This paper presents results on the preparation of thermoelectric composite materials for flexible and wearable electronics applications. Composite materials in the form of pastes for screen printing or stencil printing were made from a mixture of PEDOT:PSS paste and Bi₂Te₃ powder. The pastes showed good adhesion both to polyimide foil (Kapton) and polyester fabric substrates. Depending on the composition and the substrate used, the pastes had a sheet resistance of 26–264 Ω/sq, a Seebeck coefficient of 14–45 μV/K and a power factor of 0.05–0.8 μW/mK². The obtained pastes enabled the fabrication of textile thermopiles using Ag and PEDOT:PSS/Bi₂Te₃ materials for both arms. The output voltage of the obtained thermopiles on textile and foil substrates was 6–8 mV at a temperature gradient of 100 °C, and the output power was 0.01–0.12 μW. Energy harvesting from the human–ambient temperature gradient using the developed generators yielded promising results, with output voltages around 0.3 mV. Full article

This study demonstrates a high-performance thermopile infrared detector that incorporates a carbon black nanoparticle (CBNP) absorption layer. To overcome the limitations associated with conventional infrared-absorbing materials—including high cost, complex fabrication, and constrained spectral response—a highly porous CBNP thin-film absorption layer was deposited onto the thermopile sensing area using inkjet printing. Combined with an optimized microcavity design, this approach significantly enhances the photothermal conversion efficiency of the device. Experimental results indicate that the detector equipped with the CBNP absorption layer achieves a responsivity of 47.9 V/W and a detectivity of 1.14 × 10⁸ cm·Hz¹/²·W⁻¹. These values represent improvements of 34.55% in responsivity and 34.28% in detectivity, respectively, compared to a reference device without the CBNP layer. This work provides a promising strategy for the development of low-cost yet high-performance infrared detectors. Full article

Thermocouples can be combined into thermopiles to sense heat differences or achieve localized heating and cooling. However, integrating them into textiles using yarns is not straightforward, and chemical methods face challenges like complex processing, poor scalability, and voltage non-uniformity. This study employs conventional weaving to fabricate textile-based thermocouples and thermopiles for wearable sensing and potential cooling applications, with a focus on protective clothing. Using stainless steel and nickel-coated carbon yarns, we demonstrate a more stable thermocouple than those made with chemical or welded methods, with minimal fabric damage. Four conductive yarns, stainless steel, carbon fiber (CF), and nickel-coated carbon fiber (NiFC), were woven and laser-cut to form thermocouples using three different binding types to connect them. Inox1–NiFC was the most efficient thermocouple, achieving the highest Seebeck coefficient of 21.87 µV/K with Binding 3. Binding 3 also reduced contact resistance by 66% across all configurations. Slightly lower but comparable performance was seen with Inox1–NiFC/Binding 2 (21.83 µV/K) and Inox2–NiFC/Binding 1 (15.79 µV/K). In contrast, FC-based thermocouples showed significantly lower Seebeck values: 5.67 µV/K (Inox2–FC/Binding 2), 5.43 µV/K (Inox1–FC/Binding 3), and 5.06 µV/K (Inox2–FC/Binding 1). A woven thermopile with three junctions made with the optimal binding and thermocouple combination generated an average of 55.54 µV/K and about 500 µV at small temperature differences (4–5 °C), with a linear voltage response suitable for sensing. While thermal sensing proved effective, Peltier cooling needs further optimization. This method offers a stable, low-cost, and scalable platform for textile-integrated thermoelectric systems, with strong potential for use in uniforms and other protective garments. Full article

Many patients with major depressive disorder (MDD) feel worse in the morning than in the evening. To clarify the differences in morning physiological characteristics between patients with MDD and healthy participants, a wearable device that measures peripheral wrist skin temperature and heart rate (HR) was adopted. The device incorporates a thermopile sensor to measure peripheral wrist skin temperature using infrared radiation emitted from the skin surface. In total, 30 patients diagnosed with MDD and 24 healthy individuals were recruited. From 00:00 to 12:00, participants wore a wrist-worn device on their non-dominant hand. It was discovered that, at 09:00, the average peripheral wrist skin temperature of patients with MDD was significantly lower (by 0.1% [2.9 °C]) than that of healthy individuals. The dramatic decrease in morning (09:00) peripheral wrist skin temperature in patients with MDD can be attributed to their morning sympathetic surge and peripheral vascular contraction. The average HR of patients with MDD was significantly higher (by 1% [17 beats/min]) than that of healthy controls. Regression analysis, including peripheral wrist skin temperature and HR at 09:00, showed 83.3% sensitivity and a negative predictive value of 76.2%. The potential impact of these results appears promising for future preliminary morning MDD screening. Full article

