Search Results (37)

Search Parameters:
Keywords = the Lorentz force characteristics

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
22 pages, 1739 KiB
Article
Design of a Lorentz Force Magnetic Bearing Group Steering Law Based on an Adaptive Weighted Pseudo-Inverse Law
by Chenyu Wang, Lei Li, Weijie Wang, Yanbin Zhao, Baiqi Li and Yuan Ren
Sensors 2025, 25(10), 3242; https://doi.org/10.3390/s25103242 - 21 May 2025
Viewed by 492
Abstract
Aiming at the high-precision torque output and saturation singularity avoidance problems in Lorentz force magnetic bearing (LFMB) swarms for magnetic levitation spacecraft, this study designs a manipulation law based on an adaptive weighted pseudo-inverse law. The system monitors each magnetic bearing’s working state [...] Read more.
Aiming at the high-precision torque output and saturation singularity avoidance problems in Lorentz force magnetic bearing (LFMB) swarms for magnetic levitation spacecraft, this study designs a manipulation law based on an adaptive weighted pseudo-inverse law. The system monitors each magnetic bearing’s working state in real time using high-precision position and current sensors. As the key input for the adaptive weighted pseudo-inverse control law, the sensor data’s measurement accuracy directly determines torque distribution effectiveness and attitude control precision. First, considering electromagnetic back-EMF effects, individual LFMB dynamics are modeled via the equivalent magnetic circuit method, with working principles elucidated. Subsequently, saturation coefficients for LFMB swarms are designed. Incorporating spacecraft maneuvering requirements, a genetic optimization algorithm establishes the optimal mounting configuration under task constraints. Considering the LFMB swarm configuration characteristics, this study proposes an adaptive weighted pseudo-inverse maneuvering law tailored to operational constraints. By designing an adaptive weighting matrix, the maneuvering law adjusts each LFMB’s torque output in real time, reducing residual saturation effects on attitude control speed and accuracy. Simulation results demonstrate that the proposed mounting configuration and adaptive weighted pseudo-inverse maneuvering law effectively mitigate saturation singularity’s impact on attitude control accuracy while reducing total energy consumption by 22%, validating the method’s effectiveness and superiority. Full article
Show Figures

Figure 1

22 pages, 1130 KiB
Article
Two-Mode Hereditary Model of Solar Dynamo
by Evgeny Kazakov, Gleb Vodinchar and Dmitrii Tverdyi
Mathematics 2025, 13(10), 1669; https://doi.org/10.3390/math13101669 - 20 May 2025
Viewed by 253
Abstract
The magnetic field of the Sun is formed by the mechanism of hydromagnetic dynamo. In this mechanism, the flow of the conducting medium (plasma) of the convective zone generates a magnetic field, and this field corrects the flow using the Lorentz force, creating [...] Read more.
The magnetic field of the Sun is formed by the mechanism of hydromagnetic dynamo. In this mechanism, the flow of the conducting medium (plasma) of the convective zone generates a magnetic field, and this field corrects the flow using the Lorentz force, creating feedback. An important role in dynamo is played by memory (hereditary), when a change in the current state of a physical system depends on its states in the past. Taking these effects into account may provide a more accurate description of the generation of the Sun’s magnetic field. This paper generalizes classical dynamo models by including hereditary feedback effects. The feedback parameters such as the presence or absence of delay, delay duration, and memory duration are additional degrees of freedom. This can provide more diverse dynamic modes compared to classical memoryless models. The proposed model is based on the kinematic dynamo problem, where the large-scale velocity field is predetermined. The field in the model is represented as a linear combination of two stationary predetermined modes with time-dependent amplitudes. For these amplitudes, equations are obtained based on the kinematic dynamo equations. The model includes two generators of a large-scale magnetic field. In the first, the field is generated due to large-scale flow of the medium. The second generator has a turbulent nature; in it, generation occurs due to the nonlinear interaction of small-scale pulsations of the magnetic field and velocity. Memory in the system under study is implemented in the form of feedback distributed over all past states of the system. The feedback is represented by an integral term of the type of convolution of a quadratic form of phase variables with a kernel of a fairly general form. The quadratic form models the influence of the Lorentz force. This integral term describes the turbulent generator quenching. Mathematically, this model is written with a system of integro-differential equations for amplitudes of modes. The model was applied to a real space object, namely, the solar dynamo. The model representation of the Sun’s velocity field was constructed based on helioseismological data. Free field decay modes were chosen as components of the magnetic field. The work considered cases when hereditary feedback with the system arose instantly or with a delay. The simulation results showed that the model under study reproduces dynamic modes characteristic of the solar dynamo, if there is a delay in the feedback. Full article
(This article belongs to the Special Issue Advances in Nonlinear Dynamical Systems of Mathematical Physics)
Show Figures

