Search Results (25)

As offshore wind energy advances into deeper waters, the dynamic response and safety assessment of tension leg platform (TLP) wind turbines under complex marine conditions have become focal research points. This study investigates a 15 MW TLP wind turbine, acquiring data on motion responses, mooring tensions, and tower-base loads through time-domain analysis, with extreme value estimation conducted using the mean up-crossing rate method. The results indicate that under normal operating conditions, second-order wave forces significantly influence extreme response estimation. At an exceedance probability of 0.01, the second-order sum-frequency force increases the extreme tower base shear by 4.28% and the bending moment by 10.11% compared to the first-order-only case, while the difference-frequency force has a minor effect. Different wind-wave incidence angles cause distinct variations in turbine motion, with head-on incidence exciting the largest wave-frequency responses and lateral incidence producing relatively weaker excitation effects. Furthermore, the coupling effect between incident direction and second-order wave forces further amplifies extreme response risks. Therefore, it is essential to fully assess the prevailing wind-wave directions in the target sea area and consider the effects of second-order wave forces, especially the sum-frequency component, to ensure the long-term safe operation of TLP wind turbines under complex sea conditions. Full article

The suction pile–gravity hybrid foundation (SPGH) has emerged as a novel foundation for floating wind turbines (FWTs) due to its superior bearing mechanism. In harsh marine environments, offshore wind turbine structures endure multidirectional wave–wind current loads, which are transmitted through mooring systems as complex multidirectional coupled loads (horizontal, vertical, bending moments, and torque), imposing severe challenges to the bearing capacity. Therefore, this study carries out 3D finite element simulations, utilizing the Hardening Soil–Small Strain constitutive model to simulate the stress–strain behavior of sand, to systematically investigate the failure modes and bearing capacity of SPGH foundations. The method underlying the failure envelope theory is proposed, applicable to tension-leg mooring systems (dominated by uplift and lateral loads) and catenary mooring systems (dominated by compression and lateral loads). Results indicate that under pure vertical uplift or torque loading, both SPGH and traditional SP foundations exhibit typical interfacial shear failure modes. Under pure horizontal or bending moment loading, SPGH and SP foundations exhibit rotational instability failure. The direction of vertical load has a significant impact on the bearing performance of SPGH foundations. In addition, horizontal load can increase its vertical uplift-bearing capacity by 46% and torque capacity by 48%. The enhancement effect of the bending moment load is more significant, and can increase the vertical uplift-bearing capacity by 115% and the torque-bearing capacity by 112%, respectively, while vertical downward loads within a certain range significantly improve horizontal and bending-bearing performance. Full article

This paper presents a 16 MW typhoon-resistant Tension Leg Platform floating offshore wind turbine (TLP FOWT) designed for the South China Sea. The survivability of the TLP FOWT under extreme environmental conditions is investigated through an integrated time-domain coupled analysis numerical model. The accuracy of the numerical model is calibrated by comparing its results with experimental data. In comparisons of mooring system static stiffness tests and white noise tests, the results from the calibrated numerical model show good agreement with the experimental data. Regarding the free decay tests and the statistical time-domain response results, the most significant discrepancies are only 1.17% and 6.91%, respectively. Subsequently, the time-domain response of the numerical model was investigated under extreme South China Sea conditions, configured according to the IEC 61400-3-2 design load conditions. The safety of the design was then evaluated against ABS specifications. The analysis yielded maximum platform motion amplitudes and inclinations of 34.99 m (less than 30% of water depth) and below 1°, respectively. Under both 50-year and 500-year return period conditions, the platform maintained stable TLP motion characteristics with no tendon slackness, evidenced by a minimum tendon tension of 107.23 kN. All motion responses and tendon tensions complied with the ABS safety factors, confirming the design’s capability to ensure safe operation throughout its service life. The present work provides valuable insights for the design and risk assessment of future large-scale TLP FOWTs. Full article

