Search Results (16)

The development of control strategies for autonomous vehicles requires a reliable and cost-effective validation approach. In this context, testbeds enabling repeatable experiments under controlled conditions are gaining relevance. Scaled vehicles have proven to be a valuable alternative to full-scale or simulation-based testing, enabling experimental validation while reducing costs and risks. This work presents a 1:5 scale modular vehicle platform, derived from a commercial Radio-Controlled (RC) vehicle and adapted as experimental testbed for control strategy validation and vehicle dynamics studies. The vehicle features an electric powertrain, operated through a Speedgoat Baseline Real-Time Target Machine (SBRTM). The hardware architecture includes a high-performance Inertial Measurement Unit (IMU) with embedded Global Navigation Satellite System (GNSS). An Extended Kalman Filter (EKF) is implemented to enhance positioning accuracy by fusing inertial and GNSS data, providing reliable estimates of the vehicle position, velocity, and orientation. Two path-following algorithms, i.e., Stanley Controller (SC) and the Linear Quadratic Regulator (LQR), are designed and integrated. Outdoor experimental tests enable the evaluation of tracking accuracy and robustness. The results demonstrate that the proposed scaled testbed constitutes a reliable and flexible platform for benchmarking autonomous vehicle controllers and enabling experimental testing. Full article

This paper presents the design, development, and experimental validation of a low-cost, modular, and scalable Advanced Driver Assistance System (ADAS) platform intended for research and educational purposes. The system integrates embedded computer vision and electronic control using an FPGA for accelerated real-time image processing and an STM32 microcontroller for sensor data acquisition and actuator management. The YOLOv3-Tiny model is implemented to enable efficient pedestrian and vehicle detection under hardware constraints, while additional vision algorithms are used for lane line detection, ensuring a favorable trade-off between accuracy and processing speed. The platform is deployed on a 1:5 scale gasoline-powered vehicle, offering a safe and cost-effective testbed for validating ADAS functionalities, such as lane tracking, pedestrian and vehicle identification, and semi-autonomous navigation. The methodology includes the integration of a CMOS camera, an FPGA development board, and various sensors (LiDAR, ultrasonic, and Hall-effect), along with synchronized communication protocols to ensure real-time data exchange between vision and control modules. A wireless graphical user interface (GUI) enables remote monitoring and teleoperation. Experimental results show competitive detection accuracy—exceeding 94% in structured environments—and processing latencies below 70 ms per frame, demonstrating the platform’s effectiveness for rapid prototyping and applied training. Its modularity and affordability position it as a powerful tool for advancing ADAS research and education, with high potential for future expansion to full-scale autonomous vehicle applications. Full article

The evolution of the internet towards supporting time-critical applications, such as industrial cyber-physical systems (CPSs) and autonomous systems, has created an urgent demand for networks capable of providing deterministic, low-latency communication. Autonomous vehicles represent a particularly challenging use case within this domain, requiring both reliability and determinism for massive data streams—a requirement that traditional Ethernet technologies cannot satisfy. This paper addresses this critical gap by proposing a comprehensive scheduling framework based on Time-Aware Shaping (TAS) within the Time-Sensitive Networking (TSN) standard. The framework features two key contributions: (1) a novel baseline scheduling algorithm that incorporates a sub-flow division mechanism to enhance schedulability for high-bandwidth streams, computing Gate Control Lists (GCLs) via an iterative SMT-based method; (2) a separate heuristic-based computation acceleration algorithm to enable fast, scalable GCL generation for large-scale networks. Through extensive simulations, the proposed baseline algorithm demonstrates a reduction in end-to-end latency of up to 59% compared to standard methods, with jitter controlled at the nanosecond level. The acceleration algorithm is shown to compute schedules for 200 data streams in approximately one second. The framework’s effectiveness is further validated on a real-world TSN hardware testbed, confirming its capability to achieve deterministic transmission with low latency and jitter in a physical environment. This work provides a practical and scalable solution for deploying deterministic communication in complex autonomous and cyber-physical systems. Full article

A small-scale supersonic flight experiment vehicle is being developed at Muroran Institute of Technology as a flying testbed for verification of innovative technologies for high-speed atmospheric flights, which are essential to next-generation aerospace transportation systems. Its baseline configuration M2011 with a cranked-arrow main wing with an inboard and outboard leading edge sweepback angle of 66 and 61 degrees and horizontal and vertical tails has been proposed. Its aerodynamics caused by attitude motion are required to be clarified for six-degree-of-freedom flight capability prediction and autonomous guidance and control. This study concentrates on characterization of such aerodynamics caused by rolling rates in the subsonic regime. A mechanism for rolling a wind-tunnel test model at various rolling rates and arbitrary pitch angle is designed and fabricated using a programmable stepping motor and an equatorial mount. A series of subsonic wind-tunnel tests and preliminary CFD analysis are carried out. The resultant static derivatives have sufficiently small scatter and agree quite well with the static wind-tunnel tests in the case of a small pitch angle, whereas the static directional stability deteriorates in the case of large pitch angles and large nose lengths. In addition, the resultant dynamic derivatives agree well with the CFD analysis and the conventional theory in the case of zero pitch angle, whereas the roll damping deteriorates in the case of large pitch angles and proverse yaw takes place in the case of a large nose length. Full article