Figure 1

23 pages, 14284 KiB
Article
Development and Performance Analysis of an Electromagnetic Pump for a Thermal Hydraulic Experimental Loop of a Lead-Cooled Fast Reactor
by Zi’ang Li, Lanfei Yuan, Chenglong Wang, Suizheng Qiu and Ying Li
Energies 2025, 18(3), 750; https://doi.org/10.3390/en18030750 - 6 Feb 2025
Viewed by 952
Abstract
With the advancement of lead–bismuth fast reactors, there has been increasing attention directed towards the design of and manufacturing technology for electromagnetic pumps employed to drive liquid lead–bismuth eutectic (LBE). These electromagnetic pumps are characterized by a simple structure, effective sealing, and ease [...] Read more.
With the advancement of lead–bismuth fast reactors, there has been increasing attention directed towards the design of and manufacturing technology for electromagnetic pumps employed to drive liquid lead–bismuth eutectic (LBE). These electromagnetic pumps are characterized by a simple structure, effective sealing, and ease of flow control. They exploit the excellent electrical conductivity of liquid metals, allowing the liquid metal to be propelled by Lorentz forces generated by the traveling magnetic field within the pump. To better understand the performance characteristics of electromagnetic pumps and master the techniques for integrated manufacturing and performance optimization, this study conducted fundamental research, development of key components, and the assembly of the complete pump. Consequently, an annular linear induction pump (ALIP) suitable for liquid lead–bismuth eutectic was developed. Additionally, within the lead–bismuth thermal experimental loop, startup and preheating experiments, performance tests, and flow-head experiments were conducted on this electromagnetic pump. The experimental results demonstrated that the output flow of the electromagnetic pump increased linearly with the input current. When the input current reached 99 A, the loop achieved a maximum flow rate of 8 m3/h. The efficiency of the electromagnetic pump also increased with the input current, with a maximum efficiency of 5.96% during the experiments. Finally, by analyzing the relationship between the flow rate and the pressure difference of the electromagnetic pump, a flow-head model specifically applicable to lead–bismuth electromagnetic pumps was established. Full article
(This article belongs to the Special Issue Thermal Hydraulics and Safety Research for Nuclear Reactors)
Show Figures

Figure 1

11 pages, 4199 KiB
Article
Experimental Study on the Propulsion Performance of Laser Ablation Induced Pulsed Plasma
by Hang Song, Jifei Ye, Ming Wen, Haichao Cui and Wentao Zhao
Aerospace 2024, 11(12), 1013; https://doi.org/10.3390/aerospace11121013 - 9 Dec 2024
Viewed by 1225
Abstract
This study investigates the influence of electromagnetic fields on the propulsion performance of laser plasma propulsion. Based on the principle of pulsed plasma thrusters, an electromagnetic field is utilized to accelerate laser plasma, achieving enhanced propulsion performance. This approach represents a novel method [...] Read more.
This study investigates the influence of electromagnetic fields on the propulsion performance of laser plasma propulsion. Based on the principle of pulsed plasma thrusters, an electromagnetic field is utilized to accelerate laser plasma, achieving enhanced propulsion performance. This approach represents a novel method for the electromagnetic enhancement of laser propulsion performance. In this paper, pulsed plasma thrusters induced by laser ablation are employed. The generated plasma is subjected to the Lorentz force under the influence of an electromagnetic field to obtain higher speed, thus increasing impulse and specific impulse. An experimental platform for laser-ablation plasma electromagnetic acceleration was constructed to explore the enhancement effect of discharge characteristics and propulsion performance. The results demonstrate that increased laser energy has little effect on discharge characteristics, while the trend of propulsion performance parameters initially rises and then declines. After coupling the electromagnetic field, the propulsion performance is significantly enhanced, with stronger electromagnetic fields yielding more pronounced effects. Full article
Show Figures

