The rapidly evolving field of functional yarns has garnered substantial research attention due to their exceptional potential in enabling next-generation electronic textiles for wearable health monitoring, human–machine interfaces, and soft robotics. Despite notable advancements, the development of yarn-based strain sensors that simultaneously achieve high flexibility, stretchability, superior comfort, extended operational stability, and exceptional electrical performance remains a critical challenge, hindered by material limitations and structural design constraints. Here, we present a bioinspired, hierarchically structured core-sheath yarn sensor (CSSYS) engineered through an efficient dip-coating process, which synergistically integrates the two-dimensional conductive MXene nanosheets and one-dimensional silver nanowires (AgNWs). Furthermore, the sensor is encapsulated using a yarn-based protective layer, which not only preserves its inherent flexibility and wearability but also effectively mitigates oxidative degradation of the sensitive materials, thereby significantly enhancing long-term durability. Drawing inspiration from the natural architecture of plant stems—where the inner core provides structural integrity while a flexible outer sheath ensures adaptive protection—the CSSYS exhibits outstanding mechanical and electrical performance, including an ultralow strain detection limit (0.05%), an ultrahigh gauge factor (up to 744.45), rapid response kinetics (80 ms), a broad sensing range (0–230% strain), and exceptional cyclic stability (>20,000 cycles). These remarkable characteristics enable the CSSYS to precisely capture a broad spectrum of physiological signals, ranging from subtle arterial pulsations and respiratory rhythms to large-scale joint movements, demonstrating its immense potential for next-generation wearable health monitoring systems. Full article

In intralogistics, autonomous mobile robots (AMRs) operate without predefined paths, leading to complex traffic patterns and potential conflicts that impact system efficiency. This paper proposes a bio-inspired optimization method for autonomously generating spatial movement constraints for autonomous mobile robots (AMRs). Unlike traditional multi-agent pathfinding (MAPF) approaches, which focus on temporal coordination, our approach proactively reduces conflicts by adapting a weighted directed grid graph to improve traffic flow. This is achieved through four mechanisms inspired by ant colony systems: (1) a movement reward that decreases the weight of traversed edges, similar to pheromone deposition, (2) a delay penalty that increases edge weights along delayed paths, (3) a collision penalty that increases weights at conflict locations, and (4) an evaporation mechanism that prevents premature convergence to suboptimal solutions. Compared to the existing approaches, the proposed approach addresses the entire intralogistic problem, including plant layout, task distribution, release and dispatching algorithms, and fleet size. Its autonomous movement rule generation and low computational complexity make it well suited for dynamic intralogistic environments. Validated through physics-based simulations in Gazebo across three scenarios, a standard MAPF benchmark, and two industrial environments, the movement constraints generated using the proposed method improved the system throughput by up to 10% compared to unconstrained navigation and up to 4% compared to expert-designed solutions while reducing the need for conflict-resolution interventions. Full article

There are many examples in nature in which the ability to detect is combined with decision-making, such as the basic survival instinct of plants and animals to search for food. We can technically translate this innate function via the use of robotics with integrated sensors and artificial intelligence. However, the integration of sensing capabilities into robotics has traditionally been neglected due to the significant associated technical challenges. Inspired by plant-root chemotropism, we present a miniaturized electrochemical array integrated into a robotic tip, embedding a customized micro-potentiometer. The system contains solid-state sensors fitted to the tip of the robotic root to three-dimensionally monitor potassium and pH changes in a moist, soil-like environment, providing an integrated electronic readout. The sensors measure a range of parameters compatible with realistic soil conditions. The sensors’ response can trigger the movement of the robotic root with a control algorithm inspired by the behavior of the plant root that determines the optimal path toward root growth, simulating the decision-making process of a plant. This nature-inspired technology may lead, in the future, to the realization of robotic devices with the potential for monitoring and exploring the soil autonomously. Full article

Soft robots have often been proposed for medical applications, creating human-friendly machines, and dedicated subject operation, and the pneumatic actuator is a representative example of such a robot. Plants, with their hingeless architecture, can take advantage of morphology to achieve a predetermined deformation. To improve the modes of motion, two pneumatic actuators that mimic the principles of the plants (the birds-of-paradise plant and the waterwheel plant) were designed, simulated, and tested using physical models in this study. The most common deformation pattern of the pneumatic actuator, bending deformation, was utilized and hingeless structures based on the plants were fabricated for a more complex motion of the lobes. Here, an ABP (actuator inspired by the birds-of-paradise plant) could bend its midrib downward to open the lobes, but an AWP (actuator inspired by the waterwheel plant) could bend its midrib upward to open the two lobes. In both the computational and physical models, the associated movements of the midrib and lobes could be observed and measured. As it lacks multiple parts that have to be assembled using joints, the actuator would be simpler to fabricate, have a variety of deformation modes, and be applicable in more fields. Full article

