Fish in nature have evolved more efficient swimming capabilities compared to that of propeller-driven autonomous underwater vehicles. Motivated by such knowledge, we discuss a bionic (bio-memetic) autonomous underwater vehicle—a fish robot—that mimics the swimming of rainbow trout (Oncorhynchus mykiss) in nature. The robot consists of three (anterior, posterior, and tail) segments, connected via two (anterior and posterior) actuated hinge joints. We divided the half-period of undulation of the robot into two phases—thrusting and braking. In addition, we hypothesized that an asymmetric duration—a short period of thrusting and a long period of braking—implemented as an exponential (rather than “canonical”, sinusoidal) control would favorably affect the net propulsion of these two phases. The experimental results verified that, compared to sinusoidal undulation, the proposed exponential control results in increased speed of the robot between 1.1 to 4 times in the range of frequencies of undulation between 0.4 Hz and 2 Hz, and improved energy efficiency from 1.1 to 3.6 times in the same frequency range. Full article

A bio-inspired vehicle with banded fin fluctuation as the propulsion mode is the research topic. However, this propulsion mode suffers from low efficiency and requires the urgent resolution of other issues. In this paper, the kinematic model of the banded fin surface and the numerical calculation model for its hydrodynamic performance are established based on the long dorsal fin propelled by MPF (Media and/or Paired Fin propulsion) mode. Through numerical simulation, the hydrodynamic performance of the banded fin under typical working conditions is explored and its propulsion mechanism is analyzed. By using a method of controlling variables, such as wave number, swing angle, and frequency, where only one independent variable is changed at a time while the others remain constant, the impact on thrust coefficient function and the obtained periodic variation laws governing hydrodynamic performance are studied. Oscillatory thrust is generated by the fin’s motion, where it first captures water through a ‘scoop’ motion and then expels it via a diagonal ‘push’ motion, producing thrust. Due to limitations in fin length and varying oscillation shapes, the effective water-pushing stroke differs, leading to variations in work and creating periodic oscillatory forces. When the variable is the oscillation frequency, the propulsion efficiency of the oscillating fins remains nearly constant when the oscillation frequency is less than or equal to 1 Hz. However, when the oscillation frequency exceeds 1 Hz, the propulsion efficiency decreases as the oscillation frequency increases, and the rate of decrease gradually slows down. The effect of leading-edge suction on hydrodynamic performance was studied by varying the oscillating fin’s angle of attack. The results showed that, compared to the unchamfered configuration, the forward chamfer better utilizes vortex energy, reducing input power and significantly improving propulsion efficiency. Guided by both numerical simulations and experimental results, we design and manufacture a prototype of an underwater banded fin bio-inspired propeller that encompasses shape modeling, mechanical structure design, and control mechanism design. We conduct real water tests to verify feasibility and reliability in terms of forward movement, backward movement, and turning ability, among others. Furthermore, we analyze how varying angle of attack or optimizing front/rear edge shapes can effectively enhance hydrodynamic performance. Full article

Amphibious robots have broad prospects in the fields of industry, defense, and transportation. To improve the propulsion performance and reduce operation complexity, a novel bionic amphibious robot, namely AmphiFinbot-II, is presented in this paper. The swimming and walking components adopt a compound drive mechanism, enabling simultaneous control for the rotation of the track and the wave-like motion of the undulating fin. The robot employs different propulsion methods but utilizes the same operation strategy, eliminating the need for mode switching. The structure and the locomotion principle are introduced. The performance of the robot in different motion patterns was analyzed via computational fluid dynamics simulation. The simulation results verified the feasibility of the wave-like swimming mechanism. Physical experiments were conducted for both land and underwater motion, and the results were consistent with the simulation regulation. Both the underwater linear and angular velocity were proportional to the undulating frequency. The robot’s maximum linear speed and steering speed on land were 2.26 m/s (2.79 BL/s) and 442°/s, respectively, while the maximum speeds underwater were 0.54 m/s (0.67 BL/s) and 84°/s, respectively. The research findings indicate that the robot possesses outstanding amphibious motion capabilities and a simplistic yet unified control approach, thereby validating the feasibility of the robot’s design scheme, and offering a novel concept for the development of high-performance and self-contained amphibious robots. Full article

