Search Results (15)

In order to improve the current standard of analysis-ready Synthetic Aperture Radar (SAR) backscatter data, we introduce a machine learning-based approach to estimate the slope of the backscatter–incidence angle relationship from several backscatter statistics. The method requires information from radiometric terrain-corrected gamma nought time series and overcomes the constraints of a limited orbital coverage, as exemplified with the Sentinel-1 constellation. The derived slope estimates contain valuable information on scattering characteristics of different land cover types, allowing for the correction of strong forward-scattering effects over water bodies and wetlands, as well as moderate surface scattering effects over bare soil and sparsely vegetated areas. Comparison of the estimated and computed slope values in areas with adequate orbital coverage shows good overall agreement, with an average RMSE value of 0.1 dB/° and an MAE of 0.05 dB/°. The discrepancy between RMSE and MAE indicates the presence of outliers in the computed slope, which are attributed to speckle and backscatter fluctuations over time. In contrast, the estimated slope excels with a smooth spatial appearance. After correcting backscatter values by normalising them to a certain reference incidence angle, orbital artefacts are significantly reduced. This becomes evident with differences up to 5 dB when aggregating the normalised backscatter measurements over certain time periods to create spatially seamless radar backscatter composites. Without being impacted by systematic differences in the illumination and physical properties of the terrain, these composites constitute a valuable foundation for land cover and land use mapping, as well as bio-geophysical parameter retrieval. Full article

In this study, we used Spanish National Forest Inventory (SNFI) data, Sentinel-2 imagery and ancillary data to develop models that estimate forest variables for major commercial timber plantations in northern Spain. We carried out the analysis in two stages. In the first stage, we considered plots with and without sub-meter geolocation, three pre-processing levels for the Sentinel-2 images and two machine learning algorithms. In most cases, geometrically, radiometrically, atmospherically and topographically (L2A-ATC) corrected images and the random forest algorithm provided the best results, with topographic correction producing a greater gain in model accuracy as the average slope of the plots increased. Our results did not show any clear impact of the geolocation accuracy of SNFI plots on results, suggesting that the usual geolocation accuracy of SNFI plots is adequate for developing forest models with data obtained from passive sensors. In the second stage, we used all plots together with L2A-ATC-corrected images to select five different groups of predictor variables in a cumulative process to determine the influence of each group of variables in the final RF model predictions. Yield variables produced the best fits, with R² ranging from 0.39 to 0.46 (RMSE% ranged from 44.6% to 61.9%). Although the Sentinel-2-based estimates obtained in this research are less precise than those previously obtained with Airborne Laser Scanning (ALS) data for the same species and region, they are unbiased (Bias% was always below 1%). Therefore, accurate estimates for one hectare are expected, as they are obtained by averaging the values of 100 pixels (model resolution of 10 m pixel⁻¹) with an expected error compensation. Moreover, the use of these models will overcome the temporal resolution problem associated with the previous ALS-based models and will enable annual updates of forest timber resource estimates to be obtained. Full article

