Based on the engineering context of prefabricated underground station structures, this paper proposed a novel diaphragm wall–beam joint based on post-poured ultra-high-performance concrete (UHPC) and non-contact lap-spliced steel bars. This research study designed and conducted a full-scale experiment on the diaphragm wall–beam joints. The failure modes, bearing capacity, overall stiffness, crack resistance performance, and force transmission mechanism of the new diaphragm wall–beam joint were investigated. Additionally, a three-dimensional finite element model (FEM) of the wall–beam joint was developed using the software ABAQUS 2020. The model was validated against experimental results and used for further analysis. The results showed that the tensile through-cracks at the UHPC-diaphragm wall interface characterize the final failure process. The proposed UHPC joint could satisfy the structural design requirements in terms of crack resistance and bearing capacity. No rebar pulled-out damage was observed, and the non-contact lap-spliced length of 10d in the UHPC joint was sufficient. Compared with the traditional cast-in-place concrete joint, the cracking moment and yield moment of the proposed UHPC joint increased by 8.7% and 5.4%, respectively. Full article

The anti-punch drilling robot is a core piece of equipment used to realize unmanned drilling and pressure relief operations in underground coal mines. Adaptive drilling, conducted according to the coal rock properties encountered during drilling, is essential to improve the safety and efficiency of the pressure relief working face. This paper analyzed the composition of the anti-punch drilling robot drilling system and workflow of the drilling system and then calculated the optimal rotary speed and the optimal feed speed for different Platts hardness coefficients of the coal rock through the analysis of the drilling rod force. Based on the characteristics of the drilling electrohydraulic control system, a rotary adaptive controller based on a self-resistant control algorithm and a feed adaptive controller based on sliding mode variable structure control were designed. A joint simulation was carried out using AMESim 2020.1 and Simulink 2020b software to analyze the control performance of each controller. Finally, an experimental platform for the drilling robot electrohydraulic control system was constructed; different hardness coefficients of concrete specimens were used to simulate the hardness of the coal rock with different traits. Single coal rock hardness experiments and drilling experiments with sudden changes in coal rock hardness were carried out. The experimental results showed that the adaptive control strategy proposed in this paper satisfies the requirements of drilling system control. Full article

Coal-bearing strata belong to sedimentary strata, and there are multiple aquifers. The accurate detection of deep aquifers is helpful to the safe mining of the working face. In order to provide guidance for the interpretation of the surface-to-underground transient electromagnetic method (SUTEM) that can be used to detect deep aquifers, we used theoretical analysis and numerical simulation methods in this study. Taking uniform half-spaces, single aquifers, and double aquifers as examples, we systematically studied the data characteristics and degree of influence of SUTEM under the influence of shallow aquifers. The results indicate the following: Under the influence of the primary field distribution, the x or y component of the induced electromotive force received by the underground receiving point has a positive and negative inflection point, which increases the difficulty of data interpretation, and the z component is easier to use for data interpretation. The influence of the aquifer on the early data of the underground receiving point is much greater than that of the ground receiving point, and the late influence is closer to the ground receiving point. The change in resistivity of the shallow aquifer has the greatest influence on the ability of each measuring point to detect the data of the deep aquifer; this influence is followed by change in thickness, and change in depth has the least influence on the detection capability of each measuring point. Full article

Exploration rovers have difficulty moving underground because the drag force from the ground restricts their movement; this hinders underground exploration. This study aimed to address this challenge. We posit a hypothesis that the rover can move underground by imparting vibration to the ground and changing the drag force. To validate this hypothesis, a testbed that moves underground was developed, and the drag force when imparting vibration was investigated. The results revealed that the drag force while imparting vibration is smaller than that after imparting vibration, and we accordingly devised the operation for moving underground. The proposed operation causes bias of the drag force by imparting vibration to make the testbed move in the direction of the small drag force. The effectiveness of the proposed method was assessed through an experiment wherein the testbed was set to move underground. The experimental results demonstrate the superiority of the proposed method, as the movement distance achieved with vibration is considerably greater than that without vibration. The findings validate the hypothesis that using vibration for underground motion is effective in improving mobility and provides valuable insights into the design of robots for underground motion. Full article

