The LuTan-1 (LT-1) satellite, launched in 2022, is China’s first L-band full-polarimetric Synthetic Aperture Radar (SAR) constellation, boasting interferometry capabilities. However, given its limited use in subsidence monitoring to date, a comprehensive evaluation of LT-1’s interferometric quality and capabilities is necessary. In this study, we utilized the Differential Interferometric Synthetic Aperture Radar (DInSAR) technique to analyze mining-induced subsidence results near Shenmu City (China) with LT-1 data, revealing nine subsidence areas with a maximum subsidence of −19.6 mm within 32 days. Furthermore, a comparative analysis between LT-1 and Sentinel-1 data was conducted focusing on the aspects of subsidence results, interferometric phase, scattering intensity, and interferometric coherence. Notably, LT-1 detected some subsidence areas larger than those identified by Sentinel-1, attributed to LT-1’s high resolution, which significantly enhances the detectability of deformation gradients. Additionally, the coherence of LT-1 data exceeded that of Sentinel-1 due to LT-1’s L-band long wavelength compared to Sentinel-1’s C-band. This higher coherence facilitated more accurate capturing of differential interferometric phases, particularly in areas with large-gradient subsidence. Moreover, the quality of LT-1’s monitoring results surpassed that of Sentinel-1 in root mean square error (RMSE), standard deviation (SD), and signal-to-noise ratio (SNR). In conclusion, these findings provide valuable insights for future subsidence-monitoring tasks utilizing LT-1 data. Ultimately, the systematic differences between LT-1 and Sentinel-1 satellites confirm that LT-1 is well-suited for detailed and accurate subsidence monitoring in complex environments. Full article

We demonstrate measurements of the absorption coefficient α ≈ 2.5 × 10⁻⁷ cm⁻¹ in synthetic crystalline quartz at a wavelength of 1071 nm with a signal-to-noise ratio of 10/1 using the Time-resolved photothermal common-path interferometry (TPCI) scheme. It utilized cells filled with flowing argon and eliminated the influence of ambient air absorption. The scheme elements limiting the sensitivity of measurements at the level of ≈7.8 × 10⁻⁸ cm⁻¹ were revealed. When these elements are replaced by better ones in terms of their thermal influence, the sensitivity of absorption coefficient measurements in crystalline quartz is ~10⁻⁸ cm⁻¹. The calculation of the correction due to these optical elements of the values of the measured absorption coefficients is also described, which makes it possible to achieve the same sensitivity without replacing the elements. The improved scheme confirms the presence of the spatial inhomogeneity of absorption with a minimum coefficient of 2.5 × 10⁻⁷ cm⁻¹ in synthetic crystalline quartz. The discrepancy of the absorption coefficient values in different regions of the crystal in the presented series of experiments was 2.5 × 10⁻⁷ cm⁻¹ to 4 × 10⁻⁶ cm⁻¹. Taking into account the ratio of thermo-optical parameters and the heat diffusion effect, the calculation shows that for quartz glasses the corresponding sensitivity of the absorption coefficient measurements equals ≈1.5 × 10⁻⁹ cm⁻¹. Full article

Absolute distance measurements based on optical frequency combs (OFCs) have greatly promoted advances in both science and technology, owing to the high precision, large non-ambiguity range (NAR), and a high update rate. However, cyclic error, which is extremely difficult to eliminate, reduces the linearity of measurement results. In this study, we quantitatively investigated the impact of cyclic error on absolute distance measurement using OFCs based on two types of interferometry: synthetic wavelength interferometry and single-wavelength interferometry. The numerical calculations indicate that selecting a suitable reference path length can minimize the impact of cyclic error when combining the two types of interferometry. Recommendations for selecting an appropriate synthetic wavelength to address the tradeoff between achieving a large NAR and minimizing the risk of failure when combining the two methods are provided. The results of this study are applicable not only in absolute distance measurements but also in other applications based on OFCs, such as surface profile, vibration analysis, etc. Full article

