Combustion processes in compression ignition engines lead to the inevitable generation of nitrogen oxides, which cannot be limited to the currently desired levels just by optimising the in-cylinder processes. Therefore, simulation-based engine development needs to include all engine-related aspects which contribute to tailpipe emissions. Among them, the SCR (selective catalytic reduction) aftertreatment-related processes, such as urea–water solution injection, urea decomposition, mixing, NOx catalytic reduction, and deposits’ formation, are the most challenging, and require as much attention as the processes taking place inside the cylinder. Over the last decade, the urea-SCR aftertreatment systems have evolved from underfloor designs to close-coupled (to the engine) architecture, characterised by the short mixing length. Therefore, they need to be tailor-made for each application. This study presents the CFD-based development of a multi-platform SCR system with a short mixing length for mobile non-road applications, compliant with Stage V NRE-v/c-5 emission standard. It combines multiphase dispersed flow, including wall wetting and urea decomposition kinetic reaction modelling to account for the critical aspects of the SCR system operation. The baseline system’s design was characterised by the severe deposit formation near the mixer’s outlet, which was attributed to the intensive cooling in the mounting area. Moreover, as the simulations suggested, the spray was not appropriately mixed with the surrounding gas in its primary zone. The proposed measures to reduce the wall film formation needed to account for the multi-platform application (ranging from 56 to 130 kW) and large-scale production capability. The performed simulations led to the system design, providing excellent UWS–exhaust gas mixing without a solid deposit formation. The developed system was designed to be manufactured and implemented in large-scale series production. Full article

Aging diesel engines on the road require the development of an after-treatment system to meet current emission regulations, and a reduction in NOx (Nitrogen Oxide) is significant. The SCR (Selective Catalytic Reduction) system is the after-treatment system for removing NOx from exhaust gas in diesel engines using NH₃ (Ammonia) gas. However, the mixing and conversion process between NH₃ and NOx in SCR has not been entirely clarified. That process produces NH₃ slip in the catalyst surface; the NH₃ slip will make the after-treatment performance worse. This study informs how the UWS (Urea Water Solution) injection controlling method can minimize the NH₃ slip in the after-treatment system. For this, the NH₃ adsorption and desorption rates are important factors for determining the quantity of UWS injection in the system. The NH₃ adsorption rate and desorption rate in the SCR are not significantly affected by engine speed, i.e., the exhaust gas flow rate. However, as the exhaust gas temperature increased, the adsorption rate and desorption rate of NH₃ in the SCR increased. Through this, the exhaust gas temperature dramatically affects the NH₃ adsorption rate and desorption rate in the SCR. Therefore, if the urea water is injected based on this knowledge that the NH₃ adsorption amount in the SCR decreases as the exhaust gas flow rate increases, NH₃ slip can be suppressed and a high NOx reduction rate can be achieved. Therefore, if the SCR adsorption and desorption mechanisms are analyzed according to the exhaust temperature and the exhaust flow rate in this paper, it can be used as a reference for selecting an appropriate SCR when retrofitting an old diesel engine car. Full article

Computational fluid dynamics (CFD) are an essential tool for the development of diesel engine aftertreatment systems using selective catalytic reduction (SCR) to reduce nitrous oxides (${\mathrm{NO}}_{\mathrm{x}}$). In urea-based SCR, liquid urea–water solution (UWS) is injected into the hot exhaust gas, where it transforms into gaseous ammonia. This ammonia serves as a reducing agent for ${\mathrm{NO}}_{\mathrm{x}}$. CFD simulations are used to predict the ammonia distribution in the exhaust gas at the catalyst inlet. The goal is to achieve the highest possible uniformity to realize homogeneous ${\mathrm{NO}}_{\mathrm{x}}$ reduction across the catalyst cross section. The current work focuses on the interaction of UWS droplets with the hot walls of the exhaust system. This is a crucial part of the preparation of gaseous ammonia from the injected liquid UWS. Following experimental investigations, a new impingement model is described based on the superposition of four basic impingement behaviors, each featuring individual secondary droplet characteristics. The droplet–wall heat transfer, depending on surface temperature and impingement behavior, is also calculated using a newly parameterized model. Applying the presented approach, the cooling of a steel plate from intermittent spray impingement is simulated and compared to measurements. The second validation case is the distribution of ammonia at the catalyst inlet of an automotive SCR system. Both applications show good agreement and demonstrate the quality of the new model. Full article

