The spaceborne-airborne bistatic radar (SABR) system employs a spaceborne transmitter and an airborne receiver, offering significant advantages, such as wide coverage, outstanding anti-stealth capabilities, and notable resistance to jamming. However, SABR operates in a downward-looking configuration, and due to the separation of the transmitter and receiver, non-side-looking array reception, and the effects of Earth’s rotation, clutter exhibits both spatial-temporal coupling and distance dependence. These factors cause substantial expansion in spatial and temporal frequency domains, leading to severe degradation in radar detection performance for moving targets. This paper establishes an SABR clutter signal model that applies to arbitrary geometric configurations to respond to these challenges. The paper uses this model to analyze the non-side-looking clutter characteristics in a geostationary spaceborne-airborne bistatic radar configuration. Furthermore, the paper investigates the impact of various observation areas and geometric configurations on detection performance, using SCNR loss as the performance index. Finally, this paper gives suggestions on the transceiver’s geometric configuration and the observation area selection. Full article

For ultra-high-resolution (UHR) squint spotlight airborne synthetic aperture radar (SAR), the severe range-azimuth coupling caused by squint mode and the spatial and frequency dependence of the motion error brought by ultra-wide bandwidth both make it difficult to obtain satisfactory imaging results. Although some autofocus methods for squint airborne SAR have been presented in the published literature, their practical applicability in UHR situations remains limited. In this article, a new 2D wavenumber domain autofocus method combined with the Omega-K algorithm dedicated to UHR squint spotlight airborne SAR is proposed. First, we analyze the dependence of range envelope shift error (RESE) and range defocus on the squint angle and then propose a new spectrum modification strategy, after which the spectrum transforms into a quasi-side-looking one. The accuracy of estimation and compensation can be improved significantly in this way. Then, the 2D phase error can be calculated with the 1D estimated error by the mapping relationship, and after that the 2D compensation is performed in the wavenumber domain. Furthermore, the image-blocking technique and range-dependent motion error compensation method are embedded to accommodate the spatial-variant motion error for UHR cases. Simulations are carried out to verify the effectiveness of the proposed method. Full article

Non-side-looking airborne radar provides important applications on account of its all-round multi-angle airspace coverage. However, it suffers clutter range dependence that makes the samples fail to satisfy the condition of being independent and identically distributed (IID), and it severely degrades traditional approaches to clutter suppression and target detection. In this paper, a novel reweighted extreme learning machine (ELM)-based clutter suppression and range compensation algorithm is proposed for non-side-looking airborne radar. The proposed method involves first designing the pre-processing stage, the special reweighted complex-valued activation function containing an unknown range compensation matrix, and two new objective outputs for constructing an initial reweighted ELM-based network with its training. Then, two other objective outputs, a new loss function, and a reverse feedback framework driven by the specifically designed objectives are proposed for the unknown range compensation matrix. Finally, aiming to estimate and reconstruct the unknown compensation matrix, special processes of the complex-valued structures and the theoretical derivations are designed and analyzed in detail. Consequently, with the updated and compensated samples, further processing including space–time adaptive processing (STAP) can be performed for clutter suppression and target detection. Compared with the classic relevant methods, the proposed algorithm achieves significantly superior performance with reasonable computation time. It provides an obviously higher detection probability and better improvement factor (IF). The simulation results verify that the proposed algorithm is effective and has many advantages. Full article

The high-squint airborne Synthetic Aperture Radar (SAR) has the ability to detect the target area flexibly, and the detection swath is significantly increased compared with the side-looking SAR system. Therefore, it is of great significance to carry out research on high-precision imaging methods for high-squint airborne SAR. However, the high-squint SAR echoes have large Range Cell Migration (RCM), resulting in severe range–azimuth coupling and strong spatial variation. In this paper, a Modified Range Doppler Algorithm (MRDA) is proposed to cope with these effects introduced by the significant RCM in high-squint airborne SAR imaging. The bulk compensation preprocessing is first adopted to remove the considerable RCM and severe cross-coupling in a two-dimensional frequency domain. Then, Non-Linear Chirp Scaling (NLCS) in the range direction is utilized to equalize the range-variant chirp rate caused by the residual RCM and coupling and, therefore, the consistent range phase compensation can be fulfilled in range frequency domain. The modified correlation processing is executed to compensate the residual Doppler phase modulation, the residual RCM and the range-variant cubic phase modulation, which guarantees the characteristics of high efficiency and high precision. The simulations have demonstrated that the MRDA can focus the SAR echoes with large squint angles more effectively than the algorithms based on the Linear Range Walk Correction (LRWC) method. Full article

