It is difficult to achieve high-precision color reproduction using traditional color reproduction methods when the angle is changed, and, for large-sized artefacts, it is also significantly difficult to collect a large amount of data and reproduce the colors. In this paper, we use three Bidirectional Reflectance Distribution Function (BRDF) modeling methods based on spectral imaging techniques, namely, the five-parameter model, the Cook–Torrance model and the segmented linear interpolation model. We investigated the color reproduction of color chips with matte surfaces and Chinese paintings with rough surfaces under unknown illumination angles. Experiments have shown that all three models can effectively perform image reconstruction under small illumination angle intervals. The segmented linear interpolation model exhibits a higher stability and accuracy in color reconstruction under small and large illumination angle intervals; it can not only reconstruct color chips and Chinese painting images under any illumination angle, but also achieve high-quality image color reconstruction standards in terms of objective data and intuitive perception. The best test model (segmented linear interpolation) performs well in reconstruction, reconstructing Chinese paintings at 65° and 125° with an illumination angle interval of 10°. The average RMSE of the selected reference color blocks is 0.0450 and 0.0589, the average CIEDE2000 color difference is 1.07 and 1.50, and the SSIM values are 0.9227 and 0.9736, respectively. This research can provide a theoretical basis and methodological support for accurate color reproduction as well as the large-sized scientific prediction of artifacts at any angle, and has potential applications in cultural relic protection, art reproduction, and other fields. Full article

The value of the Buddhist cave lies not only in the Buddha statues but also in the surface painting. Hyperspectral imaging technology, as an emerging and effective method for component identification, offers a non-contact and non-destructive approach to the preservation and restoration of oil paintings. This study employed hyperspectral cameras to capture common pigments on the surfaces of Buddhist caves. Then, the results were processed and used as a database to identify the paintings. Additionally, a series of experiments were conducted to examine the impact of binder, substrate types, and pigment sizes on the reflectance spectrum of the paints. The Spectral Angle Matching (SAM) algorithm was then used to analyze the Yuanjue Cave and Qiqushan Stone Carvings of the Tang Dynasty in China. The findings revealed that the position of absorption peaks in the reflectance spectra is not significantly influenced by the substrate but is affected by the binder. Moreover, the absorption depth varies regularly with particle size. Furthermore, the spectral matching results demonstrate that components can be accurately identified even for similar colors. Based on the pigment distribution, the study also inferred specific details of ancient paintings, including the painting steps and hidden information in the manuscript layout. These findings hold significant implications for the restoration of representative surface paintings of the Tang Dynasty Buddhist cave, providing a reference for the selection of restoration materials and methods. Full article

This paper introduces an innovative sensor utilizing bubbles coated with thermochromic paint, aiming to facilitate temperature measurements in challenging-to-reach locations without the requirement of an external power source. The research conducted is innovative in terms of both methodology and application. The characterization of the thermochromic properties of paints was, in fact, performed using spectroradiometric measurements by selecting a temperature range useful for applications in various fields including preventive conservation. The study encompasses two main objectives: (1) analyzing the color characteristics of thermochromic paint and plastic resin that forms the bubbles, and (2) assessing a temperature sensor comprising a thermochromic paint-coated bubble subjected to temperature variations. The thermochromic paint exhibits reversible color modifications in response to temperature changes, making it an ideal candidate for applications of this nature. The color characterization phase involves measurements using a spectroradiometer to compare the spectral reflectance factor (SRF%) of the colored plastic resin spread on canvas with that of the inflated bubbles. The sensor characterization entails evaluating color changes of the thermochromic paint on the bubble surface with varying temperatures. Experimental results indicate that the combination of a red (R) bubble and blue (B) thermochromic paint produces quantifiable color variations suitable for the proposed applications, whereas the alternative combination under examination, namely a blue bubble and red thermochromic paint, yields less accurate results. Considering that for both thermochromic paints the color change temperature is 35 °C, it is possible to see how, for B bubble with R thermochromic paint, the chromatic coordinates change value: C* = 3.14 ± 0.14 and h = 289.54 ± 11.58 at room temperature, while C* = 2.96 ± 0.12 and h = 304.20 ± 12.17 at 35 °C. The same is true for R bubble with B thermochromic paint where C* = 25.31 ± 1.01 and h* = 285.05 ± 11.40 at room temperature, while C* = 20.87 ± 0.85 and h = 288.37 ± 11.53 at 35 °C. The study demonstrates the potential of the approach and suggests further investigations into reproducibility and expanded color combinations. The results provide a promising basis for future improvements in temperature monitoring with thermochromic bubble sensors. Full article

