Search Results (109)

Search Parameters:
Keywords = stator topology

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
15 pages, 5296 KiB
Article
Study on Multiple-Inverter-Drive Method for IPMSM to Improve the Motor Efficiency
by Koki Takeuchi and Kan Akatsu
World Electr. Veh. J. 2025, 16(7), 398; https://doi.org/10.3390/wevj16070398 - 15 Jul 2025
Viewed by 126
Abstract
In recent years, the rapid spread of electric vehicles (EVs) has intensified the competition to develop power units for EVs. In particular, improving the driving range of EVs has become a major topic, and in order to achieve this, many studies have been [...] Read more.
In recent years, the rapid spread of electric vehicles (EVs) has intensified the competition to develop power units for EVs. In particular, improving the driving range of EVs has become a major topic, and in order to achieve this, many studies have been conducted on improving the efficiency of EV power units. In this study, we propose a multiple-inverter-drive permanent magnet synchronous motor based on an 8-pole, 48-slot structure, which is commonly used as an EV motor. The proposed motor is composed of two completely independent parallel inverters and windings, and intermittent operation is possible; that is, only one inverter and one parallel winding is used depending on the situation. In the proposed motor, we compare losses including stator iron loss, rotor iron loss, and magnet eddy current loss by PWM voltage inputs for some stator winding topologies, we show that the one-side winding arrangement is the most efficient during intermittent operation, and that it is more efficient than normal operation especially in the low-speed, low-torque range. Finally, through a vehicle-driving simulation considering the efficiency map including motor loss and inverter loss, we show that the intentional use of intermittent operation can improve electrical energy consumption. Full article
Show Figures

Figure 1

21 pages, 3497 KiB
Article
Structural Optimization Design and Analysis of Interior Permanent Magnet Synchronous Motor with Low Iron Loss Based on the Adhesive Lamination Process
by Liyan Guo, Huatuo Zhang, Xinmai Gao, Ying Zhou, Yan Cheng and Huimin Wang
World Electr. Veh. J. 2025, 16(6), 321; https://doi.org/10.3390/wevj16060321 - 9 Jun 2025
Viewed by 962
Abstract
The interior permanent magnet synchronous motors (IPMSMs) are extensively applied in the field of new energy vehicles due to their high-power density and excellent performance control. However, the iron loss has a significant impact on their performance. This study conducts an optimization analysis [...] Read more.
The interior permanent magnet synchronous motors (IPMSMs) are extensively applied in the field of new energy vehicles due to their high-power density and excellent performance control. However, the iron loss has a significant impact on their performance. This study conducts an optimization analysis on the processing technology of silicon steel sheets and motor structure, targeting the reduction of iron loss and the improvement of the motor’s integrated efficiency. Firstly, the influences of two iron core processing technologies on iron loss, namely gluing and welding, are compared. Through experimental tests, it is found that the iron loss density of the gluing process is lower than that of the welding process, and as the magnetic flux density increases, the difference between the two is expanding. Therefore, the iron loss test data from the adhesive process are employed to develop a variable-coefficient iron loss model, enabling precise calculation of the motor’s iron loss. On this basis, aiming at the problem of excessive iron loss of the motor, a novel topological structure of the stator and rotor is proposed. With the optimization goal of reducing the motor iron loss and taking the connection port of the air magnetic isolation slot and the gap of the stator module as the optimization variables, the optimized design of the IPMSM with low iron loss is achieved based on the Taguchi method. After optimization, the stator iron loss decreases by 13.60%, the rotor iron loss decreases by 20.14%, and the total iron loss is reduced by 15.34%. The optimization scheme takes into account both the electromagnetic performance and the process feasibility, it offers technical backing for the high-efficiency operation of new energy vehicle drive motors. Full article
Show Figures

