Geogrids are frequently utilized in engineering for reinforcement; yet, they are vulnerable to construction damage when employed on coarse-grained soil subgrades. In contrast, waste tire grids are more appropriate for subgrade reinforcement owing to their rough surfaces, integrated steel meshes, robust transverse ribs, extended degradation cycles, and superior durability. Based on the limit equilibrium theory, this study developed formulae for calculating the internal and external frictional resistance, as well as the end resistance of waste tires, to ascertain the interface bearing properties and calculation techniques of waste tire grids. Based on this, a mechanical model for the ultimate pull-out resistance of waste-tire-reinforced soil was developed, and its validity was confirmed through a series of pull-out tests on single-sided strips, double-sided strips, and tire grids. The results indicated that the tensile strength of one side of the strip was approximately 43% of that of both sides, and the rough outer surface of the tire significantly enhanced the tensile performance of the strip; under identical normal stress, the tensile strength of the single-sided tire grid was roughly nine times and four times greater than that of the single-sided and double-sided strips, respectively, and the grid structure exhibited superior anti-deformation capabilities compared to the strip structure. The average discrepancy between the calculated values of the established model and the theoretical values was merely 2.38% (maximum error < 5%). Overall, this research offers technical assistance for ensuring the safety of subgrade design and promoting environmental sustainability in engineering, enabling the effective utilization of waste tire grids in sustainable reinforcement applications. Full article

Water migration occurs in unsaturated loess subgrade due to extreme rainfall, making it prone to subgrade subsidence and other water damage disasters, which seriously impact road safety and sustainable development of the Loess Plateau. The study performed a rainfall test using a compacted loess subgrade model based on a self-developed water migration test device. The effects of extreme rainfall on the water distribution, wetting front, and infiltration rate in the subgrade were systematically explored by setting three rainfall intensities (4.6478 mm/h, 9.2951 mm/h, and 13.9427 mm/h, namely J1 stage, J2stage, and J3 stage), and a lateral water migration model was proposed. The results indicated that the range of water content change areas constantly expands as rainfall intensity and time increase. The soil infiltration rate gradually decreased, and the ratio of surface runoff to infiltration rainfall increased. The hysteresis of lateral water migration refers to the physical phenomenon in which the internal water response of the subgrade is delayed in time and space compared to changes in boundary conditions. The sensor closest to the side of the slope changed first, with the most significant fluctuations. The farther away from the slope, the slower the response and the smaller the fluctuation. The bigger the rainfall intensity, the faster the wetting front moved horizontally. The migration rate at the slope toe is the highest. The migration rate of sensor W3 increased by 66.47% and 333.70%, respectively, in the J3 stage compared to the J2 and J1 stages. The results of the model and the measured data were in good agreement, with the R² exceeding 0.90, which verifies the reliability of the model. The study findings are important for guiding the prevention and control of disasters caused by water damage to roadbeds in loess areas. Full article

The primary purpose of this paper is to investigate the impact of traffic wander on road pavement life for application in connected and autonomous vehicles. Research shows that in autonomous vehicles, drivers often follow the same path, leading to significant pavement damage on specific, well-defined paths. The paper examined the impact of traffic wander on pavement life by analysing two different wander distributions: normal and uniform. Based on the estimated pavement life for various pavement structures, a model that predicts the increase in pavement life due to traffic wander was developed for cracking and rutting prediction. The result of the research is the determination of relative pavement life influence functions, in which the variables are the traffic wander, asphalt layer thickness and subgrade stiffness. The obtained equations can be easily implemented for pavement service life extension evaluation. The model was also used to estimate the asphalt layer thickness as a function of the traffic expressed in terms of Equivalent Single Axle Load (ESALs). An analysis of the implications of the lateral distribution of traffic on the pavement thickness was presented. Significant reductions in the asphalt layer thickness of the pavement are achieved when wander is considered. Full article

Temperature variations have a significant impact on the performance and durability of rigid (concrete) pavement. As concrete is subjected to daily and seasonal temperature changes, it experiences thermal expansion and contraction. These movements, if not properly managed, can lead to cracking, joint deterioration, and loss of structural integrity. The pavement system is adversely affected by intense heat and significant flooding. This study aims to analyze the impact of several parameters on the performance of rigid pavement under typical, thermal, and flooding situations. This study investigates the properties of concrete and the dimensional design of rigid pavement with FEACONS IV software to assess their impact on the performance of concrete pavement during thermal and flooding conditions. The main conclusions of this study derived from the FEACONS IV analysis are as follows. Rigid pavement can enhance load-carrying capacity due to a lower elastic modulus, adequate flexural strength, and aggregates with a lower coefficient of thermal expansion. Increased thickness of concrete slabs and shorter slab lengths assist in minimizing load- and temperature-induced stresses. The increase in the subgrade modulus reaction value during flooding conditions improves pavement strength. However, in higher thermal conditions, a higher subgrade reaction modulus can increase the stress induced by temperature and load. Rigid pavement using porous limestone aggregate exhibits a reduced elastic modulus and coefficient of thermal expansion, suggesting higher resilience compared to rigid pavement composed of river gravel or granite. The findings suggest that higher thermal conditions will cause pavement damage. Agencies need to account for higher temperatures while designing and maintaining pavement. Flooding saturates the concrete pavement and subgrade layer, adversely affecting its performance over time. Full article

