Tungsten heavy alloys (WHAs) are two-phase composites known for their exceptional density, strength, hardness, and ductility, making them ideal for radiation shielding, kinetic energy penetrators, and aerospace components. Due to their high melting point, WHAs are primarily processed via powder metallurgy, with liquid-phase sintering (LPS). Spark plasma sintering (SPS) and microwave sintering are emerging as advanced consolidation techniques. Recent research has focused on improving WHA performance through microstructural manipulation, alloying with elements like Fe, Co, Mo, and Re; rare earth oxides like Y₂O₃, La₂O₃, and Ce₂O₃; and employing high-entropy alloys (HEAs) as matrix phase. Additionally, additive manufacturing (AM) techniques are increasingly being used to fabricate complex WHA components. Despite their advantages, WHAs still exhibit limitations in penetration performance, primarily due to their tendency to form mushroom-like heads upon impact rather than self-sharpening. Ongoing research seeks to enhance shear localization, refine grain structure, and optimize processing methods to improve the mechanical properties and impact resistance of WHAs. Furthermore, modeling and simulation approaches are being explored to understand the mechanical behavior of WHAs. This review comprehensively overviews the above aspects and presents recent advances in WHA processing. Full article

Welded cable composed of nickel–chromium (Ni-Cr) alloy and copper is a crucial component in the resistance heating technology used for heavy oil production. Tungsten inert gas (TIG) welding was employed to join the copper and Ni-Cr alloy using copper filler wire, and the stability of the welded joint was analyzed under high-temperature service conditions. We examined the changes in the microstructure and properties of the welded joint after postweld heat treatment (PWHT) at 600 °C for 3, 6, and 12 days. The results showed that the welded joint was appropriately formed, with fractures occurring in the copper substrate. The average tensile strength of the welded joint was 240 MPa. The copper and nickel dissolved into each other, forming a Cu_0.81Ni_0.19 strengthening phase. A columnar crystal diffusion layer formed at the interface between the Ni-Cr alloy and the fusion zone after welding. Grain boundary migration promoted the continuous growth in the columnar crystals as the PWHT duration increased, eliminating the microdefects and inhomogeneities caused by welding. The microhardness progressively decreased from the Ni-Cr alloy side to the copper side. However, the nanoindentation results at the Ni-Cr fusion line initially decreased and then increased with increasing PWHT duration, which contrasted the overall hardness trend observed across the joint after PWHT. Full article

Experimental and finite element studies of the rotary friction welding (RFW) process of tungsten heavy alloy (THA) with aluminium alloy 5XXX series are presented. A 2.5D torsion simulation model including the circumferential effects was developed in this study. The temperature distributions, effective stress, flash dimensions and axial shortening were calculated on un-rotated friction welding aluminium parts. The peak temperatures were measured both in the axis and at the half-radius of the specimen. The maximum interface temperature of 581 °C for the friction weld was below the melting temperature of the aluminium alloy. The experimental and numerical results of the temperature and final weld geometries show good agreement between them. The results indicate very small deviations of 4.45%, 2.96%, and 2.34% on the flash width, flash height and axial shortening of friction welds. Full article

The present work was aimed at the investigation of the effect of high-energy ball milling (HEBM) time on the sintering kinetics, structure, and properties of the heavy tungsten alloy (HTA) W-7%Ni-3%Fe. The HTA samples were obtained from nanopowders (20–80 nm) using conventional liquid-phase sintering (LPS) in hydrogen and using spark plasma sintering (SPS) in vacuum. The HTA density was shown to depend non-monotonously on the HEBM time that originates from the formation of nonequilibrium solid solutions in the W-Ni-Fe systems during HEBM. The SPS kinetics of the HTA nanopowders was shown to have a two-stage character, the intensity of which depends on the Coble diffusion creep rate and on the intensity of diffusion of the tungsten atoms in the crystal lattice of the γ-phase. The kinetics of sintering of the initial submicron powders has a single-stage character originating from the intensity of the grain boundary diffusion in the γ-phase. The dependencies of the hardness and of the yield strength on the grain sizes were found to obey the Hall–Petch relation. The hardness, strength, and dynamic strength in the compression tests of the fine-grained tungsten alloys obtained using SPS and LPS were studied. Full article

