Search Results (544)

The increasing integration of renewable energy sources into interconnected multi-area power systems (IMAPSs) has led to a significant reduction in synchronous inertia, making frequency regulation considerably more challenging. While existing studies have explored the use of integral sliding mode load frequency control (ISMLFC) schemes to stabilize area frequency and tie-line power flows in IMAPSs, these approaches predominantly rely on conventional two-phase sliding mode control. Such methods, however, have demonstrated notable limitations in maintaining the stability of IMAPSs under increasingly complex operating conditions. In addition, all the IMAPS state variables must be measured, which can cause difficulty in real IMAPS applications. Therefore, this study proposes a novel load frequency control (LFC) strategy that coordinates the single-phase sliding mode control and state observer methods to solve these above limitations. First, a dynamic IMAPS model with single phase sliding mode control based on state observer scheme is established under renewable resource uncertainties and load disturbances. Then, a novel linear matrix inequality (LMI) based on Lyapunov functional is constructed to analyze the stability of the IMAPS. Furthermore, the decentralized single-phase sliding mode load frequency control (DSPSMLFC) method is developed for the LFC of the ISMLFC. Finally, three testing scenarios are employed to verify the efficiency and advantage of the proposed DSPSMLFC approach in MATLAB/Simulink R2023a. The simulation results confirm that the proposed DSPSMLFC scheme can improve the LFC of the IMAPS under renewable resource uncertainties and load disturbances. Full article

Grid-forming virtual synchronous generator control can improve the frequency-support capability of converter-interfaced systems. However, under successive disturbances and varying operating conditions, fixed inertia and damping settings often struggle to balance inertial response, oscillation suppression, and recovery speed. To address this issue, this paper develops an adaptive parameter coordination strategy for grid-forming virtual synchronous generators by using frequency deviation and rate of change of frequency as dynamic indicators. A piecewise regulation law is established to adjust virtual inertia and damping during different transient stages, while an improved parrot optimization algorithm is introduced for the offline coordinated tuning of the adaptive-law parameters. In the proposed optimizer, SPM-chaotic initialization, adaptive probability adjustment, and Cauchy-Gaussian hybrid mutation are incorporated to improve population diversity, convergence efficiency, and local refinement capability. Simulation results obtained in MATLAB/Simulink under successive disturbance events show that the proposed strategy achieves smaller frequency excursions, weaker secondary oscillations, and shorter settling times than fixed-parameter control and standard PO-based tuning. The results demonstrate that the proposed method can effectively enhance the dynamic support capability and disturbance adaptability of grid-forming virtual synchronous generators under complex operating conditions. Full article

As power grids transition towards highly renewable generation on a global scale, maintaining dynamic stability is becoming a major challenge. Replacing traditional synchronous generators with inverter-based renewables strips the grid of rotational inertia, leaving active distribution networks highly vulnerable to frequency deviations and voltage spikes. To avoid expensive poles and wires upgrades, Battery Energy Storage Systems (BESS) are increasingly being deployed as Non-Network Solutions (NNS). However, the current literature reveals a distinct gap between the macro-scale economic planning of these storage assets and the micro-scale dynamic control actually required to keep the grid resilient. To address this gap, this review proposes a multi-layer deterministic synthesis framework that links physical renewable modelling, degradation-aware techno-economic planning, deterministic forecasting, and EMS dispatch through offline time-domain control validation for AC-microgrid energy storage integration. The research examines how advanced central control units within battery management systems can rigorously and jointly estimate State of Charge (SoC) and State of Energy (SoE) to ensure accurate grid-aware dispatch. Furthermore, the study explores the integration of degradation-aware economic modelling in HOMER Pro with dynamic transient control in MATLAB/Simulink R2025b, driven by hybrid metaheuristic optimization algorithms like Grey Wolf Optimizer (GWO) and Particle Swarm Optimization (PSO). This analysis demonstrates that integrating energy storage must be treated as a tightly coupled multidimensional optimization problem to successfully deliver the secure and sustainable infrastructure needed to solve the modern energy trilemma. Full article

