Search Results (97)

Many kinds of panel structures are proposed in aircraft design. This study presents a topology optimization method to improve the buckling resistance of panel structures. It should be noted that a popular configuration of the present panel structure is that with ribs and frames. Stiffening characteristics (i.e., effects of increasing structural stiffness of a panel structure with ribs and frames) are thus included during analysis of panel structures. After studying the coupling relationship between the dynamic characteristics and buckling behavior of the panel, a developed MMC (moving morphable component) method is proposed for topology optimization to improve the buckling resistance of the panel. It is seen that the coupling relationship between the dynamic characteristics and buckling behavior of the panel is mainly reflected when the compression force acts on the panel, corresponding that dynamic characteristics will vary with the load. If the load acts on the structure, the first-order natural frequency of the panel with ribs and frames in this study decreases with the increase in the load, with the optimization objective of maximizing the first-order natural frequency. Based on the coupling relationship between dynamic characteristics and buckling behavior, the critical buckling load of the panel increases as the first-order natural frequency increases. The present optimization method can reduce computational complexity without changing the accuracy of the calculation. At the same time, the coupling relationship between dynamic characteristics and buckling behavior is applied in topology optimization, which is of great significance to improve the comprehensive performance of panel structures in the engineering design process. This paper improves the dynamic characteristics and buckling resistance of panels with ribs and frames based on the improved MMC method. The proposed method effectively meets the design requirements of flight vehicle design in complex environments. Full article

This study investigates two novel prefabricated frame joints: prestressed steel sleeve-connected prefabricated reinforced concrete joints (PSFRC) and non-prestressed steel sleeve-connected prefabricated reinforced concrete joints (SSFRC). A total of three PSFRC specimens, four SSFRC specimens, and one cast-in-place joint were designed and fabricated. Seismic performance tests were conducted using different end-plate thicknesses, grout strengths, stiffener configurations, and prestressing tendon configurations. The experimental results showed that all specimens experienced beam end failures, and three failure modes occurred: (1) failure of the end plate of the beam sleeve, (2) failure of the variable cross-section of the prefabricated beam, and (3) failure of prefabricated beams at the connection with the steel sleeves. The load-bearing capacity and initial stiffness of the structure are increased by 35.41% and 32.64%, respectively, by increasing the thickness of the end plate. Specimens utilizing C80 grout exhibited a 39.05% higher load capacity than those with lower-grade materials. Adding stiffening ribs improved the initial stiffness substantially. Specimen XF2 had 219.08% higher initial stiffness than XF1, confirming the efficacy of stiffeners in enhancing joint rigidity. The configuration of the prestressed tendons significantly influenced the load-bearing capacity. Specimen YL2 with symmetrical double tendon bundles demonstrated a 27.27% higher ultimate load capacity than specimen YL1 with single centrally placed tendon bundles. An analytical model to calculate the moment–rotation relationship was established following the evaluation criteria specified in Eurocode 3. The results demonstrated a good agreement, providing empirical references for practical engineering applications. Full article

The present study investigates the influence of the configurations of anchor bolts and stiffeners on the monotonic response under moment conditions in the major axis and compression force of partial-strength exposed column base plate connections in order to ameliorate their response, limiting the number of welded details. Parametric finite element simulations were performed based on models calibrated against experimental results available from the recent literature. The results show the efficiency of the investigated configurations, namely, (i) the presence of rib stiffener results in high stiffness and strength with a reduction in ductility; (ii) the linear pattern of anchor bolts (e.g., rectangular distribution) is characterized by the limited contribution of the outer anchor bolts to the overall resistance of the connection; (iii) the trapezoidal pattern of the anchor bolts exhibit a better mechanical performance as well as their efficiency; and (iv) the increase in compression force influences the mechanical response of the base connection with an increase in both resistance and rigidity until the column is stable against the moment–axial force interaction. Full article

This paper investigates the axial deformation characteristics and crashworthiness of thin-walled metal tubes (TWT) reinforced with Polyetherketoneketone (PEKK) honeycomb lattice structures consisting of bio-inspired hierarchical cellular topological features. Experimentally validated numerical results revealed that the specific energy absorption capacity (SEA) of these composite structures increased with filler volume corresponding to a specific cellular topology. This includes the bio-inspired hierarchical sparse (BHS) topology, which registered a remarkable improvement in SEA over the hollow tube of 202%. In contrast, the central (BHC) topology deformed in an unstable hex-dominated pattern and triggered catastrophic failure of the composite in global bending mode. Furthermore, rigid cells were shown to drastically increase the initial peak force (IPF), while cells with low stiffness were beneficial for maintaining a low level of IPF and moderately improving SEA. Moreover, the rib and wall thickness of the BHS honeycomb cells were suitably tailored to increase the SEA by 2.1%, while simultaneously reducing the IPF by 3.7%. These findings suggest that multi-functional mechanical attributes of PEKK hierarchical honeycomb lattice fillers can mutually benefit thin-walled tubes with superior energy absorption capability and lightweight features over conventional lattice-filled tubes or a hollow tube. Full article