The unique P-band synthetic aperture radar (SAR) instrument, BIOMASS, is scheduled for launch in 2024. This satellite will enhance the estimation of subcanopy topography, owing to its strong penetration and fully polarimetric observation capability. In order to conduct global-scale mapping of the subcanopy topography, it is crucial to calibrate systematic errors of different strips through interferometric SAR (InSAR) DEM (digital elevation model) block adjustment. Furthermore, the BIOMASS mission will operate in repeat-pass interferometric mode, facing the atmospheric delay errors introduced by changes in atmospheric conditions. However, the existing block adjustment methods aim to calibrate systematic errors in bistatic mode, which can avoid possible errors from atmospheric effects through interferometry. Therefore, there is still a lack of systematic error calibration methods under the interference of atmospheric effects. To address this issue, we propose a block adjustment model considering atmospheric effects. Our model begins by employing the sub-aperture decomposition technique to form forward-looking and backward-looking interferograms, then multi-resolution weighted correlation analysis based on sub-aperture interferograms (SA-MRWCA) is utilized to detect atmospheric delay errors. Subsequently, the block adjustment model considering atmospheric effects can be established based on the SA-MRWCA. Finally, we use robust Helmert variance component estimation (RHVCE) to build the posterior stochastic model to improve parameter estimation accuracy. Due to the lack of spaceborne P-band data, this paper utilized L-band Advanced Land Observing Satellite (ALOS)-1 PALSAR data, which is also long-wavelength, to emulate systematic error calibration of the BIOMASS mission. We chose climatically diverse inland regions of Asia and the coastal regions of South America to assess the model’s effectiveness. The results show that the proposed block adjustment model considering atmospheric effects improved accuracy by 72.2% in the inland test site, with root mean square error (RMSE) decreasing from 10.85 m to 3.02 m. Moreover, the accuracy in the coastal test site improved by 80.2%, with RMSE decreasing from 16.19 m to 3.22 m. Full article

In this study, repeat-pass synthetic aperture radar interferometry (repeat-pass THz InSAR) is first extended to the terahertz band, and it has tremendous potential in the application of high-resolution three-dimensional (3D) imaging due to its shorter wavelength, larger bandwidth, and greater sensitivity to elevation variation. The super-resolution and high sensitivity of THz InSAR pose greater demands on the baseline calibration for high-precision digital elevation model (DEM) generation. To meet the elevation accuracy requirement of THz InSAR, we propose a baseline calibration method relying on the estimation of the azimuth fringe frequency (EAFF) of the interferometric phase. Initially, a model for non-parallel sampling path errors within the squint SAR repeat-pass interferometry was established, and then, we conducted the theoretical analysis of the phase errors induced by the non-parallel errors. Following this, using a reference DEM, the relationship between the fringe frequency of the error phase and the bias in the repeat-path positioning was established. This allowed the estimation of the position errors to be transformed into the frequency spectrum estimation based on the FFT, which would mitigate the impact of unknown SAR sampling positions. Ultimately, we investigated the accuracy of the proposed EAFF calibration method, and the simulation showed that it can achieve the theoretical accuracy when the correlation coefficient exceeds 0.3. Furthermore, we configured the repeat-pass THz InSAR system with the 0.3 THz stepped-frequency radar. Compared to the conventional calibration based on ground control points (GCPs), the 3D reconstruction of both a knife and a terrain model, calibrated using the proposed EAFF algorithm, demonstrated that the elevation accuracy can achieve millimeter-level precision across the entire image swath. The above results also proved the great potential of THz InSAR in high-precision 3D imaging and remote sensing. Full article

