This research investigates resonator width optimization for simultaneously enhancing electrical performance and mechanical reliability in wideband RF MEMS filters through systematic evaluation of three configurations: 0% (L1), 60% (L2), and 100% (L3) matching ratios between cap and bottom wafers using Au-Au thermocompression bonding. The study demonstrates that resonator width alignment significantly influences both electromagnetic field coupling and bonding interface integrity. The L3 configuration with complete width matching achieved optimal RF performance, demonstrating 3.34 dB insertion loss across 4.5 GHz bandwidth (25% fractional bandwidth), outperforming L2 (3.56 dB) and L1 (3.10 dB), while providing enhanced electromagnetic wave coupling and minimized contact resistance. Mechanical reliability testing revealed superior bonding strength for the L3 configuration, withstanding up to 7.14 Kgf in shear pull tests, significantly exceeding L1 (4.22 Kgf) and L2 (2.24 Kgf). SEM analysis confirmed uniform bonding interfaces with minimal void formation (~180 nm), while Q-factor measurements showed L3 achieved optimal loaded Q-factor (Q_L = 3.31) suitable for wideband operation. Comprehensive environmental testing, including thermal cycling (−50 °C to +145 °C) and humidity exposure per MIL-STD-810E standards, validated long-term stability across all configurations. This investigation establishes that complete resonator width matching between cap and bottom wafers optimizes both electromagnetic performance and mechanical bonding reliability, providing a validated framework for developing high-performance, reliable RF MEMS devices for next-generation communication, radar, and sensing applications. Full article

In recent years, the building insulation layer peeling caused by quality problems has brought about safety hazards to human life. Existing means of non-destructive testing of building insulation layers, including laser scanning, infrared thermal imaging, ultrasonic testing, acoustic emission, ground-penetrating radar, etc., are unable to simultaneously guarantee the detection depth and resolution of the insulation layer defects, not to mention high-precision imaging of the insulation layer structure. A new type of high-precision imaging radar is specifically designed for the quantitative quality inspection of external building insulation layers in this paper. The center frequency of the radar is 8800 MHz and the −10 dB bandwidth is 3100 MHz, which means it can penetrate the insulated panel not less than 48.4 mm thick and catch the reflected wave from the upper surface of the bonding mortar. When the bonding mortar is 120 mm away from the radar, the radar can achieve a lateral resolution of about 45 mm (capable of distinguishing two parties of bonding mortar with a 45 mm gap). Furthermore, an ultra-wideband high-bunching antenna is designed in this paper combining the lens and the sinusoidal antenna, taking into account the advantages of high directivity and ultra-wideband. Finally, the high-precision imaging of data collected from multiple survey lines can visually reveal the distribution of bonded mortar and the bonding area. This helps determine whether the bonding area meets construction standards and provides data support for evaluating the quality of the insulation layer. Full article

This study proposes an occupant-centric control strategy for residential heating systems, aiming to enhance thermal comfort and reduce energy consumption. A sensor station utilizing a frequency-modulated continuous wave radar sensor was developed to detect occupancy and infer activities within residential spaces. By analyzing field measurement data, schedules for occupancy and activities were established. These schedules were then used to implement a variable control strategy for the hydronic radiant heating system, adjusting its operating characteristics based on the identified activities. The proposed control strategy, which includes resetting the indoor set temperature during unoccupied periods and adjusting it during sleep to account for changes in metabolic rate and clothing insulation, resulted in significant energy savings. Compared to continuous operation, the hydronic radiant heating system’s energy consumption was reduced by approximately 21% on peak load days and up to 34% over three winter months. This study demonstrates the potential of occupant-centric control for achieving substantial energy savings in residential buildings while maintaining occupant thermal comfort. Full article