Figure 1

15 pages, 3921 KiB
Article
High-Precision Inertial Sensor Charge Ground Measurement Method Based on Phase-Sensitive Demodulation
by Yang Liu, Tao Yu, Yuhua Wang, Zihan Zhao and Zhi Wang
Sensors 2024, 24(3), 1009; https://doi.org/10.3390/s24031009 - 4 Feb 2024
Cited by 1 | Viewed by 1552
Abstract
Inertial sensors are the key payloads in space gravitational wave detection missions, and they need to ensure that the test mass (TM), which serves as the inertial reference, freely floats in the spacecraft without contact, so that the TM is not disturbed by [...] Read more.
Inertial sensors are the key payloads in space gravitational wave detection missions, and they need to ensure that the test mass (TM), which serves as the inertial reference, freely floats in the spacecraft without contact, so that the TM is not disturbed by the satellite platform and the cosmic environment. Space gravitational wave detection missions require that the residual acceleration of the TM should be less than 3×1015ms2Hz1/2. However, the TM with charges will interact with surrounding conductors and magnetic fields, introducing acceleration noise such as electrostatic force and Lorentz force. Therefore, it is necessary to carry out charge management on the TM, in which the high-precision measurement of charge is crucial. Space gravitational wave detection missions require a residual charge measurement accuracy of 3×1013C for the TM. In this paper, we design a high-precision inertial sensor charge measurement method based on phase-sensitive demodulation (PSD). By establishing a torsion pendulum rotation model based on the force modulation method, the characteristics of the TM torsion angle signal are analyzed. The PSD is used to extract the amplitude of the specific frequency signal component containing the charge information, and then to calculate the value of the accumulated charges. The method is compared with the Butterworth band-pass filtering method, and the simulation results show that the method has a higher measurement accuracy, shorter settling time, and stronger anti-interference ability, meeting the TM residual charge measurement accuracy index requirement. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

16 pages, 4120 KiB
Article
Reflection of Elastic Waves in Dipolar Gradient Half-Space under the Control of External Magnetic Field
by Wanrong Pei, Tongde Wu, Zhiwen Wang, Yunlei Jiang, Chuanping Zhou, Rougang Zhou and Yongping Gong
Appl. Sci. 2024, 14(1), 376; https://doi.org/10.3390/app14010376 - 31 Dec 2023
Viewed by 1258
Abstract
This paper investigated the reflection of plane waves at the interface of dipolar gradient elastic solids under the control of an external magnetic field. This study focused on the increasing influence of the microstructural effect as the incident wavelength approaches the characteristic length [...] Read more.
This paper investigated the reflection of plane waves at the interface of dipolar gradient elastic solids under the control of an external magnetic field. This study focused on the increasing influence of the microstructural effect as the incident wavelength approaches the characteristic length of the microstructure or at higher frequencies. Initially, the dispersion equation for the propagation of elastic waves was derived from the dipole strain gradient theory and Maxwell’s electromagnetic theory. Subsequently, the amplitude ratios of various reflected waves to incident P-waves and incident SV-waves were calculated based on the interface conditions. Finally, the numerical results were used to discuss the impact of the external magnetic field and microstructural characteristic length on the propagation of the reflected wave. It was observed that the microstructural effect generated new wave modes and introduced dispersion characteristics into the elastic waves. Conversely, the external magnetic field primarily influences the amplitude of the elastic wave propagation via the Lorentz force without creating new wave modes or affecting the dispersion properties of the elastic wave in the dipolar gradient elastic solid. Full article
(This article belongs to the Section Applied Physics General)
Show Figures