Accurate estimation of forest height over a large area is beneficial to reduce the uncertainty of forest carbon sink estimation, which is of great significance to the terrestrial carbon cycle, global climate change, forest resource management, and forest-related scientific research. Forest height inversion using polarimetric interferometry synthetic aperture radar (PolInSAR) data through Random volume over ground (RVoG) models has demonstrated great potential for large-area forest height mapping. However, the wavelength and baseline length used for the PolInSAR data acquisition plays an important role during the forest height estimation procedure. In this paper, X–, C–, L–, and P–band PolInSAR datasets with four different baseline lengths were simulated and applied to explore the effects of wavelength and baseline length on forest height inversion using RVoG models. Hierarchical Bayesian models developed with a likelihood function of RVoG model were developed for estimated results uncertainty quantification and decrease. Then a similar procedure was applied in the L– and P–band airborne PolInSAR datasets with three different baselines for each band. The results showed that (1) Wavelength showed obvious effects on forest height inversion results with the RVoG model. For the simulated PolInSAR datasets, the L– and P–bands performed better than the X– and C–bands. The best performance was obtained at the P–band with a baseline combination of 10 × 4 m with an absolute error of 0.05 m and an accuracy of 97%. For the airborne PolInSAR datasets, an L–band with the longest baseline of 24 m in this study showed the best performance with R² = 0.64, RMSE = 3.32 m, and Acc. = 77.78%. (2) It is crucial to select suitable baseline lengths to obtain accurate forest height estimation results. In the four baseline combinations of simulated PolInSAR datasets, the baseline combination of 10 × 4 m both at the L– and P–bands performed best than other baseline combinations. While for the airborne PolInSAR datasets, the longest baseline in three different baselines obtained the highest accuracy at both L– and P–bands. (3) Bayesian framework is useful for estimation results uncertainty quantification and decrease. The uncertainties related to wavelength and baseline length. The uncertainties were reduced obviously at longer wavelengths and suitable baselines. Full article

In this study, we investigated the quality of Interferometric Synthetic Aperture Radar (InSAR) data to measure surface displacements in upstate New York, an area with dense vegetation, snowy winters, and strong seasonal signals. We used data from the German Space Agency’s TerraSAR-X and TanDEM-X satellites (X-band, 3.1 cm radar wavelength) as well as the European Space Agency’s Sentinel-1 satellite (C-band, 5.6 cm radar wavelength); both datasets covered a ~3-year time period from 2018 to 2021. Using persistent scatterer interferometry (PSI), we were able to observe several deforming features in the region with sub-centimeter/year deformation rates. We also examined a version of the X-band data that we spatially averaged to the same pixel size as the Sentinel-1 imagery in order to separate out the effects of wavelength and pixel size on PSI accuracy and coverage. Overall, the largest number of stable PS points was found in the full-resolution X-band data, which was followed by the C-band data and then by the downsampled X-band data. Our analysis also included a subset of snow-free imagery so that we could assess the effect that snow-covered images had on the distribution and accuracy of PS points and the resulting time series. This analysis revealed that PS populations increased by 50–60% for the snow-free data when compared with analyses using the full datasets. The average deformation rates inferred from the time series generated using only snow-free images were nearly identical to those estimated from the full time series. We assessed the accuracy of the inferred rates through comparisons between the results of different datasets and with limited ground survey data. We found that all of the inferred deformation rates from each of the datasets agreed with in situ measurements in an area of known ground subsidence above an underground salt mine in Lansing, NY. The S1 datasets, however, had higher levels of noise. Full article

Differential synthetic aperture radar interferometry (InSAR) is widely used to monitor ground surface deformation due to its wide coverage and high accuracy. However, the large-scale and rapid deformation that occurs in mining areas often leads to densely spaced interference fringes, thus, severely limiting the applicability of D-InSAR in mining subsidence monitoring. Sub-band InSAR can reduce phase gradients in interferograms by increasing the simulated wavelength, thereby characterising large-scale surface deformations. Nonetheless, accurate registration between non-overlapping sub-band images with conventional sub-band InSAR is challenging. Therefore, our study proposed a new sub-band InSAR deformation extraction method, based on raw full-bandwidth single-look complex image pair registration data to facilitate sub-band interferometric processing. Simulations under noiseless conditions demonstrated that the maximum difference between the sub-band InSAR-monitored results and real surface deformations was 26 mm (1.86% of maximum vertical deformation), which theoretically meets the requirements for mining subsidence monitoring. However, when modelling dynamic deformation with noise, the sub-band InSAR-simulated wavelength could not be optimised for surface deformation due to the limitation in current SAR satellite bandwidths, which resulted in significantly noisy and undistinguishable interference fringes. Nonetheless, this method could still be advantageous in high-coherence regions where surface deformation exceeds 1/5th of the simulated wavelength. Full article