Operational applications for Synthetic Aperture Radar (SAR) are under development around the world, driven by the free-and-open access of SAR C-band observations that Sentinel-1 of Copernicus has provided since 2014. Radiometric Terrain Correction (RTC) data are key entry-level products for multiple applications ranging from ecosystem to hazard monitoring. Various open-source software packages exist to create RTC products from Single Look Complex (SLC) or Ground Range Detected (GRD) level SAR data, including the Interferometric SAR Computing Environment (ISCE), and the Sentinel-1 Toolbox from the European Space Agency (SNAP 8). Despite the growing availability of RTC software solutions, little work has been performed to identify differences between RTC products generated using different software packages. This work evaluates several Sentinel-1 RTC products and two other Sentinel-1 Analysis Ready Data (ARD) to address the following questions: (1) Which software provides the most accurate RTC product? and (2) how appropriate for analysis are other non-RTC products that are readily available? The RTCs are produced with GAMMA, ISCE-2, and SNAP 8. The other two ARD products evaluated consisted of an angular-based radiometric slope correction produced in Google Earth Engine (GEE) following Vollrath et al., and the Sentinel-1 GRD product. Products are evaluated across 10 sites in a single image approach for (1) radiometric calibration, (2) geometric corrections, and for (3) geolocation quality. In addition, time-series stacks over two sites representing varied terrain and ecosystems are evaluated. The GAMMA-derived RTC product implemented by the Alaska Satellite Facility (ASF) is used as a reference for some of the time-series metrics. The results provide direct guidance and recommendations about the quality of the RTC and ARD products obtained from open source methods. The results indicate that it is not recommended to use the GRD product with no radiometric or geometric corrections for any applications given low performance in multiple metrics. The radiometric calibration and geometric corrections have overall good performance for all open-source solutions, only the non-RTC products (Vollrath et al. and GRD) portray some significant variances in steep terrain. The geolocation assessment indicated that the GRD product has the most significant displacement errors, followed by SNAP 8 with Digital Elevation Model (DEM) matching, and ISCE-2. RTCs created without DEM-matching performed better for both GAMMA and SNAP 8. The time-series results indicate that SNAP 8 products align more closely to GAMMA products than other open-source software in terms of radiometric and geometric quality. This understanding of software performance for SAR image processing is key to designing the affordable and scalable solutions needed for the operational application of SAR Sentinel-1 data. Full article

In the Central Himalayas, glaciers and snowmelt play an important hydrological role, as they ensure the availability of surface water outside the monsoon period. To compensate for the lack of field measurements in glaciology and hydrology, high temporal and spatial resolution optical remotely sensed data are necessary. The French–Israeli VENµS Earth observation mission has been able to complement field measurements since 2017. The aim of this paper is to evaluate the performance of different reflectance products over the Everest region for constraining the energy balance of glaciers and for cloud and snow cover mapping applied to hydrology. Firstly, the results indicate that a complete radiometric correction of slope effects such as the Gamma one (direct and diffuse illumination) provides better temporal and statistical metrics (R² = 0.73 and RMSE = 0.11) versus ground albedo datasets than a single cosine correction, even processed under a fine-resolution digital elevation model (DEM). Secondly, a mixed spectral-textural approach on the VENµS images strongly improves the cloud mapping by 15% compared with a spectral mask thresholding process. These findings will improve the accuracy of snow cover mapping over the watershed areas downstream of the Everest region. Full article

Low-frequency tomographic synthetic aperture radar (TomoSAR) techniques provide an opportunity for quantifying the dynamics of dense tropical forest vertical structures. Here, we compare the performance of different TomoSAR processing, Back-projection (BP), Capon beamforming (CB), and MUltiple SIgnal Classification (MUSIC), and compensation techniques for estimating forest height (FH) and forest vertical profile from the backscattered echoes. The study also examines how polarimetric measurements in linear, compact, hybrid, and dual circular modes influence parameter estimation. The tomographic analysis was carried out using P-band data acquired over the Paracou study site in French Guiana, and the quantitative evaluation was performed using LiDAR-based canopy height measurements taken during the 2009 TropiSAR campaign. Our results show that the relative root mean squared error (RMSE) of height was less than 10%, with negligible systematic errors across the range, with Capon and MUSIC performing better for height estimates. Radiometric compensation, such as slope correction, does not improve tree height estimation. Further, we compare and analyze the impact of the compensation approach on forest vertical profiles and tomographic metrics and the integrated backscattered power. It is observed that radiometric compensation increases the backscatter values of the vertical profile with a slight shift in local maxima of the canopy layer for both the Capon and the MUSIC estimators. Our results suggest that applying the proper processing and compensation techniques on P-band TomoSAR observations from space will allow the monitoring of forest vertical structure and biomass dynamics. Full article

