The constitutive model is widely employed to characterize the rheological properties of metallic materials under high-temperature conditions. It is typically derived from a series of high-temperature tests conducted at varying deformation temperatures, strain rates, and strains, including hot stretching, hot compression, separated Hopkinson pressure bar testing, and hot torsion. The original experimental data used for establishing the constitutive model serves as the foundation for developing phenomenological models such as Arrhenius and Johnson–Cook models, as well as physical-based models like Zerilli–Armstrong or machine learning-based constitutive models. The resulting constitutive equations are integrated into finite element analysis software such as Abaqus, Ansys, and Deform to create custom programs that predict the distributions of stress, strain rate, and temperature in materials during processes such as cutting, stamping, forging, and others. By adhering to these methodologies, we can optimize parameters related to metal processing technology; this helps to prevent forming defects while minimizing the waste of consumables and reducing costs. This study provides a comprehensive overview of commonly utilized experimental equipment and methods for developing constitutive models. It discusses various types of constitutive models along with their modifications and applications. Additionally, it reviews recent research advancements in this field while anticipating future trends concerning the development of constitutive models for high-temperature deformation processes involving metallic materials. Full article

The integration of fiber-reinforced cementitious composites (FRCCs) with fiber-reinforced polymer (FRP) bars represents a significant advancement in concrete technology, aimed at enhancing the structural performance of reinforced concrete elements. The incorporation of fibers into cementitious composites markedly improves their mechanical properties, including tensile strength, ductility, compressive strength, and flexural strength, by effectively bridging cracks and optimizing load distribution. Furthermore, FRP bars extend these properties with their high tensile strength, lightweight characteristics, and exceptional corrosion resistance, rendering them ideal for applications in aggressive environments. In recent years, there has been a notable increase in interest from the engineering research community regarding this topic, primarily to solve the issues of aging and deteriorating infrastructure. Researchers have conducted extensive investigations into the structural performance of FRCC and FRP composite systems. This paper presents a systematic literature review that surveys experimental and analytical studies, findings, and emerging trends in this field. A comprehensive search on the Web of Science identified 40 relevant research articles through a rigorous selection process. Key factors of structural performance, such as bond behavior, flexural behavior, ductility performance assessments, shear and torsional performance, and durability evaluations, have been documented. This review aims to provide an in-depth understanding of the structural performance of these innovative composite materials, paving the way for future research and development in construction materials technology. Full article

Vehicles are now rapidly transitioning from a conventional torsion bar suspension to an in-arm suspension unit (ISU), reflecting the growing industrial demand for more compact, high-performance systems. Although the ISU system can adapt well to rough terrain, the side forces produced when the piston moves can affect its reliability. Current models built on ideal gas assumptions fail to describe the complex nonlinear behavior of nitrogen under extreme pressure and temperature variations. This study incorporates the Beattie–Bridgeman real-gas equation into a dynamic force-displacement model to overcome this limitation. Furthermore, a bi-objective optimization strategy was devised that simultaneously minimizes the side forces and enhances acceleration stability across diverse environmental conditions. The optimized design based on a metamodel and a hybrid metaheuristic algorithm resulted in an 81.4% reduction in peak lateral forces and a 53.3% improvement in acceleration robustness, which marks a significant increase in suspension system durability. These findings not only advance ISU design methodologies but also offer viable solutions to existing reliability challenges. Full article

This study investigates the application of Bayesian statistical methods to analyze and predict the dimensional changes in torsion bars made from 20CrMnTi alloy steel during carburizing heat treatment. The process parameters, including a treatment temperature of 920 °C followed by oil quenching, were selected to optimize surface hardness while maintaining core toughness. The dimensional changes were measured pre- and post-treatment using precise caliper measurements. Bayesian statistics, particularly conjugate normal distributions, were utilized to model the dimensional variations, providing both posterior and predictive distributions. These models revealed a marked concentration of the posterior distributions, indicating enhanced accuracy in predicting dimensional changes. The findings offer valuable insights for improving the control of carburizing-induced deformations, thereby ensuring the dimensional integrity and performance reliability of torsion bars used in high-stress applications such as pneumatic clutch systems in mining ball mills. This study underscores the potential of Bayesian approaches in advancing precision engineering and contributes to the broader field of statistical modeling in manufacturing processes. Full article

