Search Results (18)

Hydrogen oxy-combustion with high CO₂ dilution is a key component of supercritical CO₂ (sCO₂) power cycles, such as the Allam cycle, enabling high-efficiency, near-zero-emission power generation with integrated carbon capture. However, combustion behavior under high-CO₂ conditions remains insufficiently characterized, particularly with respect to mixing and flame stability. In this study, hydrogen combustion in an O₂–CO₂ environment was investigated experimentally and numerically using a custom-designed multi-hole burner. The experiments were conducted in a 1-bar combustion chamber, while the inlet pressures of the reactants were varied between 10 and 50 bar to isolate the effect of injection conditions. Numerical simulations were performed to analyze flow, mixing, and flame structure. The results show that increasing inlet pressure leads to a more compact and localized flame, despite reduced velocity levels in the combustor due to increased reactant density. Higher inlet pressures result in increased peak temperatures but lower mean combustor temperatures, indicating more intense but spatially confined heat release. The flow field remains structurally similar across cases, while reduced radial spreading and longer residence times influence combustion behavior. Stable flame operation was achieved over a wide range of conditions, demonstrating the feasibility of hydrogen oxy-combustion under high CO₂ dilution. The combined experimental and numerical analysis provides insight into the interplay between injection conditions, mixing, and reaction rates in highly CO₂-diluted hydrogen combustion. The obtained results support the development of compact and stable direct-fired combustors for next-generation supercritical CO₂ power cycles and hydrogen-based low-emission energy systems. Full article

In magnetron sputtering-based gas aggregation sources, nanoparticle formation and yield are strongly influenced by the flow-regulated transport and residence time of particles within the condensation chamber. However, the effect of internal geometric parameters on flow structure and nanoparticle growth is not well understood. In this study, computational fluid dynamics (CFD) coupled with a discrete phase model (DPM) is employed to investigate how magnetron radius affects flow characteristics, particle transport, and their implications for nanoparticle formation. The results show that increasing the magnetron radius significantly enhances axial flow uniformity and suppresses vortex structures near the inlet. This shift from radial diffusion-dominated to primarily axial transport effectively reduces particle trapping and wall deposition. Furthermore, the regulation of flow structure modifies particle residence time distributions, which is considered a key factor associated with nanoparticle growth potential and size evolution in gas-phase synthesis. Larger magnetron radii promote more stable transport pathways and improve particle transmission efficiency, thereby improving particle transmission efficiency and providing more favorable conditions for nanoparticle formation. These findings indicate that geometric optimization can simultaneously enhance transport efficiency and influence the conditions potentially favorable for particle growth, providing valuable guidance for the design of high-yield nanoparticle synthesis systems. Overall, this work provides insight into how flow field characteristics influence nanoparticle transport and potential growth behavior, offering a foundation for optimizing magnetron sputtering-based nanoparticle synthesis. Full article

The utilization of hydrocyclones dates back more than a century. As the key channel for multiphase flow, the inlet chamber exerts a notable influence on the separation efficiency of hydrocyclones. Conventional feed bodies mainly adopt straight lines as guidelines. During the transition of fluid from linear motion to circumferential motion, significant kinetic energy loss and particle misalignment are exhibited, resulting in relatively low classification accuracy of the hydrocyclone. Therefore, in this study, a hydrocyclone featuring a complex curved inlet chamber structure was designed, and numerical analysis was employed to examine the particle distribution and aggregation characteristics within both the inlet chamber and the hydrocyclone. Supplemented with RSM/VOF/TFM simulations and quartz sand experimental validation, this study compares the separation performance of the complex curved inlet with the conventional linear inlet. The results indicate the following: when particle sizes are small, particles are dispersed throughout the hydrocyclone and inlet chamber, exhibiting a disordered state, which leads to poor classification performance. As particle size increases, particles gradually form layers along the radial direction; larger particles tend to accumulate on the hydrocyclone wall. When the particle concentration is maintained within a specific range, it promotes the migration of fine particles toward the center, thereby reducing the likelihood of fine particles entering the outer vortex and allowing for more precise classification of fine particles. As the particle concentration increases, the cutting ability of the hydrocyclone progressively diminishes; when the concentration exceeds 20%, the maximum underflow recovery rate for particles smaller than 50 µm is only 60%, resulting in significant coarse overflow and a notable decrease in classification precision. Furthermore, as the inlet concentration increases, the dispersion index for 0.5 µm particles ranges from 0.6 to 1.6, for 4 µm particles from 0.6 to 1.4, and for 60 µm particles from 0.6 to 1. The decreasing dispersion index indicates an increasing classification force, which aids in the formation of a coarse particle layer on the wall. The conclusions and data obtained provide a theoretical foundation and empirical support for the design of innovative inlet chamber structures. Full article