Polysilicon is widely used as a thermoelectric material due to its CMOS compatibility and tunability through doping. The accurate measurement of the thermoelectric parameters—such as the Seebeck coefficient, thermal conductivity, and electrical resistivity—of polysilicon with various doping conditions is essential for designing and fabricating high-performance thermopile sensors. This work presents an all-in-one testing chip that incorporates double-layer thermoelectric structures on a suspended membrane-based supporting layer, with polysilicon constituting at least one of these thermoelectric layers. By employing a differential calculation approach in conjunction with thermal imaging methods, we could simultaneously measure various thermoelectric parameters—including resistivity, the Seebeck coefficient, and thermal conductivity—of polysilicon under different doping conditions. Furthermore, the method proposed in this study provides a means for accurately obtaining thermoelectric parameters for other materials, thereby facilitating the design and optimization of thermoelectric devices. Full article

Thermopile sensor arrays provide a sufficient counterbalance between person detection and localization while preserving privacy through low resolution. The latter is especially important in the context of smart building automation applications. Current research has shown that there are two machine learning-based algorithms that are particularly prominent for general object detection: You Only Look Once (YOLOv5) and Detection Transformer (DETR). Over the course of this paper, both algorithms are adapted to localize people in 32 × 32-pixel thermal array images. The drawbacks in precision due to the sparse amount of labeled data were counteracted with a novel generative image generator (IIG). This generator creates synthetic thermal frames from the sparse amount of available labeled data. Multiple robustness tests were performed during the evaluation process to determine the overall usability of the aforementioned algorithms as well as the advantage of the image generator. Both algorithms provide a high mean average precision (mAP) exceeding 98%. They also prove to be robust against disturbances of warm air streams, sun radiation, the replacement of the sensor with an equal type sensor, new persons, cold objects, movements along the image frame border and people standing still. However, the precision decreases for persons wearing thick layers of clothes, such as winter clothing, or in scenarios where the number of present persons exceeds the number of persons the algorithm was trained on. In summary, both algorithms are suitable for detection and localization purposes, although YOLOv5m has the advantage in real-time image processing capabilities, accompanied by a smaller model size and slightly higher precision. Full article

The accurate measurement of cooking vessel temperatures in induction hobs is crucial for ensuring optimal cooking performance and safety. To achieve this, improvements in existing measurement methods such as thermocouples, thermistors, and infrared (IR) temperature sensors are being explored. However, traditional IR sensors are sensitive to interference from the heated glass ceramic, severely affecting accuracy. This challenge is addressed by introducing a new sensor system with an optical filter designed to match the glass ceramic’s optical characteristics. The theoretical model presented here proposes the separation of the total radiation reaching the IR sensor into components emitted by the cooking vessel and the glass ceramic. However, the radiation component originating from the glass ceramic mentioned here is significantly higher than the radiation component of the cooking vessel, which creates difficulties in measuring the temperature of the cooking vessel. Simulations and real cooking experiments validate the model and demonstrate that the optic filter significantly increases the contribution of pot radiation to the sensor measurement. This causes a more accurate reflection of the actual cooking vessel temperature, leading to improved temperature control and enhanced cooking experiences in domestic induction hob appliances. This research contributes to the field by innovatively addressing challenges in real-time temperature control for induction cooking appliances. The elimination of pot dependence and improved accuracy have significant implications for cooking efficiency, safety and food quality. Full article

Uncooled infrared (IR) sensors, including bolometers, thermopiles, and pyroelectrics, have traditionally dominated the market. Nevertheless, a new innovative technology, dubbed the TMOS sensor, has emerged. It is based on CMOS-SOI-MEMS (complementary-metal-oxide-semiconductor silicon-on-insulator micro-electromechanical systems) fabrication. This pioneering technology utilizes a suspended, micro-machined, thermally insulated transistor to directly convert absorbed infrared radiation into an electrical signal. The miniaturization of IR sensors, including the TMOS, is crucial for seamless integration into wearable and mobile technologies. However, this presents a significant challenge: balancing size reduction with sensor sensitivity. Smaller sensor footprints can often lead to decreased signal capture and, consequently, diminished performance. Metamaterial advancements offer a promising solution to this challenge. These engineered materials exhibit unique electromagnetic properties that can potentially boost sensor sensitivity while enabling miniaturization. The strategic integration of metamaterials into sensor design offers a pathway towards compact, high-sensitivity IR systems with diverse applications. This study explores the impact of electro-optical metal-insulator-metal (MIM) metamaterial absorbers on the thermal and electro-optical characteristics of CMOS-SOI-MEMS sensors in the mid-IR region. We target the key thermal properties critical to IR sensor performance: thermal conductance (Gth), thermal capacitance (Cth), and thermal time constant (τth). This study shows how material selection, layer thickness, and metamaterial geometry fill-factor affect the sensor’s thermal performance. An analytical thermal model is employed alongside 3D finite element software for precise numerical simulations. Full article

