Search Results (18)

In order to explore the influence of pilot structure on the lean ignition characteristics in a certain type of internally staged combustor, the current study was conducted on the effects of the auxiliary fuel nozzle diameter, the rotating direction of the pilot swirler, and the swirl number on the lean ignition fuel–gas ratio limit, combining numerical simulation and experimental validation. The optimization potential of the mixing structure of this type of internally staged combustor was further explored. It indicated that the lean ignition fuel–gas ratio limit was significantly influenced by the diameter of the auxiliary fuel nozzles the swirl number of the pilot swirler and the combination of the same rotating direction for both pilot swirlers, while the mass flow rate of air was constant. Increasing the diameter of the auxiliary fuel path nozzles (0.4~0.6 mm) and having excessively higher or lower swirl numbers of the pilot module primary swirlers are not conducive to broadening the lean ignition boundary. Compared with the two-stage pilot swirler with the same rotation combination, the fuel–gas ignition performance of the two-stage pilot swirler with the opposite rotation combination is better. Under the typical working conditions (the air mass flow rate is 46.7 g/s and the ignition energy is 4 J), for a pilot swirler with a rotating direction opposite to the main swirler, the diameter of the auxiliary fuel nozzles is 0.2 mm, the swirl number of first-stage of pilot swirler is 1.4, and the lean ignition fuel–air ratio was reduced to 0.0121, which is 32.78% lower than the baseline scheme, which further broadens the lean ignition boundary of the centrally staged combustion chamber. Full article

Hybrid rockets have very interesting characteristics like simplicity, reliability, safety, thrust modulation, environmental friendliness and lower costs, which make them very attractive for several applications like sounding rockets, small launch vehicles, upper stages, hypersonic test-beds and planetary landers. In recent years, advancements have been made to increase hybrid motor performance, and two of the most promising solutions are vortex injection and paraffin-based fuels. Moreover, both technologies can be also used to tailor the fuel regression rate, in the first case varying the swirl intensity, and in the second case with the amount and type of additives. In this way, it is possible not only to design high-performing hybrid motors, but also to adjust their grain and chamber geometries to different mission requirements, particularly regarding thrust and burning time. In this paper, the knowledge about these two technical solutions and their coupling is extended. Three sets of experimental campaigns were performed in the frame of the Italian Space Agency-sponsored PHAEDRA program. The first one investigated a reference paraffin fuel with axial and standard vortex injection. The second campaign tested vortex injection with low values of swirl numbers down to 0.5 with a conventional plastic fuel, namely polyethylene. Finally, the last campaign tested another, lower regressing, paraffin-based fuel with the same low swirl numbers as the second campaign. Full article

The purpose of this study was to analyze the ultrastructure of the testes of sexually immature calves and reproductive bulls of the Polish Holstein-Friesian Black-and-White breed. Utilizing TEM, this study identified three distinct stages of seminiferous tubule development in calves, characterized by varying shapes, distributions, and arrangements of individual cells. In immature animals, early developing spermatocytes, prespermatogonia, and pre-Sertoli cells were observed within the seminiferous tubules. In sexually mature bulls, all cells of the spermatogenic series were observed, situated on a thin, multilayered basal lamina, which forms characteristic undulations. An abundant smooth endoplasmic reticulum was observed in the cytoplasm of spermatogonia in both groups of animals, forming characteristic membranous swirls. In adult bulls, spermatogonia maintain contact with each other through numerous cytoplasmic bridges and cell connections, forming small spaces with visible microvilli between them. The ultrastructural analysis facilitated the identification of morphological changes occurring during the maturation of pre-Sertoli cells, transitioning from a large euchromatic nucleus to a nucleus in which the formation of characteristic vesicles and tubules could be observed. It should also be emphasized that two types of Sertoli cells, namely dark and light electron-dense cells, can be found in cattle. These cells differ from each other, indicating that they may perform different functions. The widespread recognition of the presence of two types of Sertoli cells in cattle will undoubtedly contribute to a better understanding of the processes occurring within the testes and provide a basis for further research in this area. Full article

Turbulence intensity impacts the performance of turbine stages and it is an important inlet boundary condition for CFD computations; the knowledge of its value at the turbine inlet is then of paramount importance. In combustor–turbine interaction experimental studies, combustor simulators replace real combustors and allow for the introduction of flow perturbation at the turbine inlet. Therefore, the turbulence intensity of a combustor simulator used in a wide experimental campaign at Politecnico di Milano is characterized using a hot-wire probe in a blow-down wind tunnel, and the results are compared to URANS CFD computations. This combustor simulator can generate a combination of a swirl profile with a steady/unsteady temperature disturbance. In the cold unsteady disturbance case, hot-wire measurements are phase-averaged at the frequency of the injected perturbation. The combustor simulator turbulence intensity is measured at two different axial positions to understand its evolution. Full article

