The present study introduces an AI (Artificial Intelligence) framework for surface roughness assessment in milling operations through sound signal processing. As industrial demands escalate for in-process quality control solutions, the proposed system leverages audio data to estimate surface finish states without interrupting production. In order to address this, a novel classification approach was developed that maps audio waveform data into predictive indicators of surface quality. In particular, an experimental dataset was employed consisting of sound signals that were captured during milling procedures applying various machining conditions, where each signal was labeled with a corresponding roughness quality obtained via offline metrology. The formulated classification pipeline commences with audio acquisition, resampling, and normalization to ensure consistency across the dataset. These signals are then transformed into Mel-Frequency Cepstral Coefficients (MFCCs), which yield a compact time–frequency representation optimized for human auditory perception. Next, several AI algorithms were trained in order to classify these MFCCs into predefined surface roughness categories. Finally, the results of the work demonstrate that sound signals could contain sufficient discriminatory information enabling a reliable classification of surface finish quality. This approach not only facilitates in-process monitoring but also provides a foundation for intelligent manufacturing systems capable of real-time quality assurance. Full article

The noticeable growth of road transport means that the protection of road infrastructure is becoming a critical issue. The main factor leading to the excessive degradation of roads are overloaded vehicles. The effective elimination of such vehicles from road traffic is possible through widespread usage of Weigh-In-Motion (WIM) systems for direct mass enforcement, thus eliminating the need for “manual” vehicle checks which are currently carried out by the appropriate services. WIM mass enforcement systems require strict metrological control, meaning that an initial verification, conducted at the moment when the system is installed, and subsequent periodic verifications are required. These operations aim to ensure that vehicle weighing error is consistently maintained within a permissible range of values. Fulfilment of this condition allows for the minimisation of the probability that a vehicle loaded within normative limits will be classified as overloaded. The long-term study of two WIM systems located on provincial road 975 in Wielka Wies, in southern Poland, equipped with load sensors made using different technologies (strain gauge sensors and quartz sensors) and in different weather conditions, has allowed us to formulate recommendations regarding the frequency with which subsequent verifications should be performed in order to ensure the reliability of the weighing results. This paper presents the results of these studies and conclusions formulated based on them; in this case, they showed a verification of the system can be performed every 8 months. The conclusions and recommendations that we have presented concern primarily those WIM stations which were the object of our study and caution should be exercised when generalising these to other cases. Its novelty results from several premises. For the first time, long-term studies of two WIM systems equipped with load sensors made with different technologies were carried out. Both systems were installed on the same surface, in the immediate vicinity of each other. They were installed on a standard road and were subjected to the constant impact of road traffic with identical parameters. Tests of both WIM systems were performed periodically, using the pre-weighed vehicles method, in different seasons, for a period of 15 months. During the tests, the same test vehicles drove through both WIM systems at the same speed. All of this resulted in the obtainment of a unique set of measurement data, the analysis of which allowed for the assessment and comparison of the proprieties of the load sensors made with both technologies. Full article

The reliable generation of dissipative Kerr solitons (DKSs) enables applications in communications, metrology, optical clocks, and, more recently, artificial intelligence. We show how single DKS can be generated by Si₃N₄ dual-coupled microring resonators (DCMs). We modeled this coupled structure using the Lugiato–Lefever equation (LLE), including mode interactions in the dispersion profile. We also characterized the pump power and detuning parameter space for several mode interaction strengths and frequencies, and we found parameters for which a DKS could be deterministically obtained using a single, adiabatic frequency sweep with a constant pump power. We demonstrated deterministic single DKS generation for this path by simulating 200 times with different random noise inputs. This result paves the way for reliable, inexpensive, and deterministic single DKS generation in a simple setup. Full article

The amplitude modulation of a pump field and the phase-sensitive detection of a pump-induced intensity change of a probe field encompass a common practice in nonlinear spectroscopies to enhance the detection sensitivity. A drawback of this approach arises when the modulation frequency is comparable to the width of the spectral feature of interest, since the presence of sidebands in the amplitude-modulated pump field provides distortion to the observed spectral lineshape. This represents a problem when accurate measurements of spectral lineshapes and line positions are pursued, as recently happened in our group with the metrology of the Q(1) line in the 1-0 band of molecular hydrogen. The measurement was performed with a Stimulated Raman Scattering spectrometer that was calibrated, for the first time, against an optical frequency comb. In this work, we develop an analytical tool for nonlinear Stimulated Raman spectroscopies that allows us to precisely quantify spectral distortions arising from high-frequency amplitude modulation in one of the interacting fields. Once they are known, spectral distortions can be deconvolved from the measured spectra to retrieve unbiased data. The application of this tool to the measured spectra is discussed. Full article

