Step-stare imaging systems are widely used in aerospace optical remote sensing. In order to achieve fast scanning of the target region, efficient coverage path planning (CPP) is a key challenge. However, traditional CPP methods are mostly designed for fixed cameras and disregard the irregular shape of the sensor’s projection caused by the step-stare rotational motion. To address this problem, this paper proposes an efficient, seamless CPP method with an adaptive hyperbolic grid. First, we convert the coverage problem in Euclidean space to a tiling problem in spherical space. A spherical approximate tiling method based on a zonal isosceles trapezoid is developed to construct a seamless hyperbolic grid. Then, we present a dual-caliper optimization algorithm to further compress the grid and improve the coverage efficiency. Finally, both boustrophedon and branch-and-bound approaches are utilized to generate rotation paths for different scanning scenarios. Experiments were conducted on a custom dataset consisting of 800 diverse geometric regions (including 2 geometry types and 40 samples for 10 groups). The proposed method demonstrates comparable performance of closed-form path length relative to that of a heuristic optimization method while significantly improving real-time capabilities by a minimum factor of 2464. Furthermore, in comparison to traditional rule-based methods, our approach has been shown to reduce the rotational path length by at least 27.29% and 16.71% in circle and convex polygon groups, respectively, indicating a significant improvement in planning efficiency. Full article

Retinal vessel segmentation is critical in detecting retinal blood vessels for a variety of eye disorders, and a consistent computerized method is required for automatic eye disorder screening. Many methods of retinal blood vessel segmentation are implemented, but these methods only yielded accuracy and lack of good sensitivity due to the coherence of retinal blood vessel segmentation. Another main factor of low sensitivity is the proper technique to handle the low-varying contrast problem. In this study, we proposed a five-step technique for assessing the impact of retinal blood vessel coherence on retinal blood vessel segmentation. The proposed technique for retinal blood vessels involved four steps and is known as the preprocessing module. These four stages of the pre-processing module handle the retinal image process in the first stage, uneven illumination and noise issues using morphological operations in the second stage, and image conversion to grayscale using principal component analysis (PCA) in the third step. The fourth step is the main step of contributing to the coherence of retinal blood vessels using anisotropic diffusion filtering and testing their different schemes and get a better coherent image on the optimized anisotropic diffusion filtering. The last step included double thresholds with morphological image reconstruction techniques to produce a segmented image of the vessel. The performances of the proposed method are validated on the publicly available database named DRIVE and STARE. Sensitivity values of 0.811 and 0.821 on STARE and DRIVE respectively meet and surpass other existing methods, and comparable accuracy values of 0.961 and 0.954 on STARE and DRIVE databases to existing methods. This proposed new method for retinal blood vessel segmentations can help medical experts diagnose eye disease and recommend treatment in a timely manner. Full article

Diabetes is a widespread disease in the world and can lead to diabetic retinopathy, macular edema, and other obvious microvascular complications in the retina of the human eye. This study attempts to detect diabetic retinopathy (DR), which has been the main reason behind the blindness of people in the last decade. Timely or early treatment is necessary to prevent some DR complications and control blood glucose. DR is very difficult to detect in time-consuming manual diagnosis because of its diversity and complexity. This work utilizes a deep learning application, a convolutional neural network (CNN), in fundus photography to distinguish the stages of DR. The images dataset in this study is obtained from Xiangya No. 2 Hospital Ophthalmology (XHO), Changsha, China, which is very large, little and the labels are unbalanced. Thus, this study first solves the problem of the existing dataset by proposing a method that uses preprocessing, regularization, and augmentation steps to increase and prepare the image dataset of XHO for training and improve performance. Then, it takes the advantages of the power of CNN with different residual neural network (ResNet) structures, namely, ResNet-101, ResNet-50, and VggNet-16, to detect DR on XHO datasets. ResNet-101 achieved the maximum level of accuracy, 0.9888, with a training loss of 0.3499 and a testing loss of 0.9882. ResNet-101 is then assessed on 1787 photos from the HRF, STARE, DIARETDB0, and XHO databases, achieving an average accuracy of 0.97, which is greater than prior efforts. Results prove that the CNN model (ResNet-101) has better accuracy than ResNet-50 and VggNet-16 in DR image classification. Full article