Figure 1

21 pages, 5367 KiB
Article
Analysis and Optimization Design of a Brushless Power Feedback PM Adjustable Speed Drive with Bilayer Wound Rotor
by Xinlei Zheng, Heyun Lin, Yibo Li, Jian Wang and Quanwei Wen
Actuators 2025, 14(5), 241; https://doi.org/10.3390/act14050241 - 12 May 2025
Viewed by 346
Abstract
A novel brushless power feedback permanent magnet adjustable speed drive (BLPF-PMASD) is developed for the energy-saving of a large power electrical machine drive system in this paper. It can transfer the slip power between the input and output shafts to a stator and [...] Read more.
A novel brushless power feedback permanent magnet adjustable speed drive (BLPF-PMASD) is developed for the energy-saving of a large power electrical machine drive system in this paper. It can transfer the slip power between the input and output shafts to a stator and then transmit it back to the power grid, achieving higher drive efficiency and stability. First, the topology feature, operation principle, and power feedback mechanism of the proposed drive are clearly illustrated. Second, a multi-objective optimization design method suitable for all working conditions is proposed to provide an effective design means for this type of adjustable speed drive with power feedback. Finally, the electromagnetic performance of the optimized drive is analyzed by using the finite element method (FEM) to demonstrate the effectiveness and superiority of the proposed drive. Full article
(This article belongs to the Section High Torque/Power Density Actuators)
Show Figures

Figure 1

16 pages, 9202 KiB
Article
Hybrid Brushless Wound-Rotor Synchronous Machine with Dual-Mode Operation for Washing Machine Applications
by Sheeraz Ahmed, Qasim Ali, Ghulam Jawad Sirewal, Kapeel Kumar and Gilsu Choi
Machines 2025, 13(5), 342; https://doi.org/10.3390/machines13050342 - 22 Apr 2025
Viewed by 726
Abstract
This paper proposes a hybrid brushless wound-rotor synchronous machine (HB-WRSM) with an outer rotor topology that can operate as a permanent magnet synchronous machine (PMSM), as well as an HB-WRSM. In the first part, the existing brushless wound-rotor synchronous machine (BL-WRSM) is modified [...] Read more.
This paper proposes a hybrid brushless wound-rotor synchronous machine (HB-WRSM) with an outer rotor topology that can operate as a permanent magnet synchronous machine (PMSM), as well as an HB-WRSM. In the first part, the existing brushless wound-rotor synchronous machine (BL-WRSM) is modified into a hybrid model by introducing permanent magnets (PMs) in the rotor pole faces to improve the magnetic field strength and other performance variables of the machine. In the second part, a centrifugal switch is introduced, which can change the machine operation from HB-WRSM to PMSM. The proposed machine uses an inner stator, outer rotor model with 36 stator slots and 48 poles, making the stator winding a concentrated winding. The HB-WRSM is utilized for dual-speed applications such as washing machines that run at low speed (46 rpm) and high speed (1370 rpm). For high speed, to have a better efficiency and less torque ripple, the machine is switched to PMSM mode using a centrifugal switch. The results are compared with the existing BL-WRSM. A 2D model is simulated using ANSYS Electromagnetics Suite to validate the machine model and performance. Full article
(This article belongs to the Special Issue Recent Developments in Machine Design, Automation and Robotics)
Show Figures