Density is a crucial parameter for quantitatively describing the physical properties of liquids. It serves as an important indicator for scientific research, production process control, pipeline transportation, and other aspects. In oil pipeline transportation and raw material processing, the real-time online measurement of liquid density is of great significance. This paper analyzes the working principle of an online vibrating tube densitometer and derives the fitting equation for temperature, pressure, and density; it also conducts experiments with an online vibrating tube liquid densitometer and establishes a traceability chain for the experimental device. The experimental setup includes a desktop densitometer system, a multi-temperature field constant-temperature stirring system, a walk-in constant-temperature box, an automatic blowing system, and a frequency acquisition and calculation system. The uncertainty of the device’s evaluation is U = 0.08 kg/m³, k = 2. We built a set of pressure-density static test systems, statically testing the online vibrating tube’s liquid-density meter vibration frequency at different pressures; the whole set of systems can be used to assess the specific density, temperature, and pressure range of online vibrating tube liquid density meters in the experimental research to derive the standard temperature. Through the experimental research, we can accurately derive the fitting coefficients under the standard temperature, specific temperature, and pressure of online vibrating tube liquid densitometers, and calculate the fitting error of online vibrating tube liquid densitometers under different temperatures and pressures within the experimental range through fitting equations and coefficients, so as to realize the practical application of online vibrating tube liquid densitometers in engineering by utilizing straight-tube-type and curved-type online vibrating tube densitometers. A preliminary study was conducted on the effects of different densities, temperatures, and pressures on the vibrating tube system’s vibration cycle. The fit coefficient and error were calculated, and the experimental results were compared to the theoretical analysis to confirm the device’s conformity. The study verified the device’s scientific and reasonable design, and demonstrated that it is feasible to use the device for follow-up research. Using this device in subsequent experiments can verify the effects of viscosity, inlet, installation, and other factors on the online vibrating tube liquid densitometer’s metrological performance. Further experimental research on the pressure–frequency–density test system and the establishment of a wide range of temperatures and pressures within the pressure standard density test system are needed to achieve a wide range of temperatures and pressures under the standard density test. Full article

In this review, we summarize the latest advances in the design of optical frequency-domain reflectometers (OFDRs), digital signal processing, and sensors based on special optical fibers. We discuss state-of-the-art approaches to improving metrological characteristics, such as spatial resolution, SNR, dynamic range, and the accuracy of determining back reflection coefficients. We also analyze the latest achievements in the OFDR-based sensors: the accuracy of spatial localization of the impact, the error in detecting temperatures, deformation, and other quantities, and the features of separate measurement of various physical quantities. We also pay attention to the trend of mutual integration of frequency-domain optical reflectometry methods with time-domain optical reflectometry, which provides completely new sensing possibilities. We believe that this review may be useful to engineers and scientists focused on developing a lab setup, complete measurement instrument, or sensing system with specific requirements. Full article

Absolute distance measurements based on optical frequency combs (OFCs) have greatly promoted advances in both science and technology, owing to the high precision, large non-ambiguity range (NAR), and a high update rate. However, cyclic error, which is extremely difficult to eliminate, reduces the linearity of measurement results. In this study, we quantitatively investigated the impact of cyclic error on absolute distance measurement using OFCs based on two types of interferometry: synthetic wavelength interferometry and single-wavelength interferometry. The numerical calculations indicate that selecting a suitable reference path length can minimize the impact of cyclic error when combining the two types of interferometry. Recommendations for selecting an appropriate synthetic wavelength to address the tradeoff between achieving a large NAR and minimizing the risk of failure when combining the two methods are provided. The results of this study are applicable not only in absolute distance measurements but also in other applications based on OFCs, such as surface profile, vibration analysis, etc. Full article

