Improving outdoor thermal comfort is a critical objective in urban design, particularly in densely built urban environments. Elevated semi-open spaces—outdoor areas located beneath raised building structures—have been recognized for enhancing pedestrian comfort by improving airflow and shading. However, previous studies primarily focused on warm or temperate climates, leaving a significant research gap regarding their thermal performance in cold climate zones characterized by extreme seasonal variations. Specifically, few studies have investigated how these spaces perform under conditions typical of northern Chinese cities like Xi’an, which is explicitly classified within the Cold Climate Zone according to China’s national standard GB 50176-2016 and experiences both severe summer heat and cold winter conditions. To address this gap, we conducted field measurements and numerical simulations using the ENVI-met model (v5.0) to systematically evaluate the microclimatic performance of elevated ground-floor spaces in Xi’an. Key microclimatic parameters—including air temperature, mean radiant temperature, relative humidity, and wind velocity—were assessed during representative summer and winter conditions. Our findings indicate that the height of the elevated structure significantly affects outdoor thermal comfort, identifying an optimal elevated height range of 3.6–4.3 m to effectively balance summer cooling and winter sheltering needs. These results provide valuable design guidance for architects and planners aiming to enhance outdoor thermal environments in cold climate regions facing distinct seasonal extremes. Full article

While forced-air convective systems remain the predominant method for heating and cooling worldwide, radiant cooling and heating systems are emerging as a more efficient alternative. Current radiant cooling systems primarily rely on hydronic chilled water systems. This study introduces direct-expansion radiant cooling as a novel technique that could enhance the efficiency of radiant cooling and reduce its environmental impact. Water (R-718) has been tested as a refrigerant due to its favorable thermodynamic properties and environmental advantages; however, to the author’s knowledge, it has yet to be tested in direct-expansion radiant cooling. This research investigated several refrigerants, including water (R-718), ammonia (R-717), R-410a, R-32, R-134a, and R-1234yf, for this application. The findings indicate that water demonstrates efficiency comparable to other non-natural refrigerants, making it a promising candidate, given its favorable thermodynamic properties and substantial environmental benefits. Despite challenges such as a high compression ratio necessitating multi-stage compression, a high compressor discharge temperature exceeding 300 °C and requiring specialized blade materials, and a high suction volume flow rate, direct-expansion radiant cooling operates within a different temperature range. Consequently, the compressor discharge temperature can be reduced to 176 °C, and the compression ratio can be lowered to approximately 3.5, making water a more viable refrigerant option for this application. Full article

Radiant cooling floors combined with ventilation systems have been widely applied in large space buildings. However, there has been a lack of research on system control strategies for their adaptation to weather changes. This study aimed to find control strategies for radiant cooling floors combined with displacement ventilation systems used in large space buildings in order to achieve energy conservation and environmental improvement. Supply air temperature and cooling surface temperature were determined to be the control variables. It was found that cooling capacity of the combined system and the comfort index, PMV (predicted mean vote), were linear in relation to the supply air temperature and cooling surface temperature. The linear equations regarding cooling capacity and PMV were established separately using environment data, and then the optimal region was determined. A case study on Terminal 3 of Xi’an Xianyang International Airport was conducted. The thermal environment was investigated through on-site measurements, questionnaires, and numerical simulations with CFD (computational fluid dynamics). It was found that supply air temperature and cooling surface temperature had a significant impact on PMV, and less impact on the cooling capacity. Therefore, it was determined that the supply air temperature should be altered first when the indoor temperature exceeds the upper limit, and then the cooling surface temperature should be changed if the indoor environment continues to overheat with the supply air temperature set to 18 °C. Thus, the supply air temperature was kept at 18 °C, and the floor surface temperature was set to be 22 °C on a high-temperature day. The average PMV was 0.87, and the cooling capacity of the combined system was 200 W/(m²·K), according to the CFD simulation. In addition, the surface heat transfer coefficient of the cooling floor was found to be 10.26 W/(m²·K). This research provides important references for the design and operational management of radiant cooling floors in large space buildings. Full article

With the growing interest in radiant heating and cooling systems, driven by their improved efficiency and enhanced thermal comfort compared to air systems, there is an increasing need to develop a more accessible method for designers to understand the implications of radiation heat exchange between the human body and radiant panels. To address this, a novel angle factor calculation model, named the HNU Angle Factor Model, was developed, taking into account the spatial arrangement and geometric relationship between the human body and radiant panels. The angle factors obtained using the HNU Angle Factor Model exhibited good agreement with the results obtained with Fanger diagrams and the contour integral method, with average relative differences of 8.1% and 10.0% for 140 cases, respectively. Furthermore, placing a radiant panel on the floor while maintaining its fixed size can contribute to the creation of an even and efficient thermal environment for individuals in both seated and standing positions. By implementing the HNU Angle Factor Model in practical engineering applications, more effective utilization of radiant systems can be achieved, as it provides an evaluation of the heat transfer between the human body and radiant panels. Full article

