Search Results (15)

Rising energy prices, especially in Europe, make it necessary to look for cost reductions wherever possible. It also concerns the industry and hot rolling processes. One of the ideas of reducing costs is to use a roll gap lubrication (RGL) system. Lubrication makes it possible to reduce the forces needed for the materials processing, which directly translates into lower power consumption, but also makes it possible to extend the service life of the working rolls. The authors associated with Krakow Hot Rolling Mill, as a part of their work related to improving the production process of HSLA-type steel, also took into account the possibility of analyzing the subject of roll gap lubrication. This paper is a review of interesting papers concerning research on this topic over the past years. The authors also included in this paper a section on what the RGL system looks like on the AMP HSM in Krakow itself. This paper is a prelude to considering possible modifications to the RGL system. Full article

With the development of steel sheets towards higher strength and lower thickness, the process of rolling is facing more challenges, and one of the most important issues is lubrication, which directly determines the rolling stability, product quality, and production efficiency. This study focuses on the modeling and analysis of oil film thickness with viscosity–pressure–temperature (VPT) coupling effects under a hybrid lubrication system. Firstly, the mechanisms and limitations of direct spray and recirculation lubrication systems are systematically compared, highlighting the advantages of hybrid lubrication for high-speed tandem cold rolling. Subsequently, the mathematical models corresponding to different positions within the rolling interface between the roll and strip, are presented; the initial oil film thickness is described based on both plate-out and dynamic concentration formation mechanisms under the hybrid lubrication; and the model of inlet oil film thickness integrates the Reynolds equation, VPT effects, energy conservation, and continuity equations to quantify temperature-driven viscosity degradation. Furthermore, the influences of rolling process and lubrication parameters on the oil film thickness are analyzed, and a dynamic regulation strategy is proposed to optimize direct emulsion flow with regard to the actual rolling speed and the expected oil film thickness. This work bridges the gap between theoretical models and industrial requirements, providing actionable insights for high-speed rolling of advanced high-strength steel sheets. Full article

Lubrication is a critical process in cold strip rolling, and the accurate characterization of lubrication characteristics is an essential factor affecting the strip quality. The roll bending and tilting roll in the flatness actuators change the loaded roll gap profile and affect the lubrication characteristics by flatness dynamic correction, thus the mismatch between the actual and setting values of the lubrication status factor. Firstly, the flatness deviation correction model of roll bending and tilting roll based on the key information of the rolling process is established according to the high-order flatness target. Secondly, the characterization of the instantaneous oil film thickness in the work zone based on the loaded roll gap profile is derived from Reynolds’ equation. Finally, the explicit characterization method of the lubrication status factor in the rolling force model of the final stand is established with the work roll bending, tilting roll, and instantaneous oil film thickness of the work zone as variables, relying on the UCM five-stand, six-roll tandem cold rolling mill. The statistical evaluation and application results show that the mentioned optimization method can improve the setting accuracy of the rolling force by about 60% and the after-rolling gauge accuracy by about 50%. Full article

Integrated bearings, characterized by their unique structure, feature an inner ring that is seamlessly integrated with the shaft. This study is based on the theoretical framework of rolling bearing dynamics and considers bearing friction, lubrication, and Hertz elastic contact theory. A dynamic simulation model considering the interaction between the components of the rolling bearing is established. Additionally, a subroutine for calculating the interaction forces between the bearing components was written in C and compiled into a dynamic link library, which was then integrated with the dynamic simulation software. To solve and simulate the dynamics of the integrated bearing model, a sophisticated combination of a refined integration method and the predictor-corrector Adams–Bashforth–Moulton multistep technique was employed. The theoretical analysis offers insights into the vibration characteristics of the integrated bearings across different structural and operational parameters. Results indicate that a judicious selection of parameters, such as the curvature radius ratio of the inner and outer grooves and the gap of the cage pockets, can significantly enhance the bearings’ vibration and noise reduction capabilities. Furthermore, the application of an appropriate axial preload effectively reduces bearing vibrations, and there exists an optimal range of rotational speeds that minimizes these vibrations. Full article

