Thermal control in rolling mills motors is gaining importance as more and more hard-to-deform steel grades are rolled. The capabilities of diagnostics monitoring also expand as digital IIoT-based technologies are adopted. Electrical drives in modern rolling mills are based on synchronous motors with frequency regulation. Such motors are expensive, while their reliability impacts the metallurgical plant output. Hence, developing the on-line temperature monitoring systems for such motors is extremely urgent. This paper presents a solution applying to synchronous motors of the upper and lower rolls in the horizontal roll stand of plate mill 5000. The installed capacity of each motor is 12 MW. According to the digitalization tendency, on-line monitoring systems should be based on digital shadows (coordinate observers) that are similar to digital twins, widely introduced at metallurgical plants. Modern reliability requirements set the continuous temperature monitoring for stator and rotor windings and iron core. This article is the first to describe a method for calculating thermal loads based on the data sets created during rolling. The authors have developed a thermal state observer based on four-mass model of motor heating built using the Simscape Thermal Models library domains that is part of the MATLAB Simulink. Virtual adjustment of the observer and of the thermal model was performed using hardware-in-the-loop (HIL) simulation. The authors have validated the results by comparing the observer’s values with the actual values measured at control points. The discrete masses heating was studied during the rolling cycle. The stator and rotor winding temperature was analysed at different periods. The authors have concluded that the motors of the upper and lower rolls are in a satisfactory condition. The results of the study conducted generally develop the idea of using object-oriented digital shadows for the industrial electrical equipment. The authors have introduced technologies that improve the reliability of the rolling mills electrical drives which accounts for the innovative development in metallurgy. The authors have also provided recommendations on expanded industrial applications of the research results. Full article

This study presents a design and optimization methodology to enhance the power density and efficiency of wound field synchronous machines (WFSMs) by selectively applying grain-oriented electrical steel (GOES). Unlike conventional non-grain-oriented electrical steel (NOES), GOES exhibits significantly lower core loss along its rolling direction, making it suitable for regions with predominantly alternating magnetic fields. Based on magnetic field analysis, four machine configurations were investigated, differing in the placement of GOES within stator and rotor teeth. Finite element analysis (FEA) was employed to compare electromagnetic performance across the configurations. Subsequently, a multi-objective optimization was conducted using Latin Hypercube Sampling, meta-modeling, and a genetic algorithm to maximize power density and efficiency while minimizing torque ripple. The optimized WFSM achieved a 13.97% increase in power density and a 1.0% improvement in efficiency compared to the baseline NOES model. These results demonstrate the feasibility of applying GOES in rotating machines to reduce core loss and improve overall performance, offering a viable alternative to rare-earth permanent magnet machines in xEV applications. Full article

This study addresses the gap in the experimental validation of the tilt-rotor vertical take-off and landing (VTOL) UAVs by developing a novel prototype that integrates fixed-wing and multi-rotor advantages. A dynamic model based on the “X” quadrotor configuration was established, and Euler parameters were employed to derive the attitude transformation matrix. Structural optimization using hybrid meshing and inertia release methods revealed a maximum deformation of 57.1 mm (2.82% of half-wingspan) and stress concentrations below material limits (379.21 MPa on fasteners). The landing gear was optimized using the unified objective method, and the stress was reduced by 32.63 MPa compared to the pre-optimization stress. Vibration analysis identified hazardous frequencies (11–12 Hz) to avoid resonance. Stable motor speed tracking (±5 RPM) and rolling attitude control (less than 10% error) are achieved using a dual-serial PID control system based on the DSP28377D master. Experimental validation in low-altitude flights confirmed the prototype’s feasibility, though ground effects impacted pitch/yaw performance. This work provides critical experimental data for future tilt-rotor UAV development. Full article

The twin propeller system can be powered by a motor with dual-rotating rotors, which generally necessitates that both rotors run at the same speed to prevent rolling. The motor with dual-rotating rotors is popular for applications that benefit from high torque density and an axially compact form factor. In order to minimize the effects of load disturbances and internal parameter perturbations on the motor performance, this paper proposes a control strategy combining disturbance observer and sliding mode control (SMC) technologies to realize the purpose of both rotors rotating at the same speed. There are issues with the conventional proportional-integral (PI) control for load disturbances and motor parameter variations, whereas the SMC method has its invariant properties. Meanwhile, the system disturbances obtained by a disturbance observer are estimated to be used as feed-forward compensation for the SMC control in order to reduce the undesired chattering during the SMC control process. The validity and practicability of the control strategies proposed in this paper are demonstrated by both simulations and experiments. Full article

