Poly[bis(4-phenyl) (2,5,6-trimethylphenyl) amine (PTAA), as a hole transfer material, has been widely used in perovskite solar cells (PSCs). However, the optimal solvent for preparing the PTAA solution and coating the PTAA layer is still uncertain. In this work, we investigated three types of organic solvents (toluene, chlorobenzene and dichlorobenzene) for processing PTAA layers as the hole transport layer in PSCs. Based on the experimental verification and molecular dynamics simulation results, all the evidence indicated that toluene performs best among the three candidates. This is attributed to the significant polarity difference between toluene and PTAA, which leads to the formation of a uniform surface morphology characterized by granular protuberances after spin coating. The contact area of the hole transfer layer with the surface aggregation is increased in reference to the rough surface, and the hydrophilicity of the PTAA layer is also increased. The improvement of these two aspects are conducive to the effective interfacial charge transfer. This leads to the generation of more photocurrent. The PSCs employing toluene-processed PTAA exhibit an average power conversion efficiency (PCE) of 19.1%, which is higher than that of PSCs using chlorobenzene- and dichlorobenzene-processed PTAA (17.3–17.9%). This work provides a direct optimization strategy for researchers aiming to fabricate PSCs based on PTAA as a hole transport layer and lays a solid foundation for the development of high-efficiency inverted PSCs. Full article

Developing functional perovskites is important for advancing solar energy conversion technologies. This study investigates the effects of dopants on the structural, optical, electronic, and solar conversion performances of Ba₂M_0.4Bi_1.6O₆ double perovskites. X-ray diffraction (XRD) and Rietveld refinement confirm crystallization in the I2/m space group (M = La, Ce, Pr, Pb), and Fm$\overline{3}$m and I2/m space groups (M = Y). The B1-O-B2 structure modulates to highly ordered (M = La, Y), partially ordered (M = Pr), or disordered (M = Ce, Pb). UV-vis spectra show strong light absorption, with Tauc plots estimating ~1.57 eV (M = La) and ~1.73 eV (M = Pr) optical band gaps. Under AM 1.5G illumination, the M = La photoelectrode generates photocurrents of 1 mA cm⁻² at 0.3 V_RHE, surpassing M = Ce and Pb (1 μm, 4-times spin-coating). Increasing its thickness to 7.7 μm (4-times dip-coating) further enhances the photocurrents to 2.3 mA cm⁻² at 0.2 V_RHE, outperforming all counterparts due to improved stability. Fine-tuning crystal and electronic structures via strategic B-site doping provides a new route for engineering Ba₂Bi₂O₆-based double perovskites for broad solar energy conversion applications. Full article

Hybrid organic–inorganic perovskites have emerged as promising materials for next-generation optoelectronic devices owing to their tunable properties and low-cost fabrication. We report the synthesis of 3D hybrid perovskites with monoethanolammonium cations. Specifically, we investigated the optoelectronic properties and morphological characteristics of polycrystalline films of hybrid perovskites MA_xMEA_1−xPbI₃, which contain methylammonium (MA) and monoethanolammonium (MEA) cations. MA_xMEA_1−xPbI₃ crystallizes in a tetragonal perovskite structure. The substitution of methylammonium cations with monoethanolammonium ions led to an increase in the lattice parameters and the bandgap energy. Energy level diagrams of the synthesized samples were also constructed. The bandgap of MA_0.5MEA_0.5PbI₃ makes it a promising material for use in tandem solar cells. These polycrystalline films, namely MA_0.5MEA_0.5PbI₃ and MA_0.25MEA_0.75PbI₃ were fabricated using a one-step spin-coating method without an antisolvent. These films exhibit a uniform surface morphology under the specified deposition parameters. Within the scope of this study, no evidence of dendritic structures or pinhole-type defects were observed. All synthesized samples demonstrated photocurrent generation under visible light illumination. Moreover, using monoethanolammonium cations reduced the hysteresis of the I–V characteristics, indicating improved device stability. Full article