Tungsten heavy alloys (WHAs) are an extremely hard-to-machine material extensively used in demanding applications such as missile liners, aerospace, and optical molds. However, the machining of WHAs remains a challenging task as a result of their high density and elastic stiffness which lead to the deterioration of the machined surface roughness. This paper proposes a brand-new multi-objective dung beetle algorithm. It does not take the cutting parameters (i.e., cutting speed, feed rate, and depth of cut) as the optimization objects but directly optimizes cutting forces and vibration signals monitored using a multi-sensor (i.e., dynamometer and accelerometer). The cutting parameters in the WHA turning process are analyzed through the use of the response surface method (RSM) and the improved dung beetle optimization algorithm. Experimental verification shows that the algorithm has better convergence speed and optimization ability compared with similar algorithms. The optimized forces and vibration are reduced by 9.7% and 46.47%, respectively, and the surface roughness R_a of the machined surface is reduced by 18.2%. The proposed modeling and optimization algorithms are anticipated to be powerful to provide the basis for the parameter optimization in the cutting of WHAs. Full article

Ultrasonic elliptical vibration cutting has a wide range of applications in the field of precision cutting of difficult-to-machine metal materials. However, due to its intermittent cutting characteristics and the weak rigidity of the horn, cutting chatter is prone to occur during its cutting process, which has an important impact on cutting surface quality and tool wear. In this paper, the rigid/viscoplastic rod model is used to simulate the horn in the ultrasonic elliptical vibration cutting device, and the influence factors of the amplitude-frequency response of the horn are analyzed. The influence of cutting speed and cutting depth on cutting chatter was studied by ultrasonic elliptical vibration cutting experiment of tungsten heavy alloy, and the influence of cutting chatter on cutting surface morphology and diamond tool wear was studied. The research shows that cutting speed will change the excitation frequency of the horn, and reasonable cutting speed can inhibit the occurrence of cutting chatter and avoid resonance of the horn. The cutting depth will affect the excitation amplitude and amplify the vibration amplitude when chatter or resonance occurs. The experimental results show that in ultrasonic elliptical vibration cutting of heavy tungsten alloy, chatter suppression can significantly improve the quality of the cutting surface and reduce the wear of diamond tools. Full article

It is of extreme importance to develop a reliable numerical prediction technique to simulate the ballistic response of ceramic armor subjected to high-velocity impact (HVI) to economize the test cost and shorten the design period. In the present manuscript, a series of experiments on tungsten heavy alloy (WHA) fragment’s penetration into 99.5% alumina (AD995) armors are systematically simulated by employing the FE-converting-SPH technique. The numerical results are compared with the experimental counterparts to find that the FE-converting-SPH method is fairly efficient in predicting the depth of penetration, the residual velocity, length and mass of fragment, and reproducing the crack forms of ceramic. The applicability and accuracy of the numerical model in terms of the algorithm, material model parameters and contact definitions are validated. Then, the relevant parameters of the calibrated numerical model are incorporated to explore the influence of cover-layer thickness on the armor performance. A few mechanisms regarding the cover plate have been identified to act on the armor performance, such as the alteration of fracture cone half-angle, proportion of energy absorbed by ceramic, mushrooming deformation of fragment, etc. The result of multi-mechanism superposition is that the best ballistic performance is endued with 1 mm cover-layer armor, which demonstrates a 24.6% improvement over the bi-layer armor with 4.96 g/cm² area density, only at the cost of 15.7% increase in areal density, when back-plate thickness is held as 2 mm; for a constant area density of 4.96 g/cm², a 1 mm cover-layer is also expected to be the best choice, with 10.7% improvement in armor performance. Full article

A fitting method capable of describing the fatigue crack growth rate (FCGR) data in all stages of crack propagation by a simple Forman-style analytical formula was developed. To demonstrate its robustness, this method was used to quantify the fracture behavior of RF-plasma-sprayed W, Mo, W-Mo composite, and four selected Ni-based tungsten heavy alloys (WHA). The fitted FCGR parameters categorized the studied materials into two distinct sets. W, Mo, and W-Mo composite deposits made from inherently brittle refractory metals that contained a range of defects inherent to plasma spray process represented the first class. This class was characterized by low fracture toughness and a relatively wide range of fatigue crack growth thresholds. The second class of materials was represented by WHA. Here, the deposit defects were suppressed by liquid state diffusion that formed a typical WHA structure consisting of a Ni-rich matrix and large spherical W reinforcement particles. The WHA generally showed higher fatigue crack growth thresholds, but differed in fracture toughness values based on the W particle concentrations. The obtained fracture mechanical data represent a reference dataset of plasma-sprayed refractory materials, and their classification into groups clearly demonstrates the capabilities of the developed method to capture a wide range of different types of FCGR behavior. Full article