Figure 1

20 pages, 1835 KiB
Article
Magnetohydrodynamic and Ferrohydrodynamic Fluid Flow Using the Finite Volume Method
by Grigorios Chrimatopoulos, Efstratios E. Tzirtzilakis and Michalis A. Xenos
Fluids 2024, 9(1), 5; https://doi.org/10.3390/fluids9010005 - 25 Dec 2023
Cited by 3 | Viewed by 2831
Abstract
Many problems in fluid mechanics describe the change in the flow under the effect of electromagnetic forces. The present study explores the behaviour of an electric conducting, Newtonian fluid flow applying the magnetohydrodynamics (MHD) and ferrohydrodynamics (FHD) principles. The physical problems for such [...] Read more.
Many problems in fluid mechanics describe the change in the flow under the effect of electromagnetic forces. The present study explores the behaviour of an electric conducting, Newtonian fluid flow applying the magnetohydrodynamics (MHD) and ferrohydrodynamics (FHD) principles. The physical problems for such flows are formulated by the Navier–Stokes equations with the conservation of mass and energy equations, which constitute a coupled non-linear system of partial differential equations subject to analogous boundary conditions. The numerical solution of such physical problems is not a trivial task due to the electromagnetic forces which may cause severe disturbances in the flow field. In the present study, a numerical algorithm based on a finite volume method is developed for the solution of such problems. The basic characteristics of the method are, the set of equations is solved using a simultaneous direct approach, the discretization is achieved using the finite volume method, and the solution is attained solving an implicit non-linear system of algebraic equations with intense source terms created by the non-uniform magnetic field. For the validation of the overall algorithm, comparisons are made with previously published results concerning MHD and FHD flows. The advantages of the proposed methodology are that it is direct and the governing equations are not manipulated like other methods such as the stream function vorticity formulation. Moreover, it is relatively easily extended for the study of three-dimensional problems. This study examines the Hartmann flow and the fluid flow with FHD principles, that formulate MHD and FHD flows, respectively. The major component of the Hartmann flow is the Hartmann number, which increases in value the stronger the Lorentz forces are, thus the fluid decelerates. In the case of FHD fluid flow, the major finding is the creation of vortices close to the external magnetic field source, and the stronger the magnetic field of the source, the larger the vortices are. Full article
(This article belongs to the Special Issue Fluids in Magnetic/Electric Fields, 2nd Edition)
Show Figures

Figure 1

11 pages, 4263 KiB
Article
Analysis and Design of a Pulsed Power Generator for a Low-Energy Magnetic Pulse Welding System
by Young-Min Kwon, Min-Wook Hwang and Kwang-Cheol Ko
Electronics 2023, 12(24), 4921; https://doi.org/10.3390/electronics12244921 - 7 Dec 2023
Cited by 1 | Viewed by 1715
Abstract
Magnetic pulse welding (MPW) is a joining method that uses Lorentz force generated from an electromagnetic field. This method not only has the advantage of not causing thermal deformation of the material and no by-products compared to the method of joining by melting [...] Read more.
Magnetic pulse welding (MPW) is a joining method that uses Lorentz force generated from an electromagnetic field. This method not only has the advantage of not causing thermal deformation of the material and no by-products compared to the method of joining by melting by heat but also enables the joining of dissimilar metals rather than the joining of the same metal. Joining dissimilar metals can reduce the weight of mechanical devices and apply them to various fields. Recent research on MPW has focused on the characteristics of bonding according to the material or structure of metal rather than on pulse power research that generates the main factor of operation. However, in the operation of MPW, a Lorentz force is generated by the induced current caused by the electromotive force created in the flyer tube and the external magnetic field in the actuator. Therefore, it is necessary to analyze and optimize the pulse power to improve reliability and to miniaturize the system to expand the MPW utilization range. In this paper, we analyzed MPW operation according to a section of the pulse power output waveform. A condition for obtaining the maximum current in the flyer tube was proposed, and a plateau-shaped waveform was derived as an ideal output waveform capable of maintaining the Lorentz force. Through analysis, the proposed pulse power device is designed as a pulse-forming network (PFN) that generates a plateau output waveform. The design specification is that the circuit of PFN (type E) is designed so that the output waveform is pulse width 10 (μs) and the maximum output current is 100 (kA), and it is verified by simulation. Full article
(This article belongs to the Section Industrial Electronics)
Show Figures