In this study, an exhaust system compliant with future regulations was developed for a non-road 110PS engine with a Tier-4f aftertreatment system, and the emission characteristics of the engine were investigated in the non-road transient mode (NRTC). For the system to comply with future exhaust regulations, a DPF was installed, and an electrical heated catalyst (EHC) device was installed to manage exhaust gas temperature. The emission characteristics of exhaust gas were examined according to the power and applied duration of EHC, and the effects of catalyst coating and the urea water solution (UWS) injection map on NOx reduction, NH₃ slip, and N₂O emissions in NRTC mode were investigated. The application of a 4 kW class EHC system enables the lowering of the injection starting temperature of the UWS, as reliable gas heating (heating duration control) is guaranteed. When the injection starting temperature (based on the SCR inlet temperature) was set to 150 °C, NSR map, (III) in conjunction with the operation of the EHC, effectively achieved significant NOx reduction in NRTC mode without deposit and wetting occurring in the mixer and exhaust pipe. Regarding changes in EHC power from 3 kW to 4 kW, it was observed that a NOx reduction of 0.05 g/kWh occurs in the cold NRTC mode, but in the hot NRTC mode, it was found that the relative decrease in the UWS is due to the increased NO₂ conversion efficiency as a result of the oxidation catalyst, making 3 kW more advantageous. Furthermore, due to the increase in NO₂ concentration caused by the oxidation catalyst and the increase in the low-temperature injected UWS, NH₄NO₃ was formed, which resulted in an increase in PM emissions and a significant increase in N₂O emissions around an exhaust temperature of 250 °C. When the EHC power was set to 3 kW and the volume of oxidation catalyst and the amount of UWS injection were adjusted, applying EHC in the NRTC mode resulted in an additional NOx reduction of 58.6% and 88.4% in cold and hot modes, respectively, compared with not using EHC, with a fuel penalty of approximately 1.67%, while limiting the peak concentrations of N₂O and NH₃. Full article

The diesel engine is utilized in most commercial vehicles to carry items from various firms; nevertheless, diesel engines emit massive amounts of nitrogen oxides (NOx) which are harmful to human health. A typical approach for reducing NOx emissions from diesel engines is the selective catalytic reduction (SCR) system; however, several reasons make reducing NOx emissions a challenge: urea particles frequently become solid in the injector and difficult to disseminate across the system; the injector frequently struggles to spray the smaller particles of urea; the larger urea particles from the injector readily cling to the system; it is also difficult to evaporate urea droplets because of the exhaust and wall temperatures (Tw), resulting in an increase in solid deposits in the system, uncontrolled ammonia water solution injection, and NOx emissions problems. The light-duty diesel engine (LDD), medium-duty diesel engine (MDD), heavy-duty diesel engine (HDD), and marine diesel engine use different treatments to optimize NOx conversion efficiency in the SCR system. This review analyzes several studies in the literature which aim to increase NOx conversion in different diesel engine types. The approach and methods demonstrated in this study provide a suitable starting point for future research into reducing NOx emissions from diesel engines, particularly for engines with comparable specifications. Full article

Selective catalytic reduction (SCR) is currently one of the most efficient denitration technologies to reduce nitrogen oxide (NO_x) emissions of diesel engines. AdBlue (urea water solution, UWS) is the carrier of the reducing agent of SCR, and the spray process of UWS is one of the critical factors affecting denitration efficiency. In this paper, a non-air-assisted pressure-driven full process spray (NPFPS) model is proposed to illustrate the breakup mechanism and the spray distribution properties of UWS through computational fluid dynamics (CFD). In the NPFPS model, the mechanism of the primary breakup is described by the volume of fluid (VOF) approach, which realizes the quantitative study of the critical parameters determining spray characteristics such as the breakup length, inclination angle, droplet size of the primary breakup, and primary velocity. The distribution of the spray after the primary breakup is depicted by the discrete phase model (DPM) coupled with the Taylor analogy breakup (TAB) model, through which the degree of secondary breakup can be obtained including quantitative studies of the droplet size distribution and velocity distribution in the different cross-sections. To verify the accuracy and feasibility of the NPFPS model, the experimental data are employed to compare with the simulation data. The results are in good agreement, which indicate the practical value of the model. Full article