Currently, there is limited experimental research on the stability of journal bearing-rotor systems under base motion, and the influence of rocking motion on the stability of such systems remains unclear. This study develops an experimental test rig for a journal bearing-rotor system and employs a six-degrees-of-freedom shaking table to apply complex alternating loads, with the aim of investigating the effects of rocking amplitude and frequency on the vibration characteristics of the shaft system. The experimental results show that, under the excitation of base roll and pitch motions, the critical speed of the sliding bearing-rotor system remains nearly unchanged, while the resonance amplitude increases significantly, and the instability speed occurs earlier. In addition, base rocking motion not only induces periodic and uniform changes in the vibration amplitude of the shaft system but also demonstrates a strong positive correlation between the amplitude of system vibration and the amplitude of base rocking. Full article

This study employs response surface methodology (RSM) with a custom optimal design to develop and optimize iron (Fe) grade and recovery through magnetization roasting followed by induced dry-roll magnetic separation. The relationships between the independent and dependent variables are investigated. The effect of roasting temperature, magnetization roasting time, magnetic field intensity, rotor speed, and product splitter position for the induced dry-roll magnetic separator on Fe grade and recovery are studied. Suitable models are generated to predict the optimum operating conditions. An analysis of Variance (ANOVA) is employed to validate the developed regression models’ adequacy and assess the main and interaction-related effects on Fe grade and recovery. During magnetization roasting, a satisfactory Fe grade of 66.8% with a recovery of 16.7% was obtained under optimal conditions of 1050 °C for 97 min. Conversely, after the induced dry-roll magnetic separator optimization, an Fe grade of 66.1% with a recovery of 60.2% was achieved under optimum conditions of 0.105 T for magnetic field intensity, 70 Hz for rotor speed, and an 11 mm product splitter position. This study effectively illustrates how RSM can model the processes of magnetization roasting and induced dry-roll magnetic separation, particularly concerning the operating parameters used for treating iron ore plant tailings. Furthermore, it highlights the efficiency of this methodology in generating substantial insights in a short timeframe while minimizing the number of experiments conducted. Full article

Solid-lubricated rolling bearings are widely used in the aerospace field and are key components to support spacecraft rotors. During the start-up of the engine, the sharp acceleration may cause bearing skidding, resulting in damage of the solid lubricating film and a reduction in the remaining useful life of the bearing. However, the existing research on the tribo-dynamic responses of solid-lubricated ball bearings mostly relies on semi-empirical tribological models, which are limited in their ability to reveal the micro–macro sliding mechanisms of the ball–raceway contact interface. In this paper, a novel tribo-dynamic model for solid-lubricated angular contact ball bearings is developed by applying Kalker’s rolling contact theory to the Gupta dynamic model. The interpolation method is adopted to calculate contact parameters to improve the model’s efficiency. Using the proposed model, the dynamic response of the bearing in the acceleration process is studied, and the mechanism and influence characteristics of skidding, over-skidding, and creepage of the rolling element are analyzed. The results show that the main reason for skidding is that the traction force is not enough to overcome the resistance, and the gyroscopic effect is the main cause of over-skidding, which follows the principle of conservation of the angular momentum of the ball. Full article

The generation of digital aerial photogrammetry products using unmanned aerial vehicle-digital aerial photogrammetry (UAV-DAP) has become an essential task due to the increasing use of UAVs in the world of geomatics, thanks to their low cost and spatial resolution. Therefore, it is relevant to explore the performance of new digital cameras equipped in UAVs using electronic rolling shutters instead of ideal mechanical or global shutter cameras to achieve accurate and reliable photogrammetric products, if possible, while minimizing workload, especially for their application in projects that require a high level of detail. In this paper, we analyse performance using oblique images along the perimeter (3D perimeter) on a flat area, i.e., with slopes of less than 3%. The area was photogrammetrically surveyed with a DJI (Dà-Jiāng Innovations) Inspire 2 multirotor UAV equipped with a Zenmuse X5S rolling shutter camera. The photogrammetric survey was accompanied by a Global Navigation Satellite System (GNSS) survey, in which dual frequency receivers were used to determine the ground control points (GCPs) and checkpoints (CPs). The study analysed different scenarios, including the combination of forward and transversal strips and oblique images. After examining the ideal scenario with the least root mean square error (RMSE), six different combinations were analysed to find the best location for the GCPs. The most significant results indicate that the optimal calibration of the camera is obtained in scenarios including oblique images, which outperform the rest of the scenarios for achieving the lowest RMSE (2.5x the GSD in Z and 3.0x the GSD in XYZ) with optimum GCPs layout; with non-ideal GCPs layout, unacceptable errors can be achieved (11.4x the GSD in XYZ), even with ideal block geometry. The UAV-DAP rolling shutter effect can only be minimised in the scenario that uses oblique images and GCPs at the edges of the overlapping zones and the perimeter. Full article