During railway operations, changes in the support conditions of sleepers, owing to various internal and external factors, can damage rails and concrete sleepers and alter the structural characteristics of gravel-ballasted tracks. However, current methods for evaluating gravel ballast conditions primarily rely on visual inspection. This study proposes a quantitative approach using modal testing to assess ballast conditions. This is achieved by analyzing and experimentally verifying the relationship between track ballast loosening (caused by subgrade deformation) and track support performance. Finite element analysis results and field experimental values were compared using spring stiffness as a parameter. The results showed that natural frequencies and mode shapes changed in response to variations in the vertical spring stiffness of the gravel-ballasted track. Therefore, the sleeper support condition of a gravel-ballasted track can be readily identified by analyzing the natural frequency corresponding to different sleeper support conditions. Full article

This study investigated the small-strain dynamic properties of expanded polystyrene (EPS) lightweight soil (ELS), a low-density geosynthetic material used to stabilize slopes and alleviate the subgrade settlement of soft soil. Resonant column tests were conducted to evaluate the effects of EPS’s granule content (20–60%), confining pressures (50 kPa, 100 kPa, and 200 kPa), and curing ages (3 days, 7 days, and 28 days) on the dynamic shear modulus (G) of ELS within a small strain range (10⁻⁶–10⁻⁴). The results indicate that ELS exhibits a high dynamic shear modulus under small strains, which increases with higher confining pressure and longer curing age but decreases with an increasing EPS granule content and dynamic shear strain, leading to mechanical property deterioration and structural degradation. The maximum shear modulus (G_max) ranges from 64 MPa to 280 MPa, with a 60% reduction in G_max observed as the EPS granule content increases and increases by 11% and 55% with higher confining pressure and longer curing ages, respectively. A damage model incorporating the EPS granule content (a_E) and confining pressure (P) was established, effectively describing the attenuation behavior of G in ELS under small strains with higher accuracy than the Hardin–Drnevich model. This study also developed an engineering testing experiment that integrates materials science, soil mechanics, and environmental protection principles, enhancing students’ interdisciplinary knowledge, innovation, and practical skills with implications for engineering construction, environmental protection, and experimental education. Full article

This study aims to explore the dynamic response of ballastless tracks under various temperatures of the cement-emulsified asphalt (CA) mortar layer and other environmental factors. CA mortar is the key material in the ballastless track structure, exhibiting notably temperature-dependent viscoelastic properties. It can be damaged or even fail due to the continuous loads from trains. However, the dynamic behaviors of ballastless tracks considering the temperature-dependent viscoelasticity of CA mortar have been insufficiently studied. This paper captures the temperature-dependent viscoelastic characteristics of CA mortar by employing the fractional Maxwell model and applying it to finite element simulations through a Prony series. A vehicle–track–subgrade (VTS) coupled CRTS I ballastless track model, encompassing Hertz nonlinear contact and track irregularity, is established. The model is constrained symmetrically on both of the longitudinal sides, and the bottom is fixed on the infinite element boundary, which can reduce the effects of reflected waves. After the simulation outcomes in this study are validated, variations in the dynamic responses under different environmental factors are analyzed, offering a theoretical foundation for maintaining the ballastless tracks. The results show that the responses in the track subsystem will undergo significant changes as the temperature rises; a notable effect is caused by the increase in speed and fastener stiffness on the entire system; the CA mortar layer experiences the maximum stress at its edge, which makes it highly susceptible to damage in this area. The original contribution of this work is the establishment of a temperature-dependent vehicle–track–subgrade coupled model that incorporates the viscoelasticity of the CA mortar, enabling the investigation of dynamic responses in ballastless tracks. Full article