This paper presents an innovative active monitoring strategy to manage asymmetry in aircraft flaps. Complex mechanical systems like high-lift devices may undergo a wide range of faults, such as a broken transmission torsion bar or wear and tear on control surface actuators just to name a few. These faults can alter the surface symmetry between the two sides of the wing, potentially leading to dangerous conditions. The proposed relative dynamic position control technique provides a more effective monitoring method to detect and identify flap asymmetry. Once the faulty side has been identified, the system activates the wingtip brakes to halt the uncontrolled flap. The remaining functional flap is then moved to match the braking point of the failed flap, reducing the asymmetry. This approach effectively manages the unwanted roll moment caused by flap asymmetry, thereby partially restoring the aircraft’s maneuverability post-failure. The proposed monitoring technique has been subjected to extensive testing under various operational and failure conditions with the use of a mathematical model, with both new and worn actuators, and considering a wide range of possible failure scenarios. Full article

The diagnosis of post-stressed anchor rods is essential for maintaining the service and ensuring the safety of Electricité de France (EDF) structures. These rods are critical for the mechanical strength of structures and electromechanical components. Currently, the standard method for estimating the effective tension of post-stressed tie rods with a free length involves measuring the residual force using a hydraulic jack. However, this method can be costly, impact the structure’s operation, and pose risks to employees. Until now, there has been no reliable on-field approach to estimating residual tension using a lightweight setup. This research introduces a nondestructive method using multimodal ultrasonic guided waves to evaluate the residual tension of anchor rods with a few centimeters free at one end. The methodology was developed through both laboratory experiments and simulations. This new method allows for the extraction of dispersion curves for the first three modes, bending, torsional, and longitudinal, using time–frequency analysis and enables the estimation of the steel bar’s properties. Future work will focus on applying this methodology in the field. Full article

This paper presents a novel variable stiffness mechanism, namely the SBTDTS (Spinal Biomimetic Two-Dimensional Tensegrity Structure), which is constructed by integrating bioinspiration derived from biological spinal structures with the T-Bar mechanical design within tensegrity structures. A method for determining the torsional stiffness of the SBTDTS around a virtual rotational center is established based on parallel mechanism theory. The relationship between various structural parameters is analyzed through multiple sets of typical parameter combinations. Ultimately, the PSO (Particle Swarm Optimization) algorithm is employed to identify the optimal combination of structural parameters for maximizing the stiffness ratio, $K_{\theta \_time}$, of SBTDTS under different constraint conditions. This optimal configuration is then compared with the RAPRPM (a type of rotational parallel mechanism) under different values of $\mu$, with an analysis of the distinct advantages of both variable stiffness structures. Full article

This paper aims to report the design of a mechanism to drive a propeller to deform between an aerial and one aquatic shape. This mechanism can realize the deformation of blade angle, radius, blade twist angle distribution and blade section thickness. Inspired by the Kresling origami structure and utilizing its rotation-folding motion characteristics, a propeller hub structure with variable blade angle is designed. A blade deformation unit (S-unit) with extensional-torsional kinematic characteristics is designed through the motion analysis of a spherical four-bar mechanism. A rib support structure fixed to the linkages of the s-unit is designed to achieve the change in blade section thickness. Based on motion analysis, the coordinate transformation method has been used to establish the relationship between propeller shape and deformation mechanism. The deformation of blade extension, blade twist distribution, and blade section thickness are analyzed. The deformation ability of the proposed structure can be verified then by kinematic simulation and rapid prototyping based on 3-D printing. It is proved that the proposed mechanism is applicable to deformable propeller design. The rapid prototype testing validates the stable motion of the mechanism. However, due to the relatively large self-weight of the structure, the blade has a slight deformation. In the subsequent work, the structural strength issue needs to be emphasized. Full article

The Torsion-Bar Antenna (TOBA) is a torsion pendulum-based gravitational detector developed to observe gravitational waves in frequencies between 1 mHz and 10 Hz. The low resonant frequency of the torsion pendulum enables observation in this frequency band on the ground. The final target of TOBA is to observe gravitational waves with a 10 m detector and expand the observation band of gravitational waves. In this paper, an overview of TOBA, including the previous prototype experiments and the current ongoing development, is presented. Full article