Driven by the demands of ocean exploration, an increasing number of manta ray-inspired robots have been designed and manufactured, primarily utilizing flexible skeletons combined with motor-driven mechanisms. However, the mechanical analysis of these designs remains underdeveloped, often relying on simplistic imitation of biological prototypes and typically neglecting the vertical motion induced by pectoral fin flapping. This paper presents a fluid–structure interaction analysis framework that couples rigid body motion with elastic deformation using flexible multibody dynamics and the vortex particle method. An implicit iterative algorithm with Aitken relaxation is employed to address added-mass instability, and the framework has been validated against experimental data. An analysis of a representative manta-bot model shows that self-induced vertical undulations reduce the thrust coefficient by approximately 40% compared to fixed vertical degrees of freedom, while slightly improving overall propulsive efficiency. The study also highlights the critical role of mass distribution in manta-bots, noting that excessive focus on complex pectoral fin movements and large fin mass can significantly reduce thrust by increasing vertical displacement, ultimately proving counterproductive. Full article

This paper conducts a comprehensive analysis of undulating and oscillatory movements in fish, utilizing numerical simulations to explore correlations among fin thrust and swimming speed. The study distinguishes itself through a unique approach by employing kinematic equations of motion control, specifically in oscillation and undulation, for computational fluid dynamics. Despite increasing energy loss with undulation, the study reveals a reduction in power demand with oscillation, underscoring its effectiveness in achieving desired speeds. The dynamics of undulating fins in aquatic and aerial locomotion remain insufficiently understood. The trade-off between more energy-consuming but highly propulsive movements or simpler and faster movements requires sophisticated design techniques to reduce volume. The geometry, developed using Rhino 6 software, incorporates precise fluid resistance calculations conducted with Ansys Fluent 19. Spanning flow velocities from 1 to 4 m/s were used for the simulation condition. Critical factors such as flexibility, viscosity, and shape change were meticulously examined for their impact on efficiency enhancement. Full article

This study introduces a cybernetic control and architectural framework for a robotic fish avatar operated by a human. The behavior of the robot fish is influenced by the electromyographic (EMG) signals of the human operator, triggered by stimuli from the surrounding objects and scenery. A deep artificial neural network (ANN) with perceptrons classifies the EMG signals, discerning the type of muscular stimuli generated. The research unveils a fuzzy-based oscillation pattern generator (OPG) designed to emulate functions akin to a neural central pattern generator, producing coordinated fish undulations. The OPG generates swimming behavior as an oscillation function, decoupled into coordinated step signals, right and left, for a dual electromagnetic oscillator in the fish propulsion system. Furthermore, the research presents an underactuated biorobotic mechanism of the subcarangiform type comprising a two-solenoid electromagnetic oscillator, an antagonistic musculoskeletal elastic system of tendons, and a multi-link caudal spine composed of helical springs. The biomechanics dynamic model and control for swimming, as well as the ballasting system for submersion and buoyancy, are deduced. This study highlights the utilization of EMG measurements encompassing sampling time and $\mu$-volt signals for both hands and all fingers. The subsequent feature extraction resulted in three types of statistical patterns, namely, $\mathsf{\Omega },\gamma ,\lambda$, serving as inputs for a multilayer feedforward neural network of perceptrons. The experimental findings quantified controlled movements, specifically caudal fin undulations during forward, right, and left turns, with a particular emphasis on the dynamics of caudal fin undulations of a robot prototype. Full article