During the construction of concrete-filled steel tubular (CFST) arch bridges, hollow steel tube arch ribs are typically erected using the cantilever method with cable hoisting. In this construction stage, the arch ribs exhibit low out-of-plane stiffness and are thus highly susceptible to wind-induced vibrations, which may lead to cable failure or even collapse of the structure. Despite these critical risks, research on the aerodynamic performance of CFST arch ribs with different cross-sectional forms during cantilever construction remains limited. Most existing studies focus on individual bridge cases rather than generalized aerodynamic behavior. To obtain generalized aerodynamic parameters and buffeting response characteristics applicable to cantilevered CFST arch ribs, this study investigates two common cross-sectional configurations: four-tube trussed and horizontal dumbbell trussed sections. Sectional model wind tunnel tests were conducted to determine the aerodynamic force coefficients and aerodynamic admittance functions (AAFs) of these arch ribs. Comparisons with commonly used empirical AAF formulations (e.g., the Sears function) indicate that these simplified models, or assumptions equating aerodynamic forces with quasi-steady values, are inaccurate for the studied cross-sections. Considering the influence of the curved arch axis on buffeting behavior, a buffeting analysis computational program was developed, incorporating the experimentally derived aerodynamic characteristics. The program was validated against classical theoretical results and practical measurements from an actual bridge project. Using this program, a parametric analysis was conducted to evaluate the effects of equivalent AAF formulations, coherence functions, first-order mode shapes, and the number of structural modes on the buffeting response. The results show that the buffeting response of cantilevered hollow steel arch ribs is predominantly governed by the first-order mode, which can be effectively approximated using a bending-type mode shape expression. Full article

The static performances of an assembled integral two-way multi-ribbed composite floor system have been studied experimentally and numerically, while the dynamic characteristics and comfort analysis under a human load have not been investigated. In this article, a 9.2 m × 9.2 m floor system, composed of 16 precast panels and integrated into a whole structure through six wet joints, was designed and tested under pedestrian loads. Dynamic performances related to its natural frequencies, vibration mode shapes, and maximum acceleration were analyzed. Theoretical formulas were proposed to predict its natural frequency and maximum acceleration under a single-person load. It was found that the dynamic behavior of this innovative floor system meets the requirements of GB50010-2010 and ISO 2631. Elastic plate theory could be applied to predict the natural frequency and acceleration, with the bending stiffness obtained from the experiment. Some design and dynamic test suggestions for this floor system and similar structures are proposed based on a parametric analysis. Full article

Orthotropic Steel Bridge Decks (OSBDs) are often used in long-span bridges due to their high performance and ease of installation. However, issues such as fatigue cracking and the deterioration of asphalt overlays due to their local stiffness inefficiency necessitate innovative solutions. Orthotropic Steel–Ultra-High-Performance Concrete Composite Bridge Decks (OS-UHPC-CBDs) have enhanced OSBD performance; however, they have disadvantages such as a heavier weight and high initial cost requirements. In this study, an Orthotropic Steel–Lightweight Ultra-High-Performance Concrete Composite Bridge Deck (OS-LUHPC-CBD) is proposed as a solution that integrates a novel Lightweight Ultra-High-Performance Concrete (LUHPC) with a high-strength Q425 steel deck and trapezoidal ribs. A comprehensive experimental investigation, including full-scale four-point bending tests, was undertaken to evaluate the flexural behavior of the proposed OS-LUHPC-CBD compared to the OS-UHPC-CBD. The experimental results show that the proposed OS-LUHPC-CBD has equivalent flexural capacity and improved ductility compared to the OS-UHPC-CBD. This study found the proposed OS-LUHPC-CBD to be a promising solution for application in long-span bridges with an 8.4% lighter weight and a 6.8% lower cost, and with the same ease of construction as OS-UHPC-CBDs. A finite element model with a strong correlation was developed and validated through the experimental results. Based on this, a parametric study was undertaken on the effect of the key geometric design parameters on the flexural capacity of the OS-LUHPC-CBD. Full article

Air ribs are the critical components of tents. Ten air ribs were designed to study the influence of rise–span ratios on load-bearing performance and explore the failure mechanism. According to the maximum stress that appears at the top and bending regions of the rib, the ribs can be divided into an upright region and an arc-like region. So, a segmentation failure competition mechanism was proposed. In order to enhance the bearing performance, the upright region and arc-like region should be designed to fail at the same time. For the rib named 0.333-S, the stress distributes uniformly and the critical load is 2.62 ${\mathrm{kN}/\mathrm{m}}^2$; the upright region and arc-like region fail at the same time. For the rib named 0.5-S/R, the critical load is 1.465 ${\mathrm{kN}/\mathrm{m}}^2$, and it fails at the upright region, resulting in a reduction of 44%. The tent with ribs named 0.333-S shows better resistance performance against wind load, and the end ribs of this tent deform less. Its maximum displacement is 0.112 m, which is reduced by 65.8% compared with that of the original upright arch tent. Full article