To commercialize supersonic and hypersonic passenger aircraft and reusable spaceplanes, we are developing a small-scale supersonic flight experiment vehicle as a flying testbed for technical demonstrations in high-speed flight environments. This experiment vehicle is equipped with a fuel tank and an oxidizer tank, and the propellants inside the tanks slosh due to changes in acceleration during flight. In this situation, there is a risk of gas entrainment during liquid discharge, which could potentially cause an engine malfunction. To avoid such a situation, we considered installing a propellant management device (PMD) inside the tank to suppress the gas entrainment. In this study, a capillary type PMD with a screen channel structure, commonly used in satellites featuring no moving parts, was adopted due to its applicability to a wide acceleration range. The PMD was designed with a structure featuring cylindrical mesh screen nozzles installed at the top and bottom of a cylindrical tank. A one-dimensional flow analysis model was developed taking into account factors such as the pressure loss across the mesh screens and the flow loss within the mesh screen nozzles, which enabled the identification of conditions under which gas entrainment occurred. In this analytical model, separate formulations were developed using Hartwig’s and Ingmanson’s formulas for evaluating the flow losses through the mesh screens. Furthermore, by applying the flow analysis model, the specifications of the mesh screens as key parameters of the PMD, together with the nozzle diameter and nozzle length, were selected. Moreover, we fabricated prototype PMDs with each nozzle and conducted visualization tests using a transparent tank. The tests were conducted under static conditions, where a gravitational acceleration acted downward, and the effects of the cylindrical mesh screen length and discharge flow rate on the free surface height at which gas entrainment occurred were investigated. This experiment demonstrated the effectiveness of the propellant acquisition mechanism of the present PMD. The height of the free surface was also compared with the experimental and analytical results, and it was shown that the results obtained by using Ingmanson’s formula for pressure loss through the screen mesh were closer to the experimental results. These findings demonstrated the validity of the one-dimensional flow analysis model. Full article

Side impacts tend to produce more severe injuries than frontal collisions, particularly for vulnerable occupants such as children. Despite this, there is a limited number of studies and developments focused on side impact protection systems, and existing airbag evaluations often rely on destructive and high-cost test methods. This study introduces a novel, cost-effective, and nondestructive experimental testbed designed to evaluate curtain airbags for vehicles in segments B, C, D, and E. The main objective is to develop an adjustable mechanical structure that replicates the side frame geometry of multiple vehicles, allowing the mounting and evaluation of various curtain airbags under realistic conditions. The prototype, capable of withstanding deployment forces of up to 7000 N, was tested with a 3-year-old child dummy, recording a peak head acceleration of 136.17 g, corresponding to AIS level 2. Deployment speeds reached 7.77 m/s, with inflation times between 29 and 36 ms—values that fall within the range reported in previous experimental and numerical studies. The testbed demonstrated consistency in its performance metrics and offers a valuable tool for enhancing child occupant safety in side impacts. Furthermore, it provides a measurable Head Injury Criterion (HIC) range that can be used to interpret injury severity in child occupants. This work contributes significantly to the development of flexible and safe testing methodologies for side airbag systems, reducing the reliance on full-scale crash testing. Full article

This article presents an optimal tracking controller retrofitted with a nonlinear adaptive integral compensator, specifically designed to ensure robust and accurate positioning of Vertical Take-Off and Landing (VTOL) Unmanned Aerial Vehicles (UAVs) that utilize contra-rotating motorized propellers for differential thrust generation. The baseline position controller is synthesized by employing a fixed-gain Linear Quadratic Integral (LQI) tracking controller that stabilizes position by tracking both state variations and pitch-axis tracking error integral, which adjusts the voltage to control each coaxial propeller’s speed accurately. Additionally, the baseline tracking control law is supplemented with a rate-varying integral compensator. It operates as a nonlinear scaling function of the tracking-error velocity and the braking acceleration to enhance the accuracy of reference tracking without sacrificing its robustness against exogenous disruptions. The controller’s performance is analyzed by performing experiments on a tailored hardware-in-the-loop aero-pendulum testbed, which is representative of VTOL UAV dynamics. Experimental results demonstrate significant improvements over the nominal LQI tracking controller, achieving 17.9%, 61.6%, 83.4%, 43.7%, 35.8%, and 6.8% enhancement in root mean squared error, settling time, overshoot during start-up, overshoot under impulsive disturbance, disturbance recovery time, and control energy expenditure, respectively, underscoring the controller’s effectiveness for potential UAV and drone applications under exogenous disturbances. Full article

