To study the mechanical properties of asymmetric K-shaped square tubular joints with built-in stiffening rib lap joints, axial tensile tests were carried out on one K-shaped joint without built-in stiffening ribs and four K-shaped joints with built-in stiffening ribs using an electro-hydraulic servo structural testing system. The effects of the addition of stiffening ribs and the welding method of the stiffening ribs on the mechanical properties were studied comparatively. The failure mode of the K-shaped joint was obtained, and the strain distribution and peak displacement reaction force in the nodal region were analyzed. A finite element analysis of the K-shaped joint was carried out, and the finite element results were compared with the experimental results. The results showed that the addition of transverse reinforcement ribs and more complete welds shared the squeezing effect of the brace on the chord. Arranging more reinforcing ribs in the fittings makes the chord more uniformly stressed and absorbs more energy while increasing the flexural load capacity of the fittings’ side plates. The presence of a weld gives a short-lived temperature increase in the area around the crack, and the buckling of the structure causes the surface temperature in the buckling area to continue to increase for some time. The temperature change successfully localized where the structure was deforming and creating cracks. The addition of the reinforcing ribs resulted in a change in the deformation pattern of the model, and the difference occurred because the flexural capacity of the brace with the added reinforcing ribs was greater than that of the side plate buckling. Full article

The limited build space of additive manufacturing (AM) machines constrains the maximum size of AM components, while manufacturing costs rise with geometric complexity. To enhance value and overcome size limitations, it can be more efficient to join non-AM and AM components to meet the requirements by means of a hybrid structure. Adhesive bonding is particularly suitable for such joints, as it imposes no constraints on the joining surface’s geometry or the adherend’s material. To ensure structural integrity, it is conceivable to exploit the design freedom underlying AM processes by optimizing the topology of the AM component to stress the adhesive layer homogeneously. This study explores the feasibility of this concept using the example of an axially loaded single-lap tubular joint between a carbon fiber-reinforced composite tube and an additively manufactured laser-based powder-bed-fusion aluminum alloy sleeve. The sleeve topology was optimized using the finite element method, achieving a $75 \%\mathrm{P}$ reduction in adhesive stress increase compared to a non-optimized sleeve. Due to the pronounced ductility of the two-component epoxy-based adhesive, the static bond strength remained unaffected, whereas fatigue life significantly improved. The findings demonstrate the feasibility of leveraging AM design freedom to enhance adhesive joint performance, providing a promising approach for hybrid structures in lightweight applications. Full article

Circular hollow sections (CHSs) are widely used in offshore jacket structures due to their excellent compressive strength, torsional resistance, and direction-independent stiffness. However, CHS joints are prone to fatigue-induced cracking caused by complex geometries, environmental loading, and aging. Fatigue crack propagation, governed by the stress intensity factor (SIF), threatens structural integrity if the SIF exceeds fracture toughness. Composite reinforcement has emerged as a promising solution for mitigating crack propagation and enhancing joint performance. This study presents a numerical parametric investigation of fatigue-cracked tubular T-joints, focusing on the effects of crack size, crack location, and composite reinforcement on the SIF under various loading conditions. The highest SIF was consistently observed at the saddle point in T-joints under axial and out-of-plane bending (OPB) loads. However, in T-joints subjected to in-plane bending (IPB) loads, the highest SIF was found between the crown and saddle points. The SIF increased with the size and diameter of the cracks. The application of CFRP wrapping was found to reduce the SIF by more than 50% across all loading conditions, with the most significant reductions observed when the reinforcement was oriented along the chord axis. Full article

