Search Results (48)

Metal–Organic Frameworks (MOFs) have emerged as advanced porous crystalline materials due to their highly ordered structures, ultra-high surface areas, fine-tunable pore sizes, and massive chemical diversity. These features, arising from the coordination between an almost unlimited number of metal ions/clusters and organic linkers, have resulted in significant interest in MOFs for applications in gas storage, catalysis, sensing, energy, and biomedicine. Beyond their stand-alone properties and applications, recent research has increasingly explored the integration of MOFs with other substrates, particularly electrodes, polymeric thin films, and glass surfaces, to create synergistic effects that enhance material performance and broaden application potential. Coating MOFs onto these substrates can yield significant benefits, including, but not limited to, improved sensitivity and selectivity in electrochemical sensors, enhanced mechanical and separation properties in membranes, and multifunctional coatings for optical and environmental applications. This review provides a comprehensive and up-to-date summary of recent advances (primarily from the past 3–5 years) in MOF coating techniques, including layer-by-layer assembly, in situ growth, and electrochemical deposition. This is followed by a discussion of the representative applications arising from MOF-substrate coating and an outline of key challenges and future directions in this rapidly evolving field. This article aims to serve as a focused reference point for researchers interested in both fundamental strategies and applied developments in MOF surface coatings. Full article

We studied the influence of annealing on the magnetic properties and microstructure of ultrathin (metallic nucleus diameter ≈ 5 μm, total diameter ≈ 19 μm) Heusler-type NiMnGa glass-coated microwires prepared using the Taylor–Ulitovsky method. The as-prepared NiMnGa microwires exhibit unexpectedly strong magnetic anisotropy, characterized by a coercivity exceeding 3 kOe at room temperature. Furthermore, their Curie temperature (T_c) lies above room temperature. Additionally, a spontaneous exchange bias of approximately 120 Oe is observed in the as-prepared sample at 100 K. Annealing the microwires leads to a decrease in coercivity, spontaneous exchange bias, and T_c values. Notably, the annealing process shifts the T_c of the samples closer to room temperature, making them more suitable for magnetic solid-state refrigeration applications. Moreover, the hysteresis observed in the temperature dependence of magnetization for the samples annealed for 1 h and 2 h, along with the magnetic softening observed at around 260 K, is attributed to a first-order phase transformation. The observed changes are discussed in the context of internal stress relaxation after annealing, the nanocrystalline structure of both the as-prepared and annealed samples, the recrystallization process, and the magnetic ordering of phases identified in the as-prepared sample and those appearing during recrystallization. The glass coating on microwires offers benefits like better flexibility and resistance to damage and corrosion. However, it is important to recognize that this coating can substantially alter the microwires’ magnetic characteristics. Consequently, precise control over the annealing process is vital to obtain the specific martensitic transformation needed. Full article

Titanium thin films with thicknesses of up to 105 nm were deposited on borosilicate glass implementing low-power continuous (25 W) and pulsed (85 W, with an ultra-low duty cycle) DC magnetron sputtering. The characteristics of the resulting films were studied via atomic force microscopy (AFM), X-ray photoelectron spectroscopy (XPS), VIS spectroscopy, and four-point-probe measurements. Both deposition modes yield films with low surface roughness, and AFM analysis showed no topographical features indicative of columnar-and-void structures. The films exhibited high optical reflectivity and stable transmittance and reflectance across the visible spectrum. The electric resistivity could be measured even at single nanometer thickness, emphasizing the metallic character of the films and approaching the bulk titanium value at higher film thicknesses. The low power regime of magnetron sputter deposition not only offers the possibility of studying the development of physical characteristics during the growth of ultra-thin films but also provides the advantage of extremely low heat development and no evident mechanical stress on the substrate during the coating process. These results outline a path for low-power DC sputtering as a reliable approach for studying the evolution of functional properties in ultra-thin films and for the gentle fabrication of coatings where thermal stress must be avoided, making the method compatible with temperature-sensitive applications. Full article

High stress and shape deviation during the glass forming process often led to low yield rates, posing a challenge in the production of high-precision smartwatch components. To address this issue, a numerical model was developed to simulate and analyze the forming behavior of 3D curved glass. The study focused on achieving a balance between energy consumption and key quality attributes, such as residual stress and shape accuracy. Results showed that forming pressure primarily affects shape deviation, while forming temperature plays a dominant role in energy usage and residual stress. Through orthogonal experiments, optimal parameters were identified: a forming temperature of 630 °C, pressure of 0.25 MPa, and cooling rate of 0.25 °C/s effectively minimize residual stress. Meanwhile, shape deviation is minimized at 630 °C, 0.30 MPa, and a cooling rate of 0.75 °C/s. Energy efficiency analysis indicated that low efficiency occurs at 610 °C with a 3 °C/s heating rate. Furthermore, NSGA-II multi-objective optimization validated the model’s accuracy, with prediction errors under 20%, offering valuable guidance for the precise fabrication of smartwatch glass. Full article

