The dynamic development of distributed sources (mainly RES) contributes to the emergence of, among others, balance and overload problems. For this reason, many RES do not receive conditions for connection to the power grid in Poland. Operators sometimes extend permits based on the possibility of periodic power reduction in RES in the event of the problems mentioned above. Before making a decision, investors, for economic reasons, need information on the probability of annual power reduction in their potential installation. Analyses that allow one to determine such a probability require knowledge of the reliability indicators of transmission lines and transformers, as well as failure removal times. The article analyses the available literature on the annual risk of outages of these elements and methods to determine the appropriate reliability indicators. Example calculations were performed for two networks (test and real). The values of indicators and times that can be used in practice were indicated. The unique contribution of this article lies not only in the comprehensive comparison of current, relevant transmission line and transformer reliability analysis methods but also in developing the first reliability indices for the Polish power system in more than 30 years. It is based on the relationships presented in the article and their comparison with results reported in the international literature. Full article

While power system resilience studies continue to grow due to the criticality of electrical infrastructures, the challenge of inconsistencies in evaluation frameworks remains. Furthermore, the desire for researchers to contribute towards the development of practical assessment frameworks continues to grow. In addition, the locality of resilience issues has challenged researchers to find context-based resilience solutions. This paper addresses these by proposing an assessment framework, which evaluates the five phases of the resilience trapezoid: preventive, absorptive, adaptive, restorative, and transformative. This framework presents metrics for measuring preventive indicators for the anticipating system status, frequency of functionality degradation, how low functionality drops, extension in a degraded state, the promptness of recovery, and system transformation—the AFLEPT model. The AFLEPT framework is applied, with its resilience indicators and capacities, to evaluate the resilience of Malawi’s transmission network to the 2022 Tropical Cyclone Ana (TCA). DigSILENT PowerFactory 2023 SP5 was utilised to support this research. The results indicate significant resilience challenges, manifested by an inadequate generation reserve, significant decline in grid functionality, extended total grid outage hours, longer restoration times, and a lack of transformation. Eight percent of key transmission lines and eighteen percent of power generation infrastructure were completely damaged by the TCA, which lasted up to 25 days and 16 months to, respectively, before restoration. Thus, the analysis reveals gaps in preventive, absorptive, adaptive, restorative, and transformative resilience capacities. The results underscore the need for context-based infrastructural and operational resilience enhancement measures, which have been discussed in this paper. Directions for further research have been proposed, which include exploring multiple grid improvement measures and an economic modelling of these measures. Full article

High-voltage direct-current (HVdc) transmission lines are gaining more attention as an integral part of modern power system networks. Monitoring the dc current is important for metering and the development of dynamic line rating control schemes. However, this has been a challenging task, and there is a need for wireless sensing methods with high accuracy and a dynamic range. Conventional methods require direct contact with the high-voltage conductors and utilize bulky and complex equipment. In this paper, an ultra-high-frequency (UHF) radio frequency identification (RFID)-based sensor is introduced for the monitoring of the dc current of an HVdc transmission line. The sensor is composed of a passive RFID tag with a custom-designed antenna, integrated with a Hall effect magnetic field device and an RF power harvesting unit. The dc current is measured by monitoring the dc magnetic field around the conductor using the Hall effect device. The internal memory of the RFID tag is encoded with the magnetic field data. The entire RFID sensor can be wirelessly powered and interrogated using a conventional RFID reader. The advantage of this approach is that the sensor does not require batteries and does not need additional maintenance during its lifetime. This is an important feature in a high-voltage environment where any maintenance requires either an outage or special equipment. In this paper, the detailed design of the RFID sensor is presented, including the antenna design and measurements for both the RFID tag and the RF harvesting section, the microcontroller interfacing design and testing, the magnetic field sensor calibration, and the RF power harvesting section. The UHF RFID-based magnetic field sensor was fabricated and tested using a laboratory experimental setup. In the experiment, a 40 mm-diameter-aluminum conductor, typically used in 500 kV HVdc transmission lines carrying a dc current of up to 1200 A, was used to conduct dc current tests for the fabricated sensor. The sensor was placed near the conductor such that the Hall effect device was close to the surface of the conductor, and readings were acquired by the RFID reader. The sensitivity of the entire RFID sensor was 30 mV/mT, with linear behavior over a magnetic flux density range from 0 mT to $4.5$ mT. Full article