This paper presents a comprehensive on-site decision-making framework for assessing the structural integrity of a jacket-type offshore platform in the Gulf of Mexico, installed at a water depth of 50 m. Six critical analyses—(i) static operation and storm, (ii) dynamic storm, (iii) strength-level seismic, (iv) seismic ductility (pushover), (v) maximum wave resistance (pushover), and (vi) spectral fatigue—are performed using SACS V16 software to capture both linear and nonlinear interactions among the soil, piles, and superstructure. The environmental conditions include multi-directional wind, waves, currents, and seismic loads. In the static linear analyses (i, ii, and iii), the overall results confirm that the unity checks (UCs) for structural members, tubular joints, and piles remain below allowable thresholds (UC < 1.0), thus meeting API RP 2A-WSD, AISC, IMCA, and Pemex P.2.0130.01-2015 standards for different load demands. However, these three analyses also show hydrostatic collapse due to water pressure on submerged elements, which is mitigated by installing stiffening rings in the tubular components. The dynamic analyses (ii and iii) reveal how generalized mass and mass participation factors influence structural behavior by generating various vibration modes with different periods. They also include a load comparison under different damping values, selecting the most unfavorable scenario. The nonlinear analyses (iv and v) provide collapse factors (Cr = 8.53 and RSR = 2.68) that exceed the minimum requirements; these analyses pinpoint the onset of plasticization in specific elements, identify their collapse mechanism, and illustrate corresponding load–displacement curves. Finally, spectral fatigue assessments indicate that most tubular joints meet or exceed their design life, except for one joint (node 370). This joint’s service life extends from 9.3 years to 27.0 years by applying a burr grinding weld-profiling technique, making it compliant with the fatigue criteria. By systematically combining linear, nonlinear, and fatigue-based analyses, the proposed framework enables robust multi-hazard verification of marine platforms. It provides operators and engineers with clear strategies for reinforcing existing structures and guiding future developments to ensure safe long-term performance. Full article

Tubular structures are critical in renewable energy and offshore industries but face significant loads over time, leading to joint degradation. Carbon fiber-reinforced polymers (CFRPs) offer promising rehabilitation solutions, yet existing studies often overlook stress concentration factors (SCFs) along the weld toe. This study examines SCFs at 24 weld toe positions in CFRP-reinforced KT-joints under axial compression. Using 5429 simulations and artificial neural networks, precise estimations of CFRPs’ impact on SCFs were achieved, with <10% error. These findings demonstrate CFRPs’ potential to reduce SCFs and improve fatigue life prediction for tubular joints under axial compression. Full article

With growing concerns about the danger of global climate change and worldwide demand for energy, the interest in the investigation and construction of renewable energy technologies has increased. Fixed platforms are a type of support structure for wind turbines composed of different types of tubular joints. These structures are under different kinds of cyclic loadings in ocean environmental conditions, which must be designed and reinforced against fatigue. In the present paper, the relationships between the parameters in DKT-joints reinforced with FRP under axial loads are investigated using several models, under 16 axial loading cases, with different nondimensional parameters and different FRP materials, and orientations were generated in ANSYS (total 5184) and analyzed. The four loading conditions that cause the maximum stress concentration factors were selected. After analyzing the 1296 reinforced models, relevant data were extracted, and possible samples were created. The extracted data were used in a multivariate data analysis of maximum stress concentration factors. The Pearson correlation coefficient is utilized to study the relationship between parameters and subsequently to make predictions. To reduce the number of variables and to group the data points into clusters based on certain similarities, hierarchical and non-hierarchical classifications are used, respectively. Full article

In the present study, a total of 360 FE analyses were carried out on tubular X-joints strengthened with collar plates under brace tension under laboratory testing conditions (20 °C) and various fire conditions. The generated FE models were validated based on 31 tests. The FE analyses produced a comprehensive dataset that encapsulated resistance metrics, with detailed simulations of welds, contacts, and the incorporation of non-linear geometrical and material attributes. Twelve theoretical probability density functions (PDFs) were matched to the constructed histograms, with the maximum likelihood (ML) technique utilized to assess the parameters of these fitted PDFs. The theoretical PDFs, rigorously evaluated against the Anderson–Darling, Kolmogorov–Smirnov, and Chi-squared tests, identified the Generalized Petrov distribution as the optimal model for capturing the resistance behaviors of X-joints under tensile load and varying fire conditions. The findings have led to the proposition of five detailed theoretical PDFs and cumulative distribution functions (CDFs), introducing a novel perspective for assessing and reinforcing the structural resilience of strengthened CHS X-joints in engineering practices. Full article

