Search Results (13)

Search Parameters:
Keywords = supersonic leading edge

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
23 pages, 12169 KiB
Article
Effect of Quasi-Static Door Operation on Shear Layer Bifurcations in Supersonic Cavities
by Skyler Baugher, Datta Gaitonde, Bryce Outten, Rajan Kumar, Rachelle Speth and Scott Sherer
Aerospace 2025, 12(8), 668; https://doi.org/10.3390/aerospace12080668 - 26 Jul 2025
Viewed by 203
Abstract
Span-wise homogeneous supersonic cavity flows display complicated structures due to shear layer breakdown, flow acoustic resonance, and even non-linear hydrodynamic-acoustic interactions. In practical applications, such as aircraft bays, the cavity is of finite width and has doors, both of which introduce distinctive phenomena [...] Read more.
Span-wise homogeneous supersonic cavity flows display complicated structures due to shear layer breakdown, flow acoustic resonance, and even non-linear hydrodynamic-acoustic interactions. In practical applications, such as aircraft bays, the cavity is of finite width and has doors, both of which introduce distinctive phenomena that couple with the shear layer at the cavity lip, further modulating shear layer bifurcations and tonal mechanisms. In particular, asymmetric states manifest as ‘tornado’ vortices with significant practical consequences on the design and operation. Both inward- and outward-facing leading-wedge doors, resulting in leading edge shocks directed into and away from the cavity, are examined at select opening angles ranging from 22.5° to 90° (fully open) at Mach 1.6. The computational approach utilizes the Reynolds-Averaged Navier–Stokes equations with a one-equation model and is augmented by experimental observations of cavity floor pressure and surface oil-flow patterns. For the no-doors configuration, the asymmetric results are consistent with a long-time series DDES simulation, previously validated with two experimental databases. When fully open, outer wedge doors (OWD) yield an asymmetric flow, while inner wedge doors (IWD) display only mildly asymmetric behavior. At lower door angles (partially closed cavity), both types of doors display a successive bifurcation of the shear layer, ultimately resulting in a symmetric flow. IWD tend to promote symmetry for all angles observed, with the shear layer experiencing a pitchfork bifurcation at the ‘critical angle’ (67.5°). This is also true for the OWD at the ‘critical angle’ (45°), though an entirely different symmetric flow field is established. The first observation of pitchfork bifurcations (‘critical angle’) for the IWD is at 67.5° and for the OWD, 45°, complementing experimental observations. The back wall signature of the bifurcated shear layer (impingement preference) was found to be indicative of the 3D cavity dynamics and may be used to establish a correspondence between 3D cavity dynamics and the shear layer. Below the critical angle, the symmetric flow field is comprised of counter-rotating vortex pairs at the front and back wall corners. The existence of a critical angle and the process of door opening versus closing indicate the possibility of hysteresis, a preliminary discussion of which is presented. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

16 pages, 3539 KiB
Article
Aerodynamics Caused by Rolling Rates of a Small-Scale Supersonic Flight Experiment Vehicle with a Cranked-Arrow Main Wing
by Kazuhide Mizobata, Koji Shirakata, Atsuya Honda, Keisuke Shiono, Yukiya Ishigami, Akihiro Nishida and Masaaki Miura
Aerospace 2025, 12(7), 572; https://doi.org/10.3390/aerospace12070572 - 24 Jun 2025
Viewed by 251
Abstract
A small-scale supersonic flight experiment vehicle is being developed at Muroran Institute of Technology as a flying testbed for verification of innovative technologies for high-speed atmospheric flights, which are essential to next-generation aerospace transportation systems. Its baseline configuration M2011 with a cranked-arrow main [...] Read more.
A small-scale supersonic flight experiment vehicle is being developed at Muroran Institute of Technology as a flying testbed for verification of innovative technologies for high-speed atmospheric flights, which are essential to next-generation aerospace transportation systems. Its baseline configuration M2011 with a cranked-arrow main wing with an inboard and outboard leading edge sweepback angle of 66 and 61 degrees and horizontal and vertical tails has been proposed. Its aerodynamics caused by attitude motion are required to be clarified for six-degree-of-freedom flight capability prediction and autonomous guidance and control. This study concentrates on characterization of such aerodynamics caused by rolling rates in the subsonic regime. A mechanism for rolling a wind-tunnel test model at various rolling rates and arbitrary pitch angle is designed and fabricated using a programmable stepping motor and an equatorial mount. A series of subsonic wind-tunnel tests and preliminary CFD analysis are carried out. The resultant static derivatives have sufficiently small scatter and agree quite well with the static wind-tunnel tests in the case of a small pitch angle, whereas the static directional stability deteriorates in the case of large pitch angles and large nose lengths. In addition, the resultant dynamic derivatives agree well with the CFD analysis and the conventional theory in the case of zero pitch angle, whereas the roll damping deteriorates in the case of large pitch angles and proverse yaw takes place in the case of a large nose length. Full article
(This article belongs to the Special Issue Research and Development of Supersonic Aircraft)
Show Figures