Exhaust is generated by engine flows through a turbocharger, front exhaust pipe, and selective catalytic reduction (SCR) post-treatment device. The structure of the front exhaust pipe affects the temperature, velocity, and turbulent kinetic energy of exhaust and the Sauter Mean Diameter (SMD) of urea water solution (UWS). A high temperature and turbulent kinetic energy in the exhaust will promote the decomposition of UWS, and further accelerate the evaporation and atomization effect of the UWS droplets. Therefore, in order for the exhaust to reach a high temperature and turbulent kinetic energy, a double-layered pipe structure with air insulation was designed. The flow field and the atomization of UWS in the double-layered pipe based on hydroforming processing was investigated through numerical simulation. The thermal insulation simulation was verified by the temperature measurement system and the temperature drops between the double-layered pipe and the volcanic rock-wrapped pipe were also compared. The results indicate that the temperature at the outlet of the designed double-layered pipe was 3.5% higher than that of a single-layered pipe with the same structure, and the velocity at the outlet of the exhaust of the double-layered pipe was 16.1% higher than that of a single-layered pipe. The maximum turbulent kinetic energy in the double-layered pipe was 71 times that of the single-layered pipe. The design is not only conducive to the mixing of UWS and exhaust, but can also improve the atomization performance of UWS. Full article

The urea-selective catalytic reduction (SCR) system, a nitrogen oxide reduction device for diesel vehicles, is a catalytic system that uses urea water solution (UWS) as a reducing agent. This system has a relatively wide range of operating temperatures. However, the freezing point of the reducing urea solution used in this system is −11 °C. When the ambient temperature dips below this freezing point in winter, the solution may freeze. Therefore, it is important to understand the melting characteristics of frozen UWS in relation to the operating conditions of the heating device to supply the minimum amount of aqueous solution required by the system in the initial stage of normal operation and startup of the urea–SCR system. In this study, we artificially froze a liquid solution by placing it along with a heating module in an acrylic chamber to simulate a urea solution tank. Two types of heating modules (P120 and P160) consisting of two heating elements and heat transfer bodies were used to melt the frozen solution. The melting characteristics of the frozen solution were observed, for example, changes in the temperature distribution around the heating module and the cross-sectional melting shape with the passage of time since the start of the power supply to the heating module. The shape of melting around the heating module differed depending on the level of UWS relative to the heater inside the urea tank. In case 1, it melted in a wide shape with an open top, and in case 2, it melted in a closed shape. This shape change was attributed to the formation of internal gaseous space due to volume reduction during melting and the heat transfer characteristics of the fluid and solid substances. Full article

The NH₃ uniformity and conversion rate produced by the urea–water solution spray system is an essential factor affecting de-NO_x efficiency. In this work, a three-dimensional simulation model was developed with the CFD software and was employed to investigate the effects of two typical injection methods (wall injection and center injection) and three distribution strategies (pre-mixer, post-mixer, pre-mixer, and post-mixer) of two typical mixers on the urea conversion rate and uniformity. The field synergy principle was employed to analyze the heat transfer of different mixer flow fields. The results show that the single mixer has instability in optimizing different injection positions due to different injection methods and injection positions. The dual-mixer is stable in the optimization of the flow field under different conditions. The conclusion of the field synergy theory of the single mixer accords with the simulation result. The Fc of the dual-mixer cases is low, but the NH₃ conversion and uniformity index rate are also improved due to the increase in the residence time of UWS. Full article

Heavy-duty diesel engines in highway use account for more than 40% of total particulate and nitrogen oxide (NOx) emissions around the world. Selective catalytic reduction (SCR) is a method with effective results to reduce this problem. This research deals with problems in the urea evaporation process and ammonia gas distribution in an SCR system. The studied system used two types of urea injectors to elucidate the quality of ammonia uniformity in the SCR system, and a 12,000-cc heavy-duty diesel engine was used for experimentation to reduce NOx in the system. The uniformity of the generated quantities of ammonia was sampled at the catalyst inlet using a gas sensor. The ammonia samples from the two types of urea injectors were compared in experimental and simulation results, where the simulation conditions were based on experimental parameters and were performed using the commercial CFD (computational fluid dynamics) code of STAR-CCM+. This study produces temperatures of 371 to 374 °C to assist the vaporization phenomena of two injectors, the gas pattern informs the distributions of ammonia in the system, and the high ammonia quantity from the I-type urea injector and high quality of ammonia uniformity from the L-type urea injector can produce different results for NOx reduction efficiency quality after the catalyst process. The investigations showed the performance of two types of injectors and catalysts in the SCR system in a heavy-duty diesel engine. Full article

This study presents modeling of selective catalytic reduction (SCR) for systems of diesel exhaust gases aftertreatment. The main purpose of this work is to develop the modeling approach that allows accurate prediction of urea–water solution behavior (UWS) in the real diesel exhausts in temperature range 373 K to 873 K. The UWS is a key element of catalytic reduction of diesel NOx which utilizes ammonia as reducing specie. The finite volume method (FVM) extended by the nonrandom two liquids (NRTL) phase equilibrium model was used to perform the calculations. The results obtained were verified with experimental measurements. The comparison show that the NRTL extension introduced in this work allows reproducing the actual process conditions in the diesel exhaust environment. The accuracy of the results permits the model to be used for the design purposes and simulation approaches as well. Full article