Figure 1

19 pages, 4766 KiB
Article
Rotating Lorentz Force Magnetic Bearings’ Dynamics Modeling and Adaptive Controller Design
by Feiyu Chen, Weijie Wang and Shengjun Wang
Sensors 2023, 23(20), 8543; https://doi.org/10.3390/s23208543 - 18 Oct 2023
Cited by 5 | Viewed by 1622
Abstract
To address the issues of our agile satellites’ poor attitude maneuverability, low pointing stability, and pointing inaccuracy, this paper proposes a new type of stabilized platform based on seven-degree-of-freedom Lorentz force magnetic levitation. Furthermore, in this study, we designed an adaptive controller based [...] Read more.
To address the issues of our agile satellites’ poor attitude maneuverability, low pointing stability, and pointing inaccuracy, this paper proposes a new type of stabilized platform based on seven-degree-of-freedom Lorentz force magnetic levitation. Furthermore, in this study, we designed an adaptive controller based on the RBF neural network for the rotating magnetic bearing, which can improve the pointing accuracy of satellite loads. To begin, the advanced features of the new platform are described in comparison with the traditional electromechanical platform, and the structural characteristics and working principle of the platform are clarified. The significance of rotating magnetic bearings in improving load pointing accuracy is also clarified, and its rotor dynamics model is established to provide the input and output equations. The adaptive controller based on the RBF neural network is designed for the needs of high accuracy of the load pointing, high stability, and strong robustness of the system, and the current feedback inner loop is added to improve the system stiffness and rapidity. The final simulation results show that, when compared to the PID controller and robust sliding mode controller, the controller’s pointing accuracy and anti-interference ability are greatly improved, and the system robustness is strong, which can effectively improve the pointing accuracy and pointing stability of the satellite/payload, as well as provide a powerful means of solving related problems in the fields of laser communication, high score detection, and so on. Full article
Show Figures

Figure 1

19 pages, 6235 KiB
Article
Antisymmetric Lamb Wave Simulation Study Based on Electromagnetic Acoustic Transducer with Periodic Permanent Magnets
by Lianren Du, Ruizhen Gao and Xiaojuan Jia
Sensors 2023, 23(16), 7117; https://doi.org/10.3390/s23167117 - 11 Aug 2023
Viewed by 1477
Abstract
Due to its multi-mode and dispersion characteristics, Lamb waves cause interference to signal processing, which profoundly limits their application in nondestructive testing. To resolve this issue, firstly, based on the traditional EMAT, a horizontal polarization periodic permanent magnet electromagnetic acoustic transducer (HP-PPM-EMAT) was [...] Read more.
Due to its multi-mode and dispersion characteristics, Lamb waves cause interference to signal processing, which profoundly limits their application in nondestructive testing. To resolve this issue, firstly, based on the traditional EMAT, a horizontal polarization periodic permanent magnet electromagnetic acoustic transducer (HP-PPM-EMAT) was proposed. A 2-D finite element model was then developed to compare magnetic flux density, Lorentz force, and signal strength between the traditional EMAT and the HP-PPM-EMAT. The simulation results show that the HP-PPM-EMAT enhances the A0 mode Lamb wave (A0 wave) and suppresses the S0 mode Lamb wave (S0 wave). Finally, the influence of structural parameters of the HP-PPM-EMAT on the total displacement amplitude ratio of A0 and S0 was investigated using orthogonal test theory, and the width of magnet units was improved based on the orthogonal test. The results show that the total displacement amplitude ratio of A0 to S0 of the improved HP-PPM-EMAT can be improved by a factor of 7.74 compared with that of the traditional Lamb wave EMAT, which can produce higher-purity A0 mode Lamb waves. Full article
Show Figures

Figure 1

13 pages, 6932 KiB
Article
Electromagnetic Design and Analysis of Inertial Mass Linear Actuator for Active Vibration Isolation System
by Do-Kwan Hong and Jang-Hyun Park
Actuators 2023, 12(7), 295; https://doi.org/10.3390/act12070295 - 20 Jul 2023
Cited by 3 | Viewed by 2760
Abstract
Underwater radiated noise from anthropogenic structures must be reduced to protect the marine environment. Active vibration isolation that can reduce noise generated from vibration sources by providing counteracting forces can solve this issue. This paper presents a 120 N class electromagnetic inertial mass [...] Read more.
Underwater radiated noise from anthropogenic structures must be reduced to protect the marine environment. Active vibration isolation that can reduce noise generated from vibration sources by providing counteracting forces can solve this issue. This paper presents a 120 N class electromagnetic inertial mass linear actuator for an active vibration control system in a large ship. The proposed actuator is operated based on the Lorentz force, also known as electromagnetic force. To achieve a high thrust force to weight ratio, a permanent magnet with outer radial magnetization is used. In order to design and analyze the proposed model, a simple magnetic equivalent circuit analysis was first conducted to achieve an appropriate force, and its value was compared and verified with the magnetostatic finite element method. The dynamic characteristics of the actuator were then evaluated, and the performance was analyzed at various operating frequency points. The bobbin housing supporting the coil causes an eddy current loss due to materials with electrical conductivity. As a result, the damping force is generated by the reduction in magnetic flux, and the control force tends to decrease. Full article
(This article belongs to the Section High Torque/Power Density Actuators)
Show Figures