Radiant floor heating systems have become a reference technology, but their use for cooling purposes has proven inconvenient in many applications due to their reduced cooling capacity and condensation issues. Nonetheless, potentialities and drawbacks of radiant floor cooling systems have been frequently addressed and simulated, given the large potential advantages of employing a single emissive system for all seasons. This paper aims to provide a comprehensive review of the modeling methods for radiant floor cooling systems proposed in scientific papers and also used in simulation software and technical standards. Models are classified according to their characterizing features, and the distinctive contributions of each method are discussed. Additionally, the modeling of the most relevant phenomena affecting floor performance is further discussed. The review revealed the presence of two main modeling classes, one only focusing on the floor’s conductive heat transfer and the other integrating active floor analysis within the building’s energy model of the thermal zone. Despite the presence of many modeling methods that are able to consider the most important effects in the radiant cooling system operation, not all the phenomena present in a practical application are fully described. Therefore, there is an ongoing need for more comprehensive, possibly easily characterizable, modeling approaches. Full article

In this study, a method is proposed to expand the utilization of an existing calculation model for a floor heat exchanger (HX) from room scale to small district scale. The model, namely Trnsys Type 653, is typically employed for the simulation of single or simultaneously controlled parallel heating circuits. It uses a simplified approach to calculate the heat exchange between fluid and screed, taking the HX effectiveness as an input. In order to calculate the effectiveness based on the HX design, fluid properties and mass flow rate, a Python model is developed to be coupled with Type 653. The results are compared to a reference finite element model set up in COMSOL^® and depend on the HX design. The highest deviations range from over 1 K for 35 min to over 2 K for 175 min, while the lowest deviations range from below 0.5 K to below 1 K. Furthermore, the simplification of the floor HX model is analyzed by summarizing heating circuits from single rooms to a whole flat and from single flats to a whole floor. This approach results in deviations of approximately 2 and 4%, respectively, in the overall transferred heat over longer periods of time, while the switch-on frequency of the controller in an exemplary day is halved. While further analysis is required, the described simplifications seem promising for detailed district simulations with relatively low computational effort. Full article

In most regions of southern China, condensation frequently occurs on building surfaces during the period from March to April. This phenomenon has been affecting people’s safety and structural properties. This article proposes an innovative anti-condensation floor system based on the reverse Carnot cycle. The evaporation side treats the air and reduces the moisture content, and the heat extracted from the condensation side is recovered by a heat exchanger and transferred to the floor through capillary mats. Simulation studies of the dynamic operation performance have been conducted through the TRNSYS 18 software. The results show that an innovative anti-condensation floor system can effectively keep the floor dry in Guilin. At the same time, regarding the indoor comfort level index, the PMV value is within ±0.5, and the energy consumption of the system is 42% less than that of the cooling dehumidification system. The system also performs well in representative cities where the air moisture content is less than 12 g/kg. This article also provides a reference for the feasibility of radiant floor systems in humid climate areas. Full article

The combined radiant floor and fan coil cooling (RFCAFC) system is widely used due to its high comfort and large energy saving potential. In this study, as an example, the combined RFCAFC system was studied in a high humidity environment in Jinan, Shandong Province, China. The novelty of the combined RFCAFC system lies in its ability to automatically adjust the water supply temperature of the radiant floor and fan coil in real time according to outdoor meteorological conditions, achieving thermal comfort while eliminating the likelihood of condensation on the radiant floor surface. Days with similar outdoor meteorological conditions were grouped, and the comfort level and hourly cooling performance coefficient (EER_h) of different operating strategies for different outdoor meteorological conditions were monitored along with other evaluation indicators. The RFCAFC had good energy efficiency and comfort in a high humidity room environment. This study showed that the indoor vertical air temperature difference ranged from 1.6 to 1.8 °C, which met the ASHRAE55-2017 standard. The radiant floor surface temperature uniformity coefficient (S) fluctuated between 0.7 and 1.0, and the time it took the radiant floor surface temperature to reach 63.2% of the total variability range (τ₆₃) for different operation strategies based on different outdoor meteorological conditions ranged between 4.4 and 4.7 h, which was within the normal range. The proportion of the total cooling capacity contributed by fan coil cooling under low temperature and high humidity (LH), high temperature and low humidity (HL), and medium temperature and medium humidity (MM) were 68.0%, 73.8%, and 71.7%, respectively. Based on this study, the following recommendations for the combined cooling system can be made: (1) When the outdoor humidity is high, the radiant floor system should be turned on early to provide cooling capacity. When the outdoor temperature is high, the fan coil system should be turned on early to reduce the indoor temperature. (2) To reduce energy consumption and achieve efficient operation of the system, the radiant floor system should be continuously operated to maximize its contribution to the cooling capacity, while the fan coil can be operated intermittently. Natural cooling can be integrated to provide additional cooling capacity to the room in the hours preceding occupation (i.e., 7:00–9:00). (3) The operation strategy of the combined cooling system must be able to respond in real time to changes in outdoor meteorological conditions to prevent discomfort in times of extreme heat or humidity. Full article

