Search Results (19)

This article proposes an adaptive sliding mode fault-tolerant tracking control scheme for underactuated unmanned surface vehicles (USVs) that suffer from loss of effectiveness and increase in bias input when performing path tracking. First, the mathematical model and fault model of USVs are introduced. Then, the USV is driven along the planned path by back-stepping and fast terminal sliding mode control. The radial basis function (RBF) neural network is used to approximate the unknown external disturbances caused by wind, waves, and currents, the unmodeled dynamics of the system, the actuator non-executed portions and bias faults. An adaptive law is designed to account for the loss of effectiveness of the thruster. In addition, through the analysis of Lyapunov stability criteria, it is proved that the proposed control method can asymptotically converge the tracking error to zero. Finally, this paper uses a simulation to demonstrate that, when a fault occurs, the tracking effect of the fault-tolerant control method proposed in this paper is almost the same as that without a fault, which proves the effectiveness of the designed adaptive law. Full article

Aiming to address the problem of underactuated unmanned surface vehicles (USVs) performing fixed-point operations at sea without dynamic positioning control systems, this paper introduces an original approach to positioning control: the virtual anchor control method. This method is applicable in environments with currents that change slowly and does not require prior knowledge of current information or vessel motion model parameters, thus offering convenient usability. This method comprises four steps. First, a concise linear motion model with unknown disturbances is proposed. Then, a motion planning law is designed by imitating underlying principles of ship anchoring. Next, an adaptive disturbance observer is proposed to estimate uncertainties in the motion model. In the last step, based on the observer, a sliding-mode method is used to design a heading control law, and a thrust control law is also designed by applying the Lyapunov method. Numerical simulation experiments with significant disturbances and tidal current variations are conducted, which demonstrate that the proposed method has a good control effect and is robust. Full article

In this paper, a bio-inspired sliding mode control (bio-SMC) and minimal learning parameter (MLP) are proposed to achieve the cooperative formation control of underactuated unmanned surface vehicles (USVs) with external environmental disturbances and model uncertainties. Firstly, the desired trajectory of the follower USV is generated by the leader USV’s position information based on the leader–follower framework, and the problem of cooperative formation control is transformed into a trajectory tracking error stabilization problem. Besides, the USV position errors are stabilized by a backstepping approach, then the virtual longitudinal and virtual lateral velocities can be designed. To alleviate the system oscillation and reduce the computational complexity of the controller, a sliding mode control with a bio-inspired model is designed to avoid the problem of differential explosion caused by repeated derivation. A radial basis function neural network (RBFNN) is adopted for estimating and compensating for the environmental disturbances and model uncertainties, where the MLP algorithm is utilized to substitute for online weight learning in a single-parameter form. Finally, the proposed method is proved to be uniformly and ultimately bounded through the Lyapunov stability theory, and the validity of the method is also verified by simulation experiments. Full article

To achieve precise control of the symmetrical unmanned surface vehicle (USV) under strong external disturbances, we propose a disturbance estimation and conditional disturbance compensation control (CDCC) scheme. First, the differential flatness method is applied to convert the underactuated model into a fully actuated one, simplifying the controller design. Then, a nonlinear disturbance observer (NDOB) is designed to estimate the lumped disturbance. Subsequently, a continuous disturbance characterization index (CDCI) is proposed, which not only indicates whether the disturbance is beneficial to the system stability but also makes the controller switch smoothly and suppresses the chattering phenomenon greatly. Indicated by the CDCI, the proposed CDCC method can not only utilize the beneficial disturbance but also compensate for the detrimental disturbance, which improves the USV’s control performance under strong external disturbances. Moreover, a trajectory-planning method is designed to generate an obstacle avoidance reference trajectory for the controller. Finally, simulations verify the feasibility of applying the proposed control method to USV. Full article

In this paper, targeting the problem that it is difficult to deal with the time-varying sideslip angle of an underactuated unmanned surface vehicle (USV), a line–of–sight (LOS) guidance law based on an improved extended state observer (ESO) is proposed. A reduced-order ESO is introduced into the identification of the sideslip angle caused by the environmental disturbance, which ensures a fast and accurate estimation of the sideslip angle. This enables the USV to follow the reference path with high precision, despite external disturbances from wind, waves, and currents. These unknown disturbances are modeled as drift, which the modified ESO-based LOS guidance law compensates for using the ESO. In the guidance subsystem incorporating the reduced-order state observer, the observer estimation and track errors are proved uniformly ultimately bounded. Simulation and experimental results are presented to validate the effectiveness of the proposed method. The simulation and comparison results demonstrate that the proposed ELOS guidance can help a USV track different types of paths quickly and smoothly. Additionally, the experimental results confirm the feasibility of the method. Full article