Restorers and curators in museums sometimes find it difficult to accurately segment areas of paintings that have been contaminated with other pigments or areas that need to be restored, and work on the painting needs to be carried out with minimum possible damage. It is therefore necessary to develop measurement systems and methods that facilitate this task in the least invasive way possible. The aim of this study was to obtain high-dynamic-range (HDR) spectral reflectance and spatial resolution for Dalí’s painting entitled Two Figures (1926) in order to segment a small area of black and white pigment that was affected by the contact transfer of reddish pigment from another painting. Using Hypermatrixcam to measure the HDR spectral reflectance developed by this research team, an HDR multispectral cube of 12 images was obtained for the band 470–690 nm in steps of 20 nm. With the values obtained for the spectral reflectance of the HDR cube, the colour of the area of paint affected by the transfer was studied by calculating the a*b* components with the CIELab system. These a*b* values were then used to define two methods of segmenting the exact areas in which there was a transfer of reddish pigment. The area studied in the painting was originally black, and the contamination with reddish pigment occupied 13.87% to 32% of the total area depending on the selected method. These different solutions can be explained because the lower limit is segmentation based on pure pigment and the upper limit considers red as an exclusion of non-black pigment. Over- and under-segmentation is a common problem described in the literature related to pigment selection. In this application case, as red pigment is not original and should be removed, curators will choose the method that selects the highest red area. Full article

Proper selections of microwave-transmitting thermal control materials play key roles in the orbit operations of aerospace microwave detectors. Currently, white paint and germanium-coated polyimide film are common choices for microwave-transmitting thermal control, which have been extensively studied from the perspective of material compositions, ignoring the influence of the micro-nano structure on the surface of the material. Inspired by Saharan silver ants relying on micro-nano structures of hairs for heat protection and dissipation, in this paper, based on finite element simulation, spectral characteristics (e.g., solar absorptance and infrared emissivity) of three types of biomimetic micro-nano structures (e.g., including pyramid, tetrahedron, and triangular prism) were studied and compared. Simulation results revealed that spectral characteristics of these biomimetic micro-nano structures were mainly regulated by the tip height and the air gap; the decrease of the tip height led to the decrease in the solar absorptance and the infrared emissivity; the solar absorptance was decreased, and the infrared emissivity was increased with the increase of the air gap. When these biomimetic structures were compared with flat surfaces without micro-nano topographies, a decrease of the solar absorptance to block the incidence of heat flow from the sun and an increase of the infrared emissivity to dissipate its own heat to the space were located, which may give suggestions on the adjustment of spectral characteristics of aerospace microwave-transmitting thermal control materials. Full article

(1) Background. The aim of this work is to combine non-invasive imaging with chemical characterization analyses to study original and restoration materials of a late 16th-century painting on a canvas representing the “Coronation of the Virgin with the Saints Ambrose and Jerome”, preserved in the Diocesan archive of Orte, a town in the district of Viterbo (Italy). The diagnostic campaign was addressed to support the restoration activities and the choice of the most suitable cleaning operations. (2) Methods. Both traditional analytical techniques and innovative multispectral imaging were applied to solve the diagnostic issues and best address the restoration of the painting. Specifically, hypercolorimetric multispectral imaging (HMI), X-ray fluorescence spectroscopy (XRF), Fourier transform infrared spectroscopy (FT-IR), optical microscopy, and gas chromatography coupled with mass spectrometry (GC-MS) were combined to obtain information on the general conservation state of the artwork and the characterization of pigments, organic binders, and superimposed materials, these last being particularly important to identify ancient and not-documented restoration intervention, enabling the correct choice of the most suitable and effective cleaning intervention. (3) Results. Multispectral data allowed us to differentiate and map original materials through infrared and ultraviolet false color images and spectral reflectance-based similarity maps, suggesting pigment attribution and focusing point analysis for characterization. This approach was particularly successful to identify and locate the presence of unaltered smalt blue in the first painting coat, which had been covered with other pigments, and to suggest the use of organic dye in mixtures with cinnabar and ochres. Spectroscopic and chromatographic techniques enabled us to identify the painting palette and confirm the use of oil-based binder for the pigments and characterize the altered top layers, made with a natural resin and an animal glue. (4) Conclusions. The characterization of the artwork’s materials was essential to select the most suitable methods and materials for the bio-cleaning, based on bacteria, experimented with during the restoration activities. Full article