Intelligent and diversified development of modern detection technology greatly affects the battlefield survivability of military targets, especially infrared, acoustic wave, and radar detection expose targets by capturing their unavoidable infrared radiation, acoustic wave, and electromagnetic wave information, greatly affecting their battlefield survival and penetration capabilities. Therefore, there is an urgent need to develop stealth-protective materials that can suppress infrared radiation, reduce acoustic characteristics, and weaken electromagnetic signals. Fibrous three-dimensional porous materials, with their high porosity, excellent structural adjustability, and superior mechanical properties, possess strong potential for development in the field of stealth protection. This article introduced and reviewed the characteristics and development process of fibrous three-dimensional porous materials at both the micrometer and nanometer scales. Then, the process and characteristics of preparing fibrous three-dimensional porous materials through vacuum forming, gel solidification, freeze-casting, and impregnation stacking methods were analyzed and discussed. Meanwhile, their current application status in infrared, acoustic wave, and radar stealth fields was summarized and their existing problems and development trends in these areas from the perspectives of preparation processes and applicability were analyzed. Finally, several prospects for the current challenges faced by fibrous three-dimensional porous materials were proposed as follows: functionally modifying fibers to enhance their applicability through self-cross-linking; establishing theoretical models for the transmission of thermal energy, acoustic waves, and electromagnetic waves within fibrous porous materials; constructing fibrous porous materials resistant to impact, shear, and fracture to meet the needs of practical applications; developing multifunctional stealth fibrous porous materials to confer full-spectrum broadband stealth capability; and exploring the relationship between material size and mechanical properties as a basis for preparing large-scale samples that meet the application’s requirement. This review is very timely and aims to focus researchers’ attention on the importance and research progress of fibrous porous materials in the field of stealth protection, so as to solve the problems and challenges of fibrous porous materials in the field of stealth protection and to promote the further innovation of fibrous porous materials in terms of structure and function. Full article

Most advances in the remote sensing of floating marine plastic litter have been made using passive remote-sensing techniques in the visible (VIS) to short-wave-infrared (SWIR) parts of the electromagnetic spectrum based on the spectral absorption features of plastic surfaces. In this paper, we present developments of new and emerging remote-sensing technologies of marine plastic litter such as passive techniques: fluid lensing, multi-angle polarimetry, and thermal infrared sensing (TIS); and active techniques: light detection and ranging (LiDAR), multispectral imaging detection and active reflectance (MiDAR), and radio detection and ranging (RADAR). Our review of the detection capabilities and limitations of the different sensing technologies shows that each has their own weaknesses and strengths, and that there is not one single sensing technique that applies to all kinds of marine litter under every different condition in the aquatic environment. Rather, we should focus on the synergy between different technologies to detect marine plastic litter and potentially the use of proxies to estimate its presence. Therefore, in addition to further developing remote-sensing techniques, more research is needed in the composition of marine litter and the relationships between marine plastic litter and their proxies. In this paper, we propose a common vocabulary to help the community to translate concepts among different disciplines and techniques. Full article

Polymer materials with a low dielectric constant and low dielectric loss have the potential to be applied to high-frequency signal transmissions, such as mobile phone antennas and millimeter wave radars. Two types of diamines, 4,4′-diamino-p-tetraphenyl (DPT) and crown ether diamine (CED), were prepared for ternary copolymerization with BPDA in this study. Cross-links with molecular chains were formed, increasing molecular chain distance by utilizing rings of CED. The MPI films exhibit a good thermal performance with the increase in CED addition, with Tg > 380 °C and CTE from −4 × 10⁻⁶ K⁻¹ to 5 × 10⁻⁶ K⁻¹. The Young’s modulus can reach 8.6 GPa, and the tensile strength is above 200 MPa when 5% and 7% CED are introduced. These MPI films exhibit good mechanical performances. The dielectric constant of PI−10% film can go as low as 3.17. Meanwhile, the relationship between dielectric properties and molecular structure has been demonstrated by Molecular Simulation (MS). PI molecules are separated by low dielectric groups, resulting in a decrease in the dielectric constant. Full article

A space-borne remote sensing method was applied, validated, and demonstrated in a case study on the Samuel de Champlain Bridge in Montreal, Canada. High-resolution C-band radar satellite imagery was analyzed using the Persistent Scatterer Interferometric Synthetic Aperture Radar technique to derive bridge displacements and compare them against theoretical estimates. Multispectral and long-wave thermal infrared satellite imagery acquired during the InSAR observation period and historical environmental data were analyzed to provide context for the interpretation and understanding of InSAR results. Thermal deformation measurements compared well with their theoretical estimates based on known bridge geometry and ambient temperature data. Non-thermal deformation measurements gave no evidence of settlement during the 2-year monitoring period, as would normally be expected for a newly constructed bridge with its foundation on bedrock. The availability of environmental data obtained from multispectral and thermal infrared satellite imagery was found to be useful in providing context for the bridge stability assessment. Ambient temperature measurements from thermal infrared satellite imagery were found to be a suitable alternative in cases where data from in situ temperature sensors or nearby weather stations are not available or not fit for purpose. No strong correlation was found between the river conditions and bridge deformation results from the InSAR analysis; this is partly due to the fact that most of these effects act along the river flow in the north–south direction, to which the satellite sensor is not sensitive. Full article