Intelligent toilets can effectively remove odors and harmful substances from exhaust gases and wastewater, maintaining a fresh and clean indoor atmosphere, which is beneficial to the indoor environment and human health. Currently, research on intelligent toilets conducted by sanitary ware manufacturers is still in its early stages. Many of the intelligent toilets available on the market exhibit issues such as an excessive oscillation amplitude of the cleaning spray bar, premature breakdown of the water column, and inadequate air intake. The present study involves the analysis and redesign of a cleaning spray bar model for intelligent toilets. Additionally, several optimization schemes concerning the flow channel of the cleaning spray bar are proposed in order to enhance the performance of the liquid–air ejector. The computational fluid dynamics (CFD) technique is utilized to analyze the water flow characteristics within the cleaning spray bar of the intelligent toilet and to compare and evaluate the proposed schemes. The calculation results indicate that, for the same inlet flow rate, the optimal structure the block with a length of L = 1.5 mm and the block positioned (4). The swirl numbers of these two optimized models are 14.8% and 8.3% of the protype, respectively, while their air intake is 133% and 131% of the protype, respectively. The optimized solutions exhibited significant performance improvements when compared to the prototype. The computational results offer valuable insights for optimizing the flow characteristics of the enhanced product. Full article

In modern civil aeroengines, the hot streak and swirl at the exit of the combustor have a significant impact on the aerothermal performance of the high-pressure turbine (HPT). Due to the different design purposes of the combustor and the turbine, hot streak (HS) and swirl (SW) have different spatial distributions at the turbine inlet. This paper conducts a transient simulation of the GE E3 first-stage HPT, considering the swirl and hot streak facing the middle of the passage and the leading edge of the nozzle guide vane, respectively, and also explores the impact of positive and negative swirl. The results show that different clocking positions and swirl directions will change the incident angle and streamline distribution of the vane, thereby affecting the migration of the hot streak, the temperature and the Nusselt number distribution on the stator surface. In positive cases, the hot streak gathers in the upper part of the passage, and in negative cases, it is in the lower part. In middle cases, high-temperature areas appear in both vanes, and the distributions are opposite. Affected by the swirl, when facing the passage center, the pressure side stagnation lines of the two vanes are also different, so the Nusselt number distribution is opposite. When facing the leading edge, only one vane appears. Due to the insensitive interference of the rotor–stator, the transient migration of the hot streak in the rotor is mainly affected by the inherent secondary flow and the temperature at the inlet of the rotor (especially the conditions facing the leading edge), while the upstream residual swirl is less affected. Unlike the middle case, in leading edge cases, the hot streak is separated and needs to be re-mixed before entering the blade passage, so the temperature change in the blade cascade is relatively gentle. Based on this, the Nusselt number distribution on the surface of the blade is similar. In order to obtain the most favorable operating conditions for the engine, the turbine efficiency is used to compare the aerothermal performance under different conditions. Ultimately, it was found that the turbine with the hot streak and positive swirl directly facing the leading edge was the most efficient. Full article

Modern gas turbines find extensive applications in aero engines, power generation, marine, and various other industries. Most numerical studies concentrate on turbine aero-thermal performance under different external conditions with vane or coupon; there are a few published results on combustor-turbine interactions. This study reveals the cooling performance of the first stage with or without coatings to provide a reference for high-performance combustors and turbine-integrated design. The results of the study show that (1) The velocity and temperature distribution inside the combustion chamber are obviously affected by the swirling flow. A central recirculation zone is formed near the central axis, and two external recirculation zones are formed between the inlet section of the combustion chamber and the fluid reattachment point. (2) Inside the combustion chamber, the flame temperature in the central recirculation zone is relatively high, and the range of the high-temperature zone expands with the increase of axial distance. Increasing the swirl number decreases the peak temperature level in the combustion chamber. (3) Under the influence of swirl number, the greater the swirl number, the greater the cooling effectiveness of most areas on the vane surface. (4) In regions where there is a decrease in local heat flux, positive values are evident. This suggests that the application of a coating in these areas results in a reduction of heat transfer from the vane to the mainstream. (5) When comparing the coated vane to the uncoated vane, the cooling effectiveness across the entire surface is notably enhanced, with a particularly significant improvement observed on the vane’s suction side. With the increase of C_ax, the difference in cooling effectiveness increment under different swirl numbers also increases. Full article