This paper presents the modelling and dynamic analysis of a Virtual Synchronous Generator (VSG) operating under three representative load models: constant impedance (Z), constant power load (CPL), and composite ZIP (constant impedance, constant current, and constant power) loads. The VSG control strategy enables voltage-source converters to emulate the inertial behavior of synchronous machines. However, load characteristics strongly affect the stability of such systems, and CPLs can be particularly destabilizing because of their negative incremental impedance. This study provides a theoretical and simulation-based analysis of VSG performance under Z-, CPL, and ZIP load conditions. A swing-equation-based control model is linearized to obtain a reduced-order small-signal stability model. The incremental impedance properties of the load types are evaluated analytically, showing that CPL behavior reduces effective damping and can destabilize the system. The resulting analytical stability condition provides a practical basis for selecting virtual inertia and damping parameters. Practical DC-side energy storage and current-limiting constraints associated with inertia emulation are also discussed. The analysis is supported by simulation studies that quantify the influence of load dynamics on frequency stability and transient response. In contrast to current research, this paper offers a single comparative framework in which all load types are analyzed under the same operating conditions and derives analytical stability conditions that inform the selection of virtual inertia and damping parameters. Full article

The displacement of synchronous generators by inverter-based renewable energy sources (RES) has eroded system inertia, weakening frequency stability even as voltage stability improves. This paradox poses a major challenge for modern grids. Battery Energy Storage Systems (BESS) offer synthetic inertia and rapid frequency response, but their stabilising impact depends critically on placement. Using dynamic simulations on the IEEE 9-bus system, this study demonstrates the voltage–frequency paradox across increasing RES penetration. Results show that strategic siting prevents frequency collapse while enhancing voltage recovery, providing a unified mitigation strategy for high-renewable systems. Full article

This paper presents a capability-aware frequency control strategy for microgrids comprising a ramp-rate-limited synchronous generator (SG) and a bounded inverter-based resource (IBR). In contrast to conventional droop and virtual inertia methods, the proposed design activates IBR support according to whether the required power-rate exceeds the ramp-rate capability of synchronous generation. A smooth activation mechanism detects when the required power-ramp demand exceeds the SG ramp-rate limit. The IBR is then engaged to supply the excess ramping requirement while providing additional damping through frequency-deviation feedback. A two-timescale model is formulated, where the IBR power-tracking dynamics evolve on a fast boundary-layer timescale. In contrast, the SG regulation loop evolves on a slow electromechanical timescale. Using singular perturbation theory combined with Lyapunov and input-to-state stability (ISS) analysis, local practical stability of the closed-loop system is established for sufficiently fast IBR dynamics. The proposed framework yields a physically interpretable coordination mechanism that exploits the fast response of IBR without introducing artificial inertia or frequency-domain disturbance splitting. Full article

With the rising trend of replacing synchronous generators with inverter-based resources, the grid inertia, frequency control, voltage stability, and fault ride-through are compromised. The current research focuses on the coordinated control of Voltage Source Converter-based HVDC (VSC HVDC) and Battery Energy Storage Systems (BESS) for improving the grid stability in the presence of intermittent sources. Two models are created in the MATLAB/Simulink 2025a environment: one for the grid-connected PV system with the addition of BESS in grid-forming mode (GFM) and grid-following mode (GFL), and the other for the multi-terminal HVDC system with the integration of wind energy from the ocean. The results show that the grid-forming converters perform better than grid-following converters in the event of disturbances, and the coordinated control structure aligns with the IEEE 2800-2022 for low-inertia grids. Full article

This study investigates the coordinated impact of a synchronous condenser (SC), battery energy storage system (BESS), and static synchronous compensator (STATCOM) on enhancing voltage and frequency stability in a modified IEEE 9-bus power system under severe disturbances. The aim is to quantify the individual and combined contributions of these technologies during both fault ride-through (FRT) and load-increment events. The methodology includes dynamic modelling of all three devices in DIgSILENT PowerFactory. The SC is represented as a synchronous machine with inertia and AVR-based voltage control; the BESS employs converter-based active power and frequency-droop control; and the STATCOM provides fast reactive power injection through a dual-loop voltage regulator. Key indicators include nadir (minimum frequency), Rate of Change of Frequency (RoCoF), steady-state deviation, voltage sag depth, and recovery characteristics. Results indicate distinct roles for each device. The SC increases inertia and improves damping, but it also introduces small, well-damped oscillations. The BESS significantly enhances frequency stability by mitigating nadir, reducing RoCoF, and accelerating recovery, with negligible effect on voltage regulation. The STATCOM substantially reduces voltage sag and speeds up voltage recovery, but it does not influence frequency behaviour. When combined, the hybrid SC–BESS–STATCOM system demonstrates strong complementarity: the SC supports inertia, the BESS stabilizes active-power imbalance, and the STATCOM ensures fast reactive-power compensation. Full article