The micro-physical characteristics of a typical sea of clouds process in Jiuxian Mountain are investigated by comprehensively analyzing parameters that delineate the micro-physical characteristics of clouds and atmospheric stratification based on data from a cloud radar, wind profiler, meteorological gradient observation in high mountains, and other observations. The results show that water vapor condenses into cloud particles via an entrained and mixing process accompanied by an updraft originating from orographic uplift. During the thickening stage of the sea of clouds, atmospheric motion within the clouds is featured as “downdraft on the top—updraft on the bottom”. The zero vertical velocity area is located closely to the maximum of liquid water content. The thermal inversion layer is formed during the maintenance stage; however, the enhancement of inversion on the cloud top could suppress updraft in areas with a high liquid water content. The values mainly concentrate on the cloud top, and repetitively lifting and falling processes caused by the atmospheric upward and downward motion are in favor of the coalescence growth of cloud particles, which result in the persistence of strong radar echo. At the dissipation stage, warming on the cloud top is greater than that on the cloud bottom due to the short-wave absorption of clouds as the solar radiation enhances. As a result, the inversion layer thickens and elevates, evaporation caused by heating outweighs the condensation caused by cooling, a strong radar echo band descends from the top to the middle part of clouds, a sea of clouds dissipates gradually as cloud particles evaporates, and the particle size and concentration number of cloud particles decrease simultaneously. Full article

During the COVID-19 pandemic, the number of cases continued to rise. As a result, there was a growing demand for alternative control methods to traditional buttons or touch screens. However, most current gesture recognition technologies rely on machine vision methods. However, this method can lead to suboptimal recognition results, especially in situations where the camera is operating in low-light conditions or encounters complex backgrounds. This study introduces an innovative gesture recognition system for large movements that uses a combination of millimeter wave radar and a thermal imager, where the multi-color conversion algorithm is used to improve palm recognition on the thermal imager together with deep learning approaches to improve its accuracy. While the user performs gestures, the mmWave radar captures point cloud information, which is then analyzed through neural network model inference. It also integrates thermal imaging and palm recognition to effectively track and monitor hand movements on the screen. The results suggest that this combined method significantly improves accuracy, reaching a rate of over 80%. Full article

We present multi-sensor measurements from satellites, unmanned aerial vehicle, marine radar, thermal profilers, and repeated conductivity–temperature–depth casts made in the Kara Gates strait connecting the Barents and the Kara Seas during spring tide in August 2021. Analysis of the field data during an 18-h period from four stations provides evidence that a complex sill in the Kara Gates is the site of regular production of intense large-amplitude nonlinear internal waves. Satellite data show a presence of a relatively warm northeastward surface current from the Barents Sea toward the Kara Sea attaining 0.8–0.9 m/s. Triangle-shaped measurements using three thermal profilers revealed pronounced vertical thermocline oscillations up to 40 m associated with propagation of short-period nonlinear internal waves of depression generated by stratified flow passing a system of shallow sills in the strait. The most intense waves were recorded during the ebb tide slackening and reversal when the background flow was predominantly supercritical. Observed internal waves had wavelengths of ~100 m and traveled northeastward with phase speeds of 0.8–0.9 m/s. The total internal wave energy per unit crest length for the largest waves was estimated to be equal to 1.0–1.8 MJ/m. Full article

Composite thin film absorbers show superior performance and have a wide range of applications. Obtaining a broadband composite thin film absorber is a challenge. In this work, we proposed a modeling of a broadband microwave composite thin film absorber based on the impedance matching theory and equivalent circuit model of the square loop. The unit cell of the absorber was composed of metal square loops with high magnetic conductivity deposited on the polyethylene substrate, and an FR-4 (epoxy glass cloth) substrate was the spacer substrate layer. The simulation results show that the absorptivity of the absorber reached more than 90% in the frequency range of 8.7–18 GHz for TE and TM waves under normal incidence. The thickness of the designed absorber was 2.05 mm (0.059 λ_max, λ_max corresponds to the maximum absorption wavelength). The simulation results show that the energy distribution in the proposed absorber was mainly localized in the top metal FSS layer due to the ohmic loss of metal, and the dielectric loss played a small role in the absorption of the absorber. Our work provides a design approach to improve the efficiency of optoelectronic devices and thermal detectors and has application prospects in radar and aircraft stealth applications. Full article

