Search Results (247)

This study presents colorless polyimides (PIs) suitable for use as plastic substrates in flexible displays, designed to be compatible with controlled soft adhesion and easy delamination (temporary adhesion) processes. For this purpose, we focused on a PI system derived from norbornane-2-spiro-α-cyclopentanone-α′-spiro-2″-norbornane-5,5″,6,6″-tetracarboxylic dianhydride (CpODA) and 2,2′-bis(trifluoromethyl)benzidine (TFMB). This system was selected with the aim of exhibiting excellent optical transparency and low linear coefficient of thermal expansion (CTE) properties. However, fabricating this PI film via the conventional two-step process was challenging because of crack formation. In contrast, modified one-pot polymerization at 200 °C using a combined catalyst resulted in a homogeneous solution of PI with an exceptionally high molecular weight, yielding a flexible cast film. The solubility of PI plays a crucial role in its success. This study delves into the mechanism behind the significant catalytic effect on enhancing molecular weight. The CpODA/TFMB PI cast film simultaneously achieved very high optical transparency, an extremely high glass transition temperature (T_g = 411 °C), a significantly low linear coefficient of thermal expansion (CTE = 16.7 ppm/K), and sufficient film toughness, despite the trade-off between low CTE and high film toughness. The CpODA/TFMB system was modified by copolymerization with minor contents of another cycloaliphatic tetracarboxylic dianhydride, 5,5′-(1,4-phenylene)-exo-bis(hexahydro-4,7-methanoisobenzofuran-cis-exo-1,3-dione) (BzDAxx). This approach was effective in improving the film toughness without sacrificing the low CTE and other target properties. The peel strengths (σ_peel) of laminates comprising surface-modified glass substrates and various colorless PI films were measured to evaluate the compatibility with the temporary adhesion process. Most colorless PI films studied were found to be incompatible. Additionally, no correlation between σ_peel and PI structure was observed, making it challenging to identify the structural factors influencing σ_peel control. Surprisingly, a strong correlation was observed between σ_peel and CTE of the PI films, suggesting that the observed solid–solid lamination is closely linked to the unexpectedly high surface mobility of the PI films. The laminate using CpODA(90);BzDAxx(10)/TFMB copolymer exhibited suitable adhesion strength for the temporary adhesion process, while meeting other target properties. The modified one-pot polymerization method significantly contributed to the development of colorless PIs suitable for plastic substrates. Full article

High-Bandwidth Memory (HBM) enables the bandwidth required by modern AI and high-performance computing, yet its three dimensional stack traps heat and amplifies thermo mechanical stress. We first review how conventional solutions such as heat spreaders, microchannels, high density Through-Silicon Vias (TSVs), and Mass Reflow Molded Underfill (MR MUF) underfills lower but do not eliminate the internal thermal resistance that rises sharply beyond 12layer stacks. We then synthesize recent hybrid bonding studies, showing that an optimized Cu pad density, interface characteristic, and mechanical treatments can cut junction-to-junction thermal resistance by between 22.8% and 47%, raise vertical thermal conductivity by up to three times, and shrink the stack height by more than 15%. A meta-analysis identifies design thresholds such as at least 20% Cu coverage that balances heat flow, interfacial stress, and reliability. The review next traces the chain from Coefficient of Thermal Expansion (CTE) mismatch to Cu protrusion, delamination, and warpage and classifies mitigation strategies into (i) material selection including SiCN dielectrics, nano twinned Cu, and polymer composites, (ii) process technologies such as sub-200 °C plasma-activated bonding and Chemical Mechanical Polishing (CMP) anneal co-optimization, and (iii) the structural design, including staggered stack and filleted corners. Integrating these levers suppresses stress hotspots and extends fatigue life in more than 16layer stacks. Finally, we outline a research roadmap combining a multiscale simulation with high layer prototyping to co-optimize thermal, mechanical, and electrical metrics for next-generation 20-layer HBM. Full article

