Search Results (25)

Deep groove ball bearings are relatively weak in design for withstanding axial forces, but in practical applications, they may be subject to slight axial impact. Spalling failure may occur at a non-central position on the raceway. In response to this issue, this paper studies the axial impact characteristics generated in the bearing system due to uneven contact on both axial sides of the raceway when the rolling element passes through the defect area. A three-degree-of-freedom kinetic model considering the axial impact is proposed in this paper, simulating the effect of the impact on the rolling bearing when the flaking failure occurs at the non-central position of the roller path. The contact deformation area between the rolling element and raceway under axial forces and the position condition of the spalling fault in the raceway axial direction are introduced, and the impact characteristics of the spalling fault at different axial positions of the inner raceway are simulated by the time-varying energy method. Through comparative analysis of simulation and experiment, the variation characteristics of the vibration intensity in three directions of the bearing system when the spalling fault is at different axial positions of the raceway are obtained, and the correctness of the model is verified. This also provides theoretical support for improving the design and selection of bearings. Full article

The finishing mill is a critical link in the hot rolling process, influencing the final product’s quality, and even economic efficiency. The distribution box of the finishing mill plays a vital role in power transmission and distribution. However, harsh operating conditions can frequently lead to distribution box damage and even failure. To diagnose faults in the distribution box promptly, a fault diagnosis network model is constructed in this paper. This model combines depthwise separable convolution and Bi-LSTM. Depthwise separable convolution and Bi-LSTM can extract both spatial and temporal features from signals. This structure enables comprehensive feature extraction and fully utilizes signal information. To verify the diagnostic capability of the model, five types of data are collected and used: the pitting of tooth flank, flat-headed sleeve tooth crack, gear surface crack, gear tooth surface spalling, and normal conditions. The model achieves an accuracy of 97.46% and incorporates a lightweight design, which enhances computational efficiency. Furthermore, the model maintains approximately 90% accuracy under three noise conditions. Based on these results, the proposed model can effectively diagnose faults in the distribution box, and reduce downtime in engineering. Full article

In the fractured weak fault zone, rock mass exhibits low strength and poor self-stability. The geological conditions are complex, and when tunnels cross through fractured zones, significant deformations and collapses are prone to occur, leading to geological hazards. This paper investigates the in situ stress and deformation patterns of the Dongmachang Tunnel No. 1, proposing support solutions for addressing tunnel deformations through field experiments and numerical simulations. The on-site monitoring results indicate that despite implementing measures such as grouting reinforcement and temporary steel supports to control surrounding rock deformation, significant structural damage still occurred in the tunnel support system. The manifestations included severe sinking and cracking of the arch crown, strong inward deformation of the sidewalls, widespread cracking, crushing, and spalling of shotcrete, slight arching uplift, and severe distortion and twisting of steel arches forming a “Z” or “S” shape. To ensure tunnel safety and control the stability of excavations in weak fault zones, a comparison of tunnel deformation support schemes is conducted through field experiments and numerical simulations, indicating that replacing the upper tunnel structure and invert can effectively prevent tunnel deformations. These measures are vital for the sustainable development of tunnel. Full article

The prediction of spalling failure evolution in the lifespan of aeroengine bearings is crucial for en-suring the safe return of aircrafts after such failures occur. This study examines the spalling failure evolution process in bearings by integrating the proposed spalling region contact stress analysis model with the multi-directional subsurface crack extension analysis model. The results elucidate the general pattern of spalling expansion. Utilizing this methodology, the fatigue spalling fault evolution in bearings is thoroughly analyzed. Additionally, a two-dimensional model has been developed to simulate and analyze crack propagation in the critical direction of the spalling region, significantly enhancing the model’s computational efficiency. Full article

