Search Results (17)

This systematic review explores recent advancements in antenna and rectifier systems for radio frequency (RF) energy harvesting within the gigahertz frequency range, aiming to support the development of sustainable and efficient low-power electronic applications. Conducted under the PRISMA methodology, our review filtered 2465 initial records down to 80 relevant studies, addressing three research questions focused on antenna design, operating frequency bands, and rectifier configurations. Key variables such as antenna type, resonant frequency, gain, efficiency, bandwidth, and physical dimensions were examined. Antenna designs including fractal, spiral, bow-tie, slot, and rectangular structures were analyzed, with fractal antennas showing the highest efficiency, while array antennas exhibited lower performance despite their compact dimensions. Frequency band analysis indicated a predominance of 2.4 GHz and 5.8 GHz applications. Evaluation of substrate materials such as FR4, Rogers, RT Duroid, textiles, and unconventional composites highlighted their impact on performance optimization. Rectifier systems including Schottky, full-wave, half-wave, microwave, multi-step, and single-step designs were assessed, with Schottky rectifiers demonstrating the highest energy conversion efficiency. Additionally, correlation analyses using boxplots explored the relationships among antenna area, efficiency, operating frequency, and gain across design variables. The findings identify current trends and design considerations crucial for enhancing RF energy harvesting technologies. Full article

This paper presents a novel Spiral Slot Planar Inverted-F Antenna (SSPIFA) specifically designed for telemedicine and healthcare applications, featuring compact size, biocompatible safety, and high integration suitability. By replacing the conventional top metal patch of a Planar Inverted-F Antenna (PIFA) with a slot spiral radiator whose geometry is precisely matched to the ground plane, the proposed antenna achieves a significant size reduction, making it ideal for encapsulation in miniaturized medical devices—a critical requirement for implantation scenarios. Tailored for the ISM 915 MHz band, the antenna is fabricated with a four-turn slot spiral etched on a 30 mm-diameter dielectric substrate, achieving an overall height of 22 mm and an electrically small profile of approximately 0.09λ × 0.06λ (λ: free-space wavelength at the center frequency). Simulation and measurement results demonstrate a −16 dB impedance matching (S11 parameter) at the target frequency, accompanied by a narrow fractional bandwidth of 1% and stable right-hand circular polarization (RHCP). When implanted in a layered biological tissue model (skin, fat, muscle), the antenna exhibits a near-omni directional radiation pattern in the azimuthal plane, with a peak gain of 2.94 dBi and consistent performance across the target band. These characteristics highlight the SSPIFA’s potential for reliable wireless communication in implantable medical systems, balancing miniaturization, radiation efficiency, and biocompatible design. Full article

This paper introduces a novel miniaturized, four-mode, semi-flexible leaky wave Multiple-Input Multiple-Output (MIMO) antenna specifically designed to advance vehicular communication systems. The proposed antenna addresses key challenges in 5G low- and high-frequency bands, including millimeter-wave communication, by integrating innovative features such as a periodic Spoof Surface Plasmon Polariton Transmission Line (SSPP-TL) and logarithmic-spiral-like semi-circular strip patches parasitically fed via orthogonal ports. These design elements facilitate stable impedance matching and wide impedance bandwidths across operating bands, which is essential for vehicular networks. The hybrid combination of leaky wave and SSPP structures, along with a defected wide-slot ground structure and backside meander lines, enhances radiation characteristics by reducing back and bidirectional radiation. Additionally, a naturalization network incorporating chamfered-edge meander lines minimizes mutual coupling and introduces a fourth radiation mode at 80 GHz. Compact in size (14 × 12 × 0.25 mm³), the antenna achieves high-performance metrics, including S11 < −18.34 dB, dual-polarization, peak directive gains of 11.6 dBi (free space) and 14.6 dBi (on vehicles), isolation > 27 dB, Channel Capacity Loss (CCL) < 3, Envelope Correlation Coefficient (ECC) < 0.001, axial ratio < 2.25, and diversity gain (DG) > 9.85 dB. Extensive testing across various vehicular scenarios confirms the antenna’s robustness for Vehicle-to-Vehicle (V2V), Vehicle-to-Pedestrian (V2P), and Vehicle-to-Infrastructure (V2I) communication. Its exceptional performance ensures seamless connectivity with mobile networks and enhances safety through Specific Absorption Rate (SAR) compliance. This compact, high-performance antenna is a transformative solution for connected and autonomous vehicles, addressing critical challenges in modern automotive communication networks and paving the way for reliable and efficient vehicular communication systems. Full article

Conventional circularly polarized antennas have been employed to deliver microwave illumination in microwave-induced thermoacoustic tomography (TAT). However, these antennas exhibit several limitations in TAT systems, including low efficiency, poor axial ratio (AR) roundness, and narrow axial ratio beamwidth (ARBW). These issues lead to uniform radiation only within a relatively confined area, thereby restricting their effectiveness in clinical applications such as breast imaging. To address these issues, we propose a novel planar slot array antenna that offers a wide ARBW and improved axial ratio (AR) roundness, enabling homogeneous illumination over a larger field. We validated this approach both theoretically and experimentally. Tissue-mimicking phantoms were imaged, demonstrating that the antenna generated a circularly polarized electric field as well as a uniformly illuminated area. These advantages make the antenna proposed in this paper more suitable for clinical imaging compared to traditional microwave radiating antennas. Full article