The double-layered cylindrical shell represents a key structural configuration for underwater vehicles, where its vibration behavior remains a primary concern in engineering design and analysis. This study develops a spectral element method (SEM) for dynamic modeling of multi-component shell systems by extending the vibrational governing equations of conical shells. The methodology is validated through finite element method (FEM) case studies on both conical shells and double-layered cylindrical configurations. Parametric investigations examine ribbed substructures and solid rib plates within the cylindrical shell assembly, while artificial spring techniques model arbitrary boundary conditions—with validation against classical benchmarks confirming their effectiveness for elastic constraints. Numerical demonstrations reveal the following: rib and plate thickness variations exhibit a negligible impact on low-frequency vibrational responses; the natural frequency sensitivity peaks when the elastic boundary stiffness approaches the inherent dynamic stiffness of the shell’s base configuration, while extreme stiffness values approximate clamped or free boundary conditions with engineering significance. The proposed SEM framework demonstrates a superior computational efficiency and accuracy compared to conventional FEM approaches. These findings deliver practical guidance for marine structural engineering, particularly in the boundary condition specifications and performance optimization of composite shell systems. Full article

This study investigates the bending behavior of steel-ribbed composite slabs for a 500 kV substation project in China through numerical simulation. The unidirectional bending performance of the slab was first analyzed and validated against theoretical calculations. After that, the bidirectional bending performance of double-spliced and triple-spliced composite slabs were evaluated against the monolithic slab, followed by a parametric analysis to identify the influence of key factors. The results indicate that the steel-ribbed composite slabs feature high cracking strength, post-crack stiffness, bearing capacity, and commendable ductility under both unidirectional and bidirectional loading conditions. Under unidirectional loading, the ultimate capacity of the slab reaches 57–58 kN/m². Under bidirectional loading, the cracking load and bearing capacity of the dense-splicing composite slabs increase by more than 60% compared with unidirectional loading. Composite and monolithic slabs exhibit similar crack patterns and ultimate capacities under bidirectional loading; however, the presence of splicing joints results in a slight increase in the ultimate deflection of the double-spliced and triple-spliced composite slabs by 7.53% and 7.75% compared with that of the monolithic slab. The ratio of prestressing steel is identified as the most critical parameter for failure control, followed by the concrete strength. When the strength of the joint-connecting rebars exceeds 235 MPa and the diameter is greater than 4 mm, transversal force transfer across the joints is reliable. This paper provides valuable insights and practical guidance for the prefabricated construction of substations. Full article

In order to solve the problems of high production cost and complex control of the inverted arch of an unsupported prestressed concrete composite slab, a flange truss high-ductility concrete composite slab floor is proposed to change the structure and pouring material to meet the requirements of no support during construction. The crack distribution and bending performance of the flange truss high-ductile concrete composite slab floor (CRHDCS) under different structures are clarified through the test and numerical analysis of four different rib plate structure floors. According to the analysis results, the calculation formulas of the cracking moment and short-term stiffness before cracking are modified, and the equivalent short-term stiffness formula of a single web member of the “V” truss to this kind of bottom plate is established. The results show that, unlike the short-term stiffness-change law of typical concrete composite slabs after cracking, the short-term stiffness of the designed bottom plate in this paper includes a short-term increase stage. The numerical simulation results are the same as the experimental ones; the maximum error is 10%. The maximum errors between the modified cracking moment and the short-term stiffness calculation formula are 6% and 8%, respectively. The influence rates of removing flange plate, truss-inverted binding, and adding rib plate on the cracking bending moment of foundation structure are −81.5%, 11.0%, and 22.2% respectively, and the influence rates on short-term stiffness are −87.6%, −1.5%, and 37.5% respectively. Full article

Prestressed, precast composite panels are a type of building component that combines prestressing technology with composite materials; but, for most of them, it is difficult to balance structural stress performance and assembly efficiency. This paper proposes a series of novel bidirectional, prestressed, prefabricated, composite slabs, aiming to enhance their bidirectional force characteristics and assembly efficiency. By implanting a kind of specially designed concrete movable core rib with the same geometry as the cavity in the hollow-core slab at medium spacing, the transverse stressing performance of the structure is enhanced without affecting the unidirectional structural performance. Then, in the pre-set transverse apertures, several pieces of unidirectional, prestressed, precast hollow-core slabs that are implanted in the core mold are connected in series with high-strength strands and prestressed; finally, we obtain a bidirectional, prestressed, prefabricated composite slab. Two types of slabs (i.e., 3.3 m × 4.5 m and 4.5 m × 4.5 m) are selected and their mechanical behavior is investigated experimentally and by the finite element method, and the results are in good agreement. The proposed bidirectional, prestressed, precast composite slab not only has better overall bearing performance but also improves the structural stiffness and assembly rate, which can greatly improve the economic benefits and is of great significance for the popularization and application of assembled concrete structures. Full article