This paper focuses on a distributed cooperative time-varying formation maneuvering issue of under-actuated unmanned surface vehicles (USVs). A fleet of USVs is guided by a parameterized path with a time-varying formation while avoiding collisions and preserving the connectivity in the environment with multiple obstacles. In some surface missions, due to the obstacles in the external environment, the bandwidth limitations of the communication channel, and the hardware components/performance constraints of the USVs themselves, each vehicle is considered to be subject to model uncertainty, actuator quantization, sensor dead zone, and velocity constraints. During the control design process, the radial basis function (RBF) neural networks (NNs) are utilized to deal with nonlinear terms. Based on a nonlinear decomposition method, the relationship between the control signal and the quantization one is established, which overcomes the difficulty arising from actuator quantization. A Nussbaum function is introduced to handle the unknown output dead zone problem caused by reduced sensor sensitivity. Moreover, a universal-constrained function is employed to satisfy both the constrained and unconstrained requirements during formation keeping and obstacle avoidance. The Lyapunov stability theory confirmed that the error signals are uniformly ultimately bounded (UUB). The simulation results demonstrate the effectiveness of the proposed distributed formation control of multiple USVs. Full article

Model predictive control (MPC), an extensively developed rolling optimization control method, is widely utilized in the industrial field. While some researchers have incorporated predictive control into underactuated unmanned surface vehicles (USVs), most of these approaches rely primarily on theoretical simulation research, emphasizing simulation outcomes. A noticeable gap exists regarding whether predictive control adequately aligns with the practical application conditions of underactuated USVs, particularly in addressing real-time challenges. This paper aims to fill this void by focusing on the application of MPC in the path following of USVs. Using the hydrodynamic model of USVs, we examine the details of both linear MPC (LMPC) and nonlinear MPC (NMPC). Several different paths are designed to compare and analyze the simulation results and time consumption. To address the real-time challenges of MPC, the calculation time under different solvers, CPUs, and programming languages is detailed through simulation. The results demonstrate that NMPC exhibits superior control accuracy and real-time control potential. Finally, we introduce an enhanced A* algorithm and use it to plan a global path. NMPC is then employed to follow that path, showing its effectiveness in tracking a common path. In contrast to some literature studies using the LMPC method to control underactuated USVs, this paper presents a different viewpoint based on a large number of simulation results, suggesting that LMPC is not fit for controlling underactuated USVs. Full article

An effective path-following controller is a guarantee for stable sailing of underactuated unmanned surface vehicles (USVs). This paper proposes an event-triggered robust control approach considering an unknown model nonlinearity, external disturbance, and event-triggered mechanism. The proposed method consists of guidance and dynamic control subsystems. Based on the tracking error dynamics equations, the guidance subsystem is designed to achieve the guidance law. For the dynamic control subsystem, the radial basis function neural networks (RBFNNs) are designed to approximate the unknown model nonlinearity and external disturbances to improve the robustness of the proposed method. In addition, an event-triggered mechanism is constructed to reduce the triggering times. The closed-loop system is proven to be stable, and the effectiveness of the proposed method is illustrated through simulation results. Full article

In this paper, a solution to the problem of following a curved path for underactuated unmanned surface vehicles (USVs) with unknown sideslip angle and model uncertainties is studied. A novel smooth sliding mode control (SSMC) based on a finite-time extended state observer (FTESO) for heading control is proposed. Firstly, the model of a USV with rudderless double thrusters is established. Secondly, the path-following error dynamics of a USV is established in a path-tangential reference frame. Thirdly, a finite-time observer is introduced to estimate the unidentified sideslip angle, and the line-of-sight (LOS) guidance law is applied to produce the desired heading angle. Finally, an SSMC controller is proposed to force USV tracking at the desired heading angle and surge speed, in which FTESO is used to estimate and compensate the unknown disturbance in sliding mode dynamics. The theoretical analysis for FTESO-SSMC verifies that the controller can provide finite-time convergence to and stability on the sliding surface. Simulation studies and contrast test are conducted to demonstrate the robustness and rapidity of the proposed FTESO-SSMC controller. Full article

This paper mainly addresses the model-parameter-free prescribed time trajectory tracking control issue for under-actuated unmanned surface vehicles (USVs) that are susceptible to model uncertainties, time-varying disturbances, and saturation constraints. Firstly, a state extension based on coordinate transformation was designed to address the lack of control in the sway channel. Secondly, nonlinear behavior stemming from saturation constraints is not always differentiable. Regarding this, a smooth dead-zone-based model was conducted to fit the behavior, leaving a relatively simple actuator model. Then, an improved prescribed time–prescribed performance function (PTPPF) and error transformation method were utilized to propose a model-parameter-free control algorithm that guarantees user-defined constrained boundaries while ensuring all tracking errors converge within small domains before a preassigned settling time. The theoretical analysis was conducted by the initial value theorem, Lyapunov’s second method, and proof by contradiction, followed by comparative simulation results that verified the effectiveness of the proposed control scheme. Full article