Figure 1

20 pages, 6392 KiB
Article
A Rotational Speed Sensor Based on Flux-Switching Principle
by Duy-Tinh Hoang, Joon-Ku Lee, Kwang-Il Jeong, Kyung-Hun Shin and Jang-Young Choi
Mathematics 2025, 13(8), 1341; https://doi.org/10.3390/math13081341 - 19 Apr 2025
Viewed by 367
Abstract
This study proposes a rotational speed measurement machine based on the flux-switching principle with a 6-stator-slot/19-rotor-pole (6s/19p) topology. With a rotor shape similar to a variable reluctance sensor (VRS), the proposed machine features a simple and robust structure while ensuring the same output [...] Read more.
This study proposes a rotational speed measurement machine based on the flux-switching principle with a 6-stator-slot/19-rotor-pole (6s/19p) topology. With a rotor shape similar to a variable reluctance sensor (VRS), the proposed machine features a simple and robust structure while ensuring the same output frequency as VRS. Additionally, compared to the conventional 12s/10p topology, the 6s/19p configuration reduces permanent magnet (PM) consumption by half while maintaining high induced voltage characteristics. A nonlinear analytical model (NAM), which incorporates the harmonic modeling (HM) technique and an iterative process, is presented. This model more accurately captures the rectangular shape of the PM and stator teeth while accounting for core saturation effects. Based on this model, the optimal dimensions of the proposed machine are investigated to achieve the best performance for speed measurement applications. A coupling FEA simulation between Ansys Maxwell and Twin Builder further analyzes the machine’s performance. Compared to a commercial product of the same size, the proposed machine achieves 31.5% higher output voltage while ensuring lower linearity errors. Moreover, superior load characteristics are observed, with a voltage drop of only 1.58% at 1500 rpm and 30 mA. The proposed machine and NAM provide an improved solution and analytical tool for speed measurement applications. Full article
Show Figures

Figure 1

18 pages, 5955 KiB
Article
Characteristics Improvement of Brushless Doubly-Fed Wind Turbine Generator with Minimized Asymmetric Phenomena
by Yongjiang Jiang, Kejie Wang, Lingkang Zhou, Wenfeng Zhang and Zhen Hu
Electronics 2025, 14(8), 1649; https://doi.org/10.3390/electronics14081649 - 19 Apr 2025
Viewed by 381
Abstract
Compared with the traditional brushless doubly-fed generator (BDFG), the BDFG with double stator (BDFG-DS) architecture achieves enhanced configurability by physically decoupling the power and control windings onto independent stator assemblies. The design offers benefits such as expanded slot dimensions and enhanced power density, [...] Read more.
Compared with the traditional brushless doubly-fed generator (BDFG), the BDFG with double stator (BDFG-DS) architecture achieves enhanced configurability by physically decoupling the power and control windings onto independent stator assemblies. The design offers benefits such as expanded slot dimensions and enhanced power density, yet it remains constrained by inherent asymmetry in three phases, which causes large harmonics and torque ripples. In this paper, the working mechanism of the BDFG-DS is introduced. Then the root cause of the asymmetric phenomena is discussed. And based on the analysis, an optimization method with complementary skewed stators is developed to enhance the performance of the BDFG-DS. By adopting the appropriate combination of pole slot and skewing slot angles of the two stators, the asymmetry and performance, including harmonics and torque ripples, are improved. Meanwhile, unlike the traditional skewing slot method, the torque density and power density are not decreased. Finally, a finite element analysis model is built and simulations are conducted to demonstrate the electromagnetic optimization efficacy of the proposed skewed-stator topology. Full article
Show Figures