In this paper, we advance the concept of an electronic controller for switching devices actuated by means of direct current (DC) electromagnets. Based on the method of controlling the supply voltage delivery and disconnection moment to the drive coil, it is feasible to control switching-on and switching-off operations of an electromagnetic (EM) circuit-breaker (CB). The developed control method, built upon an ATmega328P microcontroller and operating in the Arduino IDE 2.3.4 environment, minimizes the impact of CB moving part inertia and drive coil (de)energization time. As a result, it enables contacts to be made at the near-to-zero point of the voltage waveform and contacts to break at the near-to-zero point of the current waveform. Consequently, the implementation of the proposed synchronized switching (SS) method allows the minimization of overvoltages and overcurrents during switching operations. Through continuous monitoring of the drive coil supply source parameters, the developed electronic controller allows for minimizing the impact of potential voltage fluctuations on CB switching parameters. Extensive laboratory tests confirmed the effectiveness of the proposed controller and applied method for controlling various types and sizes of EM contactors and relays. Full article

To address the increasingly prominent challenges of “low inertia” and “weak damping” in modern power systems, grid-forming (GFM) control technologies with inertia and damping support capabilities are being extensively adopted. However, distributed generation units interfaced with GFM inverters are highly susceptible to overcurrent phenomena during grid short-circuit faults. Existing research primarily focuses on current-limiting control strategies for virtual synchronous generators (VSGs), while investigations into their fault current characteristics remain insufficient. Given this, this paper proposes a short-circuit current calculation methodology for VSG-based PV-storage grid-connected systems. First, a model of a grid-forming PV-storage grid-connected system based on virtual synchronous control is established. Subsequently, the virtual impedance is solved within the timescale of current inner-loop stabilization, and the virtual internal electromotive force (EMF) equation for the VSG is formulated. This leads to the derivation of an analytical expression for the VSG short-circuit current, accounting for variations in the virtual internal potential. Furthermore, the impacts of diverse control parameters and fault severities on the short-circuit current are investigated based on this expression. Finally, simulations are conducted on the MATLAB/Simulink(R2024b) platform to validate the accuracy of the proposed short-circuit current calculation method and the correctness of the analysis regarding the influencing factors. Full article

The grid-forming (GFM) wind turbine with energy storage is regarded as a promising solution for the integration of renewable energy sources (RESs) into power systems. However, the system faces the risk of instability during large grid disturbances, such as grid voltage sags and frequency variations. To address this issue, this paper proposes a coordinated control method to enhance the transient stability of GFM wind turbines with energy storage. First, a permanent magnet synchronous generator (PMSG)-based wind turbine employing grid-forming control and integrated with an energy storage system is introduced. Then, transient stability cases are identified based on the equal area criterion (EAC) within the virtual synchronous generator (VSG) control framework. On this basis, a low-voltage ride-through (LVRT) method is developed by coordinately adjusting inertia, damping, and active power reference according to fault severity, thereby ensuring system stability under low-voltage grid fault. Furthermore, a frequency fluctuation mitigation (FFM) is proposed to suppress power oscillations under frequency disturbances. The coordinated LVRT and FFM methods enable effective stabilization of the system under grid voltage and frequency faults. Finally, simulation results validate the theoretical analysis and demonstrate the effectiveness of the proposed control strategy. Full article

The increasing penetration of inverter-based renewable energy resources, especially photovoltaic (PV) systems, has decreased the available system inertia and introduced challenges in maintaining stable grid-forming operation. This paper presents a grid-forming photovoltaic multilevel inverter (MLI) with a modified delta-connected cascaded H-bridge (CHB) multilevel configuration. The proposed system decreases the number of semiconductor switches and provides inherent voltage balancing, while also achieving high power quality, rendering it suitable for grid-forming applications. Each H-bridge cell is connected to an isolated Cúk converter to enable maximum power point tracking (MPPT) of distributed PV modules, allowing for flexible and modular DC-side integration. The proposed MLI operates as a virtual synchronous generator. A control scheme is proposed to attain grid-forming capability, hence providing stable voltage and frequency support. Moreover, a DC-link voltage regulation strategy is also developed to maintain the DC-link voltage at the reference voltage. A detailed mathematical model is developed to characterize the associated dynamics of the proposed MLI and the control system with a grid interface. The model is built in the SIMULINK environment, and the simulation results are presented under variations in solar radiation and grid voltage disturbances to exhibit the functionality of the proposed system and the effectiveness of the control scheme in providing a well-damped frequency response and stable generated voltage and currents. The results demonstrate stable frequency regulation with a settling time of approximately 0.3 s, and the output current exhibits low harmonic distortion, with a Total Harmonic Distortion (THD) of about 0.53%. Simulation results show stable operation and confirm that the proposed approach is a competitive solution for PV-based grid-forming applications. Full article