The aim of this paper is to compare the power measurement capabilities in millimetre- and sub-millimetre-wave frequency bands of several national metrology institutes and one research institute. The first comparison, in WR-6.5 waveguide (110 GHz to 170 GHz), involved NPL, TUBITAK UME and PTB. The second comparison, in WR-1.5 waveguide (500 GHz to 750 GHz), involved NPL, METAS, TUBITAK UME, LNE, WAT, GUM and VDI. Two types of travelling standards were used for these comparisons: a thermoelectric power sensor in the WR-6.5 band and a calorimetric power sensor in the WR-6.5 and WR-1.5 bands. The thermoelectric power sensor was characterised by the participants against their own standards and a generalised effective efficiency was calculated. The calorimetric power sensor operating in the WR-6.5 band was measured to observe its behaviour during the comparison and was also measured in the WR-1.5 band after being fitted with a suitable waveguide taper and used in conjunction with a frequency multiplier. The participants measured the output of the calorimetric power sensor and their own power sensor standard. A normalised power ratio method was used as a comparison parameter for the WR-1.5 band measurements. In addition, a pyroelectric power standard was used by METAS to measure absolute power, and a frequency of 650 GHz was used as a link between the absolute power and the power ratios. Finally, all but two of the measurement points compared between the participants achieved agreement in terms of $\left|E_n\right|$ scores less than 1. For the first time, an interlaboratory comparison of power measurements at sub-millimetre frequencies has been performed and, overall, good agreement was achieved between the different laboratories. Full article

Energy efficiency is an important issue in industry, especially with the ever-increasing consumption of electrical energy. The power quality and the traceability of metering devices are essential when integrating energy metering systems for energy efficiency. This management requires an understanding of electrical current events such as pulse and transient currents. Current transducers are widely used to measure these electrical current events up to a few megahertz. Their use makes it possible to measure not only the main current flowing through the transducer, but also the bypass current that affects electrical equipment. Calibration of these sensors up to a few megahertz then becomes an essential step. Currently, most calibration methods are limited to 100 kHz frequency for a current of 10 A. This paper presents an improvement of a traceable calibration methodology for current transducers up to 10 A and 1 MHz, thus increasing, by 10 times, the current level for such high frequency applications. This calibration methodology is based on a metrological traceability chain (uninterrupted link to the International System of Units) with respect to a calculable current shunt and is currently the only traceable method for calibrating current transducers at 10 A and up to 1 MHz. The uncertainty obtained for the transimpedance ratio is less than 0.2%, which is considerably reduced with respect to the existing capabilities. Full article

In many applications, such as space navigation, metrology, testing, and geodesy, it is necessary to measure accelerations with frequencies ranging from fractions of a hertz to several kilohertz. For this purpose, optomechanical sensors are used. The natural frequency of such sensors should be approximately ten times greater than the frequency of the measured acceleration. In the case of triaxial acceleration measurements, a planar design with two sensors that measure accelerations in two perpendicular in-plane directions and a third sensor that measures out-of-plane acceleration is effective. The mechanical characteristics of the existing designs of both in-plane and out-of-plane types of sensors were analyzed, and the improved designs were elaborated. Using numerical simulation, the dependencies of the natural frequency level in the range from several hertz to tens of kilohertz on the designs and geometric parameters of opto-mechanical accelerometers were modeled. This allows one to select the accelerometer design and its parameters to measure the acceleration at the assigned frequency. It is shown that the opto-mechanical accelerometers of the proposed designs have reduced dissipation losses and crosstalk. Full article

Optical frequency combs have emerged as a new generation of metrological tools, driving advancements in various fields such as free-space two-way time–frequency transfer, low-noise microwave source generation, and gas molecule detection. Among them, fiber combs based on erbium-doped fiber mode-locked lasers have garnered significant attention due to their numerous advantages, including low noise, high system integration, and cost-effectiveness. In this review, we discuss recent developments in erbium-doped fiber combs and analyze the advantages and disadvantages of constructing fiber combs utilizing different erbium-doped mode-locked fiber lasers. First, we provide a brief introduction to the basic principles of optical frequency combs. Then, we explore erbium-doped fiber combs implemented utilizing various mode-locking techniques, such as nonlinear polarization rotation (NPR), real saturable absorber (SA), and nonlinear amplifying loop mirror (NALM). Finally, we present an outlook on the future perspectives of erbium-doped fiber combs. Full article