Rotational speed measuring is important in order tracking under non-stational working conditions. However, sometimes, encoders or coded discs are not easy to mount due to the limited measurement environment. In this paper, a new in situ gravity acceleration decomposition method (GAD) is proposed for rotational speed estimation, and it is applied in the order tracking scene for fault diagnosis of a gearbox under non-stationary working conditions. In the proposed method, a MEMS accelerometer is locally embedded on the rotating shaft or disc in the tangential direction. The time-varying gravity acceleration component is sensed by the in situ accelerometer during the rotation of the shaft or disc. The GAD method is established to exploit the gravity acceleration component based on the linear-phase finite impulse response (FIR) filter and complete ensemble empirical mode decomposition with adaptive noise (CEEMDAN) methods. Then, the phase signal of time-varying gravity acceleration is derived for rotational speed estimations. A motor–shaft–disc experimental setup is established to verify the correctness and effectiveness of the proposed method in comparison to a mounted encoder. The results show that both the estimated average and instantaneous rotational speed agree well with the mounted encoder. Furthermore, both the proposed GAD method and the traditional vibration-based tacholess speed estimation methods are applied in the context of order tracking for fault diagnosis of a gearbox. The results demonstrate the superiority of the proposed method in the detection of tooth spalling faults under non-stationary working conditions. Full article

Shock-induced plastic deformation and spall damage in the single-crystalline FCC Co₂₅Ni₂₅Fe₂₅Al_7.5Cu_17.5 high-entropy alloy (HEA) under varying shock intensities were systematically investigated using large-scale molecular dynamics simulations. The study reveals the significant influence of crystalline orientation on the deformation mechanism and spall damage. Specifically, the shock wave velocities in the [110] and [111] directions are significantly higher than that in the [001] direction, resulting in a two-zone elastic-plastic shock wave structure observed in the [110] and [111] samples, while only a single-wave structure is found in the [001] sample. The plastic deformation is dominated by the FCC to BCC transformation following the Bain path and a small amount of stacking faults during the compression stage in the [001] sample, whereas it depends on the stacking faults induced by Shockley dislocation motion in the [110] and [111] samples. The stacking faults and phase transformation in the [001] sample exhibit high reversibility under release effects, while extensive dislocations are present in the [110] and [111] samples after release. Interestingly, tension-strain-induced FCC to BCC phase transformation is observed in the [001] sample during the release stage, resulting in increased spall strength compared to the [110] and [111] samples. The spall strength estimated from both bulk and free surface velocity history shows reasonable consistency. Additionally, the spall strength remains stable with increasing shock intensities. The study discusses in detail the shock wave propagation, microstructure change, and spall damage evolution. Overall, our comprehensive studies provide deep insights into the deformation and fracture mechanisms of Co₂₅Ni₂₅Fe₂₅Al_7.5Cu_17.5 HEA under shock loading, contributing to a better understanding of dynamic deformation under extreme environments. Full article

Gear tooth spalling is one of the inevitable fault modes in the long-term service of the traction transmission system of railway vehicles, which can worsen the dynamic load of the rotating mechanical system and reduce the operating quality. Therefore, it is necessary to study its fault mechanism to guide fault diagnosis scientifically. This paper established a planar railway vehicle model with a traction transmission system and an analytical time-varying meshing stiffness (TVMS) model of the spalling spur gear. Then, it analyzed the dynamic characteristics under traction conditions. The research found that the spalling length and depth affect the amplitude of the TVMS at the defect, while the width affects the range of the TVMS loss. The crest factor is the best evaluation indicator in ideal low-noise environments due to its sensitivity and linearity, but it is not good in strong-noise environments. Similarly, a time–frequency analysis tool cannot significantly detect the sideband characteristics that are excited by spalling. After high-pass filtering, the root mean square and variance exhibit excellent classification and vehicle speed independence in strong-noise environments. This research achievement can provide adequate theoretical support for feature selection and making strategies for fault diagnosis of railway vehicle gear systems. Full article

Atomistic molecular dynamics (MD) and a microstructural dislocation density-based crystalline plasticity (DCP) framework were used together across time scales varying from picoseconds to nanoseconds and length scales spanning from angstroms to micrometers to model a buried copper–nickel interface subjected to high strain rates. The nucleation and evolution of defects, such as dislocations and stacking faults, as well as large inelastic strain accumulations and wave-induced stress reflections were physically represented in both approaches. Both methods showed similar qualitative behavior, such as defects originating along the impactor edges, a dominance of Shockley partial dislocations, and non-continuous dislocation distributions across the buried interface. The favorable comparison between methods justifies assumptions used in both, to model phenomena, such as the nucleation and interactions of single defects and partials with reflected tensile waves, based on MD predictions, which are consistent with the evolution of perfect and partial dislocation densities as predicted by DCP. This substantiates how the nanoscale as modeled by MD is representative of microstructural behavior as modeled by DCP. Full article