Different materials are studied for environmental gas sensors as well as photodetection prototypes. A ZnO/MoS₂ p-n junction was synthetized to act as a multifunctional sensor prototype. After the ZnO was prepared on a silicon substrate by using DC sputtering at room temperature, molybdenum disulfide layers were spin-coated on a nanostructured zinc oxide flake-shaped surface to form an active layer. The heterostructure’s composite surface was examined using scanning electron microscopy, energy-dispersed X-ray, and Raman spectroscopy. Responses to light frequencies, light intensities, and gas chemical tracing were characterized, revealing an enhanced multifunctional performance of the prototype. Characterizations of light-induced photocurrents indicted that the obtained response strength (photocurrent/illumination light power) was up to 0.01 A/W, and the response time was less than 5 ms. In contrast, the gas-sensing measurements showed that its response strength (variation in resistance/original resistance) was up to 3.7% and the response time was down to 150 s when the prototype was exposed to ammonia gas, with the concentration down to 168 ppm. The fabricated prototype appears to have high stability and reproducibility, quick response and recovery times, as well as a high signal-to-noise ratio. Full article

Photodetectors based on selenium (Se) have attracted significant attention because of their outstanding optoelectronic characteristics, including their rapid reactivity and high photoconductivity. However, the poor responsivity of pure Se limits their further development. In this study, a novel Se-P/P3HT:G photodetector was designed and fabricated by combining an organic semiconductor made of poly-3-hexylthiophene mixed with graphene (P3HT:G) with self-supporting Se paper (Se-P) via spin-coating process. The device possesses a dark current of around 4.23 × 10⁻¹² A and self-powered characteristics at 300–900 nm. At zero bias voltage and 548 nm illumination, the Se-P/P3HT:G photodetector demonstrates a maximum photocurrent of 1.35 × 10⁻⁹ A (745% higher than that of Se-P at 0.1 V), a quick response time (16.2/27.6 ms), an on/off ratio of 292, and a maximum detectivity and responsivity of 6.47 × 10¹¹ Jones and 34 mA W⁻¹, respectively. Moreover, Se-P/P3HT:G exhibits superior environmental stability. After one month, the photocurrent value of the Se-P/P3HT:G device held steady at 91.4% of its initial value, and even following pre-treatment at 140 °C, the on/off ratio still remained 17 (at a retention rate of about 5.9%). The excellent thermal stability, environmental reliability, and optoelectronic performance of this heterojunction structure offer a useful pathway for the future advancement of high-performance optoelectronic devices. Full article

The promising possibility of an organic photodetector (OPD) is emerging in the field of sensing applications for its tunable absorption range, flexibility, and large-scale fabrication abilities. In this work, we fabricated a bulk heterojunction OPD with a device structure of glass/ITO/PEDOT:PSS/P3HT:PC₆₁BM/Al using the spin-coating process and characterized the dark and photocurrent densities at different applied bias conditions for red, green, and blue incident LEDs. The OPD photocurrent density exhibited a magnitude up to 2.5–3 orders higher compared to the dark current density at a −1 V bias while it increased by up to 3–4 orders at zero bias conditions for red, green, and blue lights, showing an increasing trend when a higher voltage is applied in the negative direction. Different OPD inner periphery shapes, the OPD to LED distance, and OPD area were also considered to bring the variation in the OPD dark and photocurrent densities, which can affect the on/off ratio of the OPD–LED hybrid system and is a critical phenomenon for any sensing application. Full article

