With the advancement of modern fan architectures, dedicated experimental benchmarks are becoming fundamental to improving the knowledge of flow physics, validating novel CFD methods, and fine-tuning existing methods. In this context the open test case ECL5/CATANA, representative of a modern Ultra High Bypass Ratio (UHBR) architecture, has been designed and experimentally investigated at École Centrale de Lyon (ECL) in a novel test facility with multi-physical instrumentation, providing a large database of high-quality aerodynamic and aeromechanic measurements. In this paper, a thorough numerical study of the fan stage aerodynamics was performed using the CFD TRAF code developed at the University of Florence. Fan stage performance was studied at design speed over the entire operating range. The results were discussed and compared with datasets provided by ECL. Detailed sensitivity on numerical schemes and state-of-the-art turbulence/transition models allowed for the selection of the best numerical setup to perform UHBR fan simulations. Moreover, to have a deeper understanding of the fan stall margin, unsteady simulations were also carried out. The results showed the appearance of blade tip instability, precursor of a rotating stall condition, which may generate non-synchronous blade vibrations. Full article

This study examines how leading-edge inclination angles affect a two-stage centrifugal compressor’s aerodynamic performance using numerical and experimental methods. Five impellers with varied inclination configurations were designed for both stages. The results show that negative inclination improves the pressure ratio and efficiency under near-choke conditions, with greater enhancements in the low-pressure stage. Positive inclination significantly boosts the pressure ratio and efficiency under near-stall conditions, particularly in the low-pressure stage. Negative inclinations optimize blade loading and choke flow capacity, while effectively reducing incidence angle deviations induced by interstage pipeline distortion and decreasing outlet pressure fluctuation amplitude in the high-pressure stage. Positive inclinations delay flow separation, suppress tip leakage vortices, and extend the stall margin. Full article

This paper presents an analysis of the stability margin improvement (SMI), which is also known as stall margin improvement, achieved by continuous tip air injection. New piezoelectric actuators were designed and manufactured with a new engine inlet for the Larzac 04 C5 jet engine. It has noninvasive injection positions that do not have any measurable effect on the inlet air flow when it is switched off. The main focus of the system design was to achieve high power of the injected air and, as a result, a high SMI. The results presented enable a maximum SMI of 99%. A variety of engine operating conditions and injection positions were experimentally tested and discussed regarding SMI. Additionally, the complex relationship between SMI gains and thrust specific fuel consumption (TSFC) is explored in a power balance analysis, revealing a trade-off between SMI improvement and increased energy consumption. Full article

Operational safety and fuel efficiency are critical, yet often conflicting, objectives in modern civil get engine designs. Optimal efficiency operating conditions are typically close to unsafe regions, such as compressor stalls, which can cause severe engine damage. Consequently, engines are generally operated below peak efficiency to maintain a sufficient stall margin. Reducing this margin through active control requires stall precursor detection and mitigation mechanisms. While several algorithms have shown promising results in predicting modal stalls, predicting spike stalls remains a challenge due to their rapid onset, leaving little time for corrective actions. This study addresses this gap by proposing a method to identify spike stall precursors based on the changing dynamics within a compressor blade passage. An autoregressive time series model is utilized to capture these dynamics and its changes are related to the flow condition within the blade passage. The autoregressive model is adaptively extracted from measured pressure data from a one-stage axial compressor test stand. The corresponding eigenvalues of the model are monitored by utilizing an outlier detection mechanism that uses pressure reading statistics. Outliers are proposed to be associated with spike stall precursors. The model order, which defines the number of relevant eigenvalues, is determined using three information criteria: the Akaike Information Criterion (AIC), the Bayesian Information Criterion (BIC), and the Conditional Model Estimator (CME). For prediction, an outlier detection algorithm based on the Generalized Extreme Studentized Deviate (GESD) Test is introduced. The proposed method is experimentally validated on a single-stage low-speed axial compressor. Results demonstrate consistent stall precursor detection, with future application for timely control interventions to prevent spike stall inception. Full article