Figure 1

30 pages, 23769 KiB
Article
A 2D Generalized Equivalent Magnetic Network Model for Electromagnetic Performance Analysis of Surface-Mounted Permanent Magnet Electric Machines
by Zhixin Liu, Chenqi Tang, Yisong He and Junquan Chen
Electronics 2025, 14(8), 1642; https://doi.org/10.3390/electronics14081642 - 18 Apr 2025
Viewed by 362
Abstract
This paper proposes a two-dimensional (2D) generalized equivalent magnetic network (GEMN) model suitable for surface-mounted permanent magnet electric machines (SPEMs). The model divides the SPEM into eight types of regions: stator yoke, stator tooth body, stator tooth tips, stator slot body, stator slot [...] Read more.
This paper proposes a two-dimensional (2D) generalized equivalent magnetic network (GEMN) model suitable for surface-mounted permanent magnet electric machines (SPEMs). The model divides the SPEM into eight types of regions: stator yoke, stator tooth body, stator tooth tips, stator slot body, stator slot openings, air gap, rotor permanent magnets, and rotor yoke. Each region is subdivided radially and tangentially into multiple 2D magnetic network units containing radial and tangential magnetic circuit parameters, forming a regular magnetic network covering all regions of the SPEM. The topology of this magnetic network remains unchanged during rotor rotation and can accommodate various surface-mounted permanent magnet structures including Halbach arrays, which enhances the generality of the model significantly. The proposed model can be used to calculate the 2D magnetic flux density distribution, winding electromotive force, electromagnetic torque, stator iron loss, and permanent magnet demagnetization in the influence of magnetic saturation, stator slotting, and current harmonic. Comparative analysis with the accurate subdomain method (ASDM) and finite element method (FEM) demonstrates that the GEMN model achieves a good balance between computational speed and accuracy, making it particularly suitable for efficient electromagnetic performance evaluation of SPEMs. Full article
Show Figures

Figure 1

27 pages, 12122 KiB
Article
An Investigation into the Saliency Ratio of Fractional-Slot Concentrated-Winding Generators for Offshore Wind Power
by Isaac Rudden, Guang-Jin Li, Zi-Qiang Zhu, Alexander Duke and Richard Clark
Energies 2025, 18(8), 2057; https://doi.org/10.3390/en18082057 - 17 Apr 2025
Viewed by 382
Abstract
This paper investigates the nature of the low saliency ratio of large permanent magnet generators with fractional-slot concentrated windings (FSCWs). A saliency ratio of at least 1.2 is typically required to enable sensorless control of large generators—a value naturally achieved in integer slot [...] Read more.
This paper investigates the nature of the low saliency ratio of large permanent magnet generators with fractional-slot concentrated windings (FSCWs). A saliency ratio of at least 1.2 is typically required to enable sensorless control of large generators—a value naturally achieved in integer slot winding topologies but absent in FSCW surface-mounted permanent magnet machines reported in the literature. The low saliency ratio in FSCW designs is attributed to larger teeth, which reduce magnetic saturation and increase d-axis inductance. This work explores methods to enhance the saliency ratio of FSCW machines for offshore wind turbines, facilitating sensorless rotor position estimation. The proposed approaches are categorized into two groups: (1) those that preserve the conventional machine geometry with minimal modification to the magnetic circuit and (2) those involving magnetic circuit alterations. The results show that significant improvement in saliency ratio is only achievable through magnetic circuit modifications, such as rotor shoes, albeit with some performance trade-offs. A multi-objective genetic algorithm is employed to design two optimized 3 MW FSCW machine topologies, achieving saliency ratios of 1.15 and 1.2 with minimal performance loss. Compared to a 3 MW FSCW baseline, the optimized designs show stator power reductions of 3.40% and 6.16% for saliency ratios of 1.15 and 1.2, respectively. Full article
Show Figures

Figure 1

16 pages, 5146 KiB
Article
Comparative Study of Dual-Stator Permanent Magnet Machines with Different PM Arrangements and Rotor Topologies for Aviation Electric Propulsion
by Minchen Zhu, Lijian Wu, Dongliang Liu, Yiming Shen, Rongdeng Li and Hui Wen
Machines 2025, 13(4), 273; https://doi.org/10.3390/machines13040273 - 26 Mar 2025
Viewed by 491
Abstract
The dual-stator permanent magnet (DSPM) machine has proved to have high space utilization and a redundant structure, which can be beneficial to improving the fault tolerance and torque density performance. In this paper, three types of DSPM machines are proposed and compared, where [...] Read more.
The dual-stator permanent magnet (DSPM) machine has proved to have high space utilization and a redundant structure, which can be beneficial to improving the fault tolerance and torque density performance. In this paper, three types of DSPM machines are proposed and compared, where two sets of armature windings are wound in both inner/outer stators, producing more than one torque component compared with single-stator PM machines. The machine topology and operating principle of three DSPM machines are analyzed first. Next, feasible stator/rotor-pole number combinations are compared and determined. Furthermore, based on the finite-element (FE) method, both the electromagnetic performances of three DSPM machines under open-circuit and rated-load conditions after optimization are compared, aimed at generating maximum torque at fixed copper loss. The FE analyses indicate that the dual-stator consequent-pole permanent magnet (DSCPPM) machine generates maximum torque per PM volume, together with relatively high efficiency, which makes it a potentially hopeful candidate for low-speed and high-torque applications. In addition, a thermal analysis is carried out to confirm the validity of the design scheme. Finally, in order to verify the FE predictions, a prototype DSCPPM machine is manufactured and experimentally tested. Full article
Show Figures