In spray studies related to selective catalytic reduction (SCR) systems a common approach is to replace the urea–water solution (UWS) with pure water, even though there is very limited detailed information on the spray properties for these two liquids obtained under the same conditions using the same experimental equipment. Neither is it known how the possible differences in spray properties influence computational fluid dynamics (CFD) simulations. In this study, besides the flow characteristics, we compare both global and local spray parameters measured for UWS and pure water in the same conditions. To our knowledge, this is the first study which examines the influence on the injection process of replacing UWS with water over such a wide range. Moreover, the influence of different spray properties on CFD simulations is also examined. The experimental studies showed differences in almost all considered spray parameters. Moreover, different spray behaviour was noticed in terms of primary break-up. One important finding is that water and UWS sprays do have a similar Sauter mean diameter, but at the same time the droplet size distribution is considerably different. The simulation results indicated noticeable differences in terms of wall film formation; nevertheless, the overall mixing performance was not significantly affected. Full article

To cope with the progressive tightening of the emission regulations, gasoline and diesel engines will continuously require highly improved exhaust after-treatment systems. In the case of diesel engines, the selective catalytic reduction (SCR) appears as one of the widely adopted technologies to reduce NO_x (nitrogen oxides) emissions. Thereby, with the help of available heat from exhaust gas, the injected urea–water solution (UWS) turns inside the exhaust port immediately into gaseous ammonia (NH₃) by evaporation of mixture and thermal decomposition of urea. The reaction and conversion efficiency mostly depend upon the evaporation and subsequent mixing of the NH₃ into the exhaust gas, which in turn depends upon the engine loading conditions. Up to now, the aggregation of urea after evaporation of water and during the thermal decomposition of urea is not clearly understood. Hence, various scenarios for the urea depletion in the gaseous phase that can be envisaged have to be appraised under SCR operating conditions relying on an appropriate evaporation description. The objective of the present paper is therefore fourfold. First, a reliable multi-component evaporation model that includes a proper binary diffusion coefficient is developed for the first time in the Euler–Lagrangian CFD (computational fluid dynamics) framework to account properly for the distinct evaporation regimes of adBlue droplets under various operating conditions. Second, this model is extended for thermal decomposition of urea in the gaseous phase, where, depending on how the heat of thermal decomposition of urea is provided, different scenarios are considered. Third, since the evaporation model at and around the droplet surface is based on a gas film approach, how the material properties are evaluated in the film influences the process results is reported, also for the first time. Finally, the impact of various ambient temperatures on the adBlue droplet depletion characteristics as well as the effect of gravity is pointed out. The prediction capability of the model variants is assessed by comparing the achieved results to each other and with experimental data. It turns out that satisfactory agreement between experiment and numerical predictions is achieved for a wide range of operating temperatures by using correlations by “Wilke and Lee” for urea and by “Fuller et al.” for water. The results are essentially sensitive to gravity. From subsequent comparisons of different ways to account for the thermal decomposition in the gaseous urea, a significant difference is observed. Finally, the 1/3 film rule widely used for evaluating the material properties in the film shows accurate prediction of both evaporation and thermal decomposition regimes of urea. Full article

Since the Euro-ІІІ standard was adopted, the main methods to inhibit NO_x production in diesel engines are exhaust gas recirculation (EGR) and select catalyst reduction (SCR). On these methods SCR offers great fuel economy, so it has received wide attention. However, there also exists a trade-off law between NO_x conversion efficiency and NH₃ slip under dynamic conditions. To inhibit NH₃ slip with high NO_x conversion efficiency, a dynamic control method for a urea water solution (UWS) injection was investigated. The variation phenomena of SCR conversion efficiency with respect to the cross-sensitivity characteristics of the NO_x sensor to NH₃ have been thoroughly analyzed. The methodology of “uncertain conversion efficiency curve tangent analysis” has been applied to estimate the concentration of the slipped NH₃. The correction factor “φ” of UWS injection is obtained by a comparative calculation of the NO_x conversion ability and subsequent NH₃ slip. It also includes methods of flow compensation and flow reduction. The proposed control method has been authenticated under dynamic conditions. In low frequency dynamic experiments, this control method has accurately justified the NH₃ slip process and inhibits the NH₃ emission to a lower level thereby improving the conversion efficiency to a value closer to the target value. The results of European transient cycle (ETC) experiments indicate that NH₃ emissions are reduced by 90.8% and the emission level of NO_x is close to the Euro-Ѵ standard. Full article