Tungsten heavy alloys (WHAs) are candidates for use in fusion reactor divertors. Here, we characterize liquid-phase sintered WHAs with 90, 92.5, 95, and 97 (wt.%) tungsten (W), with a balance of a 0.7Ni–0.3Fe ductile phase. These WHAs show remarkable room temperature (RT) fracture toughness at the maximum load, K_Jm, ranging from ≈ 38 to 107 MPa√m, compared to a monolithic W toughness of ≈ 8 MPa√m. In most cases, the fracture of WHAs occurs through stable crack tearing. However, the 97W WHA has the lowest toughness and fracture elastically in all but the smallest specimens. As lower Ni contents are desirable for fusion application, we explore the potential for improving the ductility and K_Jm of WHAs using vacuum annealing at 1300 °C for 24 h. The microstructural observations reveal negligible changes in the WHA microstructure and constituent compositions. While annealing reduces the Vickers microhardness (HV), it does not significantly change the RT yield (σ_y) and ultimate (σ_u) strengths but results in beneficial increases in total elongation in the 95 and 97W WHAs by a factor of 2. RT tests on the precracked three-point-bend (3PB) bars show that annealing increases the K_Jm of these WHAs, and in the case of the 97W WHA, the increase is from 42 to 92%, depending on the size of the specimen. Toughening is due to enhanced crack tip process zone microcracking and dilatation. Full article

This study shows the results of Ni replacement with Co in a W-Ni-Co-type tungsten heavy alloy (WHA) in terms of the structure and mechanical properties. Five alloys containing 92 wt. % of tungsten plus Ni and Co changing in the proportions (Co:Ni) of 1:9, 2:8, 3:7, 4:6, and 5:5 were prepared using liquid phase sintering (LPS). The specimens were studied directly after sintering and after solution heat treatment. The tensile strength, yield strength, and elongation were evaluated. The results of tensile tests were supplemented with microhardness measurements of tungsten grains and matrix. Light microscopy was used for the microstructure, and a scanning electron microscope (SEM) equipped with an EDS attachment was applied for the assessment of the fracture mode and chemical microanalysis. It was concluded that the replacement of Ni with Co led to a tensile property increase that was accompanied by a gradual decrease in elongation that started to be critical for a Co:Ni ratio higher than 4:6. Full article

The development of nanomaterials and nanotechnology enables the production of nanosized metallic alloys with advanced characteristics from their oxides via a thermal reduction technique. The aim of the present work was to produce metallic iron, nickel, and tungsten through the gaseous reduction of nanosized metal oxide powders as a preliminary step towards the fabrication of nanosized heavy tungsten alloys with unique properties. Nanosized NiO, Fe₂O₃, and WO₃ were isothermally and non-isothermally reduced with H₂, and the oxygen weight loss was continuously recorded as a function of time. The Thermogravimetric TG-DTA technique was applied in the non-isothermal reduction up to 1000 °C. The reduction extents were calculated from the TG curve, whereas the accompanying heat of the reaction was measured from the DTA curve. The results revealed that NiO was reduced at <420 °C, Fe₂O₃ was reduced at <600 °C, and WO₃ was reduced at >950 °C. In the isothermal process, metal oxides were reduced with H₂ at 700–1000 °C; a micro-force balance was used and the O₂ weight loss was continuously recorded. At a given temperature, the rate of reduction increased in the order NiO > Fe₂O₃ > WO₃. The nano-oxide powders and the reduced products were physically and chemically characterized. The activation energy (Ea) values were computed from the isothermal reduction in the initial and later stages to elucidate the corresponding reduction mechanism. The Ea values indicated that the reduction of metal oxides was controlled by the gas diffusion mechanism at both the initial and later stages of reduction. The results of the present study determined the optimal operation parameters at which the thermal gaseous reduction technique could be applied for preparing metallic alloys from nanosized metal oxides. Full article

