Search Results (18)

Low Earth orbit (LEO) signal of opportunity (SOP) positioning relies on the accumulation of epochs obtained through prolonged observation periods. The contribution of an LEO satellite single epoch to positioning accuracy is influenced by multi-level characteristics that are challenging for traditional models. To address this limitation, we propose an Agent-Weighted Recursive Least Squares (RLS) Positioning Framework (AWR-PF). This framework employs an agent to comprehensively analyze individual epoch characteristics, assess their credibility, and convert them into adaptive weights for RLS iterations. We developed a novel Markov Decision Process (MDP) model to assist the agent in addressing the epoch weighting problem and trained the agent utilizing the Double Deep Q-Network (DDQN) algorithm on 107 h of Iridium signal data. Experimental validation on a separate 28 h Iridium signal test set through 97 positioning trials demonstrated that AWR-PF achieves superior average positioning accuracy compared to both standard RLS and randomly weighted RLS throughout nearly the entire iterative process. In a single positioning trial, AWR-PF improves positioning accuracy by up to 45.15% over standard RLS. To the best of our knowledge, this work represents the first instance where an AI algorithm is used as the core decision-maker in LEO SOP positioning, establishing a groundbreaking paradigm for future research. Full article

Signal-of-Opportunity (SOP) positioning based on Low-Earth-Orbit (LEO) constellations has gradually become a research hotspot. Due to their large quantity, wide spectral coverage, and strong signal power, LEO satellite SOP positioning exhibits robust anti-jamming capabilities. However, no in-depth studies have been conducted on their anti-jamming performance, particularly regarding the most common type of interference faced by ground receivers—Periodic Frequency Modulation (PFM) interference. Due to the significant differences in signal characteristics between LEO satellite downlink signals and those of Global Navigation Satellite Systems (GNSSs) based on Medium-Earth-Orbit (MEO) or Geostationary-Earth-Orbit (GEO) satellites, traditional interference suppression techniques cannot be directly applied. This paper proposes a Signal Adaptive Iterative Optimization Resampling (SAIOR) algorithm, which leverages the periodicity of PFM jamming signals and the characteristics of LEO constellation signals. The algorithm enhances the concentration of jamming energy by appropriately resampling the data, thereby reducing the overlap between LEO satellite signals and interference. This approach effectively minimizes the damage to the desired signal during anti-jamming processing. Simulation and experimental results demonstrate that, compared to traditional algorithms, this method can effectively eliminates single/multiple-component PFM interference, improve the interference suppression performance under the conditions of narrow bandwidth and high signal power, and holds a high application value in LEO satellite SOP positioning. Full article

This paper focuses on a solution of target self-positioning when a Global Navigation Satellite System (GNSS) is denied. It is composed of Inertial Navigation Systems (INS), Signals of Opportunities (SOPs), and a navigation prototype. One of the options for navigation via SOP (NAVSOP) is to utilize cellular signals, such as Long Time Evolution (LTE). When the prior information is insufficient, the location of the base station (BS) is obtained by collecting the demodulation of the downlink signal, and the synchronization signal is used for static time offset correction. In view of the large positioning error of the trilateral positioning method based on Received Signal Strength (RSS), a multi-station positioning optimization method is proposed by introducing the robust regression. Monte Carlo simulation experiments indicate that the method has improved the positioning failure and insufficient accuracy. Aiming at the influence of the state estimation errors on filtering results, the Second Order Mutual Difference (SOMD) method with the noise covariance R, which is independent of the existing Extended Kalman Filter (EKF) framework and combined with Redundant Measurement Noise Covariance Estimation (RMNCE), is applied to the model. The simulation results show that the average error of the robust model is 10.28 m, which is better than the EKF method. Finally, a vehicle test in constant speed has been carried out. The results show that the proposed model can realize self-positioning with limited BS location information, and the positioning accuracy can reach 11.68 m over a 283 m trajectory. Full article

To address the limitations of Global Navigation Satellite Systems (GNSSs), such as vulnerability to electromagnetic interference and weak ground signal power, signal of opportunity (SOP) provided by low Earth orbit (LEO) satellites can serve as a backup positioning method. By simulating a LEO constellation, the impact of satellite visibility, Doppler geometric dilution of precision (DGDOP), and positioning accuracy was explored. Considering positioning errors such as satellite clock drift rate, ionospheric delay rate, tropospheric delay rate, and Earth rotation effects, the instantaneous positioning performance with satellite orbital errors and satellite velocity errors of different magnitudes was simulated. The results show that satellite visibility and DGDOP are negatively correlated. In a typical atmospheric environment with orbital errors of 10 m and satellite velocity errors of 0.1 m/s, positioning accuracy within 30 m can be achieved. This confirms that Doppler-based positioning with LEO satellites can be used as a backup method for GNSSs. Full article