Figure 1

21 pages, 28976 KiB
Article
Interaction of the Shock Train Leading Edge and Filamentary Plasma in a Supersonic Duct
by Loren C. Hahn, Philip A. Lax, Scott C. Morris and Sergey B. Leonov
Fluids 2024, 9(12), 291; https://doi.org/10.3390/fluids9120291 - 7 Dec 2024
Cited by 1 | Viewed by 961
Abstract
Quasi-direct current (Q-DC) filamentary electrical discharges are used to control the shock train in a back-pressured Mach 2 duct flow. The coupled interaction between the plasma filaments and the shock train leading edge (STLE) is studied for a variety of boundary conditions. Electrical [...] Read more.
Quasi-direct current (Q-DC) filamentary electrical discharges are used to control the shock train in a back-pressured Mach 2 duct flow. The coupled interaction between the plasma filaments and the shock train leading edge (STLE) is studied for a variety of boundary conditions. Electrical parameters associated with the discharge are recorded during actuation, demonstrating a close correlation between the STLE position and dynamics. High-speed self-aligned focusing schlieren (SAFS) and high frame-rate color camera imaging are the primary optical diagnostics used to study the flowfield and plasma morphology. Shock tracking and plasma characterization algorithms are employed to extract time-resolved quantitative data during shock–plasma interactions. Four distinct shock–plasma interaction types are identified and outlined, revealing a strong dependence on the spacing between the uncontrolled STLE and discharge electrodes and a moderate dependence on flow parameters. Full article
(This article belongs to the Special Issue High Speed Flows, 2nd Edition)
Show Figures

Figure 1

24 pages, 9950 KiB
Article
Impact Response of Monolithic and Laminated Polycarbonate Panels: An Experimental and Numerical Investigation
by Navid Ghavanini, Antonio Maria Caporale, Paolo Astori, Alessandro Airoldi and Paolo Panichelli
Polymers 2023, 15(24), 4677; https://doi.org/10.3390/polym15244677 - 11 Dec 2023
Viewed by 1771
Abstract
This study aimed to investigate the impact resistance of monolithic and laminated polycarbonate plates for windshields in motorsport applications through a coupled experimental–numerical study. Both low- and high-velocity impact tests were performed by using a drop tower and a gas gun, respectively, considering [...] Read more.
This study aimed to investigate the impact resistance of monolithic and laminated polycarbonate plates for windshields in motorsport applications through a coupled experimental–numerical study. Both low- and high-velocity impact tests were performed by using a drop tower and a gas gun, respectively, considering a sharp-edged projectile impacting on flat panels. The response of the polycarbonate plates was evaluated in terms of the failure mode, perforation velocity threshold, and energy absorption mechanism. The experiments allowed for the assessment and the generalization of a 3D finite element modeling approach originally developed for supersonic application based on different state-of-the-art constitutive theories, including temperature-dependent and rate-dependent von Mises plasticity coupled with ductile damage, Mie–Grüneisen equation of state, and temperature variation due to energy dissipation under adiabatic assumptions. The approach was completed with a cohesive zone model for a laminate plate and studies were performed to highlight the relevancy of different aspects of material characterization. The tests and numerical analyses performed at different velocity ranges highlight the importance of viscoplastic behavior in a polycarbonate windshield. The numerical approach showed its capability to model the different failure modes for monolithic and laminated panels and capture the perforation velocity thresholds with appreciable accuracy, which were actually found to be quite similar for the two types of panels in the test conditions considered. A numerical investigation suggests that the development of delaminations could lead to the improved energy absorption of laminated polycarbonate. To further assess the numerical model, it was used to successfully predict the penetration threshold velocity of a polycarbonate windshield subjected to a gas gun impact test. Full article
Show Figures