The development of thermoelectric modules based on skutterudite materials requires stable, low-resistance interfaces between segments operating at different temperature ranges. This study investigates the microstructure, thermoelectric performance, and thermal stability of the following two joints: In_0.4Co₄Sb₁₂/Co₄Sb_10.8Te_0.6Se_0.6 (n-type) and CeFe₃Co_0.5Ni_0.5Sb₁₂/In_0.25Co₃FeSb₁₂ (p-type), fabricated by pulse plasma sintering (PPS). Scanning electron microscopy (SEM) and energy-dispersive spectroscopy (EDS) analyses confirmed the formation of well-bonded interfaces without pores or cracks. Aging at 773 K for 168 h did not result in morphological or chemical degradation, and phase composition remained unchanged according to X-ray diffraction (XRD). Surface Seebeck coefficient mapping and contact resistance measurements showed negligible changes after annealing, confirming electrical stability. To provide context for potential applications, theoretical energy conversion efficiencies were estimated based on measured thermoelectric properties, yielding 13.2% and 10.1% for the n- and p-type segmented legs, respectively. Additionally, measured coefficients of thermal expansion (CTE) indicated low mismatch between jointed materials, supporting good mechanical compatibility. The results demonstrate that the selected material combinations are thermally, chemically, and electrically stable and can be effectively used in segmented thermoelectric legs for intermediate-temperature applications. Full article

This research investigates whether metakaolin can be used as a partial substitution for slag to mitigate significant volume changes in alkali-activated slags. Its effect on compressive strength and workability (as well as on isothermal calorimetry, autogenous strain, and coefficient of thermal expansion (CTE)) were found to depend on both the type and concentration of the alkaline activator. When using 8 M and 10 M sodium hydroxide (NaOH), increasing the substitution rate increased the compressive strength. With sodium silicate (Na₂SiO₃), compressive strength decreased as the substitution increased. Isothermal calorimetry revealed metakaolin’s dilution effect at 10% substitution. With 8 M NaOH, a third reaction peak appeared, whose magnitude increased with the substitution rate, while the second peak decreased. The swelling was increased at 10% substitution, followed by constant shrinkage in case of NaOH-activation. Shrinkage was mitigated with Na₂SiO₃-activation. Higher substitutions with 8 M NaOH resulted in a significant increase in the shrinkage rate and CTE, occurring when the third reaction peak appeared. A 10% substitution delayed the CTE increase but resulted in higher later-age values (dilution effect). The 20% substitution led to a similar final CTE value at 300 h, while 30% substitution resulted in a decrease in CTE after the initial increase. Full article

Metamaterials, owing to their exceptional properties such as a negative Poisson’s ratio, phonon band gap, and energy absorption, have garnered significant interest in aerospace, automotive transportation, and other domains. The increasing demand for metamaterial structures with diverse specialized attributes requires innovative design approaches. In this study, a novel bi-material triangular curved beam honeycomb metamaterial (BTBM) is designed, which exhibits a tunable Poisson’s ratio (PR), coefficient of thermal expansion (CTE), and band gap characteristics. These properties are intrinsically coupled through the geometric and material design of the bi-material triangular curved beam structure, meaning that adjustments to the unit cell configuration simultaneously influence PR, CTE, and band gap behavior. This dual-mode control offers versatile design strategies for multifunctional metamaterials. The energy band structure is calculated using finite element simulation analysis, and its accuracy is validated by computing the transmission characteristic curve. Numerical simulations were performed to systematically analyze the coupled effects of geometric parameters and material combinations on the PR and CTE. The results demonstrate significant tunability of these mechanical properties through parametric optimization. The results of this study provide valuable insights into the design and optimization of metamaterial structures with tailored properties for various applications. Full article