Prefilming air-blast atomizers are widely used in modern gas turbine combustors. Due to insufficient awareness of the coupling mechanism of multi-stage swirling flow in gas turbines, there is a lack of effective methods for flow field optimization in combustor. In this study, the effect of some critical parameters on the flow field of a prefilming air-blast atomizer was analyzed with CFD. The parameters include the angle and number of the first swirler blades, the angle of the second swirler blades and the angle of sleeve. Furthermore, the coupling mechanism of two-stage swirling airflows of prefilming air-blast atomizer was discussed. Moreover, the influence of the interaction between two-stage counter swirling airflows on the characteristics of flow field was explained. The results show that with the increase in SN_i, the axial length of the primary recirculation zone decreased, while the radial width increased. The starting position of primary recirculation zone (PRZ) moves forward with the increase in SN_o. Reducing the sleeve angle β helps to form the primary recirculation zone. The results indicate that it is the transition of tangential velocity of airflow to radial velocity that promotes the formation of the PRZ. These results provide theoretical support for optimization of the flow field in swirl combustor. Full article

The work aims to numerically evaluate different injection configurations for the analysis of a two-phase flow behavior and evolution through a staggered Y-junction pipeline. To minimize agglomeration between inlets, the injection zones have a separation distance, avoiding areas with eddies or swirls owing to strong turbulence. Six input scenarios were examined accordingly with injection system experimental data. Results show significant variations because the main fluid develops a swirl over the pipe center. This is generated immediately after the phases’ supply zone due to the oil-phase because it presents a partial pipe flooding, even in the water injection zone. Moreover, the supply configuration has significant relevance to the main flow development. Accordingly, many flow patterns can be achieved depending on the phases’ confluence coming from the supply system. The interface velocities confirm the transition process and flow pattern development, which are driven by the phases’ velocities describing the early stages of three flow patterns formed during the fluids’ confluence. Finally, a substantial extent of the conjunction process points out that caution must be exercised during the injection supply system selection for this type of junction pipeline to achieve a better, and smooth blend, with either narrow, medium, or wide emulsions. Full article

In this study, we developed the design process and optimization of structural parameters of a new low-NO_x burner based on low-NO_x combustion technology and the flame stabilization principle. Firstly, on the basis of the two-stage swirl burner, we applied the fuel-graded combustion technology and introduced the central nozzle structure to explore the influence law of graded combustion on NO_x emissions. Secondly, on the previously optimized structure, the matching law between the first- and second-stage cyclone blades is analyzed to obtain the optimum structural design solution for heat exchange efficiency and flame front length. Finally, a new conical blunt structure is introduced in conjunction with the flame stabilization principle, and we discuss the effects of different half cone angles on the flame stabilization, flame front length, and heat exchange efficiency of the burner. The research in this paper provides a reliable direction for the design optimization of low-NO_x burners. Full article

This study investigates using tailor-developed combustion and air-handling system concepts to achieve high-efficiency, clean gasoline compression ignition (GCI) combustion, aimed at addressing a future heavy-duty ultralow NOx standard of 0.027 g/kWh at the vehicle tailpipe and the tightening CO₂ limits around the world by combining GCI with a cost-effective engine aftertreatment system. The development activities were conducted based on a 15 L heavy-duty diesel engine. By taking an analysis-led design approach, a first-generation (Gen1) GCI engine concept was developed and tested, encompassing tailor-designed piston bowl geometry, fuel spray pattern, and swirl motion paired with a customized, fixed-geometry, two-stage turbocharging system and a high-pressure EGR loop with two-stage cooling. Across four key steady-state operating points, the Gen1 GCI concept demonstrated 85–95% lower smoke and 2–3% better diesel-equivalent gross indicated fuel consumption compared to the diesel baseline at 1 g/kWh engine-out NOx. By upgrading to a Gen2 air-handling concept that was composed of a prototype, single-stage, variable-geometry turbocharger and a less restrictive EGR loop, 1D system-level analysis predicted that the pumping mean effective pressure was reduced by 43–54% and the diesel-equivalent brake-specific fuel consumption was improved by 2–4%, thereby demonstrating the performance enhancement potential of refining the air-handling system. Full article