Rapid advancements in construction technologies have accelerated the development of complex and deep underground structures, raising concerns about the impact of groundwater on structures, particularly anti-floating measures. Traditional tensioned anchors, commonly used for preventing flotation, suffer from limitations like low pull-out bearing capacity, shallow critical anchoring depth, and localized stress concentration. To overcome these limitations, this paper introduces a tension–compression dispersed composite anchor, which combines casing, load-bearing plates, and tensioned anchors. Comparative tests were conducted between these composite anchors and traditional tensioned anchors to analyze their anchoring behavior. Our results show that tensioned anchors exhibit a stable axial force distribution as anchoring length increases. By identifying abrupt changes in the axial force curve, optimal anchoring lengths for load-dispersed anchors can be determined, thereby enhancing rock and soil strength utilization. The tension–compression-dispersed composite anchor outperforms tensioned anchors, with 1.44 times the ultimate bearing capacity for equivalent anchoring lengths and 1.1 times the capacity for an additional 1 m length. It also displays superior deformation adaptability and structural ductility under high-bearing loads compared to tensioned anchors with extended anchoring lengths. Effectively mobilizing the strength of the lower anchoring segment within the rock and soil results in a lower critical anchoring depth and a more uniform distribution of lateral friction resistance. In conclusion, the tension–compression-dispersed composite anchor offers significant advantages, making it a promising engineering solution for anti-floating anchor systems in complex underground environments. Full article

Large deformations can easily occur when tunneling through weak surrounding rock with high underground stresses. Under high-stress environments, the surrounding rock stores a large amount of strain energy, and the strain energy stored in the soft and weak surrounding rock enclosure is dissipated through the large traveling plastic deformation. Therefore, the effective use of the surrounding rock’s bearing capacity and energy dissipation is a feasible solution to the large deformation problem. Based on the energy principle, this study designs a high compressibility, large stroke energy-dissipation element, which transforms the traditional support into energy-dissipation support and solves the problem of large deformation by reasonably utilizing the “displacement” of the surrounding rock. The experimental results showed that the steel plate assembled structure had an initial peak value of about 15 MPa, a constant resistance of about 2 MPa with a large stroke, and a compression rate of more than 75%, with good post-compression flexural peak characteristics. Elastic–plastic buckling analyses of defective steel plate composite structures were carried out using finite element analysis software, and the deformation and force characteristics of a variety of steel plate composite structures after buckling under actual field conditions were investigated. Based on the 3D laser scanning system, the thickness of the upper and lower steel plates of the steel plate composite structure was set to 1 cm, the height of the vertical plate was set to 28 cm, and the thickness was set to 8 mm. The original rigid supporting method was converted into one of compression support by circumferentially embedding the steel plate composite structure into the initial support structure. The resulting support configuration offered a high safety factor because the pressure of the surrounding rock was released by the deformation of the steel plate composite structure. Full article

A simplified analytical method useful for ductile ground support design in underground mine workings is presented. This approach allows for maintaining the stability of sidewalls in rectangular openings extracted in competent and homogeneous rocks, especially in high-pressure conditions, favoring rockburst event occurrence. The proposed design procedure involves the typical assumptions governing the limit equilibrium method (LEM) with respect to a triangular rock block expelled from a sidewall of a long mine excavation subjected to normal stresses of the values determined based on the Maugis’s analytical solution concerned with stress distribution around the elliptical opening extracted within the homogeneous infinite elastic space. This stage of the local assessment of rock susceptibility to ejection from the walls of the excavation allowed for determining the geometry of the block whose ejection is most likely in a given geological and mining situation. Having extensive information about the geometry of the excavations and the properties of the surrounding rocks, it was possible to make an exemplary map of the risk from rockburst hazard, developed as the 2D contours of safety indexes’ values, for special-purpose excavations such as heavy machinery chambers, main excavations, etc. in conditions of selected mining panel of the deep copper mine at Legnica-Głogów Copper Basin, Poland. Another important element of the obtained results is the calculated values of the horizontal forces potentially pushing out the predetermined rock blocks. These forces are the surplus over the potential of frictional resistance and cohesion on the surfaces of previously identified discontinuities or on new cracks appearing as a result of overloading of the sidewalls. Finally, the presented algorithm allows us to perform quantitative tracking of rockburst phenomena as a function of time by determination of acceleration, velocity, and displacement of expelled rocks. Such information may be useful at the stage of designing the support for underground workings. Full article