We investigate the time domain characterization of a coplanar waveguide (CPW) based on an on-chip electro-optic sampling (EOS) system for millimeter waveform metrology. The CPW is fabricated on a thin layer of low-temperature gallium arsenide (LT-GaAs), and the substrate material is GaAs. A femtosecond laser generates and detects ultrashort pulses on the CPW. The forward propagating pulses are simulated using a simplified current source for the femtosecond laser at different positions on the CPW for the first time. Then, the influences of the CPW geometry parameters on the measured pulses are discussed. The varying slot width has larger influences on the amplitude of millimeter wave pulses than the center conductor width and the pumping gap. Finally, in the frequency range of 10 GHz to 500 GHz, the transfer functions calculated by the time domain pulses are in good agreement with the transfer functions calculated by the frequency domain ports. The above results are important for improving the measurement precision of the millimeter waveform on the CPW for millimeter waveform metrology. Full article

Problems related to reducing energy consumption constitute an important basis for scientific research worldwide. A proposal to use various renewable energy sources, including creating a biogas plant, is emphasized in the introduction of this article. However, the indicated solutions require continuous monitoring and control to maximise the installations’ effectiveness. The authors took up the challenge of developing a computer solution to reduce the costs of maintaining technological process monitoring systems. Concept diagrams of a metrological system using multi-sensor techniques containing humidity, temperature and pressure sensors coupled with Electrical Impedance Tomography (EIT) sensors were presented. This approach allows for effective monitoring of the anaerobic fermentation process. The possibility of reducing the energy consumed during installation operation was proposed, which resulted in the development of algorithms for determining alarm states, which are the basis for controlling the frequency of technological process measurements. Implementing the idea required the preparation of measurement infrastructure and an analytical engine based on AI techniques, including an expert system and developed algorithms. Numerous time-consuming studies and experiments have confirmed reduced energy consumption, which can be successfully used in biogas production. Full article

Time and frequency metrology depends on stable oscillators in both radio-frequency and optical domains. With the increased complexity of the highly precise oscillators also came the demand for delivering the oscillators’ harmonic signals between delocalized sites for comparison, aggregation, or other purposes. Besides the traditional optical fiber networks, free-space optical links present an alternative tool for disseminating stable sources’ output. We present a pilot experiment of phase-coherent optical frequency transfer using a free-space optical link testbed. The experiment performed on a 30 m long link demonstrates the phase-noise parameters in a free-space optical channel under atmospheric turbulence conditions, and it studies the impact of active MEMS mirror stabilization of the received optical wave positioning on the resulting transfer’s performance. Our results indicate that a well-configured MEMS mirror beam stabilization significantly enhances fractional frequency stability, achieving the−14th-order level for integration times over 30 s. Full article

For space-based gravitational wave detection, a laser interferometric measurement system composed of a three-spacecraft formation offers the most rewarding bandwidth of astrophysical sources. There are no oscillators available that are stable enough so that each spacecraft could use its own reference frequency. The conversion between reference frequencies and their distribution between all spacecrafts for the synchronization of the different metrology systems is the job of the inter-spacecraft frequency setting strategy, which is important for continuously acquiring scientific data and suppressing measurement noise. We propose a hierarchical optimization algorithm to solve the frequency setting strategy. The optimization objectives are minimum total readout displacement noise and maximum beat-note frequency feasible range. Multiple feasible parameter combinations were obtained for the Taiji program. These optimized parameters include lower and upper bounds of the beat note, sampling frequency, pilot tone signal frequency, ultrastable clock frequencies, and modulation depth. Among the 20 Pareto optimal solutions, the minimum total readout displacement noise was 4.12 $\mathrm{pm}/\sqrt{\mathrm{Hz}}$, and the maximum feasible beat-note frequency range was 23 MHz. By adjusting the upper bound of beat-note frequency and laser power transmitted by the telescope, we explored the effects of these parameters on the minimum total readout displacement noise and optimal local laser power in greater depth. Our results may serve as a reference for the optimal design of laser interferometry system instrument parameters and may ultimately improve the detection performance and continuous detection time of the Taiji program. Full article