This paper reviews the evolution of flow control methods for bladed linear cascades, focusing on passive techniques like riblets, grooves, vortex generators (VGs), and blade slots, which have proven effective in reducing drag, suppressing flow separation, and enhancing stability. The review outlines key historical developments that have improved flow efficiency and reduced losses in cascades. Bio-inspired designs, including riblets and grooves, help stabilize the boundary layer, reduce loss coefficients, and improve flow turning, which is vital for controlling drag and secondary flow effects. Vortex generators, fences, and slotted wingtips enhance stall margins and suppress corner separation, improving performance under off-design conditions. These methods are optimized based on aerodynamic parameters such as Reynolds number and boundary layer characteristics, offering substantial efficiency gains in high-performance compressors. Advancements in computational tools, like high-fidelity simulations and optimization techniques, have provided deeper insights into complex flow phenomena, including turbulence and vortex dynamics. Despite these advancements, challenges remain in fully optimizing these methods for diverse operating conditions and ensuring their practical application. This review highlights promising strategies for improving flow control efficiency and robustness, contributing to the design of next-generation turbomachinery. Full article

Stall events in axial compressor systems have been a limiting factor for efficiency of such systems and a source of safety concerns. The detection of the onset of stall, and in many cases the precursor of the onset of stall, have been of interest in the axial compressor community for many decades. As such, development of algorithms along with active control could lower cost, reduce emissions, improve safety, and increase market competitiveness. To gain an understanding of these stall phenomena, past and current research has focused on modeling axial compressors as dynamic systems, with a focus on obtaining descriptive formulations of the physical aspects of stall. Some of these approaches allow for active control measures that extend the stall margin of the compressor system to increase safety and efficacy. This paper reviews the major contributions in these listed pursuits and presents the latest methods and algorithms for stall precursor detection in low-speed axial compressors. In particular, a review is presented in the types and characteristics of stalls, the major mathematical models used to describe these systems, influences of physical attributes such as tip clearance, guide vanes, and groove casing—operating as passive control elements—but also active control utilities such as air injection are discussed along with a detailed review of existing stall precursor detection algorithms. In addition, a forward-looking projection is presented that includes the use of machine learning algorithms to further the understanding and the capability of stall precursor detection. Full article

The aerodynamic performance of transonic compressors, particularly the stall margin, is significantly influenced by inlet distortion. While time-marching methods accurately simulate such unsteady flows, they can be time-consuming. To enhance the computational efficiency, two Fourier-based methods are proposed in this paper: the time-accurate method with interface filtering and the time–space collocation (TSC) method. The time-accurate method with interface filtering ignores the rotor–stator interaction effects, enabling a larger time step and faster convergence. In contrast, the TSC method accounts for harmonics of conservative variables and transforms the unsteady simulation into multiple steady-state calculations, thereby reducing computational costs. The two Fourier-based methods are validated using NASA Stage 67 and a two-stage transonic fan. Near the peak efficiency point, the results from both methods closely match that of URANS simulation and experimental data. The time-accurate method with interface filtering demonstrates a speed enhancement of 4 to 5 times as a result of a reduction in the iteration steps. In contrast, the TSC method exhibits a speed improvement of at least 20 times in two specific cases, attributable to the significantly smaller mesh size and iteration steps employed in the TSC method compared to the URANS method. Near the stall point, more harmonics for inlet distortion are necessary in TSC simulation to accurately capture flow separation. In the two-stage transonic fan simulations, the strong rotor–stator interaction effects lead to deviations from the URANS simulation; nevertheless, the Fourier-based simulations accurately reflect the trend of the stall margin under total pressure distortion. Overall, the Fourier-based methods show promising potential for engineering applications in estimating the performance degradation of compressors subjected to inlet distortion. Full article

A passive flow control technique in the form of microfiber coatings with a diverging pillar cross-section area was applied to the wing suction surface of a small tailless unmanned aerial vehicle (UAV). The coatings are inspired from ‘gecko feet’ surfaces, and their impact on steady and unsteady aerodynamics is assessed through wind tunnel testing. Angles of attack from −2° to 17° were used for static experiments, and for some cases, the elevon control surface was deflected to study its effectiveness. In forced oscillation, various combinations of mean angle of attack, frequency and amplitude were explored. The aerodynamic coefficients were calculated from load cell measurements for experimental variables such as microfiber size, the region of the wing coated with microfibers, Reynolds number and angle of attack. Microfibers with a 140 µm pillar height reduce drag by a maximum of 24.7% in a high-lift condition and cruise regime, while 70 µm microfibers work best in the stall flow regime, reducing the drag by 24.2% for the same high-lift condition. Elevon deflection experiments showed that pitch moment authority is significantly improved near stall when microfibers cover the control surface and upstream, with an increase in CM magnitude of up to 22.4%. Dynamic experiments showed that microfibers marginally increase dynamic damping in pitch, improving load factor production in response to control surface actuation at low angles of attack, but reducing it at higher angles. In general, the microfiber pillars are within the laminar boundary layer, and they create a periodic slip condition on the top surface of the pillars, which increases the near-wall momentum over the wing surface. This mechanism is particularly effective in mitigating flow separation at high angles of attack, reducing pressure drag and restoring pitching moment authority provided by control surfaces. Full article