The primary challenge in the design of offshore oscillating water column (OWC) devices lies in maintaining structural integrity throughout their operational lifespan while functioning in challenging environmental conditions. Simultaneously, it is vital for these devices to demonstrate efficiency in wave power absorption across a range of environmental scenarios pertinent to the selected installation site. The present manuscript seeks to compare two distinct mooring types for a dual-chamber OWC device to enhance its wave power efficiency. To accomplish this objective, an analysis of wave power absorption efficiency will be conducted on both a catenary mooring system and a tension-leg platform (TLP) mooring arrangement, thereby identifying the most suitable configuration. The study elucidates how OWC mooring characteristics influence wave power absorption efficiency. While the catenary mooring system exhibits two distinct resonant wave frequencies, resulting in enhanced wave power absorption at those frequencies, the TLP mooring system demonstrates superior overall wave power absorption efficiency across a broader range of wave frequencies, thus showcasing its greater potential for wave energy conversion under diverse environmental conditions. Full article

To address the unstable motion of a tension leg platform (TLP) for floating wind turbines in various sea conditions, an improved method of incorporating a tuned liquid multi-column damper (TLMCD) into the TLP foundation is proposed. In order to evaluate the control effect of TLMCD on the motion response of the floating foundation, a multiphase flow solver based on a viscous flow CFD method and overlapping grid technique is applied to model the coupled multi-body dynamics interaction problem involving liquid tanks, waves, and a spring mooring system. This method has been proven to accurately capture the high-frequency motions of the structure and account for complex viscous interferences affecting the geometric motions. Additionally, the volume of fluid (VOF) method and the first-order linear superposition method are used to model the focused wave, enabling a simulation of the effects of transient wave loads on the floating foundation. The results show that the tuned damping effect of TLMCD on the TLP is mainly in the pitch motion, with the maximum pitch amplitude control volume ratio of TLMCD reaching up to 86% and the maximum surge amplitude control volume ratio of TLMCD reaching up to 25.2% under the operating conditions. These findings highlight the potential for additional research on and implementation of TLMCD technology. Full article

Online monitoring of mooring system response for the FPSO platform in any operational condition is so far challenging for machine learning (ML). This paper presents a new dynamic NARX ANN model for time series of mooring tension and a static MLP model for the offset chart prediction of a taut-leg moored FPSO with different working scenarios. A novel method for supervised feature selection of the dataset was applied to determine the most influential design features. Additionally, a design of experiments (DOE) technique was implemented for test matrix creation, simulation, database generation, and supervised selection characteristics in ML. The DOE analysis revealed that the mooring configuration, platform loading condition, and environmental loads alter the platform’s six-degree-of-freedom motion response patterns. These input data were used to predict the mooring tension and the offset chart of the floater. The results include the fair values of statistical error for mooring tension (R² = 0.8–0.98, E ≈ 1.3–5.7%, RMSE ≈ 6–66 kN) and platform offset (E ≈ 0.1–1 m) prediction when testing the trained models with unseen data representing new operational conditions. Faster convergence can be achieved by adding non-numeric (string) input values to dataset numeric features. Supervised feature selection of the dataset is a step forward in ML to improve prediction accuracy. Full article

Offshore floating wind foundations supporting a large wind turbine require a large yard facility or significant facility upgrades for their fabrication. To overcome the cost increase associated with facility upgrades, an innovative lightweight modular floating foundation is developed. The foundation comprises multiple modules to enable their assembly on water, offering many benefits and expanding fabrication options for a reduction in the overall cost of the platform. In this paper, the foundation modules and their assembly are briefly described, and an analysis of the platform’s dynamic responses is presented. The modular foundation includes a modular and lightweight tension leg platform (TLP) called “MarsVAWT” which supports a Darrieus 10 MW vertical axis wind turbine (VAWT). The platform is moored with highly pretensioned wire rope tendons. The responses of the platform are analyzed in the time domain in a semi-coupled manner under the turbine operating and parked conditions for an offshore site in the US Northeast. The tower base shear forces and bending moments increase considerably with the combination of wind and waves, compared to those with wind only. The tendon tensions on the weatherside in the operating condition at high wind speeds are comparable to the values of the 50-year extreme (parked). The tendon tension increases are highly correlated to the platform pitch, as well as the horizontal and vertical velocities and vertical acceleration at the tendon porch. The modular platform performances and tendon designs are confirmed to comply with industry standards and practices. Full article