Analyzing medical images has always been a challenging task because these images are used to observe complex internal structures of the human body. This research work is based on the study of the retinal fundus and magnetic resonance images (MRI) for the analysis of ocular and cerebral abnormalities. Typically, clinical quality images of the eyes and brain have low-varying contrast, making it challenge to diagnose a specific disease. These issues can be overcome, and preprocessing or an image enhancement technique is required to properly enhance images to facilitate postprocessing. In this paper, we propose an iterative algorithm based on the McCann Retinex algorithm for retinal and brain MRI. The foveal avascular zone (FAZ) region of retinal images and the coronal, axial, and sagittal brain images are enhanced during the preprocessing step. The High-Resolution Fundus (HRF) and MR brain Oasis images databases are used, and image contrast and peak signal-to-noise ratio (PSNR) are used to assess the enhancement step parameters. The average PSNR enhancement on images from the Oasis brain MRI database was about 3 dB with an average contrast of 57.4. The average PSNR enhancement of the HRF database images was approximately 2.5 dB with a contrast average of 40 over the database. The proposed method was also validated in the postprocessing steps to observe its impact. A well-segmented image was obtained with an accuracy of 0.953 and 0.0949 on the DRIVE and STARE databases. Brain tumors were detected from the Oasis brain MRI database with an accuracy of 0.97. This method can play an important role in helping medical experts diagnose eye diseases and brain tumors from retinal images and Oasis brain images. Full article

Fundus imaging is one of the crucial methods that help ophthalmologists for diagnosing the various eye diseases in modern medicine. An accurate vessel segmentation method can be a convenient tool to foresee and analyze fatal diseases, including hypertension or diabetes, which damage the retinal vessel’s appearance. This work suggests an unsupervised approach for vessels segmentation out of retinal images. The proposed method includes multiple steps. Firstly, from the colored retinal image, green channel is extracted and preprocessed utilizing Contrast Limited Histogram Equalization as well as Fuzzy Histogram Based Equalization for contrast enhancement. To expel geometrical articles (macula, optic disk) and noise, top-hat morphological operations are used. On the resulted enhanced image, matched filter and Gabor wavelet filter are applied, and the outputs from both is added to extract vessels pixels. The resulting image with the now noticeable blood vessel is binarized using human visual system (HVS). A final image of segmented blood vessel is obtained by applying post-processing. The suggested method is assessed on two public datasets (DRIVE and STARE) and showed comparable results with regard to sensitivity, specificity and accuracy. The results we achieved with respect to sensitivity, specificity together with accuracy on DRIVE database are 0.7271, 0.9798 and 0.9573, and on STARE database these are 0.7164, 0.9760, and 0.9560, respectively, in less than 3.17 s on average per image. Full article

Automatic segmentation and centerline extraction of blood vessels from retinal fundus images is an essential step to measure the state of retinal blood vessels and achieve the goal of auxiliary diagnosis. Combining the information of blood vessel segments and centerline can help improve the continuity of results and performance. However, previous studies have usually treated these two tasks as separate research topics. Therefore, we propose a novel multitask learning network (MSC-Net) for retinal vessel segmentation and centerline extraction. The network uses a multibranch design to combine information between two tasks. Channel and atrous spatial fusion block (CAS-FB) is designed to fuse and correct the features of different branches and different scales. The clDice loss function is also used to constrain the topological continuity of blood vessel segments and centerline. Experimental results on different fundus blood vessel datasets (DRIVE, STARE, and CHASE) show that our method can obtain better segmentation and centerline extraction results at different scales and has better topological continuity than state-of-the-art methods. Full article

This paper proposes a simple and effective retinal fundus image simulation modeling to enhance contrast and adjust the color balance for symmetric information in biomedicine. The aim of the study is for reliable diagnosis of AMD (age-related macular degeneration) screening. The method consists of a few simple steps. Firstly, local image contrast is refined with the CLAHE (Contrast Limited Adaptive Histogram Equalization) technique by operating CIE L*a*b* color space. Then, the contrast-enhanced image is stretched and rescaled by a histogram scaling equation to adjust the overall brightness offsets of the image and standardize it to Hubbard’s retinal image brightness range. The proposed method was assessed with retinal images from the DiaretDB0 and STARE datasets. The findings in the experimentation section indicate that the proposed method results in delightful color naturalness along with a standard color of retinal lesions. Full article

In order to enable the aerial photoelectric equipment to realize wide-area reconnaissance and target surveillance at the same time, a dual-band dynamic scan and stare imaging system is proposed in this paper. The imaging system performs scanning and pointing through a two-axis gimbal, compensating the image motion caused by the aircraft and gimbal angular velocity and the aircraft liner velocity using two two-axis fast steering mirrors (FSMs). The composition and working principle of the dynamic scan and stare imaging system, the detailed scheme of the two-axis FSM and the image motion compensation (IMC) algorithm are introduced. Both the structure and the mirror of the FSM adopt aluminum alloys, and the flexible support structure is designed based on four cross-axis flexural hinges. The Root-Mean-Square (RMS) error of the mirror reaches 15.8 nm and the total weight of the FSM assembly is 510 g. The IMC rate equations of the two-axis FSM are established based on the coordinate transformation method. The effectiveness of the FSM and IMC algorithm is verified by the dynamic imaging test in the laboratory and flight test. Full article