Figure 1

23 pages, 12851 KiB
Article
Optimal Design, Electromagnetic–Thermal Analysis and Application of In-Wheel Permanent Magnet BLDC Motor for E-Mobility
by Yucel Cetinceviz
Appl. Sci. 2025, 15(6), 3258; https://doi.org/10.3390/app15063258 - 17 Mar 2025
Cited by 2 | Viewed by 667
Abstract
In this paper, a 96 V, 2.5 kW, 36-slot, and 32-pole brushless direct-current (BLDC) motor is designed, analyzed, and tested in the laboratory and on the prototype vehicle to provide the required output performance for an electric vehicle (EV) according to the rated [...] Read more.
In this paper, a 96 V, 2.5 kW, 36-slot, and 32-pole brushless direct-current (BLDC) motor is designed, analyzed, and tested in the laboratory and on the prototype vehicle to provide the required output performance for an electric vehicle (EV) according to the rated operating conditions. Applications for in-wheel electric drivetrains have the potential to deliver high efficiency and high torque. Consequently, in-wheel motor topology is proposed for small EVs, and the sizing equations, including primary, stator, and rotor dimensions, are developed step by step for the preliminary design. Then, a multi-goal function is introduced to obtain optimum motor design. This motor has an outer-rotor-type construction. In addition, a concentrated winding arrangement is used, which ensures low-end winding and thus low copper loss. Then, multiphysics using the coupled electromagnetic–thermal analysis is carried out. Elective analysis using the finite element method, a motor prototype, and experimental studies verifies the design effectively. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

16 pages, 2000 KiB
Proceeding Paper
The Utilization of Printed Circuit Boards (PCBs) in Axial Flux Machines: A Systematic Review
by Isiaka Shuaibu, Eric Ho Tatt Wei, Ramani Kannan and Yau Alhaji Samaila
Eng. Proc. 2025, 87(1), 13; https://doi.org/10.3390/engproc2025087013 - 6 Mar 2025
Viewed by 1214
Abstract
The rapid advancement of technology has increased our reliance on axial flux permanent magnet machines (AFPMMs), making Printed Circuit Boards (PCBs) essential for modern, lightweight designs. This study reviews PCB roles in AFPMMs for low- and high-power applications by examining research from 2019 [...] Read more.
The rapid advancement of technology has increased our reliance on axial flux permanent magnet machines (AFPMMs), making Printed Circuit Boards (PCBs) essential for modern, lightweight designs. This study reviews PCB roles in AFPMMs for low- and high-power applications by examining research from 2019 to 2024. Using the PRISMA methodology, 38 articles from IEEE Xplore and Web of Science were analyzed. This review focuses on advancements in PCB manufacturing, defect mitigation, winding topologies, software tools, and optimization methods. A structured Boolean search strategy (“Printed Circuit Board” OR “PCB” AND “axial flux permanent magnet machine” OR “AFPM”) guided the literature retrieval process. Articles were meticulously screened using the Rayyan software for titles, abstracts, and content, with duplicate removal performed via the Mendeley software V2.120.0. Findings show significant progress in lightweight AFPMMs with PCBs, improving power quality and performance. Research activity over the 6 years showed inconsistent growth, with concentrated trapezoidal winding emerging as the dominant configuration, followed by distributed winding designs. These configurations were particularly applied in single stator double rotor (SSDR) coreless AFPM machines, characterized by minimal defects, minimal losses, and optimized single-layer winding designs utilizing tools such as ANSYS and COMSOL. Growing interest in double stator single rotor (DSSR) and multi-disk configurations highlights opportunities for innovative designs and advanced optimization techniques. Full article
(This article belongs to the Proceedings of The 5th International Electronic Conference on Applied Sciences)
Show Figures

