamic characteristics of the morphing wing. The computational fluid dynamics method is employed to analyze the aerodynamic characteristics of the morphing wing in its initial state, as well as in three deformation states, and to study its aerodynamic performance in different flight environments. Full article

In this study, a novel framework for the flight control of a morphing unmanned aerial vehicle (UAV) based on linear parameter-varying (LPV) methods is proposed. A high-fidelity nonlinear model and LPV model of an asymmetric variable-span morphing UAV were obtained using the NASA generic transport model. The left and right wing span variation ratios were decomposed into symmetric and asymmetric morphing parameters, which were then used as the scheduling parameter and the control input, respectively. LPV-based control augmentation systems were designed to track the normal acceleration, angle of sideslip, and roll rate commands. The span morphing strategy was investigated considering the effects of morphing on various factors to aid the intended maneuver. Autopilots were designed using LPV methods to track commands for airspeed, altitude, angle of sideslip, and roll angle. A nonlinear guidance law was coupled with the autopilots for three-dimensional trajectory tracking. A numerical simulation was performed to demonstrate the effectiveness of the proposed scheme. Full article

This paper studies the effect of morphing rate on the aeroelasticity of a polymorphing wing capable of active span extension and passive twist/pitch. A variable domain size finite element model is developed to capture the dynamic effects due to the presence of a variable span in the Euler–Bernoulli beam model, which introduces a structural damping term in the equations of motion. The effect of various morphing rates on the aeroelastic boundaries of the system, namely, flutter velocity and flutter frequency, is examined for a beam undergoing span extension and retraction, from baseline span to 25% span extension and vice versa, respectively. Three points of interest are analyzed: at the start of the span morphing, at the mid-point of morphing, and just before the morphing process ends. The parametric analysis is carried out to determine the effect of varying critical parameters, such as the elastic axis location of the outboard wing section and adjoining spring torsional rigidity on the aeroelastic boundaries of the polymorphing wing. Full article

The distributed electric propulsion (DEP) eVTOL aircraft has gained rising interest for its promising potential in high-speed cruise compared with conventional tilt-rotor configuration. The aerodynamic interference of the DEP units and wing could become more complicated with a variable thrust in multiple flight conditions. Thus, it requires considerable effort to trade off in the whole design process. Aimed at improving the design efficiency in iteration cycling of a ducted-fan DEP eVTOL aircraft, a conceptual design and optimization approach is proposed in this paper regarding the single-ducted fan and its surrounding wing section as the basic unit. The optimization of the ducted-fan wing (DFW) unit is targeted at improving both hover and cruise efficiencies. After the verification of the span independence of the lift-and-drag coefficients of the DFW unit, a novel DEP eVTOL aircraft conceptual design approach is established based on the vertical meridional plane DFW unit performance analysis. In the following case study, the optimized DFW unit and the conceptual method are applied on a canard configuration, achieving 720 km/h maximum speed, a hovering efficiency of 76.3%, and a 10.7 cruise lift-to-drag ratio. The remarkable performance and concise workflow in the case study both demonstrated the applicability and effectiveness of the proposed design schemes for DEP eVTOL aircraft. Full article

In this work, we use a three-dimensional computational fluid dynamics (CFD) simulation to comprehend how the two wing arrangement variables, i.e., inner/outer wing proportion and mid-stroke dihedral, affect the lift characteristic of a bat-inspired span foldable flapping wing. The employed flapping mechanism is based on previous work. In this study, the structure parameters of the flapping mechanism remain unchanged across all simulations. Based on the CFD results, the tendency and work point regarding maximum lift generation can be found by changing both of the variables. As a result, when modifying the inner/outer wing proportion without changing the total wing shape and area, the maximum time-averaged lift appears in the case of the inner wing occupying half of the semi-span. In addition, when changing the dihedral, the maximum time-averaged lift was obtained when the inner wing dihedral was equal to zero. To discuss the lift variation of the foldable flapping wing, pressure distribution and vorticity of the flow field at certain time points were provided corresponding to the instantaneous lift curves. The conclusions of this research are able to help understand the wing arrangement of birds and bats issued from natural selection, and also support the future design of flapping wing micro-aerial-vehicles. Full article

This paper is a follow-up to earlier work on applying multidisciplinary numerical optimization to develop a morphing variable span of a tapered wing (MVSTW) to reduce its weight by using composite materials. This study creates a numerical environment of multidisciplinary optimization by integrating material selection, structural sizing, and topological optimization following aerodynamic optimization results with the aim to assess whether morphing wing optimization is feasible. This sophisticated technology is suggested for developing MVSTWs. As a first step, a problem-specific optimization approach is described for specifying the weight-saving structure of wing components using composite materials. The optimization was performed using several approaches; for example, aerodynamic optimization was performed with CFD and XFLR5 codes, the material selection was conducted using MATLAB code, and sizing and topology optimization was carried out using Altair’s OptiStruct and SolidThinking Inspire solvers. The goal of this research is to achieve the MVSTW’s structural rigidity standards by minimizing wing components’ weight while maximizing stiffness. According to the results of this optimization, the weight of the MVSTW was reduced significantly to 5.5 kg in comparison to the original UAS-S4 wing weight of 6.5kg. The optimization and Finite Element Method results also indicate that the developedmorphing variable span of a tapered wing can complete specified flight missions perfectly and without any mechanical breakdown. Full article