The recent fast advances in consumer electronics, especially in cell phones and displays, have led to the development of ultra-thin, hence flexible, glasses. Once available, such flexible glasses have proven to be of great interest and usefulness in other fields, too. Flexible photonics, for instance, has quickly taken advantage of this new material. At first sight, “flexible glass” appears to be an oxymoron. Glass is, by definition, fragile and highly breakable; its structure has puzzled scientists for decades, but it is evident that in most conditions it is a rigid material, so how can it bend? This possibility, however, has aroused the interest of artists and craftsmen since ancient times; thus, in Roman times the myth of flexible glass was born. Furthermore, the myth appeared again in the Middle Age, connected to a religious miracle. Today, however, flexible glass is no more a myth but a reality due to the fact that current technology permits us to produce micron-thick glass sheets, and any ultra-thin material can be bent. Flexibility is coming from the present capability to manufacture glass sheets at a tens of microns thickness coupled with the development of strengthening methods; it is also worth highlighting that, on the micrometric and nanometric scales, silicate glass presents plastic behavior. The most significant application area of flexible glass is consumer electronics, for the displays of smartphones and tablets, and for wearables, where flexibility and durability are crucial. Automotive and medical sectors are also gaining importance. A very relevant field, both for the market and the technological progress, is solar photovoltaics; mechanical flexibility and lightweight have allowed solar cells to evolve toward devices that possess the advantages of conformability, bendability, wearability, and moldability. The mature roll-to-roll manufacturing technology also allows for high-performance devices at a low cost. Here, a brief overview of the history of flexible glass and some examples of its application in solar photovoltaics are presented. Full article

We investigated patterns formed during the polymerization process of bifunctional monomers in a liquid crystal for both large polymer concentrations (polymer-dispersed liquid crystals, PDLC) and small concentrations (polymer-stabilized liquid crystals, PSLC). The resulting experimental patterns are reminiscent of Voronoi diagrams, so a reverse Voronoi algorithm was developed that provides the seed locations of cells, thus allowing a computational reproduction of the experimental patterns. Several metrics were developed to quantify the commonality between the faithful experimental patterns and the idealized and generated ones. This led to descriptions of the experimental patterns with accuracies better than 90% and showed that the curvature or concavity of the cell edges was below 2%. Possible reasons for the discrepancies between the original and generated Voronoi diagrams are discussed. The introduced algorithm and quantification of the patterns could be transferred to many other experimental problems, for example, melting of thin polymer films, ultra-thin metal films, or bio-membranes. The discrepancies between the experimental and ideal Voronoi diagrams are quantified, which may be useful in the quality control of privacy windows, reflective displays, or smart glass. Full article

To reveal the scribing mechanism of ultra-thin glass, single-factor scribing tests were carried out. The effects of the scribing wheel angle θ, scribing force F, and scribing speed v on the lateral cracks width w, scribing depth d, median cracks size l, and cross-section deflection angle α were analyzed to present the scribing quality. The results show that w increases with an increase in θ and F. Further, l and d increase with an increase in F. However, d shows an increasing trend with the increase in θ, and l shows a decreasing trend. In the range of 120–140°, α shows a trend of increasing first and then decreasing with an increase in F. The 120° scribing wheel angle, 20 N scribing force, and 100–400 mm/s scribing speed show the best scribing quality, which limits micro-cracks at the initiation stage without any damage or chipping. Under this condition, the breaking surface edges were free of debris and cracks. A smooth and trim Wallner ripple was obtained from the median cracks with a minimum deflection angle. Full article

The heating system is an essential component of the glass molding process. It is responsible for heating the glass to an appropriate temperature, allowing it to soften and be easily molded. However, the energy consumption of the heating system becomes particularly significant in large-scale production. This study utilized G-11 glass for the simulation analysis and developed a finite element model for the thermal conduction of a 3D ultra-thin glass molding system, as well as a thermal bending model for smartwatches. Using finite element software, the heat transfer between the mold and the glass was modeled, and the temperature distribution and thermal stress under various processing conditions were predicted. The findings of the simulation, when subjected to a numerical analysis, showed that heating rate techniques significantly affect energy consumption. This study devised a total of four heating strategies. Upon comparison, optimizing with heating strategy 4, which applies an initial heating rate of 35 mJ/(mm²·s) during the initial phase (0 to 60 s) and subsequently escalates to 45 mJ/(mm²·s) during the second phase (60 to 160 s), resulted in a reduction of 4.396% in the system’s thermal output and a notable decrease of 7.875% in the heating duration, respectively. Furthermore, a single-factor research method was employed to study the forming process parameters. By comparing the numerical simulation results, it was found that within the temperature range of 615–625 °C, a molding pressure of 25–35 MPa, a heating rate of 1.5–2.5 °C/s, a cooling rate of 0.5–1 °C/s, and a pulse pressure of 45–55 Hz, the influence on residual stress and shape deviation in the glass was minimal. The relative error range was within the 20% acceptable limit, according to the experimental validation, which offered crucial direction and ideas for process development. Full article