This article provides an angular-based radiometric slope correction routine for Sentinel-1 SAR imagery on the Google Earth Engine platform. Two established physical reference models are implemented. The first model is optimised for vegetation applications by assuming volume scattering on the ground. The second model is optimised for surface scattering, and therefore targeted at urban environments or analysis of soil characteristics. The framework of both models is extended to simultaneously generate masks of invalid data in active layover and shadow affected areas. A case study, using openly available and reproducible code, exemplarily demonstrates the improvement of the backscatter signal in a mountainous area of the Austrian Alps. Furthermore, suggestions for specific use cases are discussed and drawbacks of the method with respect to pixel-area based methods are highlighted. The radiometrically corrected radar backscatter products are overcoming current limitations and are compliant with recent CEOS specifications for SAR backscatter over land. This improves a wide range of potential usage scenarios of the Google Earth Engine platform in mapping various land surface parameters with Sentinel-1 on a large scale and in a rapid manner. The provision of an openly accessible Earth Engine module allows users a smooth integration of the routine into their own workflows. Full article

The radiometric resolution of a satellite sensor refers to the smallest increment in the spectral radiance that can be detected by the imaging sensor. The fewer bits that are used for signal discretization, the larger the quantization error in the measured radiance. In satellite inter-calibration, a difference in radiometric resolution between a reference and a target sensor can induce a calibration bias, if not properly accounted for. The effect is greater for satellites with a quadratic count response, such as the Geostationary Meteorological Satellite-5 (GMS-5) visible imager, where the quantization difference can introduce non-linearity in the inter-comparison datasets, thereby affecting the cross-calibration slope and offset. This paper describes a simulation approach to highlight the importance of considering the radiometric quantization in cross-calibration and presents a correction method for mitigating its impact. The method, when applied to the cross-calibration of GMS-5 and Terra Moderate Resolution Imaging Spectroradiometer (MODIS) sensors, improved the absolute calibration accuracy of the GMS-5 imager. This was validated via radiometric inter-comparison of GMS-5 and Multifunction Transport Satellite-2 (MTSAT-2) imager top-of-atmosphere (TOA) measurements over deep convective clouds (DCC) and Badain Desert invariant targets. The radiometric bias between GMS-5 and MTSAT-2 was reduced from 1.9% to 0.5% for DCC, and from 7.7% to 2.3% for Badain using the proposed correction method. Full article

The Eastern Lagoon of New Caledonia (ELNC) is a semi-enclosed system surrounded by an extensive coral reef barrier. The system has been suffering impacts from climate variability and anthropogenic activities, including mining exploitation. Satellite monitoring is thus an essential tool to detect such changes. The present study aimed to assess the bio-optical variability of the ELNC and examine the applicability of ocean colour algorithms, using in situ bio-optical and radiometric data, collected during the March 2014 CALIOPE 2 cruise. The chlorophyll a concentration (Chla) varied from 0.13–0.72 mg·m⁻³, and the coastal stations were spectrally dominated by non-algal particles (NAP) and coloured dissolved organic matter (CDOM) (>80% of the total non-water absorption at 443 nm), due to the contribution of allochthonous sources. The phytoplankton specific absorption was generally lower (mean, 0.049 m²·mg Chla⁻¹) than typical values observed for the corresponding Chla range, as well as the spectral slopes of the absorption of CDOM plus NAP (a_dg) (mean, 0.016 nm⁻¹) and of the particle backscattering coefficient (b_bp) (mean, 0.07 nm⁻¹). The remote sensing reflectance obtained using two in-water approaches and modelled from Inherent Optical Properties (IOPs) showed less than 20% relative percent differences (RPD). Chla estimates were highly biased for the empirical (OC4 and OC3) and semi-analytical (GSM, QAA, GIOP, LMI) algorithms, especially at the coastal stations. Excluding these stations, the GSM01 yielded the best retrievals with 35–40% RPD. a_dg(443) was well retrieved by all algorithms with ~18% RPD, and b_bp(443) with ~40% RPD. Turbidity algorithms also performed reasonably well (30% RPD), showing the capacity and usefulness of the derived products to monitor the water quality of the ELNC, provided accurate atmospheric correction of the satellite data. Regionally tuned algorithms may potentially improve the Chla retrievals, but better parameterization schemes that consider the spatiotemporal variability of the specific IOPs are still needed. Full article