A centrifugal pump incorporating two inlets and a double-layered impeller is proposed for transporting a mixture of sand and water. The double-layered impeller (primary impeller) encircles a secondary impeller. To reveal the operating and flow characteristics of such a pump, numerical work is conducted with a validated numerical method. The effects of the feed rate of sand and the rotational speed of the impeller are investigated. The results show that the pump efficiency is not monotonically related to the solid volume fraction. At a feed rate of sand of 2.10 m³/min and a rotational speed of 950 rpm, the lowest pump efficiency is reached. In the volute chamber, vortices of various sizes are evidenced. With increasing rotational speed, the overall solid volume fraction in the pump decreases. Meanwhile, when the solid volume fraction attains 0.28, sand particles tend to accumulate near the outer rim of the volute chamber. The axial force acting on the primary impeller increases with the rotational speed. Under different operating conditions, the radial forces point unanimously toward the third and fourth quadrants. Full article

In this study, a comparative analysis of the shutdown transitions of a full-flow pump and an axial-flow pump was carried out through numerical simulation and model tests. The UDF method was used to achieve control of the impeller rotational speed during shutdown. The results show that during the shutdown transition, the rate of decline of rotational speed, flow rate, and torque of the axial-flow pump are greater than those of the full-flow pump, so the axial-flow pump stops faster than the full-flow pump. The axial force of the axial-flow pump is significantly lower than that of the full-flow pump, and the maximum value of the radial force of the axial-flow pump is approximately 1.14 times that of the full-flow pump. Due to the influence of the clearance backflow vortex, the impeller inlet and outlet of the full-flow pump generate clearance backflow vortices in the near-wall area, resulting in the overall flow pattern of the impeller chamber being worse than that of the axial-flow pump and the hydraulic loss being greater than that of the axial-flow pump. The runaway speed and flow rate of the axial-flow pump are higher than those of the full-flow pump. Due to the influence of the clearance backflow, the range of the high entropy production rate at the suction side of the impeller of the full-flow pump is always larger than that of the axial-flow pump. The research results in this paper can provide theoretical support for the selection and operation of pumps in large low-head pumping stations. Full article

The combustion characteristics of a swirl-radial-injection composite fuel grain were experimentally and numerically investigated. This composite grain permits swirl-radial oxidizer injection based on three hollow helical blades, each having a constant hollow space allowing uniform oxidizer injection into the main chamber along the axial direction. The oxidizer enters from channel inlets located along a hollow outer wall. This wall, together with the three blades, is fabricated as one piece from acrylonitrile-butadiene-styrene using three-dimensional printing. Paraffin-based fuel is embedded in the spaces between adjacent blades. Firing tests were conducted with gaseous oxygen as the oxidizer, using oxidizer mass flow rates ranging from 7.45 to 30.68 g/s. Paraffin-based fuel grains using conventional fore-end injection were used for comparison. Regression rate boundaries were determined taking into account the erosion of the oxidizer channels. The data show that the regression rate was significantly increased even at the lower limit. Images of the combustion chamber flame and of the exhaust plume were also acquired. The flame was found to be concentrated in the main chamber and a smoky plume was observed, consistent with the high regression rate. A three-dimensional simulation was employed. The present design was found to improve fuel/oxidizer mixing and combustion efficiency compared with a fuel grain using fore-end injection. Both the experimental results and numerical simulations confirmed the potential of this swirl-radial-injection fuel grain. Full article

The oblique flow compressor is one of the important components in the compressed air energy storage (CAES) system. The structural shape of the radial inlet chamber (RIC) directly affects the compressor performance, and a reasonable RIC design should achieve the smallest total pressure loss and outlet distortion as much as possible to meet the structural design. To study the influence of splitter blades, 4 RICs equipped with different numbers of splitter blades are designed, and the performance of 4 RICs and the overall performance of the compressor is calculated. The results show that with the increase in the number of splitter blades, the stall margin increases from 6.3% to 13.94%. At the design point, the isentropic efficiency is highest for the RIC with 17 splitter blades, and the pressure ratio is highest for the RIC with 11 splitter blades. Compared with the direct axial intake mode, the uniformity of the relative leakage distribution and the attack angle distribution of the impeller leading edge under 4 radial intake modes are poor. However, with an increase in the number of splitter blades, the uniformity of the relative tip leakage and the attack angle distribution gradually increase. The flow loss of RIC will increase simultaneously, though the uniformity of the outlet aerodynamic parameters distribution improves, and the influence on the downstream component performance gradually weakens. There is an optimal number of splitter blades in RIC, which balances the total pressure loss and distortion coefficient. Full article