Aramid copolymers have garnered significant interest due to their potential applications in extreme environments such as the aerospace, defense, and automotive industries. Recent developments in aramid copolymers have moved beyond their traditional use in high-strength, high-temperature resistant fibers. There is now a demand for new polymers that can easily be processed into thin films for applications such as electrical insulation films and membranes, utilizing the inherent properties of aramid copolymers. In this work, we demonstrate two novel aramid copolymers that are capable of polymerizing in polar organic solvents with a high degree of polymerization, achieved by incorporating flexible bis(4-aminophenoxy) benzene moieties into the chain backbone. The synthesized MBAB-aramid and PBAB-aramid have enabled the fabrication of exceptionally thin, clear films, with an average molecular weight exceeding 150 kDa and a thickness ranging from 3 to 10 μm. The dynamic mechanical analysis (DMA) and thermogravimetric analysis (TGA) reveal that the thin films of MBAB-aramid and PBAB-aramid exhibited glass transition temperatures of 270.1 °C and 292.7 °C, respectively, and thermal decomposition temperatures of 449.6 °C and 465.5 °C, respectively. The mechanical tensile analysis of the 5 μm thick films confirmed that the tensile strengths, with elongation at break, are 107.1 MPa (50.7%) for MBAB-aramid and 113.5 MPa (58.4%) for PBAB-aramid, respectively. The thermal and mechanical properties consistently differ between the two polymers, which is attributed to variations in the linearity of the polymer structures and the resulting differences in the density of intermolecular hydrogen bonding and pi-pi interactions. The resulting high-strength, ultra-thin aramid materials offer numerous potential applications in thin films, membranes, and functional coatings across various industries. Full article

The imaging quality of the Mapping Imaging Spectrometer (IMS) is crucial for spectral identification and detection performance. In IMS, the image mapper significantly influences the imaging quality. Traditional image mappers utilize a single-point diamond machining process. This process leads to inevitable edge eating phenomena that further results in noticeable deficiencies in imaging, impacting spectral detection performance. Therefore, we propose a manufacturing process for the image mapper based on ultra-thin layered glass. This process involves precision polishing of ultra-thin glass with two-dimensional angles, systematically assembling it into an image mapper. The surface roughness after coating is generally superior to 10 nm, with a maximum angle deviation of less than 3′. This results in high mapping quality. Subsequently, a principle verification experimental system was established to conduct imaging tests on real targets. The reconstructed spectrum demonstrates excellent alignment with the results obtained from the Computed Tomography Imaging Spectrometer (CTIS). We thereby validate that this approach effectively resolves the issues associated with edge eating (caused by traditional single-point diamond machining), and leads to improved imaging quality. Also when compared to other techniques (like two-photon polymerization (2PP)), this process demonstrates notable advantages such as simplicity, efficiency, low processing costs, high fault tolerance, and stability, showcasing its potential for practical applications. Full article

This study develops a new type of decorative bridge panel by ultra-high-performance concrete (UHPC) based on the project of the Guangyangwan Bridge. First, the numerical analysis was carried out using MIDAS and ABAQUS to find the critical position of the bridge and decorative panels. The numerical results showed that the last concrete cantilever segment had the greatest vertical deflection, and the corresponding panel had the greatest stress response. Based on the numerical results, this study conducted a series of full-scale, self-balanced bending tests to examine the crack resistance of six UHPC panels and six glass fiber-reinforced concrete (GRC) panels with varying curved section thicknesses (from 25 to 40 mm). The experimental results indicate that, due to the high strength of the UHPC matrix and the wall effect of steel fiber distribution, the crack resistance of UHPC panels is significantly superior to that of GRC panels. UHPC panels possessed superior stiffness and ductility, while GRC panels showed brittle fracture when the curved section thickness reached 34 mm. The uniaxial tensile cracking strength of UHPC with a steel fiber volume fraction of 1.6% was 14.7% greater than that of GRC with a glass fiber volume fraction of 5%. At the same curved section thicknesses, UHPC decorative panels exhibit cracking loads and ultimate loads that are 64.3% to 123.0% and 29.2% to 115.0% greater than GRC panels, respectively. Hence, UHPC is more suitable to produce ultra-thin decorative panels for bridges that are subjected to severe environmental action and external forces. Full article