To control the problem of coal wall spalling in large mining height working faces subject to mining, considering the Duanwang Mine 150505 fully mechanized working face, the mechanism of coal wall spalling in working faces was investigated by theoretical analysis, numerical simulation and field experiment. Based on analysis of coal wall spalling in the working face, a new grouting material was developed. The stress and plastic zone changes affecting the coal wall, before and after grouting in the working face, were analyzed using numerical simulation and surrounding rock grouting reinforcement technology was proposed for application around the new grouting material. The results showed that: (1) serious spalling of the 150505 working face was caused by the large mining height, fault influence and low roof strength, and (2) the new nano-composite low temperature polymer materials used have characteristics of rapid reaction, low polymerization temperature, adjustable setting time, high strength and environmental protection. Based on analysis of the working face coal wall spalling problem, grouting reinforcement technology based on new materials was proposed. Industrial tests were carried out on the working face. Field monitoring showed that the stability of the working face coal wall was significantly enhanced and that rib spalling was significantly improved after comprehensive anti-rib-spalling grouting measures were adopted. These results provide a basis for rib spalling control of working faces under similar conditions. Full article

Surface defect detection systems, which have advanced beyond conventional defect detection methods, lower the risk of accidents and increase working efficiency and productivity. Most fault detection techniques demand extra tools, such as ultrasonic sensors or lasers. With the advancements, these techniques can be examined without additional tools. We propose a morphological attention ensemble learning for surface defect detection called OASIS-Net, which can detect defects of three kinds (crack, efflorescence, and spalling) at the bounding box level. Based on the morphological analysis of each defect, OASIS-Net offers specialized loss functions for each defect that can be examined. Specifically, high-frequency image augmentation, connectivity attention, and penalty areas are used to detect cracks. It also compares the colors of the sensing objects and analyzes the image histogram peaks to improve the efflorescence-verification accuracy. Analyzing the ratio of the major and minor axes of the spalling through morphological comparison reveals that the spalling-detection accuracy improved. Defect images are challenging to obtain due to their properties. We labeled some data provided by AI hub and some concrete crack datasets and used them as custom datasets. Finally, an ensemble learning technique based on multi-task classification is suggested to learn and apply the specialized loss of each class to the model. For the custom dataset, the accuracy of the crack detection increased by 5%, the accuracy of the efflorescence detection increased by 4.4%, and the accuracy of the spalling detection increased by 6.6%. The experimental results reveal that the proposed network outperforms the previous state-of-the-art methods. Full article

Electromechanical actuators (EMAs), as the critical actuator system of next-generation aircraft, have attracted the attention of many institutions and enterprises around the world. However, due to harsh working conditions, their reliability cannot satisfy the requirements of widespread application in aircraft. Therefore, in order to conduct fault diagnosis on EMAs, in this paper, we establish a comprehensive dynamic model under numerous assumptions to study the fault characteristics that may occur in the displacement and acceleration responses of EMA systems. First, an eight-DOF dynamic model containing typical mechanical components of an EMA is established. Then, by obtaining the impact forces between balls and the spalling fault and the nonlinear relationship between the total elastic restoring forces and the change of ball deformation when the fault occurs, a faulty dynamic model is established. Comparison of the simulation results between the normal and faulty model reveals that the acceleration amplitude at the third harmonic of the ball passage frequency increases when fault occurs. Based on this phenomenon, a numerical calculation method of fault characteristics is proposed. Finally, the effectiveness of the established models and the identified phenomenon are verified by experiments conducted on an EMA test rig in a laboratory environment. Full article