When forming the radar situation of a terrain, in order to increase its information content and to extract useful information, multi-position spatially distributed systems for integrating multi-angle radar data established by small-sized UAV-based airborne radars are used. In this case, each radar station belonging to a multi-position system as a probing signal must have its own unique marked signal. Such a setup will allow the signals reflected from ground objects and zones to be “attached” to specific receiving-transmitting positions of the multi-position system. This requirement results from the fact that each transceiver position emits one probing signal, and then receives all the echo signals reflected from the underlying surface and previously emitted by other radar devices of the multi-position system. Such a setup of multi-position systems requires the researcher to look for and investigate specialized systems of marked code structures used to modulate the probing signals in order to identify them in a joint radar channel. Thus, the problem at hand is how to look for and investigate novel marked code structures used to generate a system of probing signals, the use of which will allow it to be “attached” to a specific receiving-transmitting position of a multi-position onboard system and to identify them in a joint radar channel in the course of the remote sensing of the underlying surface. The purpose of this work is to conduct a study on the subject of the squeak and choice of a system of code structures that have a low level of side lobes of autocorrelation functions and uniformly distributed values of the levels of the cross-correlation function. To achieve this goal, the relevance of the study is substantiated in the introduction. The second section analyzes the level of side lobes for classical and modified Barker codes with an asymmetric alphabet. On the basis of this analysis, it was concluded that it is expedient to apply this approach for codes longer than Barker codes. Therefore, in the third section, the features of the generation of M-sequences are considered. The fourth section presents a technique for searching for new marked code structures, taking into account their mutual correlation properties for modifying M-sequences in order to implement multi-positional systems. The fifth section presents computer experiments on the search for marked code structures based on the modifications of M-sequences and presents the numerical characteristics of the correlation properties of the considered marked codes. And finally, in the sixth section, the final conclusions of the study are presented and recommendations are given for their further practical application. The practical significance of this study lies in the fact that the proposed new marked code structures are necessary for the synthesis of probing signals in the implementation of spatially distributed systems that function for the high-probability detection and high-precision determination of the coordinates of physical objects and are also necessary for the formation of radar images in a multi-position mode. Full article

Aimingat non-side-looking airborne radar, we propose a novel unsupervised affinity propagation (AP) clustering radar detection algorithm to suppress clutter and detect targets. The proposed method first uses selected power points as well as space-time adaptive processing (STAP) weight vector, and designs matrix-transformation-based weighted input data, with which the first unsupervised weighted AP clustering is proposed by means of their similarity matrix, responsibility values and availability values. Then, new reconstructed weighted power inputs are designed, and the second weighted AP clustering is proposed. Finally, with their cluster results, a detection-discriminant criterion is designed for the judgment of target detection, and simultaneously, the clutter is suppressed. Compared with the conventional and important STAP, ADC and JDL algorithms, and several SO-based, GO-based and OS-based CFAR algorithms, the proposed unsupervised algorithm achieves much higher probability of detection and provides distinctly superior target-detection performance. With reasonable computation time, it can better conquer the range dependence in characteristic of clutter and better process non-independent identically distributed (non-IID) samples of non-side-looking radar. Sufficient simulations are performed, and they demonstrate that the proposed unsupervised algorithm is preferable and advantageous. Full article

