Search Results (108)

Aiming at the problems of low production efficiency and high manual dependence in the heat-sealing process of the pillow packaging machine, the existing optimization methods of process parameters were improved, and an intelligent decision-making model of the longitudinal sealing heat-sealing process based on the radial basis function neural network and orthogonal least square method was proposed to realize the efficient and accurate optimization of heat-sealing process parameters. By analyzing the fracture yield strength of the composite, the target heat-sealing strength range was determined. The heat-sealing temperature, heat-sealing speed, and heat-sealing plate distance were selected as key process variables, and the actual production data were used to train the model to accurately construct the nonlinear mapping relationship between heat-sealing process parameters and heat-sealing strength. On this basis, the genetic algorithm optimization framework with the model predictive output as the fitness function is designed to realize the rapid search of the optimal combination of process parameters. The optimization results were introduced into the pillow packaging machine for a verification test. The measured heat-sealing strength was stable within the target range. The maximum error of the optimization group was less than 10%, and the average error was less than 5%, which was significantly better than the effect of manual experience. The experimental results show that the proposed method can effectively improve the efficiency and consistency of process optimization under the premise of ensuring the quality of heat-sealing, meet the requirements of automatic production for high precision and low consumption of the heat-sealing process optimization, and realize the comprehensive improvement of efficiency, accuracy, and intelligent level in the longitudinal heat-sealing process of the pillow packaging machine. Full article

As terrestrial oil and gas resources continue to decline, deep-sea oil and gas development has become a strategic priority. A wide range of production equipment must be deployed on the seabed, among which subsea wet-mateable connectors are indispensable. To address the challenges of high pressure, low temperature, and corrosion in deep-sea environments, this study proposes a cooperative sealing strategy between the annular protrusion on the entry casing and a sliding sleeve. The leakage per single mate/demate cycle is quantified under varying insertion speeds and pressure differentials. By examining the effects of protrusion geometry, insertion speed, friction coefficient, and radial compression on sealing performance, the optimal parameters are identified: a friction coefficient of 0.15 and a trapezoidal-rib seal with 0.015 mm radial compression for dynamic sealing, yielding a contact pressure of 27.5 MPa and a mating/demating force of 197.26 N—satisfying the manipulation requirements of a remotely operated vehicle. Hydrostatic pressure tests demonstrate that the dynamic sealing design of the underwater connector achieves a balance between high reliability and low insertion resistance, and the prototype meets the operational requirements for deep-sea service. Full article

The secondary air system plays important roles in gas turbines, such as cooling hot-end components, sealing the rim, and balancing axial forces. In this paper, the flow structure and the heat transfer characteristics of the rotating disk cavity with two inlets and single outlet is studied by CFD (Computational Fluid Dynamics) approach. The effect and mechanism under higher rotational speed and larger mass flow rate are also discussed. The results show that a large-scale vortex is induced by the central inlet jet in the low-radius region of the cavity, while the flow structure in the high-radius region is significantly influenced by rotational speed and flow rate. Increasing the rotational speed generally enhances heat transfer because it amplifies the differential rotational linear velocity between the disk surface and nearby wall flow, consequently thinning the boundary layer. Increasing the mass flow rate enhances heat transfer through two primary mechanisms: firstly, it elevates the turbulence intensity of the near-wall fluid; secondly, the higher radial velocity results in a thinner boundary layer. Full article

Improving the thermal efficiency of internal combustion engines plays a crucial role in reducing fuel consumption and engine emissions. Studies have shown that the friction loss caused by the piston ring–cylinder liner pair accounts for approximately 30–40% of the engine’s total mechanical friction. The key to improving mechanical and thermal efficiency lies in reducing frictional losses through advanced solutions. However, as engine intensification increases, the growing thermal and mechanical loads lead to out-of-round deformation of the cylinder liner. This deformation reduces the sealing conformity of the piston rings, leading to increased blow-by and elevated particulate matter (PM) emissions. To address this, a dynamic–static deformation testing system for cylinder liners, combined with a multi-physics simulation for data validation, has been developed to achieve energy conservation and emission reduction in engines. Based on established strain gauge and eddy current displacement sensors, this study developed a dynamic deformation testing system, modified for a specific type of diesel engine, and analyzed the cylinder liner deformation under fired conditions. Test results show that under engine speeds ranging from 700 rpm to 1100 rpm, the overall radial out-of-roundness of the cylinder liner increased, with a maximum deformation of 49.2 μm. The second-order component of out-of-roundness also increases with speed, showing a maximum rise of 28.9 μm, while the third-order and fourth-order components exhibit relatively minor changes. These findings suggest that the overall radial deformation under fired conditions is mainly dominated by second-order out-of-roundness, with third-order and fourth-order components contributing marginally. Full article