This paper presents the development of a novel polymorphing wing capable of Active Span morphing And Passive Pitching (ASAPP) for small UAVs. The span of an ASAPP wing can be actively extended by up to 25% to enhance aerodynamic efficiency, whilst its pitch near the wingtip can be passively adjusted to alleviate gust loads. To integrate these two morphing mechanisms into one single wing design, each side of the wing is split into two segments (e.g., inboard and outboard segments). The inboard segment is used for span extension whilst the outboard segment is used for passive pitch. The inboard segment consists of a main spar that can translate in the spanwise direction. Flexible skin is used to cover the inboard segment and maintain its aerodynamic shape. The skin transfers the aerodynamic loads to the main spar through a number of ribs that can slide on the main spar through linear plain bearings. A linear actuator located within the fuselage is used for span morphing. The inboard and outboard segments are connected by an overlapping spar surrounded by a torsional spring. The overlapping spar is located ahead of the aerodynamic center of the outboard segment to facilitate passive pitch. The aero-structural design, analysis, and sizing of the ASAPP wing are detailed here. The study shows that the ASAPP wing can be superior to the baseline wing (without morphing) in terms of aerodynamic efficiency, especially when the deformation of the flexible skin is minimal. Moreover, the passive pitching near the wingtip can reduce the root loads significantly, minimizing the weight penalty usually associated with morphing. Full article

Satellite laser ranging (SLR) observations provide an independent validation of the global navigation satellite system (GNSS) orbits derived using microwave measurements. SLR residuals have also proven to be an important indicator of orbit radial accuracy. In this study, SLR validation is conducted for the precise orbits of eight Galileo satellites covering four to eight years (the current longest span), provided by multiple analysis centers (ACs) participating in the multi-GNSS experiment (MGEX). The purpose of this long-term analysis (the longest such study to date), is to provide a comprehensive evaluation of orbit product quality, its influencing factors, and the effect of perturbation model updates on precise orbit determination (POD) processing. A conventional ECOM solar radiation pressure (SRP) model was used for POD. The results showed distinct periodic variations with angular arguments in the SRP model, implying certain defects in the ECOM system. Updated SRP descriptions, such as ECOM2 or the Box-Wing model, led to significant improvements in SLR residuals for orbital products from multiple ACs. The standard deviation of these residuals decreased from 8–10 cm, before the SRP update, to about 3 cm afterward. The systematic bias of the residuals was also reduced by 2–4 cm and the apparent variability decreased significantly. In addition, the effects of gradual SRP model updates in the POD were evident in orbit comparisons. Orbital differences between ACs in the radial direction were reduced from the initial 10 cm to better than 3 cm, which is consistent with the results of SLR residual analysis. These results suggest SLR validation to be a powerful technique for evaluating the quality of POD strategies in GNSS orbits. Furthermore, this study has demonstrated that perturbation models, such as SRP, provide a better orbit modeling for the Galileo satellites. Full article

This article proposes the integration of structural sizing, topology, and aerodynamic optimization for a morphing variable span of tapered wing (MVSTW) with the aim to minimize its weight. In order to evaluate the feasibility of the morphing wing optimization, this work creates a numerical environment by incorporating simultaneous structural sizing and topology optimization based on its aerodynamic analysis. This novel approach is proposed for an MVSTW. A problem-specific optimization approach to determine the minimum weight structure of the wing components for its fixed and moving segments is firstly presented. The optimization was performed using the OptiStruct solver inside HyperMesh. This investigation seeks to minimize total structure compliance while maximizing stiffness in order to satisfy the structural integrity requirements of the MVSTW. The aerodynamic load distribution along the wingspan at full wingspan extension and maximum speed were considered in the optimization processes. The wing components were optimized for size and topology, and all of them were built from aluminum alloy 2024-T3. The optimization results show that weight savings of up to 51.2% and 55.7% were obtained for fixed and moving wing segments, respectively. Based on these results, the optimized variable-span morphing wing can perform certain flight missions perfectly without experiencing any mechanical failures. Full article

The flight performance and maneuverability of Odonata depends on wing shape and aero-structural characteristics, including airfoil shape, wingspan, and chord. Despite the superficial similarity between Odonata planforms, the frequency with which they are portrayed artistically, and the research interest in their aerodynamics, those features that are stable and those that are labile between species have not been identified. Studies have been done on 2D aerodynamics over corrugated wings; however, there is limited comparative quantified data on the planforms of Odonata wings. This study was undertaken to explore the scale relationships between the geometrical parameters of photogrammetrically reconstructed wings of 75 Odonata species, 66 from Epiprocta, and 9 from Zygoptera. The wing semi-spans captured in the database range from 24 to 85 mm. By carrying out an extensive statistical analysis of data, we show that the geometrical parameters for the suborder Epiprocta (dragonflies) can be classified into scale-dependent and independent parameters using regression analysis. A number of close correlations were found between the wingspan and the size of other structures. We found that amongst the variables considered, the largest independent variations against the forewing span were found in the chord of the hindwing, and that hindwing properties were not reliably predicted by the Odonata family. We suggest that this indicates continuous evolutionary pressure on this structure. Full article