As an important civil and military infrastructure, airport runway pavement is faced with threats from cluster munitions, since it is vulnerable to projectile impacts with internal explosions. Aiming at the damage assessment of an island airport runway pavement under impact, this work dealt with discrete modeling of rigid projectile penetration into concrete pavement and the calcareous sand subgrade multi-layer structure. First, the Discrete Element Method (DEM) is introduced to model concrete and calcareous sand granular material features, like cohesive fracture and strain hardening due to compression, with mesoscale constitutive laws governing the normal and shear interactions between adjacent particles. Second, the subsequent DEM simulations of uniaxial and triaxial compression were performed to calibrate the DEM parameters for pavement concrete, as well as subgrade calcareous sand. Prior to the multi-layer structure investigations, penetration into sole concrete or calcareous sand is validated in terms of projectile deceleration and depth of penetration (DOP) with relative error ≤ 5.6% providing a reliable numerical tool for deep penetration damage assessments. Third, projectile penetration into the airport runway structure with concrete pavement and calcareous sand subgrade was evaluated with validated DEM model. Penetration numerical simulations with various projectile weight, pavement concrete thickness as well as striking velocity, were performed to achieve the DOP. Moreover, the back-propagation (BP) neural network proxy model was constructed to predict the airport runway penetration data with good agreement realizing rapid and robust DOP forecasting. Finally, the genetic algorithm was coupled with the proxy model to realize intelligent optimization of pavement penetration, whereby the critical velocity projectile just perforates concrete pavement indicating the severest subsequent munition explosion damage. Full article

Soil–rock mixture is a common geo-material found in natural deposit slopes and various constructions, such as tunnels, hydropower stations, and subgrades. The complex mechanical characteristics of soil–rock mixture arise from its multi-phase compositions and cooperative interactions. This paper investigated the mechanical properties of soil–rock mixture, focusing on the influence of rock content, and soil–rock interface strength was discussed. Specimens with varying rock contents were subjected to uniaxial compression tests. The results indicated that rock content, as a key structural parameter, significantly controls the crack propagation trends. As rock content increases, the initial structure of the soil matrix is damaged, leading to the formation of a weak-strength soil–rock interface. The failure mode transitions from longitudinal cracking to multiple shear fractures. To analyze the strength of the soil–rock interface from a mesoscopic perspective, simulations of soil–rock mixture specimens with irregular rock blocks were conducted using the particle discrete element method (PDEM). At the meso-scale, the specimen with 30% rock content exhibited a complex particle displacement distribution, with differences in the direction and magnitude of displacement between soil and rock particles being critical to the failure modes of the specimen. As the soil–rock interface strength increased from 0.1 to 0.9, the distribution of force chains within the specimen shifted from a centralized to a more uniform distribution, and the thickness of force chains became increasingly uniform. The strength responses of the soil–rock mixture under uniaxial compression condition were discussed, revealing that the uniaxial compression strength (UCS) of soil–rock mixture decreases exponentially with increasing rock content. An estimation formula was developed to characterize the UCS of soil–rock mixture in relation to rock content and interface strength. The findings from both the experiments and simulations can provide valuable insights for evaluating the stability of deposit slopes and other constructions involving soil–rock mixture. Full article

Ground settlement resulting from consolidation may lead to tilted buildings, cracks in the pavement, damage to underground utilities, etc. Therefore, it is crucial to understand the consolidation behaviors (including primary consolidation and secondary compression) of the soil of the subgrade. There is a large amount of soft clay deposited in Nanjing, located in the Yangtze River Basin. The consolidation behavior of Nanjing soft clay can significantly affect foundation design and the cost of construction. In this study, experimental measurements of the consolidation behavior of Nanjing soft clay were conducted, and parameters (such as pre-consolidation pressure, secondary consolidation index and secondary consolidation ratio) related to consolidation were assessed. The concept of simulated over-consolidation ratio (OCR_s) was proposed, and the close relationship between primary consolidation and secondary compression settlement and the OCR_s of Nanjing clay was investigated. Full article

The subgrade serves as the foundation of road construction, typically involving a significant amount of earthwork during its establishment. However, in coastal and desert areas, soil sources are often scarce. Local soil extraction significantly damages cultivated land, impacting the local ecological environment. Transporting soil over long distances inevitably raises construction costs. Fortunately, these regions often feature abundant fine sand distribution, presenting an opportunity to utilize it as subgrade filler in coastal regions. This review comprehensively introduces the properties of fine sand as a raw material, its engineering applications, and the associated construction technologies. It emphatically discusses the road use characteristics and treatment technology of fine sand filler and puts forward a prospect combining the characteristics and development trends of fine sand so as to provide a new perspective and basic material for the application of fine sand in the subgrade. To foster the adoption of fine sand in subgrade construction, it is recommended to advance research on the evaluation and treatment of fine sand foundations, analyze its suitability and structural behavior as a filler, and refine construction methodologies and quality control measures specific to fine sand subgrades. Full article

