Search Results (37)

This article represents a full estimation of helicopter rotor aerodynamic characteristics in ground effect conditions through the application of a coupled empirical blade element–momentum theory algorithm. The main focus of this research includes the evaluation of the required weighted power coefficients $\left({\displaystyle \raisebox{1ex}{$C_P$}\!\left/ \!\raisebox{-1ex}{$\sigma $}\right.}\right)$ for a hovering state in close proximity to obstacles and their relation to the weighted thrust force coefficients’ values $\left({\displaystyle \raisebox{1ex}{$C_T$}\!\left/ \!\raisebox{-1ex}{$\sigma $}\right.}\right),$ varying the relative distance from the helicopter rotational plane to the ground surface $\left({\displaystyle \raisebox{1ex}{$H$}\!\left/ \!\raisebox{-1ex}{$R$}\right.}\right)$ and the rotor’s collective pitch angle (θ). The represented numerical and experimental results show that an increase in the collective pitch angles (θ) leads to a rise in the generated weighted thrust force coefficients $\left({\displaystyle \raisebox{1ex}{$C_T$}\!\left/ \!\raisebox{-1ex}{$\sigma $}\right.}\right)$ and in the weighted power coefficients $\left({\displaystyle \raisebox{1ex}{$C_P$}\!\left/ \!\raisebox{-1ex}{$\sigma $}\right.}\right)$ for every individual fixed normalized distance from the ground surface $\left({\displaystyle \raisebox{1ex}{$H$}\!\left/ \!\raisebox{-1ex}{$R$}\right.}\right)$. Moreover, a decline in the relative distance from the ground $\left({\displaystyle \raisebox{1ex}{$H$}\!\left/ \!\raisebox{-1ex}{$R$}\right.}\right)$ requires less power to keep the rotation going in hover. The dependencies indicate that the ground effect zone covers a distance of up to 2R from the rotational plane to the ground surface. Full article

Bioinspired morphing offers a powerful route to higher aerodynamic and hydrodynamic efficiency. Birds reposition feathers, bats extend compliant membrane wings, and fish modulate fin stiffness, tailoring lift, drag, and thrust in real time. To capture these advantages, engineers are developing airfoils, rotor blades, and hydrofoils that actively change shape, reducing drag, improving maneuverability, and harvesting energy from unsteady flows. This review surveys over 296 studies, with primary emphasis on literature published between 2015 and 2025, distilling four biological archetypes—avian wing morphing, bat-wing elasticity, fish-fin compliance, and tubercled marine flippers—and tracing their translation into morphing aircraft, ornithopters, rotorcraft, unmanned aerial vehicles, and tidal or wave-energy converters. We compare experimental demonstrations and numerical simulations, identify consensus performance gains (up to 30% increase in lift-to-drag ratio, 4 dB noise reduction, and 15% boost in propulsive or power-capture efficiency), and analyze materials, actuation, control strategies, certification, and durability as the main barriers to deployment. Advances in multifunctional composites, electroactive polymers, and model-based adaptive control have moved prototypes from laboratory proof-of-concept toward field testing. Continued collaboration among biology, materials science, control engineering, and fluid dynamics is essential to unlock robust, scalable morphing technologies that meet future efficiency and sustainability targets. Full article

The flight controllability and safety of unmanned compound rotorcraft are closely related to their aerodynamic characteristics. During forward flight, complex aerodynamic interference effects arise among the rotor, propeller, wing, fuselage, and horizontal–vertical tail. These interactions change dramatically with variations in forward speed, which may have a substantial impact on flight performance. This paper investigates aerodynamic interference related to the rotor, propeller, and fuselage of a sample unmanned compound rotorcraft with a novel configuration. On this basis, a flight dynamics model that incorporates the identified aerodynamic interference is formulated. Firstly, an analysis of rotor/propeller/fuselage aerodynamic interference is performed using the momentum source method (MSM). Subsequently, the aerodynamic models for the wing, fuselage, and horizontal–vertical tail are updated by integrating aerodynamic interference factors, leading to the development of a nonlinear flight dynamics model for the sample unmanned compound rotorcraft. Finally, to validate the updated flight dynamics model, numerical simulation results are systematically compared against wind tunnel test results. The results reveal a significant correlation between the numerical simulation data and wind tunnel test results, which indicates that the updated flight dynamics model possesses high accuracy and reliability and can characterize the dynamic characteristics of the sample unmanned compound rotorcraft within the flight speed envelope. Full article