Graphical abstract

35 pages, 25211 KiB
Article
Aerodynamic Optimization Design of Supersonic Wing Based on Discrete Adjoint
by Hanyue Rao, Yayun Shi, Junqiang Bai, Yifu Chen, Tihao Yang and Junfu Li
Aerospace 2023, 10(5), 420; https://doi.org/10.3390/aerospace10050420 - 29 Apr 2023
Cited by 4 | Viewed by 4837
Abstract
Reducing fuel consumption and improving the economy by effectively reducing cruising drag is the main objective of the aerodynamic design of supersonic civil aircraft. In this paper, the aerodynamic optimization design system based on the Reynolds-Averaged Navier–Stokes (RANS) equation and discrete adjoint theory [...] Read more.
Reducing fuel consumption and improving the economy by effectively reducing cruising drag is the main objective of the aerodynamic design of supersonic civil aircraft. In this paper, the aerodynamic optimization design system based on the Reynolds-Averaged Navier–Stokes (RANS) equation and discrete adjoint theory is applied to supersonic wing design. Based on this system, a single-point optimization design study of aerodynamic drag reduction in cruise conditions was carried out for two typical supersonic wing layouts, subsonic leading edge and supersonic leading edge, and the drag reduction reached 3.78% and 4.53%, respectively. The aerodynamic design characteristics of different types of supersonic wings were explored from the perspectives of wing load, twist angle distribution, pressure distribution, airfoil shape characteristics, and flow field characteristics. The optimization results show that the drag reduction of the subsonic leading edge configuration is dominated by the induced drag, while the optimizer mainly focuses on reducing the shock wave drag for the supersonic leading edge configuration. By comparing the sensitivity analysis of lift and drag coefficients to airfoil deformation with the optimization results, the optimized dominant directions of two types of supersonic wings are qualitatively analyzed. The derivatives obtained from discrete adjoint equations are useful to elaborate the design tendency and the reason for the trade-off generation of supersonic wings under specific layouts and engineering constraints, which provides a reference for the design of supersonic wings in the future. Full article
(This article belongs to the Special Issue Adjoint Method for Aerodynamic Design and Other Applications in CFD)
Show Figures

Figure 1

22 pages, 10672 KiB
Article
Study of Plasma-Based Vortex Generator in Supersonic Turbulent Boundary Layer
by Pavel Polivanov, Oleg Vishnyakov and Andrey Sidorenko
Aerospace 2023, 10(4), 363; https://doi.org/10.3390/aerospace10040363 - 10 Apr 2023
Cited by 6 | Viewed by 2932
Abstract
The problem of flow control under conditions of a turbulent boundary layer at transonic and supersonic free-stream velocities is considered. Such flows are integral components of the flight process and exert significant effects on the flow around both the aerodynamic object as a [...] Read more.
The problem of flow control under conditions of a turbulent boundary layer at transonic and supersonic free-stream velocities is considered. Such flows are integral components of the flight process and exert significant effects on the flow around both the aerodynamic object as a whole and its individual elements. The present paper describes investigations of a combined control device (“plasma wedge”), which is a wedge mounted along the flow with the energy supply at one side of the wedge owing to a spark discharge. The strategy of flow control by this device is based on increasing the momentum in the boundary layer, which enhances its resistance to the adverse pressure gradient and, as a consequence, its resistance to flow separation further downstream. The study includes experimental and computational aspects. The examined flow evolves on a rectangular flat plate with a sharp leading edge at the free-stream Mach number M = 1.45 and unit Reynolds numbers Re1 = 11.5·106 1/m. The experiments are performed to study the velocity fields and the pressure distribution in the wake behind the actuator. The results show that a streamwise vortex is formed in the wake behind the actuator when the discharge is initiated. Reasonable agreement of the experimental data with numerical simulations allows one to conclude that the Reynolds-averaged Navier–Stokes equations are suitable tools for solving the problem considered. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