The failure mechanism of torsional concrete beams with fiber-reinforced polymer (FRP) bars is essential for developing the design method. However, limited experimental research has been conducted on the torsion behavior of concrete beams with FRP bars. Therefore, the pure torsion test of four large-scale FRP-RC beams (2800 mm × 400 mm × 200 mm) was conducted to investigate the influence of the stirrup ratio (0, 0.49%, and 0.98%) and longitudinal reinforcement ratio (3.01%, 4.25%) on torsion behavior. The test results indicated that three typical failure patterns, including concrete cracking failure, stirrup rupturing failure, and concrete crushing failure, were observed in specimens without stirrups (stirrup ratio 0), partially over-reinforced specimens (stirrup ratio 0.49%), and over-reinforced specimens (stirrup ratio 0.98%), respectively. The tangent angle of spiral cracks at the midpoint of the long side of the cross-section was approximately 45° initially for all specimens. The torque–twist angle curves exhibited a linear and bilinear behavior for specimens without stirrups and specimens with stirrups, respectively. As the stirrup ratio increased from 0 to 0.98%, torsion capacity increased from 24.9 kN∙m to 27.8 kN∙m, increased by 12%, ultimate twist angle increased from 0.0018 rad/m to 0.0403 rad/m. As the longitudinal reinforcement ratio increased from 3.01% to 4.25%, the torsion capacity increased from 27.8 kN∙m to 28.3 kN∙m, and the ultimate twist angle decreased from 0.0403 rad/m to 0.0244 rad/m. Based on test results, the stirrup strain limit of 5200 με and spiral crack angle of 45° was suggested for torsion capacity calculation. In addition, based on the database of torsion tests, the performance of torsion capacity provisions was assessed. Full article

This paper aims to design a deformable mechanism to drive amphibious rotor blade deform from an aerial shape to an aquatic one. The Bennett four-bar and spherical four-bar mechanisms are used as the basic units (B unit and S unit) to form the Bennett–spherical spatial scissor unit (BS unit). By analyzing the kinematic characteristics of the BS unit, it is found that the BS unit can achieve the spatial deformation of expansion and torsion, effectively improving the rotor’s performance in water and air media. The wing rib support structure, which is fixed to the BS unit linkage, is designed. The coordinate transformation method describes the blade shape in aerial and aquatic modes using BS unit and rib parameters. To improve the rotor blade performance in air and water, the rotor blade design is carried out under the NSGA-II framework with BS parameters as the design variables. The Gaussian regression and CFD methods are applied to build a surrogate model to reduce the computational cost. The results show that the expansion–torsional deformation of the BS unit can effectively increase the air and water compatibility of the rotor blades. When the rotor is an aerial shape, the BS mechanism extends and decreases the torsion to increase the lift and efficiency. When it is deformed to an aquatic shape, the BS mechanism reduces its length and increases the torsion to reduce the torque effectively. The BS scissor unit and the design method can be effectively applied in the design of deformable rotor blades. Full article

Innovative designs such as morphing wings and terrain adaptive landing systems are examples of biomimicry and innovations inspired by nature, which are actively being investigated by aerospace designers. Morphing wing designs based on Variable Geometry Truss Manipulators (VGTMs) and articulated helicopter robotic landing gear (RLG) have drawn a great deal of attention from industry. Compliant mechanisms have become increasingly popular due to their advantages over conventional rigid-body systems, and the research team led by the second author at Toronto Metropolitan University (TMU) has set their long-term goal to be exploiting these systems in the above aerospace applications. To gain a deeper insight into the design and optimization of compliant mechanisms and their potential application as alternatives to VGTM and RLG systems, this study conducted a thorough analysis of the design of flexible hinges, and single-, four-, and multi-bar configurations as a part of more complex, flexible mechanisms. The investigation highlighted the flexibility and compliance of mechanisms incorporating circular flexure hinges (CFHs), showcasing their capacity to withstand forces and moments. Despite a discrepancy between the results obtained from previously published Pseudo-Rigid-Body Model (PRBM) equations and FEM-based analyses, the mechanisms exhibited predictable linear behavior and acceptable fatigue testing results, affirming their suitability for diverse applications. While including additional linkages perpendicular to the applied force direction in a compliant mechanism with N vertical linkages led to improved factors of safety, the associated increase in system weight necessitates careful consideration. It is shown herein that, in this case, adding one vertical bar increased the safety factor by ${\displaystyle \frac{100}{N}}$ percent. The present study also addressed solutions for the precise modeling of CFHs through the derivation of an empirical polynomial torsional stiffness/compliance equation related to geometric dimensions and material properties. The effectiveness of the presented empirical polynomial compliance equation was validated against FEA results, revealing a generally accurate prediction with an average error of 1.74%. It is expected that the present investigation will open new avenues to higher precision in the design of CFHs, ensuring reliability and efficiency in various practical applications, and enhancing the optimization design of compliant mechanisms comprised of such hinges. A specific focus was put on ABS plastic and aluminum alloy 7075, as they are the materials of choice for non-load-bearing and load-bearing structural components, respectively. Full article