According to the geometric parameters of the tension leg platform, the test model was made with a scale ratio of 1:61. The model was used to conduct the full-depth simulation test of uniform flow and wave current combination in the test pool. The model test results showed that when the reduced speed was between 5.5 and 8.5, and the lateral motion response of the platform was the most significant. In the interval of the reduced speed, the response frequency of transverse vortex-induced motion was close to the natural transverse frequency of the platform, and resonance occurred. The amplitude of surge motion increased with the increase of reduced speed. Due to the pull of the floating body, the tension of tension legs and risers increased with the flow rate but did not increase significantly in the floating body lock zone. The mooring tension had a certain limiting effect on the floating body sway. The displacement modes of tension legs and risers were greatly affected by the flow velocity. With the flow velocity increasing, the mode order increased. In addition, the increase in tension caused by the large displacement of the floating body had a certain impact on the displacement amplitude. The wave could reduce the sway of the floating body and strengthen the surge. Therefore, under the combined action of wave and current, the tension amplitude of the tension leg and riser was increased compared with that under the uniform flow. The conclusions obtained in this paper could be used for reference in the engineering design of tension legs and risers. Full article

This work evaluates the experimental test results regarding the operational performance of a free-float capable tension leg platform with a 10 MW wind turbine. It covers the platform dynamics in the selected installation area: Ribadeo, Spain. The model and the facility are initially presented, along with the experimental setup and the load cases. The testing campaign includes a software-in-the-loop method to emulate the rotor thrust and the aerodynamic and gyroscopic moments in pitch and yaw. The result sets are structured to start from basic information from system identification cases and continue with responses against regular and irregular waves accompanied by steady and stochastic wind scenarios. The performance in operational and extreme conditions is assessed as well as fault scenarios. The experiments demonstrate auspicious motion dynamics and mooring line behavior when examined against class society rules. Full article

A novel modular floating structure (MFS) system moored by tension legs was proposed, which is composed of hexagonal floating modules, floating artificial reefs and wave energy converters (WECs). The integration of floating artificial reefs and WECs into the MFS can improve the marine environment and produce considerable electricity. The effects of both wave characteristics and the module quantity on the hydrodynamic responses of the MFS system were studied in depth, based on a time-domain numerical model. Both the modules’ hydrodynamic interaction effect and the connectors’ mechanical coupling effect were considered. The results indicate that floating artificial reefs combined with WECs can effectively reduce wave loads and convert wave energy into electricity for the MFS system. More modules involved in the MFS system could significantly reduce motion response and produced more wave energy output, which indicates that the MFS system is suitable for large-scale expansion. The effect of different power take-off (PTO) damping coefficients on the WECs’ performance was further investigated, and the optimal damping coefficient was recommended for the MFS system. Finally, the main extreme responses of the MFS system were further investigated, and its safety was checked thoroughly. One survival strategy was proposed, which could efficiently reduce extreme connector loads by more than 50%. Full article

The open-source code DualSPHysics, based on the Smoothed Particle Hydrodynamics method for solving fluid mechanics problems, defines a complete numerical environment for simulating the interaction of floating structures with ocean waves, and includes external libraries to simulate kinematic- and dynamic-type restrictions. In this work, a full validation of the SPH framework using experimental data available for an experimental test campaign on a 1:37-scale floating offshore wind turbine tension-leg platform (TLP) is presented. The first set of validation cases includes a surge decay test, to assess the quality of the fluid–solid interaction, and regular wave tests, which stimulate the mooring system to a large extent. During this phase, tendons (tension legs) that are simulated by MoorDyn${}^{+}$ are validated. Spectral comparison shows that the model is able to capture the surge and pitch dynamic amplification that occurs around the resonant fundamental mode of vibration. This work concludes with a numerical investigation that estimates the response of TLP under extreme events defined using multiple realizations of irregular sea states; the results suggest that the tendon loads are sensitive to the sea-state realization, providing maximum tendon peak forces in a range of ±10% about the mean. Furthermore, it is shown that the load pattern that forms from considering the relative position of the tendons to the incident wave direction leads to higher forces (≈20%). Full article