The self-circulating casing treatment can effectively expand the stable working range of the compressor, with little impact on its efficiency. With a single-stage transonic axial flow compressor NASA (National Aeronautics and Space Administration) Stage 35 as the research object, a multi-channel unsteady numerical calculation method was used here to design three types of self-circulating casing treatment structures: 20% Ca (axial chord length of the rotor blade tip), 60% Ca, and 178% Ca (at this time, the bleed position is at the stator channel casing) from the leading edge of the blade tip. The effects of these three bleed positions on the self-circulating stability expansion effect and compressor performance were studied separately. The calculation results indicate that the further the bleed position is from the leading edge of the blade tip, the weaker the expansion ability of the self-circulating casing treatment, and the greater the negative impact on the peak efficiency and design point efficiency of the compressor. This is because the air inlet of the self-circulating casing with an air intake position of 20% Ca is located directly above the core area of the rotor blade top blockage, which can more effectively extract low-energy fluid from the blockage area. Compared to the other two bleed positions, it has the greatest inhibitory effect on the leakage vortex in the rotor blade tip gap and has the strongest ability to improve the blockage at the rotor blade tip. Therefore, 20% Ca from the leading edge of the blade tip has the strongest stability expansion ability, achieving a stall margin improvement of 11.28%. Full article

Casing treatments improve compressor stability but often at the expense of compressor efficiency. In this study, the differential entropy generation rate (DEGR) was applied to both efficiency evaluation and stall margin estimation. Rotor 67 was used as the compressor in this study and the simulation results were analyzed to correlate the distribution of the DEGR with the flow structures in the rotor at three rotating speeds. The characteristics of the DEGR at each speed were analyzed, exhibiting the characteristics of the flow structures at peak efficiency (PE) and near stall (NS) flow conditions. Loss analysis was conducted on the peak efficiency operating condition, particularly at 100% rotating speed. The critical state of the DEGR was investigated to identify stall occurrences on the near-stall condition. It was thus concluded that the DEGR can be a unified measure of both efficiency and stall margin. This theoretical exploration was subsequently applied to the design of casing treatments with two objectives: enhancing peak efficiency at 100% rotating speed and improving stability margins at all speeds. Two casing treatments were designed, with two circumferential grooves positioned axially at different locations. Their mechanisms for reducing the high DEGR area in the peak efficiency condition of 100% speed and suppressing an increase in DEGR during approaching stall were investigated, respectively. The results indicated that the presence of a groove near the leading edge of the blade tip can effectively suppress stall at all speeds. In order to achieve peak efficiency at high speeds, the extent of casing treatment coverage above the shock wave plays a crucial role in minimizing losses. Full article

The internal losses in the tip clearance region strongly influence the compressor performance and its operational range. Previous research proved that passive wall treatments with circumferential grooves in axial compressors effectively increase the compressor stall margin. The vortex generated inside the circumferential grooves creates a resistance to the flow that leaks into the tip clearance region of the compressor. However, most works found in the literature on circumferential grooves in axial compressors deal only with high-performance single-stage axial compressors. Therefore, there is a need to investigate and analyze the behavior of circumferential grooves in a multi-stage environment. In the present work, a passive wall treatment with circumferential grooves was implemented in a multi-stage axial compressor. Different configurations of circumferential grooves were created at the casing of the first and second rotor rows used in a four-stage axial flow compressor. Numerical simulations were performed to evaluate the influence of the circumferential grooves on the performance of a multi-stage axial compressor. The results obtained after the simulations for the different circumferential groove configurations were compared with the results obtained for the compressor without casing treatment (smooth wall) for different rotational speeds. Furthermore, the complete compressor map characteristics were simulated for the different casing treatment configurations, and the results were compared with the compressor characteristics of the smooth wall case. The passive wall treatment with circumferential grooves produced changes in the multi-stage axial compressor flow field, especially in the tip clearance region, improving the compressor stability mainly for part load speeds. Full article