Figure 1

24 pages, 11219 KiB
Article
A Study on the Design of a Fault-Tolerant Consequent-Pole Hybrid Excited Machine for Electric Vehicles
by Guangyu Qu, Jinyi Yu, Zhenghan Li and Wei Liu
World Electr. Veh. J. 2025, 16(3), 130; https://doi.org/10.3390/wevj16030130 - 26 Feb 2025
Viewed by 414
Abstract
In this paper, a new fault-tolerant consequent-pole hybrid excited (FTCPHE) machine with toroidal winding (TW) is designed for electric vehicles (EVs). In this proposed machine, U-type permanent magnets (PMs) are adopted in the consequent-pole rotor with the sequence of PM–iron–PM–iron. The stator tooth [...] Read more.
In this paper, a new fault-tolerant consequent-pole hybrid excited (FTCPHE) machine with toroidal winding (TW) is designed for electric vehicles (EVs). In this proposed machine, U-type permanent magnets (PMs) are adopted in the consequent-pole rotor with the sequence of PM–iron–PM–iron. The stator tooth placed in the stator is classified into two groups to achieve hybrid excitation. The TW is positioned on the stator yoke to achieve the simple structure and excellent fault-tolerant ability. First, the topology of this proposed FTCPHE machine with the TW is briefly introduced and compared to that with the traditional combined winding. Second, the operation principle, the magnetic circuit, and the design procedure of the FTCPHE machine are analyzed and illustrated. Third, several key structural parameters of the proposed FTCPHE machine are discussed and designed to improve electromagnetic performances. Next, some electromagnetic properties, including the flux distribution, the no-load back-EMF, the electromagnetic torque, the cogging torque, and the fault-tolerant ability, are discussed in detail. Finally, a prototype of this proposed FTCPHE machine is manufactured to validate the simulated results. Full article
(This article belongs to the Special Issue Electrical Motor Drives for Electric Vehicle)
Show Figures

Figure 1

21 pages, 11178 KiB
Review
Material Characterization and Strategies for Optimization of Additively Manufactured Electric Machines—A Review
by Shaheer Ul Hassan, Mazahir Hussain Shah, Luděk Pešek and Miroslav Chomát
Electronics 2025, 14(4), 729; https://doi.org/10.3390/electronics14040729 - 13 Feb 2025
Viewed by 1072
Abstract
With the advent of 3D printing, advancements in optimizing structures and innovations to 3D print new materials for electric machines are being developed. Conventional structures are being replaced by lattice structures which provide better properties. From plastics to metals, recent achievements have been [...] Read more.
With the advent of 3D printing, advancements in optimizing structures and innovations to 3D print new materials for electric machines are being developed. Conventional structures are being replaced by lattice structures which provide better properties. From plastics to metals, recent achievements have been made in the 3D printing of soft and hard magnetic materials. Hard magnetic materials are mostly printed by mixing them with ferrites or using a binder material. This paper focuses on all the different methods and compositions to 3D print metals and soft and hard magnetic materials. Although research is still undergoing to expand the use of different magnetic materials, we still have some limitations in their use in electric machines e.g., mixing hard magnetic materials with other materials for 3D printing weakens their electromagnetic properties. Some 3D printing processes provide a comparatively low mechanical strength. With research being undertaken to overcome these challenges, recent 3D-printed magnetic materials for the use in electric machines are discussed in this paper. Apart from materials, different optimization strategies are also introduced that increase the efficiency of the 3D-printed parts e.g., process optimization, topology optimization, and thermal optimization. Process optimization includes different multi-material strategies to reduce the time taken, print multiple parts in one process, and improve the properties of the part. Topology optimization revolves around optimized designs. The properties of electric machines are enhanced by using optimized shapes of rotor, stator, and coils. During the operation of electric machines, there is always some heat generation. The efficient removal of this heat from the system can increase the efficiency of the part. Thermal optimization to efficiently dissipate the heat to the atmosphere is achieved by using phase-changing materials (PCMs), by installing cooling systems, or by introducing optimized structures with better thermal properties. All these developments are discussed in this paper. Full article
Show Figures