Colorimetric temperature measurement is an essential technique in radiometric thermometry. Traditional colorimetric methods determine temperature by comparing the ratio of radiative energies within two narrow bands at specific wavelengths, effectively mitigating the effects of the emissivity of the measured object and ambient conditions. However, these methods typically approximate integration using area calculations when calculating radiative energy. This article eliminates this approximation and calculates the radiative energy with accurate integration. Based on the principle of monotonicity, this article demonstrates for the first time that when two narrow-band infrared radiations are selected, as long as their wavelength ranges do not overlap, the ratio of radiative energies within these bands maintains a monotonic relationship with the measured temperature. This allows the temperature to be inferred from the energy ratio. Furthermore, this conclusion is extended to arbitrary widths of bands as long as their wavelength ranges do not overlap. Building on this foundation, a thermopile-based colorimetric temperature measurement method for arbitrary bandwidth is proposed. Simulation experiments validate this method, showing that the energy ratio maintains a monotonic relationship with the measured temperature as long as the infrared radiation wavelength ranges absorbed by the thermopile do not overlap. The simulation results are consistent with the mathematical proof. Full article

A carbon dioxide (CO₂) gas sensor based on non-dispersive infrared (NDIR) technology has been developed and is suitable for use in portable devices for high-precision CO₂ detection. The NDIR gas sensor comprises a MEMS infrared emitter, a MEMS thermopile detector with an integrated optical filter, and a compact gas cell with high optical coupling efficiency. A dual-ellipsoid mirror optical system was designed, and based on optical simulation analysis, the structure of the dual-ellipsoid reflective gas chamber was designed and optimized, achieving a coupling efficiency of up to 54%. Optical and thermal simulations were conducted to design the sensor structure, considering thermal management and light analysis. By optimizing the gas cell structure and conditioning circuit, we effectively reduced the sensor’s baseline noise, enhancing the overall reliability and stability of the system. The sensor’s dimensions were 20 mm × 10 mm × 4 mm (L × W × H), only 15% of the size of traditional NDIR gas sensors with equivalent detection resolution. The developed sensor offers high sensitivity and low noise, with a sensitivity of 15 μV/ppm, a detection limit of 90 ppm, and a resolution of 30 ppm. The total power consumption of the whole sensor system is 6.5 mW, with a maximum power consumption of only 90 mW. Full article

We present an optimized version of the skin calorimeter for measuring localized skin thermal responses during physical activity. Enhancements include a new holding system, more sensitive thermopiles, and an upgraded spiked heat sink for improved efficiency. In addition, we used a new, improved calorimetric model that takes into account all the variables that influence the measurement process. Resolution in power measurement is 1 mW. Performance tests under air currents and movement disturbances showed that the device maintains high accuracy; the deviation produced by these significant disturbances is less than 5%. Human subject tests, both at rest and during exercise, confirmed its ability to accurately measure localized skin heat flux, heat capacity, and thermal resistance (less than 5% uncertainty). These findings highlight the calorimeter’s potential for applications in sports medicine and physiological studies. Full article

Accurate knowledge of solar radiation data or its estimation is crucial to maximize the benefits derived from the Sun. In this context, many sectors are re-evaluating their investments and plans to increase profit margins in line with sustainable development based on knowledge and estimation of solar radiation. This scenario has drawn the attention of researchers to the estimation and measurement of solar radiation with a low level of error. Various types of models, such as empirical models, time series, artificial intelligence algorithms and hybrid models, for estimating and measuring solar radiation have been continuously developed in the literature. In general, these models require atmospheric, geographical, climatic and historical solar radiation data from a specific region for accurate estimation. Each analysis model has its advantages and disadvantages when it comes to estimating solar radiation and, depending on the model, the results for one region may be better or worse than for another. Furthermore, it has been observed that an input parameter that significantly improves the model’s performance in one region can make it difficult to succeed in another. The research gaps, challenges and future directions in terms of solar radiation estimation have substantial impacts, but regardless of the model, in situ measurements and commercially available equipment consistently influence solar radiation calculations and, subsequently, simulations or estimates. This article aims to exemplify, through a case study in a multi-family residential building located in Viana do Castelo, a city in the north of Portugal, the difficulties of capturing the spectrum of radiations that make up the total radiation that reaches the measuring equipment or site. Three pieces of equipment are used—a silicon pyranometer, a thermopile pyranometer and a solar meter—on the same day, in the same place, under the same meteorological conditions and with the same measurement method. It is found that the thermopile pyranometer has superior behavior, as it does not oscillate as much with external factors such as the ambient temperature, which influence the other two pieces of equipment. However, due to the different assumptions of the measurement models, the various components of the measurement site make it difficult to obtain the most accurate and reliable results in most studies. Despite the advantages of each model, measurement models have gained prominence in terms of the ease of use and low operating costs rather than the rigor of their results. Full article