Cross-media vehicles, which combine the advantages of airplanes and submarines, are capable of performing complex tasks in different media and have attracted significant interest in recent years. In practice, however, cross-media rotorcrafts face numerous challenges during the cross-media transition, one of which is the complex mixed air–water flows induced by their rotors operating in close proximity to the water surface. These flows can result in aerodynamic penalties and structural damage to the rotors. The interactions between a water surface and a rotor wake bring about potential risks of cross-media locomotion, which is known as the near-water effect of rotors. Given that the distinctions between the near-water effect and the ground effect of rotors are not yet widely understood, this study details the discovery of the near-water effect and provides a comprehensive review of the evolutionary development of the near-water effect, tracing its understanding from the ground effect to the influence of droplets through aerodynamic modeling, numerical simulations, and near-water experimental studies. Furthermore, open problems and challenges associated with the near-water effect are discussed, including flow field measurements and numerical simulation approaches. Additionally, potential applications of the near-water effect for the development of cross-media rotorcraft are also described, which are valuable for aerodynamic design and cross-media control. Full article

Camber deflection concepts for a VR-12 rotorcraft airfoil were studied for the optimization of unsteady aerodynamics, including dynamic stall conditions and wing–wing interactions during pitching. The designs are based on deflections of the leading edge and trailing edge sections of the airfoil. The deflection parameters were initially established using Computational Fluid Dynamics (CFD). Results from CFD and Particle Image Velocimetry (PIV) were generated for various leading and trailing edge deflection combinations for comparison of their performances. The conditions of this study are for a Reynolds number of 250,000 and pitching reduced frequency of 0.04, representing a medium regime of rotorcraft operations. Linear tandem tests were performed to simulate unsteady wing–wing interactions. The effects of the deflections are discussed and compared to the baseline. Significant benefits are observed, notably dynamic stall mitigation from the leading edge (LE) deflected wing for certain angles of attack and decrease in the separation regions. Overall, from the numerical simulations and the experimental data fields, the LE deflection provides about 10% improvement, followed by the combined LE&TE deflections (8%). It is also found that combining various deflections can provide a performance increase over drastically different areas of the range of angle of attack. Full article

The precise regulation of the hinge moment and pitch angle driven by the pitch-regulated mechanism is crucial for modulating thrust requirements and ensuring stable attitude control in Martian coaxial rotorcraft. Nonetheless, the aerodynamic hinge moment in rotorcraft presents time-dependent dynamic properties, posing significant challenges for accurate measurement and assessment for such characteristics. In this study, we delve into the detailed aerodynamic hinge moment characteristics associated with the pitch-regulated mechanism of Mars rotorcraft under a spectrum of control strategies. A robust computational fluid dynamics model was developed to simulate the rotor’s aerodynamic loads, accompanied by a quantitative hinge moment characterization that takes into account the effects of varying rotor speeds and pitch angles. Our investigation yielded a thorough understanding of the interplay between aerodynamic load behavior and rotor surface pressure distributions, leading to the creation of an empirical mapping model for hinge moments. To validate our findings, we engineered a specialized test apparatus capable of measuring the hinge moments of the pitch-regulated mechanism, facilitating empirical assessments under replicated atmospheric conditions of both Earth and Mars. The result indicates aerodynamic hinge moments depend nonlinearly on rotational speed, peaking at a 0° pitch angle and showing minimal sensitivity to pitch under 0°. Above 0°, hinge moments decrease, reaching a minimum at 15° before rising again. Simulation and experimental comparisons demonstrate that under Earth conditions, the aerodynamic performance and hinge moment errors are within 8.54% and 24.90%, respectively. For Mars conditions, errors remain below 11.62%, proving the CFD model’s reliability. This supports its application in the design and optimization of Mars rotorcraft systems, enhancing their flight control through the accurate prediction of aerodynamic hinge moments across various pitch angles and speeds. Full article

Comprehensive rotorcraft simulation codes are the workhorses for designing and simulating helicopters and their rotors under steady and unsteady operating conditions. These codes are also used to predict helicopters’ limits as they approach rotor stall conditions. This paper focuses on the prediction of maximum rotor thrust when hovering (due to stall limits) and the thrust and power characteristics when the collective control angle is further increased. The aerodynamic factors that may significantly affect the results are as follows: steady vs. unsteady aerodynamics, steady vs. dynamic stall, blade tip losses, curvature flow, yaw angle, inflow model, and blade-vortex interaction. The inflow model and tip losses are found to be the most important factors. For real-world applications vortex-based inflow models are considered the best choice, as they reflect the blade circulation distribution within the inflow distribution. Because the focus is on the impact of aerodynamic modeling on rotor stall, the blade design and its flexibility are intentionally not considered. Full article