In this study, a hollow tubulous-shaped In₂O₃ derived from MIL (MIL-68 (In)) exhibited an enhanced specific surface area compared to MIL. To further sensitize In₂O₃, ZnIn₂S₄ was grown in situ on the derived In₂O₃. The 40In₂O₃/ZnIn₂S₄ composite (1 mmol ZnIn₂S₄ loaded on 40 mg In₂O₃) exhibited degradation rates of methyl orange (MO) under visible light (80 mW·cm⁻², 150 min) that were 17.9 and 1.4 times higher than those of the pure In₂O₃ and ZnIn₂S₄, respectively. Moreover, the 40In₂O₃/ZnIn₂S₄ exhibited an obviously improved antibacterial performance against Pseudomonas aeruginosa, with an antibacterial rate of 99.8% after visible light irradiation of 80 mW cm⁻² for 420 min. The 40In₂O₃/ZnIn₂S₄ composite showed the highest photocurrent density, indicating an enhanced separation of photogenerated charge carriers. Electron spin resonance results indicated that the 40In₂O₃/ZnIn₂S₄ composite generated both ·O₂⁻ and ·OH radicals under visible light, whereas ·OH radicals were almost not detected in ZnIn₂S₄ alone, suggesting the presence of a Z-scheme heterojunction between In₂O₃ and ZnIn₂S₄, thereby enhancing the degradation and antibacterial capabilities of the composite. This offers fresh perspectives on designing effective photocatalytic materials for use in antibacterial and antifouling applications. Full article

This study presents a pioneering synthesis of a direct Z-scheme Y₂TmSbO₇/GdYBiNbO₇ heterojunction photocatalyst (YGHP) using an ultrasound-assisted hydrothermal synthesis technique. Additionally, novel photocatalytic nanomaterials, namely Y₂TmSbO₇ and GdYBiNbO₇, were fabricated via the hydrothermal fabrication technique. A comprehensive range of characterization techniques, including X-ray diffractometry, Fourier-transform infrared spectroscopy, Raman spectroscopy, UV-visible spectrophotometry, X-ray photoelectron spectroscopy, transmission electron microscopy, X-ray energy-dispersive spectroscopy, fluorescence spectroscopy, photocurrent testing, electrochemical impedance spectroscopy, ultraviolet photoelectron spectroscopy, and electron paramagnetic resonance, was employed to thoroughly investigate the morphological features, composition, chemical, optical, and photoelectric properties of the fabricated samples. The photocatalytic performance of YGHP was assessed in the degradation of the pesticide acetochlor (AC) and the mineralization of total organic carbon (TOC) under visible light exposure, demonstrating eximious removal efficiencies. Specifically, AC and TOC exhibited removal rates of 99.75% and 97.90%, respectively. Comparative analysis revealed that YGHP showcased significantly higher removal efficiencies for AC compared to the Y₂TmSbO₇, GdYBiNbO₇, or N-doped TiO₂ photocatalyst, with removal rates being 1.12 times, 1.21 times, or 3.07 times higher, respectively. Similarly, YGHP demonstrated substantially higher removal efficiencies for TOC than the aforementioned photocatalysts, with removal rates 1.15 times, 1.28 times, or 3.51 times higher, respectively. These improvements could be attributed to the Z-scheme charge transfer configuration, which preserved the preferable redox capacities of Y₂TmSbO₇ and GdYBiNbO₇. Furthermore, the stability and durability of YGHP were confirmed, affirming its potential for practical applications. Trapping experiments and electron spin resonance analyses identified active species generated by YGHP, namely •OH, •O₂⁻, and h⁺, allowing for comprehensive analysis of the degradation mechanisms and pathways of AC. Overall, this investigation advances the development of efficient Z-scheme heterostructural materials and provides valuable insights into formulating sustainable remediation strategies for combatting AC contamination. Full article