This paper focuses on the sealing failure problem of double-lip seal rings for high-speed ball bearings used in unmanned aerial vehicles. By using ANSYS 2023R1 software, a thermal–stress–wear coupled finite element model was established. Taking the contact pressure and volume loss due to wear as indicators to evaluate sealing performance, this study analyzed the influence of lip seal structural parameters on sealing performance, performed response surface optimization of the seal structure parameters and conducted a comparative test on lip seals before and after optimization. The research results show that the contact pressure at the main lip of the lip seal was the greatest, which was 0.79 MPa, and the volume loss due to wear lip seal was 7.94 × 10⁻⁷ mm³. Optimal sealing performance is achieved when the seal lip inclination angle is 41.68°, the middle width of the lip seal is 0.153 mm, the main lip height is 0.179 mm, the spring center distance is 0.37 mm and the radial interference is 0.0034 mm. After optimization, the grease leakage rate of the sealing ring decreased by 48% compared to before optimization. Full article

This study examines the labyrinth seal disc of an aero-engine, specifically analysing the radial deformation caused by centrifugal force and heat stress during operation. This distortion may lead to discrepancies in the performance attributes of the labyrinth seal and could potentially result in contact between the labyrinth seal tip and neighbouring components. A numerical analytical model incorporating the rotor and stator cavities, along with the labyrinth seal disc structure, has been established. The sealing integrity of a standard labyrinth seal disc’s flow channel is evaluated and studied at different clearances utilising the fluid–solid-thermal coupling method. The findings demonstrate that, after considering radial deformation, a cold gap of 0.5 mm in the conventional labyrinth structure leads to stabilisation of the final hot gap and flow rate, with no occurrence of tooth tip rubbing; however, both the gap value and flow rate show considerable variation relative to the cold state. When the cold gap is 0.3 mm, the labyrinth plate makes contact with the stator wall. To resolve the problem of tooth tip abrasion in the conventional design with a 0.3 mm cold gap, two improved configurations are proposed, and a stability study for each configuration is performed independently. The leakage and temperature rise attributes of the two upgraded configurations are markedly inferior to those of the classic configuration at a cold gap of 0.5 mm. At a cold gap of 0.3 mm, the two improved designs demonstrate no instances of tooth tip rubbing. Full article

This study aims to elucidate the mechanisms by which tip seal leakage flow induces steam excitation, thereby enhancing the operational safety of steam turbines. Using numerical simulations, it investigates the detailed characteristics of the flow field in the turbine tip seal cavity. By introducing Boundary Vorticity Flux (BVF) into the tip seal flow field, this research explores the relationship between leakage vortex structures in non-uniform flow fields at the blade tip and the resulting steam excitation forces. The results demonstrate that, during eccentric rotor operation, the extent and intensity of vortices within the seal cavity vary, lead to changes in the BVF distribution along the shroud surface, which in turn alter the tangential forces and induce variations in lateral excitation force at the blade tip. Additionally, the non-uniform flow in the tip seal clearance induces circumferential pressure variations across the shroud, leading to adjustments in radial excitation force at the blade tip. Full article

As interest in liquid hydrogen (LH₂) continues to grow within the energy and mobility sectors, so does the demand for testing capabilities at deep cryogenics temperatures. However, cost-, complexity-, and safety-related challenges associated with handling LH₂ effectively limit the landscape of possible options. As an alternative, LH₂ temperatures can be accessed via a helium-based cryogenic refrigerator, or “cryocooler”. Recently, NASA and its partners CB&I and Shell began the development of a cryocooler-based calorimeter to characterize the thermal performance of insulations and other materials down to 20 K. Deemed the Guarded Hot Cylinder (GHC), the apparatus utilizes a small vacuum chamber in conjunction with a GM cryocooler and trim heater to control the cold boundary temperature. A sealed, cylindrical copper cup bolts to the cryocooler and houses the material specimen, with an internal, cylindrical test heater assembly to maintain the warm boundary. The steady-state heat load, traveling radially through the specimen, is measured via the electrical input power to the test heater and then used to evaluate the material’s absolute thermal performance. Initial checkout and validation of the GHC using a common bulk-fill insulation material showed close agreement with published data from standardized LN₂ boiloff calorimetry testing. The instrument is now considered a lab standard, with the goal of incorporating it into the ASTM C1774 standard in the future, and it is in continuous use, examining insulation materials for next-generation LH₂ applications. Full article