Carbon staple fiber composites are materials reinforced with discrete-length carbon fibers processed using traditional textile technologies, offering moderate mechanical properties and flexibility in manufacturing. These composites can be produced from recycled carbon staple fibers, aligned into yarn and tape-like structures, providing a more sustainable alternative while balancing performance, cost-effectiveness, and environmental impact. Aligning staple fibers into tape-like structures enables similar applications to those of continuous-fiber-based products, while allowing control over fiber orientation distribution, fiber volume fraction, and length distribution, which are all critical factors influencing both mechanical and thermo-mechanical properties. This study focuses on the experimental characterization and numerical investigation of Coefficients of Thermal Expansion (CTEs) in aligned carbon staple fiber composites. The effects of fiber orientation and volume fraction on coefficients of thermal expansion under different fiber alignment parameters are analyzed, revealing distinct thermal expansion behavior compared to typical aligned unidirectional continuous carbon fiber composite laminates. Unlike continuous unidirectional laminates, which typically exhibit transversely isotropic behavior without tensile–shear coupling, staple fiber composites demonstrate different in-plane axial, transverse, and out-of-plane CTE characteristics. To explain these deviations, a modeling approach is introduced, incorporating detailed experimental information on fiber distributions and microstructural features rather than averaged fiber orientation values. This involves a multi-scale analysis based on a laminate analogy through which all composite thermo-elastic properties can be predicted, accounting for variations in fiber orientations, volume fractions, and tape thicknesses. It is shown that while the local variation of fiber volume fraction has a small effect on the homogenized value of the coefficients of thermal expansion, fiber misalignment, tape thickness, and asymmetry in fiber orientation distribution will significantly affect the measurements of CTEs. For the case of carbon staple fiber composites, the asymmetry in fiber orientation distribution significantly influences the measurements of axial CTE. Fiber orientation asymmetry causes tensile–shear coupling under mechanical and thermal loading, leading to an unbalanced laminate with in-plane shear–tensile deformation. This coupling disrupts uniform displacement, complicating strain measurements and the determination of composite properties. Full article

This article presents, in detail, design considerations for a thin-walled glass fiber reinforced plastic (GFRP) liner on a fluid-cooled stator lamination of an electric motor. In addition to structural requirements due to the cooling fluid pressure, the GFRP liner needs to guarantee impermeability. Analytical considerations deriving from different coefficients of thermal expansion (CTEs) determine the two-layered laminate design. Empirical investigations show two innovative, simple, and, therefore, efficient test setups for the leakage of liquid media through a GFRP liner. The weeping investigations employ two different GFRP systems with four different configurations of interfiber failure (IFF) and, therefore, crack densities. The weeping investigations show that at least one ply in the laminate needs to be flawless regarding IFF cracks in order to guarantee the sealing function. Alternatively, a third sealing layer can be used. Full article

Residual stresses in multilayer thin coatings represent a complex multiscale phenomenon arising from the intricate interplay of multiple factors, including the number and thickness of layers, material properties of the layers and substrate, coefficient of thermal expansion (CTE) mismatch, deposition technique and growth mechanism, as well as process parameters and environmental conditions. A multiscale approach to residual stress measurement is essential for a comprehensive understanding of stress distribution in such systems. To investigate this, two AlGaN/GaN multilayer coatings with distinct layer architectures were deposited on sapphire substrates using metalorganic vapor phase epitaxy (MOVPE). High-resolution X-ray diffraction (HRXRD) was employed to confirm their epitaxial growth and structural characteristics. Focused ion beam (FIB) cross-sectioning and transmission electron microscopy (TEM) lamella preparation were performed to analyze the coating structure and determine layer thickness. Residual stresses within the multilayer coatings were evaluated using two complementary techniques: High-Resolution Scanning Transmission Electron Microscopy—Graphical Phase Analysis (HRSTEM-GPA) and Focused Ion Beam—Digital Image Correlation (FIB-DIC). HRSTEM-GPA enables atomic-resolution strain mapping, making it particularly suited for investigating interface-related stresses, while FIB-DIC facilitates microscale stress evaluation. The residual strain values obtained using the FIB-DIC and HRSTEM-GPA methods were −3.2 × 10⁻³ and −4.55 × 10⁻³, respectively. This study confirms that residual stress measurements at different spatial resolutions are both reliable and comparable at the required coating depths and locations, provided that a critical assessment of the characteristic scale of each method is performed. Full article

