Search Results (21)

The screw piles used in permafrost regions represent a new type of pile, and their vertical bearing characteristics play a crucial role in ensuring the normal operation of engineering buildings. This study establishes a numerical calculation model to simulate the interaction between screw piles and soil in permafrost regions and verifies the numerical simulation results through model tests. The bearing mechanism of screw piles in permafrost areas is studied and compared with common, bored, cast-in-place piles widely used. Finally, a method for estimating the bearing capacity of screw piles in permafrost regions is proposed. The research indicates that approximately 90% of the bearing capacity of screw piles in permafrost regions is derived from the mechanical interaction between the concrete pile’s side and the permafrost soil. The shear strength of the permafrost is the primary determinant of the pile foundation’s bearing capacity, while the seasonally active layer has a minimal impact on its bearing capacity, resulting in a stable year-round performance. In permafrost regions, the equivalent friction resistance of screw piles is significantly greater than that of the conventional cast-in-place piles. When the pile reaches its ultimate bearing capacity, the plastic zone on the pile’s side becomes connected, and shear failure occurs in the surrounding soil. The design value of the bearing capacity of a single pile can be effectively estimated in engineering practice by improving the formula of the code for calculating the vertical bearing capacity. Full article

The use of screw piles has grown rapidly, yet their varied configurations and behavior in different soils remain key research areas. This study examines the performance of Toe-wing (Tsubasa) and Spiral screw piles with similar tip areas under similar ground conditions, focusing on how the helix position (W_p) and tip embedment depth (E_d) affect the ultimate pile capacity. In the case of a fixed helix/toe-wing position with increasing pile tip depth, Spiral screw piles exhibited higher load-carrying resistance than toe-wing piles at relative densities of 55%, 80%, and 90% fine sand. Moreover, load-carrying resistance increased as the position of the helix/toe-wing increased (W_p > 0). For a fixed pile tip depth (E_d) and varying helix/toe-wing positions, spiral screw piles showed higher resistance than toe-wing piles when W_p < 90 mm. Moreover, the resistance decreased as the helix moved away (W_p/D_h > 0), and the pile tip acted independently when W_p/D_h > 1.38. Whereas, for toe-wing piles, ultimate pile capacity increased as the toe-wing moved away from the tip up to W_p/D_h = 2.15, then decreased to reflect the independent behavior of the toe-wing and pile tip. Empirical equations are presented to convert installation effort and ultimate capacity from one type to another. Full article

To ensure the connection performance of precast concrete square piles, a screw clamping and welding joint connection is applied to the solid square piles. By conducting full-scale bending performance tests on six solid square pile specimens with cross-sectional side lengths of 300, 450, and 600 mm, including pile bodies, screw clamping joints, screw clamping, and welding joints, the bending load-bearing capacity, deformation capacity, and failure characteristics of the screw clamping–welding joint connection are compared and studied. The results show that the bending failure mode of the pile body specimens is shear failure in the flexural shear section and concrete crushing in the compression zone of the pure bending section; the bending failure mode of the screw clamping joint specimens are the pull-out of steel bar heads at the joint end plate; the bending failure mode of the screw clamping and welding joint specimens are concrete crushing in the compression zone of the pure bending section, steel bar breakage in the tension zone of the flexural shear section, and pull-out of steel bar heads at the end plate. It is worth noting that no significant damage occurred at the joints. The cracks in the pure bending section of the bending specimens mainly develop vertically and are evenly distributed, while some cracks in the flexural shear section develop obliquely towards the loading point, with branching. Compared to the pile body specimens, the cracking moment of the joint specimens is up to 16% higher, the ultimate moment is within 15% lower, and the maximum mid-span deflection is within 25% lower, indicating that the provision of anchorage reinforcement can increase the stiffness and cracking moment of the specimens. Full article

The screw-core mixing pile, which enhances traditional smooth-surface rigid piles by introducing a threaded surface, has been rapidly applied in China. Indoor model testing and numerical simulation techniques are used to perform static load tests on single piles to analyze the load–settlement relationship between the new screw-core mixing pile and the traditional circular-core mixing pile. The study examines the axial force distribution between the pile core and the mixing pile shell and establishes a bearing capacity model for screw-core mixing piles. Additionally, model piles with six different thread height ratios (w/d, where w is the thread width and d is the internal diameter of the screw-core) are developed using finite element simulation software to analyze the effect of thread height ratio on the bearing capacity of screw-core mixing piles. The influence of the height ratio on the bearing capacity of screw-core mixing piles is discussed in detail. The results indicate the following: (1) Due to differences in the pile core structure, the bearing capacity of the screw-core mixing pile is 1.44 times greater than that of the circular-core mixing pile. (2) When the vertical load is small, both the pile core and the mixing pile shell share the load; however, as the vertical load increases, the axial force gradually concentrates in the pile core, with the screw core showing a higher load-bearing capacity than the circular-core. (3) Under vertical load, the settlement of the screw-core mixing pile decreases stepwise from the top of the pile down to the surrounding area, demonstrating that the screw-core is more effective than the circular core. (4) The increase in thread height ratio significantly enhances the bearing capacity of the screw-core mixing pile. However, considering material limitations and engineering costs, the optimal thread height ratio should be determined based on actual bearing capacity requirements and soil conditions. Full article