Plants are ideal for soft robot design due to their favourable ability to adapt and respond to the environment. Here, three different motile plants, bird of paradise (Strelitzia reginae), the waterwheel plant (Aldrovanda vesiculosa), and the Venus flytrap (Dionaea muscipula), are introduced. They may deform following the physics predetermined by the structure. As a decentralised species, plants respond under environmental stimulation without a controlling unit like a brain and motor-like muscles. The mechanism behind the movement of the plant should enlighten more intelligent robotics. In this study, movable plants are compared for their actuating principle, and, based on their deformation model, three pneumatic actuators are designed. The bird of paradise opens its petals when the sunbirds sit on another petal, which inspires the structure utilising the bending of the midrib to open lobes. Similarly, the waterwheel plant stores energy in the bending midrib and releases it when it closes. But, the Venus flytrap takes advantage of snapping to achieve rapid closure. Using three-dimensional (3D) printing, pneumatic actuators, which are ruled by the mechanism of plants with silicon rubber surfaces, are fabricated and tested. Under air pressure, the actuator deforms, mimicking the plant cells expanding under the turgor pressure. The hingeless actuator performs well while interacting with dedicated projects. Full article

Many plant materials in nature have the ability to change their shape to respond to external stimuli, such as humidity or moisture, to ensure their survival or safe seed release. A well-known example for this phenomenon is the pinecone, which is able to open its scales at low humidity due to the specific bilayer structures of the scale. Inspired by this, we developed a novel humidity-driven actuator based on paper. This was realized by the lamination of untreated paper made from eucalyptus fibers to a paper–carboxymethyl cellulose (CMC) composite. As observed, the hygroexpansion of the composite can be easily controlled by the amount of CMC in the impregnated paper sheet, which, thus, controls the morphologic deformation of the paper bilayer. For a more detailed understanding of these novel paper soft robots, we also studied the dynamic water vapor adsorption, polymer distribution and hygroexpansion of the paper–polymer composites. Finally, we applied a geometrically nonlinear finite element model to predict the bending behavior of paper bilayers and compared the results to experimental data. From this, we conclude that due to the complexity of structure of the paper composite, a universal prediction of the hygromorphic behavior is not a trivial matter. Full article

Advances in biomimetic triboelectric nanogenerators (TENGs) have significant implications for electronic skin (e-skin) and human–machine interaction (HMI). Emphasizing the need to mimic complex functionalities of natural systems, particularly human skin, TENGs leverage triboelectricity and electrostatic induction to bridge the gap in traditional electronic devices’ responsiveness and adaptability. The exploration begins with an overview of TENGs’ operational principles and modes, transitioning into structural and material biomimicry inspired by plant and animal models, proteins, fibers, and hydrogels. Key applications in tactile sensing, motion sensing, and intelligent control within e-skins and HMI systems are highlighted, showcasing TENGs’ potential in revolutionizing wearable technologies and robotic systems. This review also addresses the challenges in performance enhancement, scalability, and system integration of TENGs. It points to future research directions, including optimizing energy conversion efficiency, discovering new materials, and employing micro-nanostructuring techniques for enhanced triboelectric charges and energy conversion. The scalability and cost-effectiveness of TENG production, pivotal for mainstream application, are discussed along with the need for versatile integration with various electronic systems. The review underlines the significance of making bioinspired TENGs more accessible and applicable in everyday technology, focusing on compatibility, user comfort, and durability. Conclusively, it underscores the role of bioinspired TENGs in advancing wearable technology and interactive systems, indicating a bright future for these innovations in practical applications. Full article