Downdraft gasification is a promising process of energy conversion of wood biomass. There are such fuel conversion conditions that differ favorably from conventional conditions. In such conditions, there is no pyrolysis zone in the fuel bed, which precedes the oxidation zone. Fuel is supplied into the oxidizing zone without charring, where it reacts with the intensive cold air flow from tuyeres. The study aims to replicate the conversion of particles in a gasifier close to tuyeres. For this purpose, the individual particles are burned in the muffle furnace space and the quartz channel replicating presence of other bed particles at a first approximation. In the experiment, the furnace temperature was varied, as well as the velocity of air supplied to the particle. Two-stage and single-stage mechanisms of particle combustion were identified. A two-stage process is observed in the range of tuyere velocities below 20 m s⁻¹. The two-stage mechanism is characterized by a stage of devolatilization and volatiles combustion, followed by a stage of char residue combustion. The stages are predominantly separate from each other, and their degree of overlapping is low, amounting to 24%. At the tuyere velocities above 125 m s⁻¹ combustion of particles is realized primarily as a single-stage process. The intensive air flow reaches the fuel particle surface and initiates combustion of the surface char layer. In this case, the stages of devolatilization and char residue combustion run concurrently for the most part. In the single-stage mechanism, the degree of stage overlapping is significantly higher and amounts to 60–95%. For the two-stage combustion mechanism, the effect of cyclic movement of the flame across the particle surface is evident. The number of cycles can reach eight. This effect is due to the change of conversion stages. At air velocity above 95 m s⁻¹, fragmentation of fuel particles commences. A layer of char formed at an initial stage of burning heats up in the intensive air flow and is separated from the particle surface. The heated walls of the quartz channel contribute to the intensification of particle combustion. This effect is probably due to the swirling of the flame between the wall and the particle surface. Full article

This article is devoted to detailed experimental studies of the flow behind the impeller of an air model of a propeller-type microhydroturbine in a wide range of operating parameters. The measurements of two component distributions of averaged velocities and pulsations for conditions from part load to strong overload are conducted. It is shown that the flow at the impeller outlet becomes swirled when the hydraulic turbine operating mode shifts from the optimum one. The character of the behavior of the integral swirl number, which determines the state of the swirled flow, is revealed. Information about the flow peculiarities can be used when adjusting the hydraulic unit mode to optimal conditions and developing recommendations to expand the hydraulic turbine operation control range with preservation of high efficiency. This stage will significantly save time at the stage of equipment design for specific field conditions of water resource. Full article

Background: Chronic kidney disease (CKD) is a common medical problem in patients worldwide, with an increasing prevalence of patients with end-stage kidney disease (ESKD) requiring renal replacement therapy (RRT). In patients requiring RRT for more than two weeks or those who develop ESKD, tunneled hemodialysis catheter (HDC) insertion is preferred, based on a lower risk for infectious complications. While the efficacy of ultrasound (US)-guided tip positioning in antegrade-tunneled HDCs has previously been shown, its application for the insertion of retrograde-tunneled HDCs has not been described yet. This is especially important, since the retrograde-tunneled technique has several advantages over the antegrade-tunneled HDC insertion technique. Therefore, we here report our first experience of applying the rapid atrial swirl sign (RASS) for US-guided tip positioning of retrograde-tunneled HDCs. Methods: We performed a cross-sectional study to assess the feasibility of applying the RASS for US-guided tip positioning of retrograde-tunneled HDCs. We performed a total number of 24 retrograde-tunneled HDC insertions in 23 patients (requiring placement of a HDC for the temporary or permanent treatment of ESKD) admitted to our Department of Nephrology and Rheumatology at the University Medical Center Göttingen, Germany. Results: The overall success rate of applying the RASS for US-guided tip positioning of retrograde-tunneled HDCs was 24/24 (100%), with proper tip position in the right atrium in 18/23 (78.3%), or cavoatrial junction in 5/23 (21.7%) when RASS was positive and improper position when RASS was negative in 1/1 (100%), confirmed by portable anterior-posterior chest radiography, with only minor post-procedural bleeding in 2/24 (8.3%). In addition, this insertion technique allows optimal HDC flow, without any observed malfunction. Conclusion: This is the first study to investigate the efficacy of the RASS for US-guided tip positioning of retrograde-tunneled HDCs in patients with ESKD. Application of the RASS for US-guided tip positioning is an accurate and safe procedure for the proper placement of retrograde-tunneled HDCs. Full article

Fluidic oscillators have proven their capabilities and advantages in terms of the generation of oscillating jets without moving parts for many years, mainly in experimental studies. In this paper, the design, development, and integration of fluidic atomizers into the liquid-fuel system of the dual-fuel low NO_X Advanced Can Combustion (ACC) system of the MAN Gas Turbines (MGT) are presented. The two-stage system comprises a pressure-swirl nozzle as a pilot stage and an assembly of four main premixed nozzles, based on fluidic technology. The design and the features of the pilot nozzle are briefly presented, whereas the focus lies on the functionality and layout of the fluidic nozzles. The complete integration, validation, and verification of this innovative liquid-fuel injection unit are presented. The final system features fast fuel-switchovers, low complexity, high reliability, and dry low emissions in liquid-fuel operation. Full article