Within the realm of industrial energy conservation, the optimization of heat exchanger performance is paramount for the augmentation of energy utilization efficiency. This investigation employs computational fluid dynamics (CFD) simulations to elucidate the effects of an innovative DNA-Inspired Slotted Insert (DSI) on the convective heat transfer and pressure drop characteristics within heat exchange tubes. The study provides a thorough analysis of fully turbulent flow (Re = 6600–17,200), examining the effects of various DSI pitches, key lengths, and geometries. The findings reveal that the DSI instigates a three-dimensional spiral flow pattern, which is accompanied by an escalation in the Nusselt number (Nu) and friction factor (f) with increasing Reynolds numbers. An inverse relationship between Nu and both pitch and key length is observed; conversely, f exhibits a direct correlation with these parameters. The study identifies an optimal configuration characterized by a pitch of 10 mm and a key length of 1.5 mm, with square keys demonstrating superior heat transfer performance relative to other geometrical configurations. This research contributes significant design and application insights for double-helical inserts, which are pivotal for the enhancement of heat exchanger efficiency. Full article

To solve the problem of increased grain impurity rate and grain loss rate caused by clogging of sieve holes during the cleaning process of ratooning rice, a spiral step cleaning device was designed, which disturbed the flow field at the sieve holes through vortex in the slot and disrupted the force balance of the blockages at the sieve holes. The device mainly includes a cleaning separation core and a cleaning separation core shell. Firstly, the main parameters of the cleaning separation core were determined, and the critical shear airflow velocity was obtained through theoretical analysis. Through energy loss analysis, the fan wind speed was determined to be 11.5 m/s. Secondly, the CFD-DEM coupling method was used to analyze the flow patterns inside the slot and the movement patterns of blockages on the sieve surface, confirming the effectiveness of vortex guided blockage removal. Finally, a prototype was designed and built for testing, and the results showed that when the wind speed of the fan was 11.5 m/s, the grain impurity rate was 1.35%, the grain loss rate was 2.13%, and the average sieve blockage rate was ≤0.1%. All indicators were better than traditional cleaning devices and could meet the cleaning requirements. During the continuous operation of the spiral step cleaning device, performance indicators such as sieve hole blockage rate remained basically unchanged. Full article

Martian rocks contain crucial information about the genesis of Mars and the historical evolution of Martian climate change. Consequently, extracting and examining Martian rocks are pivotal in advancing our comprehensive understanding of the red planet. However, the current core drill string is prone to wear and tear, and the samples are susceptible to thermal denaturation. To address these challenges, we introduce two novel types of drill bits, the conical straight junk slot and the conical spiral junk slot, both employing impregnated diamond as the primary material. Comparative experiments were meticulously conducted to evaluate the influence of different junk configurations on drilling parameters, including speed, abrasion resistance, drilling force loading, and sample temperature rise. The findings unequivocally demonstrate the superior performance of the spiral junk slot. Furthermore, simulations were performed to examine the drilling process on basalt using a fixed configuration drill bit, validating the occurrence of the sample temperature rise. The research presented in this paper offers valuable programmatic references and essential data support for future Martian rock coring drilling missions. Full article

This paper studies the shear strength of an anti-rust bolt with a spiral oil-guiding slot and oil-bearing hole by conducting a simulation and experiment. A finite element model with the bolt and the clamp tool is developed for simulating the shearing of the bolt in progressive failure analyses. An indirect method is proposed to generate a spiral entity that can produce excellent spiral elements. A clamp tool is designed for the shear experiment of the bolt. Moreover, a substitute calculation method is presented for the shear strength analysis of the special bolt, and the effect of using the oil-guiding slot on shear strengths is considered by reducing the bolt’s radius. The study results show the following: The results of the simulation are in good agreement with the experimental results. One side of the bolt with the oil-bearing hole is first cut off, and the deviation between the result obtained by using the substitute calculation and the experiment’s result is 7.97%. Full article

The deep-sea mining vehicle is the main component of the undersea exploitation system, which gathers polymetallic nodules with its professionally designed seabed collector. The Coandă effect-based collecting method is an improved hydraulic method that forms an adverse pressure gradient over the nodules by performing wall jet flow over a rounded convex surface. In comparison to the circular cylinder surface, the effect of wall jet over the logarithmic spiral surface has a self-preserving nature, which can be advantageous to the nodule collecting. However, this effect on lift capability has seldom been studied before. In the present investigation, a reduced form modelling jet flows over logarithmic spiral surfaces was performed to study the flow characteristics and lift ability of the newly designed Coandă effect-based collector. The jet-half width has been optimized to study the influence of wall curvature on the growth rate. The lift ability was found to be stronger with larger jet exit velocity, local curvature, or non-dimensional jet slot height. The growth rate, which represents the width of the main jet flow, went up in proportion to the downstream distance. The lift capability of jet flow in logarithmical spiral of x/R = 1 is significantly better than that of x/R = 2/3. Full article