Segmentation of retinal vessels plays a crucial role in detecting many eye diseases, and its reliable computerized implementation is becoming essential for automated retinal disease screening systems. A large number of retinal vessel segmentation algorithms are available, but these methods improve accuracy levels. Their sensitivity remains low due to the lack of proper segmentation of low contrast vessels, and this low contrast requires more attention in this segmentation process. In this paper, we have proposed new preprocessing steps for the precise extraction of retinal blood vessels. These proposed preprocessing steps are also tested on other existing algorithms to observe their impact. There are two steps to our suggested module for segmenting retinal blood vessels. The first step involves implementing and validating the preprocessing module. The second step applies these preprocessing stages to our proposed binarization steps to extract retinal blood vessels. The proposed preprocessing phase uses the traditional image-processing method to provide a much-improved segmented vessel image. Our binarization steps contained the image coherence technique for the retinal blood vessels. The proposed method gives good performance on a database accessible to the public named DRIVE and STARE. The novelty of this proposed method is that it is an unsupervised method and offers an accuracy of around 96% and sensitivity of 81% while outperforming existing approaches. Due to new tactics at each step of the proposed process, this blood vessel segmentation application is suitable for computer analysis of retinal images, such as automated screening for the early diagnosis of eye disease. Full article

The accurate segmentation of retinal images is a basic step in screening for retinopathy and glaucoma. Most existing retinal image segmentation methods have insufficient feature information extraction. They are susceptible to the impact of the lesion area and poor image quality, resulting in the poor recovery of contextual information. This also causes the segmentation results of the model to be noisy and low in accuracy. Therefore, this paper proposes a multi-scale and multi-branch convolutional neural network model (multi-scale and multi-branch network (MSMB-Net)) for retinal image segmentation. The model uses atrous convolution with different expansion rates and skip connections to reduce the loss of feature information. Receiving domains of different sizes captures global context information. The model fully integrates shallow and deep semantic information and retains rich spatial information. The network embeds an improved attention mechanism to obtain more detailed information, which can improve the accuracy of segmentation. Finally, the method of this paper was validated on the fundus vascular datasets, DRIVE, STARE and CHASE datasets, with accuracies/F1 of 0.9708/0.8320, 0.9753/0.8469 and 0.9767/0.8190, respectively. The effectiveness of the method in this paper was further validated on the optic disc visual cup DRISHTI-GS1 dataset with an accuracy/F1 of 0.9985/0.9770. Experimental results show that, compared with existing retinal image segmentation methods, our proposed method has good segmentation performance in all four benchmark tests. Full article

Automated detection of vision threatening eye disease based on high resolution retinal fundus images requires accurate segmentation of the blood vessels. In this regard, detection and segmentation of finer vessels, which are obscured by a considerable degree of noise and poor illumination, is particularly challenging. These noises include (systematic) additive noise and multiplicative (speckle) noise, which arise due to various practical limitations of the fundus imaging systems. To address this inherent issue, we present an efficient unsupervised vessel segmentation strategy as a step towards accurate classification of eye diseases from the noisy fundus images. To that end, an ensemble block matching 3D (BM3D) speckle filter is proposed for removal of unwanted noise leading to improved detection. The BM3D-speckle filter, despite its ability to recover finer details (i.e., vessels in fundus images), yields a pattern of checkerboard artifacts in the aftermath of multiplicative (speckle) noise removal. These artifacts are generally ignored in the case of satellite images; however, in the case of fundus images, these artifacts have a degenerating effect on the segmentation or detection of fine vessels. To counter that, an ensemble of BM3D-speckle filter is proposed to suppress these artifacts while further sharpening the recovered vessels. This is subsequently used to devise an improved unsupervised segmentation strategy that can detect fine vessels even in the presence of dominant noise and yields an overall much improved accuracy. Testing was carried out on three publicly available databases namely Structured Analysis of the Retina (STARE), Digital Retinal Images for Vessel Extraction (DRIVE) and CHASE_DB1. We have achieved a sensitivity of 82.88, 81.41 and 82.03 on DRIVE, SATARE, and CHASE_DB1, respectively. The accuracy is also boosted to 95.41, 95.70 and 95.61 on DRIVE, SATARE, and CHASE_DB1, respectively. The performance of the proposed methods on images with pathologies was observed to be more convincing than the performance of similar state-of-the-art methods. Full article