Knowing the mechanical properties of fiber-reinforced composite materials, which are currently widely used in various industrial branches, represents a major objective for designers. This happens when new materials are used that are not yet in production or for which the manufacturer cannot give values. Given the practical importance of this problem, several methods of determining these properties have been proposed, but most of them are laborious and require a long calculation time. And, some of the proposed calculation methods are very approximate, providing only upper and lower limits for these values. Experimental measurements are obviously the optimal solution for solving this problem, but it must be taken into account that this type of method consumes time and material resources. This paper proposes a sufficiently accurate and fast estimation method for determining Young’s modulus for a homogenized fibrous material. Thus, the FEM is used to determine the natural frequencies of a standard bar, for which there are sufficiently precise classical methods to express the engineering constants according to the mechanical properties of the component phases of the homogenized material. In this paper, Young’s modulus is determined for such a material using the relationships that provide the eigenfrequencies for the longitudinal vibrations. With the adopted model, transverse and torsional vibrations are eliminated by blocking the nodes on the surfaces of the bars. In this way, more longitudinal eigenfrequencies can be obtained, so the precision in calculating Young’s modulus is increased. Full article

Infilled walls and frames typically employ closely spaced rigid connection, which, under seismic actions, can lead to adverse effects such as amplified seismic responses, overall torsion, and the formation of weak layers in the structure. Flexible connection isolating the infilled walls from the frames can effectively mitigate the adverse effects of rigid connections. In order to reduce the structural mass and seismic impacts, Autoclaved Aerated Concrete (AAC) masonry flexible connection infilled walls have been widely researched. However, most AAC masonry flexible connection infilled walls require complex process operations for AAC blocks, which is not conducive to practical applications in engineering. Therefore, an AAC flexible connection infilled wall with Basalt Fiber Grating (BFG) strips instead of steel bars, with simplified process operations, has been proposed. Existing finite element models for BFG strip-reinforced AAC masonry flexible connection infilled walls employ solid elements, which are difficult to apply to large-scale structural simulations; moreover, existing simplified models for flexible connection infilled walls cannot simulate out-of-plane loading. In this paper, based on homogenization methods, using simplified elements to simulate components, a simplified model for the BFG strip-reinforced AAC masonry flexible connection infilled frame is proposed. Utilizing this model, stress analyses under both in-plane and out-of-plane loading are conducted and compared with corresponding experimental results. The results indicate that the in-plane simplified model (ISM) fits well with the experimental results in terms of hysteresis curves, with similar relationships between stiffness degradation and strength attenuation. The displacement force curve of the out-of-plane simplified model (OSM) before reaching the peak load is in good agreement with the experimental results. The maximum plastic range of OSM is 5% smaller than the test results, and it can be considered that the plastic ranges of the two are comparable, manifesting the models’ capability to adequately manifest arching behavior. The simplified model enables simulation of out-of-plane loading and provides a new approach for modeling large-scale frame structures with flexible connection infilled wall. Full article

Ultrasonic guided waves represent a new development in the field of non-destructive testing. Longitudinal guided waves are mostly used to monitor the damage of steel bars, but the received signal is usually degraded and noisy owing to its dispersive propagation and multimodal behavior, making its implementation and location challenging. The torsional mode of T (0, 1) is not dispersive in the propagation of a steel bar and only produces circumferential displacement. It was chosen, in this study, to conduct guided wave-based damage monitoring on steel bars to reduce the signal processing complexity. The defects of steel bars, including circular surface defects, internal defects, and uniform damage defects, were thoroughly investigated, respectively, using numerical simulation. The waves were excited and received using the pitch-and-catch technique and the collected monitoring signals were processed using Hilbert transformation to highlight the amplitude and time-of-flight values of the wave signals, which were used for defect identification. In this paper, the reflectivity of guided waves is compared between torsional waves and longitudinal waves, in each case. The impact of defect size changes on damage monitoring is studied and the sensitivity of both the wave frequency and the wave mode (L and T) is also discussed. The results show that the monitoring method based on the torsional wave T (0, 1) is more sensitive to surface defects than the conventional method based on longitudinal waves. The reflectivity of the torsional wave T (0, 1) can be twice that of the longitudinal wave L (0, 1) when the depth of the defect in the circumferential grooves is less than 50% of the diameter of the steel bar. It is more sensitive to shallow surface defects within half of the bar’s radius, and it can also effectively identify defects under the conditions of the uniform damage defects of steel bars, even when the measurements are heavily noise-polluted. This proves the superiority of the torsional guided wave T (0, 1) in defect monitoring and provides a theoretical basis for the application of the torsional guided wave T (0, 1) in actual monitoring. Full article