Clutter suppression is a key problem for airborne radar, and space-time adaptive processing (STAP) is a core technology for clutter suppression and moving target detection. However, in practical applications, the non-uniform time-varying environments including clutter range dependence for non-side-looking radar lead to the training samples being unable to satisfy the sample requirements of STAP that they should be independent identical distributed (IID) and that their number should be greater than twice the system’s degree of freedom (DOF). The lack of sufficient IID training samples causes difficulty in the convergence of STAP and further results in a serious degeneration of performance. To overcome this problem, this paper proposes a novel autoencoder neural network for clutter suppression with a unique matrix designed to be decoded and encoded. The main challenges are improving the accuracy of the estimation of the clutter-plus-noise covariance matrix (CNCM) for STAP convergence, designing the form of the data input to the network, and making the network successfully explored to the improvement of CNCM. For these challenges, the main proposed solutions include designing a unique matrix with a certain dimension and a series of covariance data selections and matrix transformations. Consequently, the proposed method compresses and retains the characteristics of the covariances, and abandons the deviations caused by the non-uniformity and the deficiency of training samples. Specifically, the proposed method firstly develops a unique matrix whose dimension is less than half of the DOF, meanwhile, it is based on a processing of the selected clutter-plus-noise covariances. Then, an autoencoder neural network with $l_2$ regularization and the sparsity regularization is proposed for the unique matrix to be decoded and encoded. The training of the proposed autoencoder can be achieved by reducing the total loss function with the gradient descent iterations. Finally, an inverted processing for the autoencoder output is designed for the reconstruct ion of the clutter-plus-noise covariances. Simulation results are used to verify the effectiveness and advantages of the proposed method. It performs obviously superior clutter suppression for both side-looking and non-side-looking radars with strong clutter, and can deal with the insufficient and the non-uniform training samples. For these conditions, the proposed method provides the relatively narrowest and deepest IF notch. Furthermore, on average it improves the improvement factor (IF) by 10 dB more than the ADC, DW, JDL, and original STAP methods. Full article

Building reconstruction using high-resolution tomographic synthetic aperture radar (TomoSAR) point clouds has been very attractive in numerous applications, such as urban planning and dynamic city modeling. However, for side-looking TomoSAR, it is a challenge to reconstruct the obscured backs of buildings using traditional single-bounce scattering-based methods. It comes to our attention that the higher-order scattering points in airborne array TomoSAR point clouds may provide rich information on the backs of buildings. In this paper, the fourfold bounce (FB) scattering model of combined buildings in airborne array TomoSAR is derived, which not only explains the cause of FB scattering but also gives the distribution pattern of FB scattering points. Furthermore, a novel FB scattering-based method for the reconstruction of building backs is proposed. First, a two-step geometric constraint is used to detect the candidate FB scattering points. Subsequently, the FB scattering points are further detected by seed point selection and density estimation in the radar coordinate system. Finally, the backs of buildings can be reconstructed using the footprint inverted from the FB scattering points and the height information of the illuminated facades. To verify the FB scattering model and the effectiveness of the proposed method, the results from the simulated point clouds and the real airborne array TomoSAR point clouds are presented. Compared with the traditional roof point-based methods, the outstanding advantage of the proposed method is that it allows for the high-precision reconstruction of building backs, even in the case of poor roof points. Moreover, this paper may provide a novel perspective for the three-dimensional (3D) reconstruction of dense urban areas. Full article

We present a method to detect maritime oil spills from Side-Looking Airborne Radar (SLAR) sensors mounted on aircraft in order to enable a quick response of emergency services when an oil spill occurs. The proposed approach introduces a new type of neural architecture named Convolutional Long Short Term Memory Selectional AutoEncoders (CMSAE) which allows the simultaneous segmentation of multiple classes such as coast, oil spill and ships. Unlike previous works using full SLAR images, in this work only a few scanlines from the beam-scanning of radar are needed to perform the detection. The main objective is to develop a method that performs accurate segmentation using only the current and previous sensor information, in order to return a real-time response during the flight. The proposed architecture uses a series of CMSAE networks to process in parallel each of the objectives defined as different classes. The output of these networks are given to a machine learning classifier to perform the final detection. Results show that the proposed approach can reliably detect oil spills and other maritime objects in SLAR sequences, outperforming the accuracy of previous state-of-the-art methods and with a response time of only 0.76 s. Full article