For an underactuated unmanned surface vehicle (USV), time-varying external disturbances affect the accuracy of trajectory tracking. To ensure trajectory tracking accuracy, in this paper the reduced-order extended state observer (ESO) and the super-twisting second-order sliding mode controller are adopted. The ESO is designed to address the unknown time-varying sideslip angle in the guidance law. Additionally, the super-twisting technology contributes to a reduced chattering effect of the sliding mode. The Lyapunov method is used to analyze the stability of the tracking system and prove that the proposed controllers can ensure the convergence of the tracking errors in finite time. The simulation experiments of the proposed super-twisting sliding mode control (STSMC) and adaptive sliding mode control (ASMC) methods are compared. The results show that the STSMC method enables the USV to complete the task of the reference trajectory tracking. The chattering of the STSMC is also significantly reduced compared to that of the ASMC. Full article

Efficient trajectory generation in complex dynamic environments remains an open problem in the operation of an unmanned surface vehicle (USV). The perception of a USV is usually interfered by the swing of the hull and the ambient weather, making it challenging to plan optimal USV trajectories. In this paper, a cooperative trajectory planning algorithm for a coupled USV-UAV system is proposed to ensure that a USV can execute a safe and smooth path as it autonomously advances through multi-obstacle maps. Specifically, the unmanned aerial vehicle (UAV) plays the role of a flight sensor, providing real-time global map and obstacle information with a lightweight semantic segmentation network and 3D projection transformation. An initial obstacle avoidance trajectory is generated by a graph-based search method. Concerning the unique under-actuated kinematic characteristics of the USV, a numerical optimization method based on hull dynamic constraints is introduced to make the trajectory easier to be tracked for motion control. Finally, a motion control method based on NMPC with the lowest energy consumption constraint during execution is proposed. Experimental results verify the effectiveness of the whole system, and the generated trajectory is locally optimal for USV with considerable tracking accuracy. Full article

In this paper, we present a 3D formation control scheme for a group of torpedo-type underactuated autonomous underwater vehicles (AUVs). These multiple AUVs combined with an unmanned surface vessel (USV) construct a sort of star-topology acoustic communication network where the USV is at the center point. Due to this kind of topological feature, this paper applies a virtual school concept. This is a geometric graph where each node is taken as a virtual leader for each specific AUV and assigned its own reference trajectory. For each individual vehicle, its formation strategy is simple: just follow the trajectory of its corresponding virtual leader so as for multiple AUVs to compose the given formation. As for the formation subject, this paper mainly focuses on the formation tracking problem rather than the formation producing. For the torpedo-type vehicle considered in this paper, there are only three control inputs (surge force, pitch, and yaw moments) available for its underwater 3D motion and therefore this is a typical underactuated system. For the following vehicle’s trajectory, a sort of potential field method is used for obstacle avoidance, and a neural network-based adaptive scheme is applied to on-line approximate the vehicle’s unknown nonlinear dynamics, and the uncertainty terms including modeling errors, measurement noises, and external disturbances are handled by the properly designed robust scheme. The proposed formation method can guarantee the uniform ultimate boundedness (UUB) of the closed-loop system. Numerical studies are also carried out to verify the effectiveness of the proposed scheme. Full article

This paper studies the fast finite-time path following of underactuated unmanned surface vehicles (USV) with sideslip compensation, time-varying disturbances and input saturation. In the guidance module, the fast finite-time predictor-based line-of-sight (FFTPLOS) is proposed to overcome the large guidance angle and high-frequency oscillation and eliminate the sideslip angle with finite time. Then, the robust finite-time feedback control is applied to keep the vehicle following the desired path in the control module, where the reduced-order extended state observers (ROESO) are applied to deal with time-varying disturbances. Additionally, fast finite-time auxiliary dynamic systems with smoothly switching functions (FFTADS-SSF) achieve the saturation constraints on actuators with low consumption. The stability analysis proves that the guidance-control system of USVs is uniformly ultimately bounded stable within finite time. The effectiveness and performance of this proposed scheme are superior to the comparison schemes. Full article

Around the cooperative path-following control for the underactuated surface vessel (USV) and the unmanned aerial vehicle (UAV), a logic virtual ship-logic virtual aircraft (LVS-LVA) guidance principle is developed to generate the reference heading signals for the USV-UAV system by using the “virtual ship” and the “virtual aircraft”, which is critical to establish an effective correlation between the USV and the UAV. Taking the steerable variables (the main engine speed and the rudder angle of the USV, and the rotor angular velocities of the UAV) as the control input, a robust adaptive neural cooperative control algorithm was designed by employing the dynamic surface control (DSC), radial basic function neural networks (RBF-NNs) and the event-triggered technique. In the proposed algorithm, the reference roll angle and pitch angle for the UAV can be calculated from the position control loop by virtue of the nonlinear decouple technique. In addition, the system uncertainties were approximated through the RBF-NNs and the transmission burden from the controller to the actuators was reduced for merits of the event-triggered technique. Thus, the derived control law is superior in terms of the concise form, low transmission burden and robustness. Furthermore, the tracking errors of the USV-UAV cooperative control system can converge to a small compact set through adjusting the designed control parameters appropriately, and it can be also guaranteed that all the signals are the semi-global uniformly ultimately bounded (SGUUB). Finally, the effectiveness of the proposed algorithm has been verified via numerical simulations in the presence of the time-varying disturbances. Full article