Loess has the characteristics of loose, large pore ratio, and strong water sensitivity. Once it encounters water, its structure is damaged easily and its strength is degraded, causing a degree of subgrade settlement. The water sensitivity of loess can be evaluated by permeability and disintegration tests. This study analyzes the effects of guar gum content, basalt fiber content, and basalt fiber length on the permeability and disintegration characteristics of solidified loess. The microstructure of loess was studied through scanning electron microscopy (SEM) testing, revealing the synergistic solidification mechanism of guar gum and basalt fibers. A permeability model was established through regression analysis with guar gum content, confining pressure, basalt fiber content, and length. The research results indicate that the addition of guar gum reduces the permeability of solidified loess, the addition of fiber improves the overall strength, and the addition of guar gum and basalt fiber improves the disintegration resistance. When the guar gum content is 1.00%, the permeability coefficient and disintegration rate of solidified soil are reduced by 50.50% and 94.10%, respectively. When the guar gum content is 1.00%, the basalt fiber length is 12 mm, and the fiber content is 1.00%, the permeability of the solidified soil decreases by 31.9%, and the disintegration rate is 4.80%. The permeability model has a good fitting effect and is suitable for predicting the permeability of loess reinforced with guar gum and basalt fiber composite. This research is of vital theoretical worth and great scientific significance for guidelines on practicing loess solidification engineering. Full article

As an important part of the boundary conditions on both sides of the high-speed railway track–bridge system, the seismic response of the subgrade structure is different from that of the bridge structure. This difference has become increasingly significant with the widespread adoption of continuous welded rail technology in bridge construction. Therefore, investigating the seismic response of the bridge system, with a specific focus on the longitudinal constraint effects of the subsequent subgrade track structure, is of paramount importance. Utilizing finite element software, two distinct bridge models are developed: one incorporating the subsequent subgrade track structure and another excluding it. Through nonlinear time history analysis under varying seismic intensities, it is demonstrated that the longitudinal constraint of the subsequent subgrade track structure mitigates the longitudinal displacements and internal forces in critical components of the high-speed railway track–bridge system. Concurrently, acknowledging the heightened complexity and cost associated with post-earthquake repairs of the bridge structure compared to subgrade structure, this study uses a risk transfer connecting beam device. This device can redirect seismic damage from bridge structure to subgrade structure, thereby potentially reducing post-seismic repair expenses for the bridge. Full article

In shield tunneling, the joint is one of the most vulnerable parts of the segmental lining. Opening of the joint reduces the overall stiffness of the ring, leading to structural damage and issues such as water leakage. Currently, the Winkler method is commonly used to calculate structural deformation, simplifying the interaction between segments and soil as radial and tangential Winkler springs. However, when introducing connection springs or reduction factors to simulate the joint stiffness of segments, the challenge lies in determining the reduction coefficient and the stiffness of the springs. Currently, the hyperstatic reflection method cannot simulate the discontinuity effect at the connection of the tunnel segments, while the state space method overlooks the nonlinear interaction between the tunnel and the soil. Therefore, this paper proposes a numerical simulation method considering the interaction between the tunnel and the soil, which is subjected to compression rather than tension, and the discontinuity of the joints between the segments. The model structure and external load are symmetrical, resulting in symmetrical calculation results. This method is based on the soft soil layers and shield tunnel structures of the Shanghai Metro, and the applicability of the model is verified through deformation calculations using three-dimensional laser scanning point clouds of sections from the Shanghai Metro Line 5. When the subgrade reaction coefficient is 5000 $\mathrm{k}\mathrm{N}/{\mathrm{m}}^3$, the model can effectively simulate the deformation of operational tunnels. By adjusting the bending stiffness of individual connection springs, we investigate the influence of bending stiffness reduction on the bending moment, radial displacement, and rotational displacement of the ring. The results indicate that a decrease in joint bending stiffness significantly affects the mechanical response of the ring, and the extent and degree of this influence are correlated with the joint position and the magnitude of joint bending stiffness. Full article

Under the background of climate warming in the Qinghai-Tibetan Plateau (QTP), frequent freeze–thaw cycling (FTC) brings about great geological disasters such as subgrade failure, landslides, and mudslides, which is closely related to the strength reduction caused by the structural damage of soils. In this study, to explore the association between macro shear strength and microstructure evolution of soils subjected to FTC, the red clay distributed widely in the QTP was chosen and used to conduct a series of triaxial shear and nuclear magnetic resonance (NMR) tests in the range of 1 to 7 FTCs. Triaxial shear test results reveal that the shear strength reduction of specimens mainly occurs within five FTCs, and the trend of peak deviator stress with increasing FTCs can be described in three stages: rapid descent (FTCs less than three), slow descent (FTCs between three and five), and stabilization (FTCs greater than five). NMR tests show that the T₂ spectrum curves exhibit a distinct bimodal distribution characteristic, corresponding to macropores and micropores. Part of the micropores gradually develop into macropores with increasing FTCs, especially within five FTCs. The increase in macropores proportion leads to a loose soil structure, which is consistent with the deterioration of the shear strength of specimens. Finally, based on the experimental results and classical Mohr–Coulomb theory, a new shear strength model with structural damage for red clay has been proposed by introducing a damage factor expressed by T₂ spectral area. Full article