Ultra-high-temperature (>1500 °C) sensors play vital roles in ensuring operational excellence in variety of energy-related applications, such as power plant boilers and gas turbine engines. Crystalline sapphire fibers have enormous potential to replace conventional expensive precious metal (e.g., Pt/Rh)-based high-temperature (>1500 °C) sensors by offering higher environmental robustness and distributed sensing capabilities. However, a lack of proper cladding substantially compromises the performance of the sensor. To overcome this fundamental limitation, we develop a hybrid growing method to fabricate low-loss clad crystalline sapphire fibers. We grow a higher-refractive-index doped crystalline sapphire fiber core using the laser-heated pedestal growth (LHPG) method and lower-refractive-index undoped crystalline sapphire fiber cladding using the liquid-phase epitaxy (LPE) method. Furthermore, due to the existence of this cladding layer, a single mode of operation can be achieved at a core diameter size of 30 μm. The experimental results confirm that the grown clad crystalline sapphire fiber can survive in extremely high-temperature (>1500 °C) harsh environments due to the matched coefficient of thermal expansion (CTE) between the fiber core and the cladding. The numerical results also indicate a temperature sensing accuracy of 3.5 °C. This opens the door for developing point and distributed fiber sensor networks capable of enduring extremely harsh environments at extremely high temperatures. Full article

In this work, the influence of Ba/Ca ratios on the BaO-CaO-SiO₂ (BCS) glass network structure, crystallization phases, and coefficient of thermal expansion (CTE) was investigated. As the Ba/Ca ratio increases, the Qⁿ units in the glass network structure have undergone significant changes. The Q⁴ units in the BCS glass network transform into Q³ units, indicating the reduction of the glass network connectivity. The variation in the Ba/Ca ratio leads to a change in the crystallization phases of BCS glass-ceramics sintered at a temperature higher than Tc (crystallization temperature). The addition of α-SiO₂ (quartz) could regulate the crystallization phases and their ratio of the barium silicates (BaSi₂O₅, Ba₂Si₃O₈, and Ba₅Si₈O₂₁) in the BCS glass-ceramics. An abundant orthorhombic BaSi₂O₅ phase can be obtained in the BCS glass-ceramics with 15 wt% α-SiO₂ calcinated over 875 °C. The α-SiO₂ modified BCS glass-ceramics exhibited excellent properties (CTE = 12.10 ppm/°C, ε_r = 7.49 @ 13.4 GHz, tanδ = 4.96 × 10⁻⁴, Q × f = 27,034 GHz) sintered at optimized conditions, making it a promising candidate material for RF module and electronic packaging substrate. Full article

Concrete’s coefficient of thermal expansion (CTE) is a critical property affecting the durability and performance of rigid pavements. This review paper examines the significance of CTE in pavement design and the factors influencing it, including the type of aggregate, cement composition, age, relative humidity, and curing conditions. Thermal stress due to temperature changes and moisture variation can lead to cracking, spalling, and warping in concrete pavements, impacting their performance. The paper also discusses experimental methods for measuring CTE, alongside recent advances like mechanistic–empirical pavement design and prediction models. Integrating CTE considerations into pavement design enhances the predictive accuracy of pavement performance, particularly in addressing issues like joint movement and cracking. By comprehensive literature review and synthesizing current research, the paper emphasizes the importance of integrating CTE considerations into pavement design for improved durability and performance predictions. The paper emphasizes the importance of integrating CTE considerations into pavement design for improved durability and performance predictions. Full article

This study presents the synthesis of sintered composite foams based on the Invar alloy (64Fe-36Ni), using hollow spherical particles from a nickel superalloy (NiCrSiB) in order to generate porosity. The Invar powder was obtained by mechanical alloying (MA), and the NiCrSiB hollow spherical particles were incorporated into the composite at 20 vol %. The sintering was realized using the spark plasma sintering (SPS) process in an argon atmosphere at 600 °C and 5 MPa, with 10 s holding time. The porous structures were structurally characterized by optical microscopy (OM), scanning electron microscopy (SEM) and X-ray diffraction (XRD). The coefficient of linear thermal expansion (CTE) of the Invar/NiCrSiB syntactic foams was found to be 2.52 × 10⁻⁶ °C⁻¹ in the 25–150 °C temperature range and 19.68 × 10⁻⁶ °C⁻¹ in the 150–400 °C range. Full article