W-NiTi tungsten heavy alloys were prepared by an infiltration process using submicron W powders, and the effect of sintering temperatures on grain-coarsening behaviors and the mechanical properties of W-NiTi tungsten heavy alloys were investigated. The microstructures and mechanical properties were investigated using scanning electron microscopy, X-ray diffraction and compression tests. The results showed that tungsten particles were uniformly distributed in the NiTi binder. The W-NiTi tungsten heavy alloys consisted of B19′-NiTi and body-centered cubic W phases. The average tungsten particle sizes of W-NiTi tungsten heavy alloys sintered at 1400 °C, 1480 °C and 1560 °C were 2.62 μm, 4.04 μm and 5.20 μm, respectively. The average tungsten particle size increased with sintering temperatures, while the densities decreased at higher temperatures. The cavities retained in the W-NiTi tungsten heavy alloy sintered at 1560 °C, which degraded the mechanical properties. The calculated grain growth activation energy of W particles in the NiTi binder was 330 kJ/mol, which was higher than those in conventional W-NiFe and W-NiCo tungsten heavy alloys. The higher activation energy means more difficult diffusion process of W atoms in NiTi binders during sintering. Therefore, finer-grained heavy tungsten alloys were more easily obtained by using NiTi binders. Yield strength of W-NiTi tungsten heavy alloys decreased with increasing sintering temperatures due to coarsened tungsten particles. Full article

Tungsten-heavy alloys (WHA) are a pseudo-alloy in which tungsten is the primary phase and remains filled with additives such as Ni–Fe and Ni–Cu. These alloys are widely used to make their applications’ structural, electrical, and electronic components. According to this study, in addition to processing factors, the prime factors affecting the performance of WHAs are microstructural features such as tungsten and matrix composition, powders shapes and sizes, and distributions of tungsten particles in the matrix, as well as interface-bonding strength between the tungsten particle and matrix. This study summarises current developments in WHA processing, microstructure, and mechanical characteristics. For the manufacture of WHAs, various processing methods are discussed, including traditional powder metallurgy (PM), microwave sintering (MW), spark plasma sintering (SPS), and additive manufacturing (AM). SPS process depicts better results when compared with conventional sintering. This review will also hint at the effects of some additives in tungsten and their advantages. Full article

This work investigated the lubricating and anti-wear properties of several sulfur additives for a nickel-based superalloy–tungsten carbide friction pair. Compared with PAO40 without any active chemical compounds, the three kinds of sulfur additives could decrease the friction coefficient from 0.2 to 0.1 and the wear volume by 90%. Sulfurized fatty acid ester had the best performance under high temperature and heavy load with COF below 0.1 and the smallest wear volume. Furthermore, the lubricating mechanism was investigated by XPS. The physical adsorptive film and the tribochemical film together enhanced the friction-reducing and anti-wear performances of the lubricants. This effective lubricant for Inconel 718 can be applied to the machining of nickel-based alloy. Full article

For the first time, a powder of W-5Ni-2Fe composition with spherical particles from 15 to 50 microns and a tungsten grain size from 0.5 to 3 microns was obtained using a new technological approach, developed by the authors, based on plasma spheroidization of powder granules made from nanoparticles synthesized in a plasma chemical process. The possibility of using the obtained spheroidized powder W-5Ni-2Fe in the process of selective laser melting (SLM) has been proved. The microstructure, physical, and mechanical characteristics of experimental samples made using SLM technology from the produced W-5Ni-2Fe powder have been studied. The results of the performed studies have shown that the microstructure of experimental samples is extremely dependent on the parameters of the SLM process. The precise choice of the SLM process mode made it possible to obtain a homogeneous structure of experimental samples of tungsten heavy alloy (WHA), with a tungsten grain size of about 1–2 microns, which is much smaller than the tungsten grain size in traditional heavy alloys. This creates prerequisites for increasing the strength characteristics of parts of complex shapes made by the SLM method from such powders. The maximum values of density and hardness of experimental samples obtained in the conducted studies are not worse than the values of samples obtained using traditional liquid-phase sintering technology. It is determined that the main problem of SLM powder W-5Ni-2Fe during investigation is the heterogeneity of the microstructure of massive samples and the formation of micropores and microcracks. Full article