The features or actuation behaviors of nature’s creatures provide concepts for the development of biomimetic soft bioactuators/robots with stimuli-responsive capabilities, design convenience, and environmental adaptivity in various fields. Mimosa pudica is a mechanically responsive plant that can convert pressure to the motion of leaves. When the leaves receive pressure, the occurrence of asymmetric turgor in the extensor and flexor sides of the pulvinus from redistributing the water in the pulvinus causes the bending of the pulvinus. Inspired by the actuation of Mimosa pudica, designing soft bioactuators can convert external stimulations to driving forces for the actuation of constructs which has been receiving increased attention and has potential applications in many fields. 4D printing technology has emerged as a new strategy for creating versatile soft bioactuators/robots by integrating printing technologies with stimuli-responsive materials. In this study, we developed a hybrid ink by combining gelatin methacryloyl (GelMA) polymers with iron oxide nanoparticles (IONs). This hybrid ION-GelMA ink exhibits tunable rheology, controllable mechanical properties, magnetic-responsive behaviors, and printability by integrating the internal metal ion-polymeric chain interactions and photo-crosslinking chemistries. This design offers the inks a dual crosslink mechanism combining the advantages of photocrosslinking and ionic crosslinking to rapidly form the construct within 60 s of UV exposure time. In addition, the magnetic-responsive actuation of ION-GelMA constructs can be regulated by different ION concentrations (0–10%). Furthermore, we used the ION-GelMA inks to fabricate a Mimosa pudica-like soft bioactuator through a mold casting method and a direct-ink-writing (DIW) printing technology. Obviously, the pinnule leaf structure of printed constructs presents a continuous reversible shape transformation in an air phase without any liquid as a medium, which can mimic the motion characteristics of natural creatures. At the same time, compared to the model casting process, the DIW printed bioactuators show a more refined and biomimetic transformation shape that closely resembles the movement of the pinnule leaf of Mimosa pudica in response to stimulation. Overall, this study indicates the proof of concept and the potential prospect of magnetic-responsive ION-GelMA inks for the rapid prototyping of biomimetic soft bioactuators/robots with untethered non-contact magneto-actuations. Full article

Wearable touch sensors, which can convert force or pressure signals into quantitative electronic signals, have emerged as essential smart sensing devices and play an important role in various cutting-edge fields, including wearable health monitoring, soft robots, electronic skin, artificial prosthetics, AR/VR, and the Internet of Things. Flexible touch sensors have made significant advancements, while the construction of novel touch sensors by mimicking the unique properties of biological materials and biogenetic structures always remains a hot research topic and significant technological pathway. This review provides a comprehensive summary of the research status of wearable touch sensors constructed by imitating the material and structural characteristics in nature and summarizes the scientific challenges and development tendencies of this aspect. First, the research status for constructing flexible touch sensors based on biomimetic materials is summarized, including hydrogel materials, self-healing materials, and other bio-inspired or biomimetic materials with extraordinary properties. Then, the design and fabrication of flexible touch sensors based on bionic structures for performance enhancement are fully discussed. These bionic structures include special structures in plants, special structures in insects/animals, and special structures in the human body. Moreover, a summary of the current issues and future prospects for developing wearable sensors based on bio-inspired materials and structures is discussed. Full article

This review is dedicated to self-healing silicone materials, which can partially or entirely restore their original characteristics after mechanical or electrical damage is caused to them, such as formed (micro)cracks, scratches, and cuts. The concept of self-healing materials originated from biomaterials (living tissues) capable of self-healing and regeneration of their functions (plants, human skin and bones, etc.). Silicones are ones of the most promising polymer matrixes to create self-healing materials. Self-healing silicones allow an increase of the service life and durability of materials and devices based on them. In this review, we provide a critical analysis of the current existing types of self-healing silicone materials and their functional properties, which can be used in biomedicine, optoelectronics, nanotechnology, additive manufacturing, soft robotics, skin-inspired electronics, protection of surfaces, etc. Full article

The plant factory transplanter is a key component of the plant factory system. Its operation status directly affects the quality and survival rate of planted seedlings, which in turn affects the overall yield and economic efficiency. To monitor the operation status and transplanting quality of a transplanting machine in a timely manner, the primary task is to use a computerized and easy-to-use method to monitor the transplanting units. Inspired by the latest developments in augmented reality and robotics, a digital twin model-based and data-driven online monitoring method for plant factory transplanting equipment is proposed. First, a data-driven and virtual model approach is combined to construct a multi-domain digital twin of the transplanting equipment. Then, taking the vibration frequency domain signal above the transplanting manipulator and the image features of the transplanting seedling tray as input variables, the evaluation method and configuration method of the plant factory transplanter digital twin system are proposed. Finally, the effect of the transplanter is evaluated, and the cycle can be repeated to optimize the transplanter to achieve optimal operation parameters. The results show that the digital twin model can effectively use the sensor data to identify the mechanical vibration characteristics and avoid affecting transplanting quality due to mechanical resonance. At a transplanting rate of 3000 plants/h, the transplanting efficiency can be maintained at a high level and the vibration signal of the X, Y, and Z-axis above the transplanting manipulator is relatively calm. In this case, Combined the optimal threshold method with the traditional Wiener algorithm, the identification rate of healthy potted seedlings can reach 94.3%. Through comprehensively using the optimal threshold method and 3D block matching filtering algorithm for image threshold segmentation and denoising, the recognition rate of healthy seedlings has reached over 96.10%. In addition, the developed digital twin can predict the operational efficiency and optimal timing of the detected transplanter, even if the environmental and sensor data are not included in the training. The proposed digital twin model can be used for damage detection and operational effectiveness assessment of other plant factory equipment structures. Full article