Due to the advantages of high bearing capacity, small settlement of pile body, and high material utilization rate, rotary drilling thread special-shaped pile (RDTSSP) has been applied in pile foundation engineering at home and abroad. Through the field static load test, the bearing characteristics of the single pile of the rotary drilling screw pile are tested and analyzed. Based on the field-measured data, the stress characteristics of the rotary drilling screw pile are analyzed by FLAC3D6.0 finite difference software, and the pile characteristics affecting the vertical bearing capacity of the rotary drilling screw-shaped pile are studied. The impact of various pile factors, including length, diameter, and the ratio of pile body to screw modulus, as well as the presence of an enlarged bottom, the elastic modulus of the pile, and the ratio of the pile body to soil elastic modulus, on the load-bearing capacity of rotary drilling thread special-shaped pile (RDTSSP) is examined. The results show that with the increase in pile length, the bearing capacity of the screw-shaped pile increases gradually, but when it increases to a certain value, the increased bearing capacity per unit volume decreases gradually. The increase in pile diameter will lead to a decrease in bearing capacity per unit volume, so the smaller pile diameter should be selected in the design to make full use of the material properties. The bottom expansion has little effect on the bearing capacity, but with the increase in the inner diameter of the bottom expansion, the bearing capacity increases gradually, while the bearing capacity per unit volume decreases and the material utilization rate decreases. Enhancing the modulus of a pile modestly boosts its load-bearing capacity, whereas augmenting the elastic modulus ratio between the pile and the surrounding soil substantially amplifies this capacity. The innovation of this study is to propose a new type of rotary drilling thread-shaped pile, which has significant economic and social benefits in engineering applications. Full article

Screw-groove piles, a new type of precast pile, are economically and environmentally friendly and improve the load-bearing performance of piles through a unique screw-groove structure. To reveal the load-transfer characteristics and bearing mechanism of the screw-groove pile, the axial force, load–settlement curve, skin friction, bearing capacity, and response characteristics of the foundation for piles under vertical loading were analyzed. Furthermore, a parameter analysis of the ultimate bearing capacity and material utilization of screw-groove piles was performed using the finite element method. The results demonstrate that the screw-groove pile had an ultimate bearing capacity 1.85 times higher than that of the circular pile, and its material utilization rate was 2.85 times higher. The screw-groove surface end resistance and pile-tip resistance formed a multipoint vertical bearing mode. It efficiently utilized the soil’s shear strength and mobilized a larger volume of surrounding soil to share the load. The screw-groove structure increased the pile–soil interaction surface, thereby increasing the skin friction resistance of the pile. Additionally, increasing the inner radius of the screw groove boosts the pile’s bearing capacity but may reduce material utilization. An optimal screw-groove spacing balances both factors, while excessive groove thickness lowers material use. The pile shows high sensitivity to soil parameters. Full article

In order to study the bearing mechanism of a steel screw pile (SSP), a 3D-FEM of “SSP-stratum” was established based on the large-scale general finite element analysis platform ABAQUS. Secondly, the real friction coefficient between pile and soil was determined by comparing it with the field bearing test data of screw piles. Finally, the bearing mechanism and failure criterion of the SSP was revealed. The research showed that the pile-soil friction coefficient was about 0.6 under the condition of this stratum, and the screw pile was in the elastic working stage under the conditions of compression and tension load, which had a large bearing reserve. The magnitude of Young’s modulus was inversely correlated with the settlement value and the extreme value of principal stress. The increase in the Young’s modulus of the stratum was helpful in improving the bearing capacity of the screw pile. The compressive capacity of circular steel tube + screw pile (CST + SP) was about 2 times higher than CST, and the compressive capacity of circular steel tube + large blade + screw pile (CST + LB + SP) was about 2.4 times higher than CST. The tensile capacity of CST + SP was about 3.4 times higher than CST, and the tensile capacity of CST + LB + SP was about 4.9 times higher than CST. The arrangement of large blades better bore the load of the screw part and optimized the stress distribution of the structure. Based on the mechanical analysis in the vertical direction, the bearing mechanism of the SSP under compression and tension conditions was elaborated. The bearing failure criterion of the SSP was summarized from the aspects of mechanics and displacement. The bearing design of the SSP should meet the control of mechanics and deformation at the same time. The research work could provide a useful reference for the design and construction of SSPs. Full article