24 pages, 5776 KiB
Article
Numerical Analysis of the Effects of Grooved Stator Vanes in a Radial Turbine Operating at High Pressure Ratios Reaching Choked Flow
by José Galindo, Andrés Tiseira, Roberto Navarro, Lukas Benjamin Inhestern and Juan David Echavarría
Aerospace 2023, 10(4), 359; https://doi.org/10.3390/aerospace10040359 - 5 Apr 2023
Cited by 2 | Viewed by 2635
Abstract
The flow through the stator vanes of a variable geometry turbocharger turbine can reach supersonic conditions and generates a shock wave on the stator vanes, which has a potential impact on the flow loss as well as on unsteady aerodynamic interaction. The shock [...] Read more.
The flow through the stator vanes of a variable geometry turbocharger turbine can reach supersonic conditions and generates a shock wave on the stator vanes, which has a potential impact on the flow loss as well as on unsteady aerodynamic interaction. The shock wave causes a sudden increase in pressure and can lead to boundary separation and strong excitation force, besides pressure fluctuation in the rotor blades. Thus, in this study, the flat surface of the vanes of a commercial variable geometry turbocharger turbine has been modified to analyze the effects of two grooved surfaces configuration using CFD simulations. The results reveal that the grooves change the turbine efficiency, especially at higher speed, where the increase in the efficiency is between 2% and 6% points. Additionally, the load fluctuation around the rotor leading edge can be reduced and minimize the factors that compromise the integrity of the turbine. Furthermore, the grooves reduce the supersonic pocket developed on the suction side of the vane and diminish the shock wake intensity. Evaluating the effectiveness of the available energy usage in the turbine, on the one hand, at lower speed, the fraction of energy at the inlet destinated to produce power does not change significantly with a grooved surface on the stator vanes. On the other hand, at higher speed and higher pressure ratio with 5 grooves occurs the most effective approach of the maximum energy. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

30 pages, 13398 KiB
Article
Numerical Analysis of the Effects of Different Rotor Tip Gaps in a Radial Turbine Operating at High Pressure Ratios Reaching Choked Flow
by José Galindo, Andrés Tiseira, Roberto Navarro, Lukas Benjamin Inhestern and Juan David Echavarría
Energies 2022, 15(24), 9449; https://doi.org/10.3390/en15249449 - 13 Dec 2022
Cited by 2 | Viewed by 2146
Abstract
To operate, radial turbines used in turbochargers require a minimum tip gap between the rotor blades and the stationary wall casing (shroud). This gap generates leakage flow driven by the pressure difference between the pressure and suction side. The tip leakage flow is [...] Read more.
To operate, radial turbines used in turbochargers require a minimum tip gap between the rotor blades and the stationary wall casing (shroud). This gap generates leakage flow driven by the pressure difference between the pressure and suction side. The tip leakage flow is largely unturned, which translates into a reduction of the shaft work due to the decrease in the total pressure. This paper investigates the flow through the rotor blade tip gap and the effects on the main flow when the turbine operates at a lower and higher pressure ratio with the presence of supersonic regions at the rotor trailing edge for two rotational speeds using computational fluid dynamics (CFD). The rotor tip gap has been decreased and increased up to 50% of the original tip gap geometry given by the manufacturer. Depending on the operational point, the results reveal that a reduction of 50% of the tip gap can lead to an increase of almost 3% in the efficiency, whereas a rise in 50% in the gap penalty the efficiency up to 3%. Furthermore, a supersonic region appears in the tip gap just when the flow enters through the pressure side, then the flow accelerates, leaving the suction side with a higher relative Mach number, generating a vortex by mixing with the mainstream. The effects of the vortex with the variation of the tip gap on the choked area at the rotor trailing edge presents a more significant change at higher than lower speeds. At a higher speed, the choked region closer to the shroud is due to the high relative inlet flow angle and the effects of the high relative motion of the shroud wall. Furthermore, this relative motion forces the tip leakage vortex to stay closer to the tip suction side, generating a subsonic region, which increases with the tip gap height. The leakage flow at lower and higher rotational speed does not affect the main flow close to the hub. However, close to the shroud, the velocity profile changes, and the generated entropy increases when the flow goes through the tip gap. Full article
(This article belongs to the Special Issue Advanced Computational Fluid Dynamics Modeling)
Show Figures

Figure 1

14 pages, 2017 KiB
Article
A Study of the Dependence of the Mach Stem Height on the Trailing Edge Height
by Chen-Yuan Bai and Zi-Niu Wu
Fluids 2021, 6(9), 313; https://doi.org/10.3390/fluids6090313 - 2 Sep 2021
Cited by 4 | Viewed by 2635
Abstract
The Mach stem height is an important parameter in the Mach reflection of steady supersonic flow. Various experimental, numerical, and theoretical works have been conducted to study this parameter in the past. However, much of the established work focuses around a single set [...] Read more.
The Mach stem height is an important parameter in the Mach reflection of steady supersonic flow. Various experimental, numerical, and theoretical works have been conducted to study this parameter in the past. However, much of the established work focuses around a single set of trailing edge heights. Here, we perform a study to show the dependence of Mach stem height on the trailing edge height for a wider range of geometry. Through numerical simulation for a set of trailing edge heights, we found that the normalized Mach stem height is almost linear with respect to the normalized wedge trailing edge height. The parameter used for normalization can be either the inlet height or the length of the lower wedge surface. The observation of this linear trend is justified through a simplified analysis, which leads to an expression of the Mach stem height that linearly depends on the trailing edge height. The present study extends our knowledge about how the geometry affects the Mach stem height, and provides a basis for future work to elaborate analytical models for Mach stem height. Full article
(This article belongs to the Special Issue High Speed Flows)
Show Figures