Since the world’s energy demands are growing rapidly, there is a constant need for new energy systems. One of the cleanest, most abundant, and renewable natural resources available is solar energy; therefore, the development of surfaces with high absorption of solar radiation is increasing. To achieve the best efficiency, such surfaces are coated with spectrally selective coatings, which are strongly influenced by the pigments and resin binders. Spectrally selective paints have a very specific formulation, and since the applied dry coatings should exhibit high spectral selectivity, i.e., high solar absorptivity and low thermal emissivity, the rheological properties of liquid paints are of great importance. In the present work, we studied the effect of the rheological properties of liquid thickness-insensitive spectrally selective (TISS) paints on the spectral selectivity and adhesion of dry coatings on a polymeric substrate. The results showed that the functional and adhesion properties of dry coating on polymeric substrates is strongly dependent on the rheological properties of the binder and catalyst used for the preparation of the liquid paints. It was shown that the paints with good spectral selective properties (thermal emissivity e_T < 0.36 and solar absorptivity a_S > 0.92) and good adhesion (5B) can be prepared for polymer substrates. Full article

Spectral preprocessing data and chemometric tools are analytical methods widely applied in several scientific contexts i.e., in archaeometric applications. A systematic classification of natural powdered pigments of organic and inorganic nature through Principal Component Analysis with a multi-instruments spectroscopic study is presented here. The methodology allows the access to elementary and molecular unique benchmarks to guide and speed up the identification of an unknown pigment and its recipe. This study is conducted on a set of 48 powdered pigments and tested on a real-case sample from the wall painting in S. Maria Delle Palate di Tusa (Messina, Italy). Four spectroscopic techniques (X-ray Fluorescence, Raman, Attenuated Total Reflectance and Total Reflectance Infrared Spectroscopies) and six different spectrometers are tested to evaluate the impact of different setups. The novelty of the work is to use a systematic approach on this initial dataset using the entire spectroscopic energy range without any windows selection to solve problems linked with the manipulation of large analytes/materials to find an indistinct property of one or more spectral bands opening new frontiers in the dataset spectroscopic analyses. Full article

Multispectral imaging is a preliminary screening technique for the study of paintings. Although it permits the identification of several mineral pigments by their spectral behavior, it is considered less performing concerning hyperspectral imaging, since a limited number of wavelengths are selected. In this work, we propose an optimized method to map the distribution of the mineral pigments used by Vincenzo Pasqualoni for his wall painting placed at the Basilica of S. Nicola in Carcere in Rome, combining UV/VIS/NIR reflectance spectroscopy and multispectral imaging. The first method (UV/VIS/NIR reflectance spectroscopy) allowed us to characterize pigment layers with a high spectral resolution; the second method (UV/VIS/NIR multispectral imaging) permitted the evaluation of the pigment distribution by utilizing a restricted number of wavelengths. Combining the results obtained from both devices was possible to obtain a distribution map of a pictorial layer with a high accuracy level of pigment recognition. The method involved the joint use of point-by-point hyperspectral spectroscopy and Principal Component Analysis (PCA) to identify the pigments in the color palette and evaluate the possibility to discriminate all the pigments recognized, using a minor number of wavelengths acquired through the multispectral imaging system. Finally, the distribution and the spectral difference of the different pigments recognized in the multispectral images, (in this case: red ochre, yellow ochre, orpiment, cobalt blue-based pigments, ultramarine and chrome green) were shown through PCA false-color images. Full article

Hyperspectral technology has been used to identify pigments that adhere to the surfaces of polychrome artifacts. However, the colors are often produced by the mixing of pigments, which requires that the spectral characteristics of the pigment mixtures be considered before pigment unmixing is conducted. Therefore, we proposed an experimental approach to investigate the nonlinear degree of spectral reflectance, using several mixing models, and to evaluate their performances in the study of typical mineral pigments. First, five mineral pigments of azurite, malachite, cinnabar, orpiment, and calcite were selected to form five groups of samples, according to their different mass ratios. Second, a fully constrained least squares algorithm based on the linear model and three algorithms based on the nonlinear model were employed to calculate the proportion of each pigment in the mixtures. We evaluated the abundance accuracy as well as the similarity between the measured and reconstructed spectra produced by those mixing models. Third, we conducted pigment unmixing on a Chinese painting to verify the applicability of the nonlinear model. Fourth, continuum removal was also introduced to test the nonlinearity of mineral pigment mixing. Finally, the results indicated that the spectral mixing of different mineral pigments was more in line with the nonlinear mixing model. The spectral nonlinearity of mixed pigments was higher near to the wavelength corresponding to their colors. Meanwhile, the nonlinearity increased with the wavelength increases in the shortwave infrared bands. Full article