The article contains a description of the design solutions proposed by the authors for a hybrid wind turbine bearing, in which the sliding part takes over the load to the turbine shaft after reaching the shaft rotation speed, ensuring hydrodynamic lubrication of the plain bearing and relieving the rolling bearing. This allows for low starting resistance of the power plant and ensures quiet operation during use. Two conceptual solutions of a hybrid bearing were presented, differing in the shape of the plain bearing journal. A mechanism for automatic switching of the load between a rolling and a plain bearing was developed. A solid simulation model of this mechanism was built in the Autodesk Inventor—Dynamic Simulation software Inventor Professional 2023 environment, and its operation was simulated. The results confirmed the usefulness of using this design in shaft-bearing systems of wind turbines with a vertical axis of rotation. Based on the simulation, the speed at which the thrust roller bearing will be released was determined. Technical parameters of a plain bearing with a spherical journal shape were calculated. The height of the lubrication gap and the shaft rotational speed at which the bearing load capacity index reaches a critical value were determined. Full article

Owing to the requirements for high performance and long life, the friction and wear problems of rolling piston type rotary compressors have drawn much attention. Various theoretical models have been developed and improved to reveal the inner state of the compressor and obtain the optimization schemes. However, there remain some disadvantages and research gaps in the corresponding modeling and mixed lubrication analyses, and a comprehensive summary is lacking. To have a better understanding of the research status, this paper reviews the theoretical model development and mixed lubrication analyses of the compressor in the past decades. The determination of compression pressure, the modeling process of moving components, and the key findings are presented in detail. On this basis, some important influencing factors and the problems remaining to be solved are also discussed. This paper provides multifaceted guidance for manufacturers and researchers to conduct further theoretical analysis and optimal design. Full article

The investigation in this article focuses on the rolling resistance torque and thermal inlet shear factor in tapered roller bearings (TRBs) through systematic experiments using a modular test setup. TRBs typically operate under Elastohydrodynamic Lubrication (EHL) conditions. At sufficiently high speeds, the majority of rolling friction is due to a significant shift of the pressure centre in the EHL contact. While at lower speeds, sliding friction in the roller-rib contact becomes dominant, which operates under mixed lubrication conditions. Limited literature exists on the impact of inlet shear heating on effective lubricant temperature ($T_{in\_c}$) and rolling friction in TRBs. To fill this gap, experimental measurements of the total frictional torque under axial loading at different speeds and oil temperatures are performed. With existing models for different friction contributions described in the literature, the rolling resistance due to EHL has been determined for various operating conditions. The effects of dimension-less speed (U), material (G), and load (W) parameters have also been investigated. Under fully flooded conditions, it was observed that the influence of material (G) and load (W) parameters on rolling friction is minor, while the impact of velocity (U) is significant. In the context of rolling resistance, the heating due to shear of the lubricant in the inlet zone plays a significant role. For higher rotational velocities, the estimated rotational torque reduction resulting from inlet shear heating was found to be approximately 6–8%. Full article

This paper is devoted to the determination of the coefficient of friction (COF) in the drawbead region in metal forming processes. As the test material, AW-5251 aluminium alloys sheets fabricated under various hardening conditions (AW-5251-O, AW-5251-H14, AW-5251-H16 and AW-5251H22) were used. The sheets were tested using a drawbead simulator with different countersample roughness and different orientations of the specimens in relation to the sheet rolling direction. A drawbead simulator was designed to model the friction conditions when the sheet metal passed through the drawbead in sheet metal forming. The experimental tests were carried out under conditions of dry friction and lubrication of the sheet metal surfaces with three lubricants: machine oil, hydraulic oil, and engine oil. Based on the results of the experimental tests, the value of the COF was determined. The Random Forest (RF) machine learning algorithm and artificial neural networks (ANNs) were used to identify the parameters affecting the COF. The R statistical package software version 4.1.0 was used for running the RF model and neural network. The relative importance of the inputs was analysed using 12 different activation functions in ANNs and nine different loss functions in the RF. Based on the experimental tests, it was concluded that the COF for samples cut along the sheet rolling direction was greater than for samples cut in the transverse direction. However, the COF’s most relevant input was oil viscosity (0.59), followed by the average counter sample roughness Ra (0.30) and the yield stress R_p0.2 and strength coefficient K (0.05 and 0.06, respectively). The hard sigmoid activation function had the poorest R² (0.25) and nRMSE (0.30). The ideal run was found after training and testing the RF model (R² = 0.90 ± 0.028). Ra values greater than 1.1 and R_p0.2 values between 105 and 190 resulted in a decreased COF. The COF values dropped to 9–35 for viscosity and 105–190 for R_p0.2, with a gap between 110 and 130 when the oil viscosity was added. The COF was low when the oil viscosity was 9–35, and the Ra was 0.95–1.25. The interaction between K and the other inputs, which produces a relatively limited range of reduced COF values, was the least relevant. The COF was reduced by setting the R_p0.2 between 105 and 190, the Ra between 0.95 and 1.25, and the oil viscosity between 9 and 35. Full article