Coaxial sealing systems are increasingly used in the construction of hydraulic cylinders. In addition to the seal that ensures the actual packing of the entire system, the O-ring plays an important role in the functioning of the hydraulic subassembly. In order to understand the sealing phenomenon of coaxial systems, a physical and mathematical model of the contact between the O-ring and its contacting surfaces is required. Within this context, this paper presents a calculation method of the pressures generated in the contact areas of the O-ring with its adjacent surfaces, as well as of the widths of the contact areas. The input quantities for these calculations were certain material characteristics (hardness, elasticity modulus, and Poisson’s coefficient) of the sealed-off fluid pressure and the specific radial deformation, which is a characteristic that describes the mounting of the O-ring in its groove. This article concludes with recommendations for the mounting of the O-ring and the required characteristics of the used materials. Full article

A novel design of a proton exchange membrane electrolyzer is presented. In contrast to previous designs, the flow field plates are round and oriented horizontally with the feed water entering from a central hole and spreading evenly outward over the anode flow field in radial, interdigitated flow channels. The cathode flow field consists of a spiral channel with an outlet hole near the outside of the bipolar plate. This results in anode and cathode flow channels that run perpendicular to avoid shear stresses. The novel sealing concept requires only o-rings, which press against the electrolyte membrane and are countered by circular gaskets that are placed over the flow channels to prevent the membrane from penetrating the channels, which makes for a much more economical sealing concept compared to prior designs using custom-made gaskets. Hydrogen leaves the electrolyzer through a vertical outward pipe placed off-center on top of the electrolyzer. The electrolyzer stack is housed in a cylinder to capture the oxygen and water vapor, which is then guided into a heat exchanger section, located underneath the electrolyzer partition. The function of the heat exchanger is to preheat the incoming fresh water and condense the escape water, thus improving the efficiency. It also serves as internal phase separator in that a level sensor controls the water level and triggers a recirculation pump for the condensate, while the oxygen outlet is located above the water level and can be connected to a vacuum pump to allow for electrolyzer operation at sub-ambient pressure to further increase efficiency and/or reduce the iridium loading. Full article

Bentonite is widely used as an engineering barrier in radioactive waste disposal. This study examined the hydromechanical behavior and microstructural evolution of a bentonite mixture under controlled hydration, utilizing real-time X-ray micro-CT imaging to capture transitions from granular to dense homogeneous states. The results demonstrated that, during the early stages of hydration, bentonite pellets experienced substantial swelling, filling inter-pellet voids and transforming from a loosely packed granular structure to a compact, homogeneous matrix. This transformation significantly reduced the porosity from an initial value of 20% to below 0.1% after 60 days, thereby substantially lowering the material’s permeability. Particle displacement analysis, employing digital image correlation techniques, revealed axial displacements of up to 2.6 mm and radial displacements of up to 0.9 mm, highlighting pronounced void closure and structural reorganization. The study also examined the influence of initial dry density heterogeneities on swelling pressure and permeability, providing insights for optimizing barrier design. The findings affirm that hydrated bentonite serves as a highly effective low-permeability barrier for sealing deep geological repositories. Its capacity for environmental adaptation, demonstrated through self-healing and densification, further reinforces its suitability for critical and long-term engineering applications. Full article

In this study, the frictional behaviours of three different guide elements—guide rings, labyrinth seals, and hydrostatic bearings—in hydraulic cylinders is investigated experimentally. A modular, double-acting hydraulic cylinder was designed to compare these three different design elements under different pressures (0 bar, 120 bar, and 240 bar), velocities, and radial loads. The results show that the guide rings exhibit the highest friction, especially at high pressures. Labyrinth seals exhibit significantly lower friction and extend the service life of the components. Hydrostatic bearings allow low friction but require precise control of the fluid, which limits their use. The results provide practical guidelines for selecting guide elements and optimising the friction performance, durability, and efficiency of hydraulic systems. We found that the best solution from the points of view of design, friction, and economics is to use labyrinth seals as guiding elements for the fast reciprocal moving rods of hydraulic cylinders. Full article