Tension leg platform (TLP) is a cost-effective and high-performance support structure for floating offshore wind turbine (FOWT) because of its small responses in heave, pitch, and roll with the constraint of the tendons. China, as the largest market of offshore wind energy, has shown a demand for developing reliable, viable floating platform support structures, especially aiming at the intermediate water depth. The present paper described a newly proposed 10-MW Braceless-TLP FOWT designed for a moderate water depth of 60 m. The numerical simulations of the FOWT are carried out using the coupled aero-hydro-servo-elastic-mooring calculation tool FAST. The measured wind and wave data of the target site close to the Fujian Province of China were used to evaluate the performance of the FOWT under the 100-, 50-, 5-, and 2-year-return stochastic weather conditions. The natural periods of the platform in surge, sway, heave, pitch, roll, and yaw were found to be within the range recommended by the design standard DNV-RP-0286 Coupled Analysis of Floating Wind Turbines. The largest surge of the water depth ratio among all the load cases was 15%, which was smaller than the admissible ratio of 23%. The tower top displacements remained between −1 m and 1 m, which were at a similar order to those of a 10-MW monopile-supported offshore wind turbine. The six tendons remained tensioned during the simulation, even under the operational and extreme (parked) environmental conditions. The Braceless-TLP FOWT showed an overall satisfying performance in terms of the structural stability and illustrates the feasibility of this type of FOWT at such a moderate water depth. Full article

In this paper, fatigue analysis of oil offloading lines (OOLs) in the floating production storage and offloading (FPSO) catenary anchor leg mooring (CALM) buoy offloading system under wave and current loads in the West Africa Sea area is carried out by the numerical simulation method. The hydrodynamic coupling response is calculated, and fatigue damage is analyzed. Firstly, the numerical model is verified by comparison with the experimental results. Then, according to the environmental statistics in West Africa, the influence of various parameters on the fatigue damage of OOLs is analyzed, including tension characteristics, wave parameters, and structural parameters. Additionally, the effect of current load is studied. Results show that accumulated fatigue damage mainly occurs near the CALM buoy and is mainly caused by the 0° wind wave. Appropriately reducing the cover length of buoyancy material and increasing the wall thickness can reduce fatigue damage. Moreover, the effect of the shuttle tanker can increase the fatigue damage of the OOL near the CALM buoy by about 1.5 times, and the effect of vortex-induced vibration can increase the fatigue damage of the OOL in the middle part by up to 5–10 times. Full article

Recent design challenges in ocean observations, energy storage, offloading/discharging, and loading operations in both the offshore-renewable industry have led to advances in the application of catenary anchor leg moorings (CALM) buoys. Due to different seabed profiles, soil stiffness and environmental conditions, there is the need for numerical assessment to investigate the behaviour of the submarine hoses, based on the structural and hydrodynamic behaviour. In this study, experimental and numerical investigations are carried out on the dynamic behaviour of the submarine hoses attached to a CALM buoy in Lazy-S configuration. Six mooring lines are attached to the CALM buoy with a water depth of 100 m in the numerical model. A hydrodynamic model utilising ANSYS AQWA was developed then coupled unto the dynamic model in Orcina’s Orcaflex. The studies were carried out to study the effect of flow angles, wave height, soil stiffness and hydrodynamic loads on the structural behaviour of the submarine hoses. Waves at different angles to the submarine hose affected the effective tension more where the hose bends due to the floats attached. Parametric studies were carried out on both linear and nonlinear seabed models, and recommendations were made from the investigations on the submarine hose models. Full article

The present paper deals with the development of a multi-purpose floating tension leg platform (TLP) concept suitable for the combined offshore wind and wave energy resources exploitation, taking into account the prevailing environmental conditions at selected locations along the European coastline. The examined Renewable Energy Multi-Purpose Floating Offshore System (REFOS) platform encompasses an array of hydrodynamically interacting oscillating water column (OWC) devices, moored through tensioned tethers as a TLP platform supporting a 10 MW wind turbine (WT). The system consists of a triangular platform supported by cylindrical floaters, with the WT mounted at the deck’s center and the cylindrical OWC devices at its corners. Details of the modelling of the system are discussed and hydro-aero-elastic coupling between the floater; the mooring system; and the WT is presented. The analysis incorporates the solutions of the diffraction; the motion- and the pressure-dependent radiation problems around the moored structure, along with the aerodynamics of the WT into an integrated design approach validated through extensive experimental hydrodynamic scaled-down model tests. The verified theoretical results attest to the importance of the WT loading and the OWC characteristics on the dynamics of the system. Full article