For the analysis on the deformation of flexible ring gears in spur gear pairs, the complete flexible ring is discretized, and the boundary condition is added to the connecting points to develop a calculation method for the flexible deformation. The ovality index is used to describe the deformation degree of flexible ring gears, then the influences of ring-gear width and the spalling defects on the flexible deformation of ring gears are discussed. The result shows that the flexible deformation of ring gears is caused by the gear pair meshing force, and the deformed shape is close to an ellipse. In the single-tooth meshing interval of gear pairs, the main form of deformation is being stretched, and while in the double-tooth meshes, the main form is bending deformation. When the width of the ring gear rims is increased, the flexible deformation of the ring gears can be effectively suppressed, and the vibration amplitude of the gear pairs can be reduced. Additionally, when there is a localized spalling fault on gear pairs, the sudden changes in the deformation of flexible ring gears are generated by the shock of the meshing force. Finally, through the finite element analysis model and the experiment, the mathematical model of gear pairs with flexible rings is confirmed. Full article

As more on-road bikeways are built, the timely application of maintenance treatments becomes critical to ensure safe and comfortable conditions for bicyclists. Longitudinal and transverse cracks that evolve to potholes, rough cut utility patching, raveling, and weathering are flexible pavement distresses that pose safety threats to bicyclists. Faulting and spalling are also safety hazards to bicyclists on rigid pavements. Despite of the need to adopt preventive maintenance policies to preserve on-street bikeways in good condition, bikeway maintenance practices are mostly reactive. The main contribution of this paper is to integrate bikeways maintenance criteria into a policy planning approach for pavement management practices. This planning approach articulates inventory data, condition assessment, maintenance treatment selection, budget needs, funding prioritization, and reports for the implementation of enhanced pavement management systems. Information Technology Systems (ITS) should also support data collection and analysis in the implementation of an integrated maintenance approach. With the adoption of ITS tools, traffic flow, space occupancy and congestion information can be registered in real-time for efficient management. As a result, transportation agencies, metropolitan planning organizations, and cities should make better-informed maintenance decisions for the benefit of all road users. Full article

The dynamic characteristics and tooth spalling fault features are studied for the high-contact-ratio spur gear bearing system. The bending torsional dynamic model is proposed in this study for the gear bearing system with an ellipsoid spalling fault. This model also considers time-varying meshing stiffness, tooth friction, fractal gear backlash, and comprehensive transmission error. The meshing stiffness of the system is evaluated using the potential energy method. The bifurcation diagram, time-domain waveform, Poincaré map, phase map, frequency spectrum, and related three-dimensional map are used as tools to analyze the system’s dynamic response qualitatively. The results reveal that the system’s motion with ellipsoid tooth spalling defect exhibits rich dynamic behavior. The response of the proposed dynamic model is consistent with experimental results in the frequency domain. Therefore, the developed dynamic model can predict the system’s vibration behavior with localized spalling fault. Hence, it could also provide a theoretical foundation for future spall defect diagnosis of the gear transmission system. Full article

The effect of vacancies on dynamic response and spallation in single-crystal magnesium (Mg) is investigated by nonequilibrium molecular dynamics simulations. The initial vacancy concentration (C_v) ranges from 0% to 2.0%, and the shock loading is applied along [0001] and [10–10] directions. The simulation results show that the effects of vacancy defects are strongly dependent on the shock directions. For shock along the [0001] direction, vacancy defects have a negligible effect on compression-induced plasticity, but play a role in increasing spall damage. In contrast, for shock along the [10–10] orientation, vacancy defects not only provide the nucleation sites for compression-induced plasticity, which mainly involves crystallographic reorientation, phase transition, and stacking faults, but also significantly reduce spall damage. The degree of spall damage is probably determined by a competitive mechanism between energy absorption and stress attenuation induced by plastic deformation. Void evolution during spallation is mainly based on the emission mechanism of dislocations. The {11–22} <11–23> pyramidal dislocation facilitates the nucleation of void in the [0001] shock, as well as the {1–100} <11–20> prismatic dislocation in the [10–10] shock. We also investigated the variation of spall strength between perfect and defective Mg at different shock velocities. The relevant results can provide a reference for future investigations on spall damage. Full article