A small-scale supersonic flight experiment vehicle named OWASHI is being developed at Muroran Institute of Technology as a flying testbed for verification of innovative technologies for high-speed atmospheric flights. Drag reduction in the transonic and supersonic regimes is quite crucial for attainability of its supersonic flights. This study aims to obtain configuration modification for transonic drag reduction on the basis of the so-called area rule. In order to prevent accumulation of compression waves, various profiles of the bottleneck and the bulge are designed by using arcs with constant and large radii and spline curves approximating them. Their effects are assessed through CFD analysis, wind tunnel tests, and wave drag analysis. As a result, an area-rule-based configuration with a sharpened conical nose and a large-radius bottleneck achieves significant drag reduction in a transonic Mach range, as well as 57-count (57 × 10⁻⁴) reduction at the design Mach number of 1.1. However, the drag reduction effects of bulges are small and apparent only in a narrow Mach range. On the other hand, in the practical vehicle configuration, rearward fuselage extension shows a large amount of drag reduction, whereas the addition of an intake cancels the drag reduction effects of area-rule-based configurations. Full article

In recent years, the demand for Urban Air Mobility (UAM) and Micro Aerial Vehicles (MAVs) has driven the emergence of new aircraft designs, with the Staggered Rotor System being widely applied in these vertical take-off and landing aircraft. Due to the complex aerodynamic interference between rotors, the spacing between them has a significant impact on the performance of these new aircraft configurations. A testbed was designed and validated to investigate the effects of parameters such as axial distance and lateral distance between rotors on the thrust performance of the Staggered Rotor System. A series of systematic thrust tests was conducted on two co-rotating small-scale rotor models, with particular focus on thrust testing of individual rotors in isolation and their comparison to the conditions of the Staggered Rotor System. During the experimental process, as both the axial and lateral distance varied, an orthogonal experimental design was employed to assess the influence of aerodynamic interactions caused by different rotor diameters on rotor performance. This study conducts an analysis of experimental data to investigate the influence of these factors on the performance of rotor systems’ thrust, while also examining the aerodynamic interference and aerodynamic force evolution patterns of rotor systems under varying parameters. Furthermore, rotor speed also plays a crucial role in the performance of the system. Therefore, when designing vertical take-off and landing aircraft with multiple rotors, it is essential to consider the influence of these factors during the optimization process. Full article

Electric vehicles (EVs) are experiencing explosive growth in public adoption, causing a major shift in research and development priorities by OEMs toward electrified powertrains. To verify EV drivetrain platforms and software models in the design phase, testbeds with specific capabilities are essential. Full-scale vehicle testbeds are expensive, bulky, dissipative, and not easily reconfigurable or movable, making scaled testbeds more attractive, especially for education and research institutes. To support this cause, this paper reports on the development of a small-scale, modular, hardware-in-the-loop (HIL) testbed platform for the drivetrain of EVs that is cost-effective, efficient, and easily movable and reconfigurable and allows integration of a battery pack. The testbed is comprised of two directly coupled electric machines. The first machine emulates the traction motor and is used to control vehicle speed according to a specified drive cycle. The second machine is used to impose a torque profile on the first machine’s shaft—based on the vehicle’s parameters and driving environment—and emulates a gearbox (if necessary). A systematic two-way scaling approach is adopted to downscale the parameters and driving environment of full-size EVs to a level that can be handled by the testbed and to upscale the test results obtained from the testbed to the full-size vehicle level. The power consumption of the testbed is limited to system losses. A case study involving a full-size EV was performed and the HIL simulation results were compared to the computer simulation results to verify the performance of the testbed. Full article

This paper presents a novel scheme for fast fault detection and isolation (FDI) of position sensors based on signal processing and fault-tolerant control (FTC) for speed tracking of an electric vehicle (EV) propelled by a permanent magnet synchronous motor (PMSM). The fault is detected using a comparison algorithm between the measured and delayed rotor speed signals. The proposed scheme is more practical for diagnosing faults over a wide speed range since it does not use estimated speed value. In addition, to ensure continuous vehicle propulsion and to retain effective field-oriented control of the EV-PMSM in the event of a fault, a reconfiguration mechanism with back-EMF based position observer is employed. Rapid detection of position sensor failure is necessary for a seamless transition from sensored to sensorless control. Furthermore, a comparative analysis between sliding mode observer and flux observer for motor speed control is also presented in the context of EVs. The effectiveness of the position sensors for FDI and FTC is validated in the presence of typical vehicular disturbances, such as uneven road conditions and wind disturbance force. Finally, to validate the proposed approach experimentally in a real-world EV environment, this paper utilizes a scaled-down testbed with a TMS320F28379D DSP for the motor control of the EV. Full article