Mullite, 3Al₂O₃·2SiO₂, is a material with excellent thermal and mechanical properties. Two types of waste sand, rich in impurities, were employed as precursors for mullite ceramic synthesis. Two different synthesis routes were used: (i) solid-state reactions involving a sand and bauxite mixture, and (ii) precipitation synthesis, where alumina was deposited on sand particle surfaces; the sintering process was performed at temperatures ranging from 1300 °C to 1400 °C. Mullite was obtained as the main phase when the ceramics were obtained by solid-state reactions opposite to the second method, in which a composite ceramic with a specific microstructure, i.e., sand particles embedded in a matrix formed by alumina crystals, was assessed by electronic microscopy. The main properties, i.e., the apparent density, open porosity, compressive strength and thermal expansion coefficient (CTE) of the obtained materials were influenced by the composition and microstructure as well as the sintering temperature. The ceramics in which mullite was the main phase had slightly lower CTE’s and did not exhibit any phase transition in the 20–900 °C range. The results presented in this article highlight the importance of the synthesis route correlated with the nature of the precursors, the type and amount of impurities and the sintering temperature. Full article

This study investigates the influence of curing temperature (explored at 10 °C, 20 °C, and 30 °C) on the volume changes of alkali-activated slag (AAS) pastes with the aim of expanding existing knowledge on alkali-activated materials (AAMs). The focus was on autogenous and thermal strains, internal relative humidity (IRH), heat flow and cumulative heat, setting times, and workability. The results indicate that increasing the curing temperature to 30 °C reduces autogenous shrinkage, likely due to changes in the elastic modulus and viscoelastic properties, while promoting swelling, especially for higher molarities. The coefficient of thermal expansion (CTE), related to thermal strains, is higher when the curing temperature is increased, but its development is delayed. The IRH is influenced more by the activating solution’s molarity than by curing temperature, although temperature does affect the initial IRH. The study also revealed that higher curing temperatures accelerate chemical reactions and reduce setting times. The initial workability was significantly affected by the solution-to-binder ratio, while higher temperatures decreased workability, especially at higher molarities. These findings contribute to the understanding of how curing temperature influences the durability of AAS pastes, offering insights into optimized construction practices under varying environmental conditions. Full article

The hybridization of additive manufacturing (AM) with conventional manufacturing processes in tooling applications allows the customization of the tool. Examples include weight reduction, improving the vibration-dampening properties, or directing the coolant to the critical zones through intricate conformal cooling channels aimed at extending the tool life. In this regard, metallurgical challenges like the need for a post-processing heat treatment in the AM segment to meet the thermal and mechanical properties requirements persist. Heat treatment can destroy the dimensional accuracy of the pre-manufactured heat-treated wrought segment, on which the AM part is built. In the case of dissimilar joints, heat treatment may further impact the interface properties through the ease of diffusional reactions at elevated temperatures or buildup of residual stresses at the interface due to coefficient of thermal expansion (CTE) mismatch. In this communication, we report on the laser powder bed fusion (L-PBF) processing of MAR 60, a weldable carbon-free maraging powder, to manufacture a hybrid tool holder for general turning applications, comprising a wrought segment in 25CrMo4 low-alloy carbon-bearing tool steel. After L-PBF process optimization and manipulation, as-built (AB) MAR 60 steel was characterized with a hardness and tensile strength of ~450 HV (44–45 HRC) and >1400 MPa, respectively, matching those of pre-manufactured wrought 25CrMo4 (i.e., 42–45 HRC and 1400 MPa). The interface was defect-free with strong metallurgical bonding, showing slight microstructural and hardness variations, with a thickness of less than 400 µm. The matching strength and high Charpy V-notch impact energy (i.e., >40 J) of AB MAR 60 eliminate the necessity of any post-manufacturing heat treatment in the hybrid tool. Full article