The transport of freshly post-harvested fruit to its collection point is mainly achieved using trailers over uneven terrain, which generates impacts and vibrations that negatively affect the quality of the fruit. Although some solutions to mitigate these effects have been proposed in previous studies, none of them are applied directly to the source of the problem, i.e., the transport boxes. In this context, metamaterial sheets inspired by the design of quasi-zero stiffness isolators (QZSs) open up the possibility of exploring ways of vibration isolation thanks to their associated nonlinear characteristics. In this work, ABS sheets with different internal geometries were manufactured and compared as possible bottoms of transport boxes. Vibration reduction not only protects the physical integrity of the fruit, avoiding visible damage such as bumps or bruises, but also preserves its chemical properties, such as texture and freshness, which directly impacts its shelf life and presentation for sale. The design variables analyzed for these geometries included the number of ribs, their thickness and their angle of inclination. In these specimens, their behavior to impact-type forces and their experimental dynamic behavior were studied using an electromagnetic shaker against a sinusoidal signal and against the uniaxial vibration recorded at the base of a trailer in a real rural route. The results showed that the specimens with a rib angle of 30° and a thickness of 0.4 mm showed the best impact performance and a higher amplification of vibration transmissibility in the steady state. In the presence of the signal recorded on the route, transmissibility reduction percentages between 13% and 19% were obtained in the principal acceleration impact. Full article

To achieve the assembled connection between dovetail profiled steel sheets and the boundary members in dovetail profiled steel concrete composite shear walls (DPSCWs), self-tapping screws were employed. Three DPSCW specimens connected with self-tapping screws were tested under combined axial and cyclic lateral loads to evaluate their hysteretic response, focusing on the influence of the number of self-tapping screws and the axial compression ratio. The self-tapping screw-connected DPSCWs exhibited a mixed failure mode, characterized by shear failure of the profiled steel sheets and compression-bending failure of multiple wall limbs divided by ribs on the web concrete. Except for slight deformation at the screw holes located on the profiled sheets at the corners of the wall, the connections exhibited minimal visible damage. The yield drift ratio of the DPSCW specimens in the test ranged from 1/286 to 1/225, and the ultimate drift ratio ranged from 1/63 to 1/94, both meeting the relevant deformation standards specified in the “Code for Seismic Design of Buildings. Increasing the number of self-tapping screws enhanced the development of local tensile fields on the profiled steel sheets, thereby improving the wall’s load-carrying, deformation, and energy dissipation capacities. However, increasing the axial compression ratio improved the initial stiffness of DPSCWs but reduced their load bearing and deformation capacity. Moreover, a design method for the self-tapping screw connections in DPSCWs was proposed. Full article

Background/Objectives: Spinal flexibility radiographs are important in adolescent idiopathic scoliosis (AIS) for clinical decision-making. In this study, we introduce a new method, the ‘quantitatively controlled standing fulcrum side-bending’ test (CSFS test). This is a feasibility study; we aimed to quantify the applied force and track the temporospatial changes in the spine specifically by measuring the continuous change in the Cobb angle (in degrees) during lateral bending. Methods: In this cross-sectional study, we included patients with AIS. Using a low-dose cinematic fluoroscopic technique, we captured the lateral bending of the thoracolumbar vertebral spine while inducing quantified lateral force on the ribs by a force gauge in a three-point fixation setup of controlled lateral bending. Trial registration number: H-1703423. Results: Twenty-one patients with small-curve AIS were included as subjects. All subjects performed the CSFS test adequately. They had small curves with a mean Cobb angle of 12.0 (range: 0.0–26.0, SD: 7.1). The measured median stiffness was 3.66 N/degrees (°) of the Cobb angle (range: 0.02–11.81) with a median coefficient of determination R² of 0.58 (range: 0.002–0.92) by regression analyses. When analysed concerning the median-term clinical outcome of either progression/regression or stationary curves, various Cobb angle measurements and the other experimental parameters, there were no significant relationships. Conclusions: The CSFS test is feasible to quantify the force applied and the temporospatial changes in the spine during lateral bending. The CSFS test has been utilised in basic research for mechanical characterisation of the scoliotic spine and has the potential of being implemented directly in patient-specific bracing to estimate the forces needed for brace correction and adjustment so as not to supersede the allowed skin pressure. Full article