In the research field of rotorcraft aerodynamics, there are two fundamental challenges: resolving the complex vortex structures in rotor wakes and representing the moving rotor blades in the ambient airflow. In this paper, we address the first challenge by utilizing a third-order unstructured finite volume solver, which exhibits lower numerical dissipation than its second-order counterpart. This allows for sufficient resolution of small vortex structures on relatively coarse meshes. With this flow solver, the second challenge is addressed by modeling each rotor as an actuator disk (i.e., the actuator disk model (ADM)) or modeling each blade as an actuator line (i.e., the actuator line model (ALM)). Both of the two models are equipped with an improved tip loss correction, which is introduced in detail in the methodology section. In the section of numerical experiments, the numerical convergence properties of the two types of solvers have been compared in the case of two-dimensional infinite wing. In addition, the relationship between the ALM and the lifting line theory is discussed in the cases of fixed-wing calculations. Another goal of these cases is to validate the tip loss correction presented. The validation of the ALM/ADM and comparisons of computational efficiency are also demonstrated in simulations involving both hover and forward flight rotors. It was found that the combination of the third-order finite volume solver and the ALM/ADM with the improved tip loss correction presents an efficient way of performing the aerodynamic analysis of rotor-induced downwash flow. Full article

Tail-sitters aim to combine the advantages of fixed-wing aircraft and rotorcraft but require a robust and fast stabilization strategy to perform vertical maneuvers and transitions to and from aerodynamic flight. The research conducted in this work explores different nonlinear control solutions for the problem of stabilizing a tail-sitter when hovering. For this purpose, the first controller is an existing strategy for tail-sitter control obtained from the literature, the second is an application of Nonlinear Dynamic Inversion (NDI), and the last one is its incremental version, INDI. These controllers were implemented and tuned in a simulation in order to stabilize a model of the tail-sitter, complemented by estimation methods that allow the feedback of the necessary variables. These estimators and controllers were then implemented in a microcontroller and validated in a Hardware-in-the-Loop (HITL) scenario with simple maneuvers in vertical flight. Lastly, the developed control solutions were used to stabilize the aircraft in experimental flight while being monitored by a motion capture system. The experimental results allow the validation of the model of the X-Vert and provide a comparison of the performance of the different control solutions, where the INDI presents itself as a robust control strategy with accurate tracking capabilities and less actuator demand. Full article

The aerodynamic noise of an open rotor is one of the critical challenges that must be considered in its design and application. FODNOPP, a program specifically programmed to predict the aerodynamic discrete noise of single- and counter-rotating open rotors (such as propellers, propfans, and rotorcraft rotors) at subsonic, transonic, and supersonic helical blade tip speeds, has recently been developed by the first author. This program is composed of four prediction codes, namely code a1, code a2, code b, and code c, each based on Farassat-derived formulations Formu 1-RTE, Formu 1A, Formu 1-Sph, and Formu 3, providing time-domain solutions to the Ffowcs Williams–Hawkings equation. Four verification examples for both propeller low-speed flight noise and counter-rotating propfan take-off noise are presented, along with an application case for transonic helical tip speed counter-rotating propfan cruise noise. The results demonstrate the accuracy of FODNOPP in calculating the noise for these verification cases. And in the counter-rotating propfan cruise noise case, the maximum harmonic sound pressure level of the rear propfan is 5.5 dB higher than that of the front propfan. FODNOPP can be referred to as a comprehensive design tool, and it offers valuable guidance for engineering design focused on rotor-related noise reduction. Full article

To study the effects of synthetic jet control on the aerodynamic performance of a rotor in forward flight, we conducted a series of experiments with varying rotor rotation speeds and free stream velocities. In the test, we used a six-component balance and a PIV system and designed a blade with a particular structure that covered the frame. The experimental results revealed that the synthetic jet could effectively delay flow separation over the blade and enhance the aerodynamic efficiency of the rotor. Moreover, we investigated how different jet parameters influenced the flow control effects of synthetic jets on the rotor’s aerodynamic characteristics. We drew some valuable conclusions from our analysis. In forward flight, the jet located closer to the leading edge of the blade had a stronger impact on improving the aerodynamic performance of the rotor. The jet with a 90° jet angle increased the rotor normal force by 225%, which was the maximum possible increase, while the jet with a 30° inclined angle had the best control effects on preventing flow separation in the retreating blade. Our study provides valuable insights into the use of synthetic jets for rotor flow control and suggests possible applications for improving rotorcraft performance and stability. Full article