Polymer matrix wave transparent composites are used in a variety of high-speed communication applications. One of the applications of these involves making protective enclosures for antennas of microwave towers, air vehicles, weather radars, and underwater communication devices. Material performance, structural, thermal, and mechanical degradation are matters of concern as advanced wireless communication needs robust materials for radomes that can withstand mechanical and thermal stresses. These polymer composite radomes are installed externally on antennas and are exposed directly to ambient as well as severe conditions. In this research, epoxy resin was reinforced with a small amount of quartz fibers to yield an improved composite radome material compared to a pure epoxy composite with better thermal and mechanical properties. FTIR spectra, SEM morphology, dielectric constant (Ɛ_r) and dielectric loss (δ), thermal degradation (weight loss), and mechanical properties were determined. Compared to pure epoxy, the lowest values of Ɛ_r and δ were 3.26 and 0.021 with 30 wt.% quartz fibers in the composite, while 40% less weight loss was observed which shows its better thermal stability. The mechanical characteristics encompassing tensile and bending strength were improved by 42.8% and 48.3%. In high-speed communication applications, compared to a pure epoxy composite, adding only a small quantity of quartz fiber can improve the composite material’s dielectric performance, durability, and thermal and mechanical strength. Full article

The typical diurnal variability of tropospheric winds over West Sumatra and their changes associated with El Niño Southern Oscillation, Quasi-Biennial Oscillation, Madden–Julian Oscillations and convectively coupled Kelvin waves during the extended boreal winter season are investigated based on nineteen years of observations from Equatorial Atmosphere Radar in Kototabang, Indonesia. Sub-diurnal wind variability is assessed based on the amplitude and phase of the diurnal (24 h) and semidiurnal (12 h) modes.The results show that composite diurnal variability is dominated by cloud-induced circulation and thermal tides. Although these sub-diurnal modes do not change the daily mean wind direction, they modulate velocities throughout the day. Typical diurnal evolution of the vertical wind component is consistent with changes in the latent heating profiles associated with the evolution of a cloud field from cumulus before noon to deep convection in the afternoon and stratiform clouds in the evening. El Niño Southern Oscillation and Quasi-Biennial Oscillation affect the mean tropospheric winds, throughout the troposphere and above 250 hPa, respectively, but do not affect sub-diurnal amplitudes. Eastward propagating Madden–Julian Oscillations and convectively coupled Kelvin waves impact both the mean and sub-diurnal tropospheric wind variability. Both horizontal and vertical winds show the largest variability in the lower and mid troposphere (below 400 hPa). The observed variability in the vertical wind component highlights that large-scale phenomena interact with both the local evolution and progression of a cloud field through dynamical feedback. Full article

The composites of expanded graphite (EG) and magnetic particles have good electromagnetic wave attenuation properties in the centimeter band, which is valuable in the field of radar wave interference. In this paper, a novel preparation method of Ni–Zn ferrite intercalated EG (NZF/EG) is provided in order to promote the insertion of Ni–Zn ferrite particles (NZF) into the interlayers of EG. The NZF/EG composite is in situ prepared via thermal treatment of Ni–Zn ferrite precursor intercalated graphite (NZFP/GICs) at 900 °C, where NZFP/GICs is obtained through chemical coprecipitation. The morphology and phase characterization demonstrate the successful cation intercalation and NZF generation in the interlayers of EG. Furthermore, the molecular dynamics simulation shows that the magnetic particles in the EG layers tend to disperse on the EG layers rather than aggregate into larger clusters under the synergy of van der Waals forces, repulsive force, and dragging force. The radar wave attenuation mechanism and performance of NZF/EG with different NZF ratios are analyzed and discussed in the range of 2–18 GHz. The NZF/EG with the NZF ratio at 0.5 shows the best radar wave attenuation ability due to the fact that the dielectric property of the graphite layers is well retained while the area of the heterogeneous interface is increased. Therefore, the as-prepared NZF/EG composites have potential application value in attenuating radar centimeter waves. Full article

The existing formulas for the synthetic aperture radar (SAR) Doppler centroid estimation standard deviation (STD) suffer from various limitations, especially for a dynamic sea surface. In this study, we derive an improved version of these formulas through three steps. First, by considering the ocean wavenumber spectrum information, a new strategy for determining the number of independent samples of the sea wave velocity field is adopted in the new formula. This is contrary to the method used in the existing formulas, where the number of SAR geometric resolution cells is taken as the number of samples assuming that adjacent SAR resolution cells are statistically uncorrelated. Second, the pulse repetition frequency and Doppler bandwidth are decoupled in the new formula, unlike in the existing formulas where they are unchangeably related to each other. Third, the effects of thermal noise and Doppler aliasing are jointly quantified in a mathematically exact manner instead of being treated separately, as in the existing formulas. Comprehensive SAR raw data simulations for the ocean surface show that the new formula has a better performance in predicting the Doppler centroid estimation STD than the existing formulas. Full article