Lightning strikes are a leading cause of outages on overhead transmission lines, significantly compromising power system reliability. Consequently, monitoring lightning activity is critical to mitigate its impact on lines with high outage rates. This study presents an autonomous lightning strike counter system utilizing a split-core Rogowski coil for non-invasive current measurement on transmission towers. The system combines the Rogowski coil with an active integrator circuit to reconstruct the incident current waveform from the coil voltage signal. A microcontroller-based processing unit records strike occurrences and classifies them by amplitude using predefined thresholds. Laboratory tests were carried out to evaluate the performance of the Rogowski coil and integrator circuit, validating the system accuracy in detecting current pulses associated with lightning strikes. Underway field tests will assess the sensor’s reliability during long-term autonomous operation on 345-kV transmission towers. The results demonstrate that the proposed system represents a practical and cost-effective solution for lightning monitoring in remote areas, contributing to enhanced data collection for engineering studies and improved reliability of electrical infrastructure. Full article

This paper presents a comprehensive assessment of the accuracy of high-frequency (HF) earth meters in measuring the tower-footing ground resistance of transmission line structures, combining simulation and experimental results. The findings demonstrate that HF earth meters reliably estimate the harmonic grounding impedance ($R_{25\mathrm{k}\mathrm{H}\mathrm{z}}$) at their operating frequency, typically 25 kHz, for a wide range of soil resistivities and typical span lengths. For the analyzed tower geometries, the simulations indicate that accurate measurements are obtained for adjacent span lengths of approximately 300 m and 400 m, corresponding to configurations with one and two shield wires, respectively. Acceptable errors below 10% are observed for span lengths exceeding 200 m and 300 m under the same conditions. While the measured $R_{25\mathrm{k}\mathrm{H}\mathrm{z}}$ does not directly represent the resistance at the industrial frequency, it provides a meaningful measure of the grounding system’s impedance, enabling condition monitoring and the evaluation of seasonal or event-related impacts, such as damage after outages. Furthermore, the industrial frequency resistance can be estimated through an inversion process using an electromagnetic model and knowing the geometry of the grounding electrodes. Overall, the results suggest that HF earth meters, when correctly applied with the fall-of-potential method, offer a reliable means to assess the grounding response of high-voltage transmission line structures in most practical scenarios. Full article

Icing on transmission lines poses a serious threat to the power grid. Existing de-icing solutions have limitations in short-distance distribution networks with multiple branches. We propose a method that utilizes a flexible grounding device to adjust the zero-sequence reactive current in the distribution network, enabling de-icing of lines without power interruption. Simulation and experimental results validate the feasibility and effectiveness of the proposed method and control scheme. The method can accurately regulate the de-icing current to achieve de-icing under various conditions, with the actual de-icing current deviating from the set value by less than 0.3%. During de-icing, the line voltage on the load side remains essentially stable, with an error of less than 0.5%, ensuring that the normal supply voltage of the distribution network is not affected, and the entire network load does not require a power outage. The de-icing device interacts only with reactive power in the distribution network, saving capacity for the DC voltage stabilizing power supply and demonstrating good economic efficiency. Full article

The usefulness of the well-built electrical power system is efficient supply generation of electrical power for consumers. For a reliability assessment of power systems, the system’s actual components in terms of performance and random behavior should be evaluated. This paper presents a reliability analysis based on the Fault Tracing Paths (FTP) method to identify component outages in composite power systems. This study focuses on composite power systems because these systems are linked to generating and distribution systems, in addition to having the primary equipment in these systems being used to move the electrical power. The FTP approach will identify the primary equipment that caused the composite power systems failure. This method gives out the events matrix for numerous flow Fault Tracing paths from the power sources to the loads. The proposed events matrix is applied as input data to simulate the system behavior. A power flow study is conducted using the RTS test system to evaluate the reliability of generators, transformers, and transmission lines during an outage. The study employs a simplified one-line diagram method to determine system stability and failure impacts. Finally, the proposed FTP method can be applied to complicated composite power systems. Full article