Sentinel-2 is a constellation of two satellites launched by the European Space Agency (ESA), respectively on 23 June 2015 and 7 March 2017, to map geophysical parameters over land surfaces. ESA provides Level 2 bottom-of-atmosphere reflectance (BOA) products (ESA-L2A) for Europe, with plans for operational global coverage, as well as the Sen2Cor (S2C) offline processor. In this study, aerosol optical thickness (AOT), precipitable water vapour (WVP) and surface reflectance from ESA-L2A products are compared with S2C output when using identical input Level 1 radiance products. Additionally, AOT and WVP are validated against reference measurement. As ESA and S2C share the same input and atmospheric correction algorithm, it was hypothesized that they should show identical validation performance and that differences between products should be negligible in comparison to the uncertainty of retrieved geophysical parameters due to radiometric uncertainty alone. Validation and intercomparison was performed for five clear-sky growing season dates for each of three ESA-L2A tiles selected to span a range of vegetation and topography as well as to be close to the AERONET measurement site. Validation of S2C (ESA) products using AERONET site measurements indicated an overall root mean square error (RMSE) of 0.06 (0.07) and a bias of 0.05 (0.09) for AOT and 0.20 cm (0.22 cm) and the bias was −0.02 cm (−0.10 cm) for WVP. Intercomparison of S2C-L2A and ESA-L2A showed an overall agreement higher than 99% for scene classification (SCL) maps and negligible differences for WVP (RMSE under 0.09 and R² above 0.99). Larger disagreement was observed for aerosol optical thickness (AOT) (RMSE up to 0.04 and R² as low as 0.14). For BOA reflectance, disagreement between products depends on vegetation cover density, topography slope and spectral band. The largest differences were observed for red-edge and infrared bands in mountainous vegetated areas (RMSE up to 4.9% reflectance and R² as low as 0.53). These differences are of similar magnitude to the radiometric calibration requirements for the Sentinel 2 imager. The differences had minimal impact of commonly used vegetation indices (NDVI, NDWI, EVI), but application of the Sentinel Level 2 biophysical processor generally resulted in proportional differences in most derived vegetation parameters. It is recommended that the consistency of ESA and S2C products should be improved by the developers of the ESA and S2C processors. Full article

We evaluate the capability of three different digital image correlation (DIC) algorithms to measure long-term surface displacement caused by a large slope instability in the Swiss Alps. DIC was applied to high-resolution optical imagery taken by airborne sensors, and the accuracy of the displacements assessed against global navigation satellite system measurements. A dynamic radiometric correction of the input images prior to DIC application was shown to enhance both the correlation success and accuracy. Moreover, a newly developed spatial filter considering the displacement direction and magnitude proved to be an effective tool to enhance DIC performance and accuracy. Our results show that all algorithms are capable of quantifying slope instability displacements, with average errors ranging from 8 to 12% of the observed maximum displacement, depending on the DIC processing parameters, and the pre- and postprocessing of the in- and output. Among the tested approaches, the results based on a fast Fourier transform correlation approach provide a considerably better spatial coverage of the displacement field of the slope instability. The findings of this study are relevant for slope instability detection and monitoring via DIC, especially in the context of an ever-increasing availability of high-resolution air- and spaceborne imagery. Full article

