In recent years, skin-mounted devices have gained prominence in personal wellness and remote patient care. However, the rigid components of many wearables often cause discomfort due to their mechanical mismatch with the skin. To address this, we extend the use of the solderable stretchable sensing system (S4) to develop a wireless skin temperature-sensing smart adhesive. This work introduces two novel types of progress in wearables: the first demonstration of Bluetooth-integration and development of a thin-film-based stretchable inverted-F antenna (SIFA). Characterized through RF simulations, vector network analysis under deformation, and anechoic chamber tests, SIFA demonstrated potential as a low-profile, on-body Bluetooth antenna with a resonant frequency of 2.45 GHz that helps S4 retain its thin overall profile. The final S4 system achieved high correlation (R = 0.95, p < 0.001, mean standard error = 0.04 °C) with commercial sensors during daily activities. These findings suggest that S4-based smart adhesives integrated with SIFAs could offer a promising platform for comfortable, efficient, and functional skin-integrated wearables, supporting a range of health monitoring applications. Full article

Nowadays, additive manufacturing technologies have impacted different engineering sectors. Three- and four-dimensional printing techniques are increasingly used in soft and flexible electronics thanks to the possibility of working contemporarily with several materials on various substrates. The materials portfolio is wide, as well as printing processes. Shape memory polymers, together with composites, have gained great success in the electronic field and are becoming increasingly popular for fabricating pH, temperature, humidity, and stress sensors that are integrated into wearable, stretchable, and flexible devices, as well as for the fabrication of communication devices, such as antennas. Here, we report an overview of the state of the art about the application of 4D printing technologies and smart materials in electronics. Full article

The manuscript presents a novel approach to designing and fabricating a stretchable patch antenna designed for strain sensing and the wireless communication of sensing data at the same time. The challenge lies in combining flexible and stretchable textile materials with different physical morphologies, which can hinder the adhesion among multiple layers when stacked up, resisting the overall stretchability of the antenna. The proposed antenna design overcomes this challenge by incorporating a lattice hinge pattern into the non-stretchable conductive e-textile, transforming it into a stretchable structure. The innovative design includes longitudinal cuts inserted in both the patch and the ground plane of the antenna, allowing it to stretch along in the perpendicular direction. Implementing the lattice hinge pattern over the conductive layers of the proposed patch antenna, in combination with a 2 mm thick Polydimethylsiloxane (PDMS) substrate, achieves a maximum of 25% stretchability compared to its counterpart antenna without a lattice hinge design. The stretchable textile antenna resonates around a frequency of 2.45 GHz and exhibits a linear resonant frequency shift when strained up to 25%. This characteristic makes it suitable for use as a strain sensor. Additionally, the lattice hinge design enhances the conformability and flexibility of the antenna compared to that of a solid patch antenna. The realized antenna gains in the E and H-plane are measured as 2.21 dBi and 2.34 dBi, respectively. Overall, the presented design offers a simple and effective solution for fabricating a stretchable textile patch antenna for normal use or as a sensing element, opening up possibilities for applications in the communication and sensing fields. Full article

The development of three-dimensional printed electronics has garnered significant interest due to the ease of integration of electronic circuitry on 3D surfaces. However, it is still very challenging to achieve the desired conformability, stretchability, and adhesion of conductive pastes used for printing on thermoformable substrates. In this study, we propose the use of novel thermoformable ink composed of copper flakes coated with silver, which enables us to prevent the oxidation of copper, instead of the commonly used silver inks. Various polymer/solvent/flake systems were investigated, resulting in thermoformable conductive printing compositions that can be sintered under air. The best inks were screen printed on PC substrates and were thermoformed using molds with different degrees of strain. The effects of the various components on the thermoforming ability and the electrical properties and morphology of the resulting 3D structures were studied. The best inks resulted in a low sheet resistivity, 100 mΩ/□/mil and 500 mΩ/□/mil before and after thermoforming at 20%, respectively. The feasibility of using the best ink was demonstrated for the fabrication of a thermoformable 3D RFID antenna on PC substrates. Full article

Polymers for implantable devices are desirable for biomedical engineering applications. This study introduces a water-resistant, self-healing fluoroelastomer (SHFE) as an encapsulation material for antennas. The SHFE exhibits a tissue-like modulus (approximately 0.4 MPa), stretchability (at least 450%, even after self-healing in an underwater environment), self-healability, and water resistance (WVTR result: 17.8610 g m⁻² day⁻¹). Further, the SHFE is self-healing in underwater environments via dipole–dipole interactions, such that devices can be protected from the penetration of biofluids and withstand external damage. With the combination of the SHFE and antennas designed to operate inside the body, we fabricated implantable, wireless antennas that can transmit information from inside the body to a reader coil that is outside. For antennas designed considering the dielectric constant, the uniformity of the encapsulation layer is crucial. A uniform and homogeneous interface is formed by simply overlapping two films. This study demonstrated the possibility of wireless communication in vivo through experiments on rodents for 4 weeks, maintaining the maximum communication distance (15 mm) without chemical or physical deformation in the SHFE layer. This study illustrates the applicability of fluoroelastomers in vivo and is expected to contribute to realizing the stable operation of high-performance implantable devices. Full article