The utilization of low Earth orbit (LEO) satellites’ signals of opportunity (SOPs) for absolute positioning and navigation in global navigation satellite system (GNSS)-denied environments has emerged as a significant area of research. Among various methodologies, tightly integrated Doppler/inertial navigation system (INS) frameworks present a promising solution for achieving real-time LEO-SOP-based positioning in dynamic scenarios. However, existing integration schemes generally overlook the key characteristics of LEO opportunity signals, including the limited number of visible satellites and the random nature of signal broadcasts. These factors exacerbate the weak observability inherent in LEO-SoOP Doppler/INS positioning, resulting in difficulty in obtaining reliable solutions and degraded positioning accuracy. To address these issues, this paper proposes a novel LEO-SOP Doppler/INS tight integration method that incorporates trending information to alleviate the problem of weak observability. The method leverages a parallel filtering structure combining extended Kalman filter (EKF) and Rauch–Tung–Striebel (RTS) smoothing, extracting trend information from the quasi-real-time high-precision RTS filtering results to optimize the EKF positioning solution for the current epoch. This approach effectively avoids the overfitting problem commonly associated with directly using batch data to estimate the current epoch state. The experimental results validate the improved positioning accuracy and robustness of the proposed method. Full article

Experts and scholars from various nations have proposed studying low Earth orbit (LEO) satellite signals as the space-based signals of opportunity (SOPs) for navigation and positioning. This method serves as a robust alternative in environments where global navigation satellite systems (GNSS) are unavailable or compromised, providing users with high-precision, anti-interference, secure, and dependable backup navigation solutions. The rapid evolution of LEO communication constellations has spurred the development of SOPs positioning technology using LEO satellites. However, this has also led to a substantial increase in the number of LEO satellites, thereby reintroducing the traditional challenge of satellite selection. This research thoroughly examines three critical factors affecting positioning accuracy: satellite observable time, satellite elevation, and position dilution of precision (PDOP). It introduces a strategic approach for selecting satellites in LEO SOPs navigation and positioning. Simulation outcomes confirm that this satellite selection strategy effectively identifies visible satellites, ensuring precise positioning through LEO SOPs. Full article

Positioning based on Low Earth Orbit (LEO) satellite Signals of Opportunity (SOP) often relies on Doppler observations. Therefore, the accuracy of Doppler frequency measurements significantly impacts the positioning performance. Traditional frequency estimation methods for ORBCOMM satellite signals are typically implemented in the frequency domain and neglect the impact of the “frequency chirp” effect on measurement accuracy, which leads to low computational efficiency, poor noise resistance, and limited estimation accuracy. To address this issue, a high-precision frequency estimation method combining a “coarse and fine” process is proposed. In the coarse estimation process, ephemeris prior information is combined with matched filtering to effectively separate the Doppler rate, thereby mitigating the spectral broadening caused by the Doppler rate. In the fine estimation process, ORBCOMM signal characteristics are fully exploited. Single-sideband filtering is applied to improve noise resistance, followed by precise frequency discrimination of the delayed signal. Experimental results demonstrate that the proposed method outperforms the state-of-the-art “FFT + MLE” approach, achieving a frequency measurement accuracy on the order of 0.01 Hz while requiring fewer computational resources. Furthermore, this method improves estimation performance by approximately 12 dB without compromising frequency measurement accuracy. Full article

DOA (Direction of Arrival), as an important observation parameter for accurately locating the Signals of Opportunity (SOP), is vital for navigation in GNSS-challenged environments and can be effectively obtained through sparse arrays. In practical application, array perturbations affect the estimation accuracy and stability of DOA, thereby adversely affecting the positioning performance of SOP. Against this backdrop, we propose an approach to reconstruct non-uniform arrays under perturbation conditions, aiming to improve the robustness of DOA estimation in sparse arrays. Firstly, we theoretically derive the mathematical expressions of the Cramér–Rao Bound (CRB) and Spatial Correlation Coefficient (SCC) for the uniform linear array (ULA) with perturbation. Then, we minimize CRB as the objective function to mitigate the adverse effects of array perturbations on DOA estimation, and use SCC as a constraint to suppress sidelobes. By doing this, the non-uniform array reconstruction model is formulated as a high-order 0–1 optimization problem. To effectively solve this nonconvex model, we propose a polynomial-time algorithm, which can converge to the optimal approximate solution of the original model. Finally, through a series of simulation experiments utilizing frequency modulation (FM) signal as an example, the exceptional performance of this method in array reconstruction has been thoroughly validated. Experimental data show that the reconstructed non-uniform array excels in DOA estimation accuracy compared to other sparse arrays, making it particularly suitable for estimating the direction of terrestrial SOP in perturbed environments. Full article