High-speed rolling bearings exhibit low friction, high mechanical efficiency, low lubrication requirements, and excellent acceleration performance. The replacement of floating ring bearings in turbochargers with rolling bearings is an important tendency for modern turbochargers. However, due to the nonlinearity in rolling bearings, the nonlinear vibration characteristics of the turbocharger rotor system need to be clearly revealed. The turbocharger rotor is modeled by a lumped mass model. The nonlinear rolling bearing model is derived using the Hertz contact theory. The vibration responses of the nonlinear system are obtained by the modified incremental harmonic balance (MIHB) method. The results demonstrate that the MIHB method significantly improves computational efficiency compared to the traditional fourth-order Runge–Kutta method for solving this class of problems while also being capable of obtaining complete solution branches of the system. The stability of the responses is determined by the Floquet theory. Based on the present rotor dynamic model, the conical mode and cylindrical mode are found. Resonance peaks at 4.5 × 10⁴ rpm (conical mode) and 1.1 × 10⁵ rpm (bending mode) are identified as critical vibration thresholds. Moreover, the vibration amplitude results show that the resonance peak of the bending mode is mainly due to the nonlinearity of the rolling bearings, which also causes the amplitude jumping phenomenon. Changing the parameters of the rolling bearing could avoid the resonance peak appearing in the working speed range. The amplitude of the system under different rotating speeds could be suppressed by choosing the appropriate parameters of the rolling bearing. Full article

Electric vertical take-off and landing (eVTOL) aircraft are transforming urban air mobility (UAM) by providing efficient, low-emission, and rapid transit in congested cities. However, ensuring safe and stable landings remains a critical challenge, particularly in constrained urban environments with variable wind conditions. This study investigates the landing aerodynamics of a multi-rotor eVTOL using the lattice Boltzmann method (LBM), a computational approach well-suited to complex boundary conditions and parallel processing. This analysis examines the ground effect, descent speed, and crosswind influence on lift distribution and stability. A rooftop landing scenario is also explored, where half of the rotors operate over a rooftop while the rest remain suspended in open air. Results indicate that rooftop landings introduce asymmetric lift distribution due to crosswind and roof-induced flow circulation, significantly increasing rolling moment compared to ground landings. These findings underscore the role of descent speed, crosswinds, and landing surface geometry in eVTOL aerodynamics, particularly the heightened risk of rollover in rooftop scenarios. Full article

The installation distance between the speed sensor of the traditional rolling or sliding bearing permanent magnet synchronous motor and the rotor was very close, and the rotor of the magnetic levitation motor supported by Active Magnetic Bearings (AMBs) was in suspension. When the motor was running at high speed, the radial trajectory of the rotor changed all the time. The same frequency vibration caused by the unbalanced mass of the rotor made it easy to cause mechanical collision between the sensor and the rotor, resulting in direct damage of the sensor. Therefore, the sensorless speed estimation method was needed for the rotor control system of the magnetic levitation motor (MLM) to achieve high performance closed-loop control of speed and position. More importantly, in order to control or compensate the unbalanced force of the electromagnetic bearing rotor system, the rotor rotation speed signal should be obtained as accurately as possible. Therefore, the principle of adaptive sliding mode observer (SMO) was analyzed in detail by taking the rotor system of MLM as an example. Then, the sliding mode surface was designed, the speed estimation algorithm based on adaptive SMO was derived, and the stability analysis was completed. Finally, in order to verify the anti-disturbance performance of the system and the static and dynamic tracking performance of the motor, the dynamic performance was verified by increasing and decreasing the speed and load. The results showed that the speed estimation method based on adaptive SMO could achieve accurate speed estimation and had good static and dynamic performance. Full article