To study the mechanical performance of bolted connections with different structural forms of reinforced rings, based on the results of monotonic loading tests on two bolted connections between a concrete-filled steel tubular column and a steel beam with an outer reinforcing ring, this article uses ABAQUS v.2020 software to establish a three-dimensional refined finite element analysis model of such connections using appropriate constitutive models for concrete and steel. Subsequently, the effect of the dimensions of the steel beam, reinforcing ring, and cover plate on the load-bearing properties and the failure mechanism of the connections is investigated, and the numerical model is consistent with the verification test results. Then, the numerical simulations comparing bolted exterior reinforced rings under seven different construction measures (i.e., number of bolts, stiffeners) based on a conventional welded exterior reinforced rings with rigid connections (i.e., CGJ) are standardized. The research results indicate that when four rows of bolts are introduced on exterior reinforced rings, the web of steel beam is welded with stiffeners, and the top and bottom reinforced rings are also added with stiffeners; this bolted connection with an external reinforcing ring (i.e., GZ-7) can achieve the rigidity and load-bearing capacity of a fully welded external reinforcing ring rigid connection. At the same time, the reinforcing ring plate is bolted to the flange of the steel beam, and the force transmission path at the connection is changed to avoid the brittle fracture easily caused by the welded flange joints. It is also in line with the development trend of sustainable construction of “assembly” and “disassembly”. Full article

In this study, 90 finite-element models are used to explore the behaviour of fibre-reinforced polymer (FRP) reinforced joints under combined in-plane bending (IPB) and axial load (AX). The effects of joint geometry, FRP layer count, and AX levels of the chord or brace are considered. Three typical failure modes are observed: chord plastic failure, brace plastic failure, and brace buckling failure. Increasing the number of FRP layers can ensure that failure is chord-related failure in a ductility manner rather than the unexpectedly brace-related brittle failure. Depending on the stress distribution of fibres, FRP reinforcement can restrict the deformation of joints subjected to complex loading patterns. Moreover, added FRP layers efficiently reduce the effect of brace AX on the IPB resistance. Finally, a modified strength equation is established, including the influence of FRP reinforcement, chord AX, and brace AX. Full article

Pultruded GFRP (glass fiber-reinforced polymer) materials are widely used in structural engineering because of their lightweight, corrosion immunity, and electromagnetic transparency. However, the design of load-bearing components facing substantial compressive stresses, e.g., columns, must be more stringent than steel structures due to excessive deformability, material heterogeneity, and vulnerability to stress concentration. This manuscript investigates the failure performance of locally produced GFRP materials, focusing on the material heterogeneity effect on the mechanical resistance of a support joint of a pultruded tubular GFRP column. This experimental campaign employs relatively short rectangular profile fragments to isolate the support behavior and verify a simplified numerical finite element model, which neglects the nonlinearity of GFRP material. This work determines the material failure mechanisms behind the mechanical performance of pultruded profiles subjected to longitudinal compression for various column lengths. Full article

Recently, fiber-reinforced polymers (FRP) have begun to be used for steel structure reinforcement, following decades of successful utilization for the reinforcement of concrete structures. However, rehabilitation of tubular joints with a crack at the interface of mating members using FRP has rarely been investigated. A tubular KT-joint having a semi-elliptical crack subjected to axial tensile load is explored in this study. The joint was simulated using the fracture tool of ANSYS Structural, and the effect of crack size, location, and FRP reinforcement on stress intensity factor (SIF) was evaluated. The numerical simulations show that FRP reinforcement reduces the SIF, decreases the likelihood of crack growth, and may increase the fatigue life. A 4–12% reduction per millimeter thickness of unidirectional FRP was recorded. Full article