Upconversion nanoparticles (UCNPs) and carbon quantum dots (CQDs) have emerged as promising candidates for enhancing both the stability and efficiency of perovskite solar cells (PSCs). Their rising prominence is attributed to their dual capabilities: they effectively passivate the surfaces of perovskite-sensitive materials while simultaneously serving as efficient spectrum converters for sunlight. In this work, we synthesized UCNPs doped with erbium ions as down/upconverting ions for ultraviolet (UV) and near-infrared (NIR) light harvesting. Various percentages of the synthesized UCNPs were integrated into the mesoporous layers of PSCs. The best photovoltaic performance was achieved by a PSC device with 30% UCNPs doped in the mesoporous layer, with PCE = 16.22% and a fill factor (FF) of 74%. In addition, the champion PSCs doped with 30% UCNPs were then passivated with carbon quantum dots at different spin coating speeds to improve their photovoltaic performance. When compared to the pristine PSCs, a fabricated PSC device with 30% UCNPs passivated with CQDs at a spin coating speed of 3000 rpm showed improved power conversion efficiency (PCE), from 16.65% to 18.15%; a higher photocurrent, from 20.44 mA/cm² to 22.25 mA/cm²; and a superior fill factor (FF) of 76%. Furthermore, the PSCs integrated with UCNPs and CQDs showed better stability than the pristine devices. These findings clear the way for the development of effective PSCs for use in renewable energy applications. Full article

Although perovskite has great potential in optoelectronic devices, the simultaneous satisfaction of material stability and high performance is still an issue that needs to be solved. Most perovskite optoelectronic devices use quantum dot spin coating or the gas-phase growth of perovskite thin films as the photoelectric conversion layer. Due to stability limitations, these materials often experience a significant decrease in photoelectric conversion efficiency when encountering liquid reagents. The self-assembled growth of hybrid perovskite crystals determines superior lattice ordering and stability. There are three types of ionic liquids—[Emim]BF4, EMIMNTF2, and HMITFSI—that can effectively enhance the X-ray photoelectric conversion performance of hybrid perovskite crystal CH₃NH₃PbI₃ (MAPbI₃), and the enhancement in the photocurrent leads to an improvement in the sensitivity of X-ray detectors. We soak the perovskite crystals in an ionic liquid and perform two treatment methods: electrification and dilution with ETOH solution. It is interesting to find that MAPbI₃ perovskite single crystal materials choose the same optimized ionic liquid species in X-ray detection and photovoltaic power generation applications, and the effect is quite the opposite. Compared with untreated MAPbI₃ crystals, the average photocurrent density of Electrify-HMITFSI MAPbI₃ increased by 826.85% under X-ray excitation and the sensitivity of X-ray detectors made from these treated MAPbI₃ crystals significantly increased by 72.6%, but the intensity of the PL spectrum decreased to 90% of the untreated intensity. Full article

The crystallization conditions from the solution play an important role in determining the morphology, phase composition, and photovoltaic properties of perovskite films. Post-processing of the obtained films can have a crucial role in increasing the grain size of perovskite and enhancing its crystallinity. It has been shown that the formation of crystal nuclei can be utilized to accelerate crystallization. In this case, crystallization occurs through the growth of seed crystals created in the solution, enabling the formation of relatively large crystals. For the deposition of CH₃NH₃PbI₃ hybrid halide perovskite films from a solution of the perovskite in dimethylformamide, the spin coating technique was employed. Pre-crystallization was achieved by annealing the films at a temperature of 100 or 110 °C. The dissolution process involved adding a drop of dimethylformamide onto the substrate surface and allowing it to partially dissolve the perovskite film. Subsequently, residual solvent was removed through spin coating. The morphological analysis of the perovskite film surface after recrystallization at temperatures ranging from 80 to 130 °C was performed. The infrared transmission spectra of the obtained perovskite films were investigated, and their light absorption characteristics were studied through transmission spectra. The perovskite structure in the obtained films was confirmed by the peaks observed in the X-ray diffraction patterns. It has been shown that the photocurrent values for solar cells with perovskite films obtained by recrystallization are 15–20% higher than those of perovskite films obtained by traditional crystallization methods. Full article