After one year of operation, the Ingenuity rotorcraft and the Perseverance rover continue their exploration missions on Mars. Succeeding the technology demonstration phase, by proving its flight capabilities, Ingenuity transitioned to a new mission stage to explore modes of flight exploration for future scouting missions. This research intends to analyze, using numerical simulations, the aerodynamic conditions such as those experienced by Ingenuity during its flight missions. For this work, ANSYS Fluent software was used to simulate the flow around the cambered plates, and a three-equation intermittency (γ) shear stress transport turbulence model with compressible formulation was implemented. The influence of the camber and its position for the cambered plates were explored, and a sensitivity analysis with respect to the Mach number was performed. The objective of this project was to determine the optimal configuration to produce the optimal lift-to-drag ratio for the range of analysis. The results were in line with the ones shown by NASA (OVERFLOW). Moreover, this analysis showed the ANSYS Fluent applicability for assessing aerodynamic surfaces for unmanned aerial systems operating at low density and low Reynolds number regimes. Full article

The large reverse flow region of the rotor with a high advance ratio is an important factor that affects the performance improvement of helicopters. This paper examines the dynamic stall of the airfoil in the reverse flow region of the rotor to develop a set of dynamic pressure measurement systems for the airfoil in the reverse low region. The pitch oscillation experiment of the NACA0018 airfoil in and out of the rotor reverse flow region has been carried out, and the influence of the airfoil motion parameters on dynamic stalls has been studied. The results show that the airfoil is more likely to stall in the reverse flow region under static conditions and that stall is invariant to the Reynolds number. After a stall occurs, the lift coefficient decreases more slowly with the increase of the angle of attack (about 10% of that in the forward flow state). Under the dynamic environment, in a pitching cycle, the quarter chord moment coefficient of the airfoil alternates between positive and negative frequently during reverse-blowing. The pitching oscillation in the reverse flow region is more sensitive to the changes in airfoil parameters than that under normal flow, and there is a marked difference. The alternating moment of the airfoil in the reverse flow region is significant: the greater the pitching amplitude, the greater the alternating moment. In the reverse-blowing state, with the increase in reduced frequency, the dynamic stall angle of attack increases more significantly. Full article

In aerospace engineering, high-order computational fluid dynamics (CFD) solvers suitable for three-dimensional unstructured meshes are less developed than expected. The Runge–Kutta discontinuous Galerkin (RKDG) finite element method with compact weighted essentially non-oscillatory (WENO) limiters is one of the candidates, which might give high-order solutions on unstructured meshes. In this article, we provide an efficient parallel implementation of this method for simulating inviscid compressible flows. The implemented solvers are tested on lower-dimensional model problems and real three-dimensional engineering problems. Results of lower-dimensional problems validate the correctness and accuracy of these solvers. The capability of capturing complex flow structures even on coarse meshes is shown in the results of three-dimensional applications. For solving problems containing rotary wings, an unsteady momentum source model is incorporated into the solvers. Such a finite element/momentum source hybrid method eliminates the reliance on advanced mesh techniques, which might provide an efficient tool for studying rotorcraft aerodynamics. Full article

As an important part of the helicopter, the rotor directly affects flight safety and flight quality. Knowledge of the rotor dynamic behaviors is significant for validating and optimizing the performance of the helicopter rotor system. In this study, a photogrammetric system, based on 3D point tracking and stereo photogrammetry technology, is presented to solve the full-field dynamic motion and deformation parameters of rotating blades by identifying the retro-reflective targets arranged on the rotor. The photogrammetric system is demonstrated in the wind tunnel tests of a 2 m-diameter model rotor, conducted at the 5.5 m × 4 m Aeroacoustic Wind Tunnel of the China Aerodynamics Research and Development Center (CARDC). With the targets attached on the special hat installed directly over the rotor hub, a unified rotor coordinate system, that was stationary with respect to the rotor, could be established at any measuring instant. Therefore, by transforming the 3D coordinates of all measured targets to the rotor coordinate system, the blade displacements and deformations at different test conditions could be calculated consistently. Experimental results from current study were compared to simulation results calculated by the comprehensive analytical model of rotorcraft aerodynamics and dynamics (CAMRAD), which shows quite good agreements. Full article