Premature seal failure induced by the unevenness of interstage pressure distribution in multi-stage brush seals significantly compromises the sealing efficiency of Air-Turbo Rocket (ATR) engines operating under high-pressure (megapascal-level) differential conditions. Conventional pressure equalization designs for such seals often result in significant leakage rate increases. This study addresses the pressure imbalance phenomenon in four-tooth three-stage brush composite seals through a novel fractal–geometric porous-media model, rigorously validated against experimental data. Systematic investigations were conducted to elucidate the effects of structural parameters and operational conditions on both sealing performance and pressure distribution characteristics. Key findings reveal that, under the prototype structure parameter, the first-, second-, and third-stage brush bundles account for 18.3%, 30.0%, and 43.3% of the total pressure drop, respectively, with grate teeth contributing 8.4%, demonstrating an inherent pressure imbalance. Axial brush spacing exhibits a minimal impact on the pressure distribution, while the gradient thickness settings of the brush bundles show limited influence. Radial clearance optimization and gradient backplate height adjustment effectively regulate pressure distribution, albeit with associated leakage rate increases. Structural modifications based on these principles achieved only a 5.8% leakage increment while reducing the maximum bundle pressure drop by 23%, demonstrating effective pressure balancing. A simplified analysis of entropy reveals that the fundamental mechanism governing the pressure imbalance stems from non-uniform entropy generation caused by aerodynamic damping dissipation across sequential brush stages. These findings establish a dampened dissipation-based theoretical framework for designing high-performance multistage brush seals in aerospace applications, providing critical insights for achieving an optimal balance between leakage control and pressure equalization in extreme-pressure environments. Full article

Traditional static analysis cannot effectively explain the issue of the sealing performance of the premium connection being decreased due to the vibration of the tubing, leading to the failure of the connection sealing. In this paper, based on the energy dissipation theory and considering the influence of the micro contact slip of the sealing surface under the vibration of the tubing, a finite element model of the premium connection is established. The natural frequency and vibration mode are obtained through modal analysis experiments, and the accuracy of the finite element model is verified. The results show that the first five natural frequencies are mainly concentrated in the axial direction of the tubing, with the amplitude of the radial vibration mode being small. The vibration mode results are applied to the model as boundary conditions. It is found that an increase in the axial displacement amplitude leads to an increase in the energy dissipation of the sealing surface of the premium connection, which reduces the normal contact pressure and the effective length of the sealing surface, ultimately leading to a decrease in the sealing performance. Full article

The leakage characteristics and static stiffness of scallop damper seals have a significant impact on rotor vibration and stability. A parameter sensitivity analysis model for geometrical parameters in scallop damper seals was developed using a design of experiments (DOE) approach. The method employed a central composite design, integrating factorial, axial, and center points to assess non-linear effects efficiently. And the effects of radial clearance, cavity depth, and length–diameter ratios on leakage performance and rotor stability were investigated. The leakage rate, flow-induced force, and static stiffness coefficient for 15 different combinations of geometric parameters at eccentricities of 0.2 and 0.4 were numerically calculated. The results show that eccentricity has little effect on leakage and its parameter sensitivity. Larger cavity depths and length–diameter ratios are beneficial for seal leakage performance. The tangential force increases with increasing eccentricity but decreases with increasing radial clearance, while it first decreases and then increases with the increase in the cavity depth and length–diameter ratios. Additionally, the radial force decreases with the increase in the length-to-diameter ratio and increases first and then decreases with the increase in radial clearance. The parameter level in this study is defined as the ratio of the actual parameter value to the maximum parameter value. Static direct stiffness reaches its maximum value at a radial clearance level of 30.2%. It remains positive within a cavity depth range of 92.3~100%, as well as a length–diameter ratio range of 0~20.3%. The static cross-coupled stiffness gradually decreases with the increase in radial clearance but first decreases and then increases with the increase in the cavity depth or length–diameter ratio levels. The research results presented in this paper can serve as a reference for the analysis of the performance and design of scallop damper seals. Full article