The rectangular pipe jacking method is an efficient, green, trenchless technology for constructing urban underground space. However, some problems, including the high jacking resistance, the instability of the tunneling face, and excessive ground settlement during the large-section rectangular pipe jacking for the underpass of national highways, seriously affect construction safety and traffic. Based on the engineering background of the large-section rectangular pipe jacking in constructing the subway entrance tunnel of Guangzhou Metro Line 7, this work adopts the methods of theoretical calculation, numerical simulation, and engineering application. Five kinds of mechanical models for pipe soil slurry interactions in rectangular pipe jacking are analyzed. An evaluation of the applicability of the jacking force prediction of the different models is conducted. Moreover, the ground settlement law for the large-section rectangular pipe jacking for the underpass of national highways under different influencing factors, including slurry sleeve thickness, grouting pressure, and earth chamber pressure, is revealed. The control countermeasures of the ground settlements, such as installing a waterproof rubber curtain for the tunnel portal, pipe jacking machine receiving techniques, thixotropic slurry for reducing friction resistance, and soil stability at the tunneling face, are carried out. The results show that there is no need to install an intermediate jacking station in the large-section rectangular pipe jacking project with a jacking distance of 63 m. The most reasonable thickness of the thixotropic slurry sleeve is about 150 mm. The most reasonable grouting pressure range is 600–700 kPa. An earth chamber pressure of about 153 kPa is more reasonable to control the soil stability of the tunneling face. The engineering practice shows that the maximum ground settlement of the national highway during jacking is 10 mm. The maintenance effect is excellent, and the traffic operates normally. Full article

To study the influence law of the seismic response of underground station structures at liquifiable interlayer sites, a two-dimensional numerical model of the interaction between the soil and station structure was established based on the finite difference software FLAC^3D. The nonlinear dynamic response of the station structure located at the liquifiable interlayer site was analyzed considering the location distribution, relative density, and thickness of the liquifiable interlayer. The results show that the deformation of the structure is greatest when the liquifiable interlayer is distributed on both sides of the station side walls, while the interlayer has an energy-dissipating and damping effect on the upper station structure when it is located at the bottom of the structure. The lower the relative density of the liquifiable interlayer is, the stronger the internal dynamic response of the structure will be, and the more unfavorable it will be to the seismic resistance of the structure. When the liquefiable interlayer is only present in the lateral foundation of the station, an increase in its thickness results in a stronger shear effect on the structure and a higher probability of damage. However, when the thickness of the liquifiable interlayer reaches a point where the entire station is placed within it, the lateral force and deformation of the structure are significantly reduced. Full article

The fracturing behaviors of serial coal pillars is significant for understanding their failure mechanism. To reveal this, the bearing stress, acoustic emission, electrical resistivity, local strain, force chain distribution, and cracks evolution of serial coal pillars under uniaxial compression were evaluated by experiment and numerical simulation. The results show that four bearing stages are observed during the fracturing process (i.e., nonlinear growth, linear growth, yielding growth, and weakening stages). The acoustic emission features, electrical resistivity responses, strain develops, force chain distributions, cracks evolutions, and local displacement are highly consistent to illustrate the fracturing behaviors. System fracturing of serial coal pillar specimens is appeared along with the collapse of lower uniaxial compressive strength coal pillar specimen. The limit bearing capacity of serial coal pillar specimens is almost equal to the strength of lower uniaxial compressive strength coal pillar specimen. The unbalanced deformation characteristics of serial coal pillar specimens are presented due to the strength differences. The evolution of the key deformation element is the rooted reason for the overall fracturing mechanism of serial coal pillar specimens. For serial coal pillar specimens with different strengths, the critical condition of system fracturing is that the sum of secant modulus of upper and bottom coal pillars is zero, which is expected to predict the system fracturing of serial pillars in the underground coal mining. Full article

Under the influence of coal mining, the gravel in mining tunnel sections of a fault fracture zone is prone to collapse, and the collapse accumulation body will block the tunnel, which has a very adverse influence on the safety production of coal mining and the evacuation of personnel after underground disasters. The macroscopic and mechanical characteristics of the collapse accumulation body have been studied extensively in previous works. The purpose of this paper is to provide theoretical support and reference for the rapid excavation of the tunnel blocked by the collapse accumulation body in the fault fracture zone. Taking the fault fracture zone in the tunnel as the research background, the physical characteristics and boundary mechanical characteristics of the collapse accumulation body in the fault fracture zone are studied by the method of combining on-site investigation and theoretical analysis. The results show that the force acting on the boundary on both sides of the accumulation body is passive resistance from the side wall, which is derived from the slip effect of the accumulation body slope. Similarly, the unstable boundary of the fault fracture zone caused by tunnel instability is elliptical, and the overlying load of the rescue channel to be excavated in the accumulation body is limited. On the basis of the collapse instability dimensions of the broken zone of the tunnel surrounding the rock, the calculation formulas of the height of the accumulation body and the horizontal force at the boundary were established, respectively, under two conditions of whether the collapse space was filled, and whether the curve relationship between the distribution of the horizontal force at the boundary of the accumulation body and the buried depth in the accumulation body was obtained. Full article