Figure 1

10 pages, 413 KiB
Article
Influence of Traps and Lorentz Force on Charge Transport in Organic Semiconductors
by Seema Morab, Manickam Minakshi Sundaram and Almantas Pivrikas
Materials 2023, 16(13), 4691; https://doi.org/10.3390/ma16134691 - 29 Jun 2023
Cited by 7 | Viewed by 1716
Abstract
Charge transport characteristics in organic semiconductor devices become altered in the presence of traps due to defects or impurities in the semiconductors. These traps can lead to a decrease in charge carrier mobility and an increase in recombination rates, thereby ultimately affecting the [...] Read more.
Charge transport characteristics in organic semiconductor devices become altered in the presence of traps due to defects or impurities in the semiconductors. These traps can lead to a decrease in charge carrier mobility and an increase in recombination rates, thereby ultimately affecting the overall performance of the device. It is therefore important to understand and mitigate the impact of traps on organic semiconductor devices. In this contribution, the influence of the capture and release times of trap states, recombination rates, and the Lorentz force on the net charge of a low-mobility organic semiconductor was determined using the finite element method (FEM) and Hall effect method through numerical simulations. The findings suggest that increasing magnetic fields had a lesser impact on net charge at constant capture and release times of trap states. On the other hand, by increasing the capture time of trap states at a constant magnetic field and fixed release time, the net charge extracted from the semiconductor device increased with increasing capture time. Moreover, the net charge extracted from the semiconductor device was nearly four and eight times greater in the case of the non-Langevin recombination rates of 0.01 and 0.001, respectively, when compared to the Langevin rate. These results imply that the non-Langevin recombination rate can significantly enhance the performance of semiconductor devices, particularly in applications that require efficient charge extraction. These findings pave the way for the development of more efficient and cost-effective electronic devices with improved charge transport properties and higher power conversion efficiencies, thus further opening up new avenues for research and innovation in this area of modern semiconductor technology. Full article
Show Figures

Figure 1

21 pages, 11978 KiB
Article
Optical Properties of Reactive RF Magnetron Sputtered Polycrystalline Cu3N Thin Films Determined by UV/Visible/NIR Spectroscopic Ellipsometry: An Eco-Friendly Solar Light Absorber
by E. Márquez, E. Blanco, M. García-Gurrea, M. Cintado Puerta, M. Domínguez de la Vega, M. Ballester, J. M. Mánuel, M. I. Rodríguez-Tapiador and S. M. Fernández
Coatings 2023, 13(7), 1148; https://doi.org/10.3390/coatings13071148 - 25 Jun 2023
Cited by 8 | Viewed by 2691
Abstract
Copper nitride (Cu3N), a metastable poly-crystalline semiconductor material with reasonably high stability at room temperature, is receiving much attention as a very promising next-generation, earth-abundant, thin film solar light absorber. Its non-toxicity, on the other hand, makes it [...] Read more.
Copper nitride (Cu3N), a metastable poly-crystalline semiconductor material with reasonably high stability at room temperature, is receiving much attention as a very promising next-generation, earth-abundant, thin film solar light absorber. Its non-toxicity, on the other hand, makes it a very attractive eco-friendly (greener from an environmental standpoint) semiconducting material. In the present investigation, Cu3N thin films were successfully grown by employing reactive radio-frequency magnetron sputtering at room temperature with an RF-power of 50 W, total working gas pressure of 0.5Pa, and partial nitrogen pressures of 0.8 and 1.0, respectively, onto glass substrates. We investigated how argon affected the optical properties of the thin films of Cu3N, with the aim of achieving a low-cost solar light absorber material with the essential characteristics that are needed to replace the more common silicon that is currently in present solar cells. Variable angle spectroscopic ellipsometry measurements were taken at three different angles, 50, 60, and 70, to determine the two ellipsometric parameters psi, ψ, and delta, Δ. The bulk planar Cu3N layer was characterized by a one-dimensional graded index model together with the combination of a Tauc–Lorentz oscillator, while a Bruggeman effective medium approximation model with a 50% air void was adopted in order to account for the existing surface roughness layer. In addition, the optical properties, such as the energy band gap, refractive index, extinction coefficient, and absorption coefficient, were all accurately found to highlight the true potential of this particular material as a solar light absorber within a photovoltaic device. The direct and indirect band gap energies were precisely computed, and it was found that they fell within the useful energy ranges of 2.142.25 eV and 1.451.71 eV, respectively. The atomic structure, morphology, and chemical composition of the Cu3N thin films were analyzed using X-ray diffraction, atomic force microscopy, and energy-dispersive X-ray spectroscopy, respectively. The Cu3N thin layer thickness, profile texture, and surface topography of the Cu3N material were characterized using scanning electron microscopy. Full article
(This article belongs to the Special Issue Advanced Thin Films Technologies for Optics, Electronics, and Sensing)
Show Figures