Near space is the key to integrating “sky” and “space” into the future. A synthetic aperture radar (SAR) that works in this area would initiate a technological revolution for remote sensing applications. This study mainly focused on ground moving target imaging (GMTIm) for a near-space hypersonic vehicle-borne SAR (NS-HSV-SAR) with squint angle. The range history, parameter coupling, and Doppler ambiguity of the squint-looking NS-HSV-SAR are more complicated than traditional side-looking airborne or space-borne SARs. Thus, a precise range model is presented on the basis of phase error analyses. Then, all potential distributions of echo’s azimuth spectrum are derived, and a GMTIm method is proposed on the basis of a detailed analysis of the echo characteristics. The proposed method consists of three steps. Firstly, a prior information-based pre-processing function was created to decrease the Doppler ambiguity and range migration effects. Secondly, a blur matched keystone transform was developed to correct the residual range walk migration. Thirdly, a time-saving chirp Fourier transform was investigated for azimuth focusing. Implementation considerations, including the curvilinear trajectory of the NS-HSV-SAR, multiple moving target imaging, and applicability and limitation of the method, are discussed. Finally, simulation results are presented to validate the effectiveness of the proposed method. Full article

In this work, we use deep neural autoencoders to segment oil spills from Side-Looking Airborne Radar (SLAR) imagery. Synthetic Aperture Radar (SAR) has been much exploited for ocean surface monitoring, especially for oil pollution detection, but few approaches in the literature use SLAR. Our sensor consists of two SAR antennas mounted on an aircraft, enabling a quicker response than satellite sensors for emergency services when an oil spill occurs. Experiments on TERMA radar were carried out to detect oil spills on Spanish coasts using deep selectional autoencoders and RED-nets (very deep Residual Encoder-Decoder Networks). Different configurations of these networks were evaluated and the best topology significantly outperformed previous approaches, correctly detecting 100% of the spills and obtaining an $F_1$ score of 93.01% at the pixel level. The proposed autoencoders perform accurately in SLAR imagery that has artifacts and noise caused by the aircraft maneuvers, in different weather conditions and with the presence of look-alikes due to natural phenomena such as shoals of fish and seaweed. Full article

This work presents a method for oil-spill detection on Spanish coasts using aerial Side-Looking Airborne Radar (SLAR) images, which are captured using a Terma sensor. The proposed method uses grayscale image processing techniques to identify the dark spots that represent oil slicks on the sea. The approach is based on two steps. First, the noise regions caused by aircraft movements are detected and labeled in order to avoid the detection of false-positives. Second, a segmentation process guided by a map saliency technique is used to detect image regions that represent oil slicks. The results show that the proposed method is an improvement on the previous approaches for this task when employing SLAR images. Full article

In this study, the effects of non-sidelooking airborne radar clutter dispersion on space-time adaptive processing (STAP) is considered, and an efficient adaptive angle-Doppler compensation (EAADC) approach is proposed to improve the clutter suppression performance. In order to reduce the computational complexity, the reduced-dimension sparse reconstruction (RDSR) technique is introduced into the angle-Doppler spectrum estimation to extract the required parameters for compensating the clutter spectral center misalignment. Simulation results to demonstrate the effectiveness of the proposed algorithm are presented. Full article

Autonomous navigation airborne forward-looking synthetic aperture radar (SAR) observes the anterior inferior wide area with a short cross-track dimensional linear array as azimuth aperture. This is an application scenario that is drastically different from that of side-looking space-borne or air-borne SAR systems, which acquires azimuth synthetic aperture with along-track dimension platform movement. High precision imaging with a combination of pseudo-polar formatting and overlapped sub-aperture algorithm for autonomous navigation airborne forward-looking SAR imaging is presented. With the suggested imaging method, range dimensional imaging is operated with wide band signal compression. Then, 2D pseudo-polar formatting is operated. In the following, azimuth synthetic aperture is divided into several overlapped sub-apertures. Intra sub-aperture IFFT (Inverse Fast Fourier Transform), wave front curvature phase error compensation, and inter sub-aperture IFFT are operated sequentially to finish azimuth high precision imaging. The main advantage of the proposed algorithm is its extremely high precision and low memory cost. The effectiveness and performance of the proposed algorithm are demonstrated with outdoor GBSAR (Ground Based Synthetic Aperture Radar) experiments, which possesses the same imaging geometry as the airborne forward-looking SAR (short azimuth aperture, wide azimuth swath). The profile response of the trihedral angle reflectors, placed in the imaging scene, reconstructed with the proposed imaging algorithm and back projection algorithm are compared and analyzed. Full article