The Internet of Things (IoT) is a key technology for smart community networks, such as smart-city environments, and its evolution calls for stringent performance requirements (e.g., low delay) to support efficient communication among a wide range of objects, including people, sensors, vehicles, etc. At the same time, these ecosystems usually adopt wireless mesh technology to extend their communication range in large-scale IoT deployments. However, due to the high range of coverage, the smart-city WMNs may face different network challenges according to the network characteristic, for example, (i) areas that include a significant number of wireless nodes or (ii) areas with frequent dynamic changes such as link failures due to unstable topologies. Named-Data Networking (NDN) can enhance WMNs to meet such IoT requirements, thanks to the content naming scheme and in-network caching, but it necessitates adaptability to the challenging conditions of WMNs. In this work, we aim at efficient end-to-end NDN communication in terms of performance (i.e., delay), performing extended experimentation over a real WMN, evaluating and discussing the benefits provided by two SDN-based NDN strategies: (1) a dynamic SDN-based solution that integrates the NDN operation with the routing decisions of a WMN routing protocol; (2) a static one which based on SDN-based clustering and real WMN performance measurements. Our key contributions include (i) the implementation of two types of NDN path selection strategies; (ii) experimentation and data collection over the w-iLab.t Fed4FIRE+ testbed with real WMN conditions; (ii) real measurements released as open-data, related to the performance of the wireless links in terms of RSSI, delay, and packet loss among the wireless nodes of the corresponding testbed. Full article

This study proposes a grid-connected inverter for photovoltaic (PV)-powered electric vehicle (EV) charging stations. The significant function of the proposed inverter is to enhance the stability of a microgrid. The proposed inverter can stabilize its grid voltage and frequency by supplying or absorbing active or reactive power to or from a microgrid using EVs and PV generation. Moreover, the proposed inverter can automatically detect an abnormal condition of the grid, such as a blackout, and operate in the islanding mode, which can provide continuous power to local loads using EV vehicle-to-grid service and PV generation. These inverter functions can satisfy the requirements of the grid codes, such as IEEE Standard 1547–2018 and UL 1741 SA. In addition, the proposed inverter can not only enhance the microgrid stability but also charge EVs in an appropriate mode according to the condition of the PV array and EVs. The proposed inverter was verified through experimental results with four scenarios in a lab-scale testbed. These four scenarios include grid normal conditions, grid voltage fluctuations, grid frequency fluctuations, and a power blackout. The experimental results demonstrated that the proposed inverter could enhance the microgrid stability against grid abnormal conditions, fluctuations of grid frequency and voltage, and charge EVs in an appropriate mode. Full article

The increased demand for Unmanned Aerial Vehicles (UAV) has also led to higher demand for realistic and efficient UAV testing environments. The current use of simulated environments has been shown to be a relatively inexpensive, safe, and repeatable way to evaluate UAVs before real-world use. However, the use of generic environments and manually-created custom scenarios leaves more to be desired. In this paper, we propose a new testbed that utilizes machine learning algorithms to procedurally generate, scale, and place 3D models to create a realistic environment. These environments are additionally based on satellite images, thus providing users with a more robust example of real-world UAV deployment. Although certain graphical improvements could be made, this paper serves as a proof of concept for an novel autonomous and relatively-large scale environment generator. Such a testbed could allow for preliminary operational planning and testing worldwide, without the need for on-site evaluation or data collection in the future. Full article

Large-scale monitoring systems have seen rapid development in recent years. Wireless sensor networks (WSN), composed of thousands of sensing, computing and communication nodes, form the backbone of such systems. Integration with unmanned aerial vehicles (UAVs) leads to increased monitoring area and to better overall performance. This paper presents a hybrid UAV-WSN network which is self-configured to improve the acquisition of environmental data across large areas. A prime objective and novelty of the heterogeneous multi-agent scheme proposed here is the optimal generation of reference trajectories, parameterized after inter- and intra-line distances. The main contribution is the trajectory design, optimized to avoid interdicted regions, to pass near predefined way-points, with guaranteed communication time, and to minimize total path length. Mixed-integer description is employed into the associated constrained optimization problem. The second novelty is the sensor localization and clustering method for optimal ground coverage taking into account the communication information between UAV and a subset of ground sensors (i.e., the cluster heads). Results show improvements in both network and data collection efficiency metrics by implementing the proposed algorithms. These are initially evaluated by means of simulation and then validated on a realistic WSN-UAV test-bed, thus bringing significant practical value. Full article