Bridging the gap between the material and geometrical aspects of a structure is critical in lightweight construction. Throughout the history of structural development, shape rationalization has been of prime focus for designers and architects, with biological forms being a major source of inspiration. In this work, an attempt is made to integrate different phases of design, construction, and fabrication under a single framework of parametric modeling with the help of visual programming. The idea is to offer a novel free-form shape rationalization process that can be realized with unidirectional materials. Taking inspiration from the growth of a plant, we established a relationship between form and force, which can be translated into different shapes using mathematical operators. Different prototypes of generated shapes were constructed using a combination of existing manufacturing processes to test the validity of the concept in both isotropic and anisotropic material domains. Moreover, for each material/manufacturing combination, generated geometrical shapes were compared with other equivalent and more conventional geometrical constructions, with compressive load-test results being the qualitative measure for each use case. Eventually, a 6-axis robot emulator was integrated with the setup, and corresponding adjustments were made such that a true free-form geometry could be visualized in a 3D space, thus closing the loop of digital fabrication. Full article

Movements in plants, such as the coiling of tendrils in climbing plants, have been studied as inspiration for coiling actuators in robotics. A promising approach to mimic this behavior is the use of multimaterial systems that show different elastic moduli. Here, we report on the development of magnetically controllable/triggerable multimaterial fibers (MMFs) as artificial tendrils, which can reversibly coil and uncoil on stimulation from an alternating magnetic field. These MMFs are based on deformed shape-memory fibers with poly[ethylene-co-(vinyl acetate)] (PEVA) as their core and a silicone-based soft elastomeric magnetic nanocomposite shell. The core fiber provides a temperature-dependent expansion/contraction that propagates the coiling of the MMF, while the shell enables inductive heating to actuate the movements in these MMFs. Composites with mNP weight content ≥ 15 wt% were required to achieve heating suitable to initiate movement. The MMFs coil upon application of the magnetic field, in which a degree of coiling N = 0.8 ± 0.2 was achieved. Cooling upon switching OFF the magnetic field reversed some of the coiling, giving a reversible change in coiling ∆n = 2 ± 0.5. These MMFs allow magnetically controlled remote and reversible actuation in artificial (soft) plant-like tendrils, and are envisioned as fiber actuators in future robotics applications. Full article

Soft growing robots, which mimic the biological growth of plants, have demonstrated excellent performance in navigating tight and distant environments due to their flexibility and extendable lengths of several tens of meters. However, controlling the position of the tip of these robots can be challenging due to the lack of precise methods for measuring the robots’ Cartesian position in their working environments. Moreover, classical control techniques are not suitable for these robots because they involve the irreversible addition of materials, which introduces process constraints. In this paper, we propose two optimization-based approaches, combining Moving Horizon Estimation (MHE) with Nonlinear Model Predictive Control (NMPC), to achieve superior performance in point stabilization, trajectory tracking, and obstacle avoidance for these robots. MHE is used to estimate the entire state of the robot, including its unknown Cartesian position, based on available configuration measurements. The proposed NMPC approach considers process constraints by relying on the estimated state to ensure optimal performance. We perform numerical simulations using the nonlinear kinematic model of a vine-like robot, one of the newly introduced plant-inspired growing robots, and achieve satisfactory results in terms of reduced computation times and tracking error. Full article

Biomimetic actuators are typically constructed as functional bi- or multilayers, where actuating and resistance layers together dictate bending responses upon triggering by environmental stimuli. Inspired by motile plant structures, like the stems of the false rose of Jericho (Selaginella lepidophylla), we introduce polymer-modified paper sheets that can act as soft robotic single-layer actuators capable of hygro-responsive bending reactions. A tailored gradient modification of the paper sheet along its thickness entails increased dry and wet tensile strength and allows at the same time for hygro-responsiveness. For the fabrication of such single-layer paper devices, the adsorption behavior of a cross-linkable polymer to cellulose fiber networks was first evaluated. By using different concentrations and drying procedures fine-tuned polymer gradients throughout the thickness can be achieved. Due to the covalent cross-linking of polymer with fibers, these paper samples possess significantly increased dry and wet tensile strength properties. We furthermore investigated these gradient papers with respect to a mechanical deflection during humidity cycling. The highest humidity sensitivity is achieved using eucalyptus paper with a grammage of 150 g m⁻² modified with the polymer dissolved in IPA (~13 wt%) possessing a polymer gradient. Our study presents a straightforward approach for the design of novel hygroscopic, paper-based single-layer actuators, which have a high potential for diverse soft robotic and sensor applications. Full article