Research into how fish and other aquatic organisms propel themselves offers valuable natural references for enhancing technology related to underwater devices like vehicles, propellers, and biomimetic robotics. Additionally, such research provides insights into fish evolution and ecological dynamics. This work carried out a numerical investigation of the most relevant dimensionless parameters in a fish swimming environment (Reynolds $Re$, Strouhal $St$, and $Slip$ numbers) to provide valuable knowledge in terms of biomechanics behavior. Thus, a three-dimensional numerical study of the fish-like lambari, a BCF swimmer with carangiform kinematics, was conducted using the URANS approach with the k-$\omega$-SST transition turbulence closure model in the OpenFOAM software. In this study, we initially reported the equilibrium Strouhal number, which is represented by $S{t}^{\ast }$, and its dependence on the Reynolds number, denoted as $Re$. This was performed following a power–law relationship of $St\propto R{e}^{(-\alpha )}$. We also conducted a comprehensive analysis of the hydrodynamic forces and the effect of body undulation in fish on the production of swimming drag and thrust. Additionally, we computed propulsive and quasi-propulsive efficiencies, as well as examined the influence of the Reynolds number and $Slip$ number on fish performance. Finally, we performed a vortex dynamics analysis, in which different wake configurations were revealed under variations of the dimensionless parameters $St$, $Re$, and $Slip$. Furthermore, we explored the relationship between the generation of a leading-edge vortex via the caudal fin and the peak thrust production within the motion cycle. Full article

A bionic robotic fish based on compliant structure can excite the natural modes of vibration, thereby mimicking the body waves of real fish to generate thrust and realize undulate propulsion. The fish body wave is a result of the fish body’s mechanical characteristics interacting with the surrounding fluid. Thoroughly analyzing the complex modal characteristics in such robotic fish contributes to a better understanding of the locomotion behavior, consequently enhancing the swimming performance. Therefore, the complex orthogonal decomposition (COD) method is used in this article. The traveling index is used to quantitatively describe the difference between the real and imaginary modes of the fish body wave. It is defined as the reciprocal of the condition number between the real and imaginary components. After introducing the BCF (body and/or caudal fin) the fish’s body wave curves and the COD method, the structural design and parameter configuration of the tensegrity robotic fish are introduced. The complex modal characteristics of the tensegrity robotic fish and real fish are analyzed. The results show that their traveling indexes are close, with two similar complex mode shapes. Subsequently, the relationship between the traveling index and swimming performance is expressed using indicators reflecting linear correlation (correlation coefficient ($R_c$) and p value). Based on this correlation, a preliminary optimization strategy for the traveling index is proposed, with the potential to improve the swimming performance of the robotic fish. Full article

The traditional propeller-based propulsion of underwater robots is inefficient and poorly adapted to practice. By contrast, underwater biomimetic robots show better stability and maneuverability in harsh marine environments. This is particularly true of undulating propulsion biomimetic robots. This paper classifies the existing underwater biomimetic robots and outlines their main contributions to the field. The propulsion mechanisms of underwater biomimetic undulating robots are summarized based on theoretical, numerical and experimental studies. Future perspectives on underwater biomimetic undulating robots are also presented, filling the gaps in the existing literature. Full article

Autonomous robots are used to inspect, repair and maintain underwater assets. These tasks require energy-efficient robots, including efficient movement to extend available operational time. To examine the suitability of a propulsion system based on undulating fins, we built two robots with one and two fins, respectively, and conducted a parametric study for combinations of frequency, amplitude, wavenumber and fin shapes in free-swimming experiments, measuring steady-state swimming speed, power consumption and cost of transport. The following trends emerged for both robots. Swimming speed was more strongly affected by frequency than amplitude across the examined wavenumbers and fin heights. Power consumption was sensitive to frequency at low wavenumbers, and increasingly sensitive to amplitude at high wavenumbers. This increasing sensitivity of amplitude was more pronounced in tall rather than short fins. Cost of transport showed a complex relation with fin size and kinematics and changed drastically across the mapped parameter space. At equal fin kinematics as the single-finned robot, the double-finned robot swam slightly faster (>10%) with slightly lower power consumption (<20%) and cost of transport (<40%). Overall, the robots perform similarly to finned biological swimmers and other bio-inspired robots, but do not outperform robots with conventional propulsion systems. Full article

Stable, quiet, and efficient propulsion methods are essential for underwater robots to complete their tasks in a complex marine environment. However, with a single propulsion method, such as propeller propulsion and bionic propulsion, it is difficult to achieve high efficiency and high mobility at the same time. Based on the advantages of the high-efficiency propulsion of a bionic undulating fin and the stable control of the propeller, an underwater robot based on the hybrid propulsion of a quadrotor and undulating fin is proposed in this paper. This paper first introduces the mechanical implementation of the underwater robot. Then, based on kinematic modeling and theoretical derivation, the underwater motion and attitude of the robot are analyzed and the 6-DOF dynamic equation of the robot is established. Finally, the underwater motion performance of the robot is verified through field experiments. The experimental results show that the robot can realize the heave motion, surge motion, and in-situ steering motion independently and can hover stably. When the undulating frequency is 6 Hz, the maximum propulsion speed of the robot can reach up to 1.2 m/s (1.5 BL/s). Full article