Figure 1

22 pages, 33146 KiB
Article
Shock Reduction through Opposing Jets—Aerodynamic Performance and Flight Stability Perspectives
by Shagufta Rashid, Fahad Nawaz, Adnan Maqsood, Rizwan Riaz and Shuaib Salamat
Appl. Sci. 2020, 10(1), 180; https://doi.org/10.3390/app10010180 - 25 Dec 2019
Cited by 10 | Viewed by 4688
Abstract
In this research paper, investigations of counter flow (opposing) jet on the aerodynamic performance, and flight stability characteristics of an airfoil with blunt leading-edge in supersonic regime are performed. Unsteady Reynolds-Averaged Navier-Stokes ( U R A N S ) based solver is used [...] Read more.
In this research paper, investigations of counter flow (opposing) jet on the aerodynamic performance, and flight stability characteristics of an airfoil with blunt leading-edge in supersonic regime are performed. Unsteady Reynolds-Averaged Navier-Stokes ( U R A N S ) based solver is used to model the flow field. The effect of angle of attack ( α ), free-stream Mach number ( M ), and pressure ratio ( P R ) on aerodynamic performance of airfoil with and without jet are compared. The results indicate that the opposing jet reduces drag from 30 % to 70 % , improves the maximum lift-to-drag ratio from 2.5 to 4.0, and increases shock stand-off distance from 15 % to 35 % depending on flow conditions. The effect of opposing jet on longitudinal flight stability characteristics, studied for the first time, indicate improvement in dynamic stability coefficients ( C m q + C m α ˙ ) at low angles of attack. It is concluded that the opposing jet can help mitigate flight disturbances in supersonic regime. Full article
(This article belongs to the Section Mechanical Engineering)
Show Figures

Figure 1

22 pages, 2030 KiB
Article
Stability Analysis on Nonequilibrium Supersonic Boundary Layer Flow with Velocity-Slip Boundary Conditions
by Xin He, Kai Zhang and Chunpei Cai
Fluids 2019, 4(3), 142; https://doi.org/10.3390/fluids4030142 - 31 Jul 2019
Cited by 11 | Viewed by 3647
Abstract
This paper presents our recent work on investigating velocity slip boundary conditions’ effects on supersonic flat plate boundary layer flow stability. The velocity-slip boundary conditions are adopted and the flow properties are obtained by solving boundary layer equations. Stability analysis of two such [...] Read more.
This paper presents our recent work on investigating velocity slip boundary conditions’ effects on supersonic flat plate boundary layer flow stability. The velocity-slip boundary conditions are adopted and the flow properties are obtained by solving boundary layer equations. Stability analysis of two such boundary layer flows is performed by using the Linear stability theory. A global method is first utilized to obtain approximate discrete mode values. A local method is then utilized to refine these mode values. All the modes in these two scenarios have been tracked upstream-wisely towards the leading edge and also downstream-wisely. The mode values for the no-slip flows agree well with the corresponding past results in the literature. For flows with slip boundary conditions, a stable and an unstable modes are detected. Mode tracking work is performed and the results illustrate that the resonance phenomenon between the stable and unstable modes is delayed with slip boundary conditions. The enforcement of the slip boundary conditions also shortens the unstable mode region. As to the conventional second mode, flows with slip boundary conditions can be more stable streamwisely when compared with the results for corresponding nonslip flows. Full article
(This article belongs to the Special Issue Turbulence and Transitional Modeling of Aerodynamic Flows)
Show Figures