The development of microelectronics has been achieved by improving its performance through miniaturization. This was possible through the development of silicon-based semiconductor process technology, but recently, the demand for wearable or flexible devices has increased. These devices are made using various functional elements based on materials that are difficult to utilize with semiconductor devices that contain existing hard silicon-based materials and are bent or flexibly stretched. In this study, wireless antennas suitable for wearable devices were implemented in a stretchable form. It was possible to stably receive a wireless signal, even with a strain of 20% or more, and power light-emitting diodes (LEDs), microheaters, etc. By devising a multi-layered stack antenna without the existing semiconductor process, it was possible to improve the antenna’s reception performance. It is expected that this can be applied in various ways to smart wireless sensors and wearable biomedical devices using the near-field communication (NFC) of smartphones. Full article

Thin-film microdevices can be applied to various wearable devices due to their high flexibility compared to conventional bulk-type electronic devices. Among the various microdevice types, many IoT-based sensor devices have been developed recently. In the case of such sensor elements, it is important to control the surrounding environment to optimize the sensing characteristics. Among these environmental factors, temperature often has a great influence. There are cases where temperature significantly affects the sensor characteristics, as is the case for gas sensors. For this purpose, the development of thin-film-type micro-heaters is important. For this study, a wirelessly driven thin-film micro-heater was fabricated on the flexible and stretchable elastomer, a polydimethylsiloxane (PDMS); the antenna was optimized; and the heater was driven at the temperature up to 102 degrees Celsius. The effect of its use on gas-sensing characteristics was compared through the application of the proposed micro-heater to a gas sensor. The heated SnO₂ nanowire gas sensor improved the performance of detecting carbon monoxide (CO) by more than 20%, and the recovery time was reduced to less than half. It is expected that thin-film-type micro-heaters that can be operated wirelessly are suitable for application in various wearable devices, including those for smart sensors and health monitoring. Full article

Continuous monitoring of physical motion, which can be successfully achieved via a wireless flexible wearable electronic device, is essential for people to ensure the appropriate level of exercise. Currently, most of the flexible LC pressure sensors have low sensitivity because of the high Young’s modulus of the dielectric properties (such as PDMS) and the inflexible polymer films (as the substrate of the sensors), which don’t have excellent stretchability to conform to arbitrarily curved and moving surfaces such as joints. In the LC sensing system, the metal rings, as the traditional readout device, are difficult to meet the needs of the portable readout device for the integrated and planar readout antenna. In order to improve the pressure sensitivity of the sensor, the Ecoflex microcolumn used as the dielectric of the capacitive pressure sensor was prepared by using a metal mold copying method. The Ecoflex elastomer substrates enhanced the levels of conformability, which offered improved capabilities to establish intimate contact with the curved and moving surfaces of the skin. The pressure was applied to the sensor by weights, and the resonance frequency curves of the sensor under different pressures were obtained by the readout device connected to the vector network analyzer. The experimental results show that resonant frequency decreases linearly with the increase of applied pressure in a range of 0–23,760 Pa with a high sensitivity of −2.2 MHz/KPa. We designed a coplanar waveguide-fed monopole antenna used to read the information of the LC sensor, which has the potential to be integrated with RF signal processing circuits as a portable readout device and a higher vertical readout distance (up to 4 cm) than the copper ring. The flexible LC pressure sensor can be attached to the skin conformally and is sensitive to limb bending and facial muscle movements. Therefore, it has the potential to be integrated as a body sensor network that can be used to monitor physical motion. Full article

The conductive polymer complex poly (3,4-ethylene dioxythiophene):polystyrene sulfonate (PEDOT:PSS) is the most explored conductive polymer for conductive textiles applications. Since PEDOT:PSS is readily available in water dispersion form, it is convenient for roll-to-roll processing which is compatible with the current textile processing applications. In this work, we have made a comprehensive review on the PEDOT:PSS-based conductive textiles, methods of application onto textiles and their applications. The conductivity of PEDOT:PSS can be enhanced by several orders of magnitude using processing agents. However, neat PEDOT:PSS lacks flexibility and strechability for wearable electronics applications. One way to improve the mechanical flexibility of conductive polymers is making a composite with commodity polymers such as polyurethane which have high flexibility and stretchability. The conductive polymer composites also increase attachment of the conductive polymer to the textile, thereby increasing durability to washing and mechanical actions. Pure PEDOT:PSS conductive fibers have been produced by solution spinning or electrospinning methods. Application of PEDOT:PSS can be carried out by polymerization of the monomer on the fabric, coating/dyeing and printing methods. PEDOT:PSS-based conductive textiles have been used for the development of sensors, actuators, antenna, interconnections, energy harvesting, and storage devices. In this review, the application methods of PEDOT:SS-based conductive polymers in/on to a textile substrate structure and their application thereof are discussed. Full article