The presence of aerosol has resulted in serious limitations in the data coverage and large uncertainties in retrieving carbon dioxide (CO₂) amounts from satellite measurements. For this reason, an aerosol retrieval algorithm was developed for the Thermal and Near-infrared Sensor for carbon Observation-Cloud and Aerosol Imager (TANSO-CAI) launched in January 2009 on board the Greenhouse Gases Observing Satellite (GOSAT). The algorithm retrieves aerosol optical depth (AOD), aerosol size information, and aerosol type in 0.1° grid resolution by look-up tables constructed using inversion products from Aerosol Robotic NETwork (AERONET) sun-photometer observation over Northeast Asia as a priori information. To improve the accuracy of the TANSO-CAI aerosol algorithm, we consider both seasonal and annual estimated radiometric degradation factors of TANSO-CAI in this study. Surface reflectance is determined by the same 23-path composite method of Rayleigh and gas corrected reflectance to avoid the stripes of each band. To distinguish aerosol absorptivity, reflectance difference test between ultraviolet (band 1) and visible (band 2) wavelengths depending on AODs was used. To remove clouds in aerosol retrieval, the normalized difference vegetation index and ratio of reflectance between band 2 (0.674 μm) and band 3 (0.870 μm) threshold tests have been applied. To mask turbid water over ocean, a threshold test for the estimated surface reflectance at band 2 was also introduced. The TANSO-CAI aerosol algorithm provides aerosol properties such as AOD, size information and aerosol types from June 2009 to December 2013 in this study. Here, we focused on the algorithm improvement for AOD retrievals and their validation in this study. The retrieved AODs were compared with those from AERONET and the Aqua/MODerate resolution Imaging Sensor (MODIS) Collection 6 Level 2 dataset over land and ocean. Comparisons of AODs between AERONET and TANSO-CAI over Northeast Asia showed good agreement with correlation coefficient (R) 0.739 ± 0.046, root mean square error (RMSE) 0.232 ± 0.047, and linear regression line slope 0.960 ± 0.083 for the entire period. Over ocean, the comparisons between Aqua/MODIS and TANSO-CAI for the same period over Northeast Asia showed improved consistency, with correlation coefficient 0.830 ± 0.047, RMSE 0.140 ± 0.019, and linear regression line slope 1.226 ± 0.063 for the entire period. Over land, however, the comparisons between Aqua/MODIS and TANSO-CAI show relatively lower correlation (approximate R = 0.67, RMSE = 0.40, slope = 0.77) than those over ocean. In order to improve accuracy in retrieving CO₂ amounts, the retrieved aerosol properties in this study have been provided as input for CO₂ retrieval with GOSAT TANSO-Fourier Transform Spectrometer measurements. Full article

In recent decades, most methods proposed for radiometric slope correction involved the backscattering intensity values in synthetic aperture radar (SAR) data. However, these methods are not fully applicable to quad-polarimetric SAR (PolSAR) matrix data. In this paper, we propose a three-step semi-empirical radiometric terrain correction approach for PolSAR forest area data. The three steps of terrain effects correction are: polarisation orientation angle (POA), effective scattering area (ESA), and angular variation effect (AVE) corrections. We propose a novel method to determine adaptively the “n” value in the third step by minimising the correlation coefficient between corrected backscattering coefficients and the local incidence angle; we then constructed the correction coefficients matrix and used it to correct PolSAR matrix data. PALSAR-2 HBQ (L-band, quad-polarisation) data were used to verify the proposed method. After three-step correction, differences between front and back slopes were significantly reduced. Our results indicate that POA, ESA, and AVE corrections are indispensable steps to producing PolSAR data. In the POA correction step, horizontal–vertical (HV) polarisation was maximally influenced by the POA shift. The max deviation of the POA correction was greater than 1 dB for HV polarisation and approximately 0.5 dB for HH/VV polarisation at an intermediate shift angle (±20°). Based on Light Detection and Ranging (LiDAR)-derived forest aboveground biomass (AGB) data, we analysed the relationship between forest AGB and backscattering coefficient; the correlation was improved following the terrain correction. HV polarisation had the best correlation with forest AGB (R = 0.81) and the correlation improved by approximately 0.3 compared to the uncorrected data. Full article

Solar radiation is affected by absorption and emission phenomena during its downward trajectory from the Sun to the Earth’s surface and during the upward trajectory detected by satellite sensors. This leads to distortion of the ground radiometric properties (reflectance) recorded by satellite images, used in this study to estimate aboveground forest biomass (AGB). Atmospherically-corrected remote sensing data can be used to estimate AGB on a global scale and with moderate effort. The objective of this study was to evaluate four atmospheric correction algorithms (for surface reflectance), ATCOR2 (Atmospheric Correction for Flat Terrain), COST (Cosine of the Sun Zenith Angle), FLAASH (Fast Line-of-sight Atmospheric Analysis of Spectral Hypercubes) and 6S (Second Simulation of Satellite Signal in the Solar), and one radiometric correction algorithm (for reflectance at the sensor) ToA (Apparent Reflectance at the Top of Atmosphere) to estimate AGB in temperate forest in the northeast of the state of Durango, Mexico. The AGB was estimated from Landsat 5 TM imagery and ancillary information from a digital elevation model (DEM) using the non-parametric multivariate adaptive regression splines (MARS) technique. Field reference data for the model training were collected by systematic sampling of 99 permanent forest growth and soil research sites (SPIFyS) established during the winter of 2011. The following predictor variables were identified in the MARS model: Band 7, Band 5, slope (β), Wetness Index (WI), NDVI and MSAVI2. After cross-validation, 6S was found to be the optimal model for estimating AGB (R² = 0.71 and RMSE = 33.5 Mg·ha⁻¹; 37.61% of the average stand biomass). We conclude that atmospheric and radiometric correction of satellite images can be used along with non-parametric techniques to estimate AGB with acceptable accuracy. Full article