This study examines the impact of increasing photovoltaic (PV) penetration on the transient stability of the IEEE 9-bus power system. Synchronous machines are modeled with standard subtransient dynamics, while PV units are represented as current-limited grid-following inverters. Transient stability is assessed through the Critical Clearing Time (CCT) and the post-fault dynamic behavior, obtained from time-domain simulations carried out in MATLAB/Simulink^® R2023b. Two permanent three-phase faults are considered: a primary contingency on line 7–5 and a secondary contingency on line 9–6, introduced to assess the robustness of the observed trends across different fault locations. The results show an increase in CCT as PV generation progressively replaces the active power supplied by synchronous machines, whose inertia is therefore maintained: from 210 ms (0% PV) to 440 ms (25%)/1080 ms (40%) at bus 5, 410 ms (25%)/1130 ms (40%) and 290 ms (25%)/650 ms (40%) at buses 6 and 8, respectively, demonstrating that the penetration site is a key factor for system stability. For distributed penetration among the three buses, CCT values of 340 ms (25%) and 1020 ms (40%) highlight the significant influence of PV placement at bus 8. The fault on line 9–6 consistently yields higher CCT values across all scenarios, confirming the robustness of these trends independently of fault location. Although an overall increase in CCT was observed, higher PV penetration also led to more pronounced oscillations and operability issues after the fault. In particular, 75% of the penetration scenarios under the fault on line 9–6 do not meet the active power recovery requirements of IEEE 1547-2018 and IEEE 2800-2022, a result more severe than that observed for the fault on line 7–5. These results underscore that a higher CCT does not guarantee operational compliance, and that stability-oriented control strategies—such as grid-forming operation, fast active power support, and dynamic voltage control—remain essential. They also suggest that planning practices should favor interconnections electrically closer to the slack generator. Overall, a high PV penetration level—modifying only the operating point of synchronous machines—allows longer fault durations to be tolerated; however, appropriate siting of PV units and the adoption of advanced inverter controls could mitigate the observed oscillations and post-fault operability challenges. Full article

The energy transition is rapidly increasing the penetration of inverter-based resources (IBRs), thereby reducing the share of conventional directly grid-connected synchronous generation in modern power systems. In scenarios with very high shares of IBRs, potentially reaching 100% inverter-based operation, key features that have traditionally guaranteed power system stability and security, such as inertia, short circuit strength, fault response, and damping of oscillations, are significantly changing. This review paper examines the main challenges of operating and planning power systems with a high penetration of inverter-based resources. These challenges are grouped into three main areas: (i) technical issues, including frequency and voltage stability, system strength, fault behavior, control interactions and oscillations; (ii) regulatory issues, such as the evolution of grid codes, ride-through requirements, grid-forming specifications and testing, compliance assessment, and model validation; and (iii) market issues, focusing on how non energy services, like synthetic inertia, damping, voltage support, and stability services, are defined, measured, and procured. The paper discusses the compromises between system performance, implementation costs, and overall system robustness, relying on lessons learned from existing specifications and international standards. Finally, it outlines key research needs and provides recommendations for developing coherent technical requirements and market mechanisms to support the reliable operation of inverter-dominated power systems. Full article

Negative capacitance (NC) has been reported across a wide range of physical systems, yet its interpretation has remained fragmented due to the lack of a unified conceptual framework. Existing explanations—spanning ferroelectric free-energy curvature, tunneling transport, plasmonic resonances, and electronic compressibility—have often been treated as unrelated or even contradictory. This review resolves these inconsistencies by showing that all manifestations of NC arise from non-synchronization between external excitation and internal response. We classify NC into three fundamental categories: temporal mismatch, originating from delays or inertia in charge or polarization dynamics; spatial mismatch, caused by nonuniform field or mode distributions; and quantitative mismatch, resulting from intrinsic parameter reversal such as negative curvature or negative compressibility. Despite their diverse physical origins, these mechanisms share the same mathematical signature (${\mathrm{C}}_{eff}=\partial \mathrm{Q}/\partial \mathrm{V}<0$). Organizing NC within this unified framework clarifies long-standing ambiguities, connects previously isolated research fields, and establishes a systematic foundation for engineering NC in electronic, photonic, and quantum devices. The framework further highlights tunnel-current-induced NC as a representative single-particle mechanism within the temporal mismatch category, expanding the scope of NC beyond ferroelectricity and collective modes. Overall, this work positions NC not as a singular anomaly but as a universal response class emerging from the interplay between excitation and internal dynamics. Full article