The increasing application of floor heating technology promotes the development of floor radiant cooling technology (abbreviated as FRC technology). Many office buildings in northern China try to use FRC technology to cool in summer, but thermal comfort is the key problem restricting the promotion of this technology. The thermal comfort problems of an office room with floor radiant cooling were studied in this paper by the methods of numerical simulation, control variable, and data fitting, and the experimental results were verified in multiple ways. It was found that, for an office room using floor radiant cooling, the effect of the floor surface temperature on thermal comfort was about 16%, while the effect of indoor air temperature was about 84%, and relative humidity had little effect on thermal comfort. A simplified thermal comfort calculation model was proposed, which could be used as an indicator to adjust the floor surface and indoor air temperature, or could be used to calculate the PMV-PPD value. The findings have guiding significance for the design and control of FRC technology. Full article

A focus on indoor comfort and tightening targets for energy savings in buildings presents new opportunities for heating, ventilation, and air-conditioning products (HVAC). This paper presents a novel comfort solution that integrates a suspended radiant ceiling with diffuse ventilation, dubbed HVACeiling. In combination with the concrete slab, the HVACeiling has the potential to provide thermal comfort with minimal temperature offset, which supports operation of the heating and cooling system at temperatures very close to the room comfort temperature. The paper presents a parametric numerical study of the concept in a simplified two-pipe layout with fixed flow and fixed temperatures. First, the analysis was focused on different internal and solar loads, heat losses, and climatic locations with the aim of assessing the potential of self-regulation, i.e., no active controls, thermal comfort, ability to reduce peak loads and the consequential building design considerations. Secondly, the purpose was to analyse the concept in a generic office building with five offices and one meeting room and compare it to other HVAC solutions. The whole-year analyses of heating, cooling, energy performance, and thermal comfort were done using the building performance simulation software IDA ICE. It was found that it was possible to create thermal comfort in Paris, Munich, and Copenhagen with water circulating constantly with fixed temperatures of 20–24 °C without controls and with window sizes from 15 to 30% of the floor area. The studies showed that the HVACeiling reduced the operative peak temperatures on the warmest days in comparison with a standard radiant ceiling with mixing ventilation by 1 K. Compared to all-air solutions, the HVACeiling reduced the yearly energy consumption by 20–30% and the peak power in summer up to 69%. This study indicates that thermal comfort is achievable in a European context even at very small temperature offsets, which supports the use of more renewable energy sources. Full article

The radiant floor system market is growing rapidly because Europe is moving toward a low-carbon economy and increased awareness about environmental sustainability and energy efficiency, stimulated by the ambitious EU Energy Efficient Directive and nZEB challenge. The high growth rate of the market share is due to the involvement of homeowners in the specifications of their living commodities, so they are thus willing to invest more at the initial stage to obtain long-term benefits and lower energy exploration costs. We performed an experimental campaign over three slabs with a hydronic radiant floor system of equal dimensions, shape, and pipe pitch with different screed mortar formulations to assess their performance throughout a heating/cooling cycle. The temperature at different heights within the interior of the screed mortars and at the surface were monitored. The results revealed that an improved screed mortar has a relevant impact on the efficiency of the system. Moreover, a three-dimensional transient heat transfer model was validated using the experimental data. The model was used to evaluate the impact of different finishing materials, namely wood, cork, ceramic, and linoleum, on the floor surface temperatures. The results showed differences of 15% in the surface temperature when using different floor finishing solutions. Full article