Screw piles (often referred to as helical piles) are widely used to resist axial and lateral loads as deep foundations. Multi-helix piles experience complex interactions between the plates which depend on the soil properties, pile stiffness, helix diameter, and the number of helix plates among other factors. Design methods for these piles are typically highly empirical and there remains significant uncertainty around calculating the compression capacity. In this study, a database of 1667 3D finite element analyses was developed to better understand the effect of different inputs on the compression capacity of screw piles in clean sands. Following development of the numerical database, various machine learning methods such as linear regression, neural networks, support vector machines, and Gaussian process regression (GPR) models were trained and tested on the database in order to develop a prediction tool for the pile compression capacity. GPR models, trained on the numerical data, provided excellent predictions of the screw pile compression capacity. The test dataset root mean square error (RMSE) of 29 kN from the GPR model was almost an order of magnitude better than the RMSE of 225 kN from a traditional theoretical approach, highlighting the potential of machine learning methods for predicting the compression capacity of screw piles in homogenous sands. Full article

The bearing capacity of fiber-reinforced plastic (FRP) helical screw piles is determined by the lesser of the breaking load at the bolted joint and the resistance provided by the screw tip area. In this study, compression and tensile tests were performed with the number of bolts and edge distance as variables. It showed similar strength when compared to the failure stress derived from material testing. In addition, considering load resistance performance, the optimal screw cross section was obtained through parametric analysis. Considering the structural behavior of the screw, a prediction equation was presented to design the screw cross-section as a tapered cross-section using a theoretical method. As a result of comparing the screw cross-section with the finite element analysis results, it was confirmed that the design stress and analysis stress showed an error of 1.1 MPa and were within the allowable stress of 80 MPa. Full article

In northern Canada where permafrost is prevalent, a persistent shortage of accessible, affordable, and high-quality housing has been ongoing for decades. The design of foundations in permafrost presents unique engineering challenges due to permafrost soil mechanics and the effects of climate change. There is no specific design code for pile or shallow foundations in northern Canada. Consequently, the design process heavily relies on the experience of Arctic engineers. To clearly document the current practice and provide guidance to engineers or professionals, a comprehensive review of the practice in foundation design in the Arctic would be necessary. The main objective of this paper is to provide an overview of the common foundations in permafrost and the geotechnical considerations adopted for building on frozen soils. This study conducted a review of current practices in deep and shallow foundations used in northern Canada. The review summarized the current methods for estimating key factors, including the adfreeze strength, creep settlement, and frost heave, used in foundation design in permafrost. To understand the geotechnical considerations in foundation design, this study carried out interviews with several engineers or professionals experienced in designing foundations in permafrost; the findings and the interviewees’ opinions were summarized. Lastly, in order to demonstrate the design methods obtained from the interviews and review, the paper presents two design examples where screw piles and steel pipe piles were designed to support a residential building in northern Canada, according to the current principles for adfreeze strength, long term creep settlement, and frost heave. The permafrost was assumed to be at −1.5 °C, and the design life span was assumed to be 50 years. The design examples suggested that for an axial load of 75 kN, a 12-m-long steel pipe pile or a 7-m-long screw pile would be needed. Full article

Helical piles became a popular foundation technique, and as a result of environmental restrictions, they have become increasingly widely used. However, due to the high cost of experimentation, the influence of the number of helices and their positions on the pile-bearing capacity has not been sufficiently studied. The present study performed compression and lateral load tests on helical piles of the same diameter but with one, two, and three round helices in known sandy soil. The results from the experiments are compared with those from numerical simulations that use the mesh-free RBF method and the Winkler–Fuss approach to model how the pile and ground interact. The results are generalized to suggest an engineering equation that can predict the best pile configuration in sandy soil. Full article