As global warming continues to intensify, typhoon disasters will more frequently occur in East and Southeast Asia, posing a high risk of causing large-scale power outages in the power system. To investigate the impact of typhoon disasters on high-voltage power grids, a comprehensive risk assessment method that integrates model-driven and data-driven approaches is proposed, which can predict power grid faults in advance and provide support for power grid operators to generate emergency dispatching plans. Firstly, by comparing actual loads with the design strengths of the transmission tower-line system and analyzing the geometric relationship between typhoon wind circles and the system, key variables, such as wind speed, longitude, latitude, and other pertinent factors, are screened. The Spearman correlation coefficient is employed to pinpoint the meteorological variables that exhibit a high degree of relevance, enhancing the accuracy and interpretability of our model. Secondly, addressing the lack of power grid fault samples, three data balancing methods—Borderline-SMOTE, ADASYN, and SMOTE-Tomek—are compared, with Borderline-SMOTE selected for its superior performance in enhancing the sample set. Additionally, a power grid failure risk assessment model is built based on Light Gradient Boosting Machine (LightGBM), and the Borderline-Smoothing Algorithm (BSA) is used for the modeling of power grid faults. The nonlinear mapping relationship between typhoon meteorological data and the power grid equipment failure rate is extracted through deep learning training. Subsequently, the Tree-structured Parzen Estimator (TPE) is leveraged to optimize the hyperparameters of the LightGBM model, thus enhancing its prediction accuracy. Finally, the actual power system data of a province in China under a strong typhoon are assessed, validating the proposed assessment method’s effectiveness. Full article

Bird streamer faults occur when the streamer, i.e., bird excretion, bridges the gap between two energized components or an energized and an earthed component of a tower structure. This results in a short circuit, which may be accompanied by an outage in the electricity supply. Due to the impact of these faults on electrical infrastructure and bird mortality, a detailed literature review to identify effective mitigation measures for sub-transmission lines (44–132 kV) and transmission lines (132–765 kV) was conducted. The findings show that there are several measures used internationally to reduce streamer-related faults, e.g., bird perch deterrents, shields, changing tower design configurations, changing insulator types and properties, and bird runways. Bird perch deterrents are typically most effectively used by many utilities; however, it is imperative that the perch deterrents are placed and installed correctly. Placement should be above potential problematic areas—to prevent the bridging of the gaps—at various points on different tower structures. Moreover, bird guards need to be monitored and maintained to ensure effectiveness over time. The involvement of a range of stakeholders when making environmental management decisions, such as researching and implementing the best mitigation measures, is also critical to ensure continued success. Full article

In mountainous regions, forested areas, and other zones prone to natural disasters, power equipment faces heightened risks of shutdown. Such disruptions significantly elevate the risk of secondary cascading failures within the power grid. Consequently, devising cascading failure mitigation strategies from an operational perspective is of paramount importance for containing the spread of cascading failures in the power system during disasters and minimizing the losses incurred from disaster incidents. Firstly, based on the severity of natural disaster accident risks, this paper establishes a risk index for power equipment for the first time, providing a new perspective for the refined analysis of the development model of cascading failures in power systems. Subsequently, a new collaborative mitigation strategy for system cascading failures is proposed at the operational control level. This strategy, in conjunction with proactive prevention and control measures, aims to promptly sever potential cascading failure paths upon the occurrence of a disaster, thereby ensuring that the area of power outage is minimized to the greatest extent possible. The effectiveness of the proposed strategy is verified through simulation cases. The results show that in the scenario set in this article, the risk of cascading failures under natural disasters is nearly five times higher than that without natural disasters. At the same time, the cascading failure control method proposed in this study can reduce the risk of cascading failure by about 80%. Full article

High-voltage direct current (HVDC) transmission lines are increasing in number and overall length. This means their lightning protection must be of higher importance as well. Probability-modulated attractive space (PMAS) theory is a proven geometry-based method for lightning protection calculations. However, it cannot accurately assess the number and parameters of direct lightning strikes to the phase conductor of HVDC lines, because the effect of pole voltage on lightning attachment cannot be considered. This effect can be taken into account with leader progression models, which feature lightning physics models that can quantify the effect of the electric field around the phase conductor, which can be quite complex compared to geometric models in general. In this paper, a novel method, called the attractive space matrix, is presented to examine the effect of the DC electric field around the conductor on the attractive space. The algorithm is based on the physical background of the self-consistent leader inception and propagation model. The results could lead to improved lightning protection of HVDC lines and reduce the outages caused by direct lightning strikes. Full article