Figure 1

13 pages, 1736 KiB
Article
Diagnosing Time-Varying Harmonics in Low-k Oxide Thin Film (SiOF) Deposition by Using HDP CVD
by Yonggyun Park, Pengzhan Liu, Seunghwan Lee, Jinill Cho, Eric Joo, Hyeong-U Kim and Taesung Kim
Sensors 2023, 23(12), 5563; https://doi.org/10.3390/s23125563 - 14 Jun 2023
Viewed by 2848
Abstract
This study identified time-varying harmonic characteristics in a high-density plasma (HDP) chemical vapor deposition (CVD) chamber by depositing low-k oxide (SiOF). The characteristics of harmonics are caused by the nonlinear Lorentz force and the nonlinear nature of the sheath. In this study, a [...] Read more.
This study identified time-varying harmonic characteristics in a high-density plasma (HDP) chemical vapor deposition (CVD) chamber by depositing low-k oxide (SiOF). The characteristics of harmonics are caused by the nonlinear Lorentz force and the nonlinear nature of the sheath. In this study, a noninvasive directional coupler was used to collect harmonic power in the forward and reverse directions, which were low frequency (LF) and high bias radio frequency (RF). The intensity of the 2nd and 3rd harmonics responded to the LF power, pressure, and gas flow rate introduced for plasma generation. Meanwhile, the intensity of the 6th harmonic responded to the oxygen fraction in the transition step. The intensity of the 7th (forward) and 10th (in reverse) harmonic of the bias RF power depended on the underlying layers (silicon rich oxide (SRO) and undoped silicate glass (USG)) and the deposition of the SiOF layer. In particular, the 10th (reverse) harmonic of the bias RF power was identified using electrodynamics in a double capacitor model of the plasma sheath and the deposited dielectric material. The plasma-induced electronic charging effect on the deposited film resulted in the time-varying characteristic of the 10th harmonic (in reverse) of the bias RF power. The wafer-to-wafer consistency and stability of the time-varying characteristic were investigated. The findings of this study can be applied to in situ diagnosis of SiOF thin film deposition and optimization of the deposition process. Full article
(This article belongs to the Special Issue Recent Innovations in Plasma Sensing and Diagnosis Technology)
Show Figures

Figure 1

20 pages, 6356 KiB
Article
A Compact Electromagnetic Dual Actuation Positioning System with a 10 mm Range and Nanometer Resolution
by Bimal Jeet Goteea, Qianjun Zhang and Wei Dong
Actuators 2023, 12(3), 132; https://doi.org/10.3390/act12030132 - 21 Mar 2023
Cited by 1 | Viewed by 2495
Abstract
In this manuscript, a compact electromagnetic dual actuation positioning system (CEDAPS) based on the Lorentz force principle that features a 10 mm range and nanometer-scale resolution with flexure guides is presented. Firstly, the stiffness of the flexure mechanism is modelled. Secondly, based on [...] Read more.
In this manuscript, a compact electromagnetic dual actuation positioning system (CEDAPS) based on the Lorentz force principle that features a 10 mm range and nanometer-scale resolution with flexure guides is presented. Firstly, the stiffness of the flexure mechanism is modelled. Secondly, based on it, the primary coil is designed, and from its performance, a suitable secondary coil is made to compensate for the deficiency of the primary actuation subsystem. The characteristics of the forces generated by these coils are also evaluated by an electromagnetic FEA simulation. Thirdly, a control scheme is presented that combines the performances of these two actuators, and finally, a prototype is fabricated to evaluate the performance. The results show a 10 nm resolution for a 10 mm (±5 mm) stroke with low sub-micron sinusoidal tracking errors and nanometer accuracy for step tracking under the proposed control scheme. The thermal properties of the system are also presented. Full article
Show Figures

Figure 1