Figure 1

19 pages, 9558 KiB
Article
Investigation of a Micro Two-Phase Flux-Switching Motor
by Da-Chen Pang, Hsuan-Chi Huang, Bo-Xian Song and Gia-Thinh Bui
Energies 2025, 18(3), 751; https://doi.org/10.3390/en18030751 - 6 Feb 2025
Viewed by 714
Abstract
This paper presents the world’s smallest two-phase flux-switching motor (FSM), featuring a four-pole stator and a two-pole rotor with a non-uniform air gap design. The FSM offers several advantages, including a compact size, simple structure, and ease of manufacturing, making it suitable for [...] Read more.
This paper presents the world’s smallest two-phase flux-switching motor (FSM), featuring a four-pole stator and a two-pole rotor with a non-uniform air gap design. The FSM offers several advantages, including a compact size, simple structure, and ease of manufacturing, making it suitable for future micromachine applications. The motor has an outer stator diameter of 8 mm, an outer rotor diameter of 4 mm, and a stack length of 5 mm. This research employs a topological method and JMAG-Designer Ver.22.0 electromagnetic analysis software to enhance the rotor design for high output torque and low torque ripple. The final design achieves an average torque of 174 μN-m and a torque ripple of 40%, which is lower than those of any two-phase motor reported in the literature. The two-phase FSM has been fabricated, assembled, and tested to demonstrate its feasibility. Full article
Show Figures

Figure 1

12 pages, 1841 KiB
Article
Electromagnetic Design and End Effect Suppression of a Tubular Linear Voice Motor for Precision Vibrating Sieves
by Meizhu Luo, Zijiao Zhang, Yan Jiang and Ji-an Duan
Energies 2025, 18(3), 704; https://doi.org/10.3390/en18030704 - 3 Feb 2025
Cited by 1 | Viewed by 711
Abstract
Precision vibrating sieves need a kind of power source, featuring small size, high frequency response, and small vibration amplitude. Linear Voice Coil Motor (LVCM) can achieve a high accelerated speed in a short stroke; it is an appropriate power source for the precision [...] Read more.
Precision vibrating sieves need a kind of power source, featuring small size, high frequency response, and small vibration amplitude. Linear Voice Coil Motor (LVCM) can achieve a high accelerated speed in a short stroke; it is an appropriate power source for the precision vibrating sieves. This paper designs a tubular LVCM with a volume no more than 6 cm3 and a stroke no less than 1.5 mm. The electromagnetic topology of this LVCM is established to validate its feasibility; the back Electromotive Force (back EMF) and the electromagnetic force are calculated. The end effect of this tubular LVCM is studied in detail; the auxiliary pole and the magnetic conductive stator base are designed to suppress its end detent force. Then, the main structure parameters are globally optimized by the multi-objective genetic algorithm to obtain better performance. The prototype of this tubular LVCM is manufactured and tested. The results of the experiments are compared with those of theoretical analyses. It is indicated that this tubular LVCM can provide an accelerated speed of 15g; g is the gravitational acceleration. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1