Low-Earth-Orbit (LEO) satellite Signal-of-Opportunity (SOP) positioning technology has gradually matured to meet the accuracy requirements for unmanned aerial vehicle (UAV) positioning in daily scenarios. Advancements in miniaturization technology for positioning terminals have also made this technology’s application to UAV positioning crucial for UAV development. However, in the increasingly complex electromagnetic environment, there remains a significant risk of degradation in positioning performance for UAVs in LEO satellite SOP positioning due to unintentional or malicious jamming. Furthermore, there is a lack of in-depth research from scholars both domestically and internationally on the anti-jamming capabilities of LEO satellite SOP positioning technology. Due to significant differences in the downlink signal characteristics between LEO satellites and Global Navigation Satellite System (GNSS) signals based on Medium Earth Orbit (MEO) or Geostationary Earth Orbit (GEO) satellites, the anti-jamming research results of traditional satellite navigation systems cannot be directly applied. This study addresses the narrow bandwidth and high signal-to-noise ratio (SNR) characteristics of signals from LEO satellite constellations. We propose a Consecutive Iteration based on Signal Cancellation (SCCI) algorithm, which significantly reduces errors during the model fitting process. Additionally, an adaptive variable convergence factor was designed to simultaneously balance convergence speed and steady-state error during the iteration process. Compared to traditional algorithms, simulation and experimental results demonstrated that the proposed algorithm enhances the effectiveness of jamming threshold settings under narrow bandwidth and high-power conditions. In the context of LEO satellite jamming scenarios, it improves the frequency-domain anti-jamming performance significantly and holds high application value for drone positioning. Full article

Space-based opportunistic positioning is a crucial component of resilient positioning, navigation, and timing (PNT) systems, and it requires the acquisition of orbit information for non-cooperative low Earth orbit (LEO) satellites. Traditional methods for orbit determination (OD) of non-cooperative LEO satellites have difficulty in achieving a balance between reliability, hardware costs, and availability duration. To address these challenges, this study proposes a framework for single-station orbit determination of non-cooperative LEO satellites. By utilizing signals of opportunity (SOPs) captured by a single ground station, the system performs initial orbit determination (IOD), precise orbit determination (POD), and orbit prediction (OP), enabling the long-term determination of satellite positions and velocities. Under the proposed framework, the reliability and real-time performance are dependent on the initial orbit determination and the orbit calculation based on the dynamical model. To achieve initial orbit determination, a three-step algorithm is designed. (1) An improved search method is employed to estimate a coarse orbit using single-pass Doppler measurements. (2) Data association is conducted to obtain multi-pass Doppler observations. (3) The least squares (LS) is implemented to determine the initial orbit using the associated multi-pass Doppler measurements and the coarse orbit. Additionally, to enhance computational efficiency, two fast orbit calculation algorithms are devised. These algorithms leverage the numerical stability of the Runge–Kutta integrator to reduce computations and exploit the strong correlation among nearby time intervals of orbits with small eccentricities to minimize redundant calculations, thereby achieving orbit calculation efficiently. Finally, through positioning experiments, the determined orbits are demonstrated to have accuracy comparable to that of two-line elements (TLE) updated by the North American Aerospace Defense Command (NORAD). Full article

The purpose of this study was to evaluate the stability and therefore suitability of available fifth generation (5G) and long-term evolution (LTE) signals for positioning navigation and timing (PNT) purposes with particular focus on answering questions around the time-scale-dependent stability of these sources, which, to our knowledge, has not been addressed in the context of the numerous publications within the PNT community to date. The methodology used directly measured the over-the-air signal phase stability to one or more of the cellular signal sources that were visible from the lab environment simultaneously while using a local atomic clock or differential measurements to isolate the time stability of the observable cellular downlink signals. This approach was taken since it does not require subscription or association with the networks under test. Instead, it exploits a ‘signal of opportunity’ (SoP) approach to signal use for PNT purposes. The somewhat surprising result is that the time domain instability of the sources was highly variable, dependent on the implementation choices of the operator, and that the stability of even the modernized towers was generally best at interrogation intervals of approximately 0.01 s, which indicates that the existing exploitation of these signals within the PNT community has substantial room for improvement through simple changes to the selected update rate used. Full article