Lead halide perovskites (LHPs) containing organic parts are emerging optoelectronic materials with a wide range of applications thanks to their high optical absorption, carrier mobility, and easy preparation methods. They possess spin-dependent properties, such as strong spin–orbit coupling (SOC), and are promising for spintronics. The Rashba effect in LHPs can be manipulated by a magnetic field and a polarized light field. Considering the surfaces and interfaces of LHPs, light polarization-dependent optoelectronics of LHPs has attracted attention, especially in terms of spin-dependent photocurrents (SDPs). Currently, there are intense efforts being made in the identification and separation of SDPs and spin-to-charge interconversion in LHP. Here, we provide a comprehensive review of second-order nonlinear photocurrents in LHP in regard to spintronics. First, a detailed background on Rashba SOC and its related effects (including the inverse Rashba–Edelstein effect) is given. Subsequently, nonlinear photo-induced effects leading to SDPs are presented. Then, SDPs due to the photo-induced inverse spin Hall effect and the circular photogalvanic effect, together with photocurrent due to the photon drag effect, are compared. This is followed by the main focus of nonlinear photocurrents in LHPs containing organic parts, starting from fundamentals related to spin-dependent optoelectronics. Finally, we conclude with a brief summary and future prospects. Full article

In this study, a self-powered broadband photodetector based on graphene/NiO/n-Si was fabricated by the direct spin-coating of nanostructured NiO on the Si substrate. The current–voltage measurement of the NiO/Si heterostructure exhibited rectifying characteristics with enhanced photocurrent under light illumination. Photodetection capability was measured in the range from 300 nm to 800 nm, and a higher photoresponse in the UV region was observed due to the wide bandgap of NiO. The presence of a top graphene transparent conducting electrode further enhanced the responsivity in the whole measured wavelength region from 350 to 800 nm. The photoresponse of the NiO/Si detector at 350 nm was found to increase from 0.0187 to 0.163 A/W at −1 V with the insertion of the graphene top layer. A high photo-to-dark current ratio (≃10⁴) at the zero bias indicates that the device has advantageous application in energy-efficient high-performance broadband photodetectors. Full article

In recent years, scientists have conducted extensive research on Moiré materials and have discovered some compelling properties. The Moiré superlattice allows superconductivity through flat-band and strong correlation effects. The presence of flat bands causes the Moiré material to exhibit topological properties as well. Modulating electronic interactions with magnetic fields in Moiré materials enables the fractional quantum Hall effect. In addition, Moiré materials have ferromagnetic and antiferromagnetic properties. By tuning the interlayer coupling and spin interactions of the Moiré superlattice, different magnetic properties can be achieved. Finally, this review also discusses the applications of Moiré materials in the fields of photocurrent, superconductivity, and thermoelectricity. Overall, Moiré superlattices provide a new dimension in the development of two-dimensional materials. Full article

The high-quality n-type CdS on a p-type Si (111) photodetector device was prepared for the first time by a one-pot method based on an ns laser ablation method in a liquid medium. Cadmium target was ablated in DMSO solution, containing sulfur precursor, and stirred, assisting in 1D-growth, to create the sulfide structure as CdS nano-ropes form, followed by depositing on the Si-substrate by spin coating. The morphological, structural, and optical characteristics of the CdS structure were examined using X-ray diffraction, transmission, and scanning electron microscopy, photoluminescence, and UV-VIS spectroscopy. From X-ray diffraction analysis, the growing CdS spheres have a good crystal nature, with a high purity and desired c-axis orientation along the (002) plane, and the crystallinity was around 30 nm. According to optical characterization, high transparency was found in the visible–near-infrared areas of the electromagnetic spectrum, and the CdS spheres have a direct optical energy band gap of 3.2 eV. After that, the CdS/Si hetero-structured device was found to be improved remarkably after adding CdS. It showed that the forward current is constantly linear, while the dark current is around 4.5 µA. Up to a bias voltage of 4 V, there was no breakdown, and the reverse current of the heterojunctions somewhat increased with reverse bias voltage, while the photocurrent reached up to 580 and 690 µA for using 15 and 30 W/cm² light power, respectively. Additionally, the ideal factors for CdS/Si heterojunction were 3.1 and 3.3 for 15 and 30 W/cm² light power, respectively. These results exhibited high performance compared to the same heterojunction produced by other techniques. In addition, this opens the route for obtaining more enhancements of these values based on the changing use of sulfide structures in the heterojunction formation. Full article