Two optical waveguide sensors based on SOS (silicon-on-sapphire) for detecting CO₂ are theoretically proposed. The operational wavelength is 4.23 μm, which is the maximum absorption line of CO₂. The power confinement factor (η) value is over 40% and 50%, the propagation loss is 0.98 dB/cm and 2.99 dB/cm, respectively, in the slot waveguide and SWGS (subwavelength grating slot) waveguide. An inverted tapered structure is used for the transition from strip waveguide to slot waveguide and constitutes the sensing absorption region, with the coupling efficiency that can reach more than 90%. When the optimal absorption length of the slot waveguide and SWGS waveguide is 1.02 cm and 0.33 cm, respectively, the maximum sensitivity can reach 6.66 × 10⁻⁵ (ppm⁻¹) and 2.60 × 10⁻⁵ (ppm⁻¹). Furthermore, taking the slot waveguide as an example, spiral and meander structures enable the long-distance sensing path to integrate into a small area. Full article

Although many PMSMs are used as the driving source for electric vehicle motor drive systems, there is still a gap compared with the power density index in the DOE roadmap. Considering that the motor occupies a large space in the motor drive system, it is of great significance for the system to increase the motor power density and thus reach the system power density index. This article starts with electrical machine basic design theory and finds the motor power density influence factors. Guided by the theory and considering motor driver influence, this article proposes a high power density motor for electric vehicle integrated motor drive system. The motor for the system is a five-phase interior permanent magnet synchronous motor (IPMSM) with a double-layer rotor structure and fractional slot distributed winding. Compared with Ver1.0 motor, Ver2.0 motor power density improves significantly. In order to prevent damage from excessive temperature, a temperature field solution model is established in this article to compare the cooling effect and pressure loss of the spiral, dial, and axial water jackets. The temperature is checked at motor main operating conditions using an optimal cooling structure. Finally, the power density of the designed Ver2.0 motor reaches 3.12 kW/kg in mass and 15.19 kW/L in volume. Full article

A high-efficiency plasmonic lens composed of a single Archimedes-spiral slot with a cross section of an asymmetric slot is proposed. By adding an auxiliary nanocavity under the primary spiral slot, unidirectional plasmonic waves can be efficiently transmitted in the inward direction and focused on a hot spot in the center. Due to the asymmetric slot, the finite-difference time-domain (FDTD) method is used to numerically optimize the geometric parameters of the single spiral slot, which can achieve high-intensity unidirectional inward focusing. The proposed structure can decrease background noises and prevent cross-talk of nearby components in optical networks, which significantly improves the integration level of nanophotonic circuits and devices. Full article

A novel compact tapered-slot-fed antenna (TSA) with anti-spiral shape and lumped resistors is presented for ultra-wideband (UWB) applications. Unique coplanar waveguide (CPW) to coplanar strip (CPS) feeding structure and exponential slot are designed to ensure the continuous current propagation and good impedance matching. With a pair of anti-spiral-shaped structure loadings at the end of the antenna, the radiation performance in lower operating band can be enhanced obviously. The typical resistor loading technique is applied to improve the time domain characteristics and expand the bandwidth. The fabricated prototype of this proposed antenna with a size of 53 × 63.5 mm² was measured to confirm simulated results. The proposed antenna has S11 less than −10 dB in the range of 1.2–9.8 GHz, and the group delay result is only 0.4 ns. These findings indicate the proposed antenna can be taken as a promising candidate in UWB communication field. Full article

We report a novel broadband slot-spiral antenna that can be integrated with high-electron-mobility transistor (HEMT) terahertz (THz) detectors. The effect of various antenna parameters on the transmission efficiency of the slot-spiral structure at 150–450 GHz is investigated systematically. The performances of the slot-spiral antenna and the spiral antenna both integrated with HEMTs are compared. The results show that the slot-spiral structure has a better transmission and miniaturization capability than the spiral structure. A formula for the responsivity is derived based on the transmission line principle and antenna theory, and results show that the detector responsivity is correlated with the antenna absorptivity. Additionally, guidelines for HEMT THz detector design are proposed. The results of this study indicate the excellent application prospects of the slot-spiral antenna in THz detection and imaging. Full article

A novel adjustable three-dimensional plasmonic Archimedes spiral lens (3D PASL) has been investigated and analyzed in detail by numerical simulations. The 3D PASL consists of a spiraling Archimedes helix slot that is engraved on the inner wall of a funnel-shaped gold film on a silicon dioxide substrate. When the incident light from the bottom of substrate is composed of left-hand circularly polarized (LCP) waves, the transmitted light field will converge completely to a focused point that floats in the hollow funnel. This light field will change into an optical vortex when the incident light is changed to right-hand circularly polarized (RCP) waves. The performance of our 3D PASL is discussed for particle trapping or rotation applications. In addition, the position of the optical focus or vortex can be adjusted by varying the height of the structure. Our 3D PASL is highly flexible for practical optical manipulation applications and overcomes the problem where the previous two-dimensional PASL could only manipulate particles on the surface. Full article