The rapid growth in the technological advancements of the smartphone industry has classified contemporary smartphones as a low-cost and high quality indoor positioning tools requiring no additional infrastructure or equipment. In recent years, the fine time measurement (FTM) protocol, achieved through the Wi-Fi round trip time (RTT) observable, available in the most recent models, has gained the interest of many research teams worldwide, especially those concerned with indoor localization problems. However, as the Wi-Fi RTT technology is still new, there is a limited number of studies addressing its potential and limitations relative to the positioning problem. This paper presents an investigation and performance evaluation of Wi-Fi RTT capability with a focus on range quality assessment. A set of experimental tests was carried out, considering 1D and 2D space, operating different smartphone devices at various operational settings and observation conditions. Furthermore, in order to address device-dependent and other type of biases in the raw ranges, alternative correction models were developed and tested. The obtained results indicate that Wi-Fi RTT is a promising technology capable of achieving a meter-level accuracy for ranges both in line-of-sight (LOS) and non-line-of-sight (NLOS) conditions, subject to suitable corrections identification and adaptation. From 1D ranging tests, an average mean absolute error (MAE) of 0.85 m and 1.24 m is achieved, for LOS and NLOS conditions, respectively, for 80% of the validation sample data. In 2D-space ranging tests, an average root mean square error (RMSE) of 1.1m is accomplished across the different devices. Furthermore, the analysis has shown that the selection of the bandwidth and the initiator–responder pair are crucial for the correction model selection, whilst knowledge of the type of operating environment (LOS and/or NLOS) can further contribute to Wi-Fi RTT range performance enhancement. Full article

A variety of positioning systems have emerged for indoor localization which are based on several system strategies, location methods, and technologies while using different signals, such as radio frequency (RF) signals. Demands regarding positioning in terms of performance, robustness, availability and positioning accuracies are increasing. The overall goal of indoor positioning is to provide GNSS-like functionality in places where GNSS signals are not available. Analysis of the state-of-the-art indicates that although a lot of work is being done to combine both the outdoor and indoor positioning systems, there are still many problems and challenges to be solved. Most people moving on the city streets and interiors of public facilities have a smartphone, and most professionals working in public facilities or construction sites are equipped with tablets or smartphone devices. If users already have the necessary equipment, they should be provided with further functionalities that will help them in day-to-day life and work. In this review study, user requirements and the state-of-the-art in system development for smartphone localization are discussed. In particular, localization with current and upcoming ‘signals-of-opportunity’ (SoP) for use in mobile devices is the main focus of this paper. Full article

The traditional signal of opportunity (SOP) positioning system is equipped with dedicated receivers for each type of signal to ensure continuous signal perception. However, it causes a low equipment resources utilization and energy waste. With increasing SOP types, problems become more serious. This paper proposes a new signal perception unit for SOP positioning systems. By extracting the perception function from the positioning system and operating independently, the system can flexibly schedule resources and reduce waste based on the perception results. Through time-frequency joint representation, time-frequency image can be obtained which provides more information for signal recognition, and is difficult for traditional single time/frequency-domain analysis. We also designed a convolutional neural network (CNN) for signal recognition and a negative learning method to correct the overfitting to noisy data. Finally, a prototype system was built using USRP and LabVIEW for a 2.4 GHz frequency band test. The results show that the system can effectively identify Wi-Fi, Bluetooth, and ZigBee signals at the same time, and verified the effectiveness of the proposed signal perception architecture. It can be further promoted to realize SOP perception in almost full frequency domain, and improve the integration and resource utilization efficiency of the SOP positioning system. Full article

With the emergence of numerous low Earth orbit (LEO) satellite constellations such as Iridium-Next, Globalstar, Orbcomm, Starlink, and OneWeb, the idea of considering their downlink signals as a source of pseudorange and pseudorange rate measurements has become incredibly attractive to the community. LEO satellites could be a reliable alternative for environments or situations in which the global navigation satellite system (GNSS) is blocked or inaccessible. In this article, we present a novel in-flight alignment method for a strapdown inertial navigation system (SINS) using Doppler shift measurements obtained from single or multi-constellation LEO satellites and a rotation technique applied on the inertial measurement unit (IMU). Firstly, a regular Doppler positioning algorithm based on the extended Kalman filter (EKF) calculates states of the receiver. This system is considered as a slave block. In parallel, a master INS estimates the position, velocity, and attitude of the system. Secondly, the linearized state space model of the INS errors is formulated. The alignment model accounts for obtaining the errors of the INS by a Kalman filter. The measurements of this system are the difference in the outputs from the master and slave systems. Thirdly, as the observability rank of the system is not sufficient for estimating all the parameters, a discrete dual-axis IMU rotation sequence was simulated. By increasing the observability rank of the system, all the states were estimated. Two experiments were performed with different overhead satellites and numbers of constellations: one for a ground vehicle and another for a small flight vehicle. Finally, the results showed a significant improvement compared to stand-alone INS and the regular Doppler positioning method. The error of the ground test reached around 26 m. This error for the flight test was demonstrated in different time intervals from the starting point of the trajectory. The proposed method showed a 180% accuracy improvement compared to the Doppler positioning method for up to 4.5 min after blocking the GNSS. Full article