The lightweight floor system (LFS) with a heating coil is one of many types of radiant heating systems. It differs from most of the others, as it has a much higher thermal efficiency at low flow temperature. To verify whether adhesive mortars can safely connect the ceramic floor with the insulating substrate, the deformations and stresses values of all light system layers under thermal action should be checked and compared to their maximum strengths. For this purpose, an LFS test field was conducted using the strain gauges and digital measurement techniques, and floor displacements and deformations were determined. The results obtained from the tests were confirmed by finite element method calculations. It was also found that the stress of each floor component was much lower than their strength. This proves that the LFS with a heating coil, without metal lamellas, meets the safety regulation for use. The results of the analysis can be useful in the design of heated/cooled LFSs. Full article

Although the thermal mass of floors in buildings has been demonstrated to help shift cooling load, there is still a lack of information about how floor covering can influence the floor’s load shifting capability and buildings’ demand flexibility. To fill this gap, we estimated demand flexibility based on the daily peak cooling load reduction for different floor configurations and regions, using EnergyPlus simulations. As a demand response strategy, we used precooling and global temperature adjustment. The result demonstrated an adverse impact of floor covering on the building’s demand flexibility. Specifically, under the same demand response strategy, the daily peak cooling load reductions were up to 20–34% for a concrete floor whereas they were only 17–29% for a carpet-covered concrete floor. This is because floor covering hinders convective coupling between the concrete floor surface and the zone air and reduces radiative heat transfer between the concrete floor surface and the surrounding environment. In hot climates such as Phoenix, floor covering almost negated the concrete floor’s load shifting capability and yielded low demand flexibility as a wood floor, representing low thermal mass. Sensitivity analyses showed that floor covering’s effects can be more profound with a larger carpet-covered area, a greater temperature adjustment depth, or a higher radiant heat gain. With this effect ignored for a given building, its demand flexibility would be overestimated, which could prevent grid operators from obtaining sufficient demand flexibility to maintain a grid. Our findings also imply that for more efficient grid-interactive buildings, a traditional standard for floor design could be modified with increasing renewable penetration. Full article

Climate adaptation, mitigation, and protecting strategies are becoming even more important as climate change is intensifying. The impacts of climate change are especially tangible in dense urban areas due to the inherent characteristics of urban structure and materiality. To assess impacts of densification on urban climate and potential adaptation strategies a densely populated Viennese district was modeled as a typical sample area for the city of Vienna. The case study analyzed the large-scale densification potential and its potential effects on microclimate, air flow, comfort, and energy demand by developing 3D models of the area showing the base case and densification scenarios. Three methods were deployed to assess the impact of urban densification: Micro-climate analysis (1) explored urban heat island phenomena, wind pattern analysis (2) investigated ventilation and wind comfort at street level, and energy and indoor climate comfort analysis (3) compared construction types and greening scenarios and analyzed their impact on the energy demand and indoor temperatures. Densification has negative impacts on urban microclimates because of reducing wind speeds and thus weakening ventilation of street canyons, as well as accelerating heat island effects and associated impact on the buildings. However, densification also has daytime cooling effects because of larger shaded areas. On buildings, densification may have negative effects especially in the new upper, sun-exposed floors. Construction material has less impact than glazing area and rooftop greening. Regarding adaptation to climate change, the impacts of street greening, green facades, and green roofs were simulated: The 24-h average mean radiant temperature (MRT) at street level can be reduced by up to 15 K during daytime. At night there is only a slight reduction by a few tenths of 1 K MRT. Green facades have a similar effect on MRT reduction, while green roofs show only a slight reduction by a few tenths of 1 K MRT on street level. The results show that if appropriate measures were applied, negative effects of densification could be reduced, and positive effects could be achieved. Full article

The present study focuses on the application of large-format thermal ceramic conditioning panels (TCPs) containing polypropylene (PPR) capillary tube mats in dwellings on the Mediterranean coast. The thermal and energy behaviours were examined once the underfloor heating was installed, and they were compared with an alternative wall application. The system was implemented in a single-family house located on the Spanish Mediterranean coast. After having monitored the house during a complete one-year cycle, the annual energy demand was quantified using the Design Builder tool. TCP panels applied to radiant floors reduced energy demand by 5.15% compared to the wall-layout alternative. Significant reductions in CO₂ emissions were also achieved, as well as a 25.19% reduction in energy demand compared to convection systems. The incorporation of 24 m² of solar thermal panels into the system, combined with solar cooling systems based on lithium chloride, was also analysed. A reduction in energy demand of 57.46% was obtained compared to all-air convection systems. Finally, the amortisation periods of the investments in TCP panels and solar panels were calculated and compared to a convection system. Underfloor TCP panels proved to be more cost-effective than a wall installation. The additional cost of EUR 21,844 could be amortised over approximately 14 years with the radiant underfloor TCP system, while the wall TCP would be amortised over 17.4 years. Full article