Because the penetration depth of electromagnetic waves in forests is large in the longer wavelength band, most traditional forest height estimation methods are carried out using polarimetric interferometry synthetic aperture radar (PolInSAR) data of the L or P band, and the estimation method is a three-stage method based on the random volume over ground (RVoG) model. For X-band electromagnetic waves, the penetration depth of radar waves in forests is limited, so the traditional forest height estimation method is no longer applicable. In view of the above problems, in this paper we propose a new forest height estimation strategy for airborne X-band PolInSAR data. Firstly, the sub-view interferometric SAR pairs obtained via frequency segmentation (FS) in the Doppler domain are used to extend the polarimetric interferometry coherence coefficient (PolInCC) range of the original SAR image under different polarization states, so as to obtain the accurate ground phase. For the determination of the effective volume coherence coefficient (VCC), part of the fitting line of the extended-range PolInCC distribution that is intercepted by the fixed extinction coherence coefficient curve (FECCC) of the fixed range is averaged to obtain the accurate effective VCC. Finally, the high-precision forest canopy height in the X-band is estimated using the effective VCC with the ground phase removed in the look-up table (LUT). The effectiveness of the proposed method was verified using airborne-measured data obtained in Shaanxi Province, China. The comparison was carried out using different strategies, in which we substituted one step of the process with the conventional method. The results indicated that our new strategy could reduce the root mean square error (RMSE) of the predicted canopy height vastly to 1.02 m, with a lower estimation height error of 12.86%. Full article

Polarimetric Interferometric Synthetic Aperture Radar (PolInSAR) has many useful applications, especially in forest areas. With the development of SAR miniaturization technology, researchers can install PolInSAR on small unmanned aerial vehicles (UAV), which can reduce flight costs. Limited by size and power, UAV-borne SAR usually works in a high-frequency band, which restricts its application to such things as vegetation height inversion. While on the other hand, the high resolution acquired under a short wavelength promises its application in urban areas. However, there are fewer studies on the application of PolInSAR in urban areas compared with that in forest areas. In this paper, we propose a processing method for a Ku-band multi-rotor-UAV-borne PolInSAR and provide a preliminary analysis of height inversion results on its data from the Fudan campus in Shanghai. We obtain the digital surface model (DSM) of different polarization modes and the DSM of polarimetric interferometry optimal decomposition in this area, whose RMSE is 2.88 m. On this basis, the elevation inversion results of targets such as buildings, lampposts, and trees are compared and analyzed. We preliminarily explore and analyze the reasons for the different results of different targets. To this end, we propose a mathematical derivation of the relationship between the interferometric phase between PolInSAR and InSAR of Pauli decomposition. We also perform a simulation to analyze the relationship between the phase center height of Pauli decomposition and PolInSAR under different cases. It provides a reference for the application of small UAV-borne PolInSAR in urban areas. Full article

Synthetic Aperture Radar Interferometry (InSAR) is a space geodetic technique used for mapping deformations of the Earth’s surface. It has been developed and used increasingly during the last thirty years to measure displacements produced by earthquakes, volcanic activity and other crustal deformations. A limiting factor to this technique is the effect of the troposphere, as spatial and temporal variations in temperature, pressure, and relative humidity introduce significant phase delays in the microwave imagery, thus “masking” surface displacements due to tectonic or other geophysical processes. The use of Numerical Weather Prediction (NWP) models as a tropospheric correction method in InSAR can tackle several of the problems faced with other correction techniques (such as timing, spatial coverage and data availability issues). High-resolution tropospheric modelling is particularly useful in the case of single interferograms, where the removal of the atmospheric phase screen (and especially the highly variable turbulent component) can reveal large-amplitude deformation signals (as in the case of an earthquake). In the western Gulf of Corinth, prominent topography makes the removal of both the stratified and turbulent atmospheric phase screens a challenging task. Here, we investigate the extent to which a high-resolution WRF 1-km re-analysis can produce detailed tropospheric delay maps of the required accuracy by coupling its output (in terms of Zenith Total Delay or ZTD) with the vertical delay component in GNSS measurements. The model is operated with varying physical parameterization in order to identify the best configuration, and validated with GNSS zenithal tropospheric delays, providing a benchmark of real atmospheric conditions. We correct sixteen Sentinel-1A interferograms with differential delay maps at the line-of-sight (LOS) produced by WRF re-analysis. In most cases, corrections lead to a decrease in the phase gradient, with average root-mean-square (RMS) and standard deviation (SD) reductions in the wrapped phase of 6.0% and 19.3%, respectively. Results suggest a high potential of the model to reproduce both the long-wavelength stratified atmospheric signal and the short-wave turbulent atmospheric component which are evident in the interferograms. Full article