Accurate estimation of the buoyancy forces exerted on underground structures is a problem in geotechnical engineering that directly impacts the construction safety and cost of these structures. Therefore, studying the buoyancy resistance of underground structures has great scientific and practical value. In this study, an initial difference in the hydraulic head, Δh₀, was discovered to be present in aquitards through analysis of water-level data collected from the observation of real-world structures and in laboratory control tests. That is, seepage occurs beyond a threshold Δh₀. Analysis of test data reveals that a deviation from Darcy’s law is the theoretical basis for Δh₀ and that Δh₀ equals the initial hydraulic gradient multiplied by the length of the seepage path. The general consistency between the experimentally measured and theoretically calculated values of Δh₀ validates the theoretical explanation for Δh₀. The results of this study provide a basis for scientifically calculating the buoyancy resistance required for the construction of underground structures. Full article

Coal resources perform an important role in China’s energy structure. Hydraulic support is the main supporting equipment of fully mechanized mining face in coal mines. Because the hydraulic support frequently bears the impact pressure from the working face, it is very easy to cause failure of the balance jack. In order to solve the problem that the balance jack easily damaged by impact and improve the impact resistance of the hydraulic support, an improved fast response balance jack with multiple adaptive buffers was proposed in this paper. The energy dissipation characteristics of the balance jack were analyzed by establishing the mathematical model of the multiple buffering process of it. Based on ADAMS, the dynamic simulation model of the hydraulic support was constructed, and the mechanical response characteristics of the proposed balance jack and the traditional balance jack under different impact loads were compared and analyzed. By changing the equivalent stiffness of the novel balance jack system, the influence of different initial inflation pressure and length of the buffer cavity on the dynamic performance of the novel balance jack was discussed. The results show that compared with the traditional balance jack, the multi-adaptive response balance jack proposed in this paper can reduce the peak force of the hinge point by about 24.6% and the fluctuation frequency was also significantly reduced under the ultimate load condition at the front end of the top beam, which has better impact resistance. When the initial inflation pressure of the buffer cavity is 40~45 MPa and the initial length is less than 105 mm, a better buffer effect can be achieved. This study provides a new solution to solve the failure problem of the balance jack under the underground impact pressure and improve the safety and reliability of hydraulic support. Full article

Underground coal gasification (UCG) technology converts deep coal resources into synthesis gas for use in the production of electricity, fuels and chemicals. This study provides an overview of the systematic methods of the in situ coal gasification process. Furthermore, the model of the porous structure of coal has been presented and the gas movement taking place in the carbon matrix—which is part of the bed—has been described. The experimental tests were carried out with the use of air forced through the nozzle in the form of a gas stream spreading in many directions in a porous bed under bubbling conditions. The gas flow resistance coefficient was determined as a function of the Reynolds number in relation to the diameter of the gas flow nozzle. The proprietary calculation model was compared to the models of many researchers, indicating a characteristic trend of a decrease in the gas flow resistance coefficient with an increase in Reynolds number. The novelty of the study is the determination of the permeability characteristics of char (carbonizate) in situ in relation to melted waste rock in situ, taking into account the tortuosity and gas permeability factors for an irregularly shaped solid. Full article

Growing demand for raw materials forces mining companies to reach deeper deposits. Difficult environmental conditions, especially high temperature and the presence of toxic/explosives gases, as well as high seismic activity in deeply located areas, pose serious threats to humans. In such conditions, running an exploration strategy of machinery parks becomes a difficult challenge, especially from the point of view of technical facilities inspections performed by mining staff. Therefore, there is a growing need for new, reliable, and autonomous inspection solutions for mining infrastructure, which will limit the role of people in these areas. In this article, a method for detection of conveyor rollers failure based on an acoustic signal is described. The data were collected using an ANYmal autonomous legged robot inspecting conveyors operating at the Polish Ore Enrichment Plant of KGHM Polska Miedź S.A., a global producer of copper and silver. As a part of an experiment, about 100 m of operating belt conveyor were inspected. The sound-based fault detection in the plant conditions is not a trivial task, given a considerable level of sonic disturbance produced by a plurality of sources. Additionally, some disturbances partially coincide with the studied phenomenon. Therefore, a suitable filtering method was proposed. Developed diagnostic algorithms, as well as ANYmal robot inspection functionalities and resistance to underground conditions, are developed as a part of the “THING–subTerranean Haptic INvestiGator” project. Full article