For the first time, organic light-emitting diodes (OLEDs) based on bis(8-hydroxyquinoline) zinc with a styryl group (ZnStq) dispersed in poly(N-vinylcarbazole) matrix (ZnStq_R:PVK, where R = H, Cl, OCH₃) were fabricated. The ZnStq_R:PVK films made via the spin-coating method were used as the active layer in these devices. The produced OLEDs showed strong electroluminescence with yellow emissions at 590, 587 and 578 nm for the ZnStq_H:PVK, ZnStq_Cl:PVK and ZnStq_OCH₃:PVK, respectively. For all the studied thin films, the main photoluminescence emission bands were observed between 565 and 571 nm. The OLED with the ZnStq_OCH₃:PVK layer with a narrow electroluminescence spectrum was found to have sufficient color purity to produce ultra-high-resolution displays with reduced power consumption (full width at half maximum of 59 nm, maximum brightness of 2244 cd/m² and maximum current efficiency of 1.24 cd/A, with a turn-on voltage of 6.94 V and a threshold voltage of 7.35 V). To characterize the photophysical properties of the active layer, the ZnStq_R:PVK layers samples were additionally deposited on glass and silicon substrates. We found that the obtained results predestine ZnStq_R:PVK layers for use in the lighting industry in the future. Full article

An ultra-wideband electromagnetic (EM) absorber is proposed. The proposed absorber consists of two thin metasurfaces, four dielectric layers, a glass fiber reinforced polymer (GFRP), and a carbon fiber reinforced polymer (CFRP) which works as a conductive reflector. The thin metasurfaces are accomplished with 1-bit pixelated patterns and optimized by a genetic algorithm. Composite materials of GFRP and CFRP are incorporated to improve the durability of the proposed absorber. From the full-wave simulation, more than 90% absorption rate bandwidth is computed from 2.2 to 18 GHz such that the fractional bandwidth is about 156% for the incidence angles from 0° to 30°. Absorptivity is measured using the Naval Research Laboratory (NRL) arch method in an EM anechoic environment. It was shown that the measured results correlated with the simulated results. In addition, the proposed absorber underwent high temperature and humidity tests under military environment test conditions in order to investigate its durability. Full article

The use of optical systems in medical imaging, computer electronics, large-scale industries, and space exploration is common. The performance of these devices is closely related to the compactness and fast responses of lenses that are used in these optical systems. Typical lenses suffer from several key issues, including limited efficiency, significant size, and the presence of diffraction-induced distortions that compromise their overall performance. Herein these limitations are addressed by designing and simulating an ultra-thin compact metalens also known as a flat lens using a dielectric metasurface. A 1D array of 31 nano-cylinders is placed on a glass substrate that is utilized for focusing the incident wave both on and off center in the focal plane using simulations. The nano-cylinders are comprised of amorphous silicon hydrogenated (a-Si:H), which has a varying radius in a 1D configuration. Amorphous silicon hydrogenated (a-Si:H) nano-cylinders are utilized for the manipulation of the phase of the incident beam working at a frequency of 474 THz. Three metalenses are introduced with focal lengths of 7.46 $\mathsf{\mu }$m, 10 $\mathsf{\mu }$m, and 12.99 $\mathsf{\mu }$m, each having a numerical aperture (NA) of 0.7, 0.6, and 0.5, respectively. The designed single-array metalens showed a transmission efficiency of 73%. The nano-cylinders obtained a full 0–360 phase control that is beneficial in focusing the beam at the center and beyond the center. Symmetric focusing is obtained in the case of off-center focusing on both sides of the optical axis. The design and simulations of the metalens are performed using finite difference time domain (FDTD) simulation tools. Full article

Ultra-thin sapphire wafer processing is receiving increasing attention in the LED substrate industry. In the cascade clamping method, the motion state of the wafer determines the uniformity of material removal, while the motion state of the wafer is related to its friction coefficient in the biplane processing system, but there is little relevant literature discussing the relationship between the motion state of wafer and friction coefficient. In this study, an analytical model of the motion state of sapphire wafers in the layer-stacked clamping process based on the frictional moment is established, the effect of each friction coefficient on its motion is discussed, the base plate of different materials and different roughness are experimentally studied, the layer-stacked clamping fixture is prepared in this way, and finally the failure form of the limiting tab is analyzed experimentally. The theoretical analysis shows that the sapphire wafer is mainly driven by the polishing plate, while the base plate is mainly driven by the holder, and the rotation speed of the two is not the same; the material of the base plate of the layer-stacked clamping fixture is stainless steel, the material of the limiter is glass fiber plate, and the main form of failure of the limiter is to be cut by the edge of the sapphire wafer and damage the material structure. Full article