Interests in strain gauge sensors employing stretchable patch antenna have escalated in the area of structural health monitoring, because the malleable sensor is sensitive to capturing strain variation in any shape of structure. However, owing to the narrow frequency bandwidth of the patch antenna, the operation quality of the strain sensor is not often assured under structural deformation, which creates unpredictable frequency shifts. Geometric properties of the stretchable antenna also severely regulate the performance of the sensor. Especially rugged substrate created by printing procedure and manual fabrication derives multivariate design variables. Such design variables intensify the computational burden and uncertainties that impede reliable analysis of the strain sensor. In this research, therefore, a framework is proposed not only to comprehensively capture the sensor’s geometric design variables, but also to effectively reduce the multivariate dimensions. The geometric uncertainties are characterized based on the measurements from real specimens and a Gaussian copula is used to represent them with the correlations. A dimension reduction process with a clear decision criterion by entropy-based correlation coefficient dwindles uncertainties that inhibit precise system reliability assessment. After handling the uncertainties, an artificial neural network-based surrogate model predicts the system responses, and a probabilistic neural network derives a precise estimation of the variability of complicated system behavior. To elicit better performance of the stretchable antenna-based strain sensor, a shape optimization process is then executed by developing an optimal design of the strain sensor, which can resolve the issue of the frequency shift in the narrow bandwidth. Compared with the conventional rigid antenna-based strain sensors, the proposed design brings flexible shape adjustment that enables the resonance frequency to be maintained in reliable frequency bandwidth and antenna performance to be maximized under deformation. Hence, the efficacy of the proposed design framework that employs uncertainty characterization, dimension reduction, and machine learning-based behavior prediction is epitomized by the stretchable antenna-based strain sensor. Full article

Printed electronics on flexible substrates has attracted tremendous research interest research thanks its low cost, large area production capability and environmentally friendly advantages. Optimal characteristics of silver nanoparticles (Ag NPs) based inks are crucial for ink rheology, printing, post-print treatment, and performance of the printed electronics devices. In this review, the methods and mechanisms for obtaining Ag NPs based inks that are highly conductive under moderate sintering conditions are summarized. These characteristics are particularly important when printed on temperature sensitive substrates that cannot withstand sintering of high temperature. Strategies to tailor the protective agents capping on the surface of Ag NPs, in order to optimize the sizes and shapes of Ag NPs as well as to modify the substrate surface, are presented. Different (emerging) sintering technologies are also discussed, including photonic sintering, electrical sintering, plasma sintering, microwave sintering, etc. Finally, applications of the Ag NPs based ink in transparent conductive film (TCF), thin film transistor (TFT), biosensor, radio frequency identification (RFID) antenna, stretchable electronics and their perspectives on flexible and printed electronics are presented. Full article

Patterned conformal conductive structures are used to realize flexible electronics for applications such as electronic skin, communication devices, and sensors. Thus, there is a demand for low-cost rapid fabrication techniques for flexible and stretchable conductors. Spray-coating of liquid metals is a prototyping method that is compatible with elastic substrates. In this work, UV-curable and polyimide masks were used to pattern sprayed liquid metal (LM). The effect of the spraying parameters on the thickness and conductivity of the LM was characterized. A minimum LM linewidth of 48 µm was achieved, along with a minimum gap width of 34 µm. A LM patch antenna and transmission line, which can potentially be used for communication systems, were demonstrated using this fabrication process. Full article

Wireless technology plays an important role in data communication and power transmission, which has greatly boosted the development of flexible and stretchable electronics for biomedical applications and beyond. As a key component in wireless technology, flexible and stretchable antennas need to be flexible and stretchable, enabled by the efforts with new materials or novel integration approaches with structural designs. Besides replacing the conventional rigid substrates with textile or elastomeric ones, flexible and stretchable conductive materials also need to be used for the radiation parts, including conductive textiles, liquid metals, elastomeric composites embedding conductive fillers, and stretchable structures from conventional metals. As the microwave performance of the antenna (e.g., resonance frequency, radiation pattern, and radiation efficiency) strongly depend on the mechanical deformations, the new materials and novel structures need to be carefully designed. Despite the rapid progress in the burgeoning field of flexible and stretchable antennas, plenty of challenges, as well as opportunities, still exist to achieve miniaturized antennas with a stable or tunable performance at a low cost for bio-integrated electronics. Full article