Rolling element bearings are key components for reducing friction and supporting rotors. Harsh working conditions contribute to the wear of bearings and consequent breakdown of machines, which leads to economic losses and even catastrophic accidents. Faulty impulses from bearings can excite resonance behavior in a system and produce modulation phenomena. Fault characteristics in modulated signals can be extracted using demodulation analysis methods, significantly improving the reliability and effectiveness of the fault diagnosis of rolling bearings. Optimal demodulation frequency band selection is a primary step for the demodulation-analysis-based fault diagnosis of bearing faults. To exploit the resonant modulation mechanism in the fault diagnosis of rolling element bearings, resonant frequencies identified through stochastic subspace identification are employed to guide the impulsive sparsity measures of an Autogram for bearing fault diagnosis, which combines physical modulation dynamics and data characteristics. The frequency band that not only matches the natural frequencies but also shows highly sparse impulsive characteristics is selected as the optimal demodulation frequency band for bearing fault diagnosis. The results of simulations and experimental data validate the advantages of the proposed method, which exploits physics-guided data processing for optimal demodulation frequency band determination. Full article

Rotor motor fault diagnosis in Unmanned Aerial Vehicles (UAVs) presents significant challenges under variable speeds. Recent advances in deep learning offer promising solutions. To address challenges in extracting spatial, temporal, and hierarchical features from raw vibration signals, a hybrid CNN-BiLSTM-MHSA model is developed. This model leverages Convolutional Neural Networks (CNNs) to identify spatial patterns, a Bidirectional Long Short-Term Memory (BiLSTM) network to capture long- and short-term temporal dependencies, and a Multi-Head Self-Attention (MHSA) mechanism to highlight essential diagnostic features. Experiments on raw rotor motor vibration data preprocessed with Butterworth band-stop filters were conducted under laboratory and real-world conditions. The proposed model achieves 99.33% accuracy in identifying faulty bearings, outperforming traditional models like CNN (93.33%) and LSTM (62.00%) and recent advances including CNN-LSTM (98.87%), the Attention Recurrent Autoencoder hybrid Model (ARAE) (66.00%), Lightweight Time-focused Model Network (LTFM-Net) (96.67%), and Wavelet Denoising CNN-LSTM (WDCNN-LSTM) (96.00%). The model’s high accuracy and stability under varying conditions underscore its robustness, making it a reliable solution for rolling bearing fault diagnosis in rotor motors, particularly for dynamic UAV applications. Full article

This paper presents, for the first time, a rotary actuator functionalized by an inclined disc rotor that serves as a distal optical scanner for endoscopic probes, enabling side-viewing endoscopy in luminal organs using different imaging/analytic modalities such as optical coherence tomography and Raman spectroscopy. This scanner uses a magnetic rotor designed to have a mirror surface on its backside, being electromagnetically driven to roll around the cone-shaped hollow base to create a motion just like a precessing coin. An optical probing beam directed from the probe’s optic fiber is passed through the hollow cone to be incident and bent on the back mirror of the rotating inclined rotor, circulating the probing beam around the scanner for full 360° sideway imaging. This new scanner architecture removes the need for a separate prism mirror and holding mechanics to drastically simplify the scanner design and thus, potentially enhancing device miniaturization and reliability. The first proof-of-concept is developed using 3D printing and experimentally analyzed to reveal the ability of both angular stepping at 45° and high-speed rotation up to 1500 rpm within the biologically safe temperature range, a key function for multimodal imaging. Preliminary optical testing demonstrates continuous circumferential scanning of the laser beam with no blind spot caused by power leads to the actuator. The results indicate the fundamental feasibility of the developed actuator as an endoscopic distal scanner, a significant step to further development toward advancing optical endoscope technology. Full article

The use of segmented stator and rotor designs in AC electric machine construction offers several significant advantages, including a high-copper fill factor, increased torque density, improved field-weakening performance, simplified manufacturing processes, and enhanced mechanical strength. Additionally, segmented designs allow for the incorporation of oriented steel—either partially or fully—which exhibits excellent magnetic properties in the rolling direction, resulting in more efficient machine performance. However, lamination segmentation also introduces challenges. Parasitic air gaps between segments and an increased number of cut edges in the assembled stack can alter the magnetic properties of the machine, potentially leading to degraded performance. Furthermore, the use of oriented steel remains complex, as its highly nonlinear magnetic properties vary depending on the direction of the magnetic flux. This paper reviews the widely adopted stator and rotor segmentation techniques available in the literature, discussing their potential benefits and limitations. It also covers key aspects such as popular manufacturing approaches, the impact of segmentation on machine performance, advanced finite-element analysis (FEA) techniques for numerical modeling, and experimental methods for evaluating the performance of segmented stator and rotor constructions in AC machines. By addressing these areas, this work provides a comprehensive resource for machine designers seeking to develop AC machines with segmented stators and rotors. Full article