Applying mathematical models and numerical methods is crucial for describing and simulating the metal cold-rolling process, wherein the accurate prediction of rolling force is an effective way to improve the quality of rolled sheets. This paper considers key influencing parameters such as friction lubrication, stress, tension, and roll-flattening radius during the rolling process and establishes a calculation model for the friction coefficient and roll-flattening radius. By considering the coupling effect of the dynamic roll gap on rolling force, a rolling force model for non-steady-state friction lubrication during the rolling process is obtained. The correctness of the proposed model is verified by comparing it with industrial measurement results. The influences of the friction coefficient, stress, tension before and after rolling, and roll-flattening radius on rolling force are quantitatively studied. The results show that the rolling force increases with an increase in the friction coefficient. When the friction coefficient exceeds 0.2, the rate of increase slows down, approaching dry friction conditions. The rolling force increases linearly with stress but decreases with increasing tension before and after rolling. The rolling force model, considering the roll-flattening radius, provides numerical calculation results that are closer to an industrial measured rolling force. This work contributes to a better understanding of the mechanism behind the improvement of the cold rolling process. Full article

Rotors are often coupled with a stationary part by rolling element bearings. To suppress their excessive vibration, the bearings are inserted in squeeze film dampers. The control of damping in the support elements offers the possibility to minimize the oscillation amplitude of accelerating or decelerating rotors, passing the regions of critical speeds. The controllable damping effect can be achieved if the squeeze film dampers are lubricated with magnetorheological oil. The change in the applied current feeding the electric coil changes magnetic induction in the damper gap, which changes the oil damping properties. The minimum vibration amplitude of the rotor running up or down through the resonance area is accomplished if the current increase or decrease is not sudden, but if it is distributed in some time interval. This article concentrates on determination of the optimum parameters of this manipulation. The developed procedure leads to solving an unconstrained optimization problem with the implicit objective function. The evolution method was used for its solving. In the investigated case, the proposed procedure made it possible to reduce maximum vibration amplitude by about 40% compared with the uncontrolled current decrease. The main contribution of the conducted research work is presentation of a new and original procedure for controlling the damping effect in the rotor supports. It provides a new idea to the designers and engineers regarding how to minimize amplitude of the rotor vibration when passing the critical speed. In addition, the article points to a new area of utilization of controllable magnetorheological squeeze film dampers. Full article

In the context of targeted improvements in energy efficiency, secondary rolling bearing contacts are gaining relevance. As such, the elastohydrodynamically lubricated (EHL) roller face/rib contact of tapered roller bearings significantly affects power losses. Consequently, this contribution aimed at numerical optimization of the pairing’s macro-geometric parameters. The latter were sampled by a statistical design of experiments (DoE) and the tribological behavior was predicted by means of EHL contact simulations. For each of the geometric pairings considered, a database was generated. Key target variables such as pressure, lubricant gap and friction were approximated by a meta-model of optimal prognosis (MOP) and optimization was carried out using an evolutionary algorithm (EA). It was shown that the tribological behavior was mainly determined by the basic geometric pairing and the radii while eccentricity was of subordinate role. Furthermore, there was a trade-off between high load carrying capacity and low frictional losses. Thereby, spherical or toroidal geometries on the roller end face featuring a large radius paired with a tapered rib geometry were found to be advantageous in terms of low friction. For larger lubricant film heights and load carrying capacity, spherical or toroidal roller on toroidal rib geometries with medium radii were favorable. Full article