Optical remotely sensed images in mountainous areas are subject to radiometric distortions induced by topographic effects, which need to be corrected before quantitative applications. Based on Li model and Sandmeier model, this paper proposed an improved physics-based model for the topographic correction of Landsat Thematic Mapper (TM) images. The model employed Normalized Difference Vegetation Index (NDVI) thresholds to approximately divide land targets into eleven groups, due to NDVI’s lower sensitivity to topography and its significant role in indicating land cover type. Within each group of terrestrial targets, corresponding MODIS BRDF (Bidirectional Reflectance Distribution Function) products were used to account for land surface’s BRDF effect, and topographic effects are corrected without Lambertian assumption. The methodology was tested with two TM scenes of severely rugged mountain areas acquired under different sun elevation angles. Results demonstrated that reflectance of sun-averted slopes was evidently enhanced, and the overall quality of images was improved with topographic effect being effectively suppressed. Correlation coefficients between Near Infra-Red band reflectance and illumination condition reduced almost to zero, and coefficients of variance also showed some reduction. By comparison with the other two physics-based models (Sandmeier model and Li model), the proposed model showed favorable results on two tested Landsat scenes. With the almost half-century accumulation of Landsat data and the successive launch and operation of Landsat 8, the improved model in this paper can be potentially helpful for the topographic correction of Landsat and Landsat-like data. Full article

Comparisons between in situ measurements of surface chlorophyll-a concentration (CHL) and ocean color remote sensing estimates were conducted during an oceanographic cruise on the Brazilian Southeastern continental shelf and slope, Southwestern South Atlantic. In situ values were based on fluorometry, above-water radiometry and lidar fluorosensor. Three empirical algorithms were used to estimate CHL from radiometric measurements: Ocean Chlorophyll 3 bands (OC3M_RAD), Ocean Chlorophyll 4 bands (OC4v4_RAD), and Ocean Chlorophyll 2 bands (OC2v4_RAD). The satellite estimates of CHL were derived from data collected by the MODerate-resolution Imaging Spectroradiometer (MODIS) with a nominal 1.1 km resolution at nadir. Three algorithms were used to estimate chlorophyll concentrations from MODIS data: one empirical - OC3M_SAT, and two semi-analytical - Garver, Siegel, Maritorena version 01 (GSM01_SAT), and Carder_SAT. In the present work, MODIS, lidar and in situ above-water radiometry and fluorometry are briefly described and the estimated values of chlorophyll retrieved by these techniques are compared. The chlorophyll concentration in the study area was in the range 0.01 to 0.2 mg·m^-3. In general, the empirical algorithms applied to the in situ radiometric and satellite data showed a tendency to overestimate CHL with a mean difference between estimated and measured values of as much as 0.17 mg/m³ (OC2v4_RAD). The semi-analytical GSM01 algorithm applied to MODIS data performed better (rmse 0.28, rmse-L 0.08, mean diff. -0.01 mg/m³) than the Carder and the empirical OC3M algorithms (rmse 1.14 and 0.36, rmse-L 0.34 and 0.11, mean diff. 0.17 and 0.02 mg/m³, respectively). We find that rmsd values between MODIS relative to the in situ radiometric measurements are < 26%, i.e., there is a trend towards overestimation of R_RS by MODIS for the stations considered in this work. Other authors have already reported over and under estimation of MODIS remotely sensed reflectance due to several errors in the bio-optical algorithm performance, in the satellite sensor calibration, and in the atmospheric-correction algorithm. Full article