This paper presents the experimental research conducted for the Biomimetic Unmanned Underwater Vehicle (BUUV). The study’s major goal is to create a single, flexible side fin with adequate proportions and stiffness for an energy-efficient propulsion system. The experiments were carried out in a laboratory water tunnel equipped with a sensor for direct thrust measurement for various fin dimensions. Further, the particle image velocimetry (PIV) approach was used for a more in-depth examination of fluid–structure interaction (FSI) phenomena. The given experiments indicate the region of superior propulsion system performance and explain the main aspects that have influenced thrust generation using image processing and the PIV approach. Full article

This article covers research on an innovative propulsion system design for a Biomimetic Unmanned Underwater Vehicle (BUUV) operating at low speeds. The experiment was conducted on a laboratory test water tunnel equipped with specialised sensor equipment to assess the Fluid-Structure Interaction (FSI) and energy consumption of two different types of propulsion systems. The experimental data contrast the undulating with the drag-based propulsion system. The additional joint in the drag-based propulsion system is intended to increase thrust and decrease energy input. The tests were conducted at a variety of fins oscillation frequencies and fluid velocities. The experiments demonstrate that, in the region of low-speed forward movement, the efficiency of the propulsion system with the additional joint is greater. Full article

The method of regularised stokeslets is widely used to model microscale biological propulsion. The method is usually implemented with only the single-layer potential, the double-layer potential being neglected, despite this formulation often not being justified a priori due to nonrigid surface deformation. We describe a meshless approach enabling the inclusion of the double layer which is applied to several Stokes flow problems in which neglect of the double layer is not strictly valid: the drag on a spherical droplet with partial-slip boundary condition, swimming velocity and rate of working of a force-free spherical squirmer, and trajectory, swimmer-generated flow and rate of working of undulatory swimmers of varying slenderness. The resistance problem is solved accurately with modest discretisation on a notebook computer with the inclusion of the double layer ranging from no-slip to free-slip limits; the neglect of the double-layer potential results in up to 24% error, confirming the importance of the double layer in applications such as nanofluidics, in which partial slip may occur. The squirming swimmer problem is also solved for both velocity and rate of working to within a small percent error when the double-layer potential is included, but the error in the rate of working is above 250% when the double layer is neglected. The undulating swimmer problem by contrast produces a very similar value of the velocity and rate of working for both slender and nonslender swimmers, whether or not the double layer is included, which may be due to the deformation’s ‘locally rigid body’ nature, providing empirical evidence that its neglect may be reasonable in many problems of interest. The inclusion of the double layer enables us to confirm robustly that slenderness provides major advantages in efficient motility despite minimal qualitative changes to the flow field and force distribution. Full article

To reduce human risk and maintenance costs, Autonomous Underwater Vehicles (AUVs) are involved in subsea inspections and measurements for a wide range of marine industries such as offshore wind farms and other underwater infrastructure. Most of these inspections may require levels of manoeuvrability similar to what can be achieved by tethered vehicles, called Remotely Operated Vehicles (ROVs). To extend AUV intervention time and perform closer inspection in constrained spaces, AUVs need to be more efficient and flexible by being able to undulate around physical constraints. A biomimetic fish-like AUV known as RoboFish has been designed to mimic propulsion techniques observed in nature to provide high thrust efficiency and agility to navigate its way autonomously around complex underwater structures. Building upon advances in acoustic communications, computer vision, electronics and autonomy technologies, RoboFish aims to provide a solution to such critical inspections. This paper introduces the first RoboFish prototype that comprises cost-effective 3D printed modules joined together with innovative magnetic coupling joints and a modular software framework. Initial testing shows that the preliminary working prototype is functional in terms of water-tightness, propulsion, body control and communication using acoustics, with visual localisation and mapping capability. Full article