Gear wear is a common fault that occurs in a gear transmission system that degrades the operating efficiency and may cause other catastrophic failures such as tooth breakage and fatigue. The progressive wear of a helical gear and its influences on vibration responses are rarely investigated due to the combined effects of the complicated lubrication state and the time-varying characteristic. To fill this gap, a numerical study was put forward to investigate the interactions between gear wear and dynamic response. In this study, an Archard’s wear model with elastohydradynamic lubrication (EHL) effect is adopted to simulate the helical gear wear, which is incorporated with an eight-degree of freedom dynamic model for understanding the gear dynamic at different wear degrees. The wear model shows that the gear wear mainly happens at the gear root due to the relative high slide-to-roll ratio. The dynamic modelling results demonstrate that the wear causes a reduction in time-varying gear mesh stiffness further leads to more vibration. Besides, the simulated vibration responses and experimental validation show that the wear cause increases in the amplitudes of the gear mesh frequency and its harmonics, which can reflect the evolution of progressive gear wear and can be used as monitoring features of gear wear. Full article

This article describes the development of a mathematical model of the reverse roll coating of a thin film for an incompressible non-isothermal magnetohydrodynamics $\left(MHD\right)$ viscoplastic fluid as it passes through a small gap between two rolls rotating reversely. The equations of motion required for the fluid added to the web are constructed and simplified using the lubrication approximation theory $\left(LAT\right)$. Analytical results are obtained for the velocity profile, pressure gradient, and temperature distribution. The pressure distributions and flow rate are calculated numerically using the trapezoidal rule and regular false position method, respectively. Some of these results are presented graphically, while others are shown in a tabular form. From the present analysis, it has been observed that the magnitude of pressure distributions increases by increasing the value of the involved parameters. It is worth mentioning that the velocities ratio and Brickman’s number are controlling parameters for the temperature distributions. The results indicate the strong effectiveness of the viscoplastic parameter and velocities ratio for the velocity and pressure distributions. It is also concluded that the coating of Casson material has been remarkably affected by the magnetohydrodynamics effects. Full article

In order to analyze the flatness control characteristics for a certain UCMW (Universal Crown Mill with Work roll shifting) cold rolling mill, combined with the actual parameters in the field, a static simulation model of the quarter roll systems of the UCMW cold rolling mill was established by the ANSYS finite element software. The bearing roll gaps under the factors of the unit width rolling force, the roll bending force and the roll shift were calculated, which reflects the shape control characteristics and has a great influence on the friction and lubrication characteristics between the roll gaps. Additionally, the shape control strategy of the process parameters in the field was put forward. The results show that, at first, the work roll shift is the most effective shape control means, while the current-used range of the intermediate roll shift cannot make full use of the roll end contour of the intermediate roll, so the intermediate roll negative shift should be considered for shape control. At second, the excessive rolling force goes against the shape control, so the rolling force of each stand should be reasonably distributed. Finally, the shape control ability of the bending force is relatively weak, so the range of the work roll bending force should be appropriately increased. Full article

A focus of the railway industry over the past decades has been to research, find and develop methods to mitigate noise and vibration resulting from wheel/rail contact along track infrastructure. This resulted in a wide range of abatement measures that are available for today’s engineers. The suitability of each method must be analysed through budget and timeframe limitations, which includes building, maintenance and inspection costs and time allocation, while also aiming at delivering other benefits, such as environmental impact and durability of infrastructure. There are several situations that need noise and vibration mitigation methods, but each design allocates different priorities on a case-by-case basis. Traditionally, the disturbance caused by railways to the community are generated by wheel/rail contact sound radiation that is expressed in different ways, depending on the movement of the rolling stock and track alignment, such as rolling noise, impact noise and curve noise. More specifically, in special trackworks such as turnouts (or called “switches and crossings”), there are two types of noise that can often be observed: impact noise and screeching noise. With respect to the screeching (or flanging), its mitigation methods are usually associated with curve lubrications. In contrast, the impact noise emerges from the sound made by the rolling stock moving through joints and discontinuities (i.e., gaps), resulting in various noise abatement features to minimise such noise impact. Life cycle analysis is therefore vital for cost efficiency benchmarking of the mitigation methods. The evaluation is based on available data from open literature and the total costs were estimated from valid industry reports to maintain coherency. A 50-year period for a life cycle analysis is chosen for this study. As for the general parameters, an area with a high density of people is considered to estimate the values for a community with very strict limits for noise and vibration. Full article