Contactless and label-free detection of urea content in aqueous solutions is of great interest in chemical, biomedical, industrial, and automotive applications. In this work, we demonstrate a compact and low-cost instrumental configuration for label-free, reagent-free, and contactless detection of urea dissolved in water, which exploits the absorption properties of urea in the near-infrared wavelength region. The intensity of the radiation transmitted through the fluid under test, contained in a rectangle hollow glass tubing with an optical pathlength of 1 mm, is detected in two spectral bands. Two low-cost, low-power LEDs with emission spectra centered at λ = 1450 nm and λ = 2350 nm are used as readout sources. The photodetector is positioned on the other side of the tubing, in front of the LEDs. The detection performances of a photodiode and of a thermal optical power detector have been compared, exploiting different approaches for LED driving current modulation and photodetected signal processing. The implemented detection system has been tested on urea–water solutions with urea concentrations from 0 up to 525 mg/mL as well as on two samples of commercial diesel exhaust fluid (“AdBlue™”). Considering the transmitted intensity in presence of the urea–water solution, at λ = 1450 nm and λ = 2350 nm, normalized to the transmitted intensity in presence of water, we demonstrate that their ratio is linearly related to urea concentration on a wide range and with good sensitivity. Full article

As greenhouse gas emissions from dairy farms are on the rise, effective monitoring of these emissions has emerged as a crucial tool for assessing their environmental impacts and promoting sustainable development. Most of the existing studies on GHGs from dairy farms involve stationary detections with long response times and high costs. In this study, a greenhouse gas detection system was constructed based on NDIR technology using a single broadband light source and a four-channel thermopile detector for the detection of CH₄, N₂O, and CO₂; the detection range of CH₄ was 0~100 ppm; that of N₂O was 0~500 ppm; and that of CO₂ was 0~20%. After the concentration calibration, the cross-interference between the gas measurement channels was studied, and the least-squares method was used to correct the interference between the three gases. The experimental results showed that the full-range deviation of the detection device was lower than 0.81%, the repeatability was lower than 0.39%, the stability was lower than 0.61%, and the response time was lower than 10 s. This study also carried out on-site testing in Luoyang Shengsheng Ranch (Luoyang, China), and the results show that the error between this device and the PTM600 portable gas analyzer is within 9.78%, and the dynamic response time of this device is within 16 s, at which point the content of greenhouse gases in dairy farms can be measured quickly and accurately. The objective of this study is to enhance the precision and effectiveness of greenhouse gas (GHG) emissions monitoring from dairy farms, thereby contributing to environmental protection and sustainable development goals. By achieving this, we aim to facilitate societal progress towards a greener and low-carbon future. Full article

This paper presents an innovative approach to the integration of thermoelectric microgenerators (μTEGs) based on thick-film thermopiles of planar constantan–silver (CuNi-Ag) and calcium cobaltite oxide–silver (Ca₃Co₄O₉-Ag) thick-film thermopiles with radio frequency identification (RFID) technology. The goal was to consider using the TEG for an active or semi-passive RFID tag. The proposed implementation would allow the communication distance to be increased or even operated without changing batteries. This article discusses the principles of planar thermoelectric microgenerators (μTEGs), focusing on their ability to convert the temperature difference into electrical energy. The concept of integration with active or semi-passive tags is presented, as well as the results of energy efficiency tests, considering various environmental conditions. On the basis of the measurements, the parameters of thermopiles consisting of more thermocouples were simulated to provide the required voltage and power for cooperation with RFID tags. The conclusions of the research indicate promising prospects for the integration of planar thermoelectric microgenerators with RFID technology, opening the way to more sustainable and efficient monitoring and identification systems. Our work provides the theoretical basis and practical experimental data for the further development and implementation of this innovative technology. Full article