This study investigates the impact of meteorological conditions on unplanned outages of overhead transmission lines (OHTL) in Lithuania’s 0.4–35 kV power grid from January 2013 to March 2023. Data from the Lithuanian electricity distribution network operator and the Lithuanian Hydrometeorological Service were integrated to attribute outage events with weather conditions. A Bayesian change point analysis identified thresholds for these meteorological factors, indicating points at which the probability of outages increases sharply. The analysis reveals that wind gust speeds, particularly those exceeding 21 m/s, are significant predictors of increased outage rates. Precipitation also plays a critical role, with a 15-fold increase in the relative number of outages observed when 3 h accumulated rainfall exceeds 32 mm, and a more than 50-fold increase for 12 h snowfall exceeding 22 mm. This study underscores the substantial contribution of lightning discharges to the number of outages. In forested areas, the influence of meteorological conditions is more significant. Furthermore, the research emphasizes that combined meteorological factors, such as strong winds accompanied by rain or snow, significantly increase the risk of outages, particularly in these forested regions. These findings emphasize the need for enhanced infrastructure resilience and targeted preventive measures to mitigate the impact of extreme weather events on Lithuania’s power grid. Full article

Overhead transmission line insulators are non-conductive materials that separate conductors from grounded transmission towers. Once in operation, they frequently experience environmental pollution and electrical or mechanical stress. Since adverse operational conditions can lead to insulation failure, regular inspections are essential to prevent power outages. To this end, this paper proposes a novel technique based on deep convolutional neural networks (CNNs) to classify high-voltage insulator surface conditions based on their image. Successful applications of CNNs in computer vision have led to several pretrained architectures for image classification. To use these pretrained models, a practitioner typically fine-tunes and selects one final model via a model selection stage and discards all other models. In contrast with many existing studies that use such a “winner-takes-all” approach, here, we identify the best subset of seven popular pretrained CNN architectures that are combined by soft voting to form an ensemble classifier. From a machine learning (ML) perspective, this focus is warranted because the convolutional base of each pretrained architecture operates as a feature extractor and an ensemble of them works as a combination of various feature extraction rules. Our numerical experiments demonstrate the advantage of the identified ensemble model to individual pretrained architectures. Full article

Line icings on the power transmission lines are dangerous risks that may lead to situations like structural damage or power outages. The current techniques used for identifying ice have certain drawbacks, particularly when used in complex environments. This paper aims to detect lines on the top and bottom in PTLI with low illumination and complex backgrounds. The proposed method integrates multistage image processing techniques, including image enhancement, filtering, thresholding, object isolation, edge detection, and line identification. A binocular camera is used to capture images of PTLI. The effectiveness of the method is evaluated through a series of metrics, including accuracy, sensitivity, specificity, and precision, and compared with existing methods. It is observed that the proposed method significantly outperforms the existing methods of ice detection and thickness measurement. This paper uses average accuracy of detection and isolation of ice formations under various conditions at a percentage of 98.35, sensitivity at 91.63%, specificity at 99.42%, and precision of 96.03%. Furthermore, the accuracy of the ice thickness based on the thickness measurements is shown with a much smaller RMSE of 1.20 mm, MAE of 1.10 mm, and R-squared of 0.95. The proposed scheme for ice detection provides a more accurate and reliable method for monitoring ice formation on power transmission lines. Full article

Power transmission line icing (PTLI) poses significant threats to the reliability and safety of electrical power systems, particularly in cold regions. Accumulation of ice on power lines can lead to severe consequences, such as line breaks, tower collapses, and widespread power outages, resulting in economic losses and infrastructure damage. This study proposes an enhanced image processing pipeline to accurately detect and match key points in PTLI images for 3D monitoring of ice thickness using binocular vision. The pipeline integrates established techniques such as multiscale retinex (MSR), oriented FAST and rotated BRIEF (ORB) and scale-invariant feature transform (SIFT) algorithms, further refined with m-estimator sample consensus (MAGSAC)-based random sampling consensus (RANSAC) optimization. The image processing steps include automatic cropping, image enhancement, feature detection, and robust key point matching, all designed to operate in challenging environments with poor lighting and noise. Experiments demonstrate that the proposed method significantly improves key point matching accuracy and computational efficiency, reducing processing time to make it suitable for real-time applications. The effectiveness of the pipeline is validated through 3D ice thickness measurements, with results showing high precision and low error rates, making it a valuable tool for monitoring power transmission lines in harsh conditions. Full article