Bored piles comprise an advanced pile foundation technology that has the advantages of high bearing capacity, fast construction speed, stable construction technology, and no noise or mud pollution. To study the applicability of bored piles to collapsible loess sites, the compaction effect and load-bearing characteristics of bored piles before and after immersion were studied via a full-scale field test combined with the theory of hole expansion. The results indicate that when the pile spacing is 1.0, 1.25, and 1.5 m, the average dry density of the soil between piles increases by 23.8%, 18.5%, and 3.1%, respectively, compared with that of untreated foundation soil. When bored piles are used to treat deep collapsible loess foundations, the reasonable pile spacing to eliminate the collapsibility of the loess foundation is 2.5 times the pile diameter. It is feasible to estimate the effective compaction range using the pore expansion theory, and the effective compaction coefficients of similar sites are given. The positive friction of bored piles in the collapsible loess area is more than 95.5 kPa, which increases by more than 48.5% compared with that of non-extruded piles. Therefore, the bearing capacity of a single pile is significantly improved, and it is an effective treatment method for collapsible loess areas. Under immersion, the pile side negative friction did not change significantly with a pile diameter of approximately 27 kPa, and the increase was approximately 14% compared with that of non-extruded piles. Consequently, to avoid the adverse effects of negative friction resistance on the bearing capacity of pile foundations and to fully utilize the technical advantages of bored piles, it is necessary to eliminate or partially eliminate site collapsibility before applying bored piles. The results can provide experimental support and theoretical guidance for the popularization and application of screw–squeeze piles in deep, collapsible loess areas. Full article

Background: The resorption of magnesium-based alloy bioabsorbable screws results in the release of hydrogen gas, which can mimic infection and enter the growth plate. The screw itself and the released gas may also affect image quality. Objective: The evaluation of magnetic resonance imaging (MRI) findings during the most active phase of screw resorption is the objective, with particular focus on the growth plate and to assess for the presence of metal-induced artifacts. Material and Methods: In total, 30 prospectively acquired MRIs from 17 pediatric patients with fractures treated with magnesium screws were assessed for the presence and distribution of intraosseous, extraosseous, and intra-articular gas; gas within the growth plate; osteolysis along the screw; joint effusion; bone marrow edema; periosteal reaction; soft tissue edema; and metal-induced artifacts. Results: Gas locules were found in the bone and soft tissues in 100% of the examinations, intra-articular in 40%, and in 37% of unfused growth plates. Osteolysis and the periosteal reaction were present in 87%, bone marrow edema in 100%, soft tissue edema in 100%, and joint effusion in 50% of examinations. Pile-up artifacts were present in 100%, and geometric distortion in 0% of examinations. Fat suppression was not significantly impaired in any examination. Conclusions: Gas and edema in the bone and soft tissues are normal findings during the resorption of magnesium screws and should not be misinterpreted as infection. Gas can also be detected within growth plates. MRI examinations can be performed without metal artifact reduction sequences. Standard fat suppression techniques are not significantly affected. Full article

A screw pile is a special-shaped pile with several advantages, including good bearing capacity, economy, and rapid construction. The calculation of the screw piles’ ultimate bearing capacity in the individual bearing failure state remains controversial. To address the problems of an unclear failure mechanism and the pile–soil contact relationship in screw piles, we conducted large-scale direct shear tests using a partial amplification method. The variation law for soil stress and the failure pattern of soil around the screw teeth were analyzed. The bearing capacity of the screw shear plate with screw teeth was found to be significantly higher than that of the plane shear plate, while that of the screw pile first increased and then decreased with an increase in the screw pitch. The optimal screw pitch allowed the determination of the maximum bearing capacity. Furthermore, the optimal screw pitch was generally equal to the critical screw pitch, which distinguished the individual bearing failure from the cylindrical shearing failure. A new calculation method for the critical screw pitch and ultimate bearing capacity in the individual bearing failure state was presented, and its rationality was proved using the direct shear test results. The calculation of the critical screw pitch considers the shear strength of soil and the geometric parameters of the screw teeth, making it more widely applicable. These results can provide a theoretical basis for the subsequent design of screw piles. Full article

The installation of screw piles can cause damage to the soil, which is a dynamic and large deformation problem. In this paper, a FEM-SPH numerical model for the analysis of this large deformation problem was developed in LS-DYNA to simulate the installation process of screw piles. In addition, field installation tests of screw piles were carried out. By comparing the FEM-SPH simulation results with the experimental results and traditional FEM simulation results, it was found that the FEM-SPH coupling method has higher efficiency and accuracy in dealing with the large deformation problems caused by the installation of screw piles. Then, numerical simulations of screw piles with various parameters were conducted to analyze the differences in the installation process. The results show that the spiral pitch and pile diameter have a significant effect on the installation torque, soil stress and soil pressure during the installation process. During the installation process, the interaction between the screw pile and the soil is transferable. The installation of the screw pile will lead to the movement of soil particles in the radial and axial directions, resulting in heave damage to the shallow soil and cylindrical shear damage to the middle and deep soil. The influence range on the soil by the heave failure mechanism (HFM) and the cylindrical shear failure mechanism (CSFM) caused by the installation of screw piles is affected by pile parameters. The change in pile diameter will act on both HFM and CSFM, whereas the variation in spiral pitch will only have an influence on CSFM. Full article