In this paper, a numerical optimization study of single-groove casing treatment was conducted on a high-speed axial compressor. One of the aims is to find the optimal structure of a single groove that can improve compressor stability with minimal loss in efficiency. Another aim is to explore suitable parameters for rapidly evaluating the compressor stall margin. A design optimization platform has been constructed in this paper, which utilizes NSGA-II and a Radial Basis Function (RBF) neural net model to carry out the optimization. The stall margin of the compressor with A single groove was accurately determined by calculating its entire overall performance line. A Pareto front is obtained through optimization, and the optimal design can be selected from the Pareto front. By considering both stall margin and efficiency loss, one of the optimal designs was found to achieve a 7.49% improvement in stall margin with a 0.24% improvement in peak efficiency. Based on the database, the effect of design parameters of a single groove on compressor stability and performance is analyzed. A series of evaluation parameters of stall margin were compared to their degree of correlation with the real stall margin calculated by the entire overall performance line. As a result, tip blockage and momentum ratio can be used as efficient parameters for quickly evaluating the compressor stall margin without the need to calculate the entire performance curve of the compressor. Full article

Compressors are an essential component of aircraft engines. Their design and operation must be extremely reliable as engine safety and performance depend greatly on these elements. Axial compressors exhibit instabilities, such as surge or rotating stall, in a region close to the peak of their performance curves. These fluid dynamic instabilities can cause drops in efficiency, stress on the blades, fatigue, and even failures. Compressors are handled therefore by operating with a safety margin far from the surge line. Moreover, models able to predict onset instabilities and to reproduce them are of great interest. A dynamic system able to describe successfully both surge and rotating stall is the model presented by Moore and Greitzer That model has also been used for developing control laws of the compressor dynamics. The present work aims at developing an artificial neural network (ANN) approach able to predict either the permanence of the system in stable working condition or the onset instabilities from a time sequence of the compressor dynamics. Different solutions were tried to find the most suitable model for identifying the system, as well as the effects of the duration of the time sequence on the accuracy of the predicted compressor working conditions. The network was further tried for sequences with different initial values in order to perform a system analysis that included multiple variations from the initial database. The results show how it is possible to identify with high accuracy both rotating stall and surge with the ANN approach. Moreover, the presence of an underlying fluid dynamic model shares some similarities with physically informed AI procedures. Full article

The compressor serves as a crucial component that influences the performance of the gas turbine engine. Researchers have been endeavoring to explore compressor types that possess a high loading level and high-efficiency characteristics concurrently. In this study, tandem blade technology was applied to a transonic ultra-highly loaded axial compressor, and the Baseline single-blade rotor was replaced by a tandem rotor to take into account the loading level and compressor performance. Detailed investigations were carried out to identify the effects on the aerodynamic performance of the ultra-highly loaded stage and the fundamental flow mechanism within the tandem-rotor stage. This paper presents original design maps for the tandem-rotor stage, and the selection criteria for tandem parameters in tandem-rotor stage are refined. The results indicate that the peak efficiency improved by 0.83%, the stall margin increased by 2.16%, and the choke flow rate rose by 0.30% for the optimal tandem-rotor configuration. The meridional division position of the rotor primarily affects the ratio of loading of the front and rear blades, while the circumferential relative position of the tandem rotor mainly influences the channel types formed by the front and rear blades. Larger values for the meridional division position parameter and smaller values for circumferential relative position parameter should be selected for the tandem rotor design to optimize both the isentropic efficiency and total pressure ratio. This investigation offers the theoretical foundation for the design of a transonic ultra-highly loaded tandem-rotor compressor. Full article

High-pressure ratio centrifugal compressors’ diffusers face challenges from high-velocity, non-uniform flow at the impeller outlet, decreasing efficiency and stall margin. To address this, this paper presents a novel vaned diffuser passage design method that successfully improved the compressor’s performance. An optimization method using axisymmetric hub contours and NURBS curves was applied to modify the diffuser’s design. After optimization, centrifugal compressor peak efficiency increased by 0.78%, and stall margin expanded from 12.8% to 20.4%. Analysis at the peak efficiency point showed loss reduction mainly from decreased recirculation and mixing losses in the diffuser’s vaneless and semi-vaneless spaces. Furthermore, correlation analysis and Mach number distribution revealed that flow behavior at the diffuser’s leading edge significantly influences efficiency. Consequently, design principles emphasize satisfying specific Mach number distribution rules at the diffuser’s leading edge under certain inflow conditions for optimal performance. Full article