In this paper, the effect of the outer reinforcing plate on the initial stiffness, ultimate strength, and failure mechanisms of tubular K-joints under axial load at ambient and different fire conditions is evaluated. In the first phase, a finite element (FE) model was generated and verified by 13 experimental tests. In the next step, 1057 numerical models were generated. In these models, the welds joining the chord and braces were modeled. Using the produced FE models, the structural behavior under ambient and different elevated temperatures (20, 150, 300, 450, 600, 750, and 900 °C) was evaluated. The results showed that the outer plate can enhance the ultimate strength by up to 319% under fire conditions. Despite the considerable effect of the outer plate on the stiffness, ultimate strength, failure modes, and the frequent usage of the K-joints in tubular structures, the static response of the reinforced K-joints at ambient and elevated temperatures has not been studied. Hence, according to the extensive parametric studies, a highly precise practical design equation has been proposed based on the yield volume model for determining the ultimate strength. Full article

Exposure to load and offshore environment degrades the load-bearing capacity of tubular joints, necessitating reinforcement of these joints. Reinforcement is sometimes required for lifespan enhancement or qualification based on new requirements. Available reinforcement techniques include welded rings inside/outside the chord, doubler/collar plate at the brace-chord interface, grout filling, and clamp installation on the joints with/without cement. While these techniques increase the load-bearing capacity of damaged tubular joints, various practical limitations exist. Clamping may require heavy machinery, whereas welding stiffeners involves hot work and may not be permitted sometimes. Fiber-reinforced polymers (FRPs) have immense potential for reinforcing steel structures and are a viable alternative for rehabilitating tubular joints due to their exceptional mechanical and physical characteristics, offering competitive advantages over other methods. FRP reinforcement is becoming more feasible and economical for underwater joints. FRP reinforcement can be either precured, pre-impregnated, or wet layup. Aside from the significance of joint rehabilitation, a document covering the well-known options was lacking. This paper summarizes the advantages and limitations of these reinforcement methods, particularly FRP reinforcement. Possible research directions in FRP reinforcement of tubular joints are also discussed. Full article

The existing connection between the concrete-filled double steel tubular (CFDST) column and the reinforced concrete (RC) beam is difficult to repair and reuse after damage. In this paper, a self-centering joint between the CFDST column and the RC beam is proposed. The self-centering of the joint is realized by prestressed steel strands, and the energy dissipation is realized by friction. The overall purpose of the research is to analyze the influence of steel strand and friction on the mechanical behavior of the joint. By comparing the envelope curve and the restoring force model of a numerical joint model with theoretical values, accuracy of the numerical model was verified. Then, joints with different parameters, including the friction, prestress of steel strands, and ratio of the resisting moment provided by steel strands to the resisting moment provided by friction in the opening moment of joints, were numerically analyzed. The results showed that the joints with greater friction and prestress of steel strands had higher bearing capacity. Increasing the friction could increase the energy dissipation capacity of the joint, but it would increase the residual deformation of the joint. To reduce residual deformation, the prestress of steel strands should be increased. When the resultant force of the pretension of steel strands was greater than friction, the steel head could be kept pressed on the connecting block, making the stress changes of steel strands and the self-centering performance of the joint stable. Full article

This study aims to verify which the performance-based design was successfully applied in the construction of the main exhibition hall of the first Hebei Garden Expo, China. Based on the idea of “equality and connectivity” among humans, buildings, and the environment, the exhibition hall was designed using digital shape generation technology, and a special double-skin structure was selected. A bright exterior glass curtain wall separated from the cell-shaped reinforced concrete (RC) structure, not only made the exhibition hall fit into the scenery so well, but also presented an adhesion area with functional links to the RC structure. Joints of the steel tubular truss and the glass curtain wall were optimally designed by means of finite element simulations. During the service of more than a decade, extension of space, function of interactivity, and energy conservation required for a green infrastructure were achieved, highlighting the ecological connectivity of the exhibition hall with the surrounding landscape. The exhibition hall performed synergy of structure and architecture functions and it is still a landmark building in Shijiazhuang, showing an excellent application achievement of the performance-based design. Full article