Figure 1

13 pages, 7477 KiB
Article
Plasma-Assisted Control of Supersonic Flow over a Compression Ramp
by Yasumasa Watanabe, Alec Houpt and Sergey B. Leonov
Aerospace 2019, 6(3), 35; https://doi.org/10.3390/aerospace6030035 - 12 Mar 2019
Cited by 13 | Viewed by 7526
Abstract
This study considers the effect of an electric discharge on the flow structure near a 19.4° compression ramp in Mach-2 supersonic flow. The experiments were conducted in the supersonic wind tunnel SBR-50 at the University of Notre Dame. The stagnation temperature and pressure [...] Read more.
This study considers the effect of an electric discharge on the flow structure near a 19.4° compression ramp in Mach-2 supersonic flow. The experiments were conducted in the supersonic wind tunnel SBR-50 at the University of Notre Dame. The stagnation temperature and pressure were varied in a range of 294–600 K and 1–3 bar, respectively, to attain various Reynolds numbers ranging from 5.3 × 105 to 3.4 × 106 based on the distance between the exit of the Mach-2 nozzle and the leading edge of the ramp. Surface pressure measurements, schlieren visualization, discharge voltage and current measurements, and plasma imaging with a high-speed camera were used to evaluate the plasma control authority on the ramp pressure distribution. The plasma being generated in front of the compression ramp shifted the shock position from the ramp corner to the electrode location, forming a flow separation zone ahead of the ramp. It was found that the pressure on the compression surface reduced almost linearly with the plasma power. The ratio of pressure change to flow stagnation pressure was also an increasing function of the ratio of plasma power to enthalpy flux, indicating that the task-related plasma control effectiveness ranged from 17.5 to 25. Full article
Show Figures

Graphical abstract

20 pages, 10917 KiB
Article
Experimental and Numerical Study of Transonic Cooled Turbine Blades
by Andrey Granovskiy, Vladimir Gribin and Nikolai Lomakin
Int. J. Turbomach. Propuls. Power 2018, 3(2), 16; https://doi.org/10.3390/ijtpp3020016 - 8 Jun 2018
Cited by 4 | Viewed by 4404
Abstract
State-of-the-art gas turbines (GT) operate at high temperatures that exceed the endurance limit of the material, and therefore the turbine components are cooled by the air taken from the compressor. The cooling provides a positive impact on the lifetime of GT but has [...] Read more.
State-of-the-art gas turbines (GT) operate at high temperatures that exceed the endurance limit of the material, and therefore the turbine components are cooled by the air taken from the compressor. The cooling provides a positive impact on the lifetime of GT but has a negative impact on its performance. In convection-cooled turbine blades the coolant is usually discharged through the trailing edge and leads to limitations on the minimal size of the trailing edge, thereby negatively affecting the losses. Moreover, the injection of cooling air in the turbine disturbs the main flow, and may lead to an additional increase in loss. Trailing edge loss is a significant part of the overall loss in modern gas turbines. This study comprises investigations of the unguided flow angle, the trailing edge shape, and cooling air injection through the trailing edge on the base pressure and profile losses in cooled blades. Some vane and blade cascades with different unguided turning angle and two shapes of trailing edges with and without coolant injection were studied both experimentally and numerically. This analysis provides a split of losses caused by different factors, and offers opportunities for efficiency and lifetime improvements of real engine designs/upgrades. In particular, it is shown that an increase in the unguided turning angle and the use of a round trailing edge result in a reduction of loss in case of a relatively thick trailing edge. Numerical investigation showed that an increase in the unguided turning angle at the initial transonic vane with a thick and blunt trailing edge, without a change in other basic geometric parameters, allowed for a significant reduction of the profile loss by about 3–4% at the exit Mach number M2is = 0.7–1.0. Experimental investigation of four cascades with cooling air injection into the base flow through the trailing edge allowed us to validate the fact that in blades with a low level of base pressure Cpb < −0.1 at m¯ = 0 a non-monotonic dependence of the change of losses against relative cooling air mass flow m¯ is observed. Firstly, the cooling air injection into wake increases base pressure and decreases losses; then the losses start to increase with increasing cooling mass flow due to the interaction between the main flow and the cooling air (mixing losses) and, finally, due to the cooling mass flow increase and momentum increase losses are decreased. In blades with an increased level of the base pressure coefficient Cpb ≥ −0.1 at m¯ = 0 the cooling air injection results in an increase in losses right from the beginning of the injection and then, according to the cooling mass flow increase and momentum rise, losses decrease. It is also shown that injection through the trailing edge slot parallel to the main flow leads to a neutral loss impact and even a loss reduction in the subsonic range and a loss increase in the supersonic range of exit Mach numbers. Full article
Show Figures

Figure 1