Tangential leakage loss is the primary factor that significantly affects the output performance of oil-free scroll expanders. A scroll expander can function under different operating conditions, and the flow of tangential leakage and generation mechanism is different. This study employed computational fluid dynamics to investigate the unsteady flow characteristics of the tangential leakage flow of a scroll expander with air as the working fluid. Consequently, the effects of different radial gap sizes, rotational speeds, inlet pressures, and temperatures on the tangential leakage were discussed. The tangential leakage decreased with increases in the scroll expander rotational speed, inlet pressure, and temperature, and decreased with decrease in radial clearance. With an equal-proportional increase in radial clearance, the flow form of the gas in the first expansion and back-pressure chambers became more complicated; when the radial clearance increased from 0.2 to 0.5 mm, the volumetric efficiency of the scroll expander decreased by approximately 5.0521%. Moreover, because of the large radial clearance, the tangential leakage flow maintained a subsonic flow. Further, the tangential leakage decreased with increase in rotational speed, and when the rotational speed increased from 2000 to 5000 r/min, the volumetric efficiency increased by approximately 8.7565%. Full article

Combustion instability is the biggest threat to the reliability of liquid rocket engines, whose prediction and suppression are of great significance for engineering applications. To predict the stability of a combustion chamber with a hypergolic propellant, this work used the method of decoupling unsteady combustion and acoustic system. The turbulence is described by the Reynolds-averaged Navier–Stokes technique, and the interaction of turbulence and chemistry interaction is described by the eddy-dissipation model. By extracting the flame transfer function of the combustion field, the eigenvalues of each acoustic mode were obtained by solving the Helmholtz equation, thereby predicting the combustion stability for the combustion chamber. By predictions of the combustion chamber instability with different flow rate distributions, it was found that the increasing of inlet flow rate amplitude will improve the stability or instability of combustion. The combustion stability of the chamber was optimized when the flow rate distribution for the oxidant was set more uniform in the radial direction. The heterogeneity of the flow rate distribution in the circumferential direction is not recommended, considering that a homogeneous flow rate distribution in the circumferential direction is beneficial to the combustion stability of the chamber. Full article

The flow field and the efficiency of the compressor can be improved and increased by the guide vane in the radial inlet chamber. However, the guide vane generates the wake and results in the rotor–stator interaction, which threatens the safety of the impeller. This paper investigated the guide vane with a self-induced slot (SIS) in a radial inlet, and the self-induced slot was a passive flow control method. Through computational fluid dynamics (CFD) simulation, the radial inlet containing unevenly distributed guide vanes (UGVs) in the hydrogen compressor was studied to clarify the flow phenomenon in the radial inlet and the aerodynamic load on the impellers. The simulation results showed that the self-induced slot did not affect the compressor performance but improved the pure wake style to the weak wake near the shroud region. The aerodynamic load on the impeller leading edge was obtained under different radial inlets through unsteady simulation. The dominant frequency and the pulse amplitude of aerodynamic load were obtained by fast Fourier transforms (FFTs). The SIS model had lower amplitude values at the impeller passing frequency, and the reduction in amplitude was about 18% compared to the UGV model near the impeller shroud region. Full article

For a blood pump, the blood flow channel and impeller parameters directly affect the performance of the pump and the resulting blood circulation. The flow channel in particular has a great impact on the hydraulic performance of the pump (e.g., flow and pressure), which directly determines the overall performance of the blood pump. Traditional bearing-supported blood pumps can cause mechanical damage to blood cells, leading to hemolysis and thrombosis. In this study, therefore, we designed a conical spiral axial blood pump with magnetic levitation. The blood pump was supported by electrodynamic bearings in the radial direction and electromagnetic bearings in the axial direction. The impeller and the front and rear hubs were integrated to minimize blood stagnation and reduce the formation of thrombosis. The hub had a conical spiral flow channel design, which not only reduced the size of the impeller but also increased blood flow and pressure while meeting the design requirements. Computational fluid dynamics (CFD) analysis was used to analyze the flow field of the axial blood pump, a power function model was used to establish a hemolysis prediction model, and the particle tracking method was used to obtain the flow trajectories of individual blood cells, thereby predicting hemolysis-related performance of the blood pump. The simulation results showed that the main high shear stress area in the blood pump was located in the impeller inlet and the clearance between the top of the impeller and the inner chamber of the blood pump. When the hub taper angle of the blood pump was 0.72° and the clearance was 0.3 mm, the average hemolysis prediction value was 0.00216. This prediction value was smaller than that of traditional axial blood pumps. These findings can provide an important reference for the structural design of axial blood pumps and for reducing the hemolysis prediction value. Full article