Blood is key evidence to reconstruct crime scenes in forensic sciences. Blood identification can help to confirm a suspect, and for that reason, several chemical methods are used to reconstruct the crime scene however, these methods can affect subsequent DNA analysis. Therefore, this study presents a non-destructive method for bloodstain identification using Hyperspectral Imaging (HSI, 397–1000 nm range). The proposed method is based on the visualization of heme-components bands in the 500–700 nm spectral range. For experimental and validation purposes, a total of 225 blood (different donors) and non-blood (protein-based ketchup, rust acrylic paint, red acrylic paint, brown acrylic paint, red nail polish, rust nail polish, fake blood, and red ink) samples (HSI cubes, each cube is of size 1000 × 512 × 224, in which 1000 × 512 are the spatial dimensions and 224 spectral bands) were deposited on three substrates (white cotton fabric, white tile, and PVC wall sheet). The samples are imaged for up to three days to include aging. Savitzky Golay filtering has been used to highlight the subtle bands of all samples, particularly the aged ones. Based on the derivative spectrum, important spectral bands were selected to train five different classifiers (SVM, ANN, KNN, Random Forest, and Decision Tree). The comparative analysis reveals that the proposed method outperformed several state-of-the-art methods. Full article

Hyperspectral imaging (HSI) technology is able to provide fine spectral and spatial information of objects. It has the ability to discriminate materials and thereby has been used in a wide range of areas. However, traditional HSI strongly depends on the sunlight and hence is restricted to daytime. In this paper, a visible/near-infrared active HSI classification method illuminated by a visible/near-infrared supercontinuum laser is developed for spectra detection and objects imaging in the dark. Besides, a deep-learning-based classifier, hybrid DenseNet, is created to learn the feature representations of spectral and spatial information parallelly from active HSI data and is used for the active HSI classification. By applying the method to a selection of objects in the dark successfully, we demonstrate that with the active HSI classification method, it is possible to detect objects of interest in practical applications. Correct active HSI classification of different objects further supports the viability of the method for camouflage detection, biomedical alteration detection, cave painting mapping and so on. Full article

IR Reflectography applied to the identification of hidden details of paintings is extremely useful for authentication purposes and for revealing technical hidden features. Recently, multispectral imaging has replaced traditional imaging techniques thanks to the possibility to select specific spectral ranges bringing out interesting details of the paintings. VIS–NIR–SWIR images of one of the The Drunkenness of Noah versions painted by Andrea Sacchi, acquired with a modified reflex and InGaAs cameras, are presented in this research. Starting from multispectral images we performed post-processing analysis, using visible and infrared false-color images and principal component analysis (PCA) in order to highlight pentimenti and underdrawings. Radiography was performed in some areas to better investigate the inner pictorial layers. This study represents the first published scientific investigation of The Drunkenness of Noah’s artistic production, painted by Andrea Sacchi. Full article

The photo-induced reactivity of compounds at the surface of photocatalytic materials is used to maintain the cleanliness of the surface of glass, concretes and paints. A standard method to quantify the photocatalytic self-cleaning (SC) properties of non-transparent materials was recently published. It is based on the covering of the sample surface with a defined amount of dye and on the evaluation of the reflectance spectra of the coloured surface under irradiation. The calibration of the spectral changes allowed the quantification of the surface residual dye and the evaluation of the self-cleaning kinetics. The method was tested on seven white and coloured photocatalytic materials using methylene blue (MB), rhodamine B (RhB) and metanil yellow (MY). The main by-products of the MB photocatalytic degradation at the solid/solid interface were identified, showing that MB degradation in solution follows a path quite different from that at the solid/solid interface. Also MY showed a different order of photoreactivity. Furthermore, experiments at the solid/solid interface are more trustworthy than tests in solution for evaluating the self-cleaning ability. The differences of the photocatalytic phenomena at the solid/solid interface in comparison with the most studied photoactivated processes at the solid/liquid interface are outlined. Furthermore, photocatalytic materials showed selectivity toward some specific dyes. This encourages the use of more than one dye for the evaluation of the self-cleaning ability of a photocatalytic material. Full article