In the last thirty years, Synthetic Aperture Radar interferometry (InSAR) and the Global Navigation Satellite System (GNSS) have become fundamental space geodetic techniques for mapping surface deformations due to tectonic movements. One major limiting factor to those techniques is the effect of the troposphere, as surface velocities are of the order of a few mm yr⁻¹, and high accuracy (to mm level) is required. The troposphere introduces a path delay in the microwave signal, which, in the case of GNSS Precise Point Positioning (PPP), can nowadays be partly removed with the use of specialized mapping functions. Moreover, tropospheric stratification and short wavelength spatial turbulences produce an additive noise to the low amplitude ground deformations calculated by the (multitemporal) InSAR methodology. InSAR atmospheric phase delay corrections are much more challenging, as opposed to GNSS PPP, due to the single pass geometry and the gridded nature of the acquired data. Thus, the precise knowledge of the tropospheric parameters along the propagation medium is extremely useful for the estimation and correction of the atmospheric phase delay. In this context, the PaTrop experiment aims to maximize the potential of using a high-resolution Limited-Area Model for the calculation and removal of the tropospheric noise from InSAR data, by following a synergistic approach and integrating all the latest advances in the fields of remote sensing meteorology (GNSS and InSAR) and Numerical Weather Forecasting (WRF). In the first phase of the experiment, presented in the current paper, we investigate the extent to which a high-resolution 1 km WRF weather re-analysis can produce detailed tropospheric delay maps of the required accuracy, by coupling its output (in terms of Zenith Total Delay or ZTD) with the vertical delay component in GNSS measurements. The model is initially operated with varying parameterization, with GNSS measurements providing a benchmark of real atmospheric conditions. Subsequently, the final WRF daily re-analysis run covers an extended period of one year, based on the optimum model parameterization scheme demonstrated by the parametric analysis. The two datasets (predicted and observed) are compared and statistically evaluated, in order to investigate the extent to which meteorological parameters that affect ZTD can be simulated accurately by the model under different weather conditions. Results demonstrate a strong correlation between predicted and observed ZTDs at the 19 GNSS stations throughout the year (R ranges from 0.91 to 0.93), with an average mean bias (MB) of –19.2 mm, indicating that the model tends to slightly underestimate the tropospheric ZTD as compared to the GNSS derived values. With respect to the seasonal component, model performance is better during the autumn period (October–December), followed by spring (April–June). Setting the acceptable bias range at ±23 mm (equal to the amplitude of one Sentinel-1 C-band phase cycle when projected to the zenithal distance), it is demonstrated that the model produces satisfactory results, with a percentage of ZTD values within the bias margin ranging from 57% in summer to 63% in autumn. Full article