This work deals with the numerical investigation of a three-dimensional, laminar hydrogen-air diffusion flame in which a cylindrical fuel jet is surrounded by in-flowing air. To calculate the distribution of gas molecules, the model solves the species conservation equation for N-1 components, using infinity fast chemistry and irreversible chemical reaction. The consideration of the component-specific diffusion has a strong influence on the position of the high-temperature zone as well as on the concentration distribution of the individual gas molecules. The calculations of the developed model predict the radial and axial species and temperature distribution in the combustion chamber comparable to those from previous publications. Deviations due to a changed burner geometry and air supply narrow the flame structure by up to 50% and the high-temperature zones merge toward the central axis. Due to the reduced inflow velocity of the hydrogen, the high-temperature zones develop closer to the nozzle inlet of the combustion chamber. As the power increases, the length of the cold hydrogen jet increases. Furthermore, the results show that the axial profiles of temperature and mass fractions scale quantitatively with the power input by the fuel. Full article

In view of the extensive application of swirl flow pipes (vortex tubes) in refrigeration systems, the parameters of swirl flow pipes were investigated to provide optimal cooling and heating conditions. Three-dimensional numerical simulations were carried out using available experimental data and models. The analysis verified that the heat pipe with a length of 175 mm performed better than the swirl flow pipe with a length of 125 mm, confirming experiments by Agrawal. Meanwhile, by comparing different pressures, it was found that in the single-nozzle swirl flow pipe, the greater the increase of pressure (0.1–1.0 MPa), the greater the burden on the vortex chamber and the more serious the wear is, which can be seen in the higher inlet pressure. In order to improve the durability of the swirl flow pipe, we suggest using a swirl flow pipe with more nozzles. Finally, according to the simulation results, with the rise of carbon dioxide pressure potential energy at the inlet, the cooling effect of the swirl flow is first increasing and then decreasing. When the swirl flow pipe is used as a refrigeration device to determine the minimum cooling temperature under the maximum pressure, the lowest temperature of the 125 mm swirl flow pipe was 252.4 K at 0.8 MPa, while the lowest temperature of the 175 mm swirl flow pipe was 246.0 K. Secondly, the distance from the inlet to the hot outlet of the swirl flow pipe had little effect on the cooling temperature and radial velocity, but increasing its distance increased the wall temperature of the swirl flow pipe because it increases the contact time between the airflow and the hot end of the tube wall. When the swirl flow pipe is used as a heat-producing device, increasing the tube length of the swirl flow pipe appropriately increases its maximum heat-producing temperature. Full article

This paper reports an experimental and numerical investigation of a methane-air diffusion flame stabilized over a swirler coaxial burner. The burner configuration consists of two tubes with a swirler placed in the annular part. The passage of the oxidant is ensured by the annular tube; however, the fuel is injected by the central jet through eight holes across the oxidizer flow. The experiments were conducted in a combustion chamber of 25 kW power and 48 × 48 × 100 cm³ dimensions. Numerical flow fields were compared with stereoscopic particle image velocimetry (stereo-PIV) fields for non-reacting and reacting cases. The turbulence was captured using the Reynolds averaged Navier-Stokes (RANS) approach, associated with the eddy dissipation combustion model (EDM) to resolve the turbulence/chemistry interaction. The simulations were performed using the Fluent CFD (Computational Fluid Dynamic) code. Comparison of the computed results and the experimental data showed that the RANS results were capable of predicting the swirling flow. The effect of the inlet velocity ratio on dynamic flow behavior, temperature distribution, species mass fraction and the pollutant emission were numerically studied. The results showed that the radial injection of fuel induces a partial premixing between reactants, which affects the flame behavior, in particular the flame stabilization. The increase in the velocity ratio (R_v) improves the turbulence and subsequently ameliorates the mixing. CO emissions caused by the temperature variation are also decreased due to the improvement of the inlet velocity ratio. Full article

Radial inlet chambers are widely used in various multistage centrifugal compressors, although they induce extra flow loss and inlet distortions. In this paper, the detailed flow characteristics inside the radial inlet chamber of an industrial centrifugal compressor have been numerically investigated for flow control and performance improvement. First, the numerical results are validated against the experimental data, and flow conditions inside the inlet chambers with different structures are compared. They indicate that, in the non-guide vane scheme, sudden expansions, tangential flows and flow separations in the spiral and annular convergent channels are the major causes of flow loss and distortions, while using guide vanes could introduce additional flow impacts, separations and wakes. Based on the flow analysis, structure improvements have been carried out on the radial inlet chamber, and an average increase of 4.97% has been achieved in the inlet chamber efficiencies over different operating conditions. However, the results further reveal that the increases in the performance and overall flow uniformity just in the radial inlet chamber do not necessarily mean a performance improvement in the downstream components, and the distribution of the positive tangential velocity at the impeller inlet might be a more essential factor for the efficiency of the whole compressor. Full article