Accurate segmentation of retinal blood vessels is a key step in the diagnosis of fundus diseases, among which cataracts, glaucoma, and diabetic retinopathy (DR) are the main diseases that cause blindness. Most segmentation methods based on deep convolutional neural networks can effectively extract features. However, convolution and pooling operations also filter out some useful information, and the final segmented retinal vessels have problems such as low classification accuracy. In this paper, we propose a multi-scale residual attention network called MRA-UNet. Multi-scale inputs enable the network to learn features at different scales, which increases the robustness of the network. In the encoding phase, we reduce the negative influence of the background and eliminate noise by using the residual attention module. We use the bottom reconstruction module to aggregate the feature information under different receptive fields, so that the model can extract the information of different thicknesses of blood vessels. Finally, the spatial activation module is used to process the up-sampled image to further increase the difference between blood vessels and background, which promotes the recovery of small blood vessels at the edges. Our method was verified on the DRIVE, CHASE, and STARE datasets. Respectively, the segmentation accuracy rates reached 96.98%, 97.58%, and 97.63%; the specificity reached 98.28%, 98.54%, and 98.73%; and the F-measure scores reached 82.93%, 81.27%, and 84.22%. We compared the experimental results with some state-of-art methods, such as U-Net, R2U-Net, and AG-UNet in terms of accuracy, sensitivity, specificity, F-measure, and AUC${}_{ROC}$. Particularly, MRA-UNet outperformed U-Net by 1.51%, 3.44%, and 0.49% on DRIVE, CHASE, and STARE datasets, respectively. Full article

In recent years, applications such as marine search and rescue, border patrol, etc. require electro-optical equipment to have both high resolution and precise geographic positioning abilities. The step and stare working based on a composite control system is a preferred solution. This paper proposed a step and stare system composed of two single-axis fast steering mirrors and a two-axis gimbal. The fast steering mirrors (FSMs) realize image motion compensation and the gimbal completes pointing control. The working principle and the working mode of the system are described first. According to the imaging optical path, the algorithm and control flow of the line of sight (LOS) and image motion compensation are developed. The proposed method is verified through ground imaging and flight tests. Under the condition of flight, the pointing accuracy of the target can be controlled within 15 m. The proposed algorithm can achieve effective motion compensation and get high-resolution images. This achieves high resolution and accurate LOS simultaneously. Full article

Segmentation of retinal blood vessels is the first step for several computer aided-diagnosis systems (CAD), not only for ocular disease diagnosis such as diabetic retinopathy (DR) but also of non-ocular disease, such as hypertension, stroke and cardiovascular diseases. In this paper, a supervised learning-based method, using a multi-layer perceptron neural network and carefully selected vector of features, is proposed. In particular, for each pixel of a retinal fundus image, we construct a 24-D feature vector, encoding information on the local intensity, morphology transformation, principal moments of phase congruency, Hessian, and difference of Gaussian values. A post-processing technique depending on mathematical morphological operators is used to optimise the segmentation. Moreover, the selected feature vector succeeded in outfitting the symmetric features that provided the final blood vessel probability as a binary map image. The proposed method is tested on three known datasets: Digital Retinal Image for Extraction (DRIVE), Structure Analysis of the Retina (STARE), and CHASED_DB1 datasets. The experimental results, both visual and quantitative, testify to the robustness of the proposed method. This proposed method achieved 0.9607, 0.7542, and 0.9843 in DRIVE, 0.9632, 0.7806, and 0.9825 on STARE, 0.9577, 0.7585 and 0.9846 in CHASE_DB1, with respectable accuracy, sensitivity, and specificity performance metrics. Furthermore, they testify that the method is superior to seven similar state-of-the-art methods. Full article

Step/stare imaging with focal plane arrays (FPAs) has become the main approach to achieve wide area coverage and high resolution imaging for long range targets. A fast steering mirror (FSM) is usually utilized to provide back-scanned motion to compensate for the image motion. However, the traditional optical design can just hold one field point relatively stable, typically the central or on-axis field point, on the FPA during back-scanning; all other field points may wander during the exposure due to imaging distortion characteristics of the optical system, which reduces the signal to noise ratio (SNR) of the target. Aiming toward this problem, this paper proposes a non-rotationally symmetric field mapping method for the back-scanned step/stare imaging system, which can make all field points stable on the FPA during back-scanning. First of all, the mathematical model of non-rotationally symmetric field mapping between object space and image space is established. Then, a back-scanned step/stare imaging system based on the model is designed, in which this non-rotationally symmetric mapping can be implemented with an afocal telescope including freeform lenses. Freeform lenses can produce an anamorphic aberration to adjust distortion characteristics of the optical system to control image wander on an FPA. Furthermore, the simulations verify the effectiveness of the method. Full article