Mass movements represent a serious threat to the stability of human structures and infrastructures, and cause loss of lives and severe damages to human properties every year worldwide. Built structures located on potentially unstable slopes are susceptible to deformations due to the displacement of the ground that at worst can lead to total destruction. Synthetic aperture radar (SAR) data acquired by Sentinel-1 satellites and processed by multi-temporal interferometric SAR (MT-InSAR) techniques can measure centimeter to millimeter-level displacement with weekly to monthly updates, characterizing long-term large-scale behavior of the buildings and slopes. However, the spatial resolution and short wavelength weaken the performance of Sentinel-1 in recognizing features (i.e., single buildings) inside image pixels and maintaining the coherence in mountainous vegetated areas. We have proposed and applied a methodology that combines Sentinel-1 interferometry with ground-based geomatics techniques, i.e., global navigation satellite system (GNSS), terrestrial laser scanning (TLS) and terrestrial structure from motion photogrammetry (SfM), for fully assessing building deformations on a slope located in the north-eastern Italian pre-Alps. GNSS allows verifying the ground deformation estimated by MT-InSAR and provides a reference system for the TLS and SfM measurements, while TLS and SfM allow the behavior of buildings located in the investigated slope to be monitored in great detail. The obtained results show that damaged buildings are located in the most unstable sectors of the slope, but there is no direct relationship between the rate of ground deformation of these sectors and the temporal evolution of damages to a single building, indicating that mass movements cause the displacement of blocks of buildings and each of them reacts differently according to its structural properties. This work shows the capability of MT-InSAR, GNSS, TLS and SfM in monitoring both buildings and geological processes that affect their stability, which plays a key role in geohazard analysis and assessment. Full article

Spaceborne and airborne polarimetric synthetic-aperture radar interferometry (PolInSAR) data have been extensively used for forest parameter retrieval. The PolInSAR models have proven their potential in the accurate measurement of forest vegetation height. Spaceborne monostatic multifrequency data of different SAR missions and the Global Ecosystem Dynamics Investigation (GEDI)-derived forest canopy height map were used in this study for vegetation height retrieval. This study tested the performance of PolInSAR complex coherence-based inversion models for estimating the vegetation height of the forest ranges of Doon Valley, Uttarakhand, India. The inversion-based forest height obtained from the three-stage inversion (TSI) model had higher accuracy than the coherence amplitude inversion (CAI) model-based estimates. The vegetation height values of GEDI-derived canopy height map did not show good relation with field-measured forest height values. It was found that, at several locations, GEDI-derived forest height values underestimated the vegetation height. The statistical analysis of the GEDI-derived estimates with field-measured height showed a high root mean square error (RMSE; 5.82 m) and standard error (SE; 5.33 m) with a very low coefficient of determination (R²; 0.0022). An analysis of the spaceborne-mission-based forest height values suggested that the L-band SAR has great potential in forest height retrieval. TSI-model-based forest height values showed lower p-values, which indicates the significant relation between modelled and field-measured forest height values. A comparison of the results obtained from different SAR systems is discussed, and it is observed that the L-band-based PolInSAR inversion gives the most reliable result with low RMSE (2.87 m) and relatively higher R² (0.53) for the linear regression analysis between the modelled tree height and the field data. These results indicate that higher wavelength PolInSAR datasets are more suitable for tree canopy height estimation using the PolInSAR inversion technique. Full article

Differential synthetic aperture radar interferometry (DInSAR) has been widely applied since the pioneering space-borne experiment in 1989, and subsequently with the launch of the ERS-1 program in 1992. The DInSAR technique is well assessed in the case of space-borne SAR data, whereas in the case of data acquired from aerial platforms, such as airplanes, helicopters, and drones, the effective application of this technique is still a challenging task, mainly due to the limited accuracy of the information provided by the navigation systems mounted onboard the platforms. The first airborne DInSAR results for measuring ground displacement appeared in 2003 using L- and X-bands. DInSAR displacement results with long correlation time in P-band were published in 2011. This letter presents a SAR system and, to the best of our knowledge, the first accuracy assessment of the DInSAR technique using a drone-borne SAR in L-band. A deformation map is shown, and the accuracy and resolution of the methodology are presented and discussed. In particular, we have obtained an accuracy better than 1 cm for the measurement of the observed ground displacement. It is in the same order as that achieved with space-borne systems in C- and X-bands and the airborne systems in X-band. However, compared to these systems, we use here a much longer wavelength. Moreover, compared to the satellite experiments available in the literature and aimed at assessing the accuracy of the DInSAR technique, we use only two flight tracks with low time decorrelation effects and not a big data stack, which helps in reducing the atmospheric effects. Full article
